2A5HQ-C2160Lightstrike

Parts Included:TRUNK LIGHT ASSEMBLY 6 CABLE TIES Installa�on Instruc�ons: WARNING: This indication alerts you to the fact that ignoring the contents described herein can result in potential serious injury or death if not followed. CAUTION: This indication alerts you to the fact that ignoring the contents described herein can or will result in material damage and/or personal injury. ATTENTION: This indication alerts you to the fact if you ignore this detail you will aect the performance or functionality of the product. All Ciro products are designed for "easy assembly" and/or "plug and play". We recommend a competent mechanic install our products, using standard mechanical procedures to assure a safe and successful installation. 1. Park on a level surface and shut off the motorcycle. Li� the motorcycle onto its center stand if available. Ensure the engine has �me to cool before installa�on. 2. Clean the surface where the Goldstrike LED Trunk Light installs with hot water and soap. 3. Open the saddlebags and remove side covers below the seat by pulling away from the motorcycle with steady pressure. 4. Remove the seat by removing the socket head screws under the front of the seat. Pull up on the front of the seat and slide forward. 5. Install Goldstrike P/N 48000 (sold separately). Plug in the Goldstrike Trunk Light to familiar- ize yourself with connector loca�ons, the lights, and how they func�on. The right side has a blue wire, le� side has orange. Unplug the light and set aside. FIG.6 6. Open the trunk then remove the screw near the hinge that secures the backrest pad. One screw per side. Circled in blue. FIG.1 7. Remove the trunk lid latches. Note their posi�on for reinstalla�on. Circled in yellow. FIG.2 8. Remove the remaining back rest screws from inside the trunk. Then disconnect the backrest heater plug, unclip the harness and set the backrest aside. Circled in blue. FIG.2 9. Remove the six screws holding the trunk lid to the hinges. Three per side. Move the trunk lid to a workbench. Use a blanket or towel to protect the paint. FIG.3 NOTE: Ciro products are designed and manufactured under very strict quality control. Ciro warrants that products sold to the original purchaser shall be free from any defects in materials and workmanship for a period of 3 (three) years from the date of purchase, and a lifetime warranty against LED failure. Ciro will have no obligation if the customer cannot show proof of purchase. Warranty will not be granted unless the part is properly installed and maintained. Ciro will not be liable for any consequential and incidental damages, including labor, or non-Ciro products. Please visit our website Ciro3d.com for our complete warranty policy. Installa�on Instruc�ons: G0048024, REV. - LIGHTSTRIKE FIG. 1 FIG. 2 G0048024, REV. - Page 2 with LIGHTSTRIKE 10. Remove the seven remaining screws to separate the painted outer trunk lid from the inner. Set the inner aside. Circled in red. FIG.2 11. Place a piece of masking tape over the center of the outer lid. Measure 1 1/2 inch (38mm) down from the top edge and mark a horizontal line. Mark the center. FIG.4 12. Drill a small pilot hole then use a step drill to open the hole up to 9/16 inch (40mm). FIG.4 13. Clean the surface where the Trunk Light installs. ATTENTION: Thoroughly clean the moun�ng surface with denatured alcohol to remove all wax, oil, and residue. NOTE: New motorcycles are delivered from the factory covered in protec�ve oil. Remove it before installing this product. NOTE: Do not install if the temperature is below 50° F. The adhesive will not cure properly. 1.5” c L 1.5” c L 14. Insert the wires from the Goldstrike LED Trunk Light and test fit its placement. It is designed to sit 1-2mm below the top surface of the trunk lid. When you have the light in the correct loca�on mark the edges with masking tape. 15. Peel off the adhesive backing and carefully s�ck the LED Trunk Light using your tape marks as a guide. Press and hold for 30 seconds. 16. Tape the wire to the the inside of the trunk lid and out the rectangular hole on the center. Rein- stall the trunk lid liner and put the lid back on the motorcycle. FIG. 1-2-3 17. Route the LED Trunk Light wire along the same path as the backrest heater cable, behind the speaker grills into the under seat area. Check that the wires will not be pinched and secure it with zip �es. FIG.5 18.Plug the LED Trunk Light connectors into the Goldstrike P/N 48000 matching the color of the wire to the correct side. The right side has a blue wire, le� side has orange. FIG.6 19. Test the LED Trunk Light for correct func�ons. run turn and brake. Reinstall the backrest, side covers and seat. 20. To use Lightstrike Technology follow the included instruc�ons. FIG. 3 FIG. 4 FIG.5 FIG.6 Lightstrike Technology uses your smartphone and Bluetooth to control this product. 1) Download the Lightstrike app where you get your iOS or Android phone apps. 2) The default password is 000000 (six zeros). 3) For additional information and video scan the QR code. Lightstrike Technology uses your smartphone and Bluetooth to control this product. 1) Download the Lightstrike app where you get your iOS or Android phone apps. TM Page 3 G0048024, REV. - L R FCC Statement Changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment. This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio…

Text truncated - open the document above for the full version.

CiroCorporation OfficeofEngineeringTechnology FederalCommunicationsCommission 7435OaklandMillsRoad Columbia,MD21046 USA Date:2022-04-27 Subject;RequestforLongTermConfidentiality FCCID:2A5HQ-C2160 ToWhomItMayConcern, PursuanttotheprovisionsoftheCommission’srulesTitle47Sections§0.457and§0.459,we arerequestingtheCommissiontowithholdthefollowingattachment(s)asconfidential documentsfrompublicdisclosureindefinitely. Thesedocumentscontaindetailedsystemandequipmentdescriptionsandareconsideredas proprietaryinformationinoperationoftheequipment.Thepublicdisclosureofthesedocuments mightbeharmfultoourcompanyandwouldgivecompetitorsanunfairadvantageinthemarket. SchematicDiagram BlockDiagram PartsList OperationalDescription Tune-upProcedure Itisourunderstandingthatallmeasurementtestreports,FCCIDlabelformatand correspondenceduringthecertificationreviewprocesscannotbegrantedasconfidential documentsandthisinformationwillbeavailableforpublicreviewoncethegrantofequipment authorizationisissued. Sincerely, Signature: Name:ThomasLEllsworth Title:ExecutiveVicePresident

CiroCorporation 1310GatewayCircle,Hudson,WISCONSIN54016 Statement Product:Lightstrike Model:C2160(48024/48025) AdditionalModel:C2147(40153/40154/40173/40174),C2175(40104/40105/40114/40115), C2015(28201/28221),C2145(48014/48015),C2177(40256/40258/40253/40254), C176(41031)(41032)(41035),C1809(48031) Trademark:Ciro WeherebystatethatAllmodelsaboveareidenticalininteriorstructure,electricalcircuitsand components,andjustmodelnamesaredifferentforthemarketingrequirement. Yourassistanceonthismatterishighlyappreciated. Yourssincerely, Signature: Date:2022/04/27 Name:ThomasLEllsworth CompanyName:CiroCorporation Address:1310GatewayCircle,Hudson,WISCONSIN54016 Tel/Fax:7158080027/N/A E-Mail:[email protected]

CiroCorporation 1310GatewayCircle,Hudson,WISCONSIN54016 AgentAuthorization Company:CiroCorporation Address:1310GatewayCircle,Hudson,WISCONSIN54016 ProductName:Lightstrike ModelNumber(s):C2160(48024/48025),C2147(40153/40154/40173/40174), C2175(40104/40105/40114/40115),C2015(28201/28221), C2145(48014/48015),C2177(40256/40258/40253/40254), C176(41031)(41032)(41035),C1809(48031) ProductDescription:Lightstrike WeauthorizeMiCOMLabsInc.,575BoulderCourt,Pleasanton,California94566,USA, toactonourbehalfonallmattersconcerningthecertificationofabovenamed equipment. WedeclarethatMiCOMLabsInc.isallowedtoforwardallinformationrelatedtothe approvalandcertificationofequipmenttotheregulatoryagenciesasrequiredandto discussanyissuesconcerningtheapprovalapplication.Anyandallactscarriedoutby MiCOMLabsonourbehalfshallhavethesameeffectasactsofourown. Signature:Date:2022-04-27 Name: ThomasLEllsworth Title: ExecutiveVicePresident Company: CiroCorporation

Page 1 of 2 Appendix C: Photographs of EUT Product: Lightstrike Model: C2160(48024/48025) External Photos Page 2 of 2

Page 1 of 2 Appendix C: Photographs of EUT Product: Lightstrike Model: C2160(48024/48025) Internal Photos Page 2 of 2 Antenna

Hotline: 400-6611-140 Tel: 86-755-27673339 Fax: 86-755-27673332 http://www.tct-lab.com TEST REPORT FCC ID. ............................ : 2A5HQ-C2160 Test Report No. ............... : TCT220303E015 Date of issue ................... : Mar. 14, 2022 Testing laboratory .......... : SHENZHEN TONGCE TESTING LAB Testing location/ address: TCT Testing Industrial Park Fuqiao 5th Industrial Zone, Fuhai Street, Bao'an District Shenzhen, Guangdong, 518103, People's Republic of China Applicant's name ............ : Ciro Corporation Address ........................... : 1310 Gateway Circle, Hudson, WISCONSIN 54016 Manufacturer's name ... : Ciro Corporation Address ........................... : 1310 Gateway Circle, Hudson, WISCONSIN 54016 Standard(s) ..................... : FCC CFR Title 47 Part 1.1307 Product Name ................. : Lightstrike Trade Mark ...................... : Ciro Model/Type reference..... : C2160(48024/48025), C2147(40153/40154/40173/40174), C2175(40104/40105/40114/40115), C2015(28201/28221), C2145(48014/48015), C2177(40256/40258/40253/40254), C176(41031)(41032)(41035), C1809(48031) Rating(s).......................... : DC 12V Date of receipt of test item ......................................... : Mar. 03, 2022 Date (s) of performance of test ................................... : Mar. 03, 2022 - Mar. 14, 2022 Tested by (+signature) ... : Onnado YE Check by (+signature) .... : Beryl ZHAO Approved by (+signature): Tomsin General disclaimer: This report shall not be reproduced except in full, without the written approval of SHENZHEN TONGCE TESTING LAB. This document may be altered or revised by SHENZHEN TONGCE TESTING LAB personnel only, and shall be noted in the revision section of the document. The test results in the report only apply to the tested sample. Report No.: TCT220303E015 Page 2 of 6 Hotline: 400-6611-140 Tel: 86-755-27673339 Fax: 86-755-27673332 http://www.tct-lab.com Table of Contents 1. General Product Information .................................................................. 3 1.1. EUT description ..................................................................................................... 3 1.2. Model(s) list ............................................................................................................ 3 2. General Information ................................................................................. 4 2.1. Test environment and mode ................................................................................. 4 2.2. Description of Support Units ................................................................................ 4 3. Facilities and Accreditations .................................................................. 5 3.1. Facilities ................................................................................................................. 5 3.2. Location ................................................................................................................. 5 4. Test Results and Measurement Data ..................................................... 6 Report No.: TCT220303E015 Page 3 of 6 Hotline: 400-6611-140 Tel: 86-755-27673339 Fax: 86-755-27673332 http://www.tct-lab.com 1. General Product Information 1.1. EUT description Product Name ....................... : Lightstrike Model/Type reference........... : C2160(48024/48025) Sample Number....................: TCT220303E006-0101 Operation Frequency ........... : 2408MHz~2468MHz Modulation Type ................... : GFSK Antenna Type ........................ : PCB Antenna Antenna Gain ........................ : 0dBi Rating(s)................................ : DC 12V Note: The antenna gain listed in this report is provided by applicant, and the test laboratory is not responsible for this parameter. 1.2. Model(s) list No. Model No. Tested with 1 C2160(48024/48025) Other models C2147(40153/40154/40173/40174), C2175(40104/40105/40114/40115), C2015(28201/28221), C2145(48014/48015), C2177(40256/40258/40253/40254), C176(41031)(41032)(41035), C1809(48031) Note: C2160(48024/48025) is tested model, other models are derivative models. The models are identical in circuit and PCB layout, only different on the model names. So the test data of C2160(48024/48025) can represent the remaining models. Report No.: TCT220303E015 Page 4 of 6 Hotline: 400-6611-140 Tel: 86-755-27673339 Fax: 86-755-27673332 http://www.tct-lab.com 2. General Information 2.1. Test environment and mode Item Normal condition Temperature +25ºC Voltage DC 12V Humidity 56% Atmospheric Pressure: 1008 mbar Test Mode: Engineering mode: Keep the EUT in continuous transmitting by select channel 2.2. Description of Support Units The EUT has been tested as an independent unit together with other necessary accessories or support units. The following support units or accessories were used to form a representative test configuration during the tests. Equipment Model No. Serial No. FCC ID Trade Name / / / / / Note: 1. All the equipment/cables were placed in the worst-case configuration to maximize the emission during the test. 2. Grounding was established in accordance with the manufacturer’s requirements and conditions for the intended use. 3. For conducted measurements (Output Power, 20dB Occupied Bandwidth, Carrier Frequencies Separation, Hopping Channel Number, Dwell Time, Spurious Emissions), the antenna of EUT is connected to the test equipment via temporary antenna connector, the antenna connector is soldered on the antenna port of EUT, and the temporary antenna connector is listed in the Test Instruments. Report No.: TCT220303E015 Page 5 of 6 Hotline: 400-6611-140 Tel: 86-755-27673339 Fax: 86-755-27673332 http://www.tct-lab.com 3. Facilities and Accreditations 3.1. Facilities The test facility is recognized, certified, or accredited by the following organizations: ● FCC - Registration No.: 645098 SHENZHEN TONGCE TESTING LAB Designation Number: CN1205 The testing lab has been registered and fully describe…

Text truncated - open the document above for the full version.

Hotline: 400-6611-140 Tel: 86-755-27673339 Fax: 86-755-27673332 http://www.tct-lab.com TEST REPORT FCC ID. ............................ : 2A5HQ-C2160 Test Report No. ............... : TCT220303E006 Date of issue ................... : Mar. 14, 2022 Testing laboratory .......... : SHENZHEN TONGCE TESTING LAB Testing location/ address: TCT Testing Industrial Park Fuqiao 5th Industrial Zone, Fuhai Street, Bao'an District Shenzhen, Guangdong, 518103, People's Republic of China Applicant's name ............ : Ciro Corporation Address ........................... : 1310 Gateway Circle, Hudson, WISCONSIN 54016 Manufacturer's name ... : Ciro Corporation Address ........................... : 1310 Gateway Circle, Hudson, WISCONSIN 54016 Standard(s) ..................... : FCC CFR Title 47 Part 15 Subpart C Section 15.247 FCC KDB 558074 D01 15.247 Meas Guidance v05r02 ANSI C63.10:2013 Product Name ................. : Lightstrike Trade Mark ...................... : Ciro Model/Type reference..... : C2160(48024/48025), C2147(40153/40154/40173/40174), C2175(40104/40105/40114/40115), C2015(28201/28221), C2145(48014/48015), C2177(40256/40258/40253/40254), C176(41031)(41032)(41035), C1809(48031) Rating(s).......................... : DC 12V Date of receipt of test item ......................................... : Mar. 03, 2022 Date (s) of performance of test ................................... : Mar. 03, 2022 - Mar. 14, 2022 Tested by (+signature) ... : Onnado YE Check by (+signature) .... : Beryl ZHAO Approved by (+signature): Tomsin General disclaimer: This report shall not be reproduced except in full, without the written approval of SHENZHEN TONGCE TESTING LAB. This document may be altered or revised by SHENZHEN TONGCE TESTING LAB personnel only, and shall be noted in the revision section of the document. The test results in the report only apply to the tested sample. Report No.: TCT220303E006 Page 2 of 45 Hotline: 400-6611-140 Tel: 86-755-27673339 Fax: 86-755-27673332 http://www.tct-lab.com Table of Contents 1. General Product Information .................................................................. 3 1.1. EUT description ..................................................................................................... 3 1.2. Model(s) list ............................................................................................................ 3 1.3. Operation Frequency ............................................................................................ 3 2. Test Result Summary .............................................................................. 4 3. General Information ................................................................................. 5 3.1. Test environment and mode ................................................................................. 5 3.2. Description of Support Units ................................................................................ 5 4. Facilities and Accreditations .................................................................. 6 4.1. Facilities ................................................................................................................. 6 4.2. Location ................................................................................................................. 6 4.3. Measurement Uncertainty ..................................................................................... 6 5. Test Results and Measurement Data ..................................................... 7 5.1. Antenna requirement ............................................................................................ 7 5.2. Conducted Emission ............................................................................................. 8 5.3. Conducted Output Power ..................................................................................... 9 5.4. Emission Bandwidth ........................................................................................... 10 5.5. Power Spectral Density ....................................................................................... 11 5.6. Conducted Band Edge and Spurious Emission Measurement ....................... 12 5.7. Radiated Spurious Emission Measurement ...................................................... 14 Appendix A: Test Result of Conducted Test Appendix B: Photographs of Test Setup Appendix C: Photographs of EUT Report No.: TCT220303E006 Page 3 of 45 Hotline: 400-6611-140 Tel: 86-755-27673339 Fax: 86-755-27673332 http://www.tct-lab.com 1. General Product Information 1.1. EUT description Product Name ....................... : Lightstrike Model/Type reference........... : C2160(48024/48025) Sample Number....................: TCT220303E006-0101 Bluetooth Version ................ : V5.0 Operation Frequency ........... : 2402MHz~2480MHz Channel Separation .............. : 2MHz Data Rate ............................... : LE 1M PHY Number of Channel .............. : 40 Modulation Type ................... : GFSK Antenna Type ........................ : PCB Antenna Antenna Gain ........................ : 0dBi Rating(s)................................ : DC 12V Note: The antenna gain listed in this report is provided by applicant, and the test laboratory is not responsible for this parameter. 1.2. Model(s) list No. Model No. Tested with 1 C2160(48024/48025) Other models C2147(40153/40154/40173/40174), C2175(40104/40105/40114/40115), C2015(28201/28221), C2145(48014/48015), C2177(40256/40258/40253/40254), C176(41031)(41032)(41035), C1809(48031) Note: C2160(48024/48025) is tested model, other models are derivative models. The models are identical in circuit and PCB layout, only different on the model names. So the test data of C2160(48024/48025) can represent the remaining models. 1.3. Operation Frequency Channel Frequency Channel Frequency Channel Frequency Channel Frequency 0 2402MHz 10 2422MHz 20 2442MHz 30 2462MHz 1 2404MHz 11 2424MHz 21 2444MHz 31 2464MHz ... ... ... ... ... ... …

Text truncated - open the document above for the full version.

Page 1 of 1 Appendix B: Photographs of Test Setup Product: Lightstrike Model: C2160(48024/48025) Radiated Emission
