2A5KC-B5019150ft Bluetooth LED Strip Lights Kit

I 5050 LED STRIP LIGHTS User Manual b. 44 keys Remote control (§) ON/OFF 。 Pause/Run Ligheing Mode & 9 Brightness Adjustment . . . . .. . . . . . . . . . Color Change 0。00 00 Color Degree Increase/Decrease � " f, - E, E, DIV Mode ee 3/7 Colors Jumping Change ee 3 /7 Colors Cross Fade e Flash Mode e Automatically Change Colors and Modes e Speed of Color Changing 。 .. Four music modes r. Specifications LED type 5050 RGB LED quantity 270PCS Output power 36W Input voltage of adapter AC100v-240v Output voltage of adapter DC 24V Remote distance within 5M Packing List 50ft LED Strip Lights 1 Controller Box 1 44-KEY IR remote Control 1 Power Adapter 1 I Instruction Manual 1 Inst『uctions 1 Installation a h O e p th e e n 1 the pack p a l g ig e h a t nd spread the n s d tri a p l strai ght.Please check w r the stri a h p e pea『ancea I parts are in good condition Then power t strip light to test whethe『it could light normally . b Clean the surface of the o n r i a e d b h j t e l t h i s q c e t w u li w i i d g ll h h w f a e t re il a ll l d o a t h h f f ff e e e re ct st m r t i h p u e s n t s e t b e ic e d k s s in m t e o o s b s o e t o h f in a s n ta d lled and e k s e iv e e p . T it h d e r y s . u A 『 n fa y c d e u w st h a ad h e clean, otherwise the stri p I g o f f. Warning 1. Please pay attention to anti-static during the installation and use of the product. Do not use sharp objects to touch the product, and avoid contact with strong chemicals such as strong acid and alkali. 2. There is no hidden nail or metal conductive object in the contact part between the lamp and the wall. If there is,remove or avoid the conductive object in advance to prevent unnecessary short-circuit of the led light strip. 3.The working voltage of the lighting is 100-240V, please do not make the working voltage of the lighting exceed the maximum allowable range. Please do not exceed the length more than 32.8ft on each port connection Customer Service We are looking forward to provide the perfect services for you,and will pay attention to your feedback. Should you have any question,please give me the letter via [email protected] c Tear off the ad hesive tap fi e r , m pa l 1 ste the strip on the correct place at once time Press the strip l y from the beginning to the end to remove the air from the strip and the surface of the object. (Notice: Do not move the strip light to other place after it 1s attached.) d 1 r n e .C f l in o u fo e n n s rc i c d e e e , y i r t. i o n I u g f the p g l r a a c v e it y a of the st n p : h light the mself and othe r can clip to eac section of the st there is a corner, place the clips on each ri s p id l e ig o h f t t t h o e right angle e. The installation is over, please connect the power with strip light. You can switch the light on/off and choose the color effect using the control box or remote or AP�Enjo y y our new strip light! 甘 严 "\I I / 厂 勹 ｀ Test Clean Paste 勹 � 勹 Press firmly connect Light up Thank you for purchasing our products, please read the instructions carefully before use Keepsmile is a brand dedicated to the development of high-end Led light strips. The company is equipped with a professional Led light strips development team and production plant. Keepsmile·s products will deffnitely add a lot of fun to your life. We are always striving to provide customers with quality products and the most satisfactory service. 2 Use a APP control 回 (!)APP name is "Keepsm1le" Please search ., for and install the r a v p i phcat1on 1n Google h p e la y and Apple store o a the QR cod e on t manual/controller @Connecting power with the device to let 回 the light on first, then open the blue tooth of y our smart phone @Then strip lights automaticall y connect to the APP I f y , t o h u e have n a g n - y G q u u id e e st i i n ons ab out the use of the APP, he y o A u P can refer to t e Sett1 the upper right corner of t P 1nte「face Note: 105 8 0 or And roid 4 3 or late「ed 1t1onre q uired Your smart device should support bluetooth 4.0 or later version Functions are listed as fillows: 1 Color fo :An djust the color and brigheness,16 million kinds of colors your choice 2.Mus,c:When you play the mus,c,the hght strip w,11 sync with the music and change the color and flashing speed, 3 iR ll h c y h thm Built-in high-sensitivity microphone,the light strip w1 change the color and speed according to the volume of sound source and the speed of speaking, 4 Scene Multiple modes to choose from,including strobe, stat,c,gradual,fade.You can choosr the right mode according to the atmoaphere; 5.Timer Set the timer,the light will turn on/off according to your schedule & WARNING • The battery case and receiver do not immerse in water. • The LED sriip light kit do not immerse in fire • Childern unde age of 16 should use this product adult supervision 三 CE芘么 凸互 FCC Warning Statement Changes or modifications not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment. This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: ‐‐ Reorient or relocate the receiving antenna. ‐‐ Increase the separation between the equipment and receiver. ‐‐ Connect the equipment into an outlet on a circuit different from that to w…

Text truncated - open the document above for the full version.

< Shenzhen Zeri E-commerce Co., Ltd. > Office of Engineering Technology Federal Communications Commission 7435 Oakland Mills Road Columbia, MD21046 Date: Apr. 02, 2022 Subject; Request for Long Term Confidentiality FCC ID: 2A5KC-B5019 To Whom It May Concern, Pursuant to the provisions of the Commission’s rules Title 47 Sections §0.457 and §0.459, we are requesting the Commission to withhold the following attachment(s) as confidential documents from public disclosure indefinitely. These documents contain detailed system and equipment descriptions and are considered as proprietary information in operation of the equipment. The public disclosure of these documents might be harmful to our company and would give competitors an unfair advantage in the market. Schematic Diagram Block Diagram Parts List Operational Description Tune-up Procedure It is our understanding that all measurement test reports, FCC ID label format and correspondence during the certification review process cannot be granted as confidential documents and this information will be available for public review once the grant of equipment authorization is issued. Sincerely, Signature: Name: Tony Chow Title: Manager

Shenzhen Zeri E-commerce Co., Ltd. Letter of Authorization Company: Shenzhen Zeri E-commerce Co., Ltd. Address: RM 2404,BLDG 1,Asia Steel Industry & Trade BLDG,No.18,Fuan,Hehua,Pinghu, Shenzhen,China Product name: 150ft Bluetooth LED Strip Lights Kit Trade name: Jerritte Model name: B5019,B5011,B5012,B5013,B5014,B5015,B5016,B5017,B5018,B501A, B501B,B501C,B501D,B501E,B501F FCC Identifier: 2A5KC-B5019 We authorize MiCOM LabsInc, 575 Boulder Court, Pleasanton, California94566, USA, to act on our behalf on all matters concerning the above named equipment. Any individual within MiCOM Labs is authorized to act on our behalf and take action on the application. We declare that MiCOM LabsInc, 575 Boulder Court, Pleasanton, California 94566, USA, is allowed to forward all information related to the approval project to the Federal Communication Commission and to discuss any issues concerning the approval application. Any and all acts carried out by MiCOM Labs on our behalf shall have the same effect as acts of our own. Name: Tony Chow Date: Apr. 02, 2022 Title: Manager Signature of applicant:

Model Difference Declaration To Whom It May Concern, We, Shenzhen Zeri E-commerce Co., Ltd. Product: 150ft Bluetooth LED Strip Lights Kit Trade Name: Jerritte Model Number: B5019,B5011,B5012,B5013,B5014,B5015,B5016,B5017, B5018,B501A, B501B,B501C,B501D,B501E,B501F All model’s the function, software and electric circuit are the same, only with a product color and model named different. Test sample model: B5019. Please contact me if you have any question. Name: Tony Chow Date: Apr. 02, 2022 Title: Manager Signature of applicant:

Model: B5019 Model: B5019 Model: B5019 Model: B5019

Model: B5019 Model: B5019 Model: B5019 Model: B5019

FCC ID LABEL: Label Location: FCC ID: 2A5KC-B5019 Product Name: 150ft Bluetooth LED Strip Lights Kit Model Name: B5019 This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1)This device may not cause harmful interference, and (2)This device must accept any interference received, including interference that may cause undesired operation. Long: 3cm Width: 2cm

Model: B5019 Model: B5019 Model: B5019 PCB Antenna

Page 1 of 30 Report No.: UNIA22022605ER-61 FCC RADIO TEST REPORT FCC ID: 2A5KC-B5019 Sample： 150ft Bluetooth LED Strip Lights Kit Trade Name： Jerritte Main Model： B5019 Additional Model： B5011,B5012,B5013,B5014,B5015, B5016,B5017,B5018,B501A,B501B, B501C,B501D,B501E,B501F Report No.： UNIA22022605ER-61 Prepared for Shenzhen Zeri E-commerce Co., Ltd. RM 2404,BLDG 1,Asia Steel Industry & Trade BLDG,No.18,Fuan, Hehua,Pinghu,Shenzhen,China Prepared by Shenzhen United Testing Technology Co., Ltd. 2F, Annex Bldg, Jiahuangyuan Tech Park, #365 Baotian 1 Rd, Tiegang Community, Xixiang Str, Bao'an District, Shenzhen, China Page 2 of 30 Report No.: UNIA22022605ER-61 TEST RESULT CERTIFICATION Applicant .............................. : Shenzhen Zeri E-commerce Co., Ltd. Address ................................. : RM 2404,BLDG 1,Asia Steel Industry & Trade BLDG,No.18,Fuan, Hehua,Pinghu,Shenzhen,China Manufacturer ........................ : Huaxin (Dongguan) Technology Co., Ltd. Address ................................. : Building 4, No. 11, Fumin Road, Tangli, Fenggang Town, Dongguan City, Guangdong Province Product description Product ....................................... : 150ft Bluetooth LED Strip Lights Kit Trade Name ........................... : Jerritte Model Name .......................... : B5019,B5011,B5012,B5013,B5014,B5015,B5016,B5017,B5018, B501A,B501B,B501C,B501D,B501E,B501F Test Methods ........................ : FCC Rules and Regulations Part 15 Subpart C Section 15.249, ANSI C63.10: 2013 This device described above has been tested by Shenzhen United Testing Technology Co., Ltd., and the test results show that the equipment under test (EUT) is in compliance with the FCC requirements. And it is applicable only to the tested sample identified in the report. This report shall not be reproduced except in full, without the written approval of UNI, this document may be altered or revised by Shenzhen United Testing Technology Co., Ltd., personnel only, and shall be noted in the revision of the document. Date of Test ........................................... : Date (s) of performance of tests ............. : Feb. 26, 2022 ~ Mar. 25, 2022 Date of Issue .......................................... : Apr. 02, 2022 Test Result.............................................. : Pass Prepared by: Jackson Fang/Editor Reviewer: Kahn yang/Supervisor Approved & Authorized Signer: Liuze/Manager Page 3 of 30 Report No.: UNIA22022605ER-61 Table of Contents Page 1 TEST SUMMARY 4 2 GENERAL INFORMATION 6 2.1 GENERAL DESCRIPTION OF EUT 6 2.2 CARRIER FREQUENCY OF CHANNELS 7 2.3 TEST MODE 7 2.4 TEST SETUP 7 2.5 DESCRIPTION TEST PERIPHERAL AND EUT PERIPHERAL 8 2.6 MEASUREMENT INSTRUMENTS LIST 9 3 CONDUCTED EMISSION 10 3.1 TEST LIMIT 10 3.2 TEST SETUP 10 3.3 TEST PROCEDURE 11 3.4 TEST RESULT 11 4 RADIATED EMISSION 14 4.1 TEST LIMIT 14 4.2 TEST SETUP 15 4.3 TEST PROCEDURE 16 4.4 TEST RESULT 16 5 BAND EDGE 23 5.1 TEST LIMIT 23 5.2 TEST PROCEDURE 23 5.3 TEST RESULT 23 6 OCCUPIED BANDWIDTH 26 6.1 TEST SETUP 26 6.2 TEST PROCEDURE 26 6.4 TEST RESULT 26 7 ANTENNA REQUIREMENT 28 8 PHOTO OF TEST 29 8.1 RADIATED EMISSION 29 8.2 CONDUCTED EMISSION 30 Page 4 of 30 Report No.: UNIA22022605ER-61 1 TEST SUMMARY 1.1 TEST PROCEDURES AND RESULTS ITEM STANGARD RESULT CONDUCTED EMISSION FCC Part 15.207 COMPLIANT RADIATED EMISSION FCC Part 15.209/15.249 COMPLIANT BAND EDGE FCC Part 15.249/15.205 COMPLIANT OCCUPIED BANDWIDTH FCC Part 15.215 COMPLIANT ANTENNA REQUIREMENT FCC Part 15.203 COMPLIANT 1.2 TEST FACILITY Test Firm : Shenzhen United Testing Technology Co., Ltd. Address : 2F, Annex Bldg, Jiahuangyuan Tech Park, #365 Baotian 1 Rd, Tiegang Community, Xixiang Str, Bao'an District, Shenzhen, China The testing quality ability of our laboratory meet with "Quality Law of People's Republic of China" Clause 19.The testing quality system of our laboratory meets with ISO/IEC-17025 requirements. This approval result is accepted by MRA of APLAC. Our test facility is recognized, certified, or accredited by the following organizations: A2LA Certificate Number: 4747.01 The EMC Laboratory has been accredited by A2LA, and in compliance with ISO/IEC 17025:2017 General Requirements for testing Laboratories. FCC Registration Number: 674885 The EMC Laboratory has been registered and fully described in a report filed with the (FCC) Federal Communications commission. IC Registration Number: 21947 The EMC Laboratory has been registered and fully described in a report filed with the (IC) Industry Canada. Page 5 of 30 Report No.: UNIA22022605ER-61 1.3 MEASUREMENT UNCERTAINTY The reported uncertainty of measurement y ± U, where expended uncertainty U is based on a standard uncertainty multiplied by a coverage factor of k=2, providing a level of confidence of approximately 95 %. A. Conducted Measurement: Test Site Method Measurement Frequency Range U, (dB) NOTE UNI ANSI 9kHz ~ 150kHz 2.96 150kHz ~ 30MHz 2.44 B. Radiated Measurement: Test Site Method Measurement Frequency Range U, (dB) NOTE UNI ANSI 9kHz ~ 30MHz 2.50 30MHz ~ 1000MHz 4.80 Above 1000MHz 4.13 Page 6 of 30 Report No.: UNIA22022605ER-61 2 GENERAL INFORMATION 2.1 GENERAL DESCRIPTION OF EUT Product: 150ft Bluetooth LED Strip Lights Kit Trade Name: Jerritte Main Model: B5019 Additional Model: B5011,B5012,B5013,B5014,B5015,B5016,B5017,B5018, B501A,B501B,B501C,B501D,B501E,B501F Model Difference: All model’s the function, software and electric circuit are the same, only with a product color and model named different. Test sample model: B5019. FCC ID: 2A5KC-B5019 Operation Frequency: 2402MHz~2480MHz Number of Channels: 40CH Modulation Type: GFSK Antenna Type: PCB Antenna Antenna Gain: 0dBi Battery: N/A Adapter: M/N: SA-2403 Input: AC 100-240V, 50/60Hz, 1.4A Output: DC 24V, 1.5A Power Source: DC 24V from adapter with AC 120(240)V/60Hz Page 7 of 30 Report No.: UNIA22022605ER-61 2.2 CARRIER FREQUENCY OF CHANNELS Channel List Channel Frequency (MHz) Channel Frequency (MHz) Channel Frequency (MHz) Channel Freq…

Text truncated - open the document above for the full version.

Model: B5019 Radiated Emission test Model: B5019 Conducted Emission test
