2A5LV-KW1Smart Watch

KW1 Instruction manual 01Product introduction Charging cable Note: Please use the charging cable to charge the product for the first time. 02 wear Button: Long press 5S to power on/off Wear the watch to about a finger away from the wrist bone, and adjust the tightness of the wrist band to a comfortable position. Tip: Wearing too loosely may affect the data collected by the heart rate sensor. 03Join binding 1. ①Search and download "InxFit" from App Store or Google Play。 ②Use your mobile phone to scan the QR code on the watch screen (Settings - APP QR code) and then scan and install the APP. You can also scan the QR code below to download and install InxFit in the App Market. 2.1 Conventional binding: After installing the APP, open InxFit, log in, and select KW1 on the device page (add a device or scan the two-dimensional code of the watch) for connection. 2.2:Child account connection: After installing the APP, open InxFit, log in, and connect in my family selection (create a child account and fill in the child information, then select the device). Note: When the child account is bound, the message reminder function cannot be used. Besides, regular binding cannot be done again after binding the child account. Regular binding can only be done after the watch is unbound from the APP. prompt： Tips: ① During the pairing process, please ensure that the Bluetooth of the mobile phone is enabled to ensure the smooth connection between the watch and the mobile phone. ② If you cannot find the device when adding it or cannot connect it when using it, set System Settings to Restore Factory defaults on the watch operation screen, and then add the device again. ③ If you can't find the watch, exit and re-open the APP. ④ Watch connection status is shown below： Disconnected state Connected state 04 Use operation 1 Shortcut Control panel: Dial home slide from bottom up 2. Message notification: Slide down from the watch face home page; 3. Main menu: Slide the dial homepage to the left; 4. Status display interface: slide the main page of the dial to the right; 5 dial replacement: Long press the dial home page 3 seconds, can slide left and right to select the dial. 6. Power on: long press the button for 5 seconds (Power off: long press the button for 5 seconds to select power off when the screen is on) 7. Press the open key to return to the main page of the watch face 05Function introduction Multiple sports modes (running, walking, cycling, dancing, badminton, basketball, soccer, etc.) In running and walking mode, you can view exercise data (heart rate, pace, exercise duration, calories, steps, distance). Heart rate: 24H heart rate monitoring, you can view the historical heart rate data in the APP. Blood oxygen measurement: The bottom of the red light to start the measurement, 30 to 60 seconds to complete the measurement. Games: Three games are built in, children can score points through the game; Calculator: can complete the suggested algorithm calculation; * The calculator button of the actual sample is different from the screenshot on the left. Status: Keep detailed records of daily steps, distance, calories, etc Sleep: record sleep time and sleep state in detail (check on APP) Music: Can control the music playing on the phone and increase or decrease the volume. (Note: Support the phone's own music player, third-party players may not be compatible.) Note: You need to enable the music function on the APP. This function is unavailable when using the family account Message: Message alert, sync the notification push on the phone. (Note: Display APP can support social software messages) Note: This function is not available when using a family account Settings: QR code, shutdown, restore factory Settings. 06 charge l、Place the watch on the charger so that the charging contact on the back of the watch fits perfectly with the metal contact on the charging head. (Charge time more than 2 hours) 2、Connect the charging cable to the standard charger purchased from the regular channel. The output voltage is 5V and the output current is 1A. If the watch can not be turned on after a long time, when you use it again, please wipe the charging line of the charging contact piece clean, to avoid sweat or moisture residue. Note: (If you do not often use the watch, please charge it once a month.) 07 Basic parameter 07 Basic parameters Hardware parameters Display screen 1.4inch TFT 240*240 Touch screen Capacitive full contact bluetooth BT5.0 Shell material ABS+PC Strap material Silica gel battery 250mAh Polymer lithium battery Standby time >30 days key Side power button Charging mode Magnetic charging waterproof IP68 08 Q&A 1. The Bluetooth connection fails. 1.1:Whether the mobile phone system meets: Android 6.0 or later, ios9.0 or later; 1.2 Confirm whether the device is connected by other mobile phones; 1.3: Whether the Bluetooth of the mobile phone has been turned on and can be used normally. It is recommended to close all programs and restart the Bluetooth before connecting； 2. Message not push。 2.1:Make sure your phone has Bluetooth enabled, and check if the APP is still connected to your watch 2.2: Check whether you authorize this APP to keep running in the background on your phone。 2.3: Confirm whether it is on the APP device page and turn on the notification switch of the corresponding app; 2.4:Check whether the application notification or short message you need can appear in the notification bar of the mobile phone. If not, enable the permission of the APP message to pop up in the notification bar in system Settings. 2.5:If the above operations cannot be solved, please unbind the watch and exit the APP to reset the watch, turn off the Bluetooth of the mobile phone and then turn on the Bluetooth of the mobile phone again. 2.6:Verify that the watch is in do not disturb mode. Enable the do not disturb mode Disable do not disturb mode 3 FCC warning statements: This equipment has been tested and found to comply with the limit…

Text truncated - open the document above for the full version.

Shenzhenshi JIAJU Technology Co., Ltd 2.911 (d)(5)(i) Equipment Type Attestation v1.2 Section 2.911(d)(5)(i) Certification – Equipment Type Company name: Shenzhenshi JIAJU Technology Co., Ltd Address: NO.625, 6th floor, Building A, Huafeng Internet Creative Park, No.107, Gonghe Gongye Road, Xixiang Street, Baoan District, Shenzhen, Guangdong, CN Product Name: Smart Watch FCC ID: 2A5LV-KW1 Model(s): KW1, FC1, D1, D2, D3, H3, H5, Lynn3, KW2, S3 2.911(d)(5)(i) Equipment Type We, Shenzhenshi JIAJU Technology Co., Ltd (“the applicant”) certify that the equipment for which authorization is sought through certification is not: • Prohibited from receiving an equipment authorization pursuant to § 2.903; of the FCC rules. • Identified as an equipment type in the “Covered List” NOTE 1 Yours sincerely, Signature: Date: 2023-04-27 Name: haiyun liao Title: / E-mail [email protected] Company: Shenzhenshi JIAJU Technology Co., Ltd NOTE 1 “Covered List”; is the List of Equipment and Services Covered By Section 2 of The Secure Networks Act, available at https://www.fcc.gov/supplychain/coveredlist References; 1) 986446 D01 Covered Equipment v01 https:// apps.fcc.gov/oetcf/kdb/forms/FTSSearchResultPage.cfm?switch=P&id=325672 2) Federal Register document 2022-28263 published on 02/06/23 https:// www.federalregister.gov/documents/2023/02/06/2022-28263/protecting-against-national-security-threats-to-the-com munications-supply-chain-through-the

Shenzhenshi JIAJU Technology Co., Ltd 2.911 (d)(5)(ii) Applicant Attestation v1.2 Section 2.911(d)(5)(ii) Certification – Applicant (Covered List) Company name: Shenzhenshi JIAJU Technology Co., Ltd Address: NO.625, 6th floor, Building A, Huafeng Internet Creative Park, No.107, Gonghe Gongye Road, Xixiang Street, Baoan District, Shenzhen, Guangdong, CN Product Name: Smart Watch FCC ID: 2A5LV-KW1 Model(s): KW1, FC1, D1, D2, D3, H3, H5, Lynn3, KW2, S3 2.911(d)(5)(ii) Applicant filing We, Shenzhenshi JIAJU Technology Co., Ltd (“the applicant”) certify that, as of the date of the filing of the application, the applicant is not identified NOTE 1 on the “Covered List” NOTE 2 , established pursuant to § 1.50002 of this chapter, as an entity producing covered communications equipment. Yours sincerely, Signature: Date: 2023-04-27 Name: haiyun liao Title: / E-mail [email protected] Company: Shenzhenshi JIAJU Technology Co., Ltd NOTE 1 Delete option not applicable to this application. NOTE 2 “Covered List ”; is the List of Equipment and Services Covered By Section 2 of The Secure Networks Act, available at https://www.fcc.gov/supplychain/coveredlist References; 1) 986446 D01 Covered Equipment v01 https:// apps.fcc.gov/oetcf/kdb/forms/FTSSearchResultPage.cfm?switch=P&id=325672 2) Federal Register document 2022-28263 published on 02/06/23 https:// www.federalregister.gov/documents/2023/02/06/2022-28263/protecting-against-national-security-threats-to-the-com munications-supply-chain-through-the

Shenzhenshi JIAJU Technology Co., Ltd Agent Authorization Company name: Shenzhenshi JIAJU Technology Co., Ltd Address: NO.625, 6th floor, Building A, Huafeng Internet Creative Park, No.107, Gonghe Gongye Road, Xixiang Street, Baoan District, Shenzhen, Guangdong, CN Product Name: Smart Watch FCC ID: 2A5LV-KW1 Model(s): KW1, FC1, D1, D2, D3, H3, H5, Lynn3, KW2, S3 We authorize MiCOM Labs Inc., 575 Boulder Court, Pleasanton, California 94566, USA, to act on our behalf on all matters concerning the certification of above named equipment. We declare that MiCOM Labs Inc. is allowed to forward all information related to the approval and certification of equipment to the regulatory agencies as required and to discuss any issues concerning the approval application. Any and all acts carried out by MiCOM Labs on our behalf shall have the same effect as acts of our own. Signature: Date: 2023-04-27 Name: haiyun liao Title: / E-mail [email protected] Company: Shenzhenshi JIAJU Technology Co., Ltd

Shenzhenshi JIAJU Technology Co., Ltd Differences Description We Shenzhenshi JIAJU Technology Co., Ltd state: Product name: Smart Watch Model: KW1, FC1, D1, D2, D3, H3, H5, Lynn3, KW2, S3 There is no difference between the except for different names of sales regions. Signature: Date: 2023-04-27 Name: haiyun liao Title: / E-mail [email protected] Company: Shenzhenshi JIAJU Technology Co., Ltd

Shenzhenshi JIAJU Technology Co., Ltd Office of Engineering Technology Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 Date: 2023-0 4-27 Subject; Request for Long Term Confidentiality FCC ID: 2A5LV-KW1 To Whom It May Concern, Pursuant to the provisions of the Commission’s rules Title 47 Sections §0.457 and §0.459, we are requesting the Commission to withhold the following attachment(s) as confidential documents from public disclosure indefinitely. These documents contain detailed system and equipment descriptions and are considered as proprietary information in operation of the equipment. The public disclosure of these documents might be harmful to our company and would give competitors an unfair advantage in the market. Schematic Diagram Block Diagram Operational Description It is our understanding that all measurement test reports, FCC ID label format and correspondence during the certification review process cannot be granted as confidential documents and this information will be available for public review once the grant of equipment authorization is issued. Sincerely, Signature: Date: 2023-04-27 Name: haiyun liao Title: / E-mail [email protected] Company: Shenzhenshi JIAJU Technology Co., Ltd

------End------

Lable: FCC ID: 2A5LV-KW1 Label location

Appendix III internal photos EUT View EUT View Antenna Location EUT View EUT View ------End------

FCC ID: 2A5LV-KW1 RF Exposure Evaluation TEST STANDARDS Follow the maximum permissible exposure (MPE) limits specified in 447498 D04 Interim General Radio Frequency Exposure Guidelines v01. The gain of the antenna used in the product was extracted from the supplied antenna data sheet and the maximum total power input to the antenna was also measured. Calculate the distance from the product to the MPE limit by the formula. LIMIT For single RF sources (i.e., any single fixed RF source, mobile device, or portable device, as defined in paragraph (b)(2) of this section): A single RF source is exempt if: (A) The available maximum time-averaged power is no more than 1 mW, regardless of separation distance. This exemption may not be used in conjunction with other exemption criteria other than those in paragraph (b)(3)(ii)(A) of Part 1.1307. Medical implant devices may only use this exemption and that in paragraph (b)(3)(ii)(A); (B) Or the available maximum time-averaged power or effective radiated power (ERP), whichever is greater, is less than or equal to the threshold Pth (mW) described in the following formula. This method shall only be used at separation distances (cm) from 0.5 centimeters to 40 centimeters and at frequencies from 0.3 GHz to 6 GHz (inclusive). Pth is given by: (C) Or using below table and the minimum separation distance (R in meters) from the body of a nearby person for the frequency (f in MHz) at which the source operates, the ERP (watts) is no more than the calculated value prescribed for that frequency. For the exemption in Table 1 to apply, R must be at least λ/2π, where λ is the free-space operating wavelength in meters. If the ERP of a single RF source is not easily obtained, then the available maximum time-averaged power may be used in lieu of ERP if the physical dimensions of the radiating structure(s) do not exceed the electrical length of λ/4 or if the antenna gain is less than that of a half-wave dipole (1.64 linear value). FCC ID: 2A5LV-KW1 For multiple RF sources: Multiple RF sources are exempt if: (A) The available maximum time-averaged power of each source is no more than 1 mW and there is a separation distance of two centimeters between any portion of a radiating structure operating and the nearest portion of any other radiating structure in the same device, except if the sum of multiple sources is less than 1 mW during the time-averaging period, in which case they may be treated as a single source (separation is not required). This exemption may not be used in conjunction with other exemption criteria other than those is paragraph (b)(3)(i)(A) of Part 1.1307. Medical implant devices may only use this exemption and that in paragraph (b)(3)(i)(A). (B) in the case of fixed RF sources operating in the same time-averaging period, or of multiple mobile or portable RF sources within a device operating in the same time averaging period, if the sum of the fractional contributions to the applicable thresholds is less than or equal to 1 as indicated in the following equation. Where: a = number of fixed, mobile, or portable RF sources claiming exemption using paragraph (b)(3)(i)(B) of Part 1.1307 for Pth, including existing exempt transmitters and those being added. b = number of fixed, mobile, or portable RF sources claiming exemption using paragraph (b)(3)(i)(C) of Part 1.1307 for Threshold ERP, including existing exempt transmitters and those being added. c = number of existing fixed, mobile, or portable RF sources with known evaluation for the specified minimum distance including existing evaluated transmitters. Pi = the available maximum time-averaged power or the ERP, whichever is greater, for fixed, mobile, or portable RF source i at a distance between 0.5 cm and 40 cm (inclusive). Pth,i = the exemption threshold power (Pth) according to paragraph (b)(3)(i)(B) of this section for fixed, mobile, or portable RF source i. FCC ID: 2A5LV-KW1 ERPj = the ERP of fixed, mobile, or portable RF source j. ERPth,j = exemption threshold ERP for fixed, mobile, or portable RF source j, at a distance of at least λ/2π according to the applicable formula of paragraph (b)(3)(i)(C) of Part 1.1307. Evaluatedk = the maximum reported SAR or MPE of fixed, mobile, or portable RF source k either in the device or at the transmitter site from an existing evaluation at the location of exposure. Exposure Limitk = either the general population/uncontrolled maximum permissible exposure (MPE) or specific absorption rate (SAR) limit for each fixed, mobile, or portable RF source k, as applicable from § 1.1310. Test Result of RF Exposure Evaluation Protocol Fre. (GHz) Output power (dBm) ANT Gain ( dBi) Max EIRP (dBm) Max EIRP (mW) Separation distance (cm) Limit (mW) Result BT 2.441 -1.53 1.2 -0.33 0.93 0.5 2.77 PASS Note: 1. This device is portable device. 2. The source of the evaluation data results is based on the test report ET-23030265E 3. The Maxinum power is less than the limit, complies with the exemption requirements.

Shenzhen Kaipushen Communication Technology Co., Ltd Antenna testreport testreport Shenzhen Kaipushen Communication Technology Co., Ltd Customer：XiaoJu Item： RF： Date：2021.11.2 Edition：01 Laboratory test environment andequipment Test itemtestingfacility S11、S12、VSWR、LOSS Network Analyzers E5071B,E5062A Efficiency、Gain 3D Radiation Pattern Satimo SG16Darkroom、GP7*4*3Darkroom、 E5071B TRP、TIS Satimo SG16Darkroom、GP7*4*3Darkroom、 8960 、CMW500、MT8820C、E4438C、 Shenzhen Kaipushen Communication Technology Co., Ltd Typeof Completemachine C01 Smart Watch Frequency bandinformationAntennaformMatchchanges Antennatypeand frequency band information Antenna 2400-2480MHZ monopole Antennamaterial Polyethylene Wire Shenzhen Kaipushen Communication Technology Co., Ltd Introductionto project commissioning Shenzhen Kaipushen Communication Technology Co., Ltd Antennapassiveefficiencydiagram free Antennapassive Applediagram free 2400.000MHzH 5-00 Shenzhen Kaipushen Communication Technology Co., Ltd AntennaSpecitification Shenzhen Kaipushen Communication Technology Co., Ltd AntennaPicture Shenzhen Kaipushen Communication Technology Co., Ltd Contact Shenzhen Kaipushen Communication Technology Co., Ltd RF: Telephone: Email: Address: 2nd Floor, Building 1, Yulong Building, Longcheng Industrial Zone, No.440, Longguan Avenue, Longhua District, Shenzhen THEEND Thank you for yourinput！ Shenzhen Kaipushen Communication Technology Co., Ltd

Report No.: ET-23030265E This test report is valid for the tested samples only. It cannot be reproduced except in full without prior written consent of Shenzhen ETR Standard Technology Co., Ltd. TEST REPORT Applicant: Shenzhenshi JIAJU Technology Co., Ltd Address of Applicant: NO.625, 6th floor, Building A, Huafeng Internet Creative Park, No.107, Gonghe Gongye Road, Xixiang Street, Baoan District, Shenzhen, Guangdong, CN Manufacturer/Factory: Shenzhenshi JIAJU Technology Co., Ltd Address of Manufacturer NO.625, 6th floor, Building A, Huafeng Internet Creative Park, No.107, Gonghe Gongye Road, Xixiang Street, Baoan District, Shenzhen, Guangdong, CN Product Name: Smart Watch Model No.: KW1, FC1, D1, D2, D3, H3, H5, Lynn3, KW2, S3 Trade Mark: N/A FCC ID: 2A5LV-KW1 Applicable standards: FCC CFR Title 47 Part 15 Subpart C Section 15.247 Date of Test: March.14, 2023- April.04, 2023 Date of report issued: April.04, 2023 Test Result : PASS * Remark: * In the configuration tested, the EUT complied with the standards specified above. The results shown in this test report refer only to the sample(s) tested, this test report cannot be reproduced, except in full without prior written permission of the company. The report would be invalid without specific stamp of test institute and the signatures of compiler and approver Prepared By Shenzhen ETR Standard Technology Co., Ltd. Address: No.103, No.10, Phase I, Zone 3, Xinxing Industrial Park, Xinhe, Fuhai Street, Bao'an District, Shenzhen, Guangdong, China Compiled by: Reviewed by: Approved by: Project Engineer Project Manager Authorized Signature - Page 2 of 31 - Report No.: ET-23030265E Tel:(86-755) 85259392 Email:[email protected] Web: www.etrlab.cn No.103, No.10, Phase I, Zone 3, Xinxing Industrial Park, Xinhe, Fuhai Street, Bao'an District, Shenzhen, Guangdong, China Report Revision History Report No. Description Issue Date ET-23030265E Original April.04, 2023 - Page 3 of 31 - Report No.: ET-23030265E Tel:(86-755) 85259392 Email:[email protected] Web: www.etrlab.cn No.103, No.10, Phase I, Zone 3, Xinxing Industrial Park, Xinhe, Fuhai Street, Bao'an District, Shenzhen, Guangdong, China Contents Page 1. TEST SUMMARY ..................................................................................................................................... 4 2. GENERAL INFORMATION ...................................................................................................................... 5 2.1 GENERAL DESCRIPTION OF EUT ................................................................................................................ 5 2.2 TEST MODE ............................................................................................................................................... 7 2.3 DESCRIPTION OF SUPPORT UNITS ....................................................................................................... 7 2.4 DEVIATION FROM STANDARDS .................................................................................................................... 7 2.5 ABNORMALITIES FROM STANDARD CONDITIONS .......................................................................................... 7 2.6 TEST FACILITY ........................................................................................................................................... 7 2.7 TEST LOCATION ......................................................................................................................................... 7 2.8 ADDITIONAL INSTRUCTIONS ........................................................................................................................ 7 3. TEST INSTRUMENTS LIST ..................................................................................................................... 8 4. TEST RESULTS AND MEASUREMENT DATA ...................................................................................... 9 4.1 ANTENNA REQUIREMENT ............................................................................................................................ 9 4.2 CONDUCTED EMISSIONS .......................................................................................................................... 10 4.3 CONDUCTED PEAK OUTPUT POWER ......................................................................................................... 13 4.4CHANNEL BANDWIDTH .............................................................................................................................. 14 4.5 POWER SPECTRAL DENSITY ..................................................................................................................... 16 4.6 BAND EDGES ........................................................................................................................................... 18 Conducted Emission Method .................................................................................................................. 18 Radiated Emission Method ..................................................................................................................... 19 4.7 SPURIOUS EMISSION ................................................................................................................................ 21 Conducted Emission Method .................................................................................................................. 21 Radiated Emission Method ..................................................................................................................... 23 5. TEST SETUP PHOTO ............................................................................................................................ 31 6. EUT CONSTRUCTIONAL DETAILS ..................................................................................................... 31 - Page 4 of 31 - Report No.: ET-23030265E Tel:(86-755) 85259392 Email:[email protected] Web: www.etrlab.cn No.103, No.10, Phase I, Zone 3, X…

Text truncated - open the document above for the full version.

Appendix I Test Setup Photo 1.1. Photos of Radiated emission 1.2. Photos of Conducted Emission test ------End------
