2A5O9-PD152KPNPortable monitor

15.6＂Po rtable Mo nitor User Manual iProda Techsupport support1@ipro da.com(1year warranty, 24/7 after-sales serv ice ) Port s and Pro duct Overv iew: Headphone jack d transmit audio, Ports Intro duction: 1. Full function USB- C ports: The all-in-one ports that supply power an image at same time. 2. Mini HDMI port: Transmit audio, image only. 3 . 3.5mmheadphone jack: Connect to speakers and headphones. Power/Return 1. Power/Return: Press and hold for 3 seconds to turn off/on monitor. 2. Dial-wheel Switch: Push up to enter volume menu, push down to enter lightness menu, short press to open OSD settings menu. Keys Introduction: 1. Power/Return: Short press to works as "Back" button in OSD settings menu. 2. Dial-wheel Switch: Short press to work as “Enter” button, push up/down to work as “up/down” buttun. Keys Introduction (OSD Settings Menu): [email protected] Power adapterProtecting jacketDesktop bracket Wireless connecting your monitor a. Connect the Monitor and power adapter. b. Turn on WiFi of your Laptop/PC. c. Press Win+K, open connection menu, select the ID that display on your monitor screen, click it to connect. Note: Support windows 10 and windows 11. 1. Windows Laptop/PC wireless connection Note: Support Android 2.0 and above, connot support google pixel 8 and below version. a. Connect the Monitor and power adapter. b. Turn on WiFi of your phone/laptop. c. Goto Miracast connection menu, select the ID that display on your monitor screen, click it to connect. 2. Android Smartphone/Laptop wireless connection Samsung Pull-down screen -- SmartView Xiaomi Settings -- Display -- Wireless Display OPPP/VIVO Settings -- Smart Projection -- Screen Mirroring Sony Settings -- Display -- Screen Mirroring LG Settings -- More Settings -- Miracast Wireless Display Note: Support iOS 9.0 and above. a. Connect the Monitor and power adapter. b. Turn on WiFi of your Apple. c. Goto “AirPlay” menu, select the ID that display on your monitor screen, click it to connect. 3. Apple wireless connection 1. Swipe down from the top right corner or up from the bottom edge of the iPhone or iPad screen to open Control Center, then tap the "Screen Mirroring" button. 2. Click the "AirPlay" icon in the menu bar in Mac. 3. Select ID from the list: 4. The first time you connect, you may need to enter the verification code '1234'. [email protected] Lightning to HDMI adapter Mini HDMI cable Compatible Mobile Devices: Huawei Mate10、Mate10Pro、Mate20、Mate20Pro、Mate20X、P20、P20Pro、 HonorNote1 0 Samsung S8 、 S8+ 、 S9 、 Note8 、 Note9 Smartisan R1、Pro 2 S OPPO R1 7 Pro More Updated continuously . . . Compatible Computers : Huawei MateBook 、 MateBook X 、 MateBook X Pro 、 MateBook E App l e MacBook 1 2、MacBook Pro、MacBook Air、ipad Pro 2 0 1 8 Honor M agic Mi Air12.5/ 13.3inch、Pro15.6 inch、Millet Game Book Lenovo Yoga5 Pro、ThinkPadX1 Carb on2 0 1 7、Miix7 2 0 Hp PavilionX2、EliteBook Folio G1 Dell XPS13、XPS15 Google ChromeBook Pixe ls、PielBook Pen Asus LIngYao3、U3 0 6、U3 2 1 seri es、U41 0 0 0、ROGseri es MicrosoftSurface Book2 Razer Blade Stealth blade/ blade sn eak versi on Mor e Updated continuously . . . Specifications: Product PortableMonitor Screen size 15.6 Inch Product size 3 6 3 * 2 2 3 * 6 mm( thickest 1 0 mm) Panel ty pe IP S Resolution 1920*1080 Aspect ratio 16:9 Color Color temperature 74 27K Viewing angle 10 1 6 . 7 M L:85/ R:85/ T:85/ D:85 (Typ .)( CR≥) Best perspective Full view Contrast 700: 1 Brightness input interfac 250 cd /m² e c interf ace× 2 Output Interface S peake mini HDinterface ( signal) , Type 3 . 5mmheadphone port r Bulit- inDual speaker System Requirements Devi ces with anHDoutputinterface ,co mputers with full TypeC video output ca pability PD152KPNPacking list: Name Number USB to Type- C Cable x1 Desktop bracket x1 Protecting jacket x1 Mini HDMIto HDMICable x1 Portble Mo PD152KPN a nitor x1x1 Type- C to Type- C Cable x1 Power adapter Troubleshooting (FAQ): Q: Why does the screen flicker when the mobile phone is connected without additional power supply? A: The output power of the mobile phone is very limited, and it is difficult to support the full load of the display. You can reduce the brightness appropriately or connect the power adapter to solve this problem. Q: Screen does not light up? A: First check if the monitor showing up “No signal” message. If not, please reconnect the power adapter and confirm the power supply is working, and press the power button for long time to confirm that the indicator light is on. Q: How to save the brightness and volume settings? A: The brightness and sound cannot be saved when there is no additional power supply. Contact us: Shenzhen iProda Technology Co. , LTD. Address: Room 1001 B, Floor 10, New Landmark Central Square, Guangming District, Shenzhen, Guangdong, China Email： support1 @ iproda. com Website: www. iproda. com FCC Statement This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: •Reorient or relocate the receiving antenna. •Increase the separation between the equipment and receiver. •Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. •Consult the dealer or an experienced radio/TV technician for help. Caution: Any changes or modifications to this device not explicitly approved …
