2A5S2-MTB4PBBQ Thermostat

Making Life Better Meat Thermometer Model: MTB-4P www.digit-en.com [email protected] and thermometer. 3. Click on “Add Device” to connect the Grill Meat Thermometer. After adding the device success- fully, click “Done”. 4. You can set the Temperature alarm and Time alarm according to your requirements, and you can also Set up the probe to choose the type of meat. The settings will be saved for the next use. 5. To unpair, you must first unplug all probes, press the button 3 times quickly, the signal icon on the screen flashes, which means the pairing is released. Warning ●Do not put the unit in high temperature places. ●Do not put probes or metal wire into fire or contact the hot surfaces and heat sources directly. ●Do not touch hot probes with bare hands during or just after cooking. Please always wear heat-re- sistant gloves. ●Please rinse or wipe the probe after use, but not let it soak in water to avoid malfunctions. ●Do not press probes and the metal wire too hard, it may damage the the plastic film of the wire and lead to short circuit. ●Please take off the black tip covers before using the probes. ●Please make sure to enable your Bluetooth on your phone to be paired correctly. ●Please make sure connecting distance range within 394ft so as to ensure Bluetooth normal con- nection (with no obstructions in between) ●Please delete the previous phone connection BBQ record before changing the new phone to pair, to ensure that the Bluetooth can be paired normally. Warranty DIGITEN products are guaranteed to the original owner for one year against defects in workmanship and materials. Please feel free to contact us if you need support or meet problems. [email protected] www.digit-en.com/support COPYRIGHT 2022 DIGITEN CO., LTD ALLRIGHTS RESERVED At A Glance 1. Celsius/Fahrenheit 2. Bluetooth Connection Status 3. Indicate Electricity 4. Current Temperature 5. Power Button 6. Type-C Charge Plug 7. Magnet Adsorption Base 8. Probe Sockets Quick Guide 1. Hold and press the Power button for about 3s to turn on/off the thermometer. 2. Short press the button to switch the temperature unit. Specification ●Battery: 1000mAh Built-in Rechargeable Lithium Battery ●Charger Type: Type-C ●Short-term Measurement Range: -10°C~300°C (32°F~572°F) ●Continuous Monitoring Range: -10°C~250°C (32°F~482°F) ●Accuracy: ±1°C/±1.8°F ●Wireless Connection: Bluetooth 5.0 ●Display: 3” Large LCD ●Backlight: Orange ●Calibration: ±7°C/±12°F ●Refresh Rate: 2s/Time ●Alarm: Buzzer Alarm * Note: It takes 4 hours per charge. Probe Installation Insert probe into the thermometer when the power is on, the thermometer will display readings of the current temperature. Please make sure probes are inserted into the center of the food to get accurate temperature readings. Free App Download Download “Smart Life” App from Google Play or App Store for free, or scan the QR code below to download the app directly. Connect with Your Phone 1. Register and sign in before using the App, please rest assured your personal info will not be stored and tracked. Turn on your phone's Bluetooth. 2. Don’t plug the probes until you pair the phone 2 3 4 4 88 6 7 1 5 At A Glance 1. Celsius/Fahrenheit 2. Bluetooth Connection Status 3. Indicate Electricity 4. Current Temperature 5. Power Button 6. Type-C Charge Plug 7. Magnet Adsorption Base 8. Probe Sockets Quick Guide 1. Hold and press the Power button for about 3s to turn on/off the thermometer. 2. Short press the button to switch the temperature unit. Specification ●Battery: 1000mAh Built-in Rechargeable Lithium Battery ●Charger Type: Type-C ●Short-term Measurement Range: -10°C~300°C (32°F~572°F) ●Continuous Monitoring Range: -10°C~250°C (32°F~482°F) ●Accuracy: ±1°C/±1.8°F ●Wireless Connection: Bluetooth 5.0 ●Display: 3” Large LCD ●Backlight: Orange ●Calibration: ±7°C/±12°F ●Refresh Rate: 2s/Time ●Alarm: Buzzer Alarm * Note: It takes 4 hours per charge. Probe Installation Insert probe into the thermometer when the power is on, the thermometer will display readings of the current temperature. Please make sure probes are inserted into the center of the food to get accurate temperature readings. Free App Download Download “Smart Life” App from Google Play or App Store for free, or scan the QR code below to download the app directly. Connect with Your Phone 1. Register and sign in before using the App, please rest assured your personal info will not be stored and tracked. Turn on your phone's Bluetooth. 2. Don’t plug the probes until you pair the phone 2 3 4 4 88 6 7 1 5 At A Glance 1. Celsius/Fahrenheit 2. Bluetooth Connection Status 3. Indicate Electricity 4. Current Temperature 5. Power Button 6. Type-C Charge Plug 7. Magnet Adsorption Base 8. Probe Sockets Quick Guide 1. Hold and press the Power button for about 3s to turn on/off the thermometer. 2. Short press the button to switch the temperature unit. Specification ●Battery: 1000mAh Built-in Rechargeable Lithium Battery ●Charger Type: Type-C ●Short-term Measurement Range: -10°C~300°C (32°F~572°F) ●Continuous Monitoring Range: -10°C~250°C (32°F~482°F) ●Accuracy: ±1°C/±1.8°F ●Wireless Connection: Bluetooth 5.0 ●Display: 3” Large LCD ●Backlight: Orange ●Calibration: ±7°C/±12°F ●Refresh Rate: 2s/Time ●Alarm: Buzzer Alarm * Note: It takes 4 hours per charge. Probe Installation Insert probe into the thermometer when the power is on, the thermometer will display readings of the current temperature. Please make sure probes are inserted into the center of the food to get accurate temperature readings. Free App Download Download “Smart Life” App from Google Play or App Store for free, or scan the QR code below to download the app directly. Connect with Your Phone 1. Register and sign in before using the App, please rest assured your personal info will not be stored and tracked. Turn on your phone's Bluetooth. 2. Don’t plug the probes until you pair the phone 2 3 4 4 88 6 7 1 5 Making Life Better Meat Thermometer Model: MTB-4P www.digit-en.com [email protected]…

Text truncated - open the document above for the full version.

CONFIDENTIALITY REQUEST for Certification Service in USA Federal Communication Commission Equipment Authorization Division, Application Processing Branch 7435 Oakland Mills Road Columbia, MD 21046 Date:<2022-9-23> Pursuant to Paragraphs §0.457 and 0.459 of the Commission’s Rules (47 C.F.R.) and Section §552(b)(4) of the Freedom of Information Act, we requests confidentiality for the following products: FCC ID Model name 2A5S2-MTB4P MTB-4P For the product stated above, we request that the following information be held confidential; Exhibits Long-Term Confidentiality Short-Term Confidentiality Short-Term Confidentiality Days External Photos Internal Photos Block Diagram Schematics Test Setup Photos User’s Manual Parts List Tune Up Operational Descriptions The long-term confidentiality exhibits contain our trade secrets and proprietary information that could be of benefit to our competitors. The short-term confidentiality on the basis of ensuring that business sensitive information remains confidential until the actual marketing of our new device. If you have any questions, please feel free to contact me at the address shown below. Sincerely, Name/Title： Wei Xie/Manager Company: Shenzhen Huimai Technology Co Ltd Address: Rm402,No.3 Factory Building,Yufeng Industrial Area Xitou New Village,ShangFen Community,Mingzhi St, Longhua District,Shenzhen,Guangdong, China Phone: +86-755-23739306 Fax: N/A E-Mail: [email protected]

Shenzhen Huimai Technology Co Ltd Rm402,No.3 Factory Building,Yufeng Industrial Area Xitou New Village,ShangFen Community,Mingzhi St, Longhua District,Shenzhen,Guangdong, China Federal Communications Commission Authorization and Evaluation Division Equipment Authorization Branch 7435 Oakland Mills Road Columbia, MD 21046 2022-9-23 To whom it may concern: We, the undersigned, hereby authorize Eurofins Product Service GmbH to act on our behalf in all matters relating to applications for equipment authorization FCC ID: 2A5S2-MTB4P including the signing of all documents related to these matters. Any and all acts carried out by Eurofins Product Service GmbH on our behalf shall have the same effect as acts of our own. By signing this application form, we agree to Eurofins’ current valid General Terms and Conditions (AGB),Testing and Certification Regulations (PZO) which can be viewed on following website www.eurofins.de/ee or retrieved on request. We also hereby certify that no party to this application is subject to a denial of benefits, including FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C. 862. Sincerely, Name/Title： Wei Xie/Manager Company: Shenzhen Huimai Technology Co Ltd Address: Rm402,No.3 Factory Building,Yufeng Industrial Area Xitou New Village,ShangFen Community,Mingzhi St, Longhua District,Shenzhen,Guangdong, China Phone: +86-755-23739306 Fax: N/A E-Mail: [email protected]

FCC ID: 2A5S2-MTB4P External Photos of the EUT Photo 1 Photo 2 Photo 3 FCC ID: 2A5S2-MTB4P Photo 4 Photo 5 Photo 6 FCC ID: 2A5S2-MTB4P Photo 7

Label and Location Size: L: 2.0cm*W: 1.0cm Label and Location FCC ID : 2A5S2-MTB4P

RF Exposure evaluation FCC ID: 2A5S2-MTB4P 1.1. Applicable Standard According to §1.1307(b)(1), systems operating under the provisions of this section shall be operated in a manner that ensures that the public is not exposed to radio frequency energy level in excess of the Commission’s guidelines. According to §1.1310 and §2.1093 RF exposure requirement KDB447498 v06: Mobile and Portable Devices RF Exposure Procedures and Equipment Authorization Policies 1.2. Requirement According to KDB447498 D01 General RF Exposure Guidance v06 Section 4.3.1 Standalone SAR test exclusion considerations: “Unless specifically required by the published RF exposure KDB procedures, standalone 1-g head or body and 10-g extremity SAR evaluation for general population exposure conditions, by measurement or numerical simulation, is not required when the corresponding SAR Test Exclusion Threshold condition, listed below, is satisfied. These test exclusion conditions are based on source-based time-averaged maximum conducted output power of the RF channel requiring evaluation, adjusted for tune-up tolerance, and the minimum test separation distance required for the exposure conditions.22 The minimum test separation distance is determined by the smallest distance from the antenna and radiating structures or outer surface of the device, according to the host form factor, exposure conditions and platform requirements, to any part of the body or extremity of a user or bystander (see 5) of section 4.1). To qualify for SAR test exclusion, the test separation distances applied must be fully explained and justified by the operating configurations and exposure conditions of the transmitter and applicable host platform requirements, typically in the SAR measurement or SAR analysis report, according to the required published RF exposure KDB procedures. When no other RF exposure testing or reporting is required, a statement of justification and compliance must be included in the equipment approval, in lieu of the SAR report, to qualify for the SAR test exclusion. When required, the device specific conditions described in the other published RF exposure KDB procedures must be satisfied before applying these SAR test exclusion provisions; for example, handheld PTT two-way radios, handsets, laptops & tablets etc.23 “ [(max. power of channel, including tune-up tolerance, mW)/ (min. test separation distance, mm)] · [√f (GHz)] ≤ 3.0 for 1-g SAR and ≤ 7.5 for 10-g extremity SAR, where: • f (GHz) is the RF channel transmit frequency in GHz • Power and distance are rounded to the nearest mW and mm before calculation • The result is rounded to one decimal place for comparison • 3.0 and 7.5 are referred to as the numeric thresholds in the step 2 below The test exclusions are applicable only when the minimum test separation distance is ≤ 50 mm and for transmission frequencies between 100 MHz and 6 GHz. When the minimum test separation distance is < 5 mm, a distance of 5 mm according to 5) in section 4.1 is applied to determine SAR test exclusion. 1.3. Manufacturing tolerance GFSK (Peak) Channel Channel 0 Channel 19 Channel 39 Target (dBm) 1.0 1.0 1.0 Tolerance ±(dB) 1.0 1.0 1.0 Page 2 of 2 2. E v a l u a t i o n R e s u l t Evaluation Results Band/Mode f (GHz) Antenna Distance (mm) RF output power (including tune-up tolerance) SAR Test Exclusion Threshold SAR Test Exclusion dBm mW BT 2.450 5 2.0 1.5849 0.4962<3.0 Yes 3. C o n c l u s i o n The measurement results comply with the FCC Limit per 47 CFR 2.1093 for the uncontrolled RF Exposure and SAR Exclusion Threshold per KDB 447498 v06 .....................End of Report.........................

1. Antenna Description: Antenna type PCB antenna Model MTB-4P Frequency range 2402-2480MHz Manufacturer Shenzhen Huimai Technology Co Ltd ANT Peak Gain 1.93 dBi 2. Antenna Photo: Length :14.41mm Width:5.65mm 3. Test Equipment & Conditions 3.1 Test instrument VSWR is tested using Agilent E5071B connected to a hand mechanism, and the status is free space. 3.2 Test environment and methods 4．Antenna Radiation Pattern 2402MHz 2440MHz 2480MHz

Shenzhen CTA Testing Technology Co., Ltd. Room 106, Building 1, Yibaolai Industrial Park, Qiaotou Community, Fuhai Street, Bao’an District, Shenzhen, China Shenzhen CTA Testing Technology Co., Ltd. Room 106, Building 1, Yibaolai Industrial Park, Qiaotou Community, Fuhai Street, Bao’an District, Shenzhen, China Tel:+86-755 2322 5875 E-mail:[email protected] Web:http://www.cta-test.cn FCC PART 15 SUBPART C TEST REPORT FCC PART 15.247 Report Reference No. ..................... : FCC ID. ........................................... : CTA22091400301 2A5S2-MTB4P Compiled by ( position+printed name+signature) .. : File administrators Zoey Cao Supervised by ( position+printed name+signature) .. : Project Engineer Amy Wen Approved by ( position+printed name+signature) .. : RF Manager Eric Wang Date of issue ..................................... : Sep. 21, 2022 Testing Laboratory Name .............. : Shenzhen CTA Testing Technology Co., Ltd. Address ............................................ : Room 106, Building 1, Yibaolai Industrial Park, Qiaotou Community, Fuhai Street, Bao’an District, Shenzhen, China Applicant’s name ............................ : Shenzhen Huimai Technology Co Ltd Address ............................................ : Rm402, No.3 Factory Building, Yufeng Industrial Area, Xitou New Village, ShangFen Community, Mingzhi St, Longhua District, Shenzhen, Guangdong, 518000, CHINA Test specification ...........................: Standard ........................................... : FCC Part 15.247 Shenzhen CTA Testing Technology Co., Ltd. All rights reserved. This publication may be reproduced in whole or in part for non-commercial purposes as long as the Shenzhen CTA Testing Technology Co., Ltd. is acknowledged as copyright owner and source of the material. Shenzhen CTA Testing Technology Co., Ltd. takes no responsibility for and will not assume liability for damages resulting from the reader's interpretation of the reproduced material due to its placement and context. Equipment description ................... : BBQ Thermostat Trade Mark ....................................... : DIGITEN Manufacturer .................................... : Shenzhen Huimai Technology Co Ltd Model/Type reference....................... : MTB-4P Listed Models .................................. : MTB-2P, MTB-1P, MTB04P, MTB02P, MTB01P, MTB4PZ, MTB4PH Modulation ....................................... : GFSK Frequency .......................................... From 2402MHz to 2480MHz Ratings ............................................. : DC 3.7V From Battery and DC 5.0V From external circuit Result................................................ : PASS Report No.: CTA22091400301 Page 2 of 35 Shenzhen CTA Testing Technology Co., Ltd. Room 106, Building 1, Yibaolai Industrial Park, Qiaotou Community, Fuhai Street, Bao’an District, Shenzhen, China Tel:+86-755 2322 5875 E-mail:[email protected] Web:http://www.cta-test.cn T E S T R E P O R T Equipment under Test : BBQ Thermostat Model /Type : MTB-4P Listed Models : MTB-2P, MTB-1P, MTB04P, MTB02P, MTB01P, MTB4PZ, MTB4PH Applicant : Shenzhen Huimai Technology Co Ltd Address : Rm402, No.3 Factory Building, Yufeng Industrial Area, Xitou New Village, ShangFen Community, Mingzhi St, Longhua District, Shenzhen, Guangdong, 518000, CHINA Manufacturer : Shenzhen Huimai Technology Co Ltd Address : Rm402, No.3 Factory Building, Yufeng Industrial Area, Xitou New Village, ShangFen Community, Mingzhi St, Longhua District, Shenzhen, Guangdong, 518000, CHINA Test Result: PASS The test report merely corresponds to the test sample. It is not permitted to copy extracts of these test result without the written permission of the test laboratory. Report No.: CTA22091400301 Page 3 of 35 Shenzhen CTA Testing Technology Co., Ltd. Room 106, Building 1, Yibaolai Industrial Park, Qiaotou Community, Fuhai Street, Bao’an District, Shenzhen, China Tel:+86-755 2322 5875 E-mail:[email protected] Web:http://www.cta-test.cn Contents 1 T E S T S T A N D A R D S .................................................................. 4 2 S U M M A R Y ............................................................................. 5 2.1 General Remarks 5 2.2 Product Description 5 2.3 Equipment Under Test 5 2.4 Short description of the Equipment under Test (EUT) 5 2.5 EUT operation mode 6 2.6 Block Diagram of Test Setup 6 2.7 Related Submittal(s) / Grant (s) 6 2.8 Modifications 6 3 T E S T E N V I R O N M E N T ............................................................... 7 3.1 Address of the test laboratory 7 3.2 Test Facility 7 3.3 Environmental conditions 7 3.4 Summary of measurement results 8 3.5 Statement of the measurement uncertainty 8 3.6 Equipments Used during the Test 9 4 T E S T C O N D I T I O N S A N D R E S U L T S ............................................ 10 4.1 AC Power Conducted Emission 10 4.2 Radiated Emissions and Band Edge 13 4.3 Maximum Peak Output Power 20 4.4 Power Spectral Density 21 4.5 6dB Bandwidth 23 4.6 Out-of-band Emissions 25 4.7 Antenna Requirement 29 5 T E S T S E T U P P H O T O S O F T H E E U T .......................................... 30 6 P H O T O S O F T H E E U T ............................................................. 31 Report No.: CTA22091400301 Page 4 of 35 Shenzhen CTA Testing Technology Co., Ltd. Room 106, Building 1, Yibaolai Industrial Park, Qiaotou Community, Fuhai Street, Bao’an District, Shenzhen, China Tel:+86-755 2322 5875 E-mail:[email protected] Web:http://www.cta-test.cn 1 T E S T S T A N D A R D S The tests were performed according to following standards: FCC Rules Part 15.247: Frequency Hopping, Direct Spread Spectrum and Hybrid Systems that are in operation within the bands of 902-928 MHz, 2400-2483.5 MHz, and 5725-5850 MHz. ANSI C63.10-2013: American National Standard for Testing Unlicensed Wireless Devices KDB558074 D01 V05r02: Guidance for Performing Compliance Measurements on Digital Transmission Systems (DTS) Operating Under §15.247 Repor…

Text truncated - open the document above for the full version.

FCC ID: 2A5S2-MTB4P Test Setup Photos of the EUT
