Quick start The see-thru glass directional speaker Audfly Technology Co., Limited Contents Focusound glass speaker 3.5mm Audio Cable Stand Driver Power Adapter Vertical Placement 90° 90° Music Player 3.5mm Audio Cable 24V Adapter AC 220V Connection Mode Connection Mode Bluetooth Connection Mobilephone 24V Adapter AC 220V 3.5mm Audio Cable USB C 24V Adapter AC 220V Connection Mode Notebook or PC Description(Driver) Rhythm LEDSPower IndicatorAudio EN Volume Knob plug in properly before turn screw ring to lock down the connector and cable Pull this ring to unlock Power Switch DC24V IN USB C 3.5mm Aux In (L) Panel Connector (R) Panel Connector The Focusound parametric speaker array system uses ultrasound technol- ogy that can be harmful if not used appropriately. Exposure to ultrasound at high volumes or for prolonged periods of time can cause permanent hearing loss or other health issues. To minimize the risk of harm, we recommend the following precautions: Limit listening time to 30 minutes per day to avoid prolonged exposure Use the product at a comfortable volume level and never at a volume that causes discomfort or pain Keep the product away from infants, young children, and pets Do not use the product near electronic medical devices, such as pacemakers, as ultrasound can interfere with their operation Ensure that the product is properly grounded and connected to a safe electrical source Do not open the product casing, as there are high-voltage components inside the driver Do not attempt to repair the product yourself. If you experience any issues, contact our customer support team for assistance. By following these guidelines, you can reduce the risk of harm associated with ultrasound exposure and electrical hazards. If you have any questions or concerns about using the Focusound parametric speaker array system, please contact us for further assistance. WARNING: ULTRASOUND SAFETY AND ELECTRICAL HAZARDS ResultItem Product model Audible sound SPL Frequency range Total harmonic distortion Rated power Input port Radiation angle Power adapter Size Color DUO 75±3dB@1m 1KHz 500Hz-20KHz 10±5% 10±3W 15°±3°(-20dB) 3.5mm AUX IN Type-C Bluetooth 5.1 370.3*152*8.7mmSize of screen frame 200*81*23mm Size of drive Gray Input:100-240Vac 50/60Hz Output:24V DC/2A Technical Specifications (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: —Reorient or relocate the receiving antenna. —Increase the separation between the equipment and receiver. —Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. —Consult the dealer or an experienced radio/TV technician for help. NOTE : Any changes or modifications to this unit not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment. FCC Radiation Exposure Statement: This equipment complies with FCC radiation exposure limits set forth for an uncontrolled environment. This equipment should be installed and operated with minimum distance 20cm between the radiator & your body. FCC STATEMENT This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: Complies with IMDA Standards DB123456 Dear customer! Thank you for purchasing the products of our company ! In order to protect your legitimate rights and improve the after-sales service of the customer,the warranty regulations are specially formulated, please read carefully and provide valuable comments and suggestions. Our company's products enjoy free warranty service for 12 months from the date of sale, if the product exceeds 12 months warranty period from the date of sale, our company will charge cost of parts as appropriate. If the repaired product which should be properly packed is damaged or lost in transit, our company will not be responsible for the loss. In the period of free warranty, If the following matters occur, our company has the right to refuse the service or collect materials and service fees as appropriate. 1.Product failure or damage caused by improper use of the user; 2.Worn parts; 3.Accident caused by electric shock or improper installation; 4.Damage caused by repair of non service personnel. To get warranty service, you can contact our customer service through our official website, or you can call 4001-581-281, thank you . WARRANTY REGULATIO Customer nameCustomer phone Customer address Maintenance record Product model: DUO Product date: Inspec�on date : Inspector: This product has passed the factory inspection! E-mail: [email protected] Add: Flat 9, 7/F, Fonda Industrial Building, 37-39 Au Pui Wan Street, Fotan, Shatin, NT, HK Web: www.focusound.com Audfly Technology MADE IN CHINA Audfly Technology Co., Limited

Audfly Technology(Suzhou) Co.,Ltd No.78,Keling Road,SND Software Park,New District, Suzhou,jiangsu,Suzhou, China Date: 2023-06-25 FederalCommunicationsCommission Authorizationand EvaluationDivision 7435 OaklandMills Road Columbia,MD 21046 Ref:AttestationStatementsPart 2.911(d)(5) (i) Filing SUBJECT:FCC Applicationfor FCC ID: 2A5S9-FOCUSOUNDF1 To WhomIt May Concern: AudflyTechnology(Suzhou)Co.,Ltdcertifiesthat the equipmentfor which authorizationis soughtis not “covered” equipmentprohibitedfrom receivingan equipmentauthorizationpursuantto section2.903 of the FCC rules. Sincerely, Signatory [Yang Li, Manager]

AudflyTechnology(Suzhou)Co.,Ltd No.78,KelingRoad,SNDSoftwarePark,NewDistrict,Suzhou,jiangsu,Suzhou,China Date:2023-06-25 FederalCommunicationsCommission AuthorizationandEvaluationDivision 7435OaklandMillsRoad Columbia,MD21046 Ref:AttestationStatementsPart2.911(d)(5)(ii)Filing SUBJECT:FCCApplicationforFCCID:2A5S9-FOCUSOUNDF1 ToWhomItMayConcern: AudflyTechnology(Suzhou)Co.,Ltdcertifiesthat,asofthedateofthefilingoftheapplication,theapplicantis notidentifiedontheCoveredListasanentityproducing“covered”equipment. Sincerely, Signatory [YangLi,Manager]

Audfly Technology(Suzhou) Co.,Ltd No.78,Keling Road,SND Software Park,New District, Suzhou,jiangsu,Suzhou, China Date: 2023-06-21 FEDERAL COMMUNICATIONS COMMISSION AUTHORIZATION AND EVALUATION DIVISION 7435 OAKLAND MILLS ROAD COLUMBIA, MD 21046 Ref: Attestation Statements Part 2.911(d)(7) Filing FCC ID: 2A5S9-FOCUSOUNDF1 Audfly Technology(Suzhou) Co.,Ltd certifies that, as of the date of the filing of the application, International Certification Solution Inc. is our designated U.S. agent for service of process for the above referenced FCC ID. Audfly Technology(Suzhou) Co.,Ltd accepts to maintain an agent for no less than one year after the grantee has terminated all marketing and importation or the conclusion of any Commission-related proceeding involving the equipment. International Certification Solution Inc. accepts, as of the date of the filing of the application, the obligation of the designated U.S. agent for service of process for the above referenced FCC ID. Designated U.S. Agent Information: Name:International Certification Solution Inc. FRN: 0033923541 Address: 22060 Queen St. Castro Valley, CA 94546, USA Contact Person: Cheuck Wong Tel.:5108166730 Email:[email protected] Sincerely, Signed on behalf of Audfly Technology(Suzhou) Co.,Ltd Signed on behalf of International Certification Solution Inc. Name: Yang Li Name: Cheuck Wong Title: Manager Title: Business Associate Date: 2023-06-21 Date: 2023-06-21

AudflyTechnology(Suzhou)Co.,Ltd No.78,KelingRoad,SNDSoftwarePark,NewDistrict,Suzhou,jiangsu,Suzhou,China Date:2023-06-25 FEDERALCOMMUNICATIONSCOMMISSION AUTHORIZATIONANDEVALUATIONDIVISION 7435OAKLANDMILLSROAD COLUMBIA,MD21046 SUBJECT:FCCApplicationforFCCID:2A5S9-FOCUSOUNDF1 ConfidentialityRequest Towhomitmayconcern, PursuanttotheprovisionsoftheCommission’srulesTitle47Sections§0.457and§0.459,wearerequestingthe Commissiontowithholdthefollowingattachment(s)asconfidentialdocumentsfrompublicdisclosureindefinitely. ☒ BlockDiagram ☐ Tune-UpInformation ☒ OperationalDescription ☐ SecurityInformation ☒ Schematics ☐ SoftwareDefinedRadio(SDR)Information ☐ PartsList Theabovematerialscontaintradesecretsandproprietaryinformationnotcustomarilyreleasedtothepublic.The publicdisclosureofthesematerialsmaybeharmfultotheapplicantandprovideunjustifiedbenefitstoits competitors. Inadditionaltoabovementioneddocuments,inordertocomplywiththemarketingregulationsinTitle47CFR §2.803andtheimportationrulesinTitle47CFR§2.1204,whileensuringthatbusinesssensitiveinformation remainsconfidentialuntiltheactualmarketingofnewlyauthorizeddevices,werequestShortTermConfidentiality ofthefollowingattachment(s); ☒ ExternalPhotos ☒ TestSetupPhotos ☒ InternalPhotos ☒ UserManual ☐For45days,pursuanttoPublicNoticeDA04-1705. or ☒For180dayspursuanttoKDB726920D01. TheapplicantunderstandsthatpursuanttoSection0.457oftheRules,disclosureofthisapplicationandall accompanyingdocumentationwillnotbemadebeforethedateoftheGrantforthisapplication. Sincerely, Signatory [YangLi,Manager]

AudflyTechnology(Suzhou)Co.,Ltd No.78,KelingRoad,SNDSoftwarePark,NewDistrict,Suzhou,jiangsu,Suzhou,China Date:2023-06-25 FEDERALCOMMUNICATIONSCOMMISSION AUTHORIZATIONANDEVALUATIONDIVISION 7435OAKLANDMILLSROAD COLUMBIA,MD21046 SUBJECT:FCCApplicationforFCCID:2A5S9-FOCUSOUNDF1 POWEROFATTORNEY ToWhomItMayConcern: We,theundersigned,herebyauthorizeWaltekTestingGroup(Shenzhen)Co.,Ltd.JandySoonourbehalf,to applytotheFederalCommunicationsCommissiononourequipment.AnyandallactscarriedoutbyWaltek TestingGroup(Shenzhen)Co.,Ltd.JandySoonourbehalfshallhavethesameeffectasactsofourown. ThisistoadvisethatweareinfullcompliancewiththeAnti-DrugAbuseAct.We,AudflyTechnology(Suzhou) Co.,LtdarenotsubjecttoadenialoffederalbenefitspursuanttoSection5301oftheAnti-DrugActof1988,21 USC853a,andnopartytotheapplicationissubjecttoadenialoffederalbenefitspursuanttothatsection. Sincerely, Signatory [YangLi,Manager]

Reference No.: WTH23X05111527W Page 2 of 25 Waltek Testing Group (Shenzhen) Co., Ltd. Http://www.waltek.com.cn EXHIBIT 2 - EUT EXTERNAL PHOTOGRAPHS Model: DUO EUT View 1 EUT View 2 Reference No.: WTH23X05111527W Page 3 of 25 Waltek Testing Group (Shenzhen) Co., Ltd. Http://www.waltek.com.cn EUT View 3 EUT View 4 Reference No.: WTH23X05111527W Page 4 of 25 Waltek Testing Group (Shenzhen) Co., Ltd. Http://www.waltek.com.cn EUT View 5 EUT View 6 Reference No.: WTH23X05111527W Page 5 of 25 Waltek Testing Group (Shenzhen) Co., Ltd. Http://www.waltek.com.cn EUT View 7 EUT View 8 Reference No.: WTH23X05111527W Page 6 of 25 Waltek Testing Group (Shenzhen) Co., Ltd. Http://www.waltek.com.cn Model: SOLO EUT View 1 EUT View 2 Reference No.: WTH23X05111527W Page 7 of 25 Waltek Testing Group (Shenzhen) Co., Ltd. Http://www.waltek.com.cn EUT View 3 EUT View 4 Reference No.: WTH23X05111527W Page 8 of 25 Waltek Testing Group (Shenzhen) Co., Ltd. Http://www.waltek.com.cn EUT View 5 EUT View 6 Reference No.: WTH23X05111527W Page 9 of 25 Waltek Testing Group (Shenzhen) Co., Ltd. Http://www.waltek.com.cn EUT View 7 EUT View 8 Reference No.: WTH23X05111527W Page 10 of 25 Waltek Testing Group (Shenzhen) Co., Ltd. Http://www.waltek.com.cn EUT View 9

Reference No.: WTH23X05111527W Page 1 of 25 Waltek Testing Group (Shenzhen) Co., Ltd. Http://www.waltek.com.cn ANNEX EXHIBIT 1 - PRODUCT LABELING Proposed FCC ID Label Format Specifications: The label shall be securely affixed to a permanently attached part of the device, in a location where it is visible or easily accessible to the user, and shall not be readily detachable. The label shall be sufficiently durable to remain fully legible and intact on the device in all normal conditions of use throughout the device’s expected lifetime. Proposed Label Location on EUT FCC ID Label Location

Reference No.: WTH23X05111527W Page 11 of 25 Waltek Testing Group (Shenzhen) Co., Ltd. Http://www.waltek.com.cn EXHIBIT 3 - EUT INTERNAL PHOTOGRAPHS Model: DUO EUT Housing and Board View 1 EUT Housing and Board View 2 Reference No.: WTH23X05111527W Page 12 of 25 Waltek Testing Group (Shenzhen) Co., Ltd. Http://www.waltek.com.cn Solder Board-Component View 1 Solder Board-Component View 2 Reference No.: WTH23X05111527W Page 13 of 25 Waltek Testing Group (Shenzhen) Co., Ltd. Http://www.waltek.com.cn Solder Board-Component View 3 Solder Board-Component View 4 Reference No.: WTH23X05111527W Page 14 of 25 Waltek Testing Group (Shenzhen) Co., Ltd. Http://www.waltek.com.cn Solder Board-Component View 5 Solder Board-Component View 6 Reference No.: WTH23X05111527W Page 15 of 25 Waltek Testing Group (Shenzhen) Co., Ltd. Http://www.waltek.com.cn Solder Board-Component View 7 Solder Board-Component View 8 Reference No.: WTH23X05111527W Page 16 of 25 Waltek Testing Group (Shenzhen) Co., Ltd. Http://www.waltek.com.cn Model: SOLO EUT Housing and Board View 1 EUT Housing and Board View 2 Reference No.: WTH23X05111527W Page 17 of 25 Waltek Testing Group (Shenzhen) Co., Ltd. Http://www.waltek.com.cn Solder Board-Component View 1 Solder Board-Component View 2 Reference No.: WTH23X05111527W Page 18 of 25 Waltek Testing Group (Shenzhen) Co., Ltd. Http://www.waltek.com.cn Solder Board-Component View 3 Solder Board-Component View 4 Reference No.: WTH23X05111527W Page 19 of 25 Waltek Testing Group (Shenzhen) Co., Ltd. Http://www.waltek.com.cn Solder Board-Component View 5 Solder Board-Component View 6 Reference No.: WTH23X05111527W Page 20 of 25 Waltek Testing Group (Shenzhen) Co., Ltd. Http://www.waltek.com.cn Solder Board-Component View 7 Solder Board-Component View 8 Reference No.: WTH23X05111527W Page 21 of 25 Waltek Testing Group (Shenzhen) Co., Ltd. Http://www.waltek.com.cn Solder Board-Component View 9 Solder Board-Component View 10 Reference No.: WTH23X05111527W Page 22 of 25 Waltek Testing Group (Shenzhen) Co., Ltd. Http://www.waltek.com.cn Solder Board-Component View 11 Antenna View

1. RF Exposure Requirements 1.1 General Information Client Information Applicant: Audfly Technology(Suzhou) Co.,Ltd Address of applicant: No.78,Keling Road,SND Software Park,New District, Suzhou,jiangsu, Suzhou, China Manufacturer: Audfly Technology Co., Limited Address of manufacturer: Flat 9, 7/F, Fonda Industrial Building, 37-39 Au Pui Wan Street, Fotan, Shatin, NT, HK General Description of EUT: Product Name: FOCUSOUND Trade Name Model No.: DUO Adding Model(s): SOLO Rated Voltage: DC 24V Battery Capacity: / Adapter Model: RYF909C240200VU INPUT:AC100~240V-50/60Hz O U T P UT:DC24.0V-2.0A FCC ID: 2A5S9-FOCUSOUNDF1 Equipment Type: Mobile device Technical Characteristics of EUT: Bluetooth(BR/EDR mode) Bluetooth Version: V5.1 (BR/EDR mode) Frequency Range: 2402-2480MHz RF Output Power: -13.49dBm (Conducted) Data Rate: 1Mbps, 2Mbps, 3Mbps Modulation: GFSK, π/4 DQPSK, 8DPSK Quantity of Channels: 79 Channel Separation: 1MHz Type of Antenna: FPC Antenna Antenna Gain: -21.49dBi Bluetooth(BLE mode) Bluetooth Version: V5.1 (BLE mode) Frequency Range: 2402-2480MHz RF Output Power: -9.14dBm (Conducted) Data Rate: 1Mbps Modulation: GFSK Quantity of Channels: 40 Channel Separation: 2MHz Type of Antenna: FPC Antenna Antenna Gain: -21.49dBi 1.2 RF Exposure Exemption According to §1.1307(b)(3) and KDB 447498 D04 Interim General RF Exposure Guidance v01, system operating under the provisions of this section shall be operating in a manner that the public is not exposed to radio frequency energy level in excess limit for maximum permissible exposure. Option A: FCC Rule Part 1.1307 (b)(3)(i)(A):The available maximum time-averaged power is no more than 1mW, regardless of separation distance. Option B: FCC Rule Part 1.1307 (b)(3)(i)(B): The available maximum time-averaged power or effective radiated power (ERP), whichever is greater, is less than or equal to the threshold P th (mW) described in the following formula. P th is given by: Option C: FCC Rule Part 1.1307 (b)(3)(i)(C): The minimum separation distance (R in meters) from the body of a nearby person for the frequency (f in MHz) at which the source operates, the ERP (watts) is no more than the calculated value prescribed for that frequency. R must be at least λ/2π, where λ is the free-space operating wavelength in meters. Single RF Sources Subject to Routine Environmental Evaluation RF Source frequency (MHz) Threshold ERP (watts) 0.3-1.34 1,920 R 2 1.34-30 3,450 R 2 /f 2 30-300 3.83 R 2 300-1,500 0.0128 R 2 f 1,500-100,000 19.2R 2 For Multiple RF sources: FCC Rule Part 1.1307(b)(3)(ii): (A) The available maximum time-averaged power of each source is no more than 1 mW and there is a separation distance of two centimeters between any portion of a radiating structure operating and the nearest portion of any other radiating structure in the same device, except if the sum of multiple sources is less than 1 mW during the time-averaging period, in which case they may be treated as a single source (separation is not required). (B) In the case of fixed RF sources operating in the same time-averaging period, or of multiple mobile or portable RF sources within a device operating in the same time averaging period, if the sum of the fractional contributions to the applicable thresholds is less than or equal to 1 as indicated in the following equation. 1.3 Calculated Result Radio Access Technology Prediction Frequency Output Power Antenna Gain Duty Cycle Tune-Up Time-Averaged Power ERP (MHz) (dBm) (dBi) (%) (dBm) (dBm) Bluetooth 2402 -9.14 -21.49 100 -9.00 -32.64 Frequency Option Min. Distance Max. Power Exposure Limit Ratio Result (MHz) (cm) (dBm) (mW) (mW) Pass/Fail 2402 C 20.00 -32.64 0.00 768.00 0.01 Pass Note: 1. Time-Averaged Power=Output Power * Duty Cycle; ERP= Time-Averaged Power+ Antenna gain-2.15dB 2. Option A, B and C refers as clause 1.2. 3. For option B, Max (time-averaged power, effective radiated power (ERP)) converts to Max. Power. For option C, ERP converts to Max. Power; 4. For option B, P th (mW) converts to Exposure Limit (mW); For option C, ERP (W) converts to Exposure Limit (mW). 5. Ratio= Tune-Up ERP (mW)/ Exposure Limit (mW) Mode for Simultaneous Multi-band Transmission: Radio Access Technology Ratio 1 Ratio 2 Simultaneous Ratio Limit Result Pass/Fail -- -- -- -- -- -- Result: Pass
