2A5UE-HTY-2222Wireless charging

尺寸：105x148mm 材质：100g书纸 工艺：单黑双面印刷 骑马钉 Thank you for purchasing this product.Please read this manual carefully before use to get the correct usage and storage method. Hope you have a pleasant shopping experience. Product Specifications Model:HTY-2222 Name:Fast Wireless Charging Stand for Fire HD 8 Plus Tablet, Material:ABS + PC（anti-flame retardant） Weight: 0.69(lb) Dimensions: 200*158.5*33(mm) Input Voltage:Adapter:100-240V AC 50 / 60HZ Station:5V/9V/12V Fast Charge Wireless charger output: 15W (15W,10W,7.5W,5W) Wireless Charging Distance: 3-8mm Wireless Charger USB-C Charging NOTE 1. Please check whether the charged device is compatible with the product voltage(Input voltage:100V-240V) first. a metal object on the back of the phone. When there is a metal piece 2. Before using the wireless charger, please check whether there is or other metal material on the back of the charged phone, the wireless charger will start up the FOD foreign object detection function, and the phone will not be charged typically. the original charging cable or a third-party certified charging cable to 3. To ensure safety and efficiency, it is strongly recommended to use power the device. 4. Only use for indoor and dry environments; avoid using in high temperature, humidity, and oily environment. It is forbidden to use after seeping liquid or throwing it into a fire. Pay attention to moisture and waterproofing. 5. It is strictly forbidden to place the product in a robust magnetic field environment. 6. Avoid placing it within reach of infants and children. 7. Non-professionals are not allowed to disassemble and repair without authorization. Package List USB-C Cable Compatible with USB-C Version Fire Tablets and Kindle E-Readers Gen-2022 release) iPhone13 Mini /iPhone13 Pro/ iPhone13 Pro Max/ iPhone12/ iPhone12 Mini/ iPhone12 Pro/ iPhone12 Pro Max/ iPhone11/iPhone11 Pro/ iPhone11 Pro Max/ iPhone X/ iPhone XS/iPhone XS Max/ iPhone XR/ iPhone8/iPhone 8 Plus Samsung phone: Galaxy S22/S22+/S22U/S21/S21+/S21U/S20/S20+/S20U/S10/ S10+ /S9/ S9+/ S8/Galaxy S8+/Galaxy Note 20/ Galaxy Note 20 Ultra/ Galaxy Note 10/ Galaxy Note 10 Ultra Google Phone : Nexus 7 Nexus 7 Pro/Nexus 6/Nexus 6 Pro/ Pixel 5, Pixel 4, Pixel 4XL, Quick & Easy: Features Wireless charging dock eliminates the need to plug in your Fire HD 8 Plus(10th Gen-2020 Release,12th Gen-2022 Release),Fire HD 10 Plus (11th Gen-2021 Release) every time you want to charge it. The dock is always ready. Just drop your tablet in the dock and let it Dock your Fire HD 8 Plus(10th Gen-2020 Release,12th Gen-2022 Perfect Fit: portrait or landscape mode. The Wireless Charging Dock charges your Fire HD 10 Plus (11th Generation) with a case up to 4mm thick, in both portrait and Full Power High-speed wireless charging your Fire HD 8 Plus(10th Fast Charging: Gen-2020 Release,12th Gen-2022 Release),Fire HD 10 Plus (11th Gen-2021 Release) tablet. Release),Fire HD 10 Plus (11th Gen-2021 Release) tablet in either Case Charging: landscape mode. you can also use the usb-c cable to fast charging your Fire HD 8 iPhone14/ iPhone14 Mini/ iPhone14 Pro/ iPhone14 Pro Max/iPhone13/ Apple phone: 6 7 平板充电器组装步骤 Tablet Charging Schematic Diagram 平板充电器示意图 3 4 5 2 1 9 8 Fire HD 10 Plus Tablet User Manual Wireless Charging for Fire HD 8 Plus Tablet, F ire HD 10 Plus Tablet New Fire HD 8/8Plus/Kids/Kids Pro Tablet (10th Gen-2020 Release,12th charge. Plus(10th Gen-2020 Release,12th Gen-2022 Release),Fire HD 10 Plus (11th Gen-2021 Release) tablet ,and charging your other USB-C version of Fire Tablets&Kinde eReaders. Included In-Box: Wireless Charging Dock, Power Supply, USB-C Cable and Quick Start Guide. USB-C Cable: Wireless Charging Dock Compatible with Mobile Phone Models Wireless Charging Dock Designed for use with Tablet Models Fire HD 10 Plus (11th Gen-2021 Release) Fire HD 8 Plus (10th Gen-2020 Release,12th Gen-2022 Release) Fire HD 10/10Plus/Kids/Kids Pro/ Tablets (9th Gen-2019 Release,11th Gen-2021 release) Kindle PaperWhite /Kids (11th Gen, 2021 Release) All-new Fire 7 tablet/Kids（12th Gen - 2022 release） all-new Kindle /Kids(11th Gen-2022 release) Kindle Scribe(1st generation - 2022 release) Pixel 3 and Pixel 3XL FCC Caution Any changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate this equipment. This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (2) this device must accept any interference received, including (1) This device may not cause harmful interference, and interference that may cause undesired operation. This equipment should be installed and operated with minimum distance 20cm between the radiator and your body. NOTE: This equipment has been tested and found to comply with the limits These limits are designed to provide reasonable protection against for a Class B digital device, pursuant to Part 15 of the FCC Rules. harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions,may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a interference to radio or television reception, which can be determined particular installation. If this equipment does cause harmful by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the followingmeasures: -- Reorient or relocate the receiving antenna. -- Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. -- Consult the dealer or an experienced radio/TV technician for help.

SHENZHEN HENGTAIYING TECHNO L OGY CO. , L T D Section 2.911 (d)(5)(ii) Certification -Applicant (Covered List ) Company name: SHENZHEN HENGTAIYING TECHNO L OGY CO. , L T D Address: 2F, 11 Block, Kaetat Industrial Park, L iaokeng, Shiyan Street, Bao ’ an District.Shenzhen, 518000 China Product Name: Wireless charging FC C I D : 2A5UE-HTY-2222 Model ( s ) : HTY-2222 2.911 { d)(5)(ii) Applicant filin g We, [ SHENZHEN HENGTAIYING TECHNOLOGY CO., L TD ] （ 气heapplicant ” ） ce叫 fy that, as of the date of the filing of the applicati 。 n,the applicant is 『’。 tide 『、 tifiedNOTE1 。 nthe “C 。 vered L ist 咔’ NOTE 2,established p ursuant to § 1.50002 of this chapte「，asan entity producing c 。 veredcommunication s equipment. Yours sincerely , Name: Jinming Sun D ate: 2/24/2023 Title and Company name: Genera 作 anager I SHENZHEN HENGTAIYING TECHNO L OGY CO . , LTD J 川 7 川 NOTE 1 Delete option not applicable to this application. NOTE 2 “Covered List ” ；is the List of Equipment and Services Co 叩 ered By Section 2 of The Secure Networks Act, available at httos://www.fcc.。。内t/suoolvchain/coveredlist References; 1) 986446 001 Covered Equipment v01 httos://aoos.fcc.aov/ oetcf/kdb/forms/FTSS earchResu ltPaae.cfm?switch=P&id=325672 2) Federal Register document 2022-28263 published on 02/06/23 httos://www.federalreaister.aov/documen ts/202 3/02/06/2022-28在63/orotectina-aaai nst-national-sect』「itv-threats-to-the-com munications-suool v -chain-throuah-the 2.911 (d) { S ) (ii) Applicant Attestation vl.3

THREE STONES MEDIA LLC U.S. Agent Letter of Attestation To: Federal Communications Commission 7435 Oakland Mills Road, Columbia, MD 21046, USA Date: 02-22-2023 Ref: Attestation Statement – Part2.911(d)(7) filing FCC ID: 2A5UE-HTY-2222 SHENZHEN HENGTAIYING TECHNOLOGY CO.,LTD (“the applicant”) certifies that, as of the date of the filing of the application, THREE STONES MEDIA LLC(“the agent”) is our designated U.S. agent for service of process for the abovereference FCC ID. The applicant accepts to maintain an agent for service of process in the United States forno less than one year after either the grantee has permanently terminated all marketing and importation of theapplicable equipment within the U.S., or the conclusion of any Commission-related administrative or judicialproceeding involving the equipment, whichever is later. The applicant further acknowledges it is ourresponsibility to inform the FCC whenever the agent information changes. THREE STONES MEDIA LLC ("the agent) understand it is the agent's obligation to accept service of process in the United States for matters related to the applicable equipment, and at the physical U.S. address and email address. Designated U.S. Agent Company Name: THREE STONES MEDIA LLC FRN: 0033401761 GC: 2A99E Address: 1200 Broadway St. APT 329, Los Angeles, CA90015 Signature: Contact Person: Sijie Zhang Tel: +1 267 909 3692 Email: [email protected] Applicant Company Name: SHENZHEN HENGTAIYING TECHNOLOGY CO.,LTD Address: 2F, 11 Block, Kaetat Industrial Park, Liaokeng, Shiyan Street, Bao'an District,Shenzhen, 518000 China Signature: Contact Person: Jinming Sun Tel: 0755-27380665 Email: [email protected]

ATTACHMENT PHOTOGRAPHS OF EUT Photo 1 Photo 2 Photo 3 Photo 4 Photo 5 Photo 6

ATTACHMENT PHOTOGRAPHS OF EUT Photo 1 Photo 2 Photo 3 Photo 10 WPT Induction coil 1 WPT Induction coil 3 WPT Induction coil 2

FCC ID:2A5UE-HTY-2222 1.Measuring Standard FCC Part 1(1.1310) and Part 2(2.1091), KDB 680106 D01v03r01 RF Exposure Wireless Charging App v03 1.2. Requiments Three different categories of transmitters are defined by the FCC in OET Bulletin 65. These categories are fixed installation, mobile, and portable and are defined as follows: o Fixed Installations: fixed location means that the device, including its antenna, is physically secured at a permanent location and is not able to be easily moved to another location. Additionally, distance to humans from the antenna is maintained to at least 2 meters. o Mobile Devices: a mobile device is defined as a transmitting device designed to be used in other than fixed locations and to be generally used in such a way that a separation distance of at least 20 centimeters is normally maintained between the transmitter's radiating structures and the body of the user or nearby persons. Transmitters designed to be used by consumers or workers that can be easily re-located, such as a wireless modem operating in a laptop computer, are considered mobile devices if they meet the 20 centimeter separation requirement. The FCC rules for evaluating mobile devices for RF compliance are found in 47 CFR §2.1091. o Portable Devices: a portable device is defined as a transmitting device designed to be used so that the radiating structure(s) of the device is/are within 20 centimeters of the body of the user. Portable device requirements are found in Section 2.1093 of the FCC's Rules (47 CFR§2.1093). The FCC also categorizes the use of the device as based upon the user’s awareness and ability to exercise control over his or her exposure. The two categories defined are Occupational/ Controlled Exposure and General Population/Uncontrolled Exposure. These two categories are defined as follows: Occupational/Controlled Exposure: In general, occupational/controlled exposure limits are applicable to situations in which persons are exposed as a consequence of their employment, who have been made fully aware of the potential for exposure and can exercise control over their exposure. This exposure category is also applicable when the exposure is of a transient nature due to incidental passage through a location where the exposure levels may be higher than the general population/uncontrolled limits, but the exposed person is fully aware of the potential for exposure and can exercise control over his or her exposure by leaving the area or by some other appropriate means. Awareness of the potential for RF exposure in a workplace or similar environment can be provided through specific training as part of a RF safety program. If appropriate, warning signs and labels can also be used to establish such awareness by providing prominent information on the risk of potential exposure and instructions on methods to minimize such exposure risks. General Population/Uncontrolled Exposure: The general population / uncontrolled exposure limits are applicable to situations in which the general public may be exposed or in which persons who are exposed as a consequence of their employment may not be made fully aware of the potential for exposure or cannot exercise control over their exposure. Members of the general public would come under this category when exposure is not employment-related; for example, in the case of a wireless transmitter that exposes persons in its vicinity. Warning labels placed on low-power consumer devices such as cellular telephones are not considered sufficient to allow the device to be considered under the occupational/controlled category, and the general population/uncontrolled exposure limits apply to these devices. 1.3 Test configuration 1, The field strength of both E-field was measured at 15cm, H-field was measured at 15cm surrounding the device, and 20 cm away from the surface from all coils using the equipment list above for determining compliance with the MPE requirements of FCC Part 1.1310. 2, The RF power density was measured at Under maximum load test 3, Maximum E-field measurements was made 15cm from each side of the EUT and H-field measurements was made 15cm from surrounding the EUT and 20 cm away from the surface from all coils. Along the side of the EUT and still 20cm away from the edge of the EUT, the field probes were positioned at the location where there is maximum field strength. The maximum E-field and H-field is reported below. 4, This device uses a wireless charging circuit for power transfer operating at the frequency of 111–175kHz. Thus, the 300kHz limits were used: E-field Limit = 614 (V/m); H-field limit = 1.63 (A/m). 1.4 Test Setup 2. Limits 3. MEASURING DEVICE AND TEST EQUIPMENT 2.1For MPE Measurement Equipment Manuf acturer Model No. Serial No. Last calibration Calibrated until Cal. Interval E-Field Probe(100kHz-3GHz) Narda EF0391 Q15221 Mar 29, 2022 Mar 28, 2023 1 Year H-Field Probe(300KHz-30MHz) Narda HF3061 Q15835 Mar 29, 2022 Mar 28, 2023 1 Year Broadband Field Meter Narda NBM-550 Q201455 Mar 29, 2022 Mar 28, 2023 1 Year Load Apple iPhone 8 Plus N/A N/A N/A N/A 4. Measuring Results EUT: Wireless charging Model Name. : HTY-2222 Temperature: 24 °C Relative Humidity: 56% Pressure: 1010hPa Test Date: 2022-01-13 Test Voltage: DC 5V from Adapter half-load: Table 1. H-Field MPE Data-Top EUT Side E (A/m) Limits (A/m) Max load 0.369 1.63 Table 2. H-Field MPE Data- Surrounding EUT Side B(A/m) A(A/m) C (A/m) D(above) (A/m) Limits (A/m) Max load 0.366 0.371 0.385 0.369 1.63 Table 3. E-Field MPE E-Field Measurement (15cm) EUT Side B(V/m) A(V/m) E(V/m) C (V/m) D(above) (V/m) Limits (V/m) Max load 2.156 2.138 2.214 2.199 2.176 614 empty load: Table 1. H-Field MPE Data-Top EUT Side E(A/m) Limits (A/m) Max load 0.334 1.63 Table 2. H-Field MPE Data- Surrounding EUT Side B(A/m) A(A/m) C (A/m) D(above) (A/m) Limits (A/m) Max load 0.338 0.339 0.349 0.351 1.63 Table 3. E-Field MPE E-Field Measurement (15cm) EUT Side B(V/m) A(V/m) E(V/m) C (V/m) D(above) (V/m) L…

Text truncated - open the document above for the full version.

深圳市恒泰盈科技有限公司 地址: 深圳市宝安区石岩街道料坑新村嘉一达科技园11栋2楼 商务QQ:207810361 Tel.电话:0755-27380665 Fax传真: 0752272139336 邮箱：[email protected] Page 1 of 1 深圳市恒泰盈科技有限公司 SHENZHEN HENGTAIYING TECHNOLOGY CO.,LTD Coil specification Date: 2022.12.07 To: supplier From: SHENZHEN HENGTAIYING TECHNOLOGY CO.,LTD Material code ：07600012 Model No: SG-9452 Total No. of Pages: Total 8 pages including this cover sheet Signature by customer SHENZHEN HENGTAIYING TECHNOLOGY CO.,LTD Checked Approved Name Date File No/Version.： 深圳市恒泰盈科技有限公司 地址: 深圳市宝安区石岩街道料坑新村嘉一达科技园11栋2楼 商务QQ:207810361 Tel.电话:0755-27380665 Fax传真: 0752272139336 邮箱：[email protected] Page 2 of 2 Update history NO Date Version Contents 1 2022-12-07 00 First release 深圳市恒泰盈科技有限公司 地址: 深圳市宝安区石岩街道料坑新村嘉一达科技园11栋2楼 商务QQ:207810361 Tel.电话:0755-27380665 Fax传真: 0752272139336 邮箱：[email protected] Page 3 of 3 INDEX 1. Basic specifications ................................................................................ 4 2. outline dimension ........................................................................................... 4 3.Windin gelectrical connection diagram ...................................................... 5 4. Winding line distribution profile map .................................................... 5 5. Circulating process ................................................................................. 6 6. Electrical performance parameters ........................................................ 6 7. process requirements ............................................................................. 7 8. Appearance and packaging requirements .............................................. 7 深圳市恒泰盈科技有限公司 地址: 深圳市宝安区石岩街道料坑新村嘉一达科技园11栋2楼 商务QQ:207810361 Tel.电话:0755-27380665 Fax传真: 0752272139336 邮箱：[email protected] Page 4 of 4 1. Basic specifications No. product name Coil model manufacturer remarks 1.0 three-winding SG-9452 supplier 07600012 K J K J K J Add a small piece of double-sided adhesive tape 深圳市恒泰盈科技有限公司 地址: 深圳市宝安区石岩街道料坑新村嘉一达科技园11栋2楼 商务QQ:207810361 Tel.电话:0755-27380665 Fax传真: 0752272139336 邮箱：[email protected] Page 5 of 5 2. External size diagram（unit：mm） K J K J G F H C H 38mm±2mm 75 6.8UH±8% The color of the line:Red K J D C A E B 1 ）： Unit ： MM 3 ）： Material ： Ferrite hard magnetic 2 ）： Single-sided adhesive backing Item Model : A28Three coils/A28Coil/Three coils/CD75/Single-sided adhesive backing/ Press the drawing Standard STD A B C D E F 94.5mm - 95mm 51.5mm - 52mm 3mm-4mm 20mm±2mm 80mm-84mm T I I 1.2mm(Max) T 4.0mm(Max) G 40mm(MAX) K 26.5mm - 27.5mm Coil Q Value （ Min) Test conditions 1.Ambient humidity ： 65±20% Ambient temperature ： 25±5 °C 2.Test conditions ： 100KHz 1V 47mm - 48mm Note ： Add a 1.5mm foam to the bottom of the core （ Black, Adhesive backing ） J 18mm - 20mm Tips：The coil overlap is four lines, the initial winding 8MM high temperature tape. unit： mm standard A B C D H E F I T G K J STD 95Ma x 52±1 3-4 22-23 37-38 80-84 40Max 1.2Max 4.0Max 47-48 26.5-27.5 18-20 深圳市恒泰盈科技有限公司 地址: 深圳市宝安区石岩街道料坑新村嘉一达科技园11栋2楼 商务QQ:207810361 Tel.电话:0755-27380665 Fax传真: 0752272139336 邮箱：[email protected] Page 6 of 6 3. circuit diagram N1 3 4 Coil2 5 6 Coil3 1 2 Coil1 Electrical performance parameters 深圳市恒泰盈科技有限公司 地址: 深圳市宝安区石岩街道料坑新村嘉一达科技园11栋2楼 商务QQ:207810361 Tel.电话:0755-27380665 Fax传真: 0752272139336 邮箱：[email protected] Page 7 of 7 5.1 test condition ：ambient humidity ：65±20% ambient temperature：25±5°C 5.2 inductance value： Coil=6.8uH±8% test condition ：100KHz 1V 5.3 direct-current resistance ： 50mΩ MAX 5.4 working temperature ：-25°C~130°C 5.5 bill of material 5.6 Q value=75MIN 5.6 bill of material 4. Coil process NO winding wire gauge number of windings The number of glue ring remarks 1 Coil1= Coil2=Coil 3 2UEW-B-0.08*105P 9TS 2 5. Appearance and packaging requirements NO project material 1 WIRE ￠0.08*105p 2UEW-1.15mm 2 FERRITE 94*52*0.8 Ferrite hard magnetic integrated molding 3 GLUE alban 4 SOLDER XCD-907B 5 Adhesive application of gum 深圳市恒泰盈科技有限公司 地址: 深圳市宝安区石岩街道料坑新村嘉一达科技园11栋2楼 商务QQ:207810361 Tel.电话:0755-27380665 Fax传真: 0752272139336 邮箱：[email protected] Page 8 of 8 1 exterior 1. The product shall have certificate of qualification, friction resistance and waterproof washing labels, indicating models and specifications. 2. The product appearance is clean and free of dirt. 2 package 1. The product should be packed in stratified intervals if one box, padded packing should be protected from impact collision, etc. 2. The cartoon box outside the package shall indicate the model name of the product, the factory date, the name of the manufacturer and the factory inspection seal. 3. After the goods reach the customer, the packing seal shall be in good condition without damage and cracking, and packed in the box

Report No.: S22122602001001 Version.1.1 Page 1 of 25 FCC Test Report FCC ID:2A5UE-HTY-2222 Product: Wireless charging Trade Name: N/A Model Number: HTY-2222 Family Model: N/A Report No.: S22122602001001 Prepared for SHENZHEN HENGTAIYING TECHNOLOGY CO.,LTD 2F, 11 Block, Kaetat Industrial Park, Liaokeng,Shiyan Street, Bao'an District,Shenzhen, 518000 China Prepared by Shenzhen NTEK Testing Technology Co., Ltd. 1/F, Building E, Fenda Science Park, SanweiCommunity,Xixiang Street, Bao’an District, Shenzhen P.R. China Tel:400-800-6106,0755-2320 0050 / 2320 0090 Website:http://www.ntek.org.cn Report No.: S22122602001001 Version.1.1 Page 2 of 25 TEST RESULTCERTIFICATION Applicant’s name ................. : SHENZHEN HENGTAIYING TECHNOLOGY CO.,LTD Address ................................. : 2F, 11 Block, Kaetat Industrial Park, Liaokeng,Shiyan Street, Bao'an District,Shenzhen, 518000 China Manufacturer's Name .......... : SHENZHEN HENGTAIYING TECHNOLOGY CO.,LTD Address ................................. : 2F, 11 Block, Kaetat Industrial Park, Liaokeng,Shiyan Street, Bao'an District,Shenzhen, 518000 China Product description Product name ........................... : Wireless charging Model and/or type reference : HTY-2222 Standards ............................. : FCC part 15C ANSI C63.10:2013 KDB 680106 D01 RF Exposure Wireless Charging App v03r01 This device described above has been tested by ShenzhenNTEK Testing Technology Co., Ltd., and the test results show that the equipment under test (EUT) is in compliance with the FCC requirements. And it is applicable only to the tested sample identified in the report. This report shall not be reproduced except in full, without the written approval of ShenzhenNTEK Testing Technology Co., Ltd., this document may be altered or revised by Shenzhen NTEK Testing Technology Co., Ltd., personnel only, and shall be noted in the revision of the document. The test results of this report relate only to the tested sample identified in this report. Date of Test ............................................ : Date (s) of performance of tests ............. : 03 Jan. 2023 ~ 13 Jan. 2023 Date of Issue ........................................... : 14 Jan. 2023 Test Result ............................................... : Pass Testing Engineer : (Allen Liu) Authorized Signatory : (Alex Li) Report No.: S22122602001001 Version.1.1 Page 3 of 25 Table of Contents Page 1 . TEST SUMMARY 4 1.1 FACILITIES AND ACCREDITATIONS 5 1.2 LABORATORY ACCREDITATIONS AND LISTINGS 5 1.3 MEASUREMENT UNCERTAINTY 5 2 . GENERAL INFORMATION 7 2.1 GENERAL DESCRIPTION OF EUT 7 2.2 DESCRIPTION OF TEST SETUP 9 2.3 DESCRIPTION TEST PERIPHERAL AND EUT PERIPHERAL 10 2.4 MEASUREMENT INSTRUMENTS LIST 11 3 . EMC EMISSION TEST 12 3.1 CONDUCTED EMISSION MEASUREMENT 12 3.1.1 POWER LINE CONDUCTED EMISSION 12 3.1.2 TEST PROCEDURE 13 3.1.3 TEST SETUP 13 3.1.4 EUT OPERATING CONDITIONS 13 3.1.5 TEST RESULTS 14 3.2 RADIATED EMISSION MEASUREMENT 16 3.2.1 LIMITS OF RADIATED EMISSION MEASUREMENT 16 3.2.2 TEST PROCEDURE 17 3.2.3 TEST SETUP 18 3.2.4 TEST RESULTS 19 4. BANDWIDTH TEST 23 4.1TEST PROCEDURE 23 4.2TEST SETUP 23 4.3 TEST RESULT 24 5. ANTENNA APPLICATION 25 5.1 Antenna Requirement 25 5.2 Result 25 Report No.: S22122602001001 Version.1.1 Page 4 of 25 1. TEST SUMMARY Test procedures according to the technical standards: EMC Emission Standard Test Item FCC Rules Limit Judgment Remark FCC part 15C:2018 ANSI C63.10:2013 Conducted Emission §15.207 Class B PASS Radiated Emission §15.209 Class B PASS ANTENNA APPLICATION §15.203 / PASS 20dB BANDWIDTH §15.215 Class B PASS NOTE: (1)’N/A’ denotes test is not applicable in this Test Report Report No.: S22122602001001 Version.1.1 Page 5 of 25 1.1 FACILITIES AND ACCREDITATIONS All measurement facilities used to collect the measurement data are located at 1/F, Building E, Fenda Science Park, Sanwei Community, Xixiang Street, Bao’an District, Shenzhen 518126 P.R. China. The sites are constructed in conformance with the requirements of ANSI C63.7, ANSI C63.10 and CISPR Publication 22. 1.2 LABORATORY ACCREDITATIONS AND LISTINGS Site Description CNAS-Lab. : The Certificate Registration Number is L5516. IC-Registration : The Certificate Registration Number is 9270A-1. FCC- Accredited : Test Firm Registration Number:463705. Designation Number: CN1184 A2LA-Lab. : The Certificate Registration Number is 4298.01 This laboratory is accredited in accordance with the recognized International Standard ISO/IEC 17025:2005General requirements for the competence of testing and calibration laboratories. This accreditation demonstratestechnical competence for a defined scope and the operation of a laboratory quality management system (refer to joint ISO-ILAC-IAF Communiqué dated 8 January 2009). Name of Firm : Shenzhen NTEK Testing Technology Co., Ltd. Site Location : 1/F, Building E, Fenda Science Park, Sanwei Community, Xixiang Street, Bao’an District, Shenzhen 518126 P.R. China. 1.3 MEASUREMENT UNCERTAINTY The reported uncertainty of measurement y ±U, where expended uncertainty U is based on a standard uncertainty multiplied by a coverage factor of k=2, providing a level of confidence of approximately 95 %. A. Conducted Measurement : Test Site Method Measurement Frequency Range U,(dB) NOTE NTEKC01 ANSI 150 KHz ~ 30MHz 2.8 B. Radiated Measurement : Test Site Method Measurement Frequency Range U,(dB) NOTE NTEKA01 ANSI 9KHz ~1000MHz 2.64 1GHz ~12.4GHz 2.40 Report No.: S22122602001001 Version.1.1 Page 6 of 25 Revision History Report No. Version Description Issued Date S22122602001001 Rev.01 Initial issue of report 14 Jan. 2023 Report No.: S22122602001001 Version.1.1 Page 7 of 25 2. GENERAL INFORMATION 2.1GENERAL DESCRIPTION OF EUT Product Feature and Specification Equipment Wireless charging Trade Name N/A FCC ID 2A5UE-HTY-2222 Model No. HTY-2222 Family Model N/A Model Difference N/A Operating Frequency 111kHz~175kHz Modulation Technique Induction Antenna Type Induction coil Power Rating Input:DC 5V2A…

Text truncated - open the document above for the full version.

Radiated Measurement Photos Conducted Measurement Photos
