2A5WDOD5STRGBCWLED Wall lamp

Smart wall lamp controlled by APP(CW+RGB) FCC Caution: Any Changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment. This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. IMPORTANT NOTE: Note: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: —Reorient or relocate the receiving antenna. —Increase the separation between the equipment and receiver. —Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. —Consult the dealer or an experienced radio/TV technician for help. FCC Radiation Exposure Statement: This equipment complies with FCC radiation exposure limits set forth for an uncontrolled environment.This equipment should be installed and operated with minimum distance 20cm between the radiator& your body.

Company Name: ADISION LIGHTING(HK).,CO.,LIMITED Add: 3rd Floor, No.13 Zhentian South Road, Yantian Village, Fenggang Town, Dongguan, Guangdong, China Tel:13684981205 Fax: 0769-88035655 Email:[email protected] Date: 2022-12-20 FEDERAL COMMUNICATIONS COMMISSIONS Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046 To whom it may concern: The RF chip, BK7231N which installed in our product LED Wall lamp , Model: OD5STRGBCW, FCC ID: 2A5WDOD5STRGBCW, supports BDR (GFSK), EDR (π/4- DQPSK, 8DPSK), BLE and 2.4G Wi-Fi functions. For use in America and this chip only support 2.4G Wi-Fi. The BLE and BDR (GFSK), EDR (π/4-DQPSK, 8DPSK) function has been shielded by the manufacturer using the software. Sincerely, Signature: Jack Chen General Manager

Company Name: ADISION LIGHTING(HK).,CO.,LIMITED Add: 3rd Floor, No.13 Zhentian South Road, Yantian Village, Fenggang Town, Dongguan, Guangdong, China Tel:13684981205 Fax: 0769-88035655 Email: [email protected] QA-FR-170-B 7/29/2014 FCC Authorization Date: 2022-12-20 FEDERAL COMMUNICATIONS COMMISSIONS Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046 Subject: Agent Authorization To whom it may concern: We ADISION LIGHTING(HK).,CO.,LIMITED, the undersigned, hereby authorizes Shenzhen Accurate Technology Co., Ltd. to act on its behalf in all matters relating to application for Equipment authorization, including the signing of all documents relating to these matters. All acts carried out by Shenzhen Accurate Technology Co., Ltd. on our behalf shall have the same effect as our own action. We, the undersigned, hereby certify that we are not subject to a denial of federal benefits, that includes FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C. 862. This authorization is valid until further written notice from the applicant. Sincerely Yours, Signature: Jack Chen General Manager

Company Name: ADISION LIGHTING(HK).,CO.,LIMITED Add: 3rd Floor, No.13 Zhentian South Road, Yantian Village, Fenggang Town, Dongguan, Guangdong, China Tel:13684981205 Fax: 0769-88035655 Email: [email protected] FCC Confidential Authorization Date: 2022-12-20 FEDERAL COMMUNICATIONS COMMISSIONS Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046 Subject: Confidentiality Request regarding application for certification of FCC ID: 2A5WDOD5STRGBCW In accordance with Sections 0.457 and 0.459 of the Commission’s Rules, ADISION LIGHTING(HK).,CO.,LIMITED hereby requests long-term confidential treatment of information accompanying this application as outlined below:  Block Diagram  Schematics  Operation Description The above materials contain proprietary and confidential information not customarily released to the public. The public disclosure of these materials provides unjustified benefits to its competitors in the market. Sincerely Yours, Signature: Jack Chen General Manager

Company Name: ADISION LIGHTING(HK).,CO.,LIMITED Add: 3rd Floor, No.13 Zhentian South Road, Yantian Village, Fenggang Town, Dongguan, Guangdong, China Tel:13684981205 Fax: 0769-88035655 Email: [email protected] Product Similarity Declaration 2022-12-20 Dear Sir/Madam, We, ADISION LIGHTING(HK).,CO.,LIMITED. hereby declare that we have a product named as LED Wall lamp (Model: OD5STRGBCW; FCC ID: 2A5WDOD5STRGBCW) was tested by Shenzhen Accurate Technology Co., Ltd., Meanwhile, for our marketing purpose, we would like to list series model: US-WL6A-X, US-WL6A-XX,on reports and certificate. The lamps are the same, but the model names are different , X,XX, representing a number, indicates how many products are contained in one box, which may be 1.2....99, etc. We confirm that all information above is true, and we’ll be responsible for all the consequences. Please contact me if you have any question. Sincerely Yours, Signature Jack Chen General Manager

Shenzhen Accurate Technology Co., Ltd. Project No.: RA221125-56986E-RF External Photos Page 1 of 3 External Photos Shenzhen Accurate Technology Co., Ltd. Project No.: RA221125-56986E-RF External Photos Page 2 of 3 Shenzhen Accurate Technology Co., Ltd. Project No.: RA221125-56986E-RF External Photos Page 3 of 3

Shenzhen Accurate Technology Co., Ltd. Project No.: RA221125-56986E-RF LABEL AND LOCATION Page 1 of 1 FCC ID Label FCC ID Label Location Information The label shown shall be permanently affixed at a conspicuous location on the device and be readily visible to the user at the time purchase (Labeling requirements per 2.925)

Shenzhen Accurate Technology Co., Ltd. Project No.: RA221125-56986E-RF Internal Photos Page 1 of 4 Internal Photos Shenzhen Accurate Technology Co., Ltd. Project No.: RA221125-56986E-RF Internal Photos Page 2 of 4 Shenzhen Accurate Technology Co., Ltd. Project No.: RA221125-56986E-RF Internal Photos Page 3 of 4 Shenzhen Accurate Technology Co., Ltd. Project No.: RA221125-56986E-RF Internal Photos Page 4 of 4 2.4G WIFI Antenna

Shenzhen Accurate Technology Co., Ltd. Report No.: RA221125-56986E-RF Version 12: 2021-11-09 Page 10 of 60 FCC- 2.4G Wi-Fi FCC §1.1307(b) – RF EXPOSURE Applicable Standard According to KDB 447498 D04 Interim General RF Exposure Guidance v01, clause 2.1.4–MPE-Based Exemption: An alternative to the SAR-based exemption is provided in § 1.1307(b)(3)(i)(C), for a much wider frequency range, from 300 kHz to 100 GHz, applicable for separation distances greater or equal to λ/2π, where λ is the free-space operating wavelength in meters. The MPE-based test exemption condition is in terms of ERP, defined as the product of the maximum antenna gain and the delivered maximum time-averaged power. For this case, a RF source is an RF exempt device if its ERP (watts) is no more than a frequency-dependent value, as detailed tabular form in Appendix B. These limits have been derived based on the basic specifications on Maximum Permissible Exposure (MPE) considered for the FCC rules in § 1.1310(e)(1). Table to § 1.1307(b)(3)(i)(C) - Single RF Sources Subject to Routine Environmental Evaluation f = frequency in MHz; R = minimum separation distance from the body of a nearby person (appropriate units, e.g., m); Test Result For worst case: Mode Frequency Range (MHz) Tune-up Output Power Antenna Gain ERP Evaluation Distance (cm) MPE-Based Exemption Limit (mW) (dBm) (mW) (dBi) (dBd) (dBm) (mW) 2.4G Wi-Fi 2412-2462 16.0 39.81 2.21 0.06 16.06 40.36 20 768 Note 1: The tune-up power was declared by the applicant. Note 2: 0dBd=2.15dBi. To maintain compliance with the FCC’s RF exposure guidelines, place the equipment at least 20cm from nearby persons. Result: Compliant.

Note: This report may contain data that are not covered by the A2LA accreditation and are marked with an asterisk “★”. Shenzhen Accurate Technology Co., Ltd. is not responsible for the authenticity of any test data provided by the applicant. Data included from the applicant that may affect testresults are marked with an asterisk ’*’. Customer model name, addresses, names, trademarks etc. are not considered data. This report cannot be reproduced except in full, without prior written approval of the Company. Unless otherwise stated the results shown in this test report refer only to the sample(s) tested. This report is valid only with a valid digital signature. The digital signature may be available only under the Adobe software above version 7.0. Shenzhen Accurate Technology Co., Ltd. 1/F., Building A, Changyuan New Material Port, Science & Industry Park, Nanshan District, Shenzhen, Guangdong, P.R. China Tel: +86 755-26503290 Fax: +86 755-26503396 Web: www.atc-lab.com Version 12: 2021-11-09 Page 1 of 60 FCC- 2.4G Wi-Fi TESTREPORT Applicant Name : ADISION LIGHTING (HK)., CO., LIMITED Address : 3rd Floor, No.13 Zhentian South Road, Yantian Village, Fenggang Town Dongguan, Guangdong, China Report Number: RA221125-56986E-RF FCC ID: 2A5WDOD5STRGBCW Test Standard (s) FCC Part 15.247 Sample Description Product: LED Wall lamp Model No.: OD5STRGBCW, US-WL6A-X, US-WL6A-XX Trade Name: N/A Date Received: 2022-11-25 Date of Test: 2022-11-30 to 2022-12-12 Report Date: 2022-12-17 Test Result: Pass* * In the configuration tested, the EUT complied with the standards above. Prepared and Checked By: Approved By: Roger.Ling Candy Li EMC Engineer EMC Engineer Shenzhen Accurate Technology Co., Ltd. Report No.: RA221125-56986E-RF Version 12: 2021-11-09 Page 2 of 60 FCC- 2.4G Wi-Fi TABLE OF CONTENTS GENERAL INFORMATION ....................................................................................................................................... 4 PRODUCT DESCRIPTION FOR EQUIPMENT UNDER TEST (EUT) ..................................................................................... 4 OBJECTIVE ................................................................................................................................................................... 4 TEST METHODOLOGY .................................................................................................................................................. 4 MEASUREMENT UNCERTAINTY .................................................................................................................................... 5 SYSTEM TEST CONFIGURATION .......................................................................................................................... 6 DESCRIPTION OF TEST CONFIGURATION ...................................................................................................................... 6 EQUIPMENT MODIFICATIONS ....................................................................................................................................... 6 EUT EXERCISE SOFTWARE .......................................................................................................................................... 6 DUTY CYCLE ................................................................................................................................................................ 6 SUPPORT EQUIPMENT LIST AND DETAILS .................................................................................................................... 6 EXTERNAL I/O CABLE.................................................................................................................................................. 6 SUMMARY OF TEST RESULTS ............................................................................................................................... 8 TEST EQUIPMENT LIST ........................................................................................................................................... 9 FCC §1.1307(b) – RF EXPOSURE ............................................................................................................................ 10 TEST RESULT ............................................................................................................................................................. 10 FCC §15.203 - ANTENNA REQUIREMENT ........................................................................................................... 11 APPLICABLE STANDARD ............................................................................................................................................ 11 ANTENNA CONNECTOR CONSTRUCTION .................................................................................................................... 11 FCC §15.207 (a) – AC LINE CONDUCTED EMISSIONS ..................................................................................... 12 APPLICABLE STANDARD ............................................................................................................................................ 12 EUT SETUP ................................................................................................................................................................ 12 EMI TEST RECEIVER SETUP ....................................................................................................................................... 12 TEST PROCEDURE ...................................................................................................................................................... 12 FACTOR & MARGIN CALCULATION ........................................................................................................................... 13 TEST DATA ................................................................................................................................................................ 13 FCC §15.209, §15.205 & §15.247…

Text truncated - open the document above for the full version.

Shenzhen Accurate Technology Co., Ltd. Project No.: RA221125-56986E-RF Test Photos Page 1 of 2 Photo of Power Line Conducted Emission Measurement Shenzhen Accurate Technology Co., Ltd. Project No.: RA221125-56986E-RF Test Photos Page 2 of 2 Radiated Spurious Emissions Test View (Below 1GHz) Radiated Spurious Emissions Test View (Above 1GHz)
