2A62QIMA02AR Glasses

FCC Warning Any Changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment. This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. Note: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: -Reorient or relocate the receiving antenna. -Increase the separation between the equipment and receiver. -Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. -Consult the dealer or an experienced radio/TV technician for help. This transmitter must not be co-located or operating in conjunction with any other antenna or transmitter. The device has been evaluated to meet general RF exposure requirement. The device can be used in portable exposure condition without restriction.

AOGES CO., LIMITED 1/1 US Agent for Service of Process LETTER OF ATTESTATION TO: Office of Engineering Technology Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 US Agent for Service of Process: Company Name: AOGES CO., LIMITED Contact Name: XIAOYAN LAI Address: Address: 1624 Market St., Ste 226, #30327 Denver CO, 80202 US Telephone No: +1 303 623 1940 Email: [email protected] FRN: 0033947847 Applicant: Company name: SHENZHEN YINGMU TECHNOLOGY CO., LTD Product Description: AR Glasses Grantee code: 2A62Q FCC ID: 2A62QIMA02 Contact Name: Eric Liu Address: D804,BUILDING F1,TCL INTERNATIONAL E CITY,SHUGUANG COMMUNITY,XILI STREET,NANSHAN DISTRICT,SHENZHEN,China Telephone No: 18603068048 Email: [email protected] [SHENZHEN YINGMU TECHNOLOGY CO., LTD] certifies that, as of the date of this filing of the application with the TCB, [AOGES CO., LIMITED] is our designated US agent for service of process for the above referenced FCC ID. [SHENZHEN YINGMU TECHNOLOGY CO., LTD] accepts to maintain an agent for no less than one year after the grantee has terminated all marketing and importation or the conclusion of any commission related proceeding involving equipment. [AOGES CO., LIMITED] accepts, as of the date of the filing of the application, the obligation of the designated US agent for service of process for the above reference FCC ID. The US Agent for Service of Process is aware of and agrees to comply with the requirements outlined in the FCC Equipment Authorization Program, Report and Order FCC 22-84, and clause § 2.911. The Applicant is aware of and agrees to comply with the requirements outlined in the FCC Equipment Authorization Program, Report and Order FCC 22-84, and clause § 2.911. Date: 2023/06/28 Applicant’s Name: SHENZHEN YINGMU TECHNOLOGY CO., LTD US Agent for Service of Process’s Name: AOGES CO., LIMITED Title: PM Title: General Manager Signature Eric Liu Signature XIAOYAN LAI

SHENZHEN YINGMU TECHNOLOGY CO., LTD Covered Equipment Certification Attestation Letter 6/26/2023 ATTN.: Reviewing Engineer FCC ID: 2A62QIMA02 SHENZHEN YINGMU TECHNOLOGY CO., LTD (“the applicant”) certifies that the equipment for which authorization is sought is not “covered” equipment prohibited from receiving an equipment authorization pursuant to section 2.903 of the FCC rules. Note: If the equipment for which the applicant seeks authorization is produced by any of the entities identified on the current Covered List, the applicant should include an explanation on why the equipment is not “covered” equipment. SHENZHEN YINGMU TECHNOLOGY CO., LTD (“the applicant”) certifies that, as of the date of the filing of the application, the applicant is not identified on the Covered List as an entity producing “covered” equipment. Signed: Printed name: Eric Liu Title: PM Company Name: SHENZHEN YINGMU TECHNOLOGY CO., LTD Date: 6/26/2023

FCC Software Configuration Control Declaration Rev1.1 SHENZHEN YINGMU TECHNOLOGY CO., LTD FCC Software Configuration Control Declaration Date: 2023.06.28 Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 USA Attn: SHENZHEN YINGMU TECHNOLOGY CO., LTD Product Name: AR Glasses Model Number(s): IMA02,IMA01,IMA03,IMA04,IMA05,IMA06,IMA07,IMA08,IMA09,IMR01,IMR02,IMR03, IMR04,IME05,IMR06,IMR07,IMR08,IMR09,IMX01,IMX02,IMX03,IMX04,IMX05,IMX06, IMX07,IMX08,IMX09,IMN01,IMN02,IMN03,IMN04,IMN05,IMN06,IMN07,IMN08,IMN09 FCC ID: 2A62QIMA02 Regarding FCC Country Code Selection guidelines identified in KDB 594280. “All applications for equipment authorization for transmitters that can have radio parameters, or other technical parameters, reported to the Commission set by software must have an attestation indicating that no third party will have software, or configuration control, to program the device out of compliance of the technical rules under which it has been certified.” We declare that no third party will have software, or configuration control, to program the device out of compliance of the technical rules under which it has been certified. Name: Jiankuai Li Date: 2023.06.28 Title: PM Signature of applicant

SHENZHEN YINGMU TECHNOLOGY CO., LTD Agent Authorization Company: SHENZHEN YINGMU TECHNOLOGY CO., LTD Address: D804,BUILDING F1,TCL INTERNATIONAL E CITY,SHUGUANG COMMUNITY,XILI STREET,NANSHAN DISTRICT,SHENZHEN,China Product Name: AR Glasses Model Number(s): IMA02,IMA01,IMA03,IMA04,IMA05,IMA06,IMA07,IMA08,IMA09,IMR01,IMR02,I MR03,IMR04,IME05,IMR06,IMR07,IMR08,IMR09,IMX01,IMX02,IMX03,IMX04,I MX05,IMX06,IMX07,IMX08,IMX09,IMN01,IMN02,IMN03,IMN04,IMN05,IMN06,I MN07,IMN08,IMN09 Product Description: AR Glasses FCC ID: 2A62QIMA02 We authorize MiCOM Labs Inc., 575 Boulder Court, Pleasanton, California 94566, USA, to act on our behalf on all matters concerning the certification of above named equipment. We declare that MiCOM Labs Inc. is allowed to forward all information related to the approval and certification of equipment to the regulatory agencies as required and to discuss any issues concerning the approval application. Any and all acts carried out by MiCOM Labs on our behalf shall have the same effect as acts of our own. Signature: Date: 2023.06.28 Name: Jiankuai Li Title: PM Company: Shenzhen STS Test Services Co., Ltd.

Differences Description We SHENZHEN YINGMU TECHNOLOGY CO., LTD state: Product： AR Glasses Model Name： IMA02,IMA01,IMA03,IMA04,IMA05,IMA06,IMA07, IMA08,IMA09,IMR01,IMR02,IMR03,IMR04,IME05, IMR06,IMR07,IMR08,IMR09,IMX01,IMX02,IMX03, IMX04,IMX05,IMX06,IMX07,IMX08,IMX09,IMN01, IMN02,IMN03,IMN04,IMN05,IMN06,IMN07,IMN08, IMN09 Trade Name: INMO FCC ID: 2A62QIMA02 The electrical circuit design, layout, components used and internal wiring for above models are identical, Only the model name is different. Signatory Signature: Date: 2023.06.28 Name: Jiankuai Li Title: PM Company: Shenzhen STS Test Services Co., Ltd.

2023.06.26 Federal Communications Commission Authorization & Evaluation Division 7345 Oakland Mills Road Columbia, Maryland 21046 RE: LETTER OF AGENT AUTHORIZATION To Whom It May Concern: We, the undersigned, hereby authorize SHENZHEN STS TEST SERVICES CO.,LTD./ A 1/F, Building B, Zhuoke Science Park, No.190 Chongqing Road, HepingShequ, Fuyong Sub-District,Bao’an District, Shenzhen, Guang Dong, China/Jiankuai Li(Name of Agent company name and address, Name of Agent) to act on our behalf in all matters relating to application for equipment authorization, including the signing of all documents relating to these matters. Name: Jiankuai Li Title: PM E-mail:[email protected] This appointment is valid until further until June 25, 2024 Sincerely, Name: Eric Liu Title: PM E-mail: [email protected] Company: SHENZHEN YINGMU TECHNOLOGY CO., LTD Signature:

SHENZHEN YINGMU TECHNOLOGY CO., LTD Office of Engineering Technology Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 USA Date: 2023.06.28 Subject; Request for Confidentiality FCC ID: 2A62QIMA02 To Whom It May Concern, Pursuant to the provisions of the Commission’s rules Title 47 Sections §0.457 and §0.459, we are requesting the Commission to withhold the following attachment(s) as confidential documents from public disclosure indefinitely. These documents contain detailed system and equipment descriptions and are considered as proprietary information in operation of the equipment. The public disclosure of these documents might be harmful to our company and would give competitors an unfair advantage in the market. Schematic Diagram Block Diagram Operational Description Tune-up Procedure Part List SOFTWARE SECURITY REQUIREMENTS FOR U-NII DEVICES In additional to above mentioned documents, in order to comply with the marketing regulations in Title 47 CFR §2.803 and the importation rules in Title 47 CFR §2.1204, while ensuring that business sensitive information remains confidential until the actual marketing of newly authorized devices, we request Short Term Confidentiality of the following attachment(s); External Photos Test Setup Photos Internal Photos User Manual For 45 days, pursuant to Public Notice DA 04-1705. OR For 180 days pursuant to KDB 726920 D01. It is our understanding that all measurement test reports, FCC ID label format and correspondence during the certification review process cannot be granted as confidential documents and this information will be available for public review once the grant of equipment authorization is issued. Sincerely, Signature: Name: Jiankuai Li Title: PM

Page 1 of 5 Report No.: STS2305321 APPENDIX-PHOTOGRAPHS OF EUT CONSTRUCTIONAL DETAILS Photo 1 Photo 2 Page 2 of 5 Report No.: STS2305321 Photo 3 Photo 4 Page 3 of 5 Report No.: STS2305321 Photo 5 Photo 6 Page 4 of 5 Report No.: STS2305321 Photo 7 Photo 8 Page 5 of 5 Report No.: STS2305321 Photo 9

FCC Label L: 40mm L W: 20mm AR Glasses Model name: IMA02 FCC ID: 2A62QIMA02

Page 1 of 6 ReportNo.:STS2305321 APPENDIX-PHOTOGRAPHSOFEUTCONSTRUCTIONALDETAILS Photo1 Photo2 BT/WIFI/GPSAntenna Page 2 of 6 ReportNo.:STS2305321 Photo3 Photo4 Page 3 of 6 ReportNo.:STS2305321 Photo5 Photo6 Page 4 of 6 ReportNo.:STS2305321 Photo7 Photo8 Page 5 of 6 ReportNo.:STS2305321 Photo9 Photo10 Page 6 of 6 ReportNo.:STS2305321 Photo11 Photo12

Any reproduction of this document must be done in full. No single part of this document may be reproduced without permission from STS, All Test Data Presented in this report is only applicable to presented Test sample. ShenZhen STS Test Services Co.,Ltd. A 1/F, Building B, Zhuoke Science Park, No.190 Chongqing Road, HepingShequ, Fuyong Sub-District, Bao’an District, Shenzhen, Guang Dong, China TEL: +86-755 3688 6288 FAX: +86-755 3688 6277 E-mail:[email protected] FCC SAR TEST REPORT Report No.: STS2305321H02 Issued for SHENZHEN YINGMU TECHNOLOGY CO., LTD D804,BUILDING F1,TCL INTERNATIONAL E CITY,SHUGUANG COMMUNITY,XILI STREET,NANSHAN DISTRICT,SHENZHEN,China Product Name: AR Glasses Brand: INMO Model Number: IMA02 Series Model(s): IMA01,IMA03,IMA04,IMA05,IMA06,IMA07, IMA08,IMA09,IMR01,IMR02,IMR03,IMR04, IME05,IMR06,IMR07,IMR08,IMR09,IMX01, IMX02,IMX03,IMX04,IMX05,IMX06,IMX07, IMX08,IMX09,IMN01,IMN02,IMN03,IMN04, IMN05,IMN06,IMN07,IMN08,IMN09 FCC ID: 2A62QIMA02 Test Standard: ANSI/IEEE Std. C95.1 FCC 47 CFR Part 2 ( 2.1093) IEC/IEEE 62209-1528 Max. Report SAR (1g): Body: 1.569 W/kg S T L A B S Page 2 of 51 Report No.: STS2305321H02 Test Report Certification Applicant’s name ................. : SHENZHEN YINGMU TECHNOLOGY CO., LTD Address ................................. : D804,BUILDING F1,TCL INTERNATIONAL E CITY,SHUGUANG COMMUNITY,XILI STREET,NANSHAN DISTRICT,SHENZHEN,China Manufacture's Name ............ : SHENZHEN YINGMU TECHNOLOGY CO., LTD Address ................................. : D804,BUILDING F1,TCL INTERNATIONAL E CITY,SHUGUANG COMMUNITY,XILI STREET,NANSHAN DISTRICT,SHENZHEN,China Product description Product name ........................ : AR Glasses Brand name ......................... : INMO Model name ......................... : IMA02 Series Model .......................... : IMA01,IMA03,IMA04,IMA05,IMA06,IMA07,IMA08,IMA09, IMR01,IMR02,IMR03,IMR04,IME05,IMR06,IMR07,IMR08,IMR09, IMX01,IMX02,IMX03,IMX04,IMX05,IMX06,IMX07,IMX08,IMX09, IMN01,IMN02,IMN03,IMN04,IMN05,IMN06,IMN07,IMN08,IMN09 Standards ............................. : ANSI/IEEE Std. C95.1-1992 FCC 47 CFR Part 2 (2.1093) IEC/IEEE 62209-1528 The device was tested by Shenzhen STS Test Services Co., Ltd. in accordance with the measurement methods and procedures specified in KDB 865664 The test results in this report apply only to the tested sample of the stated device/equipment. Other similar device/equipment will not necessarily produce the same results due to production tolerance and measurement uncertainties. Date of Test Date (s) of performance of tests ............. : 22 May 2023 ~ 26 May 2023 Date of Issue .......................................... : 31 May 2023 Test Result .............................................. : Pass Testing Engineer : (Shifan. Long) Technical Manager : (Sean she) Authorized Signatory : (Bovey Yang) Page 3 of 51 Report No.: STS2305321H02 Table of Contents 1. General Information 5 1.1 EUT Description 5 1.2 Test Environment 6 1.3 Test Factory 6 2. Test Standards and Limits 7 3. SAR Measurement System 8 3.1 Definition of Specific Absorption Rate (SAR) 8 3.2 SAR System 8 4. Tissue Simulating Liquids 11 4.1 Simulating Liquids Parameter Check 11 5. SAR System Validation 14 5.1 Validation System 14 5.2 Validation Result 14 6. SAR Evaluation Procedures 15 7. EUT Antenna Location Sketch 16 7.1 SAR test exclusion consider table 17 8. EUT Test Position 20 8.1 Body-worn Position Conditions 20 9. Measurement Uncertainty 21 10. Conducted Power Measurement 22 10.1 Test Result 22 11. EUT And Test Setup Photo 25 11.1 EUT Photo 25 11.2 Setup Photo 28 12. SAR Result Summary 31 12.1 Body-worn SAR 31 13. Equipment List 35 Appendix A. System Validation Plots 36 Appendix B. SAR Test Plots 46 Appendix C. Probe Calibration And Dipole Calibration Report 51 Page 4 of 51 Report No.: STS2305321H02 Revision History Rev. Issue Date Report No. Effect Page Contents 00 31 May 2023 STS2305321H02 ALL Initial Issue Page 5 of 51 Report No.: STS2305321H02 1. General Information Environmental evaluation measurements of specific absorption rate (SAR) distributions in emulated human head and body tissues exposed to radio frequency (RF) radiation from wireless portable devices for compliance with the rules and regulations of the U.S. Federal Communications Commission (FCC). 1.1 EUT Description Product Name AR Glasses Brand Name INMO Model Name IMA02 Series Model IMA01,IMA03,IMA04,IMA05,IMA06,IMA07,IMA08,IMA09, IMR01,IMR02,IMR03,IMR04,IME05,IMR06,IMR07,IMR08,IMR09, IMX01,IMX02,IMX03,IMX04,IMX05,IMX06,IMX07,IMX08,IMX09, IMN01,IMN02,IMN03,IMN04,IMN05,IMN06,IMN07,IMN08,IMN09 Model Difference Only the model name is different Battery Model: 411832-L Rated Voltage:3.8V Charge Limit Voltage:4.35V Capacity: 250mAh Model: 411832-R Rated Voltage:3.8V Charge Limit Voltage:4.35V Capacity: 250mAh Device Category Portable Product stage Production unit RF Exposure Environment General Population / Uncontrolled Hardware Version IMA02_V1.0 Software Version Air2_B_V2.5.020_Release_202306071200 Frequency Range WLAN802.11b/g/n20: 2412 MHz ~ 2462 MHz WLAN 802.11n40: 2422 MHz ~ 2452 MHz WLAN 802.11a/n20/n40/ac20/ac40/ac80: 5150 ~ 5250 MHz WLAN 802.11a/n20/n40/ac20/ac40/ac80: 5250 ~ 5350 MHz WLAN 802.11a/n20/n40/ac20/ac40/ac80: 5470 ~ 5725 MHz WLAN 802.11a/n20/n40/ac20/ac40/ac80: 5725 ~ 5850 MHz Bluetooth: 2402 to 2480 MHz Max. Reported SAR(1g): (Limit:1.6W/kg) Band Mode Body worn (W/kg) DTS 2.4GHz WLAN 1.323 NII 5.2GHz WLAN 1.517 NII 5.3GHz WLAN 1.569 NII 5.6GHz WLAN 1.400 NII 5.8GHz WLAN 1.536 FCC Equipment Class Part 15 Spread Spectrum Transmitter (DSS) Unlicensed National Information Infrastructure TX (NII) Digital Transmission System (DTS) Operating Mode WLAN: 802.11 a/b/g/n20/n40/ac20/ac40/ac80 Bluetooth: GFSK +π/4DQPSK+8DPSK BLE: GFSK Antenna Specification PIFA Antenna Hotspot Mode Not Support Page 6 of 51 Report No.: STS2305321H02 DTM Mode Not Support Note: 1. The EUT battery must be fully charged and checked periodically during the test to ascertain un…

Text truncated - open the document above for the full version.

Page: 1/10 Ref : ACR.60.17.23.MVGB.A SHENZHEN STS TEST SERVICES CO., LTD. 1/F, BUILDING 2, ZHUOKE SCIENCE PARK, CHONGQING ROAD FUYONG, BAO’ AN DISTRICT, SHENZHEN,CHINA MVG COMOSAR DOSIMETRIC E-FIELD PROBE SERIAL NO.: SN 07/21 EPGO352 Calibrated at MVG Z.I. de la pointe du diable Technopôle Brest Iroise – 295 avenue Alexis de Rochon 29280 PLOUZANE - FRANCE Calibration date: 02/24/2023 Accreditations #2-6789 and #2-6814 Scope available on www.cofrac.fr Summary: This document presents the method and results from an accredited COMOSAR E-Field Probe calibration performed at MVG, using the CALIPROBE test bench, for use with a MVG COMOSAR system only. The test results covered by accreditation are traceable to the International System of Units (SI). COMOSAR E-Field Probe Calibration Report COMOSAR E-FIELD PROBE CALIBRATION REPORT Page: 3/10 Template_ACR.DDD.N.YY.MVGB.ISSUE_COMOSAR Probe vH This document shall not be reproduced, except in full or in part, without the written approval of MVG. The information contained herein is to be used only for the purpose for which it is submitted and is not to be released in whole or part without written approval of MVG. TABLE OF CONTENTS 1 Device Under Test ..................................................................................................... 4 2 Product Description ................................................................................................... 4 2.1 General Information _______________________________________________________ 4 3 Measurement Method ................................................................................................ 4 3.1 Linearity ________________________________________________________________ 4 3.2 Sensitivity _______________________________________________________________ 5 3.3 Lower Detection Limit _____________________________________________________ 5 3.4 Isotropy _________________________________________________________________ 5 3.1 Boundary Effect __________________________________________________________ 5 4 Measurement Uncertainty .......................................................................................... 6 5 Calibration Measurement Results .............................................................................. 6 5.1 Sensitivity in air __________________________________________________________ 6 5.2 Linearity ________________________________________________________________ 7 5.3 Sensitivity in liquid ________________________________________________________ 8 5.4 Isotropy _________________________________________________________________ 9 6 List of Equipment .................................................................................................... 10 Ref: ACR.60.17.23.MVGB.A COMOSAR E-FIELD PROBE CALIBRATION REPORT Page: 4/10 Template_ACR.DDD.N.YY.MVGB.ISSUE_COMOSAR Probe vH This document shall not be reproduced, except in full or in part, without the written approval of MVG. The information contained herein is to be used only for the purpose for which it is submitted and is not to be released in whole or part without written approval of MVG. 1 DEVICE UNDER TEST Device Under Test Device Type COMOSAR DOSIMETRIC E FIELD PROBE Manufacturer MVG Model SSE2 Serial Number SN 07/21 EPGO352 Product Condition (new / used) Used Frequency Range of Probe 0.15 GHz-6GHz Resistance of Three Dipoles at Connector Dipole 1: R1=0.227 M Dipole 2: R2=0.203 M Dipole 3: R3=0.195 M 2 PRODUCT DESCRIPTION 2.1 GENERAL INFORMATION MVG’s COMOSAR E field Probes are built in accordance to the IEEE 1528, FCC KDB865664 D01, CENELEC EN62209 and CEI/IEC 62209 standards. Figure 1 – MVG COMOSAR Dosimetric E field Dipole Probe Length 330 mm Length of Individual Dipoles 2 mm Maximum external diameter 8 mm Probe Tip External Diameter 2.5 mm Distance between dipoles / probe extremity 1 mm 3 MEASUREMENT METHOD The IEEE 1528, FCC KDB865664 D01, CENELEC EN62209 and CEI/IEC 62209 standards provide recommended practices for the probe calibrations, including the performance characteristics of interest and methods by which to assess their affect. All calibrations / measurements performed meet the fore mentioned standards. 3.1 LINEARITY The evaluation of the linearity was done in free space using the waveguide, performing a power sweep to cover the SAR range 0.01W/kg to 100W/kg. Ref: ACR.60.17.23.MVGB.A COMOSAR E-FIELD PROBE CALIBRATION REPORT Page: 5/10 Template_ACR.DDD.N.YY.MVGB.ISSUE_COMOSAR Probe vH This document shall not be reproduced, except in full or in part, without the written approval of MVG. The information contained herein is to be used only for the purpose for which it is submitted and is not to be released in whole or part without written approval of MVG. 3.2 SENSITIVITY The sensitivity factors of the three dipoles were determined using a two step calibration method (air and tissue simulating liquid) using waveguides as outlined in the standards. 3.3 LOWER DETECTION LIMIT The lower detection limit was assessed using the same measurement set up as used for the linearity measurement. The required lower detection limit is 10 mW/kg. 3.4 ISOTROPY The axial isotropy was evaluated by exposing the probe to a reference wave from a standard dipole with the dipole mounted under the flat phantom in the test configuration suggested for system validations and checks. The probe was rotated along its main axis from 0 to 360 degrees in 15- degree steps. The hemispherical isotropy is determined by inserting the probe in a thin plastic box filled with tissue-equivalent liquid, with the plastic box illuminated with the fields from a half wave dipole. The dipole is rotated about its axis (0°–180°) in 15° increments. At each step the probe is rotated about its axis (0°–360°). 3.1 BOUNDARY EFFECT The boundary effect is defined as the deviation between the SAR measured data and the expected exponential decay in the liquid when the probe is oriented normal to the interface. To evaluate this effect, the liquid …

Text truncated - open the document above for the full version.

Report No: STS2305321W09_Appendix 5G WIFI U-NII-1 1. Duty Cycle Condition Mode Frequency (MHz) Duty Cycle (%) Correction Factor (dB) 1/T (kHz) NVNT a 5180 95.78 0.19 0.72 NVNT a 5200 96.34 0.16 0.72 NVNT a 5240 96.38 0.16 0.72 NVNT n20 5180 95.75 0.19 0.85 NVNT n20 5200 95.71 0.19 0.85 NVNT n20 5240 95.71 0.19 0.85 NVNT n40 5190 91.85 0.37 1.7 NVNT n40 5230 91.89 0.37 1.7 NVNT ac20 5180 95.73 0.19 0.84 NVNT ac20 5200 95.73 0.19 0.84 NVNT ac20 5240 95.73 0.19 0.84 NVNT ac40 5190 91.9 0.37 1.68 NVNT ac40 5230 91.94 0.36 1.68 NVNT ac80 5210 85.1 0.7 3.37 Report No: STS2305321W09_Appendix 5G WIFI U-NII-1 Test Graphs Duty Cycle NVNT a 5180MHz Duty Cycle NVNT a 5200MHz Report No: STS2305321W09_Appendix 5G WIFI U-NII-1 Duty Cycle NVNT a 5240MHz Duty Cycle NVNT n20 5180MHz Report No: STS2305321W09_Appendix 5G WIFI U-NII-1 Duty Cycle NVNT n20 5200MHz Duty Cycle NVNT n20 5240MHz Report No: STS2305321W09_Appendix 5G WIFI U-NII-1 Duty Cycle NVNT n40 5190MHz Duty Cycle NVNT n40 5230MHz Report No: STS2305321W09_Appendix 5G WIFI U-NII-1 Duty Cycle NVNT ac20 5180MHz Duty Cycle NVNT ac20 5200MHz Report No: STS2305321W09_Appendix 5G WIFI U-NII-1 Duty Cycle NVNT ac20 5240MHz Duty Cycle NVNT ac40 5190MHz Report No: STS2305321W09_Appendix 5G WIFI U-NII-1 Duty Cycle NVNT ac40 5230MHz Duty Cycle NVNT ac80 5210MHz Report No: STS2305321W09_Appendix 5G WIFI U-NII-1 2. Maximum Conducted Output Power Condition Mode Frequency (MHz) Conducted Power (dBm) Duty Factor (dB) Total Power (dBm) Limit (dBm) Verdict NVNT a 5180 10.39 0.19 10.58 <=24 Pass NVNT a 5200 10.04 0.16 10.2 <=24 Pass NVNT a 5240 10.2 0.16 10.36 <=24 Pass NVNT n20 5180 10.28 0.19 10.47 <=24 Pass NVNT n20 5200 10.31 0.19 10.5 <=24 Pass NVNT n20 5240 10.45 0.19 10.64 <=24 Pass NVNT n40 5190 9.97 0.37 10.34 <=24 Pass NVNT n40 5230 10.12 0.37 10.49 <=24 Pass NVNT ac20 5180 10.4 0.19 10.59 <=24 Pass NVNT ac20 5200 10.38 0.19 10.57 <=24 Pass NVNT ac20 5240 10.34 0.19 10.53 <=24 Pass NVNT ac40 5190 9.99 0.37 10.36 <=24 Pass NVNT ac40 5230 10.08 0.36 10.44 <=24 Pass NVNT ac80 5210 9.63 0.7 10.33 <=24 Pass Report No: STS2305321W09_Appendix 5G WIFI U-NII-1 Test Graphs Power NVNT a 5180MHz Power NVNT a 5200MHz Report No: STS2305321W09_Appendix 5G WIFI U-NII-1 Power NVNT a 5240MHz Power NVNT n20 5180MHz Report No: STS2305321W09_Appendix 5G WIFI U-NII-1 Power NVNT n20 5200MHz Power NVNT n20 5240MHz Report No: STS2305321W09_Appendix 5G WIFI U-NII-1 Power NVNT n40 5190MHz Power NVNT n40 5230MHz Report No: STS2305321W09_Appendix 5G WIFI U-NII-1 Power NVNT ac20 5180MHz Power NVNT ac20 5200MHz Report No: STS2305321W09_Appendix 5G WIFI U-NII-1 Power NVNT ac20 5240MHz Power NVNT ac40 5190MHz Report No: STS2305321W09_Appendix 5G WIFI U-NII-1 Power NVNT ac40 5230MHz Power NVNT ac80 5210MHz Report No: STS2305321W09_Appendix 5G WIFI U-NII-1 3. -26dB Bandwidth Condition Mode Frequency (MHz) -26 dB Bandwidth (MHz) Verdict NVNT a 5180 27.6539 Pass NVNT a 5200 26.5372 Pass NVNT a 5240 27.0918 Pass NVNT n20 5180 28.2911 Pass NVNT n20 5200 29.3937 Pass NVNT n20 5240 27.3702 Pass NVNT n40 5190 41.3314 Pass NVNT n40 5230 43.7805 Pass NVNT ac20 5180 25.2269 Pass NVNT ac20 5200 26.4365 Pass NVNT ac20 5240 29.5366 Pass NVNT ac40 5190 47.3817 Pass NVNT ac40 5230 39.743 Pass NVNT ac80 5210 80.0753 Pass Report No: STS2305321W09_Appendix 5G WIFI U-NII-1 Test Graphs -26dB Bandwidth NVNT a 5180MHz -26dB Bandwidth NVNT a 5200MHz Report No: STS2305321W09_Appendix 5G WIFI U-NII-1 -26dB Bandwidth NVNT a 5240MHz -26dB Bandwidth NVNT n20 5180MHz Report No: STS2305321W09_Appendix 5G WIFI U-NII-1 -26dB Bandwidth NVNT n20 5200MHz -26dB Bandwidth NVNT n20 5240MHz Report No: STS2305321W09_Appendix 5G WIFI U-NII-1 -26dB Bandwidth NVNT n40 5190MHz -26dB Bandwidth NVNT n40 5230MHz Report No: STS2305321W09_Appendix 5G WIFI U-NII-1 -26dB Bandwidth NVNT ac20 5180MHz -26dB Bandwidth NVNT ac20 5200MHz Report No: STS2305321W09_Appendix 5G WIFI U-NII-1 -26dB Bandwidth NVNT ac20 5240MHz -26dB Bandwidth NVNT ac40 5190MHz Report No: STS2305321W09_Appendix 5G WIFI U-NII-1 -26dB Bandwidth NVNT ac40 5230MHz -26dB Bandwidth NVNT ac80 5210MHz Report No: STS2305321W09_Appendix 5G WIFI U-NII-1 4. Occupied Channel Bandwidth Condition Mode Frequency (MHz) 99% OBW (MHz) NVNT a 5180 16.5733 NVNT a 5200 16.5342 NVNT a 5240 16.5691 NVNT n20 5180 17.6181 NVNT n20 5200 17.6359 NVNT n20 5240 17.5973 NVNT n40 5190 36.2907 NVNT n40 5230 36.252 NVNT ac20 5180 17.6238 NVNT ac20 5200 17.6288 NVNT ac20 5240 17.642 NVNT ac40 5190 36.313 NVNT ac40 5230 36.302 NVNT ac80 5210 75.5002 Report No: STS2305321W09_Appendix 5G WIFI U-NII-1 Test Graphs OBW NVNT a 5180MHz OBW NVNT a 5200MHz Report No: STS2305321W09_Appendix 5G WIFI U-NII-1 OBW NVNT a 5240MHz OBW NVNT n20 5180MHz Report No: STS2305321W09_Appendix 5G WIFI U-NII-1 OBW NVNT n20 5200MHz OBW NVNT n20 5240MHz Report No: STS2305321W09_Appendix 5G WIFI U-NII-1 OBW NVNT n40 5190MHz OBW NVNT n40 5230MHz Report No: STS2305321W09_Appendix 5G WIFI U-NII-1 OBW NVNT ac20 5180MHz OBW NVNT ac20 5200MHz Report No: STS2305321W09_Appendix 5G WIFI U-NII-1 OBW NVNT ac20 5240MHz OBW NVNT ac40 5190MHz Report No: STS2305321W09_Appendix 5G WIFI U-NII-1 OBW NVNT ac40 5230MHz OBW NVNT ac80 5210MHz Report No: STS2305321W09_Appendix 5G WIFI U-NII-1 5. Maximum Power Spectral Density Level Condition Mode Frequency (MHz) Conducted PSD (dBm) Duty Factor (dB) Total PSD (dBm) Limit (dBm) Verdict NVNT a 5180 -0.328 0.19 -0.138 <=11 Pass NVNT a 5200 -0.509 0.16 -0.349 <=11 Pass NVNT a 5240 -0.434 0.16 -0.274 <=11 Pass NVNT n20 5180 -0.679 0.19 -0.489 <=11 Pass NVNT n20 5200 -0.375 0.19 -0.185 <=11 Pass NVNT n20 5240 -0.358 0.19 -0.168 <=11 Pass NVNT n40 5190 -3.768 0.37 -3.398 <=11 Pass NVNT n40 5230 -3.843 0.37 -3.473 <=11 Pass NVNT ac20 5180 -0.38 0.19 -0.19 <=11 Pass NVNT ac20 5200 -0.435 0.19 -0.245 <=11 Pass NVNT ac20 5240 -0.428 0.19 -0.238 <=11 Pass NVNT ac40 5190 -4.053 0.37 -3.683 <=11 Pass NVNT ac40 5230 -3.676 0.36 -3.316 <=11 Pass NVNT ac80 5210 -7.152 0.7 -6.452 <=11 Pass Report No: STS2305321W09_Appendix 5G…

Text truncated - open the document above for the full version.

Report No: STS2305321W09_Appendix 5G WIFI U-NII-2A 1. Duty Cycle Condition Mode Frequency (MHz) Duty Cycle (%) Correction Factor (dB) 1/T (kHz) NVNT a 5260 96.38 0.16 0.72 NVNT a 5300 96.38 0.16 0.72 NVNT a 5320 96.38 0.16 0.72 NVNT n20 5260 95.71 0.19 0.85 NVNT n20 5300 95.02 0.22 0.85 NVNT n20 5320 95.71 0.19 0.85 NVNT n40 5270 91.89 0.37 1.7 NVNT n40 5310 91.89 0.37 1.7 NVNT ac20 5260 95.81 0.19 0.84 NVNT ac20 5300 95.77 0.19 0.84 NVNT ac20 5320 95.77 0.19 0.84 NVNT ac40 5270 90.64 0.43 1.68 NVNT ac40 5310 91.9 0.37 1.68 NVNT ac80 5290 85.05 0.7 3.37 Report No: STS2305321W09_Appendix 5G WIFI U-NII-2A Test Graphs Duty Cycle NVNT a 5260MHz Duty Cycle NVNT a 5300MHz Report No: STS2305321W09_Appendix 5G WIFI U-NII-2A Duty Cycle NVNT a 5320MHz Duty Cycle NVNT n20 5260MHz Report No: STS2305321W09_Appendix 5G WIFI U-NII-2A Duty Cycle NVNT n20 5300MHz Duty Cycle NVNT n20 5320MHz Report No: STS2305321W09_Appendix 5G WIFI U-NII-2A Duty Cycle NVNT n40 5270MHz Duty Cycle NVNT n40 5310MHz Report No: STS2305321W09_Appendix 5…
