2A633-A8BWifi CCTV IP CAMERA

Wifi CCTV IP Camera Quick Operation Guide 1. APP download Search and download "iCSee"in the app store or scan the QR code below to download. 2.Connect to the power supply Plz connect camera to the power cable,and turn on the power . If you need to storage the video via the local TF card, plz install the TF card first then turn on the power（TF card doesn't support the hot plugging, plz plug and unplug memory card when device is power off)recommend use the cloud storage, safe and convenient, the detailed operation see "step 6". 3.Register/login 1.Open"iCSee" app, click "sign up" then use the phone number or mailbox to register account(image 1). 2.Register successfully, enter your phone number or mail number in the login interface, enter the password, login your app. 3.You can also use the wechat, facebook, line or the temporary visit to login app. image 1 temporary visit 4.Camera network configuration wifi configuration(recommend) Note: camera can support 2.4G wifi for the time being, doesn't support 5Gwifi,plz set the router parameter to 2.4G first before configuring network, during the connection, phone,router and camera need keep within the 2m distance image 5 1.Phone connect to the wifi network. 2.Click the "+"in the upper right corner(image 2)click the "Add WiFi camera"(image 3) according to the device's voice prompt, follow the app interface guide to enter router's password(image 4)click "confirm" start to configure network(if the device doesn't appear voice prompt for a long time, you can long press the reset to restore default, then go on to configure network). image 2 image 3 image 4 image 5 image 6 image 7 image 8 image 9 3.Enter the search device's interface, the device is in the connection process, plz wait(image 5). 4.After connecting successfully ,interface will prompt to set device's password and name for your device, after finishing, follow the app interface guide to complete network configuration (image 6,7,8,9). 5.After finishing, device will show in the device's list, it represent the device is connecting successfully(image 10). 6.Click it you can view the monitoring image, and do the relevant operation and setting(image 11). image 10 image 11 If the wifi configure failed, you can choose the below ways to configure device: 01.AP mode configure network(android version) 1.Long press reset to restore default. 2.Press the camera reset three times to enter the AP mode (most devices will voice prompt "enter the AP mode"). 3. Login the “iCSee” app ,click the “+”in the upper right corner, and click “more” in the upper right corner(image 12). 4.click “Add camera(AP mode)(image 13). 5.Enter “choose device’s hotpot” interface, connect the searched device’s hotpot (robot’ hotspot name:robot_XXXX; other device's hotspot name: camera_XXXX)(image 14). image 12 image 13 image 14 6.After connecting successfully, interface will show router setting page, choose your wifi, enter wifi’s password to start configure network(image 15). 7.Interface will show “Connect to the router network”(image 16). 8.After connecting successfully, follow the app interface guide to complete network configuration. 9.Device will show in the device’s list, which represent device connection successful(image 10). click it to view the monitoring image, also can do the relevant operation and setting(image 11). image 15 image 16 01.AP mode configurate network(ios version) image 17 image 18 1.Long press reset to restore default 2.Press the camera reset three times to enter the AP mode (most devices will voice prompt "enter the AP mode"). 3. Login the “iCSee” app ,click the “+”in the upper right corner,click “Add camera(AP mode)(image 17). 4.Click the “To set the WiFi”(image 18),search the wireless network of the mobile phone, select the wireless hotspot of the device, enter the wireless password: 1234567890, then connect device's wireless hotspot (robot’ hotspot name:robot_XXXX; other device's hotspot name: camera_XXXX). 5.Return “iCSee”app, enter “router setting” interface(image 19),enter wifi account and password, click confirm to start router network configuration. 6.Enter “searching device” interface, wait for connection(image 20). 7.After connecting successfully, follow the app interface guide to complete network configuration. 8.Device will show in the device’s list, which represent device connection successful(image 10). click it to view the monitoring image, also can do the relevant operation and setting(image 11). image 19 image 20 02.Wired network configuration (the device should support wired network connection, that is, the device has a network connection port) 1.Long press reset to restore default. 2.Connect your router to camera via network cable. 3.Connect phone to your router wifi network. 4.Login “iCSee” app, click the “+”in the upper right corner, and click “more” in the upper right corner(image 21). 5.click “Add the camera on same router(image 22). 6.Enter search device interface, click searched camera to add device(image 23),device will show in the device’s list, which represent device connect successfully(image10). 7.Click it to view the monitoring image, also can do the relevant operation and setting(image11). image 21 image 22 image 23 03. Hotpot direct connection to configurate network (no need external network, connect to device’s hotpot directly to configure network ,in this mode, the mobile phone cannot receive messages from the device and use the cloud service) 1.Long press reset to restore default. 2.Press the camera Reset three times to enter the AP mode (most devices will voice prompt "enter the AP mode"). 3.Search the wireless network of the mobile phone, select the wireless hotspot of the device, enter the wireless password: 1234567890, then connect device's wireless hotspot (robot’ hotspot name:robot_XXXX; other device's hotspot name: camera_XXXX). 4.Open“iCSee”app,via temporary visit mode to add device directly(image 24) 5.Device will show in the device’s list, which represent device c…

Text truncated - open the document above for the full version.

ShenZhen Besder Technology Co.,Ltd. Agent Authorization Company: ShenZhen Besder Technology Co.,Ltd. Address: 4F Building B, East Area No.10 Of Shangxue Technology Park, Bantian , Longgang District, Shenzhen, China Product Name: Wifi CCTV IP CAMERA Model Number(s): A8B Product Description: WIFI CAMERA We authorize MiCOM Labs Inc., 575 Boulder Court, Pleasanton, California 94566, USA, to act on our behalf on all matters concerning the certification of above named equipment. We declare that MiCOM Labs Inc. is allowed to forward all information related to the approval and certification of equipment to the regulatory agencies as required and to discuss any issues concerning the approval application. Any and all acts carried out by MiCOM Labs on our behalf shall have the same effect as acts of our own. Signature: Date: May.31,2022 Name: Feng Xiaoqiong Title: Sales manager Company: ShenZhen Besder Technology Co.,Ltd.

ShenZhen Besder Technology Co.,Ltd. Office of Engineering Technology Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 USA Date: June 2, 2022 Subject; Request for Confidentiality FCC ID: 2A633-A8B To Whom It May Concern, Pursuant to the provisions of the Commission’s rules Title 47 Sections §0.457 and §0.459, we are requesting the Commission to withhold the following attachment(s) as confidential documents from public disclosure indefinitely. These documents contain detailed system and equipment descriptions and are considered as proprietary information in operation of the equipment. The public disclosure of these documents might be harmful to our company and would give competitors an unfair advantage in the market. Schematic Diagram Block Diagram Parts List Operational Description Software Security Requirements for UNII devices In additional to above mentioned documents, in order to comply with the marketing regulations in Title 47 CFR §2.803 and the importation rules in Title 47 CFR §2.1204, while ensuring that business sensitive information remains confidential until the actual marketing of newly authorized devices, we request Short Term Confidentiality of the following attachment(s); External Photos Test Setup Photos Internal Photos User Manual For 45 days, pursuant to Public Notice DA 04-1705. OR For 180 days pursuant to KDB 726920 D01. It is our understanding that all measurement test reports, FCC ID label format and correspondence during the certification review process cannot be granted as confidential documents and this information will be available for public review once the grant of equipment authorization is issued. Sincerely, Signature: Name: Feng Xiaoqiong Title: Sales manager

- Page 1 of 8 - Ext Photos - Page 2 of 8 - WIFI ANT False ANT - Page 3 of 8 -

标签位置：样品背面放上即可。 Product Name： Wifi CCTV IP CAMERA Model No.： A8B Input： 100-240V-0.5A 50/60Hz Manufacturer ： Shenzhen Besder Technology Co.,Ltd. FCC ID： 2A633-A8B Made in China 30mm Label location 10mm

- Page 4 of 8 - Internal photos - Page 5 of 8 - - Page 6 of 8 - - Page 7 of 8 - - Page 8 of 8 - ------END----- RF Module

FCC ID: 2A633-A8B RF Exposure Evaluation Limits The criteria listed in the following table shall be used to evaluate the environment impact of human exposure to radio frequency (RF) radiation as specified in 1.1307(b) Limits for Maximum Permissible Exposure (MPE) Frequency range (MHz) Electric field strength (V/m) Magnetic field strength (A/m) Power density (mW/cm 2 ) Averaging time (minutes) (A) Limits for Occupational/Controlled Exposures 0.3–3.0 614 1.63 *(100) 6 3.0–30 1842/f 4.89/f *(900/f 2 ) 6 30–300 61.4 0.163 1.0 6 300–1500 f/300 6 1500–100,000 5 6 (B) Limits for General Population/Uncontrolled Exposure 0.3–1.34 614 1.63 *(100) 30 1.34–30 824/f 2.19/f *(180/f 2 ) 30 30–300 27.5 0.073 0.2 30 300–1500 f/1500 30 1500–100,000 1.0 30 f = frequency in MHz Friis transmission formula: Pd = (Pout*G)/(4*pi*r 2 ) Where Pd = power density in mW/cm 2 , Pout = output power to antenna in mW; G = gain of antenna in linear scale, Pi = 3.1416; R = distance between observation point and center of the radiator in cm Pd id the limit of MPE, 1 mW/cm 2 . If we know the maximum gain of the antenna and the total power input to the antenna, through the calculation, we will know the distance r where the MPE limit is reached. Test Procedure Software provided by client enabled the EUT to transmit and receive data at lowest, middle and highest channel individually. FCC ID: 2A633-A8B Test Result of RF Exposure Evaluation Antenna gain=5.0dBi Mode Output power (dBm) Output power (mW) Numeric antenna gain Power Density at R=20cm (mW/cm 2 ) Limit (mW/cm 2 ) Result 802.11b 12.88 19.41 3.16 0.0122 1.0 PASS 802.11g 13.41 21.93 3.16 0.0138 1.0 PASS 802.11n20 13.26 21.18 3.16 0.0133 1.0 PASS 802.11n40 10.40 10.96 3.16 0.0069 1.0 PASS Then SAR evaluation is not require .

Report No.: ET-22050293E Tel: +86 755 85259392 Email: [email protected] No.103, No.10, Phase I, Zone 3, Xinxing Industrial Park, Xinhe, Fuhai Street, Bao'an District, Shenzhen, Guangdong, China TEST REPORT Applicant: ShenZhen Besder Technology Co.,Ltd. Address of Applicant: 4F Building B, East Area No.10 Of Shangxue Technology Park, Bantian , Longgang District, Shenzhen, China Manufacturer/Factory: ShenZhen Besder Technology Co.,Ltd. Address of Manufacturer 4F Building B, East Area No.10 Of Shangxue Technology Park, Bantian , Longgang District, Shenzhen, China Product Name: Wifi CCTV IP CAMERA Model No.: A8B Trade Mark: BESDER FCC ID: 2A633-A8B Applicable standards: FCC CFR Title 47 Part 15 Subpart C Section 15.247 Date of Test: May. 23, 2022- May.30, 2022 Date of report issued: Jun. 01, 2022 Test Result : PASS * * In the configuration tested, the EUT complied with the standards specified above. Remark: The results shown in this test report refer only to the sample(s) tested , this test report cannot be reproduced, except in full without prior written permission of the company. The report would be invalid without specific stamp of test institute and the signatures of compiler and approver Prepared By Shenzhen ETR Standard Technology Co., Ltd. Address: No.103, No.10, Phase I, Zone 3, Xinxing Industrial Park, Xinhe, Fuhai Street, Bao'an District, Shenzhen, Guangdong, China Compiled by: Reviewed by: Approved by: Project Engineer Project Manager Authorized Signature - Page 2 of 52 - Report No.: ET-22050293E Report Revision History Report No. Description Issue Date ET-22050293E Original Jun. 01, 2022 - Page 3 of 52 - Report No.: ET-22050293E Tel: +86 755 85259392 Email: [email protected] No.103, No.10, Phase I, Zone 3, Xinxing Industrial Park, Xinhe, Fuhai Street, Bao'an District, Shenzhen, Guangdong, China Contents Page 1. TEST SUMMARY ..................................................................................................................................... 4 2. GENERAL INFORMATION ...................................................................................................................... 5 3.1 GENERAL DESCRIPTION OF EUT ................................................................................................................ 5 3.2 TEST MODE ............................................................................................................................................... 7 3.3 DESCRIPTION OF SUPPORT UNITS .............................................................................................................. 7 3.4 DEVIATION FROM STANDARDS .................................................................................................................... 7 3.5 ABNORMALITIES FROM STANDARD CONDITIONS .......................................................................................... 7 3.6 TEST FACILITY ........................................................................................................................................... 7 3.7 TEST LOCATION ......................................................................................................................................... 7 ADDITIONAL INSTRUCTIONS .............................................................................................................................. 7 3. TEST INSTRUMENTS LIST ..................................................................................................................... 8 4. TEST RESULTS AND MEASUREMENT DATA ...................................................................................... 9 5.1 ANTENNA REQUIREMENT ............................................................................................................................ 9 5.2 CONDUCTED EMISSIONS .......................................................................................................................... 10 5.3 CONDUCTED PEAK OUTPUT POWER ......................................................................................................... 13 5.4CHANNEL BANDWIDTH & 99% OCCUPY BANDWIDTH .................................................................................. 15 5.5 POWER SPECTRAL DENSITY ..................................................................................................................... 19 5.6 BAND EDGES ........................................................................................................................................... 22 Conducted Emission Method .................................................................................................................. 22 Radiated Emission Method ..................................................................................................................... 25 5.7 SPURIOUS EMISSION ................................................................................................................................ 30 Conducted Emission Method .................................................................................................................. 30 Radiated Emission Method ..................................................................................................................... 35 5. TEST SETUP PHOTO ............................................................................................................................ 52 6. EUT CONSTRUCTIONAL DETAILS ..................................................................................................... 52 - Page 4 of 52 - Report No.: ET-22050293E Tel: +86 755 85259392 Email: [email protected] No.103, No.10, Phase I, Zone 3, Xinxing Industrial Park, Xinhe, Fuhai Street, Bao'an District, Shenzhen, Guangdong, China 1. Test Summary Test Item Section Result Test by Antenna requirement FCC part 15.203/15.247 (c) RSS-Gen §6.8 Pass / AC Power Line Conducted Emission FCC part 15.207 RSS-Gen §8.8 Pass Carr kang Conducted Peak Output Power FCC part 15.247 (b)(3) RSS-247 §5.4.b Pass Yvan …

Text truncated - open the document above for the full version.

ET-22050293 Page 1 of 2 Product Name: Wifi CCTV IP CAMERA Test Model No.: A8B Test Setup Photo Radiated Emission ET-22050293 Page 2 of 2 Conducted Emission ------End------
