2A65D-AMJ-002WNeck Massager

1.When the red light of the main unit flashes, accompanied by the voice p rompt "low battery", the main unit is low on battery, please charge it in time. When charging, use the USB charging cable to connect to a power adapter ( 5V 1A/2A) that meets the standard for home appliances or connect to the U SB port of your computer for charging. The red indicator light is always on when the main unit is charging normally, and the white indicator light is a lways on when it is full. 2.The display of the remote control shows the battery level, when the battery l evel is too low, please charge it in time. When charging, first put the remote control back to the designated position of the main unit, then connect the U SB charging cable at the end of the main unit to charge the remote control, the display shows the charging interface when the remote control is charging normally, and the fully charged interface when it is fully charged. 3.The product takes about 4 hours to fully charge. A full charge will last approximately 3 hours. Thank you for purchasing a LOBOOR product Dear Consumer: Status Unable to start Shows normal but no sensation Has a tingling sensation Very weak stimulation No charging or no charging light indication Whether the internal rechargeable battery is running low. Make sure that the main product on/off button is pressed. Please check that the USB connection cable is connected to the main unit and the power adapter of the mobile phone. Does the massager come into direct contact with the skin? Adjust the position so that it is close to the skin Do the electrodes of the massager fit snugly against the skin of the neck? Needs to be repositioned so that it is close to the skin Does the massage take too long? 15 minutes at a time is recommended Is twice a day too strong a massage? Adjustable small force Is the skin allergic to electrode pads? Severe allergies need to be treated with desensitisation first Cold climate and dry skin. Wipe the skin and electrode surface with a wet towel Is there a wound on the skin surface? Do not place electrode pads on the wound for massage. Are the electrodes of the massager tightly fitted to the skin of the neck? Adjust the position so that it is close to the skin and adjust the appropriate strength Are there any dirt or oil stains on the electrodes?Cleaning of electrode surfaces Is the battery low? If the battery is low, please charge it. Are there any objects such as hair or clothing or accessories between the electrode sheet and the skin? Move or remove the item. Possible causes/processing Harmful substances ○:indicates that the content of the hazardous substance in all homogeneous materials of the component is below the limit requirement specified in GB/T26572. ×: indicates that the content of the hazardous substance in at least one homogeneous material of the component exceeds the limit specified in GB/T26572. Warning Dangers Part name Hardware Plastic parts PCB Plate This product is for domestic use and should not be used for commercial purposes. Catalogue Cautions Technical specifications Electrical schematics Host microprocessor EMS generation output module Power management modules The lithium-ion batteries used in this product are a valuable resource that can be recycled. Please dispose of them at the end of use to a professional organization that can recycle rechargeable batteries. Product name Rated charging voltage Rated input power Rated voltage range of the mainframe Power rating of the main machine Rated voltage range of the remote control Remote control power rating Mainframe battery capacity Remote control battery capacity Neck Massager 5V 10W DC3.2V~DC4.2V 2W DC3.2V~DC4.2V 0.5W 800mAH 110mAH GB4706.1-2005/GB4706.10-2008 Implementation standards Charging modules Wireless receiver modules Remote control microprocessors Colour display module Power management modules Charging modules Wireless transmitter modules Product diagram Wearing style Charging instructions Instructions for use Warm Tips Daily Maintenance Troubleshooting Product and parts recycling instructions Recycling reminder Table of names and contents of harmful substances in products Environmental service life label This product has an "environmental use life" of 10 years, which we have set according to the characteristics of the product design. The "environmental use life" is only valid if the product is used under normal conditions and in an environmentally friendly manner as described in the product's operating instructions. Precautions when disposing of products Please support the recycling of rechargeable batteries (lithium ion). Product Warranty Card Product List Warning Instructions for use of the neck massager 封面二 封面一 Production models: Date of production: Date of inspection: Inspectors: Breakdowns, repairs, treatment Name： Date of delivery Maintenance unit Signature of maintainer Date of calibration Model： ADD： Warranty Period： Invoice Number： Date of purchase： Quality certificate User warranty vouchers Maintenance records Dangers Note Recommendations Warning Instruction manual 1 Strength key 2 Strength key 3 Heat application keys 4 Switch/Mode keys 5 Mainframe switch 6 electrode pads 7 Display 8 Charging port Charging cableMainframe 3 4 5 Remote control 6 7 8 1 2 Catalogue...............................................................1 Cautions.............................................................2-4 Technical specifications............................................5 Electrical schematics................................................5 Product diagram.......................................................6 Mode of operation..................................................7-8 Warm Tips...............................................................8 Daily Maintenance.....................................................8 Troubleshooting....................................................8-9 Description of product and parts recycling,....................10 P…

Text truncated - open the document above for the full version.

FCC ID: 2A65D-AMJ-002W AMJ-002W External Photos of the EUT Photo 1 Photo 2 Photo 3 FCC ID: 2A65D-AMJ-002W Photo 4 Photo 5 Photo 6 FCC ID: 2A65D-AMJ-002W Photo 7 Photo 8

FCC ID: 2A65D-AMJ-002W

FCC ID: 2A65D-AMJ-002W AMJ-002W Internal Photos of the EUT Photo 1 Photo 2 Photo 3 Antenna FCC ID: 2A65D-AMJ-002W Photo 4 Photo 5

Shenzhen CTA Testing Technology Co., Ltd. Room 106, Building 1, Yibaolai Industrial Park, Qiaotou Community, Fuhai Street, Bao’an District, Shenzhen, China FCC PART 15 SUBPART C TEST REPORT FCC PART 15.231 Report Reference No. ..................... : FCC ID. ........................................... : CTA22041101701 2A65D-AMJ-002W Compiled by ( position+printed name+signature) .. : File administrators Kevin Liu Supervised by ( position+printed name+signature) .. : Project Engineer Kevin Liu Approved by ( position+printed name+signature) .. : RF Manager Eric Wang Date of issue ..................................... : Apr. 15, 2022 Testing Laboratory Name .............: Shenzhen CTA Testing Technology Co., Ltd. Address ............................................ : Room 106, Building 1, Yibaolai Industrial Park, Qiaotou Community, Fuhai Street, Bao’an District, Shenzhen, China Applicant’s name ............................ : Sichuan YOUKEDE Medical Equipment Co., Ltd. Address ............................................ : 2F, North Wing, No.102 Building, Mianyang Export Processing Zone, No.261 East Section of Feiyun Road, Mianyang Hi-Tech Zone, 621000 Mianyang , Sichuan, P.R.China Test specification ...........................: Standard ........................................... : FCC Part 15.231 Shenzhen CTA Testing Technology Co., Ltd. All rights reserved. This publication may be reproduced in whole or in part for non-commercial purposes as long as the Shenzhen CTA Testing Technology Co., Ltd. is acknowledged as copyright owner and source of the material. Shenzhen CTA Testing Technology Co., Ltd. takes no responsibility for and will not assume liability for damages resulting from the reader's interpretation of the reproduced material due to its placement and context. Test item description ..................... : Neck Massager Trade Mark ....................................... : LOBOOR Manufacturer .................................... : Sichuan YOUKEDE Medical Equipment Co., Ltd. Model/Type reference....................... : AMJ-002W Listed Models .................................. : AMJ-002B, AMJ-002G, AMJ-002R, AMY-003B Ratings ............................................. : DC 3.7V from Battery and DC 5V from external circuit Modulation ....................................... : ASK Frequency .......................................... 433.9164MHz Hardware version ............................. : JBAM_B_V2-0-0-1. Software version ............................... : V1.0.0.0 Ratings ............................................. : Transmitter: DC 3.70V from battery Result................................................ : PASS Report No.: CTA22041101701 Page 2 of 23 T E S T R E P O R T Equipment under Test : Neck Massager Model /Type : AMJ-002W Listed Models : AMJ-002B, AMJ-002G, AMJ-002R, AMY-003B Model Declaration : PCB board, structure and internal of these model(s) are the same, So no additional models were tested. Applicant : Sichuan YOUKEDE Medical Equipment Co., Ltd. Address : 2F, North Wing, No.102 Building, Mianyang Export Processing Zone, No.261 East Section of Feiyun Road, Mianyang Hi-Tech Zone, 621000 Mianyang , Sichuan, P.R.China Manufacturer : Sichuan YOUKEDE Medical Equipment Co., Ltd. Address : 2F, North Wing, No.102 Building, Mianyang Export Processing Zone, No.261 East Section of Feiyun Road, Mianyang Hi-Tech Zone, 621000 Mianyang , Sichuan, P.R.China Test Result: PASS The test report merely corresponds to the test sample. It is not permitted to copy extracts of these test result without the written permission of the test laboratory. Report No.: CTA22041101701 Page 3 of 23 Contents 1 T E S T S T A N D A R D S .................................................................. 4 2 S U M M A R Y ............................................................................. 5 2.1 General Remarks 5 2.2 Product Description 5 2.3 Equipment Under Test 5 2.4 Short description of the Equipment under Test (EUT) 5 2.5 Block Diagram of Test Setup 5 2.6 Special Accessories 5 2.7 Related Submittal(s) / Grant (s) 6 2.8 Modifications 6 3 T E S T E N V I R O N M E N T ............................................................... 7 3.1 Address of the test laboratory 7 3.2 Test Facility 7 3.3 Environmental conditions 7 3.4 Summary of measurement results 8 3.5 Statement of the measurement uncertainty 8 3.6 Equipments Used during the Test 9 4 T E S T C O N D I T I O N S A N D R E S U L T S ............................................ 10 4.1 AC Power Conducted Emission 10 4.2 Radiated Emission 11 4.3 20dB Bandwidth 15 4.4 Deactivation Time 16 4.5 Antenna Requirement 17 5 T E S T S E T U P P H O T O S O F T H E E U T .......................................... 18 6 P H O T O S O F T H E E U T ............................................................. 19 Report No.: CTA22041101701 Page 4 of 23 1 T E S T S T A N D A R D S The tests were performed according to following standards: FCC Rules Part 15.231:Periodic operation in the band 40.66-40.70 MHz and above 70 MHz. ANSI C63.10:2013 : American National Standard for Testing Unlicensed Wireless Devices Report No.: CTA22041101701 Page 5 of 23 2 S U M M A R Y 2.1 General Remarks Date of receipt of test sample : Mar. 28, 2022 Testing commenced on : Mar. 28, 2022 Testing concluded on : Apr. 15, 2022 2.2 Product Description Product Name: Neck Massager Model/Type reference: AMJ-002W Testing sample ID： CTA220411017-1# (Engineer sample), CTA220411017-2#(Normal sample) Power supply: DC 3.7V from Battery and DC 5V from external circuit Modulation: ASK Operation frequency: 433.9164MHz Channel number: 1 Antenna type: Internal antenna Antenna gain: 0 dBi 2.3 Equipment Under Test Power supply system utilised Power supply voltage : ○ 230V / 50 Hz ○ 120V / 60Hz ○ 12 V DC ○ 24 V DC ● Other (specified in blank below) DC 3.7V from Battery and DC 5V from external circuit 2.4 Short description of the Equipment under Test (EUT) This is a Neck Massager. For more details, r…

Text truncated - open the document above for the full version.

FCC ID: 2A65D-AMJ-002W AMJ-002W Test Setup Photos of the EUT radiation L radiation H
