2A66P-P6WPstylus pen

V 2.0 Please read this instruction completely and keep it properly Product Detalls User Manual stylus pen work A light is on5%-30% Indicator lightBattery level AB light is on30%-70% ABC light is on70%-100% A light flashes5%-30% A light is on,B light flashes30%-70% ABlight is on,C light flashes70%-99% ABC light is on More than 90% Full State A light flashesLess than 5% Power prompt Touch switch Type-C charging port Indicator light Detachable nib Magnetic model ipad mini (6th generation) A2567/A2568/A2569 iPad Air (3rd generation) A2152/A2123/A2153/A2154 iPad Air (4th generation) A2316/A2324/A2325/A2072 iPad Pro (11 inches) A1980/A2013/A1934/A1979 iPad Pro11 inch (2nd generation) A2228/A2068/A2230/A2231 iPad Pro12.9 inch (3rd generation) A1876/A2014/A1895/A1983 iPad Pro12.9 inch (4th generation) A2229/A2069/A2232/A2233 iPad Pro11 inch (3rd generation) A2377/A2459/A2301/A2460 iPad Pro12.9 inch (5th generation) A2378/A2461/A2379/A2462 iPad (9th generation) A2602/A2604/A2603/A2605 Product Features 1. Fashionable and simple style, aluminum alloy material with piano baking paint, calm and luxurious, Novel and durable. 2. Replaceable pen head design, no fear of wear! The newly upgraded tilt and bold function, the larger the tilt area of the pen tip, the thicker the line. 3. The nip of the pen is made of special conductive materials and finely ground. Artificially create a smooth pen tip to prevent damage to the screen. 4. The product is compatible with ipad models after 2018 (see product parameters for specific models), which can write, draw, and record. 5. The product can be used continuously for up to 10 hours under full power, and it will stand still for 5 minutes smart power off is not used. Product parameter Model: stylus pen - P6WP Anti touch function: Yes Input: 5v-0.2a Tilt pressure sense: Yes Bluetooth: Yes Pen head: replaceable pen head Applicable model: iPad (6th generation) A1893/A1954 iPad (7th generation) A2197/A2200/A2198 iPad (8th generation) A2270/A2428/A2429/A2430 ipad mini (5th generation) A2133/A2124/A2126/A2125 ipad mini (6th generation) A2567/A2568/A2569 iPad Air (3rd generation) A2152/A2123/A2153/A2154 iPad Air (4th generation) A2316/A2324/A2325/A2072 iPad Pro (11 inches) A1980/A2013/A1934/A1979 iPad Pro11 inch (2nd generation) A2228/A2068/A2230/A2231 iPad Pro12.9 inch (3rd generation) A1876/A2014/A1895/A1983 iPad Pro12.9 inch (4th generation) A2229/A2069/A2232/A2233 iPad Pro11 inch (3rd generation) A2377/A2459/A2301/A2460 iPad Pro12.9 inch (5th generation) A2378/A2461/A2379/A2462 iPad (9th generation) A2602/A2604/A2603/A2605 P lease confirm that the above models are universal and other models are invalid. The model can be confirmed on the back of the iPad device. Instructions for use 1. The version of the ipad tablet cannot be lower than 12.2; 2. Open Settings-Memo-turn off the apple pencile doodle function; 3. Open Settings-Bluetooth, close the connection of the original Apple Pen. (After completing the above settings, you can use this product normally.) Gereral Display & Brightness Control Centre Face ID & Passcode Siri & Search Wallpaper Switch Between Current Tool an d Last Used Show Colour Palette Off Regulatory 1. Go to Settings > Apple Pencil > Turn off the Apple Pencil. Apple Pencil Tunes& App Store Wallet & Apple Pay Mail Contacts, Calendars Notes Reminders Messages FaceTime 2. Settings > Notes > Turn off "Only Draw with Apple Pencil. Save to Photos Access Notes from Lock Screen Only Draw with Aple Pencil off Save photos and videos taken in Notes to t he Photos app. LOCK SCREEN & CONTROL CENTER Quickly create or resume notes by tappin g anywhere on the Lock Screen with Apple Pencil, or pressin g the Notes control in Control Center, You can configure Notes a ccess from Control Center in Settings. APPLE PENCIL When enabled, only Apple Pencil will draw i nline in a note. Your fingers will be used for scrolling instead. Bluetooth use 1. Open Settings - Bluetooth - connect pencil; 2. Slide left on the main interface - Edit - add battery components; 3. Function: click back, double-click multitask. 2. Slide left on the main interface - Edit - add battery components. search Jack Apple ID、icloud、media and purchasing projects Apple ID proposal Software updates available Flight Mode Wireless LAN notice File Search widget Check the status of iPad and connected Bluetooth accessories. State Calendar Clock Lookup Photo Battery Equity market Mail list Mail Bluetooth Not connected Connected Can now be found as“iPad min”。 My device Other equipment Bluetoothopen Thursday Self determined complete Cupertino clear and cloudless Maximum 23 ° minimum 7 ° There is no other schedule today 1. Open Settings - Bluetooth - connect pencil. Touch switch How to Use How to Charge 1. Press and hold the top of the capacitive pen for 3 seconds to start the machine, the indicator light will be blue and start to use, press and hold the top of the capacitive pen for 3 seconds to turn off, and the indicator light will be off. 1.Please use the type-C charging wire to charge. One end is connected to the USB interface of the stylus and the other end is connected USB interface of computer or tablet.（ FIG 1) 2.Please connect one end of the adapter cable to the USB interface of the stylus, and plug in 5V DC at the other end Charge the source adapter.（ FIG 2) 3.Directly plug the 5V mobile power supply with USB interface into the stylus for charging. Charging process in, the red charging light will light up, and the whole charging time is about 1 hour.（ FIG 3) 2.It has a magnetic adsorption function, which can be adsorbed by lightly putting it, and can be adsorbed on the tablet like Apple Pencil. 3. Removable and easy to replace the pen head design, no need to worry about wear! (Twist the pen head to easily remove/install). （ Remove ）（ install ） （FIG 1） （FIG 2） （FIG 3） POWER BANK Low power Charge 正面 反面 苹果6代 WP电容笔-说明书(蓝牙版)-中英文-K+K-中性-V 2.0 Warning: Changes or modifications to this unit not expressly approved by …

Text truncated - open the document above for the full version.

Shenzhen BASIX Industrial Co., Ltd. Agent Authorization Company: Shenzhen BASIX Industrial Co., Ltd. Address: Room 201, Building A2, Taichung Industrial Zone, No. 6, Xinfeng Road, Ailian Community, Longcheng Street, Longgang District, Shenzhen Product Name: stylus pen Model Number(s): P6WP, P6W, P8 PRO, XPen, P3 PRO, P6WP-KC, P6W-KC, P3PRO-KC, P6WPA-KC, P6WA-KC, P9, P9PRO We authorize MiCOM Labs Inc., 575 Boulder Court, Pleasanton, California 94566, USA, to act on our behalf on all matters concerning the certification of above named equipment. We declare that MiCOM Labs Inc. is allowed to forward all information related to the approval and certification of equipment to the regulatory agencies as required and to discuss any issues concerning the approval application. Any and all acts carried out by MiCOM Labs on our behalf shall have the same effect as acts of our own. Date: May 30, 2022 Signature: Name: yan cao Title:manager Company: Shenzhen BASIX Industrial Co., Ltd.

Shenzhen BASIX Industrial Co., Ltd. Date: May 30, 2022 Offic e of Engineering Technology Federal Communications Commission 743 5 Oakland Mill s Road Columbia, MD 21046 USA Subject; Request for Confidentiality FCC ID: 2A66P-P6WP To Whom It May Concern, Pursuant to the provisions of the Commission’s rules Title 47 Sections §0.457 and §0.459, we are requesting the Commission to withhold the following attachment(s) as confidential documents from public disclosure indefinitely. These documents contain detailed system and equipment descriptions and are considered as proprietary information in operation of the equipment. The public disclosure of these documents might be harmful to our company and would give competitors an unfair advantage in the market. Schematic Diagram Block Diagram Part s List Operational Description Tune -up Procedure In additional to above mentioned documents, in order to comply with the marketing regulations in Title 47 CFR §2.803 and the importation rules in Title 47 CFR §2.1204, while ensuring that business sensitive information remains confidential until the actual marketing of newly authorized devices, we request Short Term Confidentiality of the following attachment(s); External Photos Test Setup Photos Internal Photos User Manual For 45 days, pursuant to Public Notice DA 04-1705 . OR For 180 days pursuant to KDB 726920 D01. It is our understanding that all measurement test reports, FCC ID label format and correspondence during the certification review process cannot be granted as confidential documents and this information will be available for public review once the grant of equipment authorization is issued. Sincerely, Signature: Name: yan cao Title: manager

Shenzhen BASIX Industrial Co., Ltd. Model Confirmation Letter We, Shenzhen BASIX Industrial Co., Ltd. , certify the product: stylus pen , Model No.: P6WP, P6W, P8 PRO, XPen, P3 PRO, P6WP-KC, P6W-KC, P3PRO-KC, P6WPA-KC, P6WA-KC, P9, P9PRO All models have the same functionality, software and electronics, only the model names may differ. Test sample model: P6WP Signiture: Grantee Contact: yan cao Company Name:Shenzhen BASIX Industrial Co., Ltd. Date: 2022-05-30

Label place Label size: 7 *20mm stylus pen FCC ID:2A66P-P6WP

internal photos BATTERY ANT

FCC ID: 2A66P-P6WP RF Exposure Evaluation According to KDB 447498 and part 2.1093, Unless specifically required by the published RF exposure KDB procedures, standalone 1-g head or body and 10-g extremity SAR evaluation for general population exposure conditions, by measurement or numerical simulation, is not required when the corresponding SAR Test Exclusion Threshold condition(s), listed below, is (are) satisfied. For 100 MHz to 6 GHz and test separation distances ≤ 5.0 mm, the 1-g and 10-g SAR test exclusion thresholds are determined by the following: [(max. power of channel, including tune-up tolerance, mW) / (min. test separation distance, mm)] · [√f (GHz) ] ≤ 3.0 for 1-g SAR, and ≤ 7.5 for 10-g extremity SAR, where f (GHz) is the RF channel transmit frequency in GHz Power and distance are rounded to the nearest mW and mm before calculation The result is rounded to one decimal place for comparison Here, Frequency (MHz) Max Power (dBm) Tune up tolerance (dBm) Max tune- up Power (dBm) Max tune-up Power (mW) Calc. thresholds limit 2440 -0.582 0±1 1 1.259 0.393 3.0 So a SAR test is not required

Project No.: ZKT-220515L3231 Page 1 of 47 FCC TEST REPORT FCC ID:2A66P-P6WP Report Number. .............................. : ZKT-220515L3231 Date of Test ...................................... : May 09, 2022 -- May 26, 2022 Date of issue .................................... : May 26, 2022 Total number of pages ..................... : 47 Test Result ....................................... : PASS Testing Laboratory. ........................ : Shenzhen ZKT Technology Co., Ltd. Address .......................................... : 1/F, No. 101, Building B, No. 6, Tangwei Community Industrial Avenue, Fuhai Street, Bao'an District, Shenzhen, China Applicant's name ......................... : Shenzhen BASIX Industrial Co., Ltd. Address .......................................... : Room 201, Building A2, Taichung Industrial Zone, No. 6, Xinfeng Road, Ailian Community, Longcheng Street, Longgang District, Shenzhen Manufacturer's name ................... : Shenzhen BASIX Industrial Co., Ltd. Address .......................................... : Room 201, Building A2, Taichung Industrial Zone, No. 6, Xinfeng Road, Ailian Community, Longcheng Street, Longgang District, Shenzhen Test specification: Standard .......................................... : FCC CFR Title 47 Part 15 Subpart C Section 15.247 ANSI C63.10:2013 Test procedure ................................. : / Non-standard test method ............. : N/A Test Report Form No. .................... : TRF-EL-110_V0 Test Report Form(s) Originator .... : ZKT Testing Master TRF .................................... : Dated: 2020-01-06 This device described above has been tested by ZKT, and the test results show that the equipment under test (EUT) is in compliance with the FCC requirements. And it is applicable only to the tested sample identified in the report. This report shall not be reproduced except in full, without the written approval of ZKT, this document may be altered or revised by ZKT, personal only, and shall be noted in the revision of the document. Product name ................................. : stylus pen Trademark ...................................... : N/A Model/Type reference ...................... : P6WP, P6W, P8 PRO, XPen, P3 PRO, P6WP-KC, P6W-KC, P3PRO-KC, P6WPA-KC, P6WA-KC, P9, P9PRO Ratings ............................................. : DC 3.7V from battery / DC 5.0V from adapter Project No.: ZKT-220515L3231 Page 2 of 47 Testing procedure and testing location: Testing Laboratory ................................... : Shenzhen ZKT Technology Co., Ltd. Address ...................................................... : 1/F, No. 101, Building B, No. 6, Tangwei Community Industrial Avenue, Fuhai Street, Bao'an District, Shenzhen, China Alen He Tested by (name + signature) .................... : Joe Liu Reviewer (name + signature) ..................... : Lake Xie Approved (name + signature) .................... : Project No.: ZKT-220515L3231 Page 3 of 47 Table of Contents Page 1. VERSION 5 2. SUMMARY OF TEST RESULTS 6 2.1 TEST FACILITY 7 2.2 MEASUREMENT UNCERTAINTY 7 3. GENERAL INFORMATION 8 3.1 GENERAL DESCRIPTION OF EUT 8 3.2 DESCRIPTION OF TEST MODES 9 3.3 BLOCK DIGRAM SHOWING THE CONFIGURATION OF SYSTEM TESTED 10 3.4 DESCRIPTION OF SUPPORT UNITS(CONDUCTED MODE) 10 3.5EQUIPMENTS LIST FOR ALL TEST ITEMS 11 4. EMC EMISSION TEST 12 4.1 CONDUCTED EMISSION MEASUREMENT 12 4.1.1 POWER LINE CONDUCTED EMISSION LIMITS 12 4.1.2 TEST PROCEDURE 12 4.1.3 DEVIATION FROM TEST STANDARD 12 4.1.4 TEST SETUP 13 4.1.5 EUT OPERATING CONDITIONS 13 4.1.6 TEST RESULT 14 4.2 RADIATED EMISSION MEASUREMENT 16 4.2.1 RADIATED EMISSION LIMITS 16 4.2.2 TEST PROCEDURE 16 4.2.3 DEVIATION FROM TEST STANDARD 17 4.2.4 TEST SETUP 17 4.2.5 EUT OPERATING CONDITIONS 18 4.2.6 TEST RESULTS 19 5.RADIATED BAND EMISSIONMEASUREMENT 24 5.1 TEST REQUIREMENT: 24 5.2 TEST PROCEDURE 24 5.3 DEVIATION FROM TEST STANDARD 24 5.4 TEST SETUP 25 5.5 EUT OPERATING CONDITIONS 25 5.6 TEST RESULT 26 6.POWER SPECTRAL DENSITY TEST 27 6.1 APPLIED PROCEDURES / LIMIT 27 6.2 TEST PROCEDURE 27 6.3 DEVIATION FROM STANDARD 27 6.4 TEST SETUP 27 6.5 EUT OPERATION CONDITIONS 27 Project No.: ZKT-220515L3231 Page 4 of 47 6.6 TEST RESULT 28 7. CHANNEL BANDWIDTH& 99% OCCUPY BANDWIDTH 30 7.1 APPLIED PROCEDURES / LIMIT 30 7.2 TEST PROCEDURE 30 7.3 DEVIATION FROM STANDARD 30 7.4 TEST SETUP 30 7.5 EUT OPERATION CONDITIONS 30 7.6 TEST RESULT 31 8.PEAK OUTPUT POWER TEST 33 8.1 APPLIED PROCEDURES/LIMIT 33 8.2 TEST PROCEDURE 33 8.3 DEVIATION FROM STANDARD 33 8.4 TEST SETUP 33 8.5 EUT OPERATION CONDITIONS 33 8.6 TEST RESULT 33 9. CONDUCTED BAND EDGE AND SPURIOUS EMISSION 35 9.1 APPLICABLE STANDARD 35 9.2 TEST PROCEDURE 35 9.3 DEVIATION FROM STANDARD 35 9.4 TEST SETUP 35 9.5 EUT OPERATION CONDITIONS 35 9.6 TEST RESULTS 35 10. ANTENNA REQUIREMENT 40 11. TEST SETUP PHOTO 41 12. EUT CONSTRUCTIONAL DETAILS 43 Project No.: ZKT-220515L3231 Page 5 of 47 1. VERSION Report No. Version Description Approved ZKT-220515L3231 Rev.01 Initial issue of report May 26, 2022 Project No.: ZKT-220515L3231 Page 6 of 47 2. SUMMARY OF TEST RESULTS Test procedures according to the technical standards: FCC Part15 (15.247) , Subpart C Standard Section Test Item Result Remark FCC part 15.203/15.247 (c) Antenna requirement PASS FCC part 15.207 AC Power Line Conducted Emission PASS FCC part 15.247 (b)(3) Conducted Peak Output Power PASS FCC part 15.247 (a)(2) Channel Bandwidth& 99% OCB PASS FCC part 15.247 (e) Power Spectral Density PASS FCC part 15.247(d) Band Edge PASS FCC part 15.205/15.209 Spurious Emission PASS NOTE: (1)” N/A” denotes test is not applicable in this Test Report Project No.: ZKT-220515L3231 Page 7 of 47 2.1 TEST FACILITY Shenzhen ZKT Technology Co., Ltd. Add. : 1/F, No. 101, Building B, No. 6, Tangwei Community Industrial Avenue, Fuhai Street, Bao'an District, Shenzhen, China FCC Test Firm Registration Number: 692225 Designation Number: CN1299 IC Registered No.: 27033 2.2 MEASUREMENT UNCERTAINTY The reported uncertainty of measureme…
