2A6CJ-BDPLAYBirdDog Play with BT/2.4Gwifi/5Gwifi

USER GUIDE October 2022 Table of Contents Welcome to BirdDog! .................................................................................................3 Using This Manual ........................................................................................................3 First Step .........................................................................................................................3 Key Features .................................................................................................................................5 Getting to Know PLAY ...............................................................................................6 Physical Layout ............................................................................................................................6 Powering Your Converter ........................................................................................................6 Operating Your Converter .......................................................................................7 Password Management ............................................................................................................7 BirdUI Layout ...............................................................................................................................8 Dashboard .....................................................................................................................................8 Network .........................................................................................................................................10 NDI Network Settings ..............................................................................................................11 System ...........................................................................................................................................12 System Update ...........................................................................................................................12 System Reboot............................................................................................................................12 Configuration Update ..............................................................................................................13 AV Setup .......................................................................................................................................13 Key Specifications.......................................................................................................15 Glossary ..........................................................................................................................16 1 Copyright Copyright 2022 BirdDog Australia all rights reserved. No part of this manual may be copied, reproduced, translated, or distributed in any form or by any means without prior consent in writing from our company. Trademark Acknowledgement and other BirdDog trademarks and logos are the property of BirdDog Australia. Other trademarks, company names and product names contained in this manual are the property of their respective owners. •Microsoft, Windows, ActiveX, and Internet Explorer are registered trademarks of Microsoft Corporation in the U.S. and/or other countries. •HDMI, the HDMI logo and High-Definition Multimedia Interface are the trademarks or registered trademarks of HDMI Licensing, LLC in the United States and other countries. •Other trademarks, company names and product names contained in this manual are the property of their respective owners. •NDI® is a registered trademark of NewTek, Inc. Important Information Legal Notice To ensure account security, please change the password after your first log in. You are recommended to set a strong password (no less than eight characters). The contents of this document are subject to change without prior notice. Updates will be added to the new version of this manual. We will readily improve or update the products or procedures described in the manual. Best effort has been made to verify the integrity and correctness of the contents in this document, but no statement, information, or recommendation in this manual shall constitute formal guarantee of any kind, expressed or implied. We shall not be held responsible for any technical or typographical errors in this manual. The product appearance shown in this manual is for reference only and may be different from the actual appearance of your device. Due to uncertainties such as physical environment, discrepancy may exist between the actual values and reference values provided in this manual. Use of this document and the subsequent results shall be entirely on the user’s own responsibility. Regulatory Compliance CE Maintenance 1. The product shall only be connected to a USB interface of version USB3.0. 2. EUT Operating temperature range: -10° C to 45°C. 3. When the device is used 20 miles away from the body, it complies with RF specifications. Declaration of Conformity Shenzhen VastDo Technology Co.,Ltd hereby declares that this BirdDog Play is in compliance with the essential requirements and other relevant provisions of Directive 2014/53/EU. In accordance with Article 10(2) and Article 10(10), This product is allowed to be used in all EU member states. 2 FCC Caution. This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. Any Changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment. Note: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful…

Text truncated - open the document above for the full version.

BirdDog Australia Pty Ltd Agent Authorization Company: BirdDog Australia Pty Ltd Address: 10-38 Down St, Collingwood, VIC, 3066, Australia Product Name: BirdDog Play Model Number(s): BDPlay Product Description: BirdDog Play with BT/2.4Gwifi/5Gwifi We authorize MiCOM Labs Inc., 575 Boulder Court, Pleasanton, California 94566, USA, to act on our behalf on all matters concerning the certification of above named equipment. We declare that MiCOM Labs Inc. is allowed to forward all information related to the approval and certification of equipment to the regulatory agencies as required and to discuss any issues concerning the approval application. Any and all acts carried out by MiCOM Labs on our behalf shall have the same effect as acts of our own. Signature: Date: 2022.12.12 Name: Dan Mial Title: Manager Company: BirdDog Australia Pty Ltd

BirdDog Australia Pty Ltd Office of Engineering Technology Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 USA Date: 2022/12/12 Subject; Request for Confidentiality FCC ID: 2A6CJ-BDPLAY To Whom It May Concern, Pursuant to the provisions of the Commission’s rules Title 47 Sections §0.457 and §0.459, we are requesting the Commission to withhold the following attachment(s) as confidential documents from public disclosure indefinitely. These documents contain detailed system and equipment descriptions and are considered as proprietary information in operation of the equipment. The public disclosure of these documents might be harmful to our company and would give competitors an unfair advantage in the market. Schematic Diagram Block Diagram Parts List Operational Description Tune-up Procedure SOFTWARE SECURITY REQUIREMENTS FOR U-NII DEVICES In additional to above mentioned documents, in order to comply with the marketing regulations in Title 47 CFR §2.803 and the importation rules in Title 47 CFR §2.1204, while ensuring that business sensitive information remains confidential until the actual marketing of newly authorized devices, we request Short Term Confidentiality of the following attachment(s); External Photos Test Setup Photos Internal Photos User Manual For 45 days, pursuant to Public Notice DA 04-1705. OR For 180 days pursuant to KDB 726920 D01. It is our understanding that all measurement test reports, FCC ID label format and correspondence during the certification review process cannot be granted as confidential documents and this information will be available for public review once the grant of equipment authorization is issued. Sincerely, Signature: Name: Dan Mial Title: Manager

Page 1 of 4 Report No.: STS2204062 APPENDIX-PHOTOGRAPHS OF EUT CONSTRUCTIONAL DETAILS Model: BDplay Photo 1 Photo 2 Page 2 of 4 Report No.: STS2204062 Photo 3 Photo 4 Page 3 of 4 Report No.: STS2204062 Photo 5 Photo 6 Page 4 of 4 Report No.: STS2204062 Photo 7

Label Size:10*30mm The label is printed on the shell FCC ID: 2A6CJ-BDPLAY .

Any reproduction of this document must be done in full. No single part of this document may be reproduced without permission from STS, All Test Data Presented in this report is only applicable to presented Test sample. Shenzhen STS Test Services Co., Ltd. A 1/F, Building B, Zhuoke Science Park, No.190 Chongqing Road, HepingShequ, Fuyong Sub-District, Bao’an District, Shenzhen, Guang Dong, China TEL: +86-755 3688 6288 FAX: +86-755 3688 6277 E-mail:[email protected] FCC Part 15B TEST REPORT Report No.: STS2204062E03 Issued for BirdDog Australia Pty Ltd 10-38 Down St, Collingwood, VIC, 3066, Australia Product Name: BirdDog Play Brand Name: BirdDog Model Name: BDPlay Series Model: N/A FCC ID: 2A6CJ-BDPLAY Test Standard: FCC 47 CFR Part 15: Subpart B S T L A B S Page 2 of 20 Report No.: STS2204062E03 TEST RESULT CERTIFICATION Applicant’s Name .................: BirdDog Australia Pty Ltd Address ..................................: 10-38 Down St, Collingwood, VIC, 3066, Australia Manufacture's Name ............: Shenzhen VastDo Technology Co., Ltd Address ..................................: Room 403-5, Building L, Baicai Technology Park, No. 26, Lane 2, Liuxian 1st Road, Baoan District, Shenzhen, Guangdong Province, China Product Description .............: Product Name ........................: BirdDog Play Brand Name ...........................: BirdDog Model Name .........................: BDPlay Series Model ........................: N/A Standards..............................: FCC 47 CFR Part 15: Subpart B Test Procedure.....................: ANSI C63.4-2014 This device described above has been tested by STS, and the test results show that the equipment under test (EUT) is in compliance with the FCC requirements. And it is applicable only to the tested sample identified in the report. This report shall not be reproduced except in full, without the written approval of STS, this document may be altered or revised by STS, personal only, and shall be noted in the revision of the document. Date of Test .......................................... : Date of Receipt of Test Item ................... : 11 Apr. 2022 Date of Performance of Tests ............... : 11 Apr. 2022~13 June 2022 Date of Issue ........................................ : 13 June 2022 Test Result ........................................... : Pass Testing Engineer : (Jane Chen) Technical Manager : (Bulun) Authorized Signatory : (Bovey Yang) Page 3 of 20 Report No.: STS2204062E03 Table of Contents 1. SUMMARY OF THE TEST RESULTS 5 1.1 TEST FACTORY 5 1.2 MEASUREMENT UNCERTAINTY 5 2. GENERAL INFORMATION 6 2.1 GENERAL DESCRIPTION OF THE EUT 6 2.2 DESCRIPTION OF THE TEST MODES 7 2.3 DESCRIPTION OF THE TEST SETUP 8 2.4 EQUIPMENTS LIST FOR ALL TEST ITEMS 9 3. EMC EMISSION TEST 10 3.1 CONDUCTED EMISSION MEASUREMENT 10 3.2 RADIATED EMISSION MEASUREMENT 14 Page 4 of 20 Report No.: STS2204062E03 Revision History Rev. Issue Date Report No. Effect Page Contents 00 13 June 2022 STS2204062E03 ALL Initial Issue Page 5 of 20 Report No.: STS2204062E03 1. SUMMARY OF THE TEST RESULTS Test procedures according to the technical standards: EMISSION Standard Item Result Remarks FCC 47 CFR Part 15 Subpart B Conducted Emission PASS Meet Class B limit Radiated Emission PASS Meet Class B limit NOTE: (1) N/A=Not Applicable. 1.1 TEST FACTORY Company Name: SHENZHEN STS TEST SERVICES CO.,LTD. Address: A 1/F, Building B, Zhuoke Science Park, No.190 Chongqing Road, HepingShequ, Fuyong Sub-District, Bao’an District, Shenzhen, Guang Dong, China Telephone: +86-755 3688 6288 Fax: +86-755 3688 6277 Registration No.: FCC test Firm Registration Number: 625569 IC test Firm Registration Number: 12108A A2LA Certificate No.: 4338.01 1.2 MEASUREMENT UNCERTAINTY The reported uncertainty of measurement y ± U, where expended uncertainty U is based on a standard uncertainty multiplied by a coverage factor of k=2, providing a level of confidence of approximately 95 %。 No. Item Uncertainty 1 Conducted Emission (9KHz-30MHz) ±2.73dB 2 All emissions,radiated(<1G) 30MHz-1000MHz ±4.09dB 3 All emissions,radiated(>1G) 1GHz-6GHz ±4.92dB 4 All emissions,radiated(>1G) 6GHz-18GHz ±5.49dB Page 6 of 20 Report No.: STS2204062E03 2. GENERAL INFORMATION 2.1 GENERAL DESCRIPTION OF THE EUT Product Name BirdDog Play Brand Name BirdDog Model Name BDPlay Series Model N/A Model Difference N/A Frequency Bands Bluetooth 2402~2480 MHz 2.4G WLAN 802.11b/g/n(HT20/40):2412~2462MHz 802.11n(40MHz):2422~2452MHz 5G WLAN IEEE 802.11a/ n(HT20)/ac(VHT20): 5.180GHz-5.240GHz IEEE 802.11n(HT40)/ac(VHT40): 5.190GHz-5.310GHz IEEE 802.11ac(VHT80): 5.210GHz IEEE 802.11a/ n(HT20)/ac(VHT20): 5.260GHz-5.320GHz IEEE 802.11n(HT40)/ac(VHT40): 5.270GHz-5.310GHz IEEE 802.11ac(VHT80): 5.290GHz IEEE 802.11a/ n(HT20)/ac(VHT20): 5.500GHz-5.700GHz IEEE 802.11n(HT40)/ac(VHT40): 5.510GHz-5.670GHz IEEE 802.11ac(VHT80): 5.530GHz-5.610GHz IEEE 802.11a/ n(HT20)/ac(VHT20): 5.745GHz-5.825GHz IEEE 802.11n(HT40)/ac(VHT40): 5.755GHz-5.795GHz IEEE 802.11ac(VHT80): 5.775GHz Modulation Mode Bluetooth GFSK(1Mbps), π/4-DQPSK(2Mbps), 8DPSK(3Mbps) BLE GFSK 2.4 G WLAN 802.11b(DSSS):CCK,DQPSK,DBPSK 802.11g(OFDM):BPSK,QPSK,16-QAM,64-QAM 802.11n(OFDM):BPSK,QPSK,16-QAM,64-QAM 5G WLAN 802.11a(OFDM): BPSK,QPSK,16-QAM,64-QAM 802.11n(OFDM): BPSK,QPSK,16-QAM,64-QAM 802.11ac(OFDM): BPSK,QPSK,16-QAM,64-QAM,256-QAM Rating Input: 5V/1.2A Hardware Version Number BirdDog v1.0 Software Version Number BD-U-V1.0.0 Note: For a more detailed features description, please refer to the manufacturer’s specifications or the User's Manual. Page 7 of 20 Report No.: STS2204062E03 2.2 DESCRIPTION OF THE TEST MODES To investigate the maximum EMI emission characteristics generates from EUT, the test system was pre-scanning tested base on the consideration of following EUT operation mode or test configuration mode which possibly have effect on EMI emission level. Each of these EUT operation mode(s) or test configuration mode(s) mentioned above was evaluated respectively. Pretest Mode Descri…

Text truncated - open the document above for the full version.

Page 1 of 2 FCC ID: 2A6CJ-BDPLAY JAB Setup photo Model name: BDPlay RE (Below 1GHz) RE (Above 1GHz) Page 2 of 2 FCC ID: 2A6CJ-BDPLAY CE
