PROJECTOR User Manual Important Note: Please read the user manual carefully before use and keep it for future use. 1 Important: In order to get the best viewing effect, it’s suggested that you use the product in a dark room. Warning: Following safety instructions can sus - tain product’s lifespan and prevent it from firing or electric shock, so please read them carefully and pay attention to all warnings. · Do not install it in a place with poor ventilation. · Do not install it in a hot or damp place. IM PORTANT SAFETY PRECAUTIONS Note: In order to maintain the performance and reliability of projector, please leave at least 30cm of space around the projector. Note: The projector’s light is very bright, so please do not look at it directly or point its light to your eyes in case of causing visual damage. · Do not block its ventilation holes (Intake or Exhaust). · Do not install it in a dusty or smoky place. · Do not install it near to the temperature/smoke sensor, since it might make the sensor fail to work. · Do not install it in a position directly blown by air condition, otherwise it might be malfunc - tioned because of the water & vapour conden - sation or high temperature. English 23 PACKING LIST ProjectorPower CableRemote ControlHDMI Cable User Manual Quick Start Guide FAQ AV CableUser ManualQuick Start GuideFAQ English Note: Please check whether the accessories are complete after opening the package. If it’s not complete, please contact customer service for a replacement. PRODUCT INTRODUCTIONEnglish AV In Audio Port HDMI Speaker Power Cable Port USB 2.0 Manually Focus Indicator Light Power Switch Lens VGA Port Keystone 45 PRODUCT INTRODUCTIONEnglish Note: Due to the design improvement, the appearance/screen printing/characters of the remote control might be somewhat different from the real product, please prevail in kind. NOTES Be cautious when using the remote control. Do not drop it, trample on it, or spill any liquid into its body. Do not put the remote control near to any heat source. Power Switch Play/Pause Fast Backward Fast Forward Upward Rightward Downward Signal Source Menu Volume+ Mute Leftward OK Return Volume- Do not expose the remote control under sunlight. Do not put the remote control in a damp place. INSTALLATION AND DEBUGGING Installation Methods Recommended Projection Distance: 2-3m/6.5-9ft Instructions Method: Put it horizontall y English USB Cable Phone 67 Referential Projection Distance Turn Off Safely Press the switch button twice on operation panel or remote control. PRODUCT SPECIFICATIONS Product Name Product Size Display Technology Light Source LED Lifespan Native Resolution Input Resolution Contrast Ratio Input Ports Projection Size Best Projection Distance Speaker Total Consumption Power Power Voltage Screen Ratio Keystone Correction Focusing Method 211mm X 88mm X 184mm LCD LED 30,000 hours 1920x1080 Pixel 800×480P/1280×720P/ 1920×1080P 10000:1 HDMI / USB 2.0/Audio Port/AV 40-210 inch 2m 1x(5W/4Ω) 60W 100V-240V~ 50Hz-60Hz 4:3/16:9 Manually Focus Video Projector (Home Use) PROJECTION SETTINGS Step 1 Step 2 Phone Projection Setting 1. Enter into Android interface of projection. 2. Enter into phone settings and select “Screen-sharing”, click it and find the device to connect. Note: For different phone brands, the names of “screen-sharing” are different. Huawei: Wireless Projection/Multi-screen Interaction Xiaomi: Wireless Display Sony: Screen Mirroring Samsung: Screen Sharing/Screen Mirroring/ Allshare Cast Smart View Android English Note: If you want to play video in Netflix App, please connect the projector to your device with a HDMI cable firs t, otherwise the video in Netflix can’t be projected directly because of the copyright. We’re sorry for that and hope you could understand. 89 Wireless Projection 1. Connect projector to your home network according to foll owing steps: Enter into Android interface of projection. 2. Turn on your iOS device and connect it to the same network as the projector. Then turn on Screen Mirroring function on the device, and find the name of the projector and connect it. 1. Enter into “Setting” interface of the projector. 2. Turn on the Bluetooth function as shown in t he right figure The projector will automatically search for and connect your Bluetooth device You can connect Bluetooth speakers to get better sound effects IOSIOS Wired Projection 1. Connect projector to phone with the USB data cable. 2. Select “Trust” to allow the program to be used on your phone. Instructions Bluetooth speakers Trust This Computer? TrustDon’t Trust Step 2Step 1 USB Sound ModeStandard Balance OFF Surround SoundOFF BluetoothON Sound Auto Volume 0 MENU SETTING English Get the best viewing effect with the most appropriate settings. You could set some relative parameters according to following steps. 1.Enter into“Setting”on main interface of the projector. 2.You could set the parameter of the“Picture”and“Sound” Picture ModeMedium Color Temperature 16:9 Noise ReductionMiddle Screen Reduce Display Size100% Projection DirectionRear PICTURE Aspect Ratio Medium ： This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) th is device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. Any changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment. NOTE: This equipment has been tested and found to comply with the limits for a Class B d igital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not in stalled and used in accordance with the in structions, may cause harmful interference to radio communications. However, there is no g…

Text truncated - open the document above for the full version.

Shenzhen Divcre Technology Co.,Ltd. Agent Authorization Company: Shenzhen Divcre Technology Co.,Ltd. Address: 2F, No.99, Tongfu Cun Industrial Zone, Dalang Community, Dalang Street, Longhua District, Shenzhen, Guangdong, China Product Name: LCD Projector Model Number(s ): H5 H6, H7, H8, H9, H10, M1, M2, M3, M4, M5, M6, M7, M8, M9, M10 Product Description: LCD Projector We authorize MiCOM Labs Inc., 575 Boulder Court, Pleasanton, California 94566, USA, to act on our behalf on all matters concerning the certification of above named equipment. We declare that MiCOM Labs Inc. is allowed to forward all information related to the approval and certification of equipment to the regulatory agencies as required and to discuss any issues concerning the approval application. Any and all acts carried out by MiCOM Labs on our behalf shall have the same effect as acts of our own. Signature: Date: 2022/04/24 Name: Peter Wang Title: Certification Engineer Company: Shenzhen Divcre Technology Co.,Ltd.

Shenzhen Divcre Technology Co.,Ltd. Office of Engineering Technology Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 USA Date: 2022/04/24 Subject; Request for Confidentiality FCC ID: 2A6D7-H5 To Whom It May Concern, Pursuant to the provisions of the Commission’s rules Title 47 Sections §0.457 and §0.459, we are requesting the Commission to withhold the following attachment(s) as confidential documents from public disclosure indefinitely. These documents contain detailed system and equipment descriptions and are considered as proprietary information in operation of the equipment. The public disclosure of these documents might be harmful to our company and would give competitors an unfair advantage in the market. Schematic Diagram Block Diagram Operational Description In additional to above mentioned documents, in order to comply with the marketing regulations in Title 47 CFR §2.803 and the importation rules in Title 47 CFR §2.1204, while ensuring that business sensitive information remains confidential until the actual marketing of newly authorized devices, we request Short Term Confidentiality of the following attachment(s); User Manual For 45 days, pursuant to Public Notice DA 04-1705. OR For 180 days pursuantto KDB 726920 D01. It is our understanding that all measurement test reports, FCC ID label format and correspondence during the certification review process cannot be granted as confidential documents and this information will be available for public review once the grant of equipment authorization is issued. Sincerely, Signature: Name: Peter Wang Title: Certification Engineer

Shenzhen Divcre Technology Co.,Ltd. Model Difference Product description: LCD Projector Model name: H5 H6,H7,H8,H9,H10,M1,M2,M3,M4,M5,M6,M7,M8,M9,M10 Trade Name: Divcre帝福溢 FCC ID: 2A6D7-H5 All the model are the same circuit and RF module, only for model name. Regards Sincerely Client’s signature: Client’s name / title : Peter Wang（Certification Engineer） Contact information / address: 2F,No.99,Tongfu Cun Industrial Zone,Dalang Community,Dalang Street,Longhua District,Shenzhen,Guangdong,China

External Photos

Model: H5 FCC ID: 2A6D7-H5 Label Location

Internal Photos BLE WIFI

§2.1091 – RF Exposure FCC ID: 2A6D7-H5 Applied procedures / limit According to FCC §15.247(i) and §1.1307(b)(1), systems operating under the provisions of this section shall be operated in a manner that ensures that the public is not exposed to radio frequency energy level in excess of the Commission’s guidelines. Limits for Occupational / Controlled Exposure Frequency Range (MHz) Electric Field Strength (E) (V/m) Magnetic Field Strength (H) (A/m) Power Density (S) (mW/ cm 2 ) Averaging Time |E| 2 ,|H| 2 or S (minutes) 0.3-3.0 614 1.63 (100)* 6 3.0-30 1842 / f 4.89 / f (900 / f)* 6 30-300 61.4 0.163 1.0 6 300-1500 F/300 6 1500-100,000 5 6 Note: ƒ is frequency in MHz * = Power density limit is applicable at frequencies greater than 100 MHz Limits for General Population / Uncontrolled Exposure Frequency Range (MHz) Electric Field Strength (E) (V/m) Magnetic Field Strength (H) (A/m) Power Density (S) (mW/ cm 2 ) Averaging Time |E| 2 ,|H| 2 or S (minutes) 0.3-1.34 614 1.63 (100)* 30 1.34-30 824/f 2.19/f (180/f)* 30 30-300 27.5 0.073 0.2 30 300-1500 F/1500 30 1500-100,000 1.0 30 Note: f = frequency in MHz * = Plane-wave equivalent power density MPE PREDICTION Predication of MPE limit at a given distance, Equation from OET Bulletin 65, Edition 97-01 Where: S = power density P = power input to antenna G = power gain of the antenna in the direction of interest relative to an isotropic radiator R = distance to the center of radiation of the antenna,R=20cm Test Result of RF Exposure Evaluation Tune up Produce power Maximu m peak output power (dBm) Output power to antenn a (mW) Antenna Gain (numeric) Power Density (S) (mW/ cm2) Lim it (m W / cm 2 ) Result BLE 1±1 2 1.585 1.2589 (1dBi) 0.000397 1 Pass 2.4G WIFI 8±1 9 7.943 1.2589 (1dBi) 0.00199 1 Pass

Shenzhen CTB Testing Technology Co., Ltd. Report No.: CTB220415046RFX Report Tel: 4008-707-283Web: http://www.ctb-lab.net Page 1 of 37 TEST REPORT Compiled by: Reviewed by: Approved by: Chen Zheng Arron Liu Bin Mei / Director The test report is effective only with both signature and specialized stamp. This result(s) shown in this report refer only to the sample(s) tested. Without written approval of Shenzhen CTB Testing Technology Co., Ltd. this report can’t be reproduced except in full. The tested sample(s) and the sample information are provided by the client. Product Name: LCD Projector FCC ID: 2A6D7-H5 Trademark: Divcre Model Number: H5, H6, H7, H8, H9, H10, M1, M2, M3, M4, M5, M6, M7, M8, M9, M10 Prepared For: Shenzhen Divcre Technology Co.,Ltd. Address: 2 F, No.99, Tongfu Cun Industrial Zone,Dalang Community, Dalang Street, Longhua District, Shenzhen,Guangdong, China Manufacturer: Shenzhen Divcre Technology Co.,Ltd. Address: 2 F, No.99, Tongfu Cun Industrial Zone,Dalang Community, Dalang Street, Longhua District,Shenzhen,Guangdong, China Prepared By: Shenzhen CTB Testing Technology Co., Ltd. Address: Floor 1&2, Building A, No. 26 of Xinhe Road, Xinqiao Community, Xinqiao Street, Baoan District, Shenzhen, Guangdong China Sample Received Date: Apr. 13, 2022 Sample tested Date: Apr. 13, 2022 to Apr. 20, 2022 Issue Date: Apr. 20, 2022 Report No.: CTB220415046RFX Test Standards FCC Part15.247 ANSI C63.10:2013 Test Results PASS Remark: This is Bluetooth radio test report. Shenzhen CTB Testing Technology Co., Ltd. Report No.: CTB220415046RFX Report Tel: 4008-707-283 Web: http://www.ctb-lab.net Page 2 of 37 TABLE OF CONTENT Test Report Declaration Page 1. VERSION............................................................ 4 2. TEST SUMMARY ..................................................... 5 3. MEASUREMENT UNCERTAINTY ....................................... 6 4. PRODUCT INFORMATION AND TEST SETUP ........................... 7 4.1 Product Information ..................................................... 7 4.2 Test Setup Configuration ................................................ 7 4.3 Support Equipment ..................................................... 7 4.4 Channel List ........................................................... 8 4.5 Test Mode ............................................................. 8 4.6 Test Environment ....................................................... 8 5. TEST FACILITY AND TEST INSTRUMENT USED ......................... 9 5.1 Test Facility ............................................................ 9 5.2 Test Instrument Used ................................................... 9 6. AC POWER LINE CONDUCTED EMISSION .............................. 12 6.1 Block Diagram Of Test Setup............................................ 12 6.2 Limit ................................................................. 12 6.3 Test procedure ........................................................ 12 6.4 Test Result ........................................................... 14 7. RADIATED SPURIOUS EMISSION ..................................... 16 7.1 Block Diagram Of Test Setup............................................ 16 7.2 Limit ................................................................. 16 7.3 Test procedure ........................................................ 17 7.4 Test Result ........................................................... 18 8. BAND EDGE AND RF COUNDUCTED SPURIOUS EMISSIONS ............ 25 8.1 Block Diagram Of Test Setup............................................ 25 8.2 Limit ................................................................. 25 8.3 Test procedure ........................................................ 25 8.4 Test Result ........................................................... 26 9. COUDUCTED PEAK OUTPUT POWER ................................. 28 9.1 Block Diagram Of Test Setup............................................ 28 9.2 Limit ................................................................. 28 9.3 Test procedure ........................................................ 28 9.4 Test Result ........................................................... 29 10. 6DB OCCUPIED BANDWIDTH ........................................ 31 10.1 Block Diagram Of Test Setup .......................................... 31 10.2 Limit ................................................................ 31 10.3 Test procedure ....................................................... 31 10.4 Test Result .......................................................... 31 11. POWER SPECTRAL DENSITY ........................................ 33 11.1 Block Diagram Of Test Setup .......................................... 33 11.2 Limit ................................................................ 33 11.3 Test procedure ....................................................... 33 Shenzhen CTB Testing Technology Co., Ltd. Report No.: CTB220415046RFX Report Tel: 4008-707-283 Web: http://www.ctb-lab.net Page 3 of 37 11.4 Test Result .......................................................... 33 12. ANTENNA REQUIREMENT ........................................... 33 13. EUT TEST SETUP PHOTOGRAPHS ................................... 36 (Note: N/A means not applicable) Shenzhen CTB Testing Technology Co., Ltd. Report No.: CTB220415046RFX Report Tel: 4008-707-283 Web: http://www.ctb-lab.net Page 4 of 37 1. VERSION Report N o. Issue Date Description Approved CTB220415046RFX Apr. 20, 2022 Original Valid Shenzhen CTB Testing Technology Co., Ltd. Report No.: CTB220415046RFX Report Tel: 4008-707-283 Web: http://www.ctb-lab.net Page 5 of 37 2. TEST SUMMARY The Product has been tested according to the following specifications: Test Item Test Requirement Test method Result AC Power Line Conducted Emission 47 CFR Part 15 Subpart C Section 15.207 ANSI C63.10-2013 Pass Radiated Spurious emissions 47 CFR Part 15 Subpart C Section 15.205/15.209 ANSI C63.10-2013 PAS S Band edge and …
