2A6FY-HS-V113 In 1 Wireless Charger

iPhone 13, iPhone 13 mini, iPhone 13 Pro, iPhone 13 Pro Max, iPhone 12, iPhone 12 mini, iPhone 12 Pro, iPhone 12 Pro Max, iPhone 11, iPhone 11 Pro, iPhone 11 Pro Max, iPhone X, iPhone Xs, iPhone Xs Max, iPhone XR, iPhone 8, Phone 8 Plus 167.5x82x27mm 11 Ultra, 11 Pro, 11, 10s, MIX 4, 10, 10 Pro, 9, 9 Pro, 9X, MIX 3, MIX 2S P50, P50 Pro, Mate 40 Pro, Mate 40 Pro+, Mate 40 RS, Mate 30, Mate 30 RS, Mate 30 Pro, Mate 30E Pro, P40 Pro, P40 Pro+, P30 Pro, Mate 20 Pro, Mate RS Blue light breath LED smart light ring color status Sky blue flash Tap to turn off the light Touch sensitive key Switch ligh 5V/3A, 9V/2A, 12V/2A FCC Statement This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: -- Reorient or relocate the receiving antenna. -- Increase the separation between the equipment and receiver. -- Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. -- Consult the dealer or an experienced radio/TV technician for help. This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. Changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment. This equipment complies with FCC radiation exposure limits set forth for an uncontrolled environment. This equipment should be installed and operated with minimum distance 20cm between the radiator & your body.

1/1 US Agent for Service of Process LETTER OF ATTESTATION TO: Office of Engineering Technology Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 US Agent for Service of Process: Company Name: UGK-LVMUNITEDINC FRN: 0033476375 Contact Name: Jimmychen Address: 6547NAcademyBlvd#2266,ColoradoSprings,CO80918 Telephone No: 001-323-51 04660 Email: [email protected] Applicant: Company name: Shenzhen Huasheng Jiahe Electronic Technology Co., Ltd Grantee code: 2A6FY FCC ID: 2A6FY-HS-V11 Contact Name: Yi Jianjun Address: C301, Building 78, Fourth Industrial Zone, Mashantou Community, Matian Street, Guangming District, Shenzhen Telephone: 13416819658 Fax: 13416819658 E-mail: [email protected] [Shenzhen Huasheng Jiahe Electronic Technology Co., Ltd] certifies that, as of the date of this filing of the application with the TCB, [UGK-LVMUNITEDINC] is our designated US agent for service of process for the above referenced FCC ID. [Shenzhen Huasheng Jiahe Electronic Technology Co., Ltd] accepts to maintain an agent for no less than one year after the grantee has terminated all marketing and importation or the conclusion of any commission related proceeding involving equipment. [UGK- LVMUNITEDINC] accepts, as of the date of the filing of the application, the obligation of the designated US agent for service of process for the above reference FCC ID. The US Agent for Service of Process is aware of and agrees to comply with the requirements outlined in the FCC Equipment Authorization Program, Report and Order FCC 22-84, and clause § 2.911. The Applicant is aware of and agrees to comply with the requirements outlined in the FCC Equipment Authorization Program, Report and Order FCC 22-84, and clause § 2.911. Date: 2023/09/20 Applicant’s Name: Yi Jianjun US Agent for Service of Process’s Name: Jimmychen Title: Manager Title: Manager Signature Signature FRN: 0032255341

C5266091_X24_Ed.2 1/1 “Attestation Statements” TO: Office of Engineering Technology Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 The Commission adopted rules that prohibit equipment authorization for “covered” telecommunications equipment and video surveillance equipment produced by entities identified on the Commission’s Covered List 1 , which is periodically updated. See the Covered List for more details. This Attestation Statement is to confirm that we follow the Section 2.911(d)(5)(i)-(ii) Applicant Company name: Shenzhen Huasheng Jiahe Electronic Technology Co., Ltd Grantee code: 2A6FY FCC ID: 2A6FY-HS-V11 Contact Name: Yi Jianjun Address: C301, Building 78, Fourth Industrial Zone, Mashantou Community, Matian Street, Guangming District, Shenzhen Telephone: 13416819658 Fax: 13416819658 E-mail: [email protected] i. [Shenzhen Huasheng Jiahe Electronic Technology Co., Ltd] (“the applicant”) certifies that the equipment for which authorization is sought is not “covered” equipment prohibited from receiving an equipment authorization pursuant to section 2.903 of the FCC rules. The applicant must sign this certification. ii. [Shenzhen Huasheng Jiahe Electronic Technology Co., Ltd] (“the applicant”) certifies that, as of the date of the filing of the application, the applicant [is not] (as a specifically named entity or any of its subsidiaries or affiliates) identified on the Covered List as an entity producing “covered” equipment. The applicant must sign this certification. [Shenzhen Huasheng Jiahe Electronic Technology Co., Ltd] (“the applicant”) certifies that, as of the date of the filing of the application, the applicant [ is not] identified on the Covered List as an entity producing “covered”equipment . Date: 2023/09/20 Applicant’s Name: Yi Jianjun Title: Manager Signature 1 The Commission’s Covered List is published by the Public Safety and Homeland Security Bureau and posted on the Commission’s website. This Covered List, which is periodically updated, identifies particular equipment, produced by particular entities, that constitutes “covered” equipment. https://www.fcc.gov/supplychain/coveredlist

Shenzhen Huasheng Jiahe Electronic Technology Co., Ltd 1/1 Letter of Authorization Company: Shenzhen Huasheng Jiahe Electronic Technology Co., Ltd Address: C301, Building 78, Fourth Industrial Zone, Mashantou Community, Matian Street, Guangming District, Shenzhen Product Name: 3 In 1 Wireless Charger Model Number: HS-V11 FCC Identifier: 2A6FY-HS-V11 We authorize LGAI Technological Center S.A., Ronda de la Font del Carme, s/n, 08193 Bellaterra, Spain, to act on our behalf on all matters concerning the above named equipment. Any individual within LGAI Technological Center S.A. is authorized to act on our behalf and take action on the application. We declare that authorize LGAI Technological Center S.A., Ronda de la Font del Carme, s/n, 08193 Bellaterra, Spain, is allowed to forward all information related to the approval project to the Federal Communication Commission and to discuss any issues concerning the approval application. Any and all acts carried out by LGAI Technological Center S.A. on our behalf shall have the same effect as acts of our own. Name: Yi Jianjun Date: 2023-09-20 Title: Manager Signature of applicant:

Shenzhen Huasheng Jiahe Electronic Technology Co., Ltd 1/1 Office of Engineering Technology Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 Date: 2022-09-20 Subject: Request for Confidentiality FCC ID: 2A6FY-HS-V11 To Whom It May Concern, Pursuant to the provisions of Sections 0.457 and 0.459 of Commission's rules (47CFR0.457, 0.459), we are requesting the Commission to withhold the following attachment(s) as confidential document from public disclosure. Exhibits Long-Term Confidentiality Short-Term Confidentiality NOTE 2 ID Label/Location No No Attestation Statement No No External Photos No ☐ Block Diagram ☒ ☐ Schematics ☒ ☐ Test Report No No Test Setup Photos No ☐ User’s Manual No ☐ Internal Photos No ☐ Parts List / Tune Up No ☐ RF Exposure Info No No Operational Description ☒ ☐ Cover Letter(s) No No SDR Software / Security Info ☐ No NOTE 1: Long-Term Confidentiality may be permitted under special conditions (See II. LONG-TERM CONFIDENTIALITY, Section 3 of KDB 726920, use last in force) NOTE 2: Short-Term Confidentiality can be requested for a maximum of 180 days from the date of the grant. Above mentioned document contains detailed system and equipment description are considered as proprietary information in operation of the equipment. The public disclosure of above documents might be harmful to our company and would give competitor an unfair advantage in the market. It is our understanding that all measurement test reports, FCC ID label format and correspondent during certification review process cannot be granted as confidential documents and those information will be available for public review once the grant of equipment authorization is issued. Sincerely, Signature: Name: Yi Jianjun Title: Manager

Size:24*20mm M/N: HS-V11 FCC ID: 2A6FY-HS-V11 Label location

ANT ANT ANT

FCC ID: 2A6FY-HS-V11 Product Name: 3 In 1 Wireless Charger Trade Mark: N/A Model No.: HS-V11 Model Difference: N/A Transmitting mode Keep the EUT in continuously wireless charging mode Power supply: Input: DC 5V/3A, DC 9V/2A, DC 12V/2A Output: 5W, 7.5W, 10W, 15W Output watch: 3W Output earphone: 3W Date of Receipt: Sep. 10, 2023 Test Date: Sep. 10, 2023 - Sep. 18, 2023 Date of Report: Sep. 18, 2023 Test Modes: Mode1: Mobile phone wireless output Mode(5W) Mode2: Mobile phone wireless output Mode(7.5W) Mode3: Mobile phone wireless output Mode(10W) Mode4: Mobile phone wireless output Mode(15W) Mode5: Watch wireless output Mode(3W) Mode6: Earphone wireless output Mode(3W) Mode7: Mobile phone wireless output Mode(5W)+Watch wireless output Mode(3W)+ Earphone wireless output Mode(3W) Mode8: Mobile phone wireless output Mode(7.5W)+Watch wireless output Mode(3W)+ Earphone wireless output Mode(3W) Mode9: Mobile phone wireless output Mode(10W)+Watch wireless output Mode(3W)+ Earphone wireless output Mode(3W) Mode10: Mobile phone wireless output Mode(15W)+Watch wireless output Mode(3W)+ Earphone wireless output Mode(3W) Note: 1. We have evaluated 1%, 50% and 99% battery charging mode, and the worst mode (99%) is showed in this report. 2. All modes have been tested, and the report only shows the results of the worst mode9. RF Exposure Evaluation 1 Measuring Standard KDB 680106 RF Exposure Wireless Charging Apps v03r01 2 Requirements According to the item 5 of KDB 680106 v03r01: Inductive wireless power transfer applications that meet all of the following requirements are excluded from submitting an RF exposure evaluation. (1) Power transfer frequency is less than 1MHz. Yes; the device operate in the frequency range from 115 KHz to 205 KHz (2) Output power from each primary coil is less than or equal to 15 watts. Yes; the maximum output power of the primary coil is 15W. (3) The system may consist of more than one source primary coils, charging one or more clients. If more than one primary coil is present, the coil pairs may be powered on at the same time. Yes; the transfer system includes four primary coils. (4) Client device is placed directly in contact with the transmitter. Yes; Client device is placed directly in contact with the transmitter. (5) Mobile exposure conditions only (portable exposure conditions are not covered by this exclusion). Yes, mobile exposure conditions only. (6) The aggregate H-field strengths anywhere at or beyond 15 cm surrounding the device, and 20 cm away Yes, see test result in item 6. from the surface from all coils that by design can simultaneously transmit, and while those coils are simultaneously energized, are demonstrated to be less than 50% of the applicable MPE limit. Remark: Meet all the above requirements. Limits The criteria listed in the following table shall be used to evaluate the environment impact of human exposure to radio frequency (RF) radiation as specified in 1.1307(b) Limits for Maximum Permissible Exposure (MPE) 3 Test Setup 4 Test Procedure 1) The RF exposure test was performed in anechoic chamber. 2) The measurement probe was placed at test distance (15 cm from all sides and 20 cm from the top) which is between the edge of the charger and the geometric center of probe. 3) The highest emission level was recorded and compared with limit as soon as measurement of each points (A, B, C, D, E) were completed. 4) The EUT was measured according to the dictates of KDB 680106 v03r01. Remark：The EUT’s test position A, B, C, D and E is valid for the E and H field measurements. 5 Description of Support Units Adapter (Provide by test lab): Manufacturer: XIAOMI Model: AD65G I/P: AC 100-240V 50/60Hz O/P: DC 5V/3A, DC 9V/3A, DC 10V/5A, DC 12V/3A, DC 15V/3A, DC 20V/3.25A Cell Phone(Provide by test lab): Manufacturer: Apple Model: iPhone 11 Pro Watch (Provide by test lab): Manufacturer: Apple Model: Series 6 Earphone (Provide by test lab): Manufacturer: Apple Model: AirPods 3 6 Test Instruments list Test Equipment Manufacturer Model No. SN. Cal.Date (mm-dd-yy) Cal.Due date (mm-dd-yy) Exposure Level Tester Narda ELT-400 N-0231 June. 25 2023 June. 26 2024 Magnetic field probe 100cm 2 Narda ELT probe 100cm 2 M0675 June. 25 2023 June. 26 2024 Field Probe ETS HI-6105 / June. 25 2023 June. 26 2024 Laser Data Interface ETS HI-6113 / June. 25 2023 June. 26 2024 7 Test Uncertainty E-Filed Strength : ±0.08V/m H-Filed Strength : ±0.02A/m uT : ±0.01 Note: The field intensity value A/m in the report is converted from uT, and the formula is as follows: 8 Test Result E-Filed Strength at 15 cm from the edges surrounding the EUT (V/m) Frequency Range (MHz) Test Position A Test Position B Test Position C Test Position D Limits (V/m) 0.115-0.205 0.19 0.18 0.16 0.14 614 E-Filed Strength at 20 cm from the top of the EUT (V/m) Frequency Range (MHz) Test Position E Limits (V/m) 0.115-0.205 0.10 614 H-Filed Strength at 15 cm from the edges surrounding the EUT (A/m) Frequency Range (MHz) Test Position A Test Position B Test Position C Test Position D Limits (A/m) 0.115-0.205 0.10 0.18 0.11 0.15 1.63 H-Filed Strength at 20 cm from the top of the EUT (A/m) Frequency Range (MHz) Test Position E Limits (A/m) 0.115-0.205 0.18 1.63 9 Test Set-up Photo Please see annex test setup photos.

客户代码版次编制日期承制方 A02022.06.10金晟智能 第 1 页 拟制审核批准 何雪松陈金凤茹威 开发/工程 审核 审核批准 广东金晟智能有限公司 GuangdongJinshengintelligentCo.,Ltd 承认书 SPECIFICATIONFORAPPROVAL 客户名称 深圳市中利冠达科技有限公司 物料描述 承制方型号 14x0.06x65px15TS-引线12mm 承认书编号 客户代码 ZLGD-A1-0022 日期 2022.09.01 生产料号 版本/页 码 A0 承制方确认使用方确认 客户在收到产品后十天内需验收完毕，并将验收结果书面通知供货方，否则视为已验收合格。 承制方：广东金晟智能有限公司 地址：东莞市东城街道温周路289号B栋2楼 电话：0769-22252827 邮箱:[email protected] 客户代码版次编制日期承制方 A02022.06.10金晟智能 第 2 页 广东金晟智能有限公司 GuangdongJinshengintelligentCo.,Ltd 变更记录 序号版次 日期更改内容更改人 1A0 2022.09.01新规格承认何雪松 客户代码版次编制日期承制方 A02022.06.10金晟智能 第 3 页 广东金晟智能有限公司 GuangdongJinshengintelligentCo.,Ltd 结构尺寸 1.外形尺寸: （单位：mm） 普通背胶 3.5±0.3(不含背胶) 7.8mm磁铁 7.8±0.15 14±0.5 24.6±1 27±1 12±1.5 2 ± 1 2.电气性能（L）： 项目 标准测式条件测试仪器备注 圈数 7+8TSTH-200 电感5.4uH±5% 100KHZ,1VTH2817B+ 空心线圈测式 电感110.5uH±0.3 100KHZ,1VTH2817B+ 带磁片测式 3.外观要求： 1)产品形状尺寸要严格控制。 2)产品表面无油污，杂质，毛刺等。 3)不经客户确认，材料不能随意更改 4)产品必须符合ROSH要求 客户代码版次编制日期承制方 A02022.06.10金晟智能 第 4 页 广东金晟智能有限公司 GuangdongJinshengintelligentCo.,Ltd 材料清单 Billofmaterials（材料清单表） 序号 number 材料名称 Materialname 品名描述 Description 物料代码 MaterialCode 1 线材0.06*65P丝包线 2 磁罐 P27*26*2.73内孔8.0（带缺口） 3 磁铁7.8*2.2H(3200±100)镀锌 4 背胶15*0.15H(无孔带耳朵） 5 胶纸3mm茶色 6 胶垫8*0.5H

东莞市德弗力五金电子材料有限公司 Dongguan city DFL Electronic Technology Co.,LTD 承 认 书 客户名称(CUSTOMER): 客户料号(PART NO.): 品 名(DESCRIPTION): 规格(SPECIFICATION): 东莞市石碣镇新风西路107号 电话：0769-86016320 传真：0769-86372427 第 1 页 共 2 页 日 期(DATE): 19.5x27.5,0.08×105P，磁边起50MM 20230920 SPECIFICATION FOR APPROVEAL 本司确认（TRX APPROVAL） 制作 审核 客户确认（CUSTOMER APPROVAL） 确认结果(Result): 合格不合格其它 承认日期 工程 批准 承认日期 曾小仙 邱志辉 20230920 双线圈+磁片 ZLGD-A1-0084 ZLGD-F19.5×27.5-50-FR F H E G A C B D 7.3uH±0.3加磁片 100KHz/1.0V SHDA 1062 J M L K ZLGD-F19.5×27.5-50-FR ZLGD-A1-0084 出线画线 O P 7.0uH±0.3加磁片 100KHz/1.0V SHDA 1062 H 双线圈+磁片 47.5±1.5 40.5±1.5 29.5±1.0 40.5±1.5 50.5±1.5 50.0±3.0 1.0±0.2 85.0±1.0 46.0±1.0 I 产品型号: SPECIFICATION 二、原理图（schematic diagram:） 拟制/日期PREPARED BY/DATE 审核/日期CHECKED BY/DATE 东莞市德弗力五金电子材料有限公司 Dongguan city DFL Electronic Technology Co.,LTD DESC Rev:A 版本 Customer: Date: Description: 一、尺寸DIMENSION:(mm) A B C D E F G I 注: 三、绕线参数(WindingSpecification:) 序号 NO. 端子 TERMINAL 线径 WIRE 圈数 Turns 绕线方向 Winding Direction 四、电气特性 ELECTRICAL CHARACTERISTICS: 温度 TEMPERATURE:25±10°C,湿度 RELATIVE HUMIDITY:65±20% 序号 NO. 客户/日期CUSTOMEU/DATE 端子 TERMINAL 项目 ITEM 标准 SPECIFICATION 测试条件 TEST FREQUENCY 测试仪器 TEST EQUIPMENTS 1 2 3 4 IND. IND. Q值 DCR 20230920 27.5±1.0 19.5±1.0 1 0.08×105P丝包线 9TS 逆时针 1.线圈贴 85*46*1.0硬磁 2.线圈出线位置缠 5MM高温胶带 3.磁片贴白色带耳 朵双面胶 4.上下线圈与磁片 平齐 5.出线画线 6.线圈不可松线 J K L 19.5±1.0 M N 3.0±2.0

惠州启泰电子科技有限公司 HuizhouQitaiElectronicTechnologyCo.,LTD SPECIFICATIONSSHEET CUSTOMER: 客户 DESCRIPTION: 品名描述 CUSTOMERP/N: 客户品名 PARTNUMBER: 制造商料号 DATEOFAPPLICATION: 提出日期 中利冠达 手表线圈 96QTS610RB01 2022-06-06 CLASSIFICATIONOFSPEC.PRESENTATION.(Ticktherelevantbox"√") oNewapplication新规格 √Newpartisaddedtoacceptedspecification新产品规格追加记录 oRevisionofacceptedspecification既存规格图面变更 ACCEPTANCESTAMP() APPROVALBY 承认 CHECKBY 审查 PREPAREBY 制作 ADDRESS:3rdFloor,No.181,Mingyue2ndRoad,ShiwanTown,BoluoCounty,Huizhoucity TELPHONE:0752-6668681 E-MAIL:[email protected] 惠州启泰电子科技有限公司 HuizhouQitaiElectronicTechnologyCo.,LTD HistoryForRevisedSpecification CUSTOMERP/N: 客户品名 中利冠达 PARTNUMBER: 制造商料号 96QTS610RB01 Item 项次 DESCRIPTION(ContentOrReasonForChanged) 变更内容 Rev. 版本 CustRev. 客户版本 Date 日期 Revisor 修订者 1 InitialRelease(初版发行) A0 2022-06-06 冯欣 APPROVEDBY 承认 CHECKEDBY 审查 PREPAREDBY 制作 DATE 日期 PAGE 页码 晁子奇 冯欣 2022-06-06 1of3 惠州启泰电子科技有限公司 HuizhouQitaiElectronicTechnologyCo.,LTD Specification 规格内容 CUSTOMERP/N: 客户品名 中利冠达 PARTNUMBER: 制造商料号 96QTS610RB01 1.DIMENSIONS():(Unit:mm) 单位（Unit）：毫米（mm） ABCDEFG 21Max 14±0.57.5±0.511±11.5±0.5 2.2Max 2.8±Max 1.背胶为3M背胶。 2.线圈1.05H。 3.磁铁尺寸：2.2*7.5。（磁场 2900-3200GS） 4.软磁出线处开线槽。 APPROVEDBY 承认 CHECKEDBY 审查 PREPAREDBY 制作 DATE 日期 PAGE 页码 2022-06-06 2of3 惠州启泰电子科技有限公司 HuizhouQitaiElectronicTechnologyCo.,LTD Specification 规格内容 CUSTOMERP/N: 客户品名 中利冠达 PARTNUMBER: 制造商料号 96QTS610RB01 2.WINDINGDETAILS(绕线详细说明) Coil1 圈数 Turns 线径 WireDia 绕线方式疏/密 Wdg.Type Spred/Close 绕线方向 Wdg.Direction 相交是/否 Intersect Yes/Not 14TS 0.08*24P热风绞线(HotAir strandedWire) 密绕（Close） 逆绕 是（Yes） 3.电气特性（ELECTRICALCHARACTERISTICS）: 温度TEMPERATURE:25±10,RELATIVEHUMIDITY:6510% 序号 NO. 项目 ITEM 端子 TERMINAL 标准 SPECIFICATION 测试条件 TESTFREQUENCY 测试仪器 TESTEQUIPMENTS Coil1 1.INDS-F 8.1±0.3 100kHz/VUC2906A 2.QS-F 20Min 100kHz/VUC2906A 3. DCRS-F 135Max 100kHz/VUC2906A APPROVEDBY 承认 CHECKEDBY 审查 PREPAREDBY 制作 DATE 日期 PAGE 页码 2022-06-06 3of3

Shenzhen DL Testing Technology Co., Ltd. Report No.: DL-20230918080E Test Report Tel: 400-688-3552 Web:www.dl-cert.com Email: [email protected] Page 1 of 18 TEST REPORT FCC ID: 2A6FY-HS-V11 Applicant: Shenzhen Huasheng Jiahe Electronic Technology Co., Ltd Address: C301, Building 78, Fourth Industrial Zone, Mashantou Community, Matian Street, Guangming District, Shenzhen Manufacturer: Shenzhen Huasheng Jiahe Electronic Technology Co., Ltd Address: C301, Building 78, Fourth Industrial Zone, Mashantou Community, Matian Street, Guangming District, Shenzhen EUT: 3 In 1 Wireless Charger Trade Mark: N/A Model Number: HS-V11 Date of Receipt: Sep. 10, 2023 Test Date: Sep. 10, 2023 - Sep. 18, 2023 Date of Report: Sep. 18, 2023 Prepared By: Shenzhen DL Testing Technology Co., Ltd. Address: 101-201, Building C, Shuanghuan, No.8, Baoqing Road, Baolong Industrial Zone, Baolong Street, Longgang District, Shenzhen, Guangdong, China Applicable Standards: FCC PART 15 Subpart C ANSI C63.10:2013 Test Result: Pass Report Number: DL-20230918080E Prepared (Engineer): Lily Fu Reviewer (Supervisor): Jack Bu Approved (Manager): Jade Yang This test report is based on a single evaluation of one sample of above mentioned products. It is not permitted to be duplicated in extracts without written approval of Shenzhen DL Testing Technology Co., Ltd. Shenzhen DL Testing Technology Co., Ltd. Report No.: DL-20230918080E Test Report Tel: 400-688-3552 Web:www.dl-cert.com Email: [email protected] Page 2 of 18 TABLE OF CONTENT Test Report Declaration Page 1. VERSION ................................................................................................................................... 3 2. TEST SUMMARY ..................................................................................................................... 3 3. GENERAL INFORMATION .................................................................................................... 4 4. TEST INSTRUMENT USED ................................................................................................... 6 5. CONDUCTED EMISSION TEST ........................................................................................... 7 6. RADIATION EMISSION TEST ............................................................................................ 11 7. BANDWIDTH TEST ............................................................................................................... 16 8. ANTENNA REQUIREMENT ................................................................................................ 18 9. SETUP PHOTOGRAPHS ..................................................................................................... 18 10. EUT PHOTOGRAPHS ....................................................................................................... 18 Shenzhen DL Testing Technology Co., Ltd. Report No.: DL-20230918080E Test Report Tel: 400-688-3552 Web:www.dl-cert.com Email: [email protected] Page 3 of 18 1. VERSION Version No. Date Description 00 Sep. 18, 2023 Original 2. TEST SUMMARY EMC Emission Test Item Section in CFR 47 Result Remark AC Power Line Conducted Emission 15.207 PASS Spurious Emission 15.209(a)(f) PASS 20dB Bandwidth 15.215 PASS Antenna requirement 15.203 PASS NOTE: (1)” N/A” denotes test is not applicable in this Test Report (2) Test Facility: Shenzhen DL Testing Technology Co., Ltd. Address: 101-201, Building C, Shuanghuan, No.8, Baoqing Road, Baolong Industrial Zone, Baolong Street, Longgang District, Shenzhen, Guangdong, China FCC Test Firm Registration Number: 854456 Designation Number: CN1307 IC Registered No.: 27485 CAB ID.: CN0118 Shenzhen DL Testing Technology Co., Ltd. Report No.: DL-20230918080E Test Report Tel: 400-688-3552 Web:www.dl-cert.com Email: [email protected] Page 4 of 18 3. GENERAL INFORMATION 3.1 Description of Device (EUT) Product Name: 3 In 1 Wireless Charger Trade Mark: N/A Model No.: HS-V11 Model Difference: N/A Serial No.: N/A Hardware version: H1.0 Software version: S1.0 Operation Frequency: 115kHz ~ 205KHz Modulation type: MSK Antenna Type: Inductive loop coil Antenna Antenna gain: 0dBi Power supply: Input: DC 5V/3A, DC 9V/2A, DC 12V/2A Output: 5W, 7.5W, 10W, 15W Output watch: 3W Output earphone: 3W 3.2 Tested System Details None. 3.3 Block Diagram of Test Set-up 3.4 Test Mode Description Mode1: Mobile phone wireless output Mode(5W) Mode2: Mobile phone wireless output Mode(7.5W) Mode3: Mobile phone wireless output Mode(10W) Mode4: Mobile phone wireless output Mode(15W) Mode5: Watch wireless output Mode(3W) Mode6: Earphone wireless output Mode(3W) Mode7: Mobile phone wireless output Mode(5W)+Watch wireless output Mode(3W)+ Earphone wireless output Mode(3W) Mode8: Mobile phone wireless output Mode(7.5W)+Watch wireless output Mode(3W)+ Earphone wireless output Mode(3W) Mode9: Mobile phone wireless output Mode(10W)+Watch wireless output Mode(3W)+ Earphone wireless output Mode(3W) Mode10: Mobile phone wireless output Mode(15W)+Watch wireless output Mode(3W)+ Earphone wireless output Mode(3W) Note: 1. We have evaluated 1%, 50% and 99% battery charging mode, and the worst mode (99%) is showed in this report. 2. All modes have been tested, and the report only shows the results of the worst mode9. AC Mains EUT Adapter Shenzhen DL Testing Technology Co., Ltd. Report No.: DL-20230918080E Test Report Tel: 400-688-3552 Web:www.dl-cert.com Email: [email protected] Page 5 of 18 3.5 Test Auxiliary Equipment Adapter (Provide by test lab): Manufacturer: XIAOMI Model: AD65G I/P: AC 100-240V 50/60Hz O/P: DC 5V/3A, DC 9V/3A, DC 10V/5A, DC 12V/3A, DC 15V/3A, DC 20V/3.25A Cell Phone(Provide by test lab): Manufacturer: Apple Model: iPhone 11 Pro Watch (Provide by test lab): Manufacturer: Apple Model: Series 6 Earphone (Provide by test lab): Manufacturer: Apple Model: AirPods 3 3.6 Test Uncertainty Conducted Emission Uncertainty(150KHz-30MHz) : ±2.56dB 20dB Bandwidth : ±0.5kHz Radiated Emission Uncertainty(9KHz-1GHz) : ±3.24dB Sh…
