2A6IE-DPFSV1Optify TM Performance Sensor

STEP 5 Begin activation Press the silicone button located on the sensor to begin activation. The LED light will blink three times. STEP 6 Assign sensor to asset On the asset page, select your new asset created in step 3. Select “Commission new sensor.” Find your new sensor from the list and follow the prompts. Required information: • Asset name • Nominal speed • Part number • Asset type STEP 7 Installation complete After completing the installation process, the application should function properly. If there are any problems, please contact support at sensortechsupport@ dodgeindustrial.com. OPTIFY ™ Performance Sensor Model: DPFSV1 Installation Instructions Review these instructions in their entirety before attempting to install your OPTIFY Performance Sensor. Getting Started Necessary equipment: Items included in the OPTIFY Performance Sensor kit: • OPTIFY Performance Sensor • Installation tool • Rubber cover (optional) Additional items (required): • Smartphone • Computer Additional items (optional): • Sensor adapter • Gloves • Clean soft cloth • Torque wrench • 1-1/4" (32mm) wrench • 7/16" (11mm) socket • Socket wrench STEP 1 Install OPTIFY application STEP 2 Create an OPTIFY account using the desktop or mobile application, then create or join a plant. dodgeoptify.com STEP 3 Create an asset Log in to the OPTIFY application with the account created in step 2. Select “Assets,” then add a new asset with the “add” button. Fill in the asset details and select “Create Asset.” STEP 4 Mount sensor Step 4.1 Clean surface to be free of dirt and debris. Step 4.2 Find a grease fitting, oil plug, or any other threaded hole that will accept either the sensor or sensor adapter. Optional: Bearing Locate a grease fitting on the 30° face of the bearing and remove plug. Optional: Gearing If being mounted to a gear reducer, locate the OPTIFY Performance Sensor adapter and remove the red push-in plug. Step 4.3 Thread sensor by hand and tighten using the installation tool. If desired, tighten sensor using a torque wrench, applying 7-12 lbs-in (0.8-1.4Nm). NOTE: This sensor is intended for application in hazardous location, typical marking shown below. Specific conditions of use for this application are as follows: 1. The maximum temperature of the mounting surface must be no hotter than +120°C. The ambient temperature range of the sensor is -40°C to 105°C. The installer is responsible for ensuring that the sensor is used between these limits. The assessment of the sensor’s functionality and its role in stopping the equipment in the event of equipment failure is not implied by the certification, which is related to its hazardous area compliance only. La température maximale de la surface de montage ne doit pas être supérieure à +120°C. La plage de température ambiante du capteur est de -40°C à 105°C. L’installateur est responsable de s’assurer que le capteur est utilisé entre ces limites. L’évaluation de la fonctionnalité du capteur et de son rôle dans l’arrêt de l’équipement en cas de défaillance de l’équipement n’est pas impliquée par la certification, qui concerne uniquement sa conformité aux zones dangereuses. 2. Under extreme circumstances, the non- metallic cap may generate an ignition-capable level of electrostatic charge. Therefore, the sensor shall not be installed in a location where the external conditions are conducive to the build-up of electrostatic charge. In addition, the equipment shall only be cleaned with a damp cloth, and the metallic base of the sensor shall be effectively connected to earthed metal when installed. Dans des circonstances extrêmes, le capuchon non métallique peut générer un niveau de charge électrostatique pouvant s’enflammer. Par conséquent, le capteur ne doit pas être installé dans un endroit où les conditions extérieures sont propices à l’accumulation de charges électrostatiques. De plus, l’équipement ne doit être nettoyé qu’avec un chiffon humide et la base métallique du capteur doit être effectivement reliée au métal mis à la terre lorsqu’il est installé. To manage your registered assets, visit OPTIFY: dodgeoptify.com MN7002_OPTIFY Performance Sensor_10.22.indd 1MN7002_OPTIFY Performance Sensor_10.22.indd 111/2/2022 8:01:21 AM11/2/2022 8:01:21 AM Dodge Industrial, Inc. 1061 Holland Road Simpsonville, SC 29681 +1 864 297 4800 All Rights Reserved. Printed in USA. MN7002 10/22 © DODGE INDUSTRIAL, INC. AN RBC BEARINGS COMPANY NOTE: These instructions must be read thoroughly before installation or operation. This instruction manual was accurate at the time of printing. Please see dodgeindustrial.com for updated instruction manuals. CAUTION: The sensor should be installed by technically qualified personnel. Failure to install the sensor in compliance with applicable codes and regulation and according to the manufacturer’s recommendations may result in unsatisfactory performance or equipment failure, and may void the sensor warranty. WARNING: Only qualified individuals who are familiar with appropriate national codes, local codes and sound practices should install, repair or modify mounted bearings and/or related accessories. Installation should conform to appropriate codes and practices. Failure to follow these instructions could result in serious personal injury, death and/or property damage. WARNING: To ensure the drive is not unexpectedly started, turn off and lock-out or tag power source before proceeding. Failure to observe these precautions could result in bodily injur y. WARNING: Because of the possible danger to person(s) or property from accidents which may result from the improper use of products, it is important that correct procedures be followed. Products must be used in accordance with the engineering information specified in the catalog. Proper installation, maintenance and operation procedures must be observed. The instructions in the instruction manuals must be followed. Inspections should be made as necessary to assure safe operation under prevailing condi…

Text truncated - open the document above for the full version.

1061 Holland Road, Simpsonville, SC 29681 USA | dodgeindustrial.com Date: 7/1/2022 UL LLC 12 Laboratory Dr. Research Triangle Park, NC 27709 USA To whom it may concern: I, the undersigned, hereby authorize UL LLC to act on our behalf in all manners relating to application for equipment authorization, including signing of all documents relating to these matters. Any and all acts carried out by UL Verification Services Inc. on our behalf shall have the same effect as acts of our own. I, the undersigned, hereby certify that we are not subject to a denial of federal benefits, that includes FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C. 853(a). In authorizing UL LLC as our representative, we still recognize that we are responsible to: a) fulfill the requirements for the scope of certification requested, including implementing any appropriate changes requested by UL Verification Services Telecommunications Certification Body (TCB) and / or the FCC; b) supply any and all information needed for the evaluation of the products for which certification is sought; c) make claims regarding certification only in respect of the scope for which certification has been granted; d) not use our product certification in such a manner as to bring the TCB or FCC into disrepute and to not make any statement regarding product certification which the TCB or FCC may consider misleading or unauthorized; e) discontinue use of all advertising matter that contains any reference thereto and complies with any and all actions required by the FCC upon suspension or cancellation of certification; f) use certification only to indicate that products are certified in conformity with specified standards; g) endeavor to ensure that no certificate or report or any part thereof is used in a misleading manner, and any copies of the grants/certificates shall be reproduced in their entirety; h) comply with the requirements of the TCB and FCC, including the use of marks and label information prescribed for the scope of certification, when making reference to product certification in communication media such as documents, brochure or advertisements; 1061 Holland Road, Simpsonville, SC 29681 USA | dodgeindustrial.com i) comply with the requirements for certification, supply any information needed for evaluation of products to be certified and, where applicable, make provision for the participation of observers; j) ensure that products marketed under the scope of the requested certification continue to comply with the certification requirements; k) provide a sample of a production unit for testing within 30 days of the request should this product be selected as part of either the TCB’s or the FCC’s market surveillance requirements; l) keep a record of all complaints relating to product’s compliance with requirements of relevant standard; make records available to UL or FCC when requested; take appropriate action with respect to such complaints and any deficiencies found in the product that affect compliance with requirements for certification; document the actions taken with respect to complaints and/or deficiencies; m) inform the TCB immediately of any changes that may affect its ability to comply with the certification requirements. This authorization is valid until further written notice from the applicant. Sincerely, Sheryl Bihler Standards and Certification Manager Dodge Industrial, Inc.

1061 Holland Road, Simpsonville, SC 29681 USA | dodgeindustrial.com Date: 11/14/2022 Attn: FCC Office of Engineering and Technology / UL Verification Services TCB Subject:Request for Confidentiality FCC ID: 2A6IE-DPFSV1 To Whom It May Concern: Pursuant to the provisions of Sections 0.457 and 0.459 of the Commission’s rules (47 CFR §§ 0.457, 0.459), we are requesting the Commission to withhold the following attachments as confidential document from public disclosure indefinitely. • Schematic Diagram • Block Diagram • Theory of Operation Above mentioned document contains detailed system and equipment description are considered as proprietary information in operation of the equipment. The public disclosure of above documents might be harmful to our company and would give competitor an unfair advantage in the market. In additional to above mentioned documents, pursuant to Public Notice DA 04-1705 of the Commission’s policy, in order to comply with the marketing regulations in 47 CFR §2.803 and the importation rules in 47 CFR §2.1204, while ensuring that business sensitive information remains confidential until the actual marketing of newly authorized devices. We are requesting the commission to grant short-term confidentiality request on the following attachments until December 31, 2022. • External Photos • Internal Photos • Test Setup Photos • User Manual It is our understanding that all measurement test reports, FCC ID label format and correspondent during certification review process cannot be granted as confidential documents and that information will be available for public review once the grant of equipment authorization is issued. Regards, Sheryl Bihler Standards and Certification Manager Dodge Industrial, Inc.

® NOTES: LAYOUT OF INFORMATION MAY VARY, PROVIDED CONTENT IS IDENTICAL1. CE , UKCA, EX, AND UL C/US MARKS TO BE 5MM HIGH MINIMUM2. MARKING TO ETCHED TO STAINLESS STEEL COMPONENT IDENTIFIED IN 8200003. WEEE WHEELIE BIN 7MM HIGH MINIMUM4. REPLACE "YYYY" AFTER "MFG:" WITH CURRENT YEAR OF MANUFACTURING. 5. SURFACE FINISH: 125 μin BREAK ALL SHARP EDGES .005-.015 - - - SEE NOTES A REARRANGED FOR CERTIFICATION USCHCOR 10/24/2022 200003691 - 749986 749986-D DODGE OPTIFY PERFORMANCE SENSOR - FULL MARKINGS DIMENSION TOLERANCE, ETC. UNLESS OTHERWISE SPECIFIED: TREATMENT: WEIGHT: MAT'L PART NO: MAT'L DESC: TDR: 1 OF 1 SHEET NUMBER: A PAPER SIZE: FABRICATION TOLERANCE PER S356 MACHINE TOLERANCE PER S022 CASTING TOLERANCE PER S249 DESCRIPTION:DRAWING NO: VERSION: MODEL NO: TIME & DATE: BY: REV: REV. DESC: TITLE BLOCK: MPT-B3

TEST REPORT Report Number. : R14147566-E3 Applicant : Dodge Industrial, Inc. 1061 Holland Rd, Simpsonville, SC, 29681, USA Model : DPFSV1 Brand : Dodge Industrial, Inc. FCC ID : 2A6IE-DPFSV1 EUT Description : OPTIFY™ Performance Sensor Test Standard(s) : FCC 47 CFR PART 1 SUBPART I FCC 47 CFR PART 2 SUBPART J Date Of Issue: 2022-12-29 Prepared by: UL LLC. 12 Laboratory Drive Research Triangle Park, 27709 NC, USA TEL: (919) 549-1400 REPORT NO: R14147566-E3 DATE: 2022-12-29 FCC ID: 2A6IE-DPFSV1 Page 2 of 11 UL LLC FORM NO: 03-EM-F00858 12 Laboratory Dr., RTP, NC 27709 TEL: (919) 549-1400 This report shall not be reproduced except in full, without the written approval of UL LLC. Revision History Rev. Issue Date Revisions Revised By V1 2022-11-10 Initial Issue Noah Bennett V2 2022-12-29 Updated Separation distance in section 7 Noah Bennett REPORT NO: R14147566-E3 DATE: 2022-12-29 FCC ID: 2A6IE-DPFSV1 Page 3 of 11 UL LLC FORM NO: 03-EM-F00858 12 Laboratory Dr., RTP, NC 27709 TEL: (919) 549-1400 This report shall not be reproduced except in full, without the written approval of UL LLC. TABLE OF CONTENTS 1. ATTESTATION OF TEST RESULTS ..................................................................................4 2. TEST METHODOLOGY ......................................................................................................6 3. REFERENCES ....................................................................................................................6 4. FACILITIES AND ACCREDITATION ..................................................................................6 5. DECISION RULES AND MEASUREMENT UNCERTAINTY ...............................................7 5.1. METROLOGICAL TRACEABILITY ...............................................................................7 5.2. DECISION RULES ........................................................................................................7 5.3. MEASUREMENT UNCERTAINTY ................................................................................7 6. MAXIMUM PERMISSIBLE EXPOSURE (LIMITS AND EQUATIONS) ................................8 6.1. FCC RULES .................................................................................................................8 6.2. EQUATIONS .................................................................................................................9 7. STANDALONE SAR TEST EXCLUSION CONSIDERATIONS .........................................11 7.1. FCC ............................................................................................................................11 REPORT NO: R14147566-E3 DATE: 2022-12-29 FCC ID: 2A6IE-DPFSV1 Page 4 of 11 UL LLC FORM NO: 03-EM-F00858 12 Laboratory Dr., RTP, NC 27709 TEL: (919) 549-1400 This report shall not be reproduced except in full, without the written approval of UL LLC. 1. ATTESTATION OF TEST RESULTS COMPANY NAME: Dodge Industrial, Inc. 1061 Holland Rd, Simpsonville, SC 29681, USA EUT DESCRIPTION: Battery-powered, stand-alone measurement device which communicates through BLE to the cloud to monitor condition of industrial machines. MODEL: DPFSV1 BRAND: Dodge Industrial, Inc. SERIAL NUMBER: Non-Serialized SAMPLE RECEIPT DATE: 2022-06-27 DATE TESTED: 2022-06-27 TO 2022-06-28 APPLICABLE STANDARDS STANDARD TEST RESULTS FCC PART 1 SUBPART I & PART 2 SUBPART J Complies UL LLC. tested the above equipment in accordance with the requirements set forth in the above standards. The test results show that the equipment tested is capable of demonstrating compliance with the requirements as documented in this report. The results documented in this report apply only to the tested sample, under the conditions and modes of operation as described herein. It is the manufacturer's responsibility to assure that additional production units of this model are manufactured with identical electrical and mechanical components. All samples tested were in good operating condition throughout the entire test program. Measurement Uncertainties are published for informational purposes only and were not taken into account unless noted otherwise. This document may not be altered or revised in any way unless done so by UL LLC. and all revisions are duly noted in the revisions section. Any alteration of this document not carried out by UL LLC. will constitute fraud and shall nullify the document. REPORT NO: R14147566-E3 DATE: 2022-12-29 FCC ID: 2A6IE-DPFSV1 Page 5 of 11 UL LLC FORM NO: 03-EM-F00858 12 Laboratory Dr., RTP, NC 27709 TEL: (919) 549-1400 This report shall not be reproduced except in full, without the written approval of UL LLC. Approved & Released For UL LLC. By: Prepared By: Jeff Moser Noah Bennett Operations Manager Electrical Engineer CONSUMER, MEDICAL and IT CONSUMER, MEDICAL and IT UL LLC. UL LLC. REPORT NO: R14147566-E3 DATE: 2022-12-29 FCC ID: 2A6IE-DPFSV1 Page 6 of 11 UL LLC FORM NO: 03-EM-F00858 12 Laboratory Dr., RTP, NC 27709 TEL: (919) 549-1400 This report shall not be reproduced except in full, without the written approval of UL LLC. 2. TEST METHODOLOGY All calculations were made in accordance with FCC Parts 1.1310, 2.1091, 2.1093, KDB 447498 D01 v06, KDB 447498 D03 V01, IEEE Std C95.1-2005, IEEE Std C95.3-2002. 3. REFERENCES Output power, Duty cycle and Antenna gain data were declared from the manufacturer. 4. FACILITIES AND ACCREDITATION UL LLC is accredited by A2LA, Certificate Number 0751.06, for all testing performed within the scope of this report. Testing was performed at the locations noted below. Address ISED CABID ISED Company Number FCC Registration ☒ Building 2800 Suite Perimeter Park Dr. Suite B Morrisville, NC 27560, U.S.A US0067 27265 825374 REPORT NO: R14147566-E3 DATE: 2022-12-29 FCC ID: 2A6IE-DPFSV1 Page 7 of 11 UL LLC FORM NO: 03-EM-F00858 12 Laboratory Dr., RTP, NC 27709 TEL: (919) 549-1400 This report shall not be reproduced except in full, without the written approval of UL LLC. 5. DECISION RULES AND MEASUREMENT UNCERTAINTY 5.1…

Text truncated - open the document above for the full version.

TEST REPORT Report Number. : R14147566-E1 Applicant : Dodge Industrial, Inc. 1061 Holland Rd, Simpsonville, SC, 29681, USA Model : DPFSV1 Brand : Dodge Industrial, Inc. FCC ID : 2A6IE-DPFSV1 IC : 28778-DPFSV1 EUT Description : OPTIFY™ Performance Sensor Test Standard(s) : FCC 47 CFR PART 15 SUBPART C:2022 ISED RSS-247 ISSUE 2: 2017 ISED RSS-GEN ISSUE 5 + A2:2021 Date Of Issue: 2022-11-11 Prepared by: UL LLC. 12 Laboratory Drive Research Triangle Park, 27709 NC, USA TEL: (919) 549-1400 REPORT NO: R14147566-E1 DATE: 2022-11-1 1 FCC ID: 2A6IE-DPFSV1 IC: 28778-DPFSV1 Page 2 of 61 UL LLC 12 Laboratory Dr., RTP, NC 27709; USA TEL:(919) 549-1400 This report shall not be reproduced except in full, without the written approval of UL LLC REPORT REVISION HISTORY Rev. Issue Date Revisions Revised By V1 2022-07-15 Initial Issue Noah Bennett V2 2022-11-11 Corrected IC Noah Bennett REPORT NO: R14147566-E1 DATE: 2022-11-1 1 FCC ID: 2A6IE-DPFSV1 IC: 28778-DPFSV1 Page 3 of 61 UL LLC 12 Laboratory Dr., RTP, NC 27709; USA TEL:(919) 549-1400 This report shall not be reproduced except in full, without the written approval of UL LLC TABLE OF CONTENTS REPORT REVISION HISTORY ..................................................................................................2 TABLE OF CONTENTS .............................................................................................................3 1. ATTESTATION OF TEST RESULTS ..................................................................................5 2. TEST RESULTS SUMMARY ...............................................................................................7 3. TEST METHODOLOGY ......................................................................................................7 4. FACILITIES AND ACCREDITATION ..................................................................................7 5. DECISION RULES AND MEASUREMENT UNCERTAINTY ...............................................8 5.1. METROLOGICAL TRACEABILITY ...............................................................................8 5.2. DECISION RULES ........................................................................................................8 5.3. MEASUREMENT UNCERTAINTY ................................................................................8 5.4. SAMPLE CALCULATION .............................................................................................8 6. EQUIPMENT UNDER TEST ................................................................................................9 6.1. EUT DESCRIPTION .....................................................................................................9 6.2. MAXIMUM OUTPUT POWER .......................................................................................9 6.3. DESCRIPTION OF AVAILABLE ANTENNAS ...............................................................9 6.4. SOFTWARE AND FIRMWARE .....................................................................................9 6.5. WORST-CASE CONFIGURATION AND MODE ...........................................................9 6.6. DESCRIPTION OF TEST SETUP ...............................................................................10 7. MEASUREMENT METHOD...............................................................................................11 8. TEST AND MEASUREMENT EQUIPMENT ......................................................................12 9. ANTENNA PORT TEST RESULTS ...................................................................................15 9.1. ON TIME AND DUTY CYCLE .....................................................................................15 9.2. 99% BANDWIDTH ......................................................................................................17 9.2.1. BLE (1Mbps) ........................................................................................................17 9.2.2. BLE (2Mbps) ........................................................................................................18 9.2.3. BLE (125Kbps) ....................................................................................................19 9.2.4. BLE (500Kbps) ....................................................................................................20 9.3. 6 dB BANDWIDTH ......................................................................................................21 9.3.1. BLE (1Mbps) ........................................................................................................21 9.3.2. BLE (2Mbps) ........................................................................................................22 9.3.3. BLE (125Kbps) ....................................................................................................23 9.3.4. BLE (500Kbps) ....................................................................................................24 9.4. OUTPUT POWER .......................................................................................................25 REPORT NO: R14147566-E1 DATE: 2022-11-1 1 FCC ID: 2A6IE-DPFSV1 IC: 28778-DPFSV1 Page 4 of 61 UL LLC 12 Laboratory Dr., RTP, NC 27709; USA TEL:(919) 549-1400 This report shall not be reproduced except in full, without the written approval of UL LLC 9.4.1. BLE (1Mbps) ........................................................................................................25 9.4.2. BLE (2Mbps) ........................................................................................................26 9.4.3. BLE (125Kbps) ....................................................................................................26 9.4.4. BLE (500Kbps) ....................................................................................................26 9.5. AVERAGE POWER ....................................................................................................27 9.5.1. BLE (1Mbps) ...................................................…

Text truncated - open the document above for the full version.

DATA SHEET WIRELESS COMPONENTS Ceramic Chip Antenna ANT3216LL00R2400A 2.4 - 2.5 GHZ 3216 Serie s Product Specification – March 27, 2013 V.0 www.yageo.com Mar. 27, 2013 V0 WIRELESS COMPONENTS 2 6 Product specification Ceramic Chip Antenna FEATURES z Compact size z Omni-directional radiation z Tape & reel automatic mounting z Reflow process compatible z RoHS compliant APPLICATIONS z 2.4 GHz WiFi device z Bluetooth gadget z Zigbee device z ISM band equipment ORDERING INFORMATION All part numbers are identified by the series, packing type, material, size, antenna type, working frequency and packing quantity. PART NUMBER ANT 3216 L L00 R 2400A (1) (2) (3) (4) (5) (6) ( 1 ) PRODUCT ANT = Antenna ( 2 ) SIZE 3216 = 3.2 × 1.6 mm ( 3 ) ANTENNA TYPE L,F,A = Chip Antenna ( 4 ) SERIAL NO. L00 ( 5 ) PACKING TYPE R = Tape and Reel ( 6 ) WORKING FREQUENCY 2400 = 2.4GHz PHYCOMP CTC CAN4311712002453K 12NC 431171200245 www.yageo.com Mar. 27, 2013 V0 WIRELESS COMPONENTS 3 6 Product specification Ceramic Chip Antenna SPECIFICATION DESCRIPTION VALUE Working Frequency 2.4 - 2.5 GHz Bandwidth 160 MHz Polarization Linear Azimuth Beamwidth Omni-directional Peak Gain 5.05 dBi (Typ.) Impedance 50Ω Operating Temperature -40 ~105°C Maximum Power 1W Termination Ni / Sn (Environmentally-Friendly Leadless) Resistance to Soldering Heats 260°C , 10sec. NOTE 1. The specification is defined on Yageo evaluation board Ta b l e 1 O O U U T T L L I I N N E E S S YNH0010 Side ViewTop View Bot t om View T W L C S1S2 Fig. 1 Antenna outlines DIMENSIONS DIMENSION L (mm) 3.20 ±0.15 W (mm) 1.60 ±0.15 T (mm) 1.20 ±0.15 C (mm) 0.40 ±0.20 Table 2 Machinical Dimension TERMINAL NAME FUNCTION S1 Feeding Point S2 Soldering Point Table 3 Termination configuration www.yageo.com Mar. 27, 2013 V0 WIRELESS COMPONENTS 4 6 Product specification Ceramic Chip Antenna YNH0011 Bottom Layer Top Layer 2.5 2.0 3.5 0.4 Matching Circuit 1.8 Unit : mm Unit : mm 1030 18 Fig. 2 Outlook and dimension of evaluation board REFERENCE DESIGN OF EVALUATION BOARD Fig. 3 Details of soldering Pad www.yageo.com Mar. 27, 2013 V0 WIRELESS COMPONENTS 5 6 Product specification Ceramic Chip Antenna 2.0 2.13.0 f (GHz) Return loss (dB) −50 −30 −10 10 30 50 2.2 2.3 2.4 2.5 2.6 2.7 2.8 2.9 YNH0012 1 2 3 Fig. 4 Return loss ELECTRICAL PERFORMANCES YNH0013 Y X Z Z axle X axleY axle Gain (dBi) 5.00 − 0.00 − − 5.00 − − 10.00 − − 15.00 − − 20.00 − − 25.00 − − 30.00 − − 35.00 − Fig. 5 Radiation pattern Max gain = 5.05 dBi, at (180, 60) MEG (mean effective gain)= 0.45dBi Directivity (dB) = 7.15 Efficiency = -1.50dB, 70.74% Evaluation board and XYZ direction Marker data 1. 2.37GHz, -10dB 2. 2.45GHz, -27.3dB 3. 2.53GHz, -10dB www.yageo.com Mar. 27, 2013 V0 WIRELESS COMPONENTS 6 6 Product specification Ceramic Chip Antenna REVISION HISTORY REVISION DATE CHANGE NOTIFICATION DESCRIPTION Version 0 Mar. 27, 2013 - - New datasheet for Ceramic Chip Antenna, 2.4-2.5 GHz application, size 3216 series

SETUP PHOTOS EXHIBIT Report Number. : R14147566-EP1 Applicant : Dodge Industrial, Inc. 1061 Holland Rd, Simpsonville, SC, 29681, USA Model : DPFSV1 Brand : Dodge Industrial, Inc. FCC ID : 2A6IE-DPFSV1 IC : 94836-DPFSV1 EUT Description : OPTIFY™ Performance Sensor Test Standard(s) : FCC 47 CFR PART 15 SUBPART C:2022 ISED RSS-247 ISSUE 2: 2017 ISED RSS-GEN ISSUE 5 + A2:2021 Date Of Issue: 2022-07-15 Prepared by: UL LLC. 12 Laboratory Drive Research Triangle Park, 27709 NC, USA TEL: (919) 549-1400 REPORT NO: R14147566-EP1 DATE: 2022-07-15 FCC ID: 2A6IE-DPFSV1 IC ID: 94836-DPFSV1 Page 2 of 11 UL LLC 12 Laboratory Dr., RTP, NC 27709; USA TEL: (919) 549-1400 This report shall not be reproduced except in full, without the written approval of UL LLC REPORT REVISION HISTORY Rev. Issue Date Revisions Revised By v1 2022-07-15 Initial Issue Noah Bennett REPORT NO: R14147566-EP1 DATE: 2022-07-15 FCC ID: 2A6IE-DPFSV1 IC ID: 94836-DPFSV1 Page 3 of 11 UL LLC 12 Laboratory Dr., RTP, NC 27709; USA TEL: (919) 549-1400 This report shall not be reproduced except in full, without the written approval of UL LLC TABLE OF CONTENTS REPORT REVISION HISTORY ..................................................................................................2 TABLE OF CONTENTS .............................................................................................................3 1. SETUP DIAGRAMS ............................................................................................................4 2. SETUP PHOTOS .................................................................................................................5 END OF TEST REPORT ..........................................................................................................11 REPORT NO: R14147566-EP1 DATE: 2022-07-15 FCC ID: 2A6IE-DPFSV1 IC ID: 94836-DPFSV1 Page 4 of 11 UL LLC 12 Laboratory Dr., RTP, NC 27709; USA TEL: (919) 549-1400 This report shall not be reproduced except in full, without the written approval of UL LLC 1. SETUP DIAGRAMS Conducted & Radiated: REPORT NO: R14147566-EP1 DATE: 2022-07-15 FCC ID: 2A6IE-DPFSV1 IC ID: 94836-DPFSV1 Page 5 of 11 UL LLC 12 Laboratory Dr., RTP, NC 27709; USA TEL: (919) 549-1400 This report shall not be reproduced except in full, without the written approval of UL LLC 2. SETUP PHOTOS CONDUCTED MEASUREMENT SETUP REPORT NO: R14147566-EP1 DATE: 2022-07-15 FCC ID: 2A6IE-DPFSV1 IC ID: 94836-DPFSV1 Page 6 of 11 UL LLC 12 Laboratory Dr., RTP, NC 27709; USA TEL: (919) 549-1400 This report shall not be reproduced except in full, without the written approval of UL LLC RADIATED MEASURMENT SETUP - BLE RADIATED BELOW 30MHz 0 DEG RADIATED BELOW 30MHz 90 DEG REPORT NO: R14147566-EP1 DATE: 2022-07-15 FCC ID: 2A6IE-DPFSV1 IC ID: 94836-DPFSV1 Page 7 of 11 UL LLC 12 Laboratory Dr., RTP, NC 27709; USA TEL: (919) 549-1400 This report shall not be reproduced except in full, without the written approval of UL LLC RADIATED BELOW 30MHz FLAT RADIATED BELOW 30MHZ FRONT REPORT NO: R14147566-EP1 DATE: 2022-07-15 FCC ID: 2A6IE…

Text truncated - open the document above for the full version.
