2A6ZM-BZJ001White noise device

第 1 页 共 7 页 白噪机使用说明书 White noise device operation instruction ■ 产品主要功能 ■Product main function 1、白噪音功能（White noise function） 2、小夜灯功能（Night light function） 3、多彩灯功能（Colorful lights function） 4、时钟功能（The Clock function） 5、蓝牙音箱功能（Bluetooth speakers） 6、音乐律动功能（Music rhythm function） 7、耳机播放功能（Headphones function） ■ 使用说明（Directions For Use） 1. 开机键（The power button）： 1.1上电时处于关机状态，短按（短按<2秒, 下同）开关键开机，开机时语音提示”Power on”，同时 点亮时钟。 While plug the USB cable, short press (short press < 2 seconds, the same blow) to turn on the device, voice play” Power on” and shows the clock. 1.2 开机状态时轻触开关键，关闭机器并记忆当前播放音乐曲目及音量，进入待机状态，时钟若是是点亮 状态则仍保留显示时钟。 When the device is working on, press the on/off button to turn off the device and memorize the current music and volume to enter the standby state. If the clock is on, it will still display the clock. 1.3 在开机状态时，长按（长按≥2秒，下同）开关键，进入关机状态, 语音提示”Power off”。 In working state, long press (hold for 2 seconds, the same below) on on/off button to enter shutdown state, voice play” Power off”. 白噪机使用说明书 V0.1 第 2 页 共 7 页 1.4 儿童锁功能：机器在当前工作状态，同时按住“+”“-”键2秒，机器进入锁定当前状态，按其它 按键操作无效， 锁定时语音提示 “lock”。 Child lock function: When the device is in the current working state, press the “+” “-“ button together for 2 seconds, the device will enter the locking state, the voice will play “lock” when the device is locked, press other keys is invalid. 1.5 儿童锁解锁：机器在锁定状态, 同时按住“+”“-”键2秒，机器解除锁定, 语音提示”unlock”。 Child lock unlock: When the device is locked, press the “+””-“ button together for 2 seconds to unlock the device and voice play “unlock”.. 2. “+”键：向上调节音量（亮度、时间），播放模式时调音量，夜灯或氛围灯模式时调亮度，设置时钟状态 时调时间。 “+”：adjust the volume (brightness and time) upward, adjust the volume in play mode, adjust the brightness in night light or atmosphere light mode. and adjust the time in clock state. 3. “-”键：向下调节音量（亮度、时间），播放模式时调音量，夜灯或氛围灯模式时调亮度，设置时钟状态时 调时间。 “-”：Down to adjust the volume, brightness, time, play mode sort of volume, night light lamp or atmosphere model sort of brightness, set the clock state sort of time. 4. 时钟键（The clock button）： 4.1 时间开启与关闭：当插上电源时，按开关键开机时，时钟显示当前时间。 Time on and off: When plugged in, press the “on” key to power on, the clock will display the current time. 4.2 开机后，待机状态(没有点亮灯光或播放音乐时)短按时钟按键，开启或关闭时钟显示。 While the device in on, press the clock button in standby state (when no light or music is played) to turn on or off the clock display. 白噪机使用说明书 V0.1 第 3 页 共 7 页 4.3 调整时钟：待机状态长按2秒时钟键，进入时钟设置功能，首先时钟 (时位闪烁)，然后通过“+”和 “-”键设定时间, 再短按时钟键进入分针设定(分位闪烁), 再长按时钟键2秒或间隔10秒无动作后保存 当前时间，并退出时钟设置功能。 Adjust clock: standby long press 2 seconds, the clock, enter the clock setting function, first of all, the clock (flash), and then through the "" and" - "button to set the time, short press the clock button to enter again set the minute hand (flash), press the clock button for 2 seconds or longer after no action to save the current time interval for 10 seconds, and exit the clock setting function. 4.4 定时功能：在开灯或播放本地音乐时，按时钟键，定时时间为15、30、60、90、120分钟（LED做 相应指示），每次开机均默认为不定时。 Timing function: when turn on the light or local music, press the clock button, timer for 15, 30, 60, 90, and 120 minutes (LED accordingly instructions), each are switched on by default for the timing. 5. 本地音乐播放（Local music playing）： 5.1 在机器开机状态：短按“音乐键”“天气键”“白噪音键”，机器开始单曲循环播放同一首曲目(对 应音乐、自然音或白噪音)，显示屏提示”ONE”表示单曲循环。 When the device is on: press "Music button". "Weather button" and "White noise button", the device starts to play the same song (corresponding to music, natural sound or white noise) repeatedly, and the display prompt "ONE“ indicates the single cycle. 5.2 再次按对应按键直接切换下一首曲目并单曲循环播放。 Press the corresponding button again to directly switch to the track and play the single in a loop. 5.3 关机时带记忆功能，记忆关机时的曲目和音量，用户再次进入时直接播放关机前所选曲目和音量。 With memory function when shutting down, memory of the track and volume when shutting down, when the user enters again directly play the selected tracks and volume before shutting down. 5.4 长按“音乐键”“天气键”“白噪音键”，机器将按轻音乐或自然音乐或白噪音列表中的曲目对应全 白噪机使用说明书 V0.1 第 4 页 共 7 页 部循环播放，显示屏提示”ALL”表示全曲循环，再次短按单曲循环播放当前曲目。 Long press "music" and "Weather" "white noise" button, the device will be effected according to the light music or natural music or white noise in the list of ALL tracks corresponding looping, screen prompts "ALL" said the whole song cycle, short by a single loop current tracks again. 5.5 播放本地存储音乐，不开启音乐律动功能。 Play the local store music, will not open the music rhythm function. 5.6在播放音乐时可通过短按时钟键作定时设定，在定时到后自动关闭音乐并记忆当前播放曲目和音量。 When playing music through short press clock timing set, in time to shut down automatically after the current play songs and music and memory volume. 6. 灯光选择（Lighting options）： 6.1在机器处于开机状态时, 短按灯光键，点亮夜灯功能。 When the device is on, press the light button to turn on the night light function. 6.2 再短按时切换灯光，灯光顺序为，暖光、蓝光、红光、绿光、蓝+红、蓝+绿、红+绿、蓝+红+绿、 七彩呼吸、七彩跑马、关灯共11档。 Switch the light in a short time. The lighting sequence Is: warm light, blue light, red light, green light, blue + red, blue + green, red + green, blue + red + green, colorful breathing, colorful horse running, and lights off. 6.3 开灯状态长按灯光键，直接关灯，或短按开关键直到关灯档位关闭灯光。 Turn on the light condition long press lights, directly to turn off the lights, or short press the open key until shut the lights turn off the lights and gear. 6.4 灯光亮度分为高中低三个档位，亮灯时默认为高档, 在亮灯状态通过“+”“-”来调整LED亮度。 Lighting brightness is divided into three gears: high, middle and low. When the light is on, it is high by default. When the light is on, the LED brightness can be adjusted by “+”and “-“ button. 6.5在亮灯时可通过短按时钟键作定时设定，在定时到后自动关闭灯光。 When the lights by short press clock timing set, in time to shut down automatically after the 白噪机使用说明书 V0.1 第 5 页 共 7 页 lights. 6.6 在待机状态(开机时灯光和声音均未工作时), 轻拍机器，自动点亮夜灯(亮度按上次关机时的档位)，开 灯后长按灯光键，直接关灯，或短按开关键直到关灯档位关闭灯光。 In standby mode (lights and sound did not work when the device is turned on), tap the device to automatically light up the night light (the brightness is the same as when it was turned off last time). After turning on the light, long press the light button to turn off the light d…

Text truncated - open the document above for the full version.

Shenzhen HTT Technology Co., Ltd. Report No.: HTT202205265 Shenzhen HTT Technology Co.,Ltd. Tel: 0755-23595200 Fax: 0755-23595201 1F, Building B, Huafeng International Robotics Industrial Park,Hangcheng Road, Nanchang Community, Xixiang Street, Bao'an District, Guangdong Province, Shenzhen, China Page 1 of 3 Product Name: White noise device Model No.: BZJ001 EUT Constructional Details External Photo Report No.: HTT202205265 Shenzhen HTT Technology Co.,Ltd. Tel: 0755-23595200 Fax: 0755-23595201 1F, Building B, Huafeng International Robotics Industrial Park,Hangcheng Road, Nanchang Community, Xixiang Street, Bao'an District, Guangdong Province, Shenzhen, China Page 2 of 3 Report No.: HTT202205265 Shenzhen HTT Technology Co.,Ltd. Tel: 0755-23595200 Fax: 0755-23595201 1F, Building B, Huafeng International Robotics Industrial Park,Hangcheng Road, Nanchang Community, Xixiang Street, Bao'an District, Guangdong Province, Shenzhen, China Page 3 of 3 ------End------

White noise device Model: BZJ001 FCC ID: 2A6ZM-BZJ001

Shenzhen HTT Technology Co., Ltd. Report No.: HTT202205265 Shenzhen HTT Technology Co.,Ltd. Tel: 0755-23595200 Fax: 0755-23595201 1F, Building B, Huafeng International Robotics Industrial Park,Hangcheng Road, Nanchang Community, Xixiang Street, Bao'an District, Guangdong Province, Shenzhen, China Page 1 of 2 Product Name: White noise device Model No.: BZJ001 EUT Constructional Details Internal Photo Report No.: HTT202205265 Shenzhen HTT Technology Co.,Ltd. Tel: 0755-23595200 Fax: 0755-23595201 1F, Building B, Huafeng International Robotics Industrial Park,Hangcheng Road, Nanchang Community, Xixiang Street, Bao'an District, Guangdong Province, Shenzhen, China Page 2 of 2 ------End------

RF Exposure evaluation FCC ID: 2A6ZM-BZJ001 1.1. Applicable Standard According to §1.1307(b)(1), systems operating under the provisions of this section shall be operated in a manner that ensures that the public is not exposed to radio frequency energy level in excess of the Commission’s guidelines. According to §1.1310 and §2.1093 RF exposure requirement KDB447498 v06: Mobile and Portable Devices RF Exposure Procedures and Equipment Authorization Policies 1.2. Requirement According to KDB447498 D01 General RF Exposure Guidance v06 Section 4.3.1 Standalone SAR test exclusion considerations: “Unless specifically required by the published RF exposure KDB procedures, standalone 1-g head or body and 10-g extremity SAR evaluation for general population exposure conditions, by measurement or numerical simulation, is not required when the corresponding SAR Test Exclusion Threshold condition, listed below, is satisfied. These test exclusion conditions are based on source-based time-averaged maximum conducted output power of the RF channel requiring evaluation, adjusted for tune-up tolerance, and the minimum test separation distance required for the exposure conditions.22 The minimum test separation distance is determined by the smallest distance from the antenna and radiating structures or outer surface of the device, according to the host form factor, exposure conditions and platform requirements, to any part of the body or extremity of a user or bystander (see 5) of section 4.1). To qualify for SAR test exclusion, the test separation distances applied must be fully explained and justified by the operating configurations and exposure conditions of the transmitter and applicable host platform requirements, typically in the SAR measurement or SAR analysis report, according to the required published RF exposure KDB procedures. When no other RF exposure testing or reporting is required, a statement of justification and compliance must be included in the equipment approval, in lieu of the SAR report, to qualify for the SAR test exclusion. When required, the device specific conditions described in the other published RF exposure KDB procedures must be satisfied before applying these SAR test exclusion provisions; for example, handheld PTT two-way radios, handsets, laptops & tablets etc.23 “ [(max. power of channel, including tune-up tolerance, mW)/ (min. test separation distance, mm)] · [√f (GHz)] ≤ 3.0 for 1-g SAR and ≤ 7.5 for 10-g extremity SAR, where: • f (GHz) is the RF channel transmit frequency in GHz • Power and distance are rounded to the nearest mW and mm before calculation • The result is rounded to one decimal place for comparison • 3.0 and 7.5 are referred to as the numeric thresholds in the step 2 below The test exclusions are applicable only when the minimum test separation distance is ≤ 50 mm and for transmission frequencies between 100 MHz and 6 GHz. When the minimum test separation distance is < 5 mm, a distance of 5 mm according to 5) in section 4.1 is applied to determine SAR test exclusion. 1.3. Manufacturing tolerance GFSK (Peak) Channel Channel 00 Channel 19 Channel 39 Target (dBm) 0 0 0 Tolerance ±(dB) 1.0 1.0 1.0 Page 2 of 2 2. E v a l u a t i o n R e s u l t Evaluation Results Band/Mode f (GHz) Antenna Distance (mm) RF output power (including tune-up tolerance) SAR Test Exclusion Threshold SAR Test Exclusion dBm mW BT 2.5 5 1 1.2589 0.3981<3.0 Yes 3. C o n c l u s i o n The measurement results comply with the FCC Limit per 47 CFR 2.1093 for the uncontrolled RF Exposure and SAR Exclusion Threshold per KDB 447498 v06 .....................End of Report.........................

Shenzhen HTT Technology Co., Ltd. Report No.: HTT202205265F01 This results shown in this test report refer only to the sample(s) tested, this test report cannot be reproduced, except in full, without prior written permission of the company. The report would be invalid without specific stamp of test institute and the signatures of compiler and approver. Page 1 of 30 TEST Report Applicant: Xiamen Lanchuang Time Technology Co.,Ltd Address of Applicant: Room 1808, No.1 Yilan Road, Siming District, Xiamen City, Fujian Province, China Manufacturer : Xiamen E-Calling Electronic Co., Ltd Address of Manufacturer : Room 201, Building 1, No. 268 Houxiang Road, Xinyang Industrial Zone, Haicang District, Xiamen, China Equipment Under Test (EUT) Product Name: White noise device Model No.: BZJ001 Series model: N/A Trade Mark: BLAUPUNKT,THOMSON FCC ID: 2A6ZM-BZJ001 Applicable standards: FCC CFR Title 47 Part 15 Subpart C Section 15.247 Date of sample receipt: May.13,2022 Date of Test: May.13,2022~May.20,2022 Date of report issued: May.20,2022 Test Result : PASS * * In the configuration tested, the EUT complied with the standards specified above. Report No.: HTT202205265F01 Shenzhen HTT Technology Co.,Ltd. Tel: 0755-23595200 Fax: 0755-23595201 1F, Building B, Huafeng International Robotics Industrial Park, Hangcheng Road,Nanchang Community, Xixiang Street, Bao'an District, Shenzhen, Guangdong, China Page 2 of 30 1. Version Version No. Date Description 00 May.20,2022 Original Tested/ Prepared By Date: May.20,2022 Project Engineer Check By: Date: May.20,2022 Reviewer Approved By : Date: May.20,2022 Authorized Signature Report No.: HTT202205265F01 Shenzhen HTT Technology Co.,Ltd. Tel: 0755-23595200 Fax: 0755-23595201 1F, Building B, Huafeng International Robotics Industrial Park, Hangcheng Road,Nanchang Community, Xixiang Street, Bao'an District, Shenzhen, Guangdong, China Page 3 of 30 2. Contents Page 1. VERSION ........................................................................................................................................................ 2 2. CONTENTS .................................................................................................................................................... 3 3. TEST SUMMARY ........................................................................................................................................... 4 4. GENERAL INFORMATION ............................................................................................................................ 5 4.1. GENERAL DESCRIPTION OF EUT ................................................................................................................ 5 4.2. TEST MODE ............................................................................................................................................... 7 4.3. DESCRIPTION OF SUPPORT UNITS .............................................................................................................. 7 4.4. DEVIATION FROM STANDARDS .................................................................................................................... 7 4.5. ABNORMALITIES FROM STANDARD CONDITIONS ........................................................................................... 7 4.6. TEST FACILITY ........................................................................................................................................... 7 4.7. TEST LOCATION ......................................................................................................................................... 7 4.8. ADDITIONAL INSTRUCTIONS ........................................................................................................................ 7 5. TEST INSTRUMENTS LIST ........................................................................................................................... 8 6. TEST RESULTS AND MEASUREMENT DATA ........................................................................................... 9 6.1. CONDUCTED EMISSIONS ............................................................................................................................ 9 6.2. CONDUCTED OUTPUT POWER .................................................................................................................. 12 6.3. CHANNEL BANDWIDTH .............................................................................................................................. 13 6.4. POWER SPECTRAL DENSITY ..................................................................................................................... 15 6.5. BAND EDGES ........................................................................................................................................... 17 6.5.1. Conducted Emission Method ......................................................................................................... 17 6.5.2. Radiated Emission Method ............................................................................................................ 18 6.6. SPURIOUS EMISSION ................................................................................................................................ 20 6.6.1. Conducted Emission Method ......................................................................................................... 20 6.6.2. Radiated Emission Method ............................................................................................................ 22 7. TEST SETUP PHOTO .................................................................................................................................. 30 8. EUT CONSTRUCTIONAL DETAILS ........................................................................................................... 30 Report No.: HTT202205265F01 Shenzhen HTT Technology Co.,Ltd. Tel: 0755-23595200 Fax: 0755-23595201 1F, Building B, Huafeng International Robotics Industrial Park, Hangche…

Text truncated - open the document above for the full version.

Shenzhen HTT Technology Co., Ltd. Report No.: HTT202205265 Shenzhen HTT Technology Co.,Ltd. Tel: 0755-23595200 Fax: 0755-23595201 1F, Building B, Huafeng International Robotics Industrial Park,Hangcheng Road, Nanchang Community, Xixiang Street, Bao'an District, Guangdong Province, Shenzhen, China Page 1 of 2 Product Name: White noise device Model No.: BZJ001 Test Setup Photo Radiated Emission Report No.: HTT202205265 Shenzhen HTT Technology Co.,Ltd. Tel: 0755-23595200 Fax: 0755-23595201 1F, Building B, Huafeng International Robotics Industrial Park,Hangcheng Road, Nanchang Community, Xixiang Street, Bao'an District, Guangdong Province, Shenzhen, China Page 2 of 2 Conducted Emission ------End------
