2A72N-P590PETKIT FRESHELEMENT GEMINI

( PETKIT NETWORK TECHNOLOGY (SHANGHAI) CO., LTD) Federal Communications Commission Authorization and Evaluation Division Confidentiality Request regarding application for certification of FCC ID: 2A72N-P590 Pursuant to Sections 0.457 and 0.459 of the Commission’s Rules, we hereby request confidential treatment of information accompanying this application as outlined below: Exhibit Type File Name Block Diagram, Schematics, Operational Description Block Diagram .pdf, Schematics .pdf , Operation Description .pdf The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these materials may be harmful to the applicant and provide unjustified benefits to its competitors. The applicant understands that pursuant to Section 0.457 of the Rules, disclosure of this application and all accompanying documentation will not be made before the date of the Grant for this application. Pursuant to DA04-1705 June 15, 2004 of the Commission’s public notice, we also request temporary confidential treatment of information accompanying this application as outlined below: Short-term confidentiality requested: 180 days Exhibit Type File Name Internal Photos, Test Setup Photos, Manual Internal Photos .pdf, Test Setup Photos .pdf, User Manual .pdf Sincerely, Ting He / Engineer PETKIT NETWORK TECHNOLOGY (SHANGHAI) CO., LTD

(PETKIT NETWORK TECHNOLOGY (SHANGHAI) CO., LTD) Federal Communications Commission Authorization and Evaluation Division 1435 Oakland Mills Road Columbia, MD 21046 Date: September 22, 2022 SUBJECT: FCC Application for FCC ID: 2A72N-P590 To Whom It May Concern: We, the undersigned, hereby authorize Tony Wei at EMTEK(NINGBO) CO., LTD. on our behalf, to apply to the Federal Communications Commission on our equipment. Any and all acts carried out by EMTEK(NINGBO) CO., LTD. on our behalf shall have the same effect as acts of our own. This is to advise that we are in full compliance with the Anti- Drug Abuse Act. We, the applicant, are not subject to a denial of federal benefits pursuant to Section 5301 of the Anti-Drug Act of 1988, 21 USC853a, and no party to the application is subject to a denial of federal benefits pursuant to that section. Regards, Ting He / Engineer PETKIT NETWORK TECHNOLOGY (SHANGHAI) CO., LTD

PETKIT NETWORK TECHNOLOGY (SHANGHAI) CO., LTD Date: 2022-9-21 To: Federal Communications Commission 7435 Oakland Mills Road Columbia, MD FCC ID: 2A72N-P590 To Whom It May Concern: This letter is to ascertain that PETKIT NETWORK TECHNOLOGY (SHANGHAI) CO., LTD EUT : PETKIT FRESHELEMENT GEMINI Model Name : P590 We will apply for FCC SDOC. If you have any question or concerns, pls. contact us. Sincerely, Client’s signature ： Client’s name / title ： Ting He / Engineer Contact information / address: PETKIT NETWORK TECHNOLOGY (SHANGHAI) CO., LTD /Room 4139, Building 2, 588 Zixing Road, Minhang District, Shanghai, China.

External photos: ---The End---

Label Location

Internal photos: Antenna ---The End---

FCC ID: 2A72N-P590 RF EXPOSURE EVALUATION According to FCC 1.1310: The criteria listed in the following table shall be used to evaluate the environment impact of human exposure to radio frequency(RF) Radiation as specified in §1.1307(b) Limits for Maximum Permissible Exposure (MPE) Frequency Range(MHz) Electric Field Strength(V/m) Magnetic Field Strength(A/m) Power Density(mW/cm 2 ) Average Time (A) Limits for Occupational/Control Exposures 300-1500 -- -- F/300 6 1500-100000 -- -- 5 6 (B) Limits for General Population/Uncontrol Exposures 300-1500 -- -- F/1500 6 1500-100000 -- -- 1 30 11.1 Friis transmission formula: Pd= (Pout*G)\ (4*pi*R 2 ) Where Pd= Power density in mW/cm 2 Pout=output power to antenna in mW G= Numeric gain of the antenna relative to isotropic antenna Pi=3.1416 R= distance between observation point and center of the radiator in cm Pd the limit of MPE,1mW/cm 2 . If we know the maximum gain of the antenna and total power input to the antenna, through the calculation, we will know the distance where the MPE limit is reached. mW = 10^( dBm/10) 11.2 Measurement Result Operation Frequency: 2412 MHz-2462 MHz; Antenna gain: 3.7 dBi; R=20cm WIFI Channel Freq. (MHz) modulation Measured power (dBm) Tune-up power (dBm) Max tune-up power (dBm) Antenna Gain Numeric Evaluation result (mW/cm2) Power density Limits (mW/cm2 ) 2412 802.11b 14.89 15±1 16 2.34 0.018566461 1 2437 14.83 15±1 16 2.34 0.018566461 1 2462 15.70 16±1 17 2.34 0.023373790 1 2412 802.11g 12.15 12±1 13 2.34 0.009305273 1 2437 11.76 12±1 13 2.34 0.009305273 1 2462 12.85 13±1 14 2.34 0.011714645 1 2412 802.11n20 12.10 12±1 13 2.34 0.009305273 1 2437 11.63 12±1 13 2.34 0.009305273 1 2462 12.77 13±1 14 2.34 0.011714645 1 2422 802.11n40 9.61 10±1 11 2.34 0.005871230 1 2437 9.93 10±1 11 2.34 0.005871230 1 2452 9.97 10±1 11 2.34 0.005871230 1 *** End of Report ***

OTA TEST REPORT Applicant Espressif Systems Product ESP-ANT A Model ESP-ANT A Report No. YXA1711-1424OTA01R1 Issue Date November 30, 2017 TA Technology (Shanghai) Co., Ltd. tested the above equipment in accordance with the requirements in ANSI/IEEE Std 149-2008. The test results show that the equipment tested is capable of demonstrating compliance with the requirements as documented in this report. Performed by: Jiangpeng Lan Approved by: Kai Xu TA Technology (Shanghai) Co., Ltd. No.145, Jintang Rd, Tangzhen Industry Park, Pudong Shanghai, China TEL: +86‐021‐50791141/2/3 FAX: +86‐021‐50791141/2/3‐8000 OTA Test Report Report No: YXA1711-1424OTA01R1 TA Technology (Shanghai) Co., Ltd. TA-MB-04-008O P age 2 of 12 This report shall not be reproduced except in full, without the written approval of TA Technology (Shanghai) Co., Ltd. TABLE OF CONTENTS 1. General Information ....................................................................................................................... 3 1.1. Notes of the Test Report ................................................................................................... 3 1.2. Test facility ........................................................................................................................ 3 1.3. Testing laboratory .............................................................................................................. 4 1.4. Laboratory Environment .................................................................................................... 4 2. General Description of Equipment under Test ............................................................................... 5 2.1. Applicant Information ......................................................................................................... 5 2.2. Manufacturer Information .................................................................................................. 5 2.3. Information of EUT ............................................................................................................ 5 2.4. Test Date ........................................................................................................................... 5 2.5. Applied Standards ............................................................................................................. 6 3. Test Conditions .............................................................................................................................. 7 3.1. Test Configuration ............................................................................................................. 7 3.2. Test Measurement ............................................................................................................. 7 4. Test Results ................................................................................................................................... 8 4.1. Gain and Efficiency ............................................................................................................ 8 4.2. Voltage Standing Wave Ratio (VSWR) .............................................................................. 9 4.3. Antenna S11 ...................................................................................................................... 9 5. Test Equipment List ..................................................................................................................... 10 APPENDIX A: 2-D Pattern Plots ............................................................................................................. 11 APPENDIX B: The EUT Appearance and Test Configuration .................................................................. 12 B.1 EUT Appearance ................................................................................................................... 12 OTA Test Report Report No: YXA1711-1424OTA01R1 TA Technology (Shanghai) Co., Ltd. TA-MB-04-008O P age 3 of 12 This report shall not be reproduced except in full, without the written approval of TA Technology (Shanghai) Co., Ltd. 1. General Information 1.1. Notes of the Test Report This report shall not be reproduced in full or partial, without the written approval of TA technology (shanghai) co., Ltd.The results documented in this report apply only to the tested sample, under the conditions and modes of operation as described herein .Measurement Uncertainties were not taken into account and are published for informational purposes only. This report is written to support regulatory compliance of the applicable standards stated above. This report must not be used by the client to claim product certification, approval, or endorsement by any government agencies. 1.2. Test facility CNAS (accreditation number:L2264) TA Technology (Shanghai) Co., Ltd. has obtained the accreditation of China National Accreditation Service for Conformity Assessment (CNAS). FCC (Designation number: CN1179, Test Firm Registration Number: 446626) TA Technology (Shanghai) Co., Ltd. has been listed on the US Federal Communications Commission list of test facilities recognized to perform electromagnetic emissions measurements. IC (recognition number is 8510A) TA Technology (Shanghai) Co., Ltd. has been listed by industry Canada to perform electromagnetic emission measurement. A2LA (Certificate Number: 3857.01) TA Technology (Shanghai) Co., Ltd. has been listed by American Association for Laboratory Accreditation to perform electromagnetic emission measurement. OTA Test Report Report No: YXA1711-1424OTA01R1 TA Technology (Shanghai) Co., Ltd. TA-MB-04-008O P age 4 of 12 This report shall not be reproduced except in full, without the written approval of TA Technology (Shanghai) Co., Ltd. 1.3. Testing laboratory Company: TA Technology (Shanghai) Co., Ltd. Address: No.145, Jintang Rd, Tangzhen Industry Park, Pudong City: Shanghai Post code: 201201 Country: P. R. China Contact: Xu Kai Telephone: +86-021-50791141/2/3 Fax: +86-021-50791141/2…

Text truncated - open the document above for the full version.

Report No.ENB2208050031W00601R Page 1 of 59 Ver.1.0 TEST REPORT $二维码$ Product Name : PETKIT FRESHELEMENT GEMINI Model Number : P590 FCC ID : 2A72N-P590 Prepared for : PETKIT Network Technology (Shanghai) Co., Ltd. Address : Room 4139, Building 2, 588 Zixing Road, Minhang District, Shanghai, China. Prepared by : EMTEK (NINGBO) CO., LTD. Address : 1F Building 4, 1177#, Lingyun Road, Ningbo National Hi-Tech Zone, Ningbo, Zhejiang, China. Tel: +86-574-27907998 Fax: +86-574-27721538 Report Number : ENB2208050031W00601R Date(s) of Tests : August 05, 2022 to August 19, 2022 Date of Issue : September 22, 2022 Report No.ENB2208050031W00601R Page 2 of 59 Ver.1.0 TABLE OF CONTENTS 1 TEST RESULT CERTIFICATION ............................................................................................................. 3 2 EUT TECHNICAL DESCRIPTION ........................................................................................................... 4 3 SUMMARY OF TEST RESULT ................................................................................................................ 5 4 TEST METHODOLOGY ........................................................................................................................... 6 4.1 GENERAL DESCRIPTION OF APPLIED STANDARDS .................................................................. 6 4.2 MEASUREMENT EQUIPMENT USED ............................................................................................ 6 4.3 DESCRIPTION OF TEST MODES ................................................................................................... 8 4.4 TEST SOFTWARE ........................................................................................................................... 9 5 FACILITIES AND ACCREDITATIONS ................................................................................................... 10 5.1 FACILITIES .................................................................................................................................... 10 5.2 LABORATORY ACCREDITATIONS AND LISTINGS ..................................................................... 10 6 TEST SYSTEM UNCERTAINTY ............................................................................................................ 11 7 SETUP OF EQUIPMENT UNDER TEST ............................................................................................... 12 7.1 RADIO FREQUENCY TEST SETUP 1 ........................................................................................... 12 7.2 RADIO FREQUENCY TEST SETUP 2 ........................................................................................... 12 7.3 CONDUCTED EMISSION TEST SETUP ....................................................................................... 13 7.4 BLOCK DIAGRAM CONFIGURATION OF TEST SYSTEM ........................................................... 14 7.5 SUPPORT EQUIPMENT ................................................................................................................ 14 8 TEST REQUIREMENTS ......................................................................................................................... 15 8.1 DTS (6DB) BANDWIDTH ............................................................................................................... 15 8.2 MAXIMUM CONDUCTED(AVERAGE) OUTPUT POWER ............................................................ 22 8.3 MAXIMUM POWER SPECTRAL DENSITY ................................................................................... 31 8.4 UNWANTED EMISSIONS IN NON-RESTRICTED FREQUENCY BANDS ................................... 38 8.5 RADIATED SPURIOUS EMISSION ............................................................................................... 43 8.6 CONDUCTED EMISSIONS TEST ................................................................................................. 55 8.7 ANTENNA APPLICATION .............................................................................................................. 58 Report No.ENB2208050031W00601R Page 3 of 59 Ver.1.0 1 TEST RESULT CERTIFICATION Applicant : PETKIT Network Technology (Shanghai) Co., Ltd. Address : Room 4139, Building 2, 588 Zixing Road, Minhang District, Shanghai, China. Manufacturer : Dongguan Zhihang Plastic Technology Co.,Ltd. Address : Building 10, Pushikegu, Pushi 1st Road, Gangtou Village, Qiaotou Town, Dongguan City, Guangdong Province, P.R.C. EUT : PETKIT FRESHELEMENT GEMINI Model Name : P590 Trademark : N/A Measurement Procedure Used: APPLICABLE STANDARDS STANDARD TEST RESULT FCC 47 CFR Part 2, Subpart J FCC 47 CFR Part 15, Subpart C PASS The above equipment was tested by EMTEK (NINGBO) CO., LTD. The test data, data evaluation, test procedures, and equipment configurations shown in this report were made in accordance with the procedures given in ANSI C63.10 (2013) and the energy emitted by the sample EUT tested as described in this report is in compliance with the requirements of FCC Rules Part 2 and Part 15.247 The test results of this report relate only to the tested sample identified in this report. Date of Test : August 05, 2022 to August 19, 2022 Prepared by : June Gao/Engineer Reviewer : Vinay/Supervisor Approved & Authorized Signer : Tony Wei/Manager Report No.ENB2208050031W00601R Page 4 of 59 Ver.1.0 2 EUT TECHNICAL DESCRIPTION Note: for more details, please refer to the User’s manual of the EUT. Characteristics Description Product PETKIT FRESHELEMENT GEMINI Model Number P590 Sample Number 1# IEEE 802.11 WLAN Mode Supported 802.11b 802.11g 802.11n(20MHz channel bandwidth) 802.11n(40MHz channel bandwidth) Data Rate 802.11 b:1,2,5.5,11Mbps; 802.11 g:6,9,12,18,24,36,48,54Mbps; 802.11 n: MCS0~7,up to 150Mbps; Modulation DSSS with DBPSK/DQPSK/CCK for 802.11b; OFDM with BPSK/ CCK /16QAM/64QAM for 802.11g/n20; Operating Frequency Range 2412-2462MHz for 802.11b/g/n(HT20); 2422-2452MHz for 802.11n(HT40); Number of Channels 11 channels for 8…

Text truncated - open the document above for the full version.

Report No.ENB2208050031W00601R Page 43 of 59 Ver.1.0 8.5 RADIATED SPURIOUS EMISSION 8.5.1 Applicable Standard According to FCC Part 15.247(d) and 15.209 and KDB 558074 D01 15.247 Meas Guidance v05r02 8.5.2 Conformance Limit According to FCC Part 15.247(d): radiated emissions which fall in the restricted bands, as defined in §15.205(a), must also comply with the radiated emission limits specified in §15.209(a) (see §15.205(c)). According to FCC Part15.205, Restricted bands MHz MHz MHz GHz 0.090-0.110 16.42-16.423 399.9-410 4.5-5.15 10.495-0.505 16.69475-16.69525 608-614 5.35-5.46 2.1735-2.1905 16.80425-16.80475 960-1240 7.25-7.75 4.125-4.128 25.5-25.67 1300-1427 8.025-8.5 4.17725-4.17775 37.5-38.25 1435-1626.5 9.0-9.2 4.20725-4.20775 73-74.6 1645.5-1646.5 9.3-9.5 6.215-6.218 74.8-75.2 1660-1710 10.6-12.7 6.26775-6.26825 123-138 2200-2300 14.47-14.5 8.291-8.294 149.9-150.05 2310-2390 15.35-16.2 8.362-8.366 156.52475-156.52525 2483.5-2500 17.7-21.4 8.37625-8.38675 156.7-156.9 2690-2900 22.01-23.12 8.41425-8.41475 162.0125-167.17 3260-3267 23.6-24.0 12.29-12.293 167.72-173.2 3332-3339 31.2-31.8 12.51975-12.52025 240-285 3345.8-3358 36.43-36.5 12.57675-12.57725 322-335.4 3600-4400 (2) 13.36-13.41 According to FCC Part15.205,the level of any transmitter spurious emission in Restricted bands shall not exceed the level of the emission specified in the following table Restricted Frequency(MHz) Field Strength ( μV/m) Field Strength (dB μV/m) Measurement Distance 0.009-0.490 2400/F(KHz) 20 log (uV/m) 300 0.490-1.705 24000/F(KHz) 20 log (uV/m) 30 1.705-30 30 29.5 30 30-88 100 40 3 88-216 150 43.5 3 216-960 200 46 3 Above 960 500 54 3 8.5.3 Test Configuration Test according to clause 7.2 radio frequency test setup 2 8.5.4 Test Procedure This test is required for any spurious emission that falls in a Restricted Band, as defined in Section 15.205. It must be performed with the highest gain of each type of antenna proposed for use with the EUT. Use the following spectrum analyzer settings: The EUT was placed on a turn table which is 0.8m above ground plane. Maximum procedure was performed on the highest emissions to ensure EUT compliance. Span = wide enough to fully capture the emission being measured RBW = 1 MHz for f  1 GHz(1GHz to 25GHz), 100 kHz for f < 1 GHz(30MHz to 1GHz), 200Hz for f<150KHz(9KHz to 150KHz), 9KHz for f<30MHz(150KHz to 30KHz) VBW  RBW Sweep = auto Report No.ENB2208050031W00601R Page 44 of 59 Ver.1.0 Detector function = peak Trace = max hold Follow the guidelines in ANSI C63.10-2013 with respect to maximizing the emission by rotating the EUT, measuring the emission while the EUT is situated in three orthogonal planes (if appropriate), adjusting the measurement antenna height and polarization, etc. A pre-amp and a high pass filter are required for this test, in order to provide the measuring system with sufficient sensitivity. Allow the trace to stabilize. The peak reading of the emission, after being corrected by the antenna factor, cable loss, pre-amp gain, etc., is the peak field strength, which must comply with the limit specified in Section 15.35(b). Submit this data. Now set the VBW to 10 Hz, while maintaining all of the other instrument settings. This peak level, once corrected, must comply with the limit specified in Section 15.209. If the dwell time per channel of the hopping signal is less than 100 ms, then the reading obtained with the 10 Hz VBW may be further adjusted by a “duty cycle correction factor”, derived from 20log(dwell time/100 ms), in an effort to demonstrate compliance with the 15.209 limit. Submit this data. Repeat above procedures until all frequency measured was complete. 8.5.5 Test Results Temperature: 22.5 C Relative Humidity: 45 ATM Pressure: 1011 mbar  Spurious Emission below 30MHz(9KHz to 30MHz) Freq. (MHz) Ant.Pol. Emission Level(dBuV/m) Limit 3m(dBuV/m) Over(dB) H/V PK AV PK AV PK AV -- -- -- -- -- -- -- -- Note: the amplitude of spurious emission that is attenuated by more than 20dB below the permissible limit has no need to be reported. Distance extrapolation factor =40log(Specific distance/ test distance)( dB); Limit line=Specific limits(dBuV) + distance extrapolation factor Report No.ENB2208050031W00601R Page 45 of 59 Ver.1.0  Spurious Emission Above 1GHz(1GHz to 25GHz)  All modes 2.4G 802.11b/g/n have been tested, and the worst result 802.11g recorded was report as below: Test mode: 802.11 g Frequency: Channel 1: 2412MHz Freq. (MHz) Ant.Pol. Emission Level(dBuV/m) Limit 3m(dBuV/m) Over(dB) H/V PK AV PK AV PK AV 4825.435 V 54.52 40.94 74.00 54.00 -19.48 -13.06 10812.82 V 56.62 42.97 74.00 54.00 -17.38 -11.03 14151.38 V 60.21 45.84 74.00 54.00 -13.79 -8.16 4825.435 H 53.63 38.72 74.00 54.00 -20.37 -15.28 7097.511 H 51.86 39.16 74.00 54.00 -22.14 -14.84 11091.03 H 56.48 41.67 74.00 54.00 -17.52 -12.33 Test mode: 802.11 g Frequency: Channel 6: 2437MHz Freq. (MHz) Ant.Po l. Emission Level(dBuV/m) Limit 3m(dBuV/m) Over(dB) H/V PK AV PK AV PK AV 4874.687 V 54.23 40.94 74.00 54.00 -19.77 -13.06 11020.80 V 57.73 42.72 74.00 54.00 -16.27 -11.28 13928.09 V 59.78 44.91 74.00 54.00 -14.22 -9.09 4871.804 H 53.45 38.91 74.00 54.00 -20.55 -15.09 11044.66 H 56.62 41.75 74.00 54.00 -17.38 -12.25 14945.44 H 60.93 45.92 74.00 54.00 -13.07 -8.08 Test mode: 802.11 g Frequency: Channel 11: 2462MHz Freq. (MHz) Ant.Pol. Emission Level(dBuV/m) Limit 3m(dBuV/m) Over(dB) H/V PK AV PK AV PK AV 4923.992 V 52.40 37.81 74.00 54.00 -21.60 -16.19 11280.92 V 56.67 42.14 74.00 54.00 -17.33 -11.86 14713.57 V 60.85 45.77 74.00 54.00 -13.15 -8.23 4923.992 H 52.59 39.48 74.00 54.00 -21.41 -14.52 10949.39 H 56.84 41.61 74.00 54.00 -17.16 -12.39 14254.52 H 61.02 45.71 74.00 54.00 -12.98 -8.29 Note: (1) All Readings are Peak Value (VBW=3MHz) and Average Value (VBW=10Hz). (2) Emission Level= Reading Level+Correct Factor. (3) Correct Factor= Ant_F + Cab_L - Preamp (4) The reading of emissions are attenuated more than 20dB below the permissible limits or the field strength is too sma…

Text truncated - open the document above for the full version.
