Text extracted from the exhibit documents filed with the FCC. Open a document above to read the original.
KU-PSJ-603020-SmartController Model:KU-PSJ-603020 Pr oduct size: L60*W30*H20mm Function effect: switch, switch mode, brightness/speed adjustment effect 1.S hort press this key to turn on the light; press for More than 2 sec onds to turn off the light . 2.T here are a total of 12 scene modes, which can be switc hed cyclically through the switch mode function button (1. R ed 2.G reen 3. B lue 4.C yan5. Purple 6. Y ellow 7. Whitestatic color, 8. T hree-color flash 9. Seven-color flash 10.three-color S trobe 11. seven-color S trobe12. white Color flash) 3.Y ou can adjust the brightness/speed by switc hing the up and down buttons, short press to adjust the brightness/speed, and adjustin a cycle; adjust the brightness in the static color mode, adjust the s peed in the dynamic mode Brightness adjust: From 100%-70%-30%Brightness 2 PCS Black M4*28 Screw for install the Controller 双面打印 风琴折 128g铜版纸 FCC Statement This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: •Reorient or relocate the receiving antenna. •Increase the separation between the equipment and receiver. •Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. •Consult the dealer or an experienced radio/TV technician for help. Caution: Any changes or modifications to this device not explicitly approved by manufacturer could void your authority to operate this equipment. This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. RF Exposure Information This equipment complies with FCC radiation exposure limits set forth for an uncontrolled environment. This equipment should be installed and operated with minimum distance 20cm between the radiator and your body.
ShenzhenKingunionLightingCO.,LTD FederalCommunicationsCommission AuthorizationandEvaluationDivision 7435OaklandMillsRoad Columbia,MD21046 USA Date:July24,2024 FCCID:2A73Z-185 Ref.#1:AttestationStatementsPart2.911(d)(5)(i)Filing ShenzhenKingunionLightingCO.,LTDcertifiesthattheequipmentforwhich authorizationissoughtisnot“covered”equipmentprohibitedfromreceivingan equipmentauthorizationpursuanttosection2.903oftheFCCrules. Ref.#2:AttestationStatementsPart2.911(d)(5)(ii)Filing ShenzhenKingunionLightingCO.,LTDcertifiesthat,asofthedateofthefilingof theapplication,theapplicantisnotidentifiedontheCoveredList(asaspecifically namedentityoranyofitssubsidiariesoraffiliates)asanentityproducing“covered” equipment. Applicant:ShenzhenKingunionLightingCO.,LTD Address:SecondFloor,No.1KaixindaTechnologyPark,No49thZhoushiRoad,Langxin Community,ShiyanTown,BaoanDistrict,ShenzhenCity,Guangdong,China ContactPerson:JackChen/ResearchandDevelopmentManager Tel.:13538218145 Email:[email protected] Sincerely, Signature:
Antenna describe 1. Antenna describe: Antenna plate PCB ANTENNA Make name/model name PDT-002 Antenna gain 0dBi Frequency range 2.4GHZ-2.483GHZ Connector type direct Manufacturer Name: DONGGUANG XIAOKE INDUSTRLES.CO.,LTD Manufacture Address: NO. 227, DONGCHENG SECTION, GUANDONG ROAD, DONGCHENG STREET, DONGGUAN CITY,CHINA 2.External view drawing: Picture of antenna Antenna Dimensions L1 2.15 mm L2 1.20 mm L3 1.95 mm W1 0.35 mm W2 0.35 mm D1 1.25 mm D2 1.65 mm D3 0.50 mm 3.Antenna Radiation Pattern
ShenzhenKingunionLightingCO.,LTD Date:2024-7-24 ProductModelNumber:KU-PSJ-603020,KU-PSJ-603520,KU-CSJ-A01 FCCID:2A73Z-185 Towhomitmayconcern, Re:ProductCertificationRepresentativeAuthorizationLetter WeauthorizeQAILaboratoriesLtd.3980NorthFraserWay,BurnabyB.C. CanadaV5J5K5toactonourbehalfonallmattersconcerningtheabove namedequipment. Thisshallincludethefollowing: Testing Approvalapplicationsandprocedures WedeclarethatORGANIZATION.isallowedtoforwardallinformation relatedtotheapprovalprojecttotheappliedcertificationbodyandtothe notificationentitiesandtodiscussanyissuesconcerningtheapproval application.AnyandallactscarriedoutbyORGANIZATION.onourbehalf shallhavethesameeffectasactsofourown. By: ContactListedonFCCWesbite Title:ResearchandDevelopmentManager Email:[email protected] Telephone:13538218145 Onbehalfof:ShenzhenKingunionLightingCO.,LTD
ShenzhenKingunionLightingCO.,LTD OfficeofEngineeringTechnology FederalCommunicationsCommission 7435OaklandMillsRoad Columbia,MD21046 USA Date:July24,2024 Subject:RequestforConfidentiality FCCID:2A73Z-185 ToWhomItMayConcern, PursuanttotheprovisionsoftheCommission’srulesTitle47Sections§0.457and§0.459,we arerequestingtheCommissiontowithholdthefollowingattachment(s)asconfidential documentsfrompublicdisclosureindefinitely. Thesedocumentscontaindetailedsystemandequipmentdescriptionsandareconsideredas proprietaryinformationinoperationoftheequipment.Thepublicdisclosureofthese documentsmightbeharmfultoourcompanyandwouldgivecompetitorsanunfairadvantage inthemarket. SchematicDiagram BlockDiagram PartsList OperationalDescription Tune-upProcedure SoftwareSecurityRequirementsforUNIIdevices Inadditionaltoabovementioneddocuments,inordertocomplywiththemarketingregulations inTitle47CFR§2.803andtheimportationrulesinTitle47CFR§2.1204,whileensuringthat businesssensitiveinformationremainsconfidentialuntiltheactualmarketingofnewly authorizeddevices,werequestShortTermConfidentialityofthefollowingattachment(s); ExternalPhotos TestSetupPhotos InternalPhotos UserManual For45days,pursuanttoPublicNoticeDA04-1705. OR For180dayspursuanttoKDB726920D01. Itisourunderstandingthatallmeasurementtestreports,FCCIDlabelformatand correspondenceduringthecertificationreviewprocesscannotbegrantedasconfidential documentsandthisinformationwillbeavailableforpublicreviewoncethegrantofequipment authorizationisissued. Sincerely, Signature: Name:JackChen Title:ResearchandDevelopmentManager
ShenzhenKingunionLightingCO.,LTD SecondFloor,No.1KaixindaTechnologyPark,No49thZhoushiRoad,Langxin Community,ShiyanTown,BaoanDistrict,ShenzhenCity,Guangdong,China ProductSimilarityDeclaration Date:July24,2024 FCCID:2A73Z-185 ModelNumber:KU-PSJ-603020,KU-PSJ-603520,KU-CSJ-A01 To: FederalCommunicationsCommission AuthorizationandEvaluationDivision 7435OaklandMillsRoad Columbia,MD ToWhomItMayConcern, We,ShenzhenLitimeTechnologyCo.,Ltd,herebydeclarethatourproduct (KU-PSJ-603020)ModelNumber:KU-PSJ-603020,KU-PSJ-603520,KU-CSJ-A01board, Schematic,Hardwareversion,Softwareversion,structureandinternalphotosaresame, onlythemodelnumberisdifferentduetomarketingpurposes. Shouldyouhaveanyquestionsorcommentsregardingthismatter,pleasehavemybest attention. Sincerely, (Signed) Name:JackChen/ResearchandDevelopmentManager Company:ShenzhenKingunionLightingCO.,LTD Address:SecondFloor,No.1KaixindaTechnologyPark,No49thZhoushiRoad,Langxin Community,ShiyanTown,BaoanDistrict,ShenzhenCity,Guangdong,China Phone:13538218145 Fax:13538218145 E-Mail:[email protected]
ReportNo.:BTEK240614001AE Page: 1 of 4 Appendix EUTPhotos forBTEK240614001AE ReportNo.:BTEK240614001AE Page: 2 of 4 EUTConstructionalDetails(EUTPhotos) EUTView1 EUTView2 EUTView3 ReportNo.:BTEK240614001AE Page: 3 of 4 EUTView4 EUTView5 EUTView6 ReportNo.:BTEK240614001AE Page: 4 of 4 EUTView7 EUTView8
ReportNo.:BTEK240614001AE Page: 1 of 1 LABELANDLOCATION
ReportNo.:BTEK240614001AE Page: 1 of 2 Appendix EUTPhotos forBTEK240614001AE ReportNo.:BTEK240614001AE Page: 2 of 2 EUTConstructionalDetails(EUTPhotos) EUTView9 EUTView10 EUTView11 ANT
Report No.: BTEK240614001AE002 Page: 1 of 5 TEST REPORT Application No.: BTEK240614001AE Applicant: Shenzhen Kingunion Lighting CO., LTD Address of Applicant: Second Floor, No. 1 Kaixinda Technology Park, No 49th Zhoushi Road, Langxin Community, Shiyan Town, Baoan District, Shenzhen City, Guangdong, China Manufacturer: Shenzhen Kingunion Lighting CO., LTD Address of Manufacturer: Second Floor, No. 1 Kaixinda Technology Park, No 49th Zhoushi Road, Langxin Community, Shiyan Town, Baoan District, Shenzhen City, Guangdong, China Equipment Under Test (EUT): EUT Name: KU-PSJ-603020 Test Model.: KU-PSJ-603020 Adding Model(s): KU-PSJ-603520, KU-CSJ-A01 Trade Mark: / FCC ID: 2A73Z-185 Standard(s) : 47 CFR Part 2 Subpart J Section 2.1091 447498 D01 General RF Exposure Guidance v06 Date of Receipt: 2024-06-14 Date of Test: 2024-06-14 to 2024-07-09 Date of Issue: 2024-07-10 Test Result: Pass* * In the configuration tested, the EUT complied with the standards specified above. Lion Cai/ Approved & Authorized EMC Laboratory Manager Report No.: BTEK240614001AE002 Page: 2 of 5 Revision Record Version Chapter Date Modifier Remark V0 2024-07-10 Original Authorized for issue by Zora Huang/Project Engineer June Li/Reviewer Remarks: The results shown in this test report refer only to the sample(s) tested, this test report cannot be reproduced, except in full, without prior written permission of the company. The report would be invalid without specific stamp of test institute and the signatures of compiler and approver. Report No.: BTEK240614001AE002 Page: 3 of 5 2 Contents Page 1 Cover Page ................................................................................................................................................ 1 2 Contents .................................................................................................................................................... 3 3 General Information .................................................................................................................................. 4 3.1 Details of E.U.T. ................................................................................................................................. 4 3.2 Description of Support Units .............................................................................................................. 4 3.3 Test Location ...................................................................................................................................... 4 3.4 Deviation from Standards ................................................................................................................... 4 3.5 Abnormalities from Standard Conditions ........................................................................................... 4 4 Test Requirement ........................................................................................................................................... 5 4.1Assessment Result..................................................................................................................................... 5 Report No.: BTEK240614001AE002 Page: 4 of 5 General Information 3.1 Details of E.U.T. Power supply: Adapter:Adapter:AED12J-1201000VWSW0 Input:100-240V~50/60Hz 0.6A Output:DC 12V,Max 1A LED Smart Controller: Input:DC 12V Output:DC 12V Max:3A RGB Frequency Range: 2402MHz to 2480MHz Bluetooth Version: V5.0 Modulation Type: GFSK Number of Channels: 40 Channel Spacing: 2MHz Antenna Type: PCB Antenna Antenna Gain: 0 dBi Sample No.: BTEK240614001AE-01 Remark: The information in this section is provided by the applicant or manufacturer, BANTEK is not liable to the accuracy, suitability, reliability or/and integrity of the information. Model No.: KU-PSJ-603020, KU-PSJ-603520, KU-CSJ-A01 Only the model KU-PSJ-603020I was tested. According to the declaration from the applicant, the electrical circuit design, layout, components used, internal wiring and functions of other models are identical for the above models, with only difference on Model No. 3.2 Description of Support Units Description Manufacturer Model No. Serial No. / / / / 3.3 Test Location All tests were performed at: Shenzhen BANTEK Testing Co., Ltd., A5&A6, Building B1&B2, No.45 Gangtou Road, Bogang Community, Shajing Street, Bao'an District, Shenzhen, Guangdong, China 518103 Tel:0755-2334 4200 Fax: 0755-2334 4200 FCC Registration Number: 264293 Designation Number: CN1356 No tests were sub-contracted. 3.4 Deviation from Standards None 3.5 Abnormalities from Standard Conditions None Report No.: BTEK240614001AE002 Page: 5 of 5 4 Test Requirement According to §1.1307(b)(1) and KDB 447498 D01 General RF Exposure Guidance v06, system operating under the provisions of this section shall be operating in a manner that the public is not exposed to radio frequency energy level in excess limit for maximum permissible exposure. Limits for Maximum Permissible Exposure (MPE) Frequency range (MHz) Electric field strength (V/m) Magnetic field strength (A/m) Power density (mW/cm 2 ) Averaging time (minutes) (A) Limits for Occupational/Controlled Exposures 0.3–3.0 614 1.63 *(100) 6 3.0–30 1842/f 4.89/f *(900/f 2 ) 6 30–300 61.4 0.163 1.0 6 300–1500 f/300 6 1500–100,000 5 6 (B) Limits for General Population/Uncontrolled Exposure 0.3–1.34 614 1.63 *(100) 30 1.34–30 824/f 2.19/f *(180/f 2 ) 30 30–300 27.5 0.073 0.2 30 300–1500 f/1500 30 1500–100,000 1.0 30 f = frequency in MHz Friis transmission formula: Pd = (Pout*G)/(4*pi*r 2 ) Where Pd = power density in mW/cm 2 , Pout = output power to antenna in mW; G = gain of antenna in linear scale, Pi = 3.1416; R = distance between observation point and center of the radiator in cm Pd id the limit of MPE, 1 mW/cm 2 . If we know the maximum gain of the antenna and the total power input to the antenna, through the calculation, we will know the distance r where the MPE limit is reached. 4.1Assessment Result Passed Not Applicable Frequency (MHz) Type Conducted Pow…
Text truncated - open the document above for the full version.
ReportNo.:BTEK240614001AE001 Page:1of17 Appendix BLETestData forBTEK240614001AE ReportNo.:BTEK240614001AE001 Page:2of17 TableofContents 1.-6dBBandwidth............................................................................................................................................................3 2.99%OccupiedBandwidth............................................................................................................................................5 3.DutyCycle.....................................................................................................................................................................7 4.PeakOutputPower.......................................................................................................................................................9 5.PowerSpectralDensity...............................................................................................................................................11 6.Bandedge....................................................................................................................................................................13 7.SpuriousEmission.......................................................................................................................................................15 ReportNo.:BTEK240614001AE001 Page:3of17 1.-6dBBandwidth ConditionAntennaRateFrequency(MHz)-6dBBW(kHz)limit(kHz)Result NVNTANT11Mbps2402.00918.52500Pass NVNTANT11Mbps2440.00933.26500Pass NVNTANT11Mbps2480.00991.50500Pass -6dB_Bandwidth_NVNT_ANT1_1Mbps_2402 -6dB_Bandwidth_NVNT_ANT1_1Mbps_2440 -6dB_Bandwidth_NVNT_ANT1_1Mbps_2480 ReportNo.:BTEK240614001AE001 Page:4of17 ReportNo.:BTEK240614001AE001 Page:5of17 2.99%OccupiedBandwidth ConditionAntennaRateFrequency(MHz)99%%BW(MHz) NVNTANT11Mbps2402.001.522 NVNTANT11Mbps2440.001.573 NVNTANT11Mbps2480.001.642 99%_Occupied_Bandwidth_NVNT_ANT1_1Mbps_2402 99%_Occupied_Bandwidth_NVNT_ANT1_1Mbps_2440 99%_Occupied_Bandwidth_NVNT_ANT1_1Mbps_2480 ReportNo.:BTEK240614001AE001 Page:6of17 ReportNo.:BTEK240614001AE001 Page:7of17 3.DutyCycle ConditionAntennaRateFrequency(MHz)Dutycycle(%)Duty_factor NVNTANT11Mbps2402.0012.908.89 NVNTANT11Mbps2440.0012.908.89 NVNTANT11Mbps2480.0015.638.06 Duty_Cycle_NVNT_ANT1_1Mbps_2402 Duty_Cycle_NVNT_ANT1_1Mbps_2440 Duty_Cycle_NVNT_ANT1_1Mbps_2480 ReportNo.:BTEK240614001AE001 Page:8of17 ReportNo.:BTEK240614001AE001 Page:9of17 4.PeakOutputPower ConditionAntennaRate Frequency (MHz) Max.Conducted Power(dBm) Max.Conducted Power(mW) Limit(mW)Result NVNTANT11Mbps2402.00-3.610.441000Pass NVNTANT11Mbps2440.00-3.250.471000Pass NVNTANT11Mbps2480.00-3.520.451000Pass Peak_Output_Power_NVNT_ANT1_1Mbps_2402 Peak_Output_Power_NVNT_ANT1_1Mbps_2440 Peak_Output_Power_NVNT_ANT1_1Mbps_2480 ReportNo.:BTEK240614001AE001 Page:10of17 ReportNo.:BTEK240614001AE001 Page:11of17 5.PowerSpectralDensity ConditionAntennaRateFrequency(MHz)PowerSpectralDensity(dBm)Limit(dBm/3kHz)Result NVNTANT11Mbps2402.00-24.658Pass NVNTANT11Mbps2440.00-24.178Pass NVNTANT11Mbps2480.00-23.578Pass Power_Spectral_Density_NVNT_ANT1_1Mbps_2402 Power_Spectral_Density_NVNT_ANT1_1Mbps_2440 Power_Spectral_Density_NVNT_ANT1_1Mbps_2480 ReportNo.:BTEK240614001AE001 Page:12of17 ReportNo.:BTEK240614001AE001 Page:13of17 6.Bandedge ConditionAntennaRate TX_Frequency (MHz) Max.MarkFrequency (MHz) Spurious level(dBm) limit(dBm)Result NVNTANT11Mbps2402.002399.965-35.062-24.512Pass NVNTANT11Mbps2480.002487.675-56.410-24.373Pass 1_Reference_Level_NVNT_ANT1_1Mbps_2402 2_Bandedge_NVNT_ANT1_1Mbps_2402 1_Reference_Level_NVNT_ANT1_1Mbps_2480 ReportNo.:BTEK240614001AE001 Page:14of17 2_Bandedge_NVNT_ANT1_1Mbps_2480 ReportNo.:BTEK240614001AE001 Page:15of17 7.SpuriousEmission ConditionAntennaRateTX_Frequency(MHz)SpuriousMAX.Value(dBm)LimitResult NVNTANT11Mbps2402.00-43.785-24.512Pass NVNTANT11Mbps2440.00-43.480-24.072Pass NVNTANT11Mbps2480.00-43.351-24.373Pass 1_Reference_Level_NVNT_ANT1_1Mbps_2402 2_Spurious_Emission_NVNT_ANT1_1Mbps_2402 1_Reference_Level_NVNT_ANT1_1Mbps_2440 ReportNo.:BTEK240614001AE001 Page:16of17 2_Spurious_Emission_NVNT_ANT1_1Mbps_2440 1_Reference_Level_NVNT_ANT1_1Mbps_2480 ReportNo.:BTEK240614001AE001 Page:17of17 2_Spurious_Emission_NVNT_ANT1_1Mbps_2480
ReportNo.:BTEK240614001AE001 Page: 1 of 27 TESTREPORT ApplicationNo.:BTEK240614001AE Applicant:ShenzhenKingunionLightingCO.,LTD AddressofApplicant:SecondFloor,No.1KaixindaTechnologyPark,No49thZhoushiRoad, LangxinCommunity,ShiyanTown,BaoanDistrict,ShenzhenCity, Guangdong,China Manufacturer:ShenzhenKingunionLightingCO.,LTD AddressofManufacturer:SecondFloor,No.1KaixindaTechnologyPark,No49thZhoushiRoad, LangxinCommunity,ShiyanTown,BaoanDistrict,ShenzhenCity, Guangdong,China EquipmentUnderTest(EUT): EUTName:KU-PSJ-603020 TestModel.:KU-PSJ-603020 AddingModel(s):KU-PSJ-603520,KU-CSJ-A01 TradeMark:/ FCCID: 2A73Z-185 Standard(s): 47CFRPart15,SubpartC15.247 KDB558074D0115.247MeasGuidancev05r02 ANSIC63.10:2013 DateofReceipt: 2024-06-14 DateofTest: 2024-06-14to2024-07-09 DateofIssue: 2024-07-10 TestResult: Pass* *Intheconfigurationtested,theEUTcompliedwiththestandardsspecifiedabove. LionCai/Approved&Authorized EMCLaboratoryManager ReportNo.:BTEK240614001AE001 Page: 2 of 27 RevisionRecord VersionChapterDateModifierRemark V02024-07-10Original Authorizedforissueby: ZoraHuang/ProjectEngineer JuneLi/Reviewer Remarks: Theresultsshowninthistestreportreferonlytothesample(s)tested,thistestreportcannotbereproduced,exceptin full,withoutpriorwrittenpermissionofthecompany.Thereportwouldbeinvalidwithoutspecificstampoftestinstitute andthesignaturesofcompilerandapprover. ReportNo.:BTEK240614001AE001 Page: 3 of 27 2TestSummary RadioSpectrumTechnicalRequirement StandardItemMethodRequirementResult Antenna Requirement 47CFRPart15,SubpartC 15.247 N/A 47CFRPart15,Subpart C15.203&15.247(b)(4) Pass RadioSpectrumMatterPart ItemStandardMethodRequirementResult 47CFRPart15, SubpartC15.247 ConductedEmissionsatAC PowerLine(150kHz-30MHz) ANSIC63.10(2013) Section6.2 47CFRPart15,Subpart C15.207 Pass ConductedPeakOutputPower ANSIC63.10(2013) Section11.9.1.3 47CFRPart15,Subpart C15.247(b)(3) Pass Minimum6dBBandwidth ANSIC63.10(2013) Section11.8.1 47CFRPart15,Subpart C15.247a(2) Pass PowerSpectrumDensity ANSIC63.10(2013) Section11.10.2 47CFRPart15,Subpart C15.247(e) Pass ConductedBandEdges Measurement ANSIC63.10(2013) Section11.13.3.2 47CFRPart15,Subpart C15.247(d) Pass ConductedSpuriousEmissions ANSIC63.10(2013) Section11.11 47CFRPart15,Subpart C15.247(d) Pass RadiatedEmissionswhichfallin therestrictedbands ANSIC63.10(2013) Section6.10.5 47CFRPart15,Subpart C15.205&15.209 Pass RadiatedSpuriousEmissions ANSIC63.10(2013) Section6.4,6.5,6.6 47CFRPart15,Subpart C15.205&15.209 Pass Note: E.U.T./EUTmeansEquipmentUnderTest. Passmeansthetestresultpassedtheteststandardrequirement,pleasefindthedetaileddecisionrule inthereportrelativesection. ReportNo.:BTEK240614001AE001 Page: 4 of 27 3Contents Page 1CoverPage......................................................................................................................................................................1 2TestSummary.................................................................................................................................................3 3Contents..........................................................................................................................................................4 4GeneralInformation........................................................................................................................................5 4.1DetailsofE.U.T.......................................................................................................................................................5 4.2EUTTestModeandTestCondition.....................................................................................................................5 4.3MeasurementUncertainty......................................................................................................................................5 4.4TestLocation...........................................................................................................................................................6 4.5DeviationfromStandards......................................................................................................................................6 4.6AbnormalitiesfromStandardConditions.............................................................................................................6 5EquipmentList................................................................................................................................................7 6RadioSpectrumTechnicalRequirement.....................................................................................................9 6.1AntennaRequirement.............................................................................................................................................9 6.1.1TestRequirement:..........................................................................................................................................9 6.1.2Conclusion.......................................................................................................................................................9 7RadioSpectrumMatterTestResults..........................................................................................................10 7.1ConductedEmissionsatACPowerLine(150kHz-30MHz)...........................................................................10 7.1.1TestSetupDiagram......................................................................................................................................10 7.1.2MeasurementProcedureandData...........................................................................................................10 7.2ConductedPeakOutputPower..........................................................................................................................13 7.2.1TestSetupDiagram......................................................................................................................................13 7.2.2MeasurementProced…
Text truncated - open the document above for the full version.
ReportNo.:BTEK240614001AE Page: 1 of 2 Appendix SetupPhotos ForBTEK240614001AE ReportNo.:BTEK240614001AE Page:2of2 Radiated Spurious Emissions (Below1GHz) Radiated Spurious Emissions (Above1GHz) Conducted Spurious Emissions
| # | Rule Parts | Frequency Range | Power Output |
|---|---|---|---|
| 1 | 15C | 2.40 GHz - 2.48 GHz | 470.00 µW |
LED STRIP
Equipment Class
DTS - Digital Transmission System
