便携式打印机 Mini Pocket Printer 型号:A2 Model:A2 cable Trouble shooting guide FCC Statement This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1)This device may not cause harmful interference. (2)This device must accept any interference received, including interference that may cause undesired operation. 2.Changes or modifications not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment. Note:This equipment has been tested and found to comply with the limits for a class B digital device,pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates uses and can radiate radio frequence energy and,if not installed and used in accordance with the instructions,may cause harmful interference to radio communications.However,there is no guarantee that interference will not occur in a particular installation.if this equipmemt does cause harmful interference to radio or television reception,which can be determined by turning the equipment off and on,the user is encouraged to try to correct the interference by one or more of the following measures: • Reorient or relocate the receiving antenna. •Increase the separation between the equipment and receiver. • Connect the equipment into an autlet on a circuit different from that to which the receiver is connected. • Consult the dealer or an experienced radio/TV technician for help. The device has been evaluated to meet general RF exposure requirement. The device can be used in portable exposure condition without restriction.

Xiamen Lujiang Technology Co., Ltd. 2024-08-14 Eurofins Electrical and Electronic Testing NA, Inc. 914 West Patapsco Avenue Baltimore, MD 21230 RE: Attestation Statements Part 2.911(d)(5)(i) request for (FCC ID: 2A74AA2 ) [Xiamen Lujiang Technology Co., Ltd. ] (“the applicant”) certifies that the equipment for which authorization is sought is not “covered” equipment prohibited from receiving an equipment authorization pursuant to section 2.903 of the FCC rules. Sincerely, Jiaan Cai GM Xiamen Lujiang Technology Co., Ltd. Room 601-2, No.63-1, Wanghai Road, Software Park Phase II, Torch Hi-Tech Zone, Xiamen, China Xiamen Lujiang Technology Co., Ltd. 2024-08-14 Eurofins Electrical and Electronic Testing NA, Inc. 914 West Patapsco Avenue Baltimore, MD 21230 RE: Attestation Statements Part 2.911(d)(5)(ii) request for(FCC ID: 2A74AA2 ) [Xiamen Lujiang Technology Co., Ltd.] (“the applicant”) certifies that, as of the date of the filing of the application, the applicant is not identified on the Covered List as an entity producing “covered” equipment. S incerely, Jiaan Cai GM Xiamen Lujiang Technology Co., Ltd. Room 601-2, No.63-1, Wanghai Road, Software Park Phase II, Torch Hi-Tech Zone, Xiamen, China

Attestation Statements (2023-11-17) TO: Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046, USA RE: Attestation Statements Part 2.911(d)(7) request for (GC: 2A74A) (Xiamen Lujiang Technology Co., Ltd), the undersigned, hereby authorize (Wilson Tech Service LLC) to act as our designated U.S. agent for service of process,( Xiamen Lujiang Technology Co., Ltd) accepts to maintain an agent for no less than one year after the grantee has terminated all marketing and importation or the conclusion of any Commission-related proceeding involving the equipment. (Wilson Tech Service LLC) accepts the responsibility to act as designated U.S. agent for service of process. Applicant Information： Company name: Xiamen Lujiang Technology Co., Ltd. Contact Name: Jiaan Cai Grantee FRN: 0032700387 Address: Room 601-2, No.63-1, Wanghai Road, Software Park Phase II, Torch Hi-Tech Zone, Xiamen, China Telephone No: 0592-5713026 Email: [email protected] Signature [Jiaan Cai] U.S. Agent Information: Company Name: Wilson Tech Service LLC Address: 1312 17th Street Suite 692, Denver, CO, 80202, US FRN: 0033402033 Contact Name: Wilson Cheung Telephone No: +1-716-965-5112 Email: [email protected] Signature [Wilson Cheung]

External

40*30mm

Internal ANT

RF EXPOSURE EVALUATION EUT Specification EUT Mini Pocket Printer Model Number A2 FCC ID 2A74AA2 Antenna gain (Max) -0.93dBi Operation Frequency 2402-2480MHz Rating 5V1A Classification Per Stipulated Test Standard §15.247(i), §2.1093 Modulation BLE: GFSK BR: GFSK Max. output power BR: -0.1dBm(0.00098W) BLE: 0.18dBm(0.00104W) Test Requirement: According to §15.247(i) and §1.1307(b)(1), systems operating under the provisions of this section shall be operated in a manner that ensures that the public is not exposed to radio frequency energy level in excess of the Commission’s guidelines. Routine SAR evaluation refers to that specifically required by §2.1093, using measurements or computer simulation. When routine SAR evaluation is not required, portable transmitters with output power greater than the applicable low threshold require SAR evaluation to quality for TCB approval. One antenna is available for the EUT. The minimum separation distance is 5mm. BR: Transmit Frequency (MHz) Mode Measur ed Power (dBm) Tune up Power (dBm) Max tune up power(dBm) Calculation Result 1-g SAR 2402 GFSK -0.1 0±1 1 0.390 3 2441 GFSK -0.35 0±1 1 0.393 3 2480 GFSK -0.81 -1±1 0 0.315 3 BLE: According to KDB 447498, no stand-alone required for BT antenna, and no simultaneous SAR measurement is required. Signature: Shawn Wen Date: 2024-08-13 Transmit Frequency (MHz) Mode Measured Power (dBm) Tune up Power (dBm) Max tune up power(dBm) Calculation Result 1-g SAR 2402 GFSK（1M） -0.18 0±1 1 0.390 3 2440 GFSK（1M） -0.37 0±1 1 0.393 3 2480 GFSK（1M） -0.85 -1±1 0 0.315 3

BluetoothAntenna specification&Testreport YichipMicroelectronics ©2014 TestCcompanyTATechnology(Shanghai)Co.,Ltd. TestAddress Building1,No.400,FangchunRoad,China(Shanghai)PilotFreeTradeZone TestDate2020/7/24 TestInstrument Keysight E5071B antennadesignspecification Antennadimensionsasblowpictureshow:thematerialisFR4andthethicknessis 1.6mmofPCB. GianandEfficiency Frequency (MHz) Efficiency(%)Gain(dBi) 240214.86-0.93 242012.54-1.17 24409.92-2.03 24607.46-2.47 24806.11-2.98 3Dand1DRadiationPatterns Total P o w e r ( d B m ) -25 0 -20 -15 -10 -5 X Y Z Azimuth = 0.0 Elevation = 0.0 Roll = 0.0 2440MTRP1 Cut1 P o w e r ( d B m ) Angle (? Scale: 2/div Min: -16 Max: -2 0 180 30 210 60 240 90270 120 300 150 330 Cut2 P o w e r ( d B m ) Angle (? Scale: 2/div Min: -22 Max: 0 0 180 30 210 60 240 90270 120 300 150 330 Cut3 P o w e r ( d B m ) Angle (? Scale: 2/div Min: -14 Max: -2 0 180 30 210 60 240 90270 120 300 150 330

1 / 28 Appendix A Maximum Conducted Output Power Condition Mode Frequency (MHz) Antenna Conducted Power (dBm) Duty Factor (dB) Total Power (dBm) Limit (dBm) Verdict NVNT 1- DH5 2402 Ant1 -0.1 0 -0.1 21 Pass NVNT 1- DH5 2441 Ant1 -0.35 0 -0.35 21 Pass NVNT 1- DH5 2480 Ant1 -0.81 0 -0.81 21 Pass 2 / 28 Test Graphs Power NVNT 1-DH5 2402MHz Ant1 Power NVNT 1-DH5 2441MHz Ant1 3 / 28 Power NVNT 1-DH5 2480MHz Ant1 4 / 28 -20dB Bandwidth Condition Mode Frequency (MHz) Antenna -20 dB Bandwidth (MHz) Limit -20 dB Bandwidth (MHz) Verdict NVNT 1- DH5 2402 Ant1 1.25 N/A N/A NVNT 1- DH5 2441 Ant1 1.24 N/A N/A NVNT 1- DH5 2480 Ant1 1.25 N/A N/A 5 / 28 Test Graphs -20dB Bandwidth NVNT 1-DH5 2402MHz Ant1 -20dB Bandwidth NVNT 1-DH5 2441MHz Ant1 6 / 28 -20dB Bandwidth NVNT 1-DH5 2480MHz Ant1 7 / 28 Occupied Channel Bandwidth Condition Mode Frequency (MHz) Antenna 99% OBW (MHz) NVNT 1- DH5 2402 Ant1 1.114 NVNT 1- DH5 2441 Ant1 1.116 NVNT 1- DH5 2480 Ant1 1.121 8 / 28 Test Graphs OBW NVNT 1-DH5 2402MHz Ant1 OBW NVNT 1-DH5 2441MHz Ant1 9 / 28 OBW NVNT 1-DH5 2480MHz Ant1 10 / 28 Carrier Frequencies Separation Condition Mode Antenna Hopping Freq1 (MHz) Hopping Freq2 (MHz) HFS (MHz) Limit (MHz) Verdict NVNT 1- DH5 Ant1 2401.758 2402.76 1.002 0.833 Pass NVNT 1- DH5 Ant1 2440.758 2441.758 1 0.827 Pass NVNT 1- DH5 Ant1 2478.758 2479.76 1.002 0.833 Pass 11 / 28 Test Graphs CFS NVNT 1-DH5 2402MHz Ant1 CFS NVNT 1-DH5 2441MHz Ant1 12 / 28 CFS NVNT 1-DH5 2480MHz Ant1 13 / 28 Number of Hopping Channel Condition Mode Antenna Hopping Number Limit Verdict NVNT 1- DH5 Ant1 79 15 Pass 14 / 28 Test Graphs Hopping No. NVNT 1-DH5 2402MHz Ant1 15 / 28 Dwell Time Condition Mode Frequency (MHz) Antenna Pulse Time (ms) Total Dwell Time (ms) Burst Count Period Time (ms) Limit (ms) Verdict NVNT 1- DH5 2402 Ant1 2.831 382.185 135 31600 400 Pass NVNT 1- DH5 2441 Ant1 2.438 329.13 135 31600 400 Pass NVNT 1- DH5 2480 Ant1 2.442 329.67 135 31600 400 Pass 16 / 28 Test Graphs Dwell NVNT 1-DH5 2402MHz Ant1 One Burst Dwell NVNT 1-DH5 2402MHz Ant1 Accumulated 17 / 28 Dwell NVNT 1-DH5 2441MHz Ant1 One Burst Dwell NVNT 1-DH5 2441MHz Ant1 Accumulated 18 / 28 Dwell NVNT 1-DH5 2480MHz Ant1 One Burst Dwell NVNT 1-DH5 2480MHz Ant1 Accumulated 19 / 28 Band Edge Condition Mode Frequency (MHz) Antenna Hopping Mode Max Value (dBc) Limit (dBc) Verdict NVNT 1- DH5 2402 Ant1 No-Hopping -38.42 -20 Pass NVNT 1- DH5 2480 Ant1 No-Hopping -45.01 -20 Pass 20 / 28 Test Graphs Band Edge NVNT 1-DH5 2402MHz Ant1 No-Hopping Ref Band Edge NVNT 1-DH5 2402MHz Ant1 No-Hopping Emission 21 / 28 Band Edge NVNT 1-DH5 2480MHz Ant1 No-Hopping Ref Band Edge NVNT 1-DH5 2480MHz Ant1 No-Hopping Emission 22 / 28 Band Edge(Hopping) Condition Mode Frequency (MHz) Antenna Hopping Mode Max Value (dBc) Limit (dBc) Verdict NVNT 1- DH5 2402 Ant1 Hopping -43.21 -20 Pass NVNT 1- DH5 2480 Ant1 Hopping -51.73 -20 Pass 23 / 28 Test Graphs Band Edge(Hopping) NVNT 1-DH5 2402MHz Ant1 Hopping Ref Band Edge(Hopping) NVNT 1-DH5 2402MHz Ant1 Hopping Emission 24 / 28 Band Edge(Hopping) NVNT 1-DH5 2480MHz Ant1 Hopping Ref Band Edge(Hopping) NVNT 1-DH5 2480MHz Ant1 Hopping Emission 25 / 28 Conducted RF Spurious Emission Condition Mode Frequency (MHz) Antenna Max Value (dBc) Limit (dBc) Verdict NVNT 1- DH5 2402 Ant1 -36.21 -20 Pass NVNT 1- DH5 2441 Ant1 -37.74 -20 Pass NVNT 1- DH5 2480 Ant1 -38.37 -20 Pass 26 / 28 Test Graphs Tx. Spurious NVNT 1-DH5 2402MHz Ant1 Ref Tx. Spurious NVNT 1-DH5 2402MHz Ant1 Emission 27 / 28 Tx. Spurious NVNT 1-DH5 2441MHz Ant1 Ref Tx. Spurious NVNT 1-DH5 2441MHz Ant1 Emission 28 / 28 Tx. Spurious NVNT 1-DH5 2480MHz Ant1 Ref Tx. Spurious NVNT 1-DH5 2480MHz Ant1 Emission

TRF No.: 04-E001-0B TRF Originator: GTG TRF Date: 2023-12-13 Web: www.gtggroup.com E-mail: [email protected] Tel.: 86-400 755 8988 CFR 47 FCC PART 15 SUBPART C TEST REPORT For Mini Pocket Printer MODEL NUMBER: A2, PPA2, PPA2H, A2H, PPA1, A1, PPA1H, A1H REPORT NUMBER: E04A24070733F00401 ISSUE DATE: August 07, 2024 FCC ID: 2A74AA2 Prepared for Xiamen Lujiang Technology Co., Ltd. Room 601-2, No.63-1, Wanghai Road, Software Park Phase II, Torch Hi-Tech Zone, Xiamen Prepared by Guangdong Global Testing Technology Co., Ltd. Room 101-105, 203-210, Building 1, No.2, Keji 8 Road, Songshan Lake Park, Dongguan city, Guangdong, People’s Republic of China, 523808 This report shall not be reproduced, except in full, without the written approval of Guangdong Global Testing Technology Co., Ltd. REPORT NO.: E04A24070733F00401 Page 2 of 53 TRF No.: 04-E001-0B Global Testing , Great Quality. Revision History Rev. Issue Date Revisions Revised By V0 August 07, 2024 Initial Issue / REPORT NO.: E04A24070733F00401 Page 3 of 53 TRF No.: 04-E001-0B Global Testing , Great Quality. Summary of Test Results Test Item Clause Limit/Requirement Result Antenna Requirement N/A FCC Part 15.203/15.247 (c) Pass AC Power Line Conducted Emission ANSI C63.10-2013 Clause 6.2 FCC Part 15.207 Pass Conducted Output Power ANSI C63.10-2013 Clause 7.8.5 FCC Part 15.247 (b)(1) Pass 20 dB Bandwidth ANSI C63.10-2013 Clause 6.9.2 FCC Part 15.247 (a)(1) Pass Carrier Hopping Channel Separation ANSI C63.10-2013 Clause 7.8.2 FCC Part 15.247 (a)(1) Pass Number of Hopping Frequency ANSI C63.10-2013 Clause 7.8.3 FCC Part 15.247 (b)(1) Pass Time of Occupancy (Dwell Time) ANSI C63.10-2013 Clause 7.8.4 FCC Part 15.247 (a)(1) Pass Conducted Bandedge and Spurious Emission ANSI C63.10-2013 Clause 6.10.4 & Clause 7.8.8 FCC Part 15.247(d) Pass Radiated Band edge and Spurious Emission ANSI C63.10-2013 Clause 6.3 & 6.5 & 6.6 FCC Part 15.205/15.209 Pass Duty Cycle ANSI C63.10-2013, Clause 11.6 None; for reporting purposes only. Pass *This test report is only published to and used by the applicant, and it is not for evidence purpose in China. *The measurement result for the sample received is <Pass> according to <CFR 47 FCC PART 15 SUBPART C> when <Accuracy Method> decision rule is applied. REPORT NO.: E04A24070733F00401 Page 4 of 53 TRF No.: 04-E001-0B Global Testing , Great Quality. CONTENTS 1. ATTESTATION OF TEST RESULTS ..................................................................................... 5 2. TEST METHODOLOGY ......................................................................................................... 6 3. FACILITIES AND ACCREDITATION ..................................................................................... 6 4. CALIBRATION AND UNCERTAINTY ................................................................................... 7 4.1. MEASURING INSTRUMENT CALIBRATION ........................................................... 7 4.2. MEASUREMENT UNCERTAINTY ............................................................................ 7 5. EQUIPMENT UNDER TEST .................................................................................................. 8 5.1. DESCRIPTION OF EUT ........................................................................................... 8 5.2. CHANNEL LIST ........................................................................................................ 8 5.3. MAXIMUM CONDUCTED OUTPUT POWER ........................................................... 9 5.4. TEST CHANNEL CONFIGURATION ........................................................................ 9 5.5. THE WORSE CASE POWER SETTING PARAMETER ............................................ 9 5.6. DESCRIPTION OF AVAILABLE ANTENNAS ......................................................... 10 5.7. SUPPORT UNITS FOR SYSTEM TEST ................................................................. 10 5.8. SETUP DIAGRAM .................................................................................................. 11 6. MEASURING EQUIPMENT AND SOFTWARE USED......................................................... 12 7. ANTENNA PORT TEST RESULTS ..................................................................................... 14 7.1. Conducted Output Power ........................................................................................ 14 7.2. 20 dB Bandwidth and 99% Occupied Bandwidth..................................................... 15 7.3. Carrier Hopping Channel Separation ...................................................................... 16 7.4. Number of Hopping Frequency ............................................................................... 18 7.5. Time of Occupancy (Dwell Time) ............................................................................ 20 7.6. Conducted Bandedge and Spurious Emission ........................................................ 22 7.7. Duty Cycle .............................................................................................................. 24 8. RADIATED TEST RESULTS ............................................................................................... 25 9. ANTENNA REQUIREMENT ................................................................................................ 43 10. AC POWER LINE CONDUCTED EMISSION ......................................................... 44 11. TEST DATA ............................................................................................................ 46 APPENDIX: PHOTOGRAPHS OF TEST CONFIGURATION ..................................................... 47 APPENDIX: PHOTOGRAPHS OF THE EUT .............................................................................. 49 REPORT NO.: E04A24070733F00401 Page 5 of 53 TRF No.: 04-E001-0B Global Testing , Great Quality. 1. ATTESTATION OF TEST RESULTS Applicant Information Company Name: Xiamen Lujiang Technology Co., Ltd. Address: Room 601-2, No.63-1, Wanghai Road…
