2A758-A30All-in-One Pet Health & Location Collar

Shenzhen Beitutu Technology Co.,Ltd.

Click to zoom

Application Details

Equipment Class: PCB - PCS Licensed Transmitter
Date of Grant: May 18, 2026
Application Purpose: Original Equipment
Equipment Note: All-in-One Pet Health & Location Collar
Frequency Range: 699.00000000 - 716.00000000
Company: Shenzhen Beitutu Technology Co.,Ltd.
Country: China

Documents & Files

Select a file to view

Document Text

Text extracted from the exhibit documents filed with the FCC. Open a document above to read the original.

Users Manual

1 All-in-OnePetHealth &LocationCollar UserManual 2 DeviceandAPPUsageProcess 1.DownloadtheAPP ScantheQRcodeonthepackagingboxorthis cardtodownloadtheofficialAPPfromtheApple AppStoreorGooglePlayStore,dependingon yourmobilesystem. 2.AccessHelpMaterials ScantheQRcodeonthepackagingboxorthis cardtovisittheHelpCenter,whereyoucanview theelectronicmanual,instructionalvideos,and othersupportcontent. 3.PowerOn Brieflypressthepowerbuttononthedeviceto turniton. 4.DeviceBindingandSubscription AfteropeningtheAPP,completethefollowing stepsinorder: ①Registeranaccount→②Login→③Bindthe device(scantheQRcodeonthedevicebody) ④Topupthesubscriptionfee→⑤Waitabout2 minutes,thenrestartthedevice→⑥Subscription successful 3 5.PowerOff Pressandholdthedevice'spowerbuttontoturn itoff. 6.ChargingStatusIndicator •Charging:Redlightflashesslowly. •FullyCharged:Redlightstayssteadilylit. Important:Checkthetightnessofthecollarby insertingonefingerbetweentheendofacontact pointandyourdog'sskin.Thefitshouldbesnug butnotconstricting. Important:Avoidleavingthecollaronyourdog formorethan12hoursaday,andneverattacha leashorIDtagtoit-useaseparatecollarforthat Thankyouforpurchasingourproducts!This manualprovidesimportantinformationthatwill helpyousafelyoperatethiscollar. Pleasereadthisusermanualcarefullybeforeusing thisproduct.Thankyou!Ifyouhaveanyproblem withtheproduct,pleasedon'thesitatetoemailus at: ([email protected]) Wewillreplytoyouwithin24hoursandgiveyou thebestsolution. 4 Catalog Introduction................................................................5 Warning.......................................................................5 GettingStarted.........................................................8 Login&Register....................................................10 AddDevice............................................................12 Subscription..............................................................16 ElectronicFenceSetup...........................................17 MainPageIntroduction........................................21 ProductSpecification...........................................34 Warranty..................................................................35 5 Introduction Thiscollarintegratesthreepracticalcorefunctions: Real-TimeTracking,WirelessGPSElectronicFence，Heart RateMonitoringand RemoteDogTraining, providingall- roundprotectionandscientificmanagementforyour belovedpet. Warning ★Pleasereadallsafetyinstructionsthoroughly.Ignoring thesewarningscouldresultininjurytoyou,yourpet, orothers,aswellaspropertydamage. ★Thecollarispoweredbyabattery.Allowingyourpetto chewonthecollaroritsbatterymaydamagetheproduct, createafirehazard,orendangeryourpet.Alwaysinspect thebatteryanditsplasticcoverforpuncturesbefore placingthecollaronyourpet. ★Thecollarcontainselectroniccomponents,includinga lithium-ionbattery,whicharesensitivetohightemperatures. Donotleavethecollarinhotenvironmentsforprolonged periods.Onlyusetheprovidedchargerforrecharging. Ifyounoticeanypuncturesonthebatteryoritscover, stopusingthecollarimmediatelyandcontact customersupportatonce. ★Nocontainmentsystemcanguarantee100%containment ofallpets.Somedogsmaybecleverenoughtoescapeany 6 containmentsystem,andthesesystemsmayoccasionallyfail ormalfunction.Itisessentialtomonitoryourpetregularly whileusingthiscollar.Ifyourdogposesadangertoothers,do notrelyonthecontainmentsystemwithoutsupervision. ★Thecollarisspecificallydesignedfordogs.Itmustnotbe usedonhumans. ★Donotdisassembleorattempttomodifythecollar,as doingsowillvoidthewarranty. ★TheGPSaccuracyofthecollarmayvarydependingon location.ItisdesignedforOUTDOORuseonlyandcannot receiveGPSsignalsindoors. ★Thiscontainmentsystemcannotpreventpredatorsfrom enteringthefencedarea. ★TheCollarisnotdesignedtoserveasyourpet'sprimary restraint.Alwaysensureyourdogisproperlysecuredandsafe. ★ThecollarmeetstheIP67standard,meaningitisdustproof andwater-resistant.Itcanresistdust,spills,splashes,drool, andrain.Notethatovertime,normalwearandtearmay affectitswaterproofperformance. ★Thecollarperformsbestwhenpetownersinvesttimein trainingtheirdogs,justastheywouldwithanyobedience program—especiallyintheinitialstage.Spendtimehelping yourdoglearnthelocationofthefenceboundariesandthe alertsthatkeepthemsafelycontained.Wecannotguarantee thatthesystemwillcontainallpets.Ifyouareconcernedthat yourpetmightposeadangertoothersoritself,donotrely solelyonthecollartokeepitwithintheboundary. ★Thecollarrequiresthemobileappforoperation,alongwith sufficientbatterypower.Theperformanceoftrackingand 7 PackageList notificationsmayvarybasedonthestrengthofthecellular networksignalinyourarea. ★Thecollarisnotatoy.Adultsupervisionandcloseattention arenecessarywhenthecollarisusedbyornearchildren Note:Pleasechecktheproductpackagingcarefully, ifanyaccessoriesaremissing, pleasecontacttheafter-salesservicepersonnelby emailat [email protected] 8 GettingStarted ●FittingtheCollarStraps Adjustthestraptofitsnuglyaroundyourdog'sneck, ensuringthestaticcontactpointsmakefullcontactwith yourdog'sskin.Youshouldonlybeabletoslideonefinger betweenthecollarandyourdog'sneck. ●Chargethecollar 1.Connectthemagneticchargingcabletoapoweradapter. 2.Carefullyattachthemagneticchargertothecollar's chargingport;itwillautomaticallysnapintoplace. ●ChargingStatusDisplay Charging:RedLEDflashes. FullyCharged:RedLEDstaysonsteadily. ChargingTime:Approx.3hoursforafullcharge. 9 ●DownloadtheLikePetApp pleasedownloadtheLikePetApp. Note:Beforeinstallation,ensurethatyourmobiledevice's browserissettoallowtheinstallationofunknownapps. YoucanscantheQRcodebelowtowatchthedetailed operationtutorialvideoofLikePetApp,accessthe 10 Login&Register ▶ OpenthedownloadedLinkPetApptoenterthelogin screen,thenloginbyenteringyour[registeredemail]and [password]andclicking[Login],ordirectlyviathird-party accountssuchas[GoogleLogin]or[AppleIDLogin]. ▶ Ifyoudon'thaveanaccount,click[Register]toenterto theregistrationscreen. 1.Enteryour[Nickname],[Email],thensetaloginpassword; Clicktheeyeicontoviewthepassword. 2.Click[GetCode]—theco…

Text truncated - open the document above for the full version.

Test Report

1.Effective (Isotropic) Radiated Power Output Data Test Result Band Bandwidth Modulation Channel RB Configuration Result(dBm) Gain (dB) EIRP (dBm) EIRP Limit (dBm) Verdict Band41 5MHz QPSK 40065 1RB#0 23.28 1.69 24.97 34.77 PASS Band41 5MHz QPSK 40065 1RB#12 23.47 1.69 25.16 34.77 PASS Band41 5MHz QPSK 40065 1RB#24 22.95 1.69 24.64 34.77 PASS Band41 5MHz QPSK 40065 12RB#0 23.52 1.69 25.21 34.77 PASS Band41 5MHz QPSK 40065 12RB#6 22.98 1.69 24.67 34.77 PASS Band41 5MHz QPSK 40065 12RB#13 21.69 1.69 23.38 34.77 PASS Band41 5MHz QPSK 40065 25RB#0 22.51 1.69 24.20 34.77 PASS Band41 5MHz 16QAM 40065 1RB#0 23.49 1.69 25.18 34.77 PASS Band41 5MHz 16QAM 40065 1RB#12 22.37 1.69 24.06 34.77 PASS Band41 5MHz 16QAM 40065 1RB#24 22.21 1.69 23.90 34.77 PASS Band41 5MHz 16QAM 40065 12RB#0 22.67 1.69 24.36 34.77 PASS Band41 5MHz 16QAM 40065 12RB#6 23.03 1.69 24.72 34.77 PASS Band41 5MHz 16QAM 40065 12RB#13 23.07 1.69 24.76 34.77 PASS Band41 5MHz 16QAM 40065 25RB#0 21.96 1.69 23.65 34.77 PASS Band41 5MHz QPSK 40590 1RB#0 23.82 1.69 25.51 34.77 PASS Band41 5MHz QPSK 40590 1RB#12 22.70 1.69 24.39 34.77 PASS Band41 5MHz QPSK 40590 1RB#24 23.53 1.69 25.22 34.77 PASS Band41 5MHz QPSK 40590 12RB#0 22.16 1.69 23.85 34.77 PASS Band41 5MHz QPSK 40590 12RB#6 22.87 1.69 24.56 34.77 PASS Band41 5MHz QPSK 40590 12RB#13 23.16 1.69 24.85 34.77 PASS Band41 5MHz QPSK 40590 25RB#0 23.86 1.69 25.55 34.77 PASS Band41 5MHz 16QAM 40590 1RB#0 23.34 1.69 25.03 34.77 PASS Band41 5MHz 16QAM 40590 1RB#12 22.41 1.69 24.10 34.77 PASS Band41 5MHz 16QAM 40590 1RB#24 22.20 1.69 23.89 34.77 PASS Band41 5MHz 16QAM 40590 12RB#0 23.47 1.69 25.16 34.77 PASS Band41 5MHz 16QAM 40590 12RB#6 22.93 1.69 24.62 34.77 PASS Band41 5MHz 16QAM 40590 12RB#13 22.89 1.69 24.58 34.77 PASS Band41 5MHz 16QAM 40590 25RB#0 23.80 1.69 25.49 34.77 PASS Band41 5MHz QPSK 41215 1RB#0 22.01 1.69 23.70 34.77 PASS Band41 5MHz QPSK 41215 1RB#12 23.81 1.69 25.50 34.77 PASS Band41 5MHz QPSK 41215 1RB#24 22.74 1.69 24.43 34.77 PASS Band41 5MHz QPSK 41215 12RB#0 23.56 1.69 25.25 34.77 PASS Band41 5MHz QPSK 41215 12RB#6 23.05 1.69 24.74 34.77 PASS Page 2 of 71 Band41 5MHz QPSK 41215 12RB#13 22.50 1.69 24.19 34.77 PASS Band41 5MHz QPSK 41215 25RB#0 22.66 1.69 24.35 34.77 PASS Band41 5MHz 16QAM 41215 1RB#0 23.41 1.69 25.10 34.77 PASS Band41 5MHz 16QAM 41215 1RB#12 23.89 1.69 25.58 34.77 PASS Band41 5MHz 16QAM 41215 1RB#24 22.56 1.69 24.25 34.77 PASS Band41 5MHz 16QAM 41215 12RB#0 23.41 1.69 25.10 34.77 PASS Band41 5MHz 16QAM 41215 12RB#6 23.76 1.69 25.45 34.77 PASS Band41 5MHz 16QAM 41215 12RB#13 23.58 1.69 25.27 34.77 PASS Band41 5MHz 16QAM 41215 25RB#0 22.87 1.69 24.56 34.77 PASS Band41 10MHz QPSK 40090 1RB#0 22.87 1.69 24.56 34.77 PASS Band41 10MHz QPSK 40090 1RB#24 23.57 1.69 25.26 34.77 PASS Band41 10MHz QPSK 40090 1RB#49 23.54 1.69 25.23 34.77 PASS Band41 10MHz QPSK 40090 25RB#0 23.03 1.69 24.72 34.77 PASS Band41 10MHz QPSK 40090 25RB#12 23.28 1.69 24.97 34.77 PASS Band41 10MHz QPSK 40090 25RB#25 22.77 1.69 24.46 34.77 PASS Band41 10MHz QPSK 40090 50RB#0 22.92 1.69 24.61 34.77 PASS Band41 10MHz 16QAM 40090 1RB#0 22.81 1.69 24.50 34.77 PASS Band41 10MHz 16QAM 40090 1RB#24 22.61 1.69 24.30 34.77 PASS Band41 10MHz 16QAM 40090 1RB#49 22.69 1.69 24.38 34.77 PASS Band41 10MHz 16QAM 40090 25RB#0 22.84 1.69 24.53 34.77 PASS Band41 10MHz 16QAM 40090 25RB#12 22.86 1.69 24.55 34.77 PASS Band41 10MHz 16QAM 40090 25RB#25 23.72 1.69 25.41 34.77 PASS Band41 10MHz 16QAM 40090 50RB#0 22.85 1.69 24.54 34.77 PASS Band41 10MHz QPSK 40590 1RB#0 22.77 1.69 24.46 34.77 PASS Band41 10MHz QPSK 40590 1RB#24 22.40 1.69 24.09 34.77 PASS Band41 10MHz QPSK 40590 1RB#49 22.49 1.69 24.18 34.77 PASS Band41 10MHz QPSK 40590 25RB#0 23.21 1.69 24.90 34.77 PASS Band41 10MHz QPSK 40590 25RB#12 22.57 1.69 24.26 34.77 PASS Band41 10MHz QPSK 40590 25RB#25 22.36 1.69 24.05 34.77 PASS Band41 10MHz QPSK 40590 50RB#0 22.48 1.69 24.17 34.77 PASS Band41 10MHz 16QAM 40590 1RB#0 22.73 1.69 24.42 34.77 PASS Band41 10MHz 16QAM 40590 1RB#24 22.41 1.69 24.10 34.77 PASS Band41 10MHz 16QAM 40590 1RB#49 23.53 1.69 25.22 34.77 PASS Band41 10MHz 16QAM 40590 25RB#0 23.70 1.69 25.39 34.77 PASS Band41 10MHz 16QAM 40590 25RB#12 22.07 1.69 23.76 34.77 PASS Band41 10MHz 16QAM 40590 25RB#25 23.06 1.69 24.75 34.77 PASS Band41 10MHz 16QAM 40590 50RB#0 22.52 1.69 24.21 34.77 PASS Band41 10MHz QPSK 41190 1RB#0 22.08 1.69 23.77 34.77 PASS Page 3 of 71 Band41 10MHz QPSK 41190 1RB#24 23.17 1.69 24.86 34.77 PASS Band41 10MHz QPSK 41190 1RB#49 22.37 1.69 24.06 34.77 PASS Band41 10MHz QPSK 41190 25RB#0 22.82 1.69 24.51 34.77 PASS Band41 10MHz QPSK 41190 25RB#12 22.05 1.69 23.74 34.77 PASS Band41 10MHz QPSK 41190 25RB#25 23.18 1.69 24.87 34.77 PASS Band41 10MHz QPSK 41190 50RB#0 22.83 1.69 24.52 34.77 PASS Band41 10MHz 16QAM 41190 1RB#0 22.67 1.69 24.36 34.77 PASS Band41 10MHz 16QAM 41190 1RB#24 23.20 1.69 24.89 34.77 PASS Band41 10MHz 16QAM 41190 1RB#49 22.90 1.69 24.59 34.77 PASS Band41 10MHz 16QAM 41190 25RB#0 22.64 1.69 24.33 34.77 PASS Band41 10MHz 16QAM 41190 25RB#12 22.44 1.69 24.13 34.77 PASS Band41 10MHz 16QAM 41190 25RB#25 22.75 1.69 24.44 34.77 PASS Band41 10MHz 16QAM 41190 50RB#0 23.60 1.69 25.29 34.77 PASS Band41 15MHz QPSK 40115 1RB#0 22.01 1.69 23.70 34.77 PASS Band41 15MHz QPSK 40115 1RB#38 22.88 1.69 24.57 34.77 PASS Band41 15MHz QPSK 40115 1RB#74 23.12 1.69 24.81 34.77 PASS Band41 15MHz QPSK 40115 38RB#0 23.00 1.69 24.69 34.77 PASS Band41 15MHz QPSK 40115 38RB#18 21.97 1.69 23.66 34.77 PASS Band41 15MHz QPSK 40115 38RB#37 22.90 1.69 24.59 34.77 PASS Band41 15MHz QPSK 40115 75RB#0 22.68 1.69 24.37 34.77 PASS Band41 15MHz 16QAM 40115 1RB#0 23.27 1.69 24.96 34.77 PASS Band41 15MHz 16QAM 40115 1RB#38 22.54 1.69 24.23 34.77 PASS Band41 15MHz 16QAM 40115 1RB#74 22.67 1.69 24.36 34.77 PASS Band41 15MHz 16QAM 40115 38RB#0 22.62 1.69 24.31 34.77 PASS Band41 15MHz 16QAM 40115 38RB#18 23.03 1.69 24.72 34.77 PASS Band41 15MHz 16QAM 40115 38RB#37 22.66 1.69 24.35 34.77 PASS Band41 15MHz 16QAM 40115 75RB#0 23.40 1.69 25.09 34.77 PASS Band4…

Text truncated - open the document above for the full version.

Test Report

Band 5 5MHz/826.5/Low QPSK 1@0 Band 5 5MHz/826.5/Low QPSK 1@24 Band 5 5MHz/826.5/Low QPSK 25@0 Band 5 5MHz/826.5/Low 16QAM 1@0 Band 5 5MHz/826.5/Low 16QAM 1@24 Band 5 5MHz/826.5/Low 16QAM 25@0 Band 5 5MHz/846.5/High QPSK 1@0 Band 5 5MHz/846.5/High QPSK 1@24 Band 5 5MHz/846.5/High QPSK 25@0 Band 5 5MHz/846.5/High 16QAM 1@0 Band 5 5MHz/846.5/High 16QAM 1@24 Band 5 5MHz/846.5/High 16QAM 25@0 Band 5 10MHz/829.0/Low QPSK 1@0 Band 5 10MHz/829.0/Low QPSK 1@49 Band 5 10MHz/829.0/Low QPSK 50@0 Band 5 10MHz/829.0/Low 16QAM 1@0 Band 5 10MHz/829.0/Low 16QAM 1@49 Band 5 10MHz/829.0/Low 16QAM 50@0 Band 5 10MHz/844.0/High QPSK 1@0 Band 5 10MHz/844.0/High QPSK 1@49 Band 5 10MHz/844.0/High QPSK 50@0 Band 5 10MHz/844.0/High 16QAM 1@0 Band 5 10MHz/844.0/High 16QAM 1@49 Band 5 10MHz/844.0/High 16QAM 50@0 6. Frequency Stability Test Result Voltage Band Bandwidt h Modulati on Channel RB Configure Voltage [Vdc] Temper ature (°C) Deviation (ppm) Limit (ppm) Verdict Band5 1.4MHz QPSK 20407 6RB#0 VL NT 0.006993 ±2.5 PASS Band5 1.4MHz QPSK 20407 6RB#0 VN NT -0.019640 ±2.5 PASS Band5 1.4MHz QPSK 20407 6RB#0 VH NT 0.009785 ±2.5 PASS Band5 1.4MHz QPSK 20525 6RB#0 VL NT -0.049928 ±2.5 PASS Band5 1.4MHz QPSK 20525 6RB#0 VN NT -0.006248 ±2.5 PASS Band5 1.4MHz QPSK 20525 6RB#0 VH NT 0.043877 ±2.5 PASS Band5 1.4MHz QPSK 20643 6RB#0 VL NT 0.002896 ±2.5 PASS Band5 1.4MHz QPSK 20643 6RB#0 VN NT 0.005256 ±2.5 PASS Band5 1.4MHz QPSK 20643 6RB#0 VH NT -0.046805 ±2.5 PASS Band5 1.4MHz 16QAM 20407 6RB#0 VL NT -0.039615 ±2.5 PASS Band5 1.4MHz 16QAM 20407 6RB#0 VN NT 0.007286 ±2.5 PASS Band5 1.4MHz 16QAM 20407 6RB#0 VH NT 0.019164 ±2.5 PASS Band5 1.4MHz 16QAM 20525 6RB#0 VL NT 0.030755 ±2.5 PASS Band5 1.4MHz 16QAM 20525 6RB#0 VN NT -0.030495 ±2.5 PASS Band5 1.4MHz 16QAM 20525 6RB#0 VH NT 0.015888 ±2.5 PASS Band5 1.4MHz 16QAM 20643 6RB#0 VL NT -0.041530 ±2.5 PASS Band5 1.4MHz 16QAM 20643 6RB#0 VN NT -0.002435 ±2.5 PASS Band5 1.4MHz 16QAM 20643 6RB#0 VH NT -0.022721 ±2.5 PASS Band5 3MHz QPSK 20415 15RB#0 VL NT 0.044377 ±2.5 PASS Band5 3MHz QPSK 20415 15RB#0 VN NT -0.018682 ±2.5 PASS Band5 3MHz QPSK 20415 15RB#0 VH NT 0.048243 ±2.5 PASS Band5 3MHz QPSK 20525 15RB#0 VL NT -0.048335 ±2.5 PASS Band5 3MHz QPSK 20525 15RB#0 VN NT -0.049733 ±2.5 PASS Band5 3MHz QPSK 20525 15RB#0 VH NT -0.004845 ±2.5 PASS Band5 3MHz QPSK 20635 15RB#0 VL NT 0.007692 ±2.5 PASS Band5 3MHz QPSK 20635 15RB#0 VN NT 0.038323 ±2.5 PASS Band5 3MHz QPSK 20635 15RB#0 VH NT 0.012097 ±2.5 PASS Band5 3MHz 16QAM 20415 15RB#0 VL NT 0.019452 ±2.5 PASS Band5 3MHz 16QAM 20415 15RB#0 VN NT -0.009146 ±2.5 PASS Band5 3MHz 16QAM 20415 15RB#0 VH NT -0.009054 ±2.5 PASS Band5 3MHz 16QAM 20525 15RB#0 VL NT 0.013666 ±2.5 PASS Band5 3MHz 16QAM 20525 15RB#0 VN NT 0.038245 ±2.5 PASS Band5 3MHz 16QAM 20525 15RB#0 VH NT 0.038814 ±2.5 PASS Band5 3MHz 16QAM 20635 15RB#0 VL NT -0.050027 ±2.5 PASS Band5 3MHz 16QAM 20635 15RB#0 VN NT -0.012238 ±2.5 PASS Band5 3MHz 16QAM 20635 15RB#0 VH NT -0.007063 ±2.5 PASS Band5 5MHz QPSK 20425 25RB#0 VL NT 0.012067 ±2.5 PASS Band5 5MHz QPSK 20425 25RB#0 VN NT 0.034394 ±2.5 PASS Band5 5MHz QPSK 20425 25RB#0 VH NT -0.041730 ±2.5 PASS Band5 5MHz QPSK 20525 25RB#0 VL NT -0.047820 ±2.5 PASS Band5 5MHz QPSK 20525 25RB#0 VN NT -0.015796 ±2.5 PASS Band5 5MHz QPSK 20525 25RB#0 VH NT 0.010979 ±2.5 PASS Band5 5MHz QPSK 20625 25RB#0 VL NT -0.023329 ±2.5 PASS Band5 5MHz QPSK 20625 25RB#0 VN NT -0.014480 ±2.5 PASS Band5 5MHz QPSK 20625 25RB#0 VH NT -0.041157 ±2.5 PASS Band5 5MHz 16QAM 20425 25RB#0 VL NT 0.026747 ±2.5 PASS Band5 5MHz 16QAM 20425 25RB#0 VN NT -0.048275 ±2.5 PASS Band5 5MHz 16QAM 20425 25RB#0 VH NT 0.044389 ±2.5 PASS Band5 5MHz 16QAM 20525 25RB#0 VL NT 0.009269 ±2.5 PASS Band5 5MHz 16QAM 20525 25RB#0 VN NT -0.045434 ±2.5 PASS Band5 5MHz 16QAM 20525 25RB#0 VH NT 0.003293 ±2.5 PASS Band5 5MHz 16QAM 20625 25RB#0 VL NT -0.015055 ±2.5 PASS Band5 5MHz 16QAM 20625 25RB#0 VN NT 0.006993 ±2.5 PASS Band5 5MHz 16QAM 20625 25RB#0 VH NT -0.019640 ±2.5 PASS Band5 10MHz QPSK 20450 50RB#0 VL NT 0.009785 ±2.5 PASS Band5 10MHz QPSK 20450 50RB#0 VN NT -0.049928 ±2.5 PASS Band5 10MHz QPSK 20450 50RB#0 VH NT -0.006248 ±2.5 PASS Band5 10MHz QPSK 20525 50RB#0 VL NT 0.043877 ±2.5 PASS Band5 10MHz QPSK 20525 50RB#0 VN NT 0.002896 ±2.5 PASS Band5 10MHz QPSK 20525 50RB#0 VH NT 0.005256 ±2.5 PASS Band5 10MHz QPSK 20600 50RB#0 VL NT -0.046805 ±2.5 PASS Band5 10MHz QPSK 20600 50RB#0 VN NT -0.039615 ±2.5 PASS Band5 10MHz QPSK 20600 50RB#0 VH NT 0.007286 ±2.5 PASS Band5 10MHz 16QAM 20450 50RB#0 VL NT 0.019164 ±2.5 PASS Band5 10MHz 16QAM 20450 50RB#0 VN NT 0.030755 ±2.5 PASS Band5 10MHz 16QAM 20450 50RB#0 VH NT -0.030495 ±2.5 PASS Band5 10MHz 16QAM 20525 50RB#0 VL NT 0.015888 ±2.5 PASS Band5 10MHz 16QAM 20525 50RB#0 VN NT -0.041530 ±2.5 PASS Band5 10MHz 16QAM 20525 50RB#0 VH NT -0.002435 ±2.5 PASS Band5 10MHz 16QAM 20600 50RB#0 VL NT -0.022721 ±2.5 PASS Band5 10MHz 16QAM 20600 50RB#0 VN NT 0.044377 ±2.5 PASS Band5 10MHz 16QAM 20600 50RB#0 VH NT -0.018682 ±2.5 PASS Temperature Band Bandwidt h Modulati on Channel RB Configure Voltage [Vdc] Temper ature (°C) Deviation (ppm) Limit (ppm) Verdict Band5 1.4MHz QPSK 20407 6RB#0 NV -30 -0.005170 ±2.5 PASS Band5 1.4MHz QPSK 20407 6RB#0 NV -20 -0.013368 ±2.5 PASS Band5 1.4MHz QPSK 20407 6RB#0 NV 0 0.036461 ±2.5 PASS Band5 1.4MHz QPSK 20407 6RB#0 NV 10 -0.043081 ±2.5 PASS Band5 1.4MHz QPSK 20407 6RB#0 NV 20 0.000541 ±2.5 PASS Band5 1.4MHz QPSK 20525 6RB#0 NV -30 0.020979 ±2.5 PASS Band5 1.4MHz QPSK 20525 6RB#0 NV -20 -0.037378 ±2.5 PASS Band5 1.4MHz QPSK 20525 6RB#0 NV 0 0.027702 ±2.5 PASS Band5 1.4MHz QPSK 20525 6RB#0 NV 10 0.047794 ±2.5 PASS Band5 1.4MHz QPSK 20525 6RB#0 NV 20 -0.043257 ±2.5 PASS Band5 1.4MHz QPSK 20643 6RB#0 NV -30 -0.029756 ±2.5 PASS Band5 1.4MHz QPSK 20643 6RB#0 NV -20 0.002725 ±2.5 PASS Band5 1.4MHz QPSK 20643 6RB#0 NV 0 -0.008645 ±2.5 PASS Band5 1.4MHz QPSK 20643 6RB#0 NV 10 0.013710 ±2.5 PASS Band5 1.4MHz QPSK 20643 6RB#0 NV 20 0.041421 ±2.5 PASS Band5 1.4MHz 16QAM 20407 6RB#0 NV -30 0.030248 ±2.5 PASS Band5 1.4MHz 16QAM 20407 6…

Text truncated - open the document above for the full version.

Test Report

1. Transmitter Conducted Output Power And ERP/EIRP Test Result Band Bandwidth (MHz) Channel Freq (MHz) Modulation RB Conducted Power (dBm) ERP/EIRP (dBm) ERP/EIRP(Limit) (dBm) Verdict 12 1.4 23017 699.7 QPSK 1@0 23.90 24.09 34.77 PASS 12 1.4 23017 699.7 QPSK 1@2 23.86 24.05 34.77 PASS 12 1.4 23017 699.7 QPSK 1@5 23.72 23.91 34.77 PASS 12 1.4 23017 699.7 QPSK 3@0 23.96 24.15 34.77 PASS 12 1.4 23017 699.7 QPSK 3@1 23.03 23.22 34.77 PASS 12 1.4 23017 699.7 QPSK 3@2 22.60 22.79 34.77 PASS 12 1.4 23017 699.7 QPSK 6@0 23.01 23.20 34.77 PASS 12 1.4 23017 699.7 16QAM 1@0 23.89 24.08 34.77 PASS 12 1.4 23017 699.7 16QAM 1@2 22.89 23.08 34.77 PASS 12 1.4 23017 699.7 16QAM 1@5 22.02 22.21 34.77 PASS 12 1.4 23017 699.7 16QAM 3@0 22.88 23.07 34.77 PASS 12 1.4 23017 699.7 16QAM 3@1 23.43 23.62 34.77 PASS 12 1.4 23017 699.7 16QAM 3@2 23.83 24.02 34.77 PASS 12 1.4 23017 699.7 16QAM 6@0 22.79 22.98 34.77 PASS 12 1.4 23095 707.5 QPSK 1@0 23.55 23.74 34.77 PASS 12 1.4 23095 707.5 QPSK 1@2 22.92 23.11 34.77 PASS 12 1.4 23095 707.5 QPSK 1@5 23.48 23.67 34.77 PASS 12 1.4 23095 707.5 QPSK 3@0 22.52 22.71 34.77 PASS 12 1.4 23095 707.5 QPSK 3@1 22.51 22.70 34.77 PASS 12 1.4 23095 707.5 QPSK 3@2 23.31 23.50 34.77 PASS 12 1.4 23095 707.5 QPSK 6@0 23.85 24.04 34.77 PASS 12 1.4 23095 707.5 16QAM 1@0 23.79 23.98 34.77 PASS 12 1.4 23095 707.5 16QAM 1@2 22.80 22.99 34.77 PASS 12 1.4 23095 707.5 16QAM 1@5 22.66 22.85 34.77 PASS 12 1.4 23095 707.5 16QAM 3@0 23.67 23.86 34.77 PASS 12 1.4 23095 707.5 16QAM 3@1 22.87 23.06 34.77 PASS 12 1.4 23095 707.5 16QAM 3@2 23.67 23.86 34.77 PASS 12 1.4 23095 707.5 16QAM 6@0 23.82 24.01 34.77 PASS 12 1.4 23173 715.3 QPSK 1@0 21.91 22.10 34.77 PASS 12 1.4 23173 715.3 QPSK 1@2 23.72 23.91 34.77 PASS 12 1.4 23173 715.3 QPSK 1@5 22.57 22.76 34.77 PASS 12 1.4 23173 715.3 QPSK 3@0 23.90 24.09 34.77 PASS 12 1.4 23173 715.3 QPSK 3@1 23.39 23.58 34.77 PASS 12 1.4 23173 715.3 QPSK 3@2 22.39 22.58 34.77 PASS 12 1.4 23173 715.3 QPSK 6@0 22.81 23.00 34.77 PASS 12 1.4 23173 715.3 16QAM 1@0 23.51 23.70 34.77 PASS 12 1.4 23173 715.3 16QAM 1@2 24.30 24.49 34.77 PASS 12 1.4 23173 715.3 16QAM 1@5 22.78 22.97 34.77 PASS 12 1.4 23173 715.3 16QAM 3@0 23.29 23.48 34.77 PASS 12 1.4 23173 715.3 16QAM 3@1 23.84 24.03 34.77 PASS 12 1.4 23173 715.3 16QAM 3@2 23.95 24.14 34.77 PASS 12 1.4 23173 715.3 16QAM 6@0 22.87 23.06 34.77 PASS 12 3.0 23025 700.5 QPSK 1@0 22.89 23.08 34.77 PASS 12 3.0 23025 700.5 QPSK 1@7 23.67 23.86 34.77 PASS 12 3.0 23025 700.5 QPSK 1@14 23.32 23.51 34.77 PASS 12 3.0 23025 700.5 QPSK 8@0 22.79 22.98 34.77 PASS 12 3.0 23025 700.5 QPSK 8@4 23.77 23.96 34.77 PASS 12 3.0 23025 700.5 QPSK 8@7 23.25 23.44 34.77 PASS 12 3.0 23025 700.5 QPSK 15@0 23.12 23.31 34.77 PASS 12 3.0 23025 700.5 16QAM 1@0 23.45 23.64 34.77 PASS 12 3.0 23025 700.5 16QAM 1@7 22.56 22.75 34.77 PASS 12 3.0 23025 700.5 16QAM 1@14 23.19 23.38 34.77 PASS 12 3.0 23025 700.5 16QAM 8@0 22.97 23.16 34.77 PASS 12 3.0 23025 700.5 16QAM 8@4 23.44 23.63 34.77 PASS 12 3.0 23025 700.5 16QAM 8@7 23.53 23.72 34.77 PASS 12 3.0 23025 700.5 16QAM 15@0 23.27 23.46 34.77 PASS 12 3.0 23095 707.5 QPSK 1@0 22.88 23.07 34.77 PASS 12 3.0 23095 707.5 QPSK 1@7 22.09 22.28 34.77 PASS 12 3.0 23095 707.5 QPSK 1@14 23.30 23.49 34.77 PASS 12 3.0 23095 707.5 QPSK 8@0 22.78 22.97 34.77 PASS 12 3.0 23095 707.5 QPSK 8@4 23.26 23.45 34.77 PASS 12 3.0 23095 707.5 QPSK 8@7 22.34 22.53 34.77 PASS 12 3.0 23095 707.5 QPSK 15@0 22.85 23.04 34.77 PASS 12 3.0 23095 707.5 16QAM 1@0 22.90 23.09 34.77 PASS 12 3.0 23095 707.5 16QAM 1@7 22.77 22.96 34.77 PASS 12 3.0 23095 707.5 16QAM 1@14 24.03 24.22 34.77 PASS 12 3.0 23095 707.5 16QAM 8@0 23.72 23.91 34.77 PASS 12 3.0 23095 707.5 16QAM 8@4 22.21 22.40 34.77 PASS 12 3.0 23095 707.5 16QAM 8@7 23.03 23.22 34.77 PASS 12 3.0 23095 707.5 16QAM 15@0 22.77 22.96 34.77 PASS 12 3.0 23165 714.5 QPSK 1@0 22.74 22.93 34.77 PASS 12 3.0 23165 714.5 QPSK 1@7 23.33 23.52 34.77 PASS 12 3.0 23165 714.5 QPSK 1@14 22.78 22.97 34.77 PASS 12 3.0 23165 714.5 QPSK 8@0 23.05 23.24 34.77 PASS 12 3.0 23165 714.5 QPSK 8@4 22.77 22.96 34.77 PASS 12 3.0 23165 714.5 QPSK 8@7 23.37 23.56 34.77 PASS 12 3.0 23165 714.5 QPSK 15@0 23.28 23.47 34.77 PASS 12 3.0 23165 714.5 16QAM 1@0 22.56 22.75 34.77 PASS 12 3.0 23165 714.5 16QAM 1@7 23.36 23.55 34.77 PASS 12 3.0 23165 714.5 16QAM 1@14 23.20 23.39 34.77 PASS 12 3.0 23165 714.5 16QAM 8@0 22.33 22.52 34.77 PASS 12 3.0 23165 714.5 16QAM 8@4 23.46 23.65 34.77 PASS 12 3.0 23165 714.5 16QAM 8@7 22.72 22.91 34.77 PASS 12 3.0 23165 714.5 16QAM 15@0 23.91 24.10 34.77 PASS 12 5.0 23035 701.5 QPSK 1@0 22.50 22.69 34.77 PASS 12 5.0 23035 701.5 QPSK 1@12 23.16 23.35 34.77 PASS 12 5.0 23035 701.5 QPSK 1@24 23.29 23.48 34.77 PASS 12 5.0 23035 701.5 QPSK 12@0 23.30 23.49 34.77 PASS 12 5.0 23035 701.5 QPSK 12@6 22.82 23.01 34.77 PASS 12 5.0 23035 701.5 QPSK 12@11 22.69 22.88 34.77 PASS 12 5.0 23035 701.5 QPSK 25@0 23.18 23.37 34.77 PASS 12 5.0 23035 701.5 16QAM 1@0 23.11 23.30 34.77 PASS 12 5.0 23035 701.5 16QAM 1@12 23.05 23.24 34.77 PASS 12 5.0 23035 701.5 16QAM 1@24 22.59 22.78 34.77 PASS 12 5.0 23035 701.5 16QAM 12@0 22.79 22.98 34.77 PASS 12 5.0 23035 701.5 16QAM 12@6 24.00 24.19 34.77 PASS 12 5.0 23035 701.5 16QAM 12@11 22.82 23.01 34.77 PASS 12 5.0 23035 701.5 16QAM 25@0 23.58 23.77 34.77 PASS 12 5.0 23095 707.5 QPSK 1@0 22.62 22.81 34.77 PASS 12 5.0 23095 707.5 QPSK 1@12 23.69 23.88 34.77 PASS 12 5.0 23095 707.5 QPSK 1@24 23.22 23.41 34.77 PASS 12 5.0 23095 707.5 QPSK 12@0 23.47 23.66 34.77 PASS 12 5.0 23095 707.5 QPSK 12@6 23.24 23.43 34.77 PASS 12 5.0 23095 707.5 QPSK 12@11 23.73 23.92 34.77 PASS 12 5.0 23095 707.5 QPSK 25@0 23.06 23.25 34.77 PASS 12 5.0 23095 707.5 16QAM 1@0 22.59 22.78 34.77 PASS 12 5.0 23095 707.5 16QAM 1@12 23.12 23.31 34.77 PASS 12 5.0 23095 707.5 16QAM 1@24 23.39 23.58 34.77 PASS 12 5.0 23095 707.5 16QAM 12@0 23.27 23.46 34.77 PASS 12 5.0 23095 707.5 16QAM 12@6 23.49 23.68 34.77 PASS 12 5.0 23095 707.5 16QAM 12@11 23.33 23.52 34.77 PASS 12 5.0 23095 707.5 16QAM 25@0 23.43 23.62 34.77 PASS 12 5.0 2…

Text truncated - open the document above for the full version.

Test Report

Band 12 3MHz/714.5/High QPSK 1@0 Band 12 3MHz/714.5/High QPSK 1@14 Band 12 3MHz/714.5/High QPSK 15@0 Band 12 3MHz/714.5/High 16QAM 1@0 Band 12 3MHz/714.5/High 16QAM 1@14 Band 12 3MHz/714.5/High 16QAM 15@0 Band 12 5MHz/701.5/Low QPSK 1@0 Band 12 5MHz/701.5/Low QPSK 1@24 Band 12 5MHz/701.5/Low QPSK 25@0 Band 12 5MHz/701.5/Low 16QAM 1@0 Band 12 5MHz/701.5/Low 16QAM 1@24 Band 12 5MHz/701.5/Low 16QAM 25@0 Band 12 5MHz/713.5/High QPSK 1@0 Band 12 5MHz/713.5/High QPSK 1@24 Band 12 5MHz/713.5/High QPSK 25@0 Band 12 5MHz/713.5/High 16QAM 1@0 Band 12 5MHz/713.5/High 16QAM 1@24 Band 12 5MHz/713.5/High 16QAM 25@0 Band 12 10MHz/704.0/Low QPSK 1@0 Band 12 10MHz/704.0/Low QPSK 1@49 Band 12 10MHz/704.0/Low QPSK 50@0 Band 12 10MHz/704.0/Low 16QAM 1@0 Band 12 10MHz/704.0/Low 16QAM 1@49 Band 12 10MHz/704.0/Low 16QAM 50@0 Band 12 10MHz/711.0/High QPSK 1@0 Band 12 10MHz/711.0/High QPSK 1@49 Band 12 10MHz/711.0/High QPSK 50@0 Band 12 10MHz/711.0/High 16QAM 1@0 Band 12 10MHz/711.0/High 16QAM 1@49 Band 12 10MHz/711.0/High 16QAM 50@0 5. Frequency Stability Test Result Voltage Band Bandwidt h Modulati on Channel RB Configure Voltage [Vdc] Temper ature (°C) Deviation (ppm) Limit (ppm) Verdict Band12 1.4MHz QPSK 23017 6RB#0 VN NT -0.012478 ±2.5 PASS Band12 1.4MHz QPSK 23017 6RB#0 VL NT -0.007643 ±2.5 PASS Band12 1.4MHz QPSK 23017 6RB#0 VH NT -0.016703 ±2.5 PASS Band12 1.4MHz 16QAM 23017 6RB#0 VN NT -0.004043 ±2.5 PASS Band12 1.4MHz 16QAM 23017 6RB#0 VL NT -0.024073 ±2.5 PASS Band12 1.4MHz 16QAM 23017 6RB#0 VH NT -0.014251 ±2.5 PASS Band12 1.4MHz QPSK 23095 6RB#0 VN NT -0.018835 ±2.5 PASS Band12 1.4MHz QPSK 23095 6RB#0 VL NT -0.012335 ±2.5 PASS Band12 1.4MHz QPSK 23095 6RB#0 VH NT -0.006103 ±2.5 PASS Band12 1.4MHz 16QAM 23095 6RB#0 VN NT -0.012774 ±2.5 PASS Band12 1.4MHz 16QAM 23095 6RB#0 VL NT -0.015910 ±2.5 PASS Band12 1.4MHz 16QAM 23095 6RB#0 VH NT -0.027376 ±2.5 PASS Band12 1.4MHz QPSK 23173 6RB#0 VN NT -0.008170 ±2.5 PASS Band12 1.4MHz QPSK 23173 6RB#0 VL NT -0.010305 ±2.5 PASS Band12 1.4MHz QPSK 23173 6RB#0 VH NT -0.004940 ±2.5 PASS Band12 1.4MHz 16QAM 23173 6RB#0 VN NT -0.026000 ±2.5 PASS Band12 1.4MHz 16QAM 23173 6RB#0 VL NT -0.013500 ±2.5 PASS Band12 1.4MHz 16QAM 23173 6RB#0 VH NT -0.007976 ±2.5 PASS Band12 3MHz QPSK 23025 15RB#0 VN NT -0.013088 ±2.5 PASS Band12 3MHz QPSK 23025 15RB#0 VL NT -0.008952 ±2.5 PASS Band12 3MHz QPSK 23025 15RB#0 VH NT -0.018875 ±2.5 PASS Band12 3MHz 16QAM 23025 15RB#0 VN NT 0.010960 ±2.5 PASS Band12 3MHz 16QAM 23025 15RB#0 VL NT -0.010997 ±2.5 PASS Band12 3MHz 16QAM 23025 15RB#0 VH NT -0.010968 ±2.5 PASS Band12 3MHz QPSK 23095 15RB#0 VN NT -0.013666 ±2.5 PASS Band12 3MHz QPSK 23095 15RB#0 VL NT -0.015507 ±2.5 PASS Band12 3MHz QPSK 23095 15RB#0 VH NT -0.017152 ±2.5 PASS Band12 3MHz 16QAM 23095 15RB#0 VN NT -0.012492 ±2.5 PASS Band12 3MHz 16QAM 23095 15RB#0 VL NT -0.011900 ±2.5 PASS Band12 3MHz 16QAM 23095 15RB#0 VH NT -0.011445 ±2.5 PASS Band12 3MHz QPSK 23165 15RB#0 VN NT -0.007124 ±2.5 PASS Band12 3MHz QPSK 23165 15RB#0 VL NT 0.020693 ±2.5 PASS Band12 3MHz QPSK 23165 15RB#0 VH NT -0.004501 ±2.5 PASS Band12 3MHz 16QAM 23165 15RB#0 VN NT -0.007045 ±2.5 PASS Band12 3MHz 16QAM 23165 15RB#0 VL NT -0.014686 ±2.5 PASS Band12 3MHz 16QAM 23165 15RB#0 VH NT 0.002999 ±2.5 PASS Band12 5MHz QPSK 23035 25RB#0 VN NT -0.009891 ±2.5 PASS Band12 5MHz QPSK 23035 25RB#0 VL NT -0.027437 ±2.5 PASS Band12 5MHz QPSK 23035 25RB#0 VH NT -0.019053 ±2.5 PASS Band12 5MHz 16QAM 23035 25RB#0 VN NT -0.006646 ±2.5 PASS Band12 5MHz 16QAM 23035 25RB#0 VL NT -0.011823 ±2.5 PASS Band12 5MHz 16QAM 23035 25RB#0 VH NT -0.007866 ±2.5 PASS Band12 5MHz QPSK 23095 25RB#0 VN NT -0.011352 ±2.5 PASS Band12 5MHz QPSK 23095 25RB#0 VL NT -0.012677 ±2.5 PASS Band12 5MHz QPSK 23095 25RB#0 VH NT -0.002840 ±2.5 PASS Band12 5MHz 16QAM 23095 25RB#0 VN NT -0.004749 ±2.5 PASS Band12 5MHz 16QAM 23095 25RB#0 VL NT -0.011793 ±2.5 PASS Band12 5MHz 16QAM 23095 25RB#0 VH NT -0.005932 ±2.5 PASS Band12 5MHz QPSK 23155 25RB#0 VN NT -0.010086 ±2.5 PASS Band12 5MHz QPSK 23155 25RB#0 VL NT -0.002463 ±2.5 PASS Band12 5MHz QPSK 23155 25RB#0 VH NT -0.008850 ±2.5 PASS Band12 5MHz 16QAM 23155 25RB#0 VN NT -0.009698 ±2.5 PASS Band12 5MHz 16QAM 23155 25RB#0 VL NT -0.008554 ±2.5 PASS Band12 5MHz 16QAM 23155 25RB#0 VH NT -0.011915 ±2.5 PASS Band12 10MHz QPSK 23060 50RB#0 VN NT -0.008853 ±2.5 PASS Band12 10MHz QPSK 23060 50RB#0 VL NT -0.009480 ±2.5 PASS Band12 10MHz QPSK 23060 50RB#0 VH NT -0.012627 ±2.5 PASS Band12 10MHz 16QAM 23060 50RB#0 VN NT -0.006931 ±2.5 PASS Band12 10MHz 16QAM 23060 50RB#0 VL NT -0.012615 ±2.5 PASS Band12 10MHz 16QAM 23060 50RB#0 VH NT -0.013570 ±2.5 PASS Band12 10MHz QPSK 23095 50RB#0 VN NT -0.012398 ±2.5 PASS Band12 10MHz QPSK 23095 50RB#0 VL NT -0.009875 ±2.5 PASS Band12 10MHz QPSK 23095 50RB#0 VH NT -0.005339 ±2.5 PASS Band12 10MHz 16QAM 23095 50RB#0 VN NT -0.006646 ±2.5 PASS Band12 10MHz 16QAM 23095 50RB#0 VL NT -0.011403 ±2.5 PASS Band12 10MHz 16QAM 23095 50RB#0 VH NT -0.004580 ±2.5 PASS Band12 10MHz QPSK 23130 50RB#0 VN NT -0.012609 ±2.5 PASS Band12 10MHz QPSK 23130 50RB#0 VL NT -0.008710 ±2.5 PASS Band12 10MHz QPSK 23130 50RB#0 VH NT -0.005818 ±2.5 PASS Band12 10MHz 16QAM 23130 50RB#0 VN NT -0.027401 ±2.5 PASS Band12 10MHz 16QAM 23130 50RB#0 VL NT -0.017530 ±2.5 PASS Band12 10MHz 16QAM 23130 50RB#0 VH NT -0.016999 ±2.5 PASS Temperature Band Bandwidt h Modulati on Channel RB Configure Voltage [Vdc] Temper ature (°C) Deviation (ppm) Limit (ppm) Verdict Band12 1.4MHz QPSK 23017 6RB#0 NV -30 0.013080 ±2.5 PASS Band12 1.4MHz QPSK 23017 6RB#0 NV -20 0.013245 ±2.5 PASS Band12 1.4MHz QPSK 23017 6RB#0 NV -10 0.043877 ±2.5 PASS Band12 1.4MHz QPSK 23017 6RB#0 NV 0 0.019693 ±2.5 PASS Band12 1.4MHz QPSK 23017 6RB#0 NV 10 0.016117 ±2.5 PASS Band12 1.4MHz QPSK 23017 6RB#0 NV 20 -0.004667 ±2.5 PASS Band12 1.4MHz QPSK 23017 6RB#0 NV 30 -0.002131 ±2.5 PASS Band12 1.4MHz QPSK 23017 6RB#0 NV 40 0.040847 ±2.5 PASS Band12 1.4MHz QPSK 23017 6RB#0 NV 50 0.004223 ±2.5 PASS Band12 1.4MHz 16QAM 23017 6RB#0 NV -30 -0.012070 ±2.5 PASS Band12 1.4MHz 16QA…

Text truncated - open the document above for the full version.

Contact Information

Applicant

Weicai Deng(CEO)

[email protected]Fax: 0086 13500063673

Technical Contact

HOPEK CORPORATION INCYangyang Xu

[email protected]

16755 Coyote Bush Dr Unit 84 · 92127 · United States

Test Firm

Shenzhen PSI Testing Co., Ltd.Simple Guan

[email protected]

Technical Specifications

#	Rule Parts	Frequency Range	Power Output	Emission	Tolerance
1	24E	1.85 GHz - 1.91 GHz	576.77 mW	17M9G7D	2.5ppm
2	24E	1.85 GHz - 1.91 GHz	538.27 mW	17M9W7D	2.5ppm
3	27	1.71 GHz - 1.75 GHz	606.74 mW	17M9G7D	2.5ppm
4	27	1.71 GHz - 1.75 GHz	524.81 mW	17M9W7D	2.5ppm
5	22H	824 MHz - 849 MHz	101.86 mW	8M94G7D	2.5ppm
6	22H	824 MHz - 849 MHz	105.20 mW	8M94W7D	2.5ppm
7	27	699 MHz - 716 MHz	284.45 mW	8M94G7D	2.5ppm
8	27	699 MHz - 716 MHz	302.69 mW	8M94W7D	2.5ppm
9	27	777 MHz - 787 MHz	126.77 mW	8M94G7D	2.5ppm
1	27	777 MHz - 787 MHz	134.59 mW	8M68W7D	2.5ppm
11	27	704 MHz - 716 MHz	271.64 mW	8M91G7D	2.5ppm
12	27	704 MHz - 716 MHz	285.76 mW	8M91W7D	2.5ppm
13	27	1.71 GHz - 1.78 GHz	328.85 mW	17M7G7D	2.5ppm
14	27	1.71 GHz - 1.78 GHz	322.85 mW	17M8W7D	2.5ppm
15	27	2.57 GHz - 2.62 GHz	416.87 mW	17M8G7D	2.5ppm
16	27	2.57 GHz - 2.62 GHz	402.72 mW	17M8W7D	2.5ppm
17	27	2.50 GHz - 2.69 GHz	461.32 mW	17M8G7D	2.5ppm
18	27	2.50 GHz - 2.69 GHz	470.98 mW	17M8W7D	2.5ppm

Confidentiality

Long Term

Grant Notes

Output power listed is ERP for frequencies below 1 GHz, and EIRP for frequencies above 1 GHz. This device supports bandwidths of 1.4/3/5/10/15/20 MHz for LTE Band 2,4 and 66, bandwidths of 1.4/3/5/10 MHz for LTE Band 5, bandwidths of 5/10/15/20 MHz for LTE Bands 38 and 41, bandwidths of 1.4/3/5/10 MHz for LTE Band 12, and bandwidths of 5/10 MHz for LTE Band 13 and 17. The antenna(s) used for this transmitter must be installed to provide a separation distance of at least 20 cm from all persons and not be co-located with any other transmitters except in accordance with FCC multi-transmitter product procedures as in this filing.
