Case No. : GTS20220530010-1-1 Ambient Condition: 25 °C, 45 %RH, Test Date: 2022.7.27 Test Engineer: Jenny zeng Appendix A.1: DTS Bandwidth Test Result TestMode Antenna Frequency[MHz] DTS BW [MHz] FL[MHz] FH[MHz] Limit[MHz] Verdict 11B Ant1 2412 10.040 2406.960 2417.000 0.5 PASS 2437 9.560 2432.440 2442.000 0.5 PASS 2462 10.040 2456.960 2467.000 0.5 PASS 11G Ant1 2412 16.360 2403.800 2420.160 0.5 PASS 2437 16.320 2428.840 2445.160 0.5 PASS 2462 16.360 2453.800 2470.160 0.5 PASS 11N20SISO Ant1 2412 17.760 2403.080 2420.840 0.5 PASS 2437 17.600 2428.200 2445.800 0.5 PASS 2462 17.640 2453.160 2470.800 0.5 PASS 11N40SISO Ant1 2422 36.320 2403.840 2440.160 0.5 PASS 2437 36.080 2419.080 2455.160 0.5 PASS 2452 36.320 2433.840 2470.160 0.5 PASS Test Graphs 11B_Ant1_2412 11B_Ant1_2437 11B_Ant1_2462 11G_Ant1_2412 11G_Ant1_2437 11G_Ant1_2462 11N20SISO_Ant1_2412 11N20SISO_Ant1_2437 11N20SISO_Ant1_2462 11N40SISO_Ant1_2422 11N40SISO_Ant1_2437 11N40SISO_Ant1_2452 Appendix A.2: Occupied Channel Bandwidth Test Result TestMode Antenna Channel Frequency[MHz] OCB [MHz] FL[MHz] FH[MHz] Limit[MHz] Verdict 11B Ant1 2412 15.204 2404.359 2419.563 --- --- 2437 15.197 2429.426 2444.623 --- --- 2462 15.122 2454.409 2469.531 --- --- 11G Ant1 2412 17.357 2403.276 2420.633 --- --- 2437 17.367 2428.314 2445.681 --- --- 2462 17.404 2453.224 2470.628 --- --- 11N20SISO Ant1 2412 18.281 2402.865 2421.146 --- --- 2437 18.276 2427.863 2446.139 --- --- 2462 18.210 2452.884 2471.094 --- --- 11N40SISO Ant1 2422 36.914 2403.527 2440.441 --- --- 2437 36.823 2418.622 2455.445 --- --- 2452 36.721 2433.664 2470.385 --- --- Test Graphs 11B_Ant1_2412 11B_Ant1_2437 11B_Ant1_2462 11G_Ant1_2412 11G_Ant1_2437 11G_Ant1_2462 11N20SISO_Ant1_2412 11N20SISO_Ant1_2437 11N20SISO_Ant1_2462 11N40SISO_Ant1_2422 11N40SISO_Ant1_2437 11N40SISO_Ant1_2452 Appendix A.3: Maximum power spectral density Test Result TestMode Antenna Frequency[MHz] Result[dBm/3-100kHz] Limit[dBm/3kHz] Verdict 11B Ant1 2412 -11.47 ≤8.00 PASS 2437 -10.42 ≤8.00 PASS 2462 -10.73 ≤8.00 PASS 11G Ant1 2412 -11.70 ≤8.00 PASS 2437 -11.42 ≤8.00 PASS 2462 -10.88 ≤8.00 PASS 11N20SISO Ant1 2412 -11.43 ≤8.00 PASS 2437 -12.25 ≤8.00 PASS 2462 -11.09 ≤8.00 PASS 11N40SISO Ant1 2422 -14.00 ≤8.00 PASS 2437 -12.57 ≤8.00 PASS 2452 -12.82 ≤8.00 PASS Test Graphs 11B_Ant1_2412 11B_Ant1_2437 11B_Ant1_2462 11G_Ant1_2412 11G_Ant1_2437 11G_Ant1_2462 11N20SISO_Ant1_2412 11N20SISO_Ant1_2437 11N20SISO_Ant1_2462 11N40SISO_Ant1_2422 11N40SISO_Ant1_2437 11N40SISO_Ant1_2452 Appendix A.4: Band edge measurements Test Result TestMode Antenna ChName Frequency[MHz] RefLevel[dBm] Result[dBm] Limit[dBm] Verdict 11B Ant1 Low 2412 5.85 -26.3 ≤-14.15 PASS High 2462 6.94 -45.87 ≤-13.06 PASS 11G Ant1 Low 2412 4.88 -23.38 ≤-15.12 PASS High 2462 5.66 -35.29 ≤-14.35 PASS 11N20SISO Ant1 Low 2412 4.52 -27.16 ≤-15.48 PASS High 2462 4.87 -33.4 ≤-15.13 PASS 11N40SISO Ant1 Low 2422 1.87 -24.15 ≤-18.14 PASS High 2452 3.12 -26.77 ≤-16.88 PASS Test Graphs 11B_Ant1_Low_2412 11B_Ant1_High_2462 11G_Ant1_Low_2412 11G_Ant1_High_2462 11N20SISO_Ant1_Low_2412 11N20SISO_Ant1_High_2462 11N40SISO_Ant1_Low_2422 11N40SISO_Ant1_High_2452 Appendix A.5: Conducted Spurious Emission Test Result TestMode Antenna Frequency[MHz] FreqRange [Mhz] RefLevel [dBm] Result [dBm] Limit [dBm] Verdict 11B Ant1 2412 Reference 5.44 5.44 --- PASS 30~1000 5.44 -60.4 ≤-14.56 PASS 1000~26500 5.44 -42.52 ≤-14.56 PASS 2437 Reference 5.90 5.90 --- PASS 30~1000 5.90 -60.29 ≤-14.1 PASS 1000~26500 5.90 -41.91 ≤-14.1 PASS 2462 Reference 6.19 6.19 --- PASS 30~1000 6.19 -60.27 ≤-13.81 PASS 1000~26500 6.19 -42.94 ≤-13.81 PASS 11G Ant1 2412 Reference 1.11 1.11 --- PASS 30~1000 1.11 -60.43 ≤-18.89 PASS 1000~26500 1.11 -44.68 ≤-18.89 PASS 2437 Reference 1.80 1.80 --- PASS 30~1000 1.80 -60.52 ≤-18.2 PASS 1000~26500 1.80 -42.03 ≤-18.2 PASS 2462 Reference 5.14 5.14 --- PASS 30~1000 5.14 -60.43 ≤-14.86 PASS 1000~26500 5.14 -42.56 ≤-14.86 PASS 11N20SISO Ant1 2412 Reference -14.85 -14.85 --- PASS 30~1000 -14.85 -60.63 ≤-34.85 PASS 1000~26500 -14.85 -47.57 ≤-34.85 PASS 2437 Reference 0.98 0.98 --- PASS 30~1000 0.98 -60.3 ≤-19.02 PASS 1000~26500 0.98 -44.07 ≤-19.02 PASS 2462 Reference 1.71 1.71 --- PASS 30~1000 1.71 -45.37 ≤-18.29 PASS 1000~26500 1.71 -42.86 ≤-18.29 PASS 11N40SISO Ant1 2422 Reference -1.44 -1.44 --- PASS 30~1000 -1.44 -60.59 ≤-21.44 PASS 1000~26500 -1.44 -46.82 ≤-21.44 PASS 2437 Reference 2.04 2.04 --- PASS 30~1000 2.04 -60.06 ≤-17.96 PASS 1000~26500 2.04 -44.16 ≤-17.96 PASS 2452 Reference 2.81 2.81 --- PASS 30~1000 2.81 -60.16 ≤-17.19 PASS 1000~26500 2.81 -43.12 ≤-17.19 PASS Test Graphs 11B_Ant1_2412_0~Reference 11B_Ant1_2412_30~1000 11B_Ant1_2412_1000~26500 11B_Ant1_2437_0~Reference 11B_Ant1_2437_30~1000 11B_Ant1_2437_1000~26500 11B_Ant1_2462_0~Reference 11B_Ant1_2462_30~1000 11B_Ant1_2462_1000~26500 11G_Ant1_2412_0~Reference 11G_Ant1_2412_30~1000 11G_Ant1_2412_1000~26500 11G_Ant1_2437_0~Reference 11G_Ant1_2437_30~1000 11G_Ant1_2437_1000~26500 11G_Ant1_2462_0~Reference 11G_Ant1_2462_30~1000 11G_Ant1_2462_1000~26500 11N20SISO_Ant1_2412_0~Reference 11N20SISO_Ant1_2412_30~1000 11N20SISO_Ant1_2412_1000~26500 11N20SISO_Ant1_2437_0~Reference 11N20SISO_Ant1_2437_30~1000 11N20SISO_Ant1_2437_1000~26500 11N20SISO_Ant1_2462_0~Reference 11N20SISO_Ant1_2462_30~1000 11N20SISO_Ant1_2462_1000~26500 11N40SISO_Ant1_2422_0~Reference 11N40SISO_Ant1_2422_30~1000 11N40SISO_Ant1_2422_1000~26500 11N40SISO_Ant1_2437_0~Reference 11N40SISO_Ant1_2437_30~1000 11N40SISO_Ant1_2437_1000~26500 11N40SISO_Ant1_2452_0~Reference 11N40SISO_Ant1_2452_30~1000 11N40SISO_Ant1_2452_1000~26500
