2A7BN-IX482VIDEO DOOR PHONE SYSTEM

IX-ENG-482/TD7-V1 / 202112 IX482 VIDEO INTERCOM SYSTEM 7’’ IPS FULL VIEW ANGLE TFT MONITOR • Please read this manual carefully before using the product you purchase,and keep it well for future use. • Please note that images and sketch maps in this manual may be different from the actual product. -1- 1. Parts and Functions LCD Screen Talk/Mon ButtonUnlock Button Power/No Disturb Indicator Microphone P+P-+12VSW-SW+ GD A1 12V A0 Z4Z3Z2Z1 Alarm zone Terminal connector Lan connector Power/No Disturb indicator Show the power status of the system. Show the no disturb status. Talk/Mon button Press to communicate hands free with visitor; Press to view the outdoor condition in standby mode. LCD screen Display the visitors' image. Microphone Transmit audio from one station to other stations. Unlock button Press to release the door. Terminal connector SW+,SW-: Extra door bell call button connection port. P+,P-: Use to connect 24V local power supply (HDR-30- 24). Alarm zone Lan connector Use to connect the indoor station to the network. Key functions -2- 3. Main Menu The Main menu is your starting point for using all the applications on your moni- tor. Touch Unlock button, or touch anywhere of the screen on monitor in standby mode, the Main menu will appear as follow: 2. Mounting 145~160 cm The unit Cat-5e/Cat-6 cable Mounting screw x 2(included) Mounting bracket Mounting box The installation height is suggested to 145~160cm. 1. Use screws to fasten the mounting bracket to the wall with mounting box. 2. Connect the cat-5e or cat-6 cables to the unit. 3. Mount the unit to the mounting bracket, make sure the unit is absolutely attached to the mounting bracket. -3- 1 Monitor icon Allows you to monitor the door stations, cameras. Close icon Touch to turn off the screen. 16 Intercom icon Allows you to call other indoor station. About icon Allows you to view the information about device. 27 Setting icon Use to change the indoor station's settings. Logo Shows "2EASY-IX" by default. Means the brand of indoor station. Can be customized. 49 Call Record icon Allows you to view the call record. Status bar Displays icons that indicate the indoor station's status(see 4. Status bar icons(page4)). 38 Call Scene icon Allows you to activate the functions of No disturb, Divert. Shortcut windows Touch to enter the corresponding items directly. 510 23 4 5 678 9 10 -4- IconDescription Missed call Display when there is missed call unread. Touch to review the missed call in shortcut. No disturb Indicates the device is in “No disturb” mode. Divert call Indicates the device is in “Divert call” mode. Device onlineIndicates device online, but not connect to internet. Cloud server workedIndicates the device is connceted to the cloud server. No cloud serverIndicates the device is not connceted to the cloud server. Cloud server anomalyIndicates the device cloud server connection is abnormal. muteIndicates the device is in “Mute” mode. IconDescription RecordingIndicates the device is recording Talking Indicates the device is in “talking” status. Unlock Indicates open the corresponding door. 4. Status Bar Icons Other status icons -5- 2. When finished, Touch icon or press TALK/MON button again. 1.Receiving a call while talking with a door station 2.Receiving a call while talking with other monitors • Other door stations calling is forbidden • Conclude current talking to answer the new call-in • The talking will stop immediately, call tone sounds in normal. • The video image from the door station is displayed on the screen, talking,unlock,capture images/videos are available. Notes: Available functions while talking on a call • Door release • Manual recording 5. Answering a Call When you receive a call, the indoor station rings. Image will be displayed on the screen. 1. Touch icon or press TALK/MON button. Speak within about 50 cm of the microphone. Begin communicating hands free with the visitor for 90 seconds. -6- 6. Monitoring 7. Favoriate Setting 1. From the main menu, tap "Monitor" icon. 2. Select the desired tap. - Allows you to select door station camera or IP camera( if the system installs multi door station or IP camera) . 3. Select the desired camera. 4. When finished, tap button on panel. Note: Tap monitor quick actions to monitor corresponding camera directly(If the monitor quick actions is set on the shortcut windows). This section can be used to monitor your home by enabling one of the cameras inside the apartment, the common areas (e.g. garages, garden), and at the entrance. This section can be used to set your favoriate. * During monitoring, images can be viewed, but audio cannot be heard. Available functions during monitoring: • Door release • Manual recording 1. From the main menu, tap "Monitor" icon. - A list of available setting categories is displayed. 2. Select "Monitor" item. 3. Click the upper left corner of the item you need to select, and then the " " icon will appear. 4. If you need to cancel, click the upper left corner again. -7- 8. PIP View Precondition: this function requires the system to access the cameras or set the camera proxy settings. The picture-in-picture display allows the user to see two images from different sources at the same time during the call, which is convenient for the user to see the visitor intuitively and concretely. Feature of PIP view: - in call mode - Picture in picture to avoid dead corner - Able to watch both view from door station and IP camera - Swap the two images by a simple touch Press call button on door station Monitor Monitor Favorite Quad DS1DS2DS3DS4 Monitor Monitor Favorite Quad DS1DS2DS3DS4 -8- 9. Quad View Precondition: this function requires the system to access the cameras or set the camera proxy settings. The Quad display allows the user to quickly and simultaneously view four images from different video resource, and to quickly switch & zoom in on a screen by one click. Monitor Monitor Favorite Quad DS1DS2DS3DS4 Feature of quad view: - In monitor mode - Able to…

Text truncated - open the document above for the full version.

GuangzhouVideo-TechElectronicsCo.,Ltd DeclarationonModelDifferences We, GuangzhouVideo-TechElectronicsCo.,Ltd 201/Building1,No.8LianhuayanRoad,HuangpuDistrict,Guangzhou510663,China Declarethatthefollowingproduct(s): FCCID:2A7BN-IX482 ProductName:VIDEODOORPHONESYSTEM ModelNo.:IX482,IX470,IX850,IX610,IX471S,IX471,IX471-HS(GL),IX439S,IX439, IX481,IPG,IX850S,IX821,821-DX2,IX-LIFT,IX-RLC Utilizetheidenticalcircuitdesign,PCBlayout,shieldingandinterfacewith(IX482),onlythe modenamedifferent.Thereforethisapplicationcanberegardedasidenticalinperformance tothesubmittedtestsample. Themanufacturerwouldtakealltheresponsibilitiesfortheaboveproduct(s). Forandonbehalfof Authorizedperson Name:JeffZhao Position:Sales Dateofissue:8/10/2022 *IherebydeclarethatIamentitledtosignonbehalfoftheapplicantandthattheinformationsuppliediscorrectandcomplete.

GuangzhouVideo-TechElectronicsCo.,Ltd AgentAuthorizationLetter (2022-09-22) RE:LETTEROFAGENTAUTHORIZATION ToWhomItMayConcern: We,authorizeMicomLabsInc.,575BoulderCourt,Pleasanton,California94566, USAtoactonourbehalfinallmattersrelatingtoapplicationforequipment authorization,includingthesigningofalldocumentsrelatingtothesematters. Thisagreementexpiresoneyearfromthecurrentdate. Sincerely, JeffZhao/Sales CompanyName:GuangzhouVideo-TechElectronicsCo.,Ltd Address:201/Building1,No.8LianhuayanRoad,HuangpuDistrict,Guangzhou 510663,China

GuangzhouVideo-TechElectronicsCo.,Ltd OfficeofEngineeringTechnology FederalCommunicationsCommission 7435OaklandMillsRoad Columbia,MD21046 USA Date:2022-09-22 Subject;RequestforConfidentiality FCCID:2A7BN-IX482 ToWhomItMayConcern, PursuanttotheprovisionsoftheCommission’srulesTitle47Sections§0.457and§0.459,we arerequestingtheCommissiontowithholdthefollowingattachment(s)asconfidential documentsfrompublicdisclosureindefinitely. Thesedocumentscontaindetailedsystemandequipmentdescriptionsandareconsideredas proprietaryinformationinoperationoftheequipment.Thepublicdisclosureofthesedocuments mightbeharmfultoourcompanyandwouldgivecompetitorsanunfairadvantageinthemarket. SchematicDiagram BlockDiagram OperationalDescription SWSECURITYDESCRIPTION PartsList Tuneup Inadditionaltoabovementioneddocuments,inordertocomplywiththemarketingregulations inTitle47CFR§2.803andtheimportationrulesinTitle47CFR§2.1204,whileensuringthat businesssensitiveinformationremainsconfidentialuntiltheactualmarketingofnewly authorizeddevices,werequestShortTermConfidentialityofthefollowingattachment(s); ExternalPhotos TestSetupPhotos InternalPhotos UserManual For45days,pursuanttoPublicNoticeDA04-1705. OR For180dayspursuanttoKDB726920D01. Itisourunderstandingthatallmeasurementtestreports,FCCIDlabelformatand correspondenceduringthecertificationreviewprocesscannotbegrantedasconfidential documentsandthisinformationwillbeavailableforpublicreviewoncethegrantofequipment authorizationisissued. Sincerely, Signature JeffZhao Sales

FCCID:2A7BN-IX482

FCCID:2A7BN-IX482 ANT

RFEXPOSUREEVALUATION AccordingtoFCC1.1310:Thecriterialistedinthefollowingtableshallbeusedto evaluatetheenvironmentimpactofhumanexposuretoradiofrequency(RF)Radiation asspecifiedin§1.1307(b) FCCID:2A7BN-IX482 EUTSpecification EUTWifiDigitalPhotoFrame Frequencyband(Operating)WLAN:2.412GHz~2.462GHz WLAN:5.18GHz~5.24GHz WLAN:5.745GHz~5.825GHz Others: DevicecategoryPortable(<20cmseparation) Mobile(>20cmseparation) Others___ ExposureclassificationOccupational/Controlledexposure(S=5mW/cm2) GeneralPopulation/Uncontrolledexposure(S=1mW/cm2) AntennadiversitySingleantenna Multipleantennas Txdiversity Rxdiversity Tx/Rxdiversity Antennagain(Max) 5dBi EvaluationappliedMPEEvaluation SAREvaluation LimitsforMaximumPermissibleExposure(MPE) Frequency Range(MHz) ElectricField Strength(V/m) MagneticField Strength(A/m) Power Density(mW/cm 2 ) Average Time (A)LimitsforOccupational/ControlExposures 300-1500----F/3006 1500-100000----56 (B)LimitsforGeneralPopulation/UncontrolExposures 300-1500----F/15006 1500-100000----130 Friistransmissionformula:Pd=(Pout*G)\(4*pi*R2) Where Pd=PowerdensityinmW/cm 2 Pout=outputpowertoantennainMw G=gainofantennainlinearscale Pi=3.1416 R=distancebetweenobservationpointandcenteroftheradiatorincm PdthelimitofMPE,1mW/cm2.Ifweknowthemaximumgainoftheantennaand totalpowerinputtotheantenna,throughthecalculation,wewillknowthedistance wheretheMPElimitisreached. MaxMeasurementResult Operating Mode Measured Power Tuneup tolerance Max.Tune upPower Antenna Gain Power densityat 20cm Power densityLimits (mW/cm2) (dBm)(dBm)(dBm)(dBi)(mW/cm2) 2.4GWIFI 17.3017.30 ±118.3050.0268 1 Result:NoStandaloneSARtestisrequired.

ReportNo.:18220WC20119701FCCID:2A7BN-IX482Page1of41 Code:AB-RF-05-a FCCTestReport ClientName:GuangzhouVideo-TechElectronicsCo.,Ltd ClientAddress: 201/Building1,No.8LianhuayanRoad, HuangpuDistrict,Guangzhou510663,China ProductName:VIDEODOORPHONESYSTEM ReportDate:Aug.10,2022 ShenzhenAnbotekComplianceLaboratoryLimited ReportNo.:18220WC20119701FCCID:2A7BN-IX482Page2of41 Code:AB-RF-05-a Contents 1.GeneralInformation ..............................................................................................................................................5 1.1.ClientInformation .......................................................................................................................................5 1.2.DescriptionofDevice(EUT) ....................................................................................................................5 1.3.AuxiliaryEquipmentUsedDuringTest ...................................................................................................6 1.4.DescriptionofTestModes ........................................................................................................................6 1.5.Listofchannels ..........................................................................................................................................7 1.6.DescriptionOfTestSetup .........................................................................................................................8 1.7.TestEquipmentList ...................................................................................................................................9 1.8.MeasurementUncertainty ......................................................................................................................10 1.9.DescriptionofTestFacility .....................................................................................................................10 2.SummaryofTestResults ...................................................................................................................................11 3.ConductedEmissionTest ..................................................................................................................................12 3.1.TestStandardandLimit ..........................................................................................................................12 3.2.TestSetup .................................................................................................................................................12 3.3.TestProcedure .........................................................................................................................................12 4.RadiationSpuriousEmissionandBandEdge ...............................................................................................15 4.1.TestStandardandLimit ..........................................................................................................................15 4.2.TestSetup .................................................................................................................................................15 4.3.TestProcedure .........................................................................................................................................16 4.4.TestData ...................................................................................................................................................17 5.MaximumOutputPowerTest ............................................................................................................................26 5.1.TestStandardandLimit ..........................................................................................................................26 5.2.TestSetup .................................................................................................................................................26 5.3.TestProcedure .........................................................................................................................................26 5.4.TestData ...................................................................................................................................................26 6.6DBOccupyBandwidthTest .............................................................................................................................27 6.1.TestStandardandLimit ..........................................................................................................................27 6.2.TestSetup .................................................................................................................................................27 6.3.TestProcedure .........................................................................................................................................27 6.4.TestData ...................................................................................................................................................27 7.PowerSpectralDensityTest .............................................................................................................................28 7.1.TestStandardandLimit ..........................................................................................................................28 7.2.TestSetup .................................................................................................................................................28 7.3.TestProcedure .........................................................................................................................................28 7.4.TestData ...................................................................................................................................................28 8.100kHzBandwidthofFrequencyBandEdgeRequirement ........................................................................29 8.1.TestStandardandLimit .........................…

Text truncated - open the document above for the full version.

ReportNo.:18220WC20119701FCCID:2A7BN-IX482Page1of41 Code:AB-RF-05-a FCCTestReport ClientName:GuangzhouVideo-TechElectronicsCo.,Ltd ClientAddress: 201/Building1,No.8LianhuayanRoad, HuangpuDistrict,Guangzhou510663,China ProductName:VIDEODOORPHONESYSTEM ReportDate:Aug.10,2022 ShenzhenAnbotekComplianceLaboratoryLimited ReportNo.:18220WC20119701FCCID:2A7BN-IX482Page2of41 Code:AB-RF-05-a Contents 1.GeneralInformation ..............................................................................................................................................5 1.1.ClientInformation .......................................................................................................................................5 1.2.DescriptionofDevice(EUT) ....................................................................................................................5 1.3.AuxiliaryEquipmentUsedDuringTest ...................................................................................................6 1.4.DescriptionofTestModes ........................................................................................................................6 1.5.Listofchannels ..........................................................................................................................................7 1.6.DescriptionOfTestSetup .........................................................................................................................8 1.7.TestEquipmentList ...................................................................................................................................9 1.8.MeasurementUncertainty ......................................................................................................................10 1.9.DescriptionofTestFacility .....................................................................................................................10 2.SummaryofTestResults ...................................................................................................................................11 3.ConductedEmissionTest ..................................................................................................................................12 3.1.TestStandardandLimit ..........................................................................................................................12 3.2.TestSetup .................................................................................................................................................12 3.3.TestProcedure .........................................................................................................................................12 4.RadiationSpuriousEmissionandBandEdge ...............................................................................................15 4.1.TestStandardandLimit ..........................................................................................................................15 4.2.TestSetup .................................................................................................................................................15 4.3.TestProcedure .........................................................................................................................................16 4.4.TestData ...................................................................................................................................................17 5.MaximumOutputPowerTest ............................................................................................................................26 5.1.TestStandardandLimit ..........................................................................................................................26 5.2.TestSetup .................................................................................................................................................26 5.3.TestProcedure .........................................................................................................................................26 5.4.TestData ...................................................................................................................................................26 6.6DBOccupyBandwidthTest .............................................................................................................................27 6.1.TestStandardandLimit ..........................................................................................................................27 6.2.TestSetup .................................................................................................................................................27 6.3.TestProcedure .........................................................................................................................................27 6.4.TestData ...................................................................................................................................................27 7.PowerSpectralDensityTest .............................................................................................................................28 7.1.TestStandardandLimit ..........................................................................................................................28 7.2.TestSetup .................................................................................................................................................28 7.3.TestProcedure .........................................................................................................................................28 7.4.TestData ...................................................................................................................................................28 8.100kHzBandwidthofFrequencyBandEdgeRequirement ........................................................................29 8.1.TestStandardandLimit .........................…

Text truncated - open the document above for the full version.

Page 1 of 37 Appendix Test Data Report No.:18220WC20119701 Test Sample No.:1-2-2 Start Test Date:2022.6.7Finish Test Date:2022.6.10 Test Engineer:Auditor: Temperature:22.5 °C Relative Humidity: 53.6 % Pressure:1012 hPa Appendix A: DTS Bandwidth Test Result TestModeAntennaChannel DTSBW [MHz] FL[MHz]FH[MHz]Limit[MHz]Verdict 11BAnt1 24129.1602407.4002416.560≥0.5PASS 24379.6002432.4402442.040≥0.5PASS 24629.6402457.4402467.080≥0.5PASS 11GAnt1 241216.4402403.8002420.240≥0.5PASS 243716.4002428.8002445.200≥0.5PASS 246216.4402453.8002470.240≥0.5PASS 11N20Ant1 241217.6802403.1602420.840≥0.5PASS 243717.6802428.2002445.880≥0.5PASS 246217.6402453.2002470.840≥0.5PASS Page 2 of 37 Test Graphs 11B_Ant1_2412 11B_Ant1_2437 11B_Ant1_2462 Page 3 of 37 11G_Ant1_2412 11G_Ant1_2437 Page 4 of 37 11G_Ant1_2462 11N20_Ant1_2412 11N20_Ant1_2437 Page 5 of 37 11N20_Ant1_2462 Page 6 of 37 Appendix B: Occupied Channel Bandwidth Test Result TestModeAntennaChannel OCB[MHz] FL[MHz]FH[MHz]Limit[MHz]Verdict 11BAnt1 241212.3852405.8452418.230---PASS 243712.3782430.8962443.274---PASS 246212.3152455.8772468.192---PASS 11GAnt1 241217.1612403.4162420.577---PASS 243717.0752428.5502445.625---PASS 246217.0862453.4912470.577---PASS 11N20Ant1 241217.9892403.0282421.017---PASS 243718.0052428.0222446.027---PASS 246217.9162453.0572470.973---PASS Page 7 of 37 Test Graphs 11B_Ant1_2412 11B_Ant1_2437 11B_Ant1_2462 Page 8 of 37 11G_Ant1_2412 11G_Ant1_2437 Page 9 of 37 11G_Ant1_2462 11N20_Ant1_2412 11N20_Ant1_2437 Page 10 of 37 11N20_Ant1_2462 Page 11 of 37 Appendix C: Maximum conducted output power Test Result TestModeAntennaChannelResult[dBm]Limit[dBm]Verdict 11BAnt1 241216.59≤30PASS 243716.90≤30PASS 246217.30≤30PASS 11GAnt1 241213.87≤30PASS 243713.75≤30PASS 246214.06≤30PASS 11N20Ant1 241213.89≤30PASS 243713.77≤30PASS 246214.22≤30PASS Page 12 of 37 Appendix D: Maximum power spectral density Test Result TestModeAntennaChannelResult[dBm/3kHz]Limit[dBm/3kHz]Verdict 11BAnt1 2412-8.98≤8PASS 2437-7.05≤8PASS 2462-7.86≤8PASS 11GAnt1 2412-17.37≤8PASS 2437-18.25≤8PASS 2462-17.82≤8PASS 11N20Ant1 2412-19.02≤8PASS 2437-18.05≤8PASS 2462-15.95≤8PASS Page 13 of 37 Test Graphs 11B_Ant1_2412 11B_Ant1_2437 11B_Ant1_2462 Page 14 of 37 11G_Ant1_2412 11G_Ant1_2437 Page 15 of 37 11G_Ant1_2462 11N20_Ant1_2412 11N20_Ant1_2437 Page 16 of 37 11N20_Ant1_2462 Page 17 of 37 Appendix E: Band edge measurements Test Result TestModeAntennaChNameChannelRefLevel[dBm]Result[dBm]Limit[dBm]Verdict 11BAnt1 Low24124.68-44.28≤-15.32 PASS High24625.78-54.96≤-14.22 PASS 11GAnt1 Low2412-4.33-50.65≤-24.33 PASS High2462-4.98-55.72≤-24.98 PASS 11N20Ant1 Low2412-4.29-49.27≤-24.29 PASS High2462-4.31-54.88≤-24.31 PASS Page 18 of 37 Test Graphs 11B_Ant1_Low_2412 11B_Ant1_High_2462 11G_Ant1_Low_2412 Page 19 of 37 11G_Ant1_High_2462 11N20_Ant1_Low_2412 Page 20 of 37 11N20_Ant1_High_2462 Page 21 of 37 Appendix F: Conducted Spurious Emission Test Result TestModeAntennaChannel FreqRange [Mhz] RefLevel [dBm] Result [dBm] Limit [dBm] Verdict 11BAnt1 2412 Reference4.874.87---PASS 30~10004.87-70.4≤-15.13PASS 1000~265004.87-52.92≤-15.13PASS 2437 Reference4.734.73---PASS 30~10004.73-70.58≤-15.27PASS 1000~265004.73-53.58≤-15.27PASS 2462 Reference5.395.39---PASS 30~10005.39-70.22≤-14.61PASS 1000~265005.39-55.35≤-14.61PASS 11GAnt1 2412 Reference-5.22-5.22---PASS 30~1000-5.22-70.72≤-25.22PASS 1000~26500-5.22-54.86≤-25.22PASS 2437 Reference-4.67-4.67---PASS 30~1000-4.67-70.01≤-24.67PASS 1000~26500-4.67-53.78≤-24.67PASS 2462 Reference-3.78-3.78---PASS 30~1000-3.78-60.24≤-23.78PASS 1000~26500-3.78-55.32≤-23.78PASS 11N20Ant1 2412 Reference-4.97-4.97---PASS 30~1000-4.97-70.22≤-24.97PASS 1000~26500-4.97-55.55≤-24.97PASS 2437 Reference-4.51-4.51---PASS 30~1000-4.51-68.67≤-24.51PASS 1000~26500-4.51-54.75≤-24.51PASS 2462 Reference-4.83-4.83---PASS 30~1000-4.83-69.49≤-24.83PASS 1000~26500-4.83-55.19≤-24.83PASS Page 22 of 37 Test Graphs 11B_Ant1_2412_0~Reference 11B_Ant1_2412_30~1000 11B_Ant1_2412_1000~26500 Page 23 of 37 11B_Ant1_2437_0~Reference 11B_Ant1_2437_30~1000 Page 24 of 37 11B_Ant1_2437_1000~26500 11B_Ant1_2462_0~Reference 11B_Ant1_2462_30~1000 Page 25 of 37 11B_Ant1_2462_1000~26500 11G_Ant1_2412_0~Reference Page 26 of 37 11G_Ant1_2412_30~1000 11G_Ant1_2412_1000~26500 11G_Ant1_2437_0~Reference Page 27 of 37 11G_Ant1_2437_30~1000 11G_Ant1_2437_1000~26500 Page 28 of 37 11G_Ant1_2462_0~Reference 11G_Ant1_2462_30~1000 11G_Ant1_2462_1000~26500 Page 29 of 37 11N20_Ant1_2412_0~Reference 11N20_Ant1_2412_30~1000 Page 30 of 37 11N20_Ant1_2412_1000~26500 11N20_Ant1_2437_0~Reference 11N20_Ant1_2437_30~1000 Page 31 of 37 11N20_Ant1_2437_1000~26500 11N20_Ant1_2462_0~Reference Page 32 of 37 11N20_Ant1_2462_30~1000 11N20_Ant1_2462_1000~26500 Page 33 of 37 Appendix G: Duty Cycle Test Result TestModeAntennaChannel Transmission Duration [ms] Transmission Period [ms] Duty Cycle [%] LimitVerdict 11BAnt1 24128.398.4199.76---PASS 24378.398.4299.64---PASS 24628.398.4199.76---PASS 11GAnt1 24121.391.4397.20---PASS 24371.391.4397.20---PASS 24621.391.4397.20---PASS 11N20Ant1 24121.301.3397.74---PASS 24371.301.3497.01---PASS 24621.301.3497.01---PASS Page 34 of 37 Test Graphs 11B_Ant1_2412 11B_Ant1_2437 11B_Ant1_2462 Page 35 of 37 11G_Ant1_2412 11G_Ant1_2437 Page 36 of 37 11G_Ant1_2462 11N20_Ant1_2412 11N20_Ant1_2437 Page 37 of 37 11N20_Ant1_2462 ‐‐‐End‐‐‐

Page 1 of 37 Appendix Test Data Report No.:18220WC20119701 Test Sample No.:1-2-2 Start Test Date:2022.6.7Finish Test Date:2022.6.10 Test Engineer:Auditor: Temperature:22.5 °C Relative Humidity: 53.6 % Pressure:1012 hPa Appendix A: DTS Bandwidth Test Result TestModeAntennaChannel DTSBW [MHz] FL[MHz]FH[MHz]Limit[MHz]Verdict 11BAnt1 24129.1602407.4002416.560≥0.5PASS 24379.6002432.4402442.040≥0.5PASS 24629.6402457.4402467.080≥0.5PASS 11GAnt1 241216.4402403.8002420.240≥0.5PASS 243716.4002428.8002445.200≥0.5PASS 246216.4402453.8002470.240≥0.5PASS 11N20Ant1 241217.6802403.1602420.840≥0.5PASS 243717.6802428.2002445.880≥0.5PASS 246217.6402453.2002470.840≥0.5PASS Page 2 of 37 Test Graphs 11B_Ant1_2412 11B_Ant1_2437 11B_Ant1_2462 Page 3 of 37 11G_Ant1_2412 11G_Ant1_2437 Page 4 of 37 11G_Ant1_2462 11N20_Ant1_2412 11N20_Ant1_2437 Page 5 of 37 11N20_Ant1_2462 Page 6 of 37 Appendix B: Occupied Channel Bandwidth Test Result TestModeAntennaChannel OCB[MHz] FL[MHz]FH[MHz]Limit[MHz]Verdict 11BAnt1 241212.3852405.8452418.230---PASS 243712.3782430.8962443.274---PASS 246212.3152455.8772468.192---PASS 11GAnt1 241217.1612403.4162420.577---PASS 243717.0752428.5502445.625---PASS 246217.0862453.4912470.577---PASS 11N20Ant1 241217.9892403.0282421.017---PASS 243718.0052428.0222446.027---PASS 246217.9162453.0572470.973---PASS Page 7 of 37 Test Graphs 11B_Ant1_2412 11B_Ant1_2437 11B_Ant1_2462 Page 8 of 37 11G_Ant1_2412 11G_Ant1_2437 Page 9 of 37 11G_Ant1_2462 11N20_Ant1_2412 11N20_Ant1_2437 Page 10 of 37 11N20_Ant1_2462 Page 11 of 37 Appendix C: Maximum conducted output power Test Result TestModeAntennaChannelResult[dBm]Limit[dBm]Verdict 11BAnt1 241216.59≤30PASS 243716.90≤30PASS 246217.30≤30PASS 11GAnt1 241213.87≤30PASS 243713.75≤30PASS 246214.06≤30PASS 11N20Ant1 241213.89≤30PASS 243713.77≤30PASS 246214.22≤30PASS Page 12 of 37 Appendix D: Maximum power spectral density Test Result TestModeAntennaChannelResult[dBm/3kHz]Limit[dBm/3kHz]Verdict 11BAnt1 2412-8.98≤8PASS 2437-7.05≤8PASS 2462-7.86≤8PASS 11GAnt1 2412-17.37≤8PASS 2437-18.25≤8PASS 2462-17.82≤8PASS 11N20Ant1 2412-19.02≤8PASS 2437-18.05≤8PASS 2462-15.95≤8PASS Page 13 of 37 Test Graphs 11B…

Text truncated - open the document above for the full version.
