2A7E4-EM2301Wearable Display

Electron Mint User Manual FCC ID: 2A7E4-EM2301 1 Important safety precautions Failure to comply with the following precautions may be dangerous or illegal Drive safely at all times Do not use a hand-held device while driving. Park your vehicle first. Switch off the device when refueling Do not use the eBling device at a re-fueling point (service station) or near fuels or chemicals. Switch off in an aircraft Wireless devices can cause interference. Using them in an aircraft is both illegal and dangerous. Switch off the device near all medical equipment Hospitals or health care facilities may be using equipment that could be sensitive to external radio frequency energy. Follow any regulations or rules in force. Interference All wireless devices may be subject to interference, which could affect their performance. Be aware of special regulations Meet any special regulations in force in any area and always switch off your device whenever it is forbidden to use it, or when it may cause interference or danger. Water resistance Your device is not water-resistant. Keep it dry. Sensible use Use only in the normal position. Keep your eBling away from small children Keep the device and all its parts, including the chain and accessories, out of the reach of small children. 2 Accessories and batteries This device contains a non-user serviceable lithium ion battery. Use only Electron Mint-approved accessories, such as USB cables. Use of any unauthorized accessories could damage you or your device and may be dangerous. 3 Unpack Make sure you have each item ●eBling Device ●Neck Chain ●Chain Ring ●USB-C cable Get Started First steps to operate your device: Charge the eBling 1.Plug the USB-C cable into the back of the eBling device 2.Plug the other end of the cable into a USB outlet 3.When the device is fully charged, unplug the cable from the USB outlet 4.Remove the other end of the USB-C cable from the eBling device. Low Battery indicator The battery charge level is displayed from the Electron Mint App. Connect your eBling to the App to check battery status. If the battery level is almost depleted, the eBling device will display a Low Battery status message and power itself off after a few seconds. If you encounter this state, plug your eBling device in to charge. Buttons and Display Input ButtonsFunctionLocation Power-Press Power Button to turn device on/off -See-below for additional specific context options Back of the device Reset-System Reset button. Push using a small wire. Small Hole on back of the device. Touch screen-Long press (1sec) left half of the screen to advance to the next image/video -Long press (1sec) the right half of the screen to go back to previous image/video -See-below for additional specific context options Screen on the front 4 Discovery and Connection to your eBling Status Screen Your eBling device will wirelessly advertise withthe name “eBling”. This name will be displayed in the discovered devices section of the Electron Mint App. If multiple eBling devices are in the same area you can temporarily uniquely identify your device by entering the Status Screen before discovering the device from the App. To enter the Status screen, long press and hold anywhere on the touch screen for about 10 seconds. This will bring up the Status Screen, which shows a field “ID:xxxxx”, where xxxxx represents a random 5 digit number. While this screen is active your eBling device will advertise with the name “eBling xxxxx” and will show up in the App’s discovered devices with that name. Once discovery and connection is complete, long press anywhere on the display to exit the Status Screen and reset the advertised name to “eBling”. Additional information on the status screen is the device firmware version number, FCCID, and Electron Mint web site address. See “FCC ID” section below for an example of this information. Connecting to your eBling Follow instructions in the Electron Mint App to complete the connection process. Solve problems To save the time and expense of an unnecessary service call, perform the simple checks in this section before contacting a service professional. Is your eBling device charged? Is the eBling screen brightness set to greater than zero? Do you have the latest version of the Electron Mint mobile app? Do you have the latest firmware installed on the eBling device? Is wireless device connectivity turned on in your mobile device? Is your mobile device on? Is your mobile device charged? Factory Reset 5 In the case that you would like to erase all user data from your eBling device, you can do so using the Factory Reset operation. To enter the “Factory Reset” mode, do the following: 1)Press and release the power button to turn off the device. Wait at least one second. 2)Press and hold the power button to turn on the device. Continue to hold the power button until the “Factory Reset” screen appears (after the initial power up screen). 3)To reset all information stored on the device, select “YES”. This operation may take up to 45 seconds depending on the amount of data stored. 4)Select “No” to cancel and return to normal operation. Using Your eBling Near Other Electronic Devices Most modern electronic equipment is shielded from radio frequency (RF) signals. However, certain electronic equipment may not be shielded against the RF signals from your wireless phone or devices. Consult the manufacturer to discuss alternatives. Pacemakers Pacemaker manufacturers recommend that a minimum distance of 15 cm (6 inches) be maintained between wireless devices and a pacemaker to avoid potential interference with the pacemaker. These recommendations are consistent with the independent research and recommendations of Wireless Technology Research. If you have any reason to suspect that interference is taking place, switch off your eBling device immediately. Persons with pacemakers: • should always keep the eBling device more than 15 cm (6 inches) from their pacemaker when the device is switch…

Text truncated - open the document above for the full version.

Electron Mint LLC 17525 Community Street Northridge, CA 91325 Jan 27, 2023 CETCB 114 Olinda Drive Brea, CA 92823 Gentlemen: This is a letter of authorization to accept Compatible Electronics, Inc., specifically including the employees of Compatible Electronics, as an Agent for Electron Mint LLC. 17525 Community Street. Northridge, CA 91325 , for a period of one year, to sign applications before the Commission on our behalf, to make representations to you on our behalf, and to receive and exchange data between our company and the Commission in connection with certification of the following Electron Mint LLC product: FCC ID: 2A7E4-EM2301 eBling Wearable Display under FCC Docket Number 20780 and General Docket Number 80-284 pursuant to Part l5 of FCC Rules and Regulations. Please also accept this letter as an attestation that neither Electron Mint LLC nor any of its officers, directors, or persons holding 5% or more of the outstanding stock or shares, voting or non-voting, have been denied federal benefits under section 5301 of the Anti- Drug-Abuse act of 1988,21 U.S.C. 853(a). In addition, Electron Mint LLC will notify the Federal Communications Commission if, at any time, the situation changes causing Electron Mint LLC to be denied federal benefits. If you have any further questions or need additional information, please feel free to give me a call at (310-469-4396). Sincerely, Nathan Cook Partner 1

Electron Mint LLC 17525 Community Street Northridge, CA 91325 Jan 27, 2023 Compatible Electronics TCB 114 Olinda Drive Brea, California 92823 Subject: TCB application submittal Gentlemen: We, Electron Mint LLC, would like to declare that the application being submitted for the device with FCC ID: 2A7E4-EM2301 , has not been submitted to another TCB or FCC for certification. If you have any questions, please do not hesitate to contact us at 310-469-4396. Sincerely, Nathan Cook Partner 1

Electron Mint LLC 17525 Community Street Northridge, CA 91325 Feb 22, 2023 Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, Maryland 21046 FCC ID: 2A7E4-EM2301 Subject: Attestation Statement pursuant to Part 2.911 (d)(7) This letter is to confirm that we, Electron Mint LLC, designate ourselves to act as our U.S. agent for service of process and that we are aware of the requirements involved in Part 2.911(d)(7) and described in FCC 22-84 and KDB 986446. Applicant/US Agent Company Name: Electron Mint LLC Contact Name: Nathan Cook Address: 17525 Community Street Northridge, CA 91325 Telephone Number: 310-469-4396 E-Mail: [email protected] Sincerely, Nathan Cook Partner 1

Electron Mint LLC 17525 Community Street Northridge, CA 91325 Feb 22, 2023 Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, Maryland 21046 FCC ID: 2A7E4-EM2301 Subject: Attestation Statements pursuant to Part 2.911 (d)(5)(i) Electron Mint LLC, 17525 Community Street, Northridge, CA certifies that the equipment for which authorization is sought is not “covered” equipment prohibited from receiving an equipment authorization pursuant to section 2.903 of the FCC rules and according to FCC 22-84 and KDB 986446. Sincerely, Nathan Cook Partner 1

Electron Mint LLC 17525 Community Street Northridge, CA 91325 Feb 22, 2023 Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, Maryland 21046 FCC ID: 2A7E4-EM2301 Subject: Attestation Statements pursuant to Part 2.911 (d)(5)(ii) Electron Mint LLC, 17525 Community Street, Northridge, CA certifies that as of the date of the filing of the application, the applicant is not identified on the Covered List 1 as an entity producing “covered” equipment according to FCC 22-84 and KDB 986446. Sincerely, Nathan Cook Partner 1 The Commission’s Covered List is published by the Public Safety and Homeland Security Bureau and posted on the Commission’s website. This Covered List, which is periodically updated, identifies particular equipment, produced by particular entities, that constitutes “covered” equipment. https://www.fcc.gov/supplychain/coveredlist 1

Electron Mint LLC 17525 Community Street Northridge, CA 91325 March 10, 2023 Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, Maryland 21046 FCC ID: 2A7E4-EM2301 Date of TCB Filing – February 7, 2023 Subject: Attestation Statement pursuant to Part 2.911 (d)(7) Electron Mint LLC certifies that, as of the date of this filing of the application with the TCB, Electron Mint LLC is our designated US agent for service of process for the above referenced FCC ID. Electron Mint LLC accepts to maintain an agent for no less than one year after the grantee has terminated all marketing and importation or the conclusion of any commission related proceeding involving equipment. Electron Mint LLC accepts, as of the date of the filing of the application, the obligation of the designated US agent for service of process for the above reference FCC ID. This letter is to confirm that Electron Mint LLC ”applicant”, as of the date of this filing, has a US agent for the purpose of accepting service of process as required in Part 2.911(d)(7). Applicant Company Name: Electron Mint LLC Contact Name: Nathan Cook Address: 17525 Community Street, Northridge, CA 91325 Telephone Number: 310-469-4396 E-Mail: [email protected] US Agent Company Name: Electron Mint LLC Contact Name: Nathan Cook Address: 17525 Community Street, Northridge, CA 91325 Telephone Number: 310-469-4396 E-Mail: [email protected] FRN: 0032542847 Grantee Code: 2A7E4 Sincerely, Applicant/GranteeUS Agent Electron Mint LLCElectron Mint LLC Nathan CookNathan Cook PartnerPartner [email protected]@electronmint.com 1

Electron Mint LLC 17525 Community Street Northridge, CA 91325 March 10, 2023 Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, Maryland 21046 FCC ID: 2A7E4-EM2301 Date of TCB Filing – February 7, 2023 Subject: Attestation Statement pursuant to Part 2.911 (d)(7) Electron Mint LLC certifies that, as of the date of this filing of the application with the TCB, Electron Mint LLC is our designated US agent for service of process for the above referenced FCC ID. Electron Mint LLC accepts to maintain an agent for no less than one year after the grantee has terminated all marketing and importation or the conclusion of any commission related proceeding involving equipment. Electron Mint LLC accepts, as of the date of the filing of the application, the obligation of the designated US agent for service of process for the above reference FCC ID. This letter is to confirm that Electron Mint LLC ”applicant”, as of the date of this filing, has a US agent for the purpose of accepting service of process as required in Part 2.911(d)(7). Applicant Company Name: Electron Mint LLC Contact Name: Nathan Cook Address: 17525 Community Street, Northridge, CA 91325 Telephone Number: 310-469-4396 E-Mail: [email protected] US Agent Company Name: Electron Mint LLC Contact Name: Nathan Cook Address: 17525 Community Street, Northridge, CA 91325 Telephone Number: 310-469-4396 E-Mail: [email protected] FRN: 0032542847 Grantee Code: 2A7E4 Sincerely, Applicant/GranteeUS Agent Electron Mint LLCElectron Mint LLC Nathan CookNathan Cook PartnerPartner [email protected]@electronmint.com 1

Electron Mint LLC 17525 Community Street Northridge, CA 91325 March 10, 2023 Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, Maryland 21046 FCC ID: 2A7E4-EM2301 Date of TCB Filing – February 7, 2023 Subject: Attestation Statement pursuant to Part 2.911 (d)(7) Electron Mint LLC certifies that, as of the date of this filing of the application with the TCB, Electron Mint LLC is our designated US agent for service of process for the above referenced FCC ID. Electron Mint LLC accepts to maintain an agent for no less than one year after the grantee has terminated all marketing and importation or the conclusion of any commission related proceeding involving equipment. Electron Mint LLC accepts, as of the date of the filing of the application, the obligation of the designated US agent for service of process for the above reference FCC ID. This letter is to confirm that Electron Mint LLC ”applicant”, as of the date of this filing, has a US agent for the purpose of accepting service of process as required in Part 2.911(d)(7). Applicant Company Name: Electron Mint LLC Contact Name: Nathan Cook Address: 17525 Community Street, Northridge, CA 91325 Telephone Number: 310-469-4396 E-Mail: [email protected] US Agent Company Name: Electron Mint LLC Contact Name: Nathan Cook Address: 17525 Community Street, Northridge, CA 91325 Telephone Number: 310-469-4396 E-Mail: [email protected] FRN: 0032542847 Grantee Code: 2A7E4 Sincerely, Applicant/GranteeUS Agent Electron Mint LLCElectron Mint LLC Nathan CookNathan Cook PartnerPartner [email protected]@electronmint.com 1

                !  !!   "
#  $ # !  % &' ! ( )   %* +$,
%-
 $ . / 0   1 )   )2, !   3!  4 5 6767
   . !  ! .   .  ! .   .  33   8   / 0
  !  !  9  . !#  . 3!! .  )# . +$5
  3!       .  !!    .   !    '   3    !  .   !!   3  ##  : 35
  3! ! .   .  .   .  33    )   .  !  9  . !#  . 3!! .  )# . +$5 / !  !  .
  ;33 ; ! .   .  ! .   !  9  .  33! . 3  !#  . 3!! ! :   4 567675 33  3 ,
   ,  ' !!,         /3 ), -%*-%*
-  , < 5 9  3 ,
   ,  ' !!,         /3 ), -%*-%*
-  , < 5 (, %=% > ,
%   33 ?>9

   ' ' 44









                !  !!   "
#  $ # !  % &' ! ( )   %* +$,
%-
 $ . / 0   1 )   )2, !   3!  4 5 6767
   . !  ! .   .  ! .   .  33   8   / 0
  !  !  9  . !#  . 3!! .  )# . +$5
  3!       .  !!    .   !    '   3    !  .   !!   3  ##  : 35
  3! ! .   .  .   .  33    )   .  !  9  . !#  . 3!! .  )# . +$5 / !  !  .
  ;33 ; ! .   .  ! .   !  9  .  33! . 3  !#  . 3!! ! :   4 567675 33  3 ,
   ,  ' !!,         /3 ), -%*-%*
-  , < 5 9  3 ,
   ,  ' !!,         /3 ), -%*-%*
-  , < 5 (, %=% > ,
%   33 ?>9

   ' ' 44









Electron Mint LLC 17525 Community Street Northridge, CA 91325 Jan 27, 2023 Compatible Electronics TCB 114 Olinda Drive Brea, California 92823 Subject: Request for withholding from public disclosure the schematics, block diagrams, and operational description pursuant to an application for certification FCC ID: 2A7E4-EM2301 Gentlemen: We, Electron Mint LLC, would like to request that all schematics, block diagrams, and operational descriptions submitted with the application for certification be withheld from public disclosure as per Section 0.459 of FCC Rules. This request is made under the provisions of Section 0.457 (d) of the Commission’s Rules, and Section 552 (b)(4) of the Freedom of Information Act. These sections authorize the withholding from public inspection, those materials which would be privileged as a matter of law if retained by the person submitting them, and materials which would not customarily be released to the public by that person. If you have any questions, please do not hesitate to contact us at (310-469-4396). Sincerely, Nathan Cook Partner 1 Electron Mint LLC 17525 Community Street Northridge, CA 91325 Note: Normally schematics, detailed block diagrams, and detailed theories of operation are the only information held confidential. Internal photographs are only held confidential in certain circumstances where the access to the information isn’t available to the end user. Test reports, cover letters, external photos, ID labels, setup photos, attestation statements, and RF exposure reports will not be held confidential. 2

Top View of the EUT Bottom View of the EUT Side View #1 of the EUT Side View #2 of the EUT Side View #3 of the EUT Side View #4 of the EUT

Electron Mint LLC 17525 Community Street Northridge, CA 91325 Jan 27, 2023 Subject: FCC ID E-Label and Location for Device with FCC ID: 2A7E4-EM2301 Procedure: (These instructions are also in the user manual, along with additional compliance statement) To access the FCC ID on the device display, press and hold the touch screen for 10 seconds. This will draw the status screen as follows: 1 Electron Mint LLC 17525 Community Street Northridge, CA 91325 Feb 28, 2023 Subject: Packaging Drawing and Temporary FCCID Label FCC ID: 2A7E4-EM2301 The following is the design for the outer printed sleeve of the product box. Note FCC ID is printed on this sleeve. 1

Inside View of the EUT - #1 Inside View of the EUT - #2 Inside View of the EUT - View #3 Bottom View of Green PCB Botom View of the Green PCB - View #2 INside Vi View of Components on Flex Cable View of Components on Flex Cable - Opposite Side - View 1 View of Components on Flex Cable - Opposite Side - View 2 Top View of the Green PCB - Closeup View #1 Top View of the Green PCB - Closeup View #2 View of the Battery

Compatible Electronics, Inc.https://celectronics.com 114 Olinda Drive Brea, CA 92823 This device FCC ID: Prepared By: Date: The maximum power that the transmitter is capable of is 0.87 mW Applied duty cycle? no Using the following formula from section 4.3.1 of KDB 447498 at test separation distances ” 50 mm [(max. power of channel, including tune-up tolerance, mW) / (min. test separation distance, mm)] * [ ¥ f(GHz)] Duty Cycle 50.00% Value 1-g (mW) 10-g (mW) 0.27 (353) -208 "Value" shall be ” 3.0 for 1-g SAR and ” 7.5 for 10-g extremity SAR 1-g power limit 10-g power limit 97 242 “source-based” time-averaging based on an inherent property or duty-cycle of a device is allowed. An example of this is the determination of exposure from a device that uses digital technology such as a time-division multiple-access (TDMA) scheme for transmission of a 2A7E4-EM2301 Max Peak Power (dBm) Min Separation distance (mm) * Frequency (Ghz) < 50mm power limits for above frequency and distance When the minimum test separation distance is < 5 mm, a distance of 5 mm according to 5) in section 4.1 is applied to determine SAR test exclusion. 2.402 5 -0.63 SAREXJUST-B-0-43 D 02/27/2020 February 28, 2023 Kyle Fujimoto

Report Number: B30124D1 FCC Part 15 Subpart B and C; and FCC Section 15.247 Test Report Wearable Display Model: eBling Brea Division 114 Olinda Drive Brea, CA 92823 (714) 579-0500 Lake Forest Division 20621 Pascal Way Lake Forest, CA 92630 (949) 587-0400 Newbury Park Division 1050 Lawrence Drive Newbury Park, CA 91320 (805) 480-4044 Page 1 of 20 FCC PART 15, SUBPART B and C; and FCC SECTION 15.247 TEST REPORT for WEARABLE DISPLAY Model: eBling Prepared for ELECTRON MINT LLC 17525 COMMUNITY STREET NORTHRIDGE, CALIFORNIA 91325 Prepared by: _____________________ JAMES ROSS Approved by: ____________________ KYLE FUJIMOTO COMPATIBLE ELECTRONICS INC. 114 OLINDA DRIVE BREA, CALIFORNIA 92823 (714) 579-0500 DATE: MARCH 1, 2023 REPORT APPENDICES TOTAL BODY A B C D E PAGES 20 2 2 2 19 99 144 This report shall not be reproduced except in full, without the written approval of Compatible Electronics. Report Number: B30124D1 FCC Part 15 Subpart B and C; and FCC Section 15.247 Test Report Wearable Display Model: eBling Brea Division 114 Olinda Drive Brea, CA 92823 (714) 579-0500 Lake Forest Division 20621 Pascal Way Lake Forest, CA 92630 (949) 587-0400 Newbury Park Division 1050 Lawrence Drive Newbury Park, CA 91320 (805) 480-4044 Page 2 of 20 TABLE OF CONTENTS Section / Title PAGE GENERAL REPORT SUMMARY 4 SUMMARY OF TEST RESULTS 5 1. PURPOSE 6 1.1 DECISION RULE & RISK 6 2. ADMINISTRATIVE DATA 7 2.1 Location of Testing 7 2.2 Traceability Statement 7 2.3 Cognizant Personnel 7 2.4 Date Test Sample was Received 7 2.5 Disposition of the Test Sample 7 2.6 Abbreviations and Acronyms 7 3. APPLICABLE DOCUMENTS 8 4. DESCRIPTION OF TEST CONFIGURATION 9 4.1.1 Cable Construction and Termination 9 5. LISTS OF EUT, ACCESSORIES AND TEST EQUIPMENT 10 5.1 EUT and Accessory List 10 5.2 Emissions Test Equipment 11 6. TEST SITE DESCRIPTION 12 6.1 Test Facility Description 12 6.2 EUT Mounting, Bonding and Grounding 12 6.3 Measurement Uncertainty 12 7. CHARACTERISTICS OF THE TRANSMITTER 13 7.1 Channel Number and Frequencies 13 7.2 Antenna 13 8. TEST PROCEDURES 14 8.1 RF Emissions 14 8.1.1 Conducted Emissions Test 14 8.1.2 Radiated Emissions Test 15 8.1.3 RF Emissions Test Results 16 8.1.4 Sample Calculations 17 8.2 DTS Bandwidth 18 8.3 Maximum Peak Conducted Output Power 18 8.4 Emissions in Non-restricted Frequency Bands 19 8.5 RF Band Edges 19 8.6 Spectral Density Test 20 8.7 Variation of the Input Power 20 9. CONCLUSIONS 20 Report Number: B30124D1 FCC Part 15 Subpart B and C; and FCC Section 15.247 Test Report Wearable Display Model: eBling Brea Division 114 Olinda Drive Brea, CA 92823 (714) 579-0500 Lake Forest Division 20621 Pascal Way Lake Forest, CA 92630 (949) 587-0400 Newbury Park Division 1050 Lawrence Drive Newbury Park, CA 91320 (805) 480-4044 Page 3 of 20 LIST OF APPENDICES APPENDIX TITLE A Laboratory Accreditations and Recognitions B Modifications to the EUT C Models Covered Under This Report D Diagrams and Charts  Test Setup Diagrams  Antenna and Effective Gain Factors E Data Sheets LIST OF FIGURES FIGURE TITLE 1 Conducted Emissions Test Setup 2 Layout of the Semi-Anechoic Test Chamber LIST OF TABLES TABLE TITLE 1 Conducted Emission Results 2 Radiated Emission Results Report Number: B30124D1 FCC Part 15 Subpart B and C; and FCC Section 15.247 Test Report Wearable Display Model: eBling Brea Division 114 Olinda Drive Brea, CA 92823 (714) 579-0500 Lake Forest Division 20621 Pascal Way Lake Forest, CA 92630 (949) 587-0400 Newbury Park Division 1050 Lawrence Drive Newbury Park, CA 91320 (805) 480-4044 Page 4 of 20 GENERAL REPORT SUMMARY This electromagnetic emission test report is generated by Compatible Electronics Inc., which is an independent testing and consulting firm. The test report is based on testing performed by Compatible Electronics personnel according to the measurement procedures described in the test specifications given below and in the "Test Procedures" section of this report. The measurement data and conclusions appearing herein relate only to the sample tested and this report may not be reproduced without the written permission of Compatible Electronics, unless done so in full. This report must not be used by the client to claim product certification, approval or endorsement by NVLAP, NIST or any agency of the U.S. Government. Device Tested: Wearable Display Model: eBling S/N: N/A Product Description: The equipment under test is a wearable display with BLE connectivity. Clock Frequencies: 32.768 kHz, 16 MHz and 96 MHz. Dimensions (LxWxH): 2.3 in. x 2.3 in x 0.55 in. Modifications: The EUT was not modified in order to meet the specifications. Customer: Electron Mint LLC 17525 Community Street Northridge, California 91325 Test Dates: January 23, 24 and 25, 2023 Test Specification covered by accreditation: Test Specifications: Emissions requirements CFR Title 47, Part 15, Subpart B; and Subpart C, sections 15.205, 15.207, 15.209, and 15.247 Test Procedures: ANSI C63.4 and ANSI C63.10 Test Deviations: The test procedure was not deviated from during the testing. Report Number: B30124D1 FCC Part 15 Subpart B and C; and FCC Section 15.247 Test Report Wearable Display Model: eBling Brea Division 114 Olinda Drive Brea, CA 92823 (714) 579-0500 Lake Forest Division 20621 Pascal Way Lake Forest, CA 92630 (949) 587-0400 Newbury Park Division 1050 Lawrence Drive Newbury Park, CA 91320 (805) 480-4044 Page 5 of 20 SUMMARY OF TEST RESULTS TEST DESCRIPTION RESULTS 1 Conducted RF Emissions, 150 kHz - 30 MHz Complies with the Class B limits of CFR Title 47, Part 15 Subpart B; the limits of CFR Title 47, Part 15, and Subpart C, section 15.207 See section 6.3 for Measurement Uncertainty 2 Radiated RF Emissions, 9 kHz – 25000 MHz Complies with the Class B limits of CFR Title 47, Part 15, Subpart B; and the limits of CFR Title 47, Part 15 Subpart C, 15.205, 15.209 and 15.247 (d) See section 6.3 for Measurement Uncertainty 3 DTS Bandwidth Complies with the relevant requirements of CFR Title 47, Part 15, Subpart C, secti…

Text truncated - open the document above for the full version.

2.4GHz Mini Antenna, SMTP/N 2450AT18A100 Detail Specification: Page 1 of 5 *Efficiency based on Johanson's standard evaluation board ±± ±± ±± www.johansontechnology.com 4001 Calle Tecate • Camarillo, CA 93012 • TEL 805.389.1166 FAX 805.389.1821 Ver. 3.0 2018 Johanson Technology, Inc. All Rights Reserved "High Frequency Ceramic Solutions" Part Number 7/9/2018 Avg. Rad Efficiency* Let us help you with the antenna design, optimization, and tuning! 2450AT18A100 2400 - 2500 76% General Specifications Frequency (MHz) 18 months max. -40 to +125°C -40 to +125°C 3000 Return Loss (dB) Impedance Input Power Storage Period Storage Temperature Operating Temperature Reel Quantity 50 Ω 2 Watts max. (CW) Johanson Technology, Inc. reserves the right to make design changes without notice. All sales are subject to Johanson Technology, Inc. terms and conditions. e.g. 2450AT18A100(E or S)100% Tin Packing Style Evaluation Board 2450AT18A100-EBSMA (see page 2&3 for details) Bulk (loose) T & R Suffix = E or S Suffix = E P/N Suffix Mechanical Dimensions In L 0.1260.0083.200.2 W 0.0630.0081.600.2 T 0.0511.30+.004/-.008 +0.1/-0.2 a 0.0200.0120.500.3 Terminal Configuration Function FEED NC No. 1 2 mm e.g. 2450AT18A100E e.g. 2450AT18A100SSuffix = S Part Number Explanation Peak Gain (dBi typ.) Average Gain (dBi typ.) 0.5 -0.5 9.5 min. ① ② L W a T Want the layout file? Request it at: www.johansontechnology.com/ask-a-question 2.4GHz Mini Antenna, SMTP/N 2450AT18A100 Detail Specification: Page 2 of 5 JTI P/N for Matching Circuit: Cap (1.0pF): 500R07S1R0BV4T Inductor (2.7nH): L-07C2N7SV6T Inductor (3.9nH): L-07C3N9SV6T www.johansontechnology.com 4001 Calle Tecate • Camarillo, CA 93012 • TEL 805.389.1166 FAX 805.389.1821 Ver. 3.0 2018 Johanson Technology, Inc. All Rights Reserved "High Frequency Ceramic Solu…

Text truncated - open the document above for the full version.
