2A7JMDNL1R0Argus

User Manual Product Name: Argus Model Name: DNL1R0 PN#: DNL1R0 Unison Labs About Unison Labsis a CA based start-up, building hardware/software solutions to track activity patterns of people, equipment and assets, with applications in supply chain operations. The product is based on company’s proprietary deep fusion of mm-wave imaging radar and cameras, with edge-based ML, and the added intelligence to make sense of all of that data. The product will be deployed in industrial facilities to provide tagless activity tracking of people & equipment, and help companies optimize resource utilization and detect unsafe behaviors. Product Usage The company’s product is installed in locations where activity patterns are desired to be monitored. Camera and mmWave sensor data is processed and fused with additional environmental information to provide analytics for a corresponding scene. The compiled analytics from one or several of the company’s products are then uploaded over Ethernet, via a PoE connection, to the cloud, where the customer is provided with a dashboard that aggregates information and can provide reports pertaining to safety events, recommendations to improve warehouse space and route efficiency, or insight into manufacturing productivity. Note: System installation or disassembly is not supported to be performed by customers. System has a debug port behind a secure door that is not to be utilized by customers. LTE is not currently available, but will be supported in future generations. mmWave radar operation is limited to the 61GHz-61.5GHz band. Installation Process: Units are professionally installed by the the company’s team using an included mount. Four screws are used to attach the mount to the mounting surface. The PoE cable can then be routed through the mount, through the IP gasket, and into the device. The IP gasket is sealed and the device can then be rested on the V-grooves of the mount. Then another four screws are used to attach the device to the mount. The mount has several axes to enable control over the field of view of the device. Once the device is mounted, the corresponding axes control screws can be tightened to fix the FoV. The screw is for earth terminal, it shall be used 18 AWG minimum size with green-yellow conductor to connect to earth. Software Operation Guide: Units are professionally installed; post-installation, the unit will automatically boot. The device is then directly accessed by the company and configured in the backend to run a capture preset. After two days of calibration, the device is then ready to start providing analytics to the customer. Data then gets automatically uploaded and displayed via the company’s customer-facing dashboard (see below). There are no user-exposed buttons; if a power-cycle is necessary, the device is unplugged. After being replugged, the device will automatically boot and capture using the last set configuration. Federal Communication Commission Interference Statement This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference when the equipment is operated in a commercial environment. This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance with the instruction manual, may cause harmful interference to radio communications. Operation of this equipment in a residential area is likely to cause harmful interference in which case the user will be required to correct the interference at his own expense. FCC Caution: Any changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate this equipment. This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. IMPORTANT NOTE: Radiation Exposure Statement: This equipment complies with FCC radiation exposure limits set forth for an uncontrolled environment. This equipment should be installed and operated with a minimum distance 20cm between the radiator & your body. This transmitter must not be co-located or operating in conjunction with any other antenna or transmitter. Professional installation instruction Please be advised that due to the unique function supplied by this product, the device is intended for use with our interactive entertainment software and licensed third-party only. The product will be distributed through a controlled distribution channel and installed by trained professionals and will not be sold directly to the general public through retail stores. 1. Installation personal This product is designed for specific applications and needs to be installed by a qualified person who has RF and related rule knowledge. The general user shall not attempt to install or change the setting. 2. Installation location The product shall be installed at a location where the radiating antenna can be kept 20cm from a nearby person in normal operation condition to meet regulatory RF exposure requirement. 3. Installation procedure Please refer to the user's manual for the details. 4. Warning Please carefully select the installation position and make sure that the final output power does not exceed the limit set force in relevant rules. The violation of the rule could lead to a serious federal penalty. Company Information: Unison Labs 1300 South El Camino Real Suite 505 San Mateo, CA 94402 650-627-4399

1300SE L C AMINO R EAL ,S UITE 505, S AN M ATEO CA94402 FederalCommunicationsCommission 7435OaklandMillsRoad ColumbiaMD21046 Subject:(UnisonLabsandGranteeCode:2A7JM)AttestationStatement Reference:a)FCCCFRsection2.911(d)(5)(i) b)FCCSection2.911(d)(5)(ii) c)FCCSection2.911(d)(7) a)[UnisonLabs](“theapplicant”)certifiesthattheequipment[FCCID:2A7JMDNL1R0]forwhich authorizationissoughtisnot“covered”equipmentprohibitedfromreceivinganequipment authorizationpursuanttosection2.903oftheFCCrules; b)[UnisonLabs](“theapplicant”)certifiesthat,asofthedateofthefilingoftheapplication,the applicant[isnot]identifiedontheCoveredList(asaspecificallynamedentityoranyofits subsidiariesoraffiliates)asanentityproducing“covered”equipment; c)[UnisonLabs](“theapplicant”)asrequiredbysection2.911(d)(7),willalsoserveastheagentfor serviceofprocessfortheabovereferencedFCCGranteeCode.Theserviceofprocessincludes, butisnotlimitedto,deliveryofanycorrespondence,notices,orders,decisions,and requirementsofadministrative,legal,orjudicialprocessrelatedtoCommissionproceedings.The applicantacknowledgesthattheywillmaintainanagentforserviceofprocessintheUnited Statesfornolessthanoneyearaftereitherthegranteehaspermanentlyterminatedall marketingandimportationoftheapplicableequipmentwithintheU.S.,ortheconclusionofany Commission-relatedadministrativeorjudicialproceedinginvolvingtheequipment,whicheveris later.TheapplicantfurtheracknowledgestheirresponsibilitytoinformtheFCCwheneverthe followingagentinformationchanges. DesignatedAgent UnisonLabs Suite505,1300SouthElCaminoReal,SanMateo,California AminArbabian /650-627-4399/[email protected] FRN:0029271624 Sincerelyyours, SignedbytheApplicant Name:AminArbabian Title:CEOandCo-Founder Date:10/12/2023

1300SE L C AMINO R EAL ,S UITE 505, S AN M ATEO CA94402 Date:2023/10/12 FederalCommunicationsCommission 7435OaklandMillsRd ColumbiaMD21046-1609 Subject:ProductCertificationRepresentativeAuthorizationLetter FCCID:2A7JMDNL1R0 Productname:Argus Towhomitmayconcern: Wetheundersigned,herebyauthorizefollowingpersontoactasouragentinthepreparationofan applicationforequipmentauthorizationofmodelDNL1R0totheFCCRulesandRegulations. InternationalCertificationCorp. Address: No.3-1,Lane6,WenSan3rdSt.KweiShan Dist.,TaoYuanCity333, Taiwan(R.O.C.) Name:GaryChang JobTitle:Manager e-mail: [email protected] Webs Wefurthercertifiesthatneithertheapplicantnoranypartytothisapplication,asdefinedin47CFR Ch.1.2002(b),issubjecttoadenialtoFederalbenefits,thatincludeFCCbenefits,pursuantto section5301oftheAnti-DrugAbuseActof1998,21U.S.C.862. ThisappointmentalsoincludestheauthoritytocompleteFCCForm731onourbehalfandsignthe applicationasanauthorizedagent. Applicant:UnisonLabs Address:1300SElCaminoReal,Suite505,SanMateo,California,UnitedStates Signature: _________________________________ NameandJobTitle.:AminArbabian/CEOandCo-founder E-mail:[email protected] Tel.:1-650-627-4399

1300SE L C AMINO R EAL ,S UITE 505, S AN M ATEO CA94402 Date:October12,2023 FederalCommunicationsCommission AuthorizationandEvaluationDivision 7435OaklandMillsRd ColumbiaMD21046-1609 Subject:Requestforconfidentiality FCCID: 2A7JMDNL1R0 Towhomitmayconcern: Short-termconfidentiality PursuanttoDA04-1705oftheCommission’spubicnotice,inordertocomplywiththemarketingregulations in47CFR§2.803andtheimportationrulesin47CFR§2.1204,whileensuringthatbusinesssensitive informationremainsconfidentialuntiltheactualmarketingofnewlyauthorizeddevices.Wearerequestingthe commissiontograntshort-termconfidentialityrequestonthefollowingattachmentsuntil180days. ☒ExternalPhotographs ☒User'smanual ☒TestSetupphoto Permanentconfidentiality PursuanttoSections0.457and0.459oftheCommission’sRules,theApplicantHerebyrequestsconfidential treatmentofinformationaccompanyingthisApplicationAsoutlinedbelow: ☒BlockDiagram ☒Schematics ☒OperationalDescription ☒InternalPhotographs Theabovematerialscontaintradesecretsandproprietaryinformationnotcustomarilyreleasedtothe public.Thepublicdisclosureofthesematerialsmaybeharmfultotheapplicantandprovideunjustified benefitstoitscompetitors. TheapplicantunderstandsthatpursuanttoSection0.457oftheRules,disclosureofthisapplicationand allaccompanyingdocumentationwillnotbemadebeforethedateoftheGrantforthisapplication. Shouldyourequireanyfurtherinformation,pleasecontacttheundersigned. Thankyouforyourconsiderationinthismatter. Applicant: UnisonLabs Address: 1300SElCaminoReal,Suite505,SanMateo,California,United States Signature: _________________________________ NameandJobTitle .:AminArbabian/CEOandCo-founder E-mail :[email protected] Tel.:1-650-627-4399

1300SE L C AMINO R EAL ,S UITE 505, S AN M ATEO CA94402 ProfessionalInstallationAttestation October12,2023 FCCID:2A7JMDNL1R0 ToWhomItMayConcern: PleasebeadvisedthatduetotheuniqueMarketandfunctiontargetedbythisproduct, thisproductwillneedspecialtrainedprofessionalinconfiguringandinstallingthe product.Weherebydeclarethattheproductwillbedistributedthroughcontrolled distributionchannelwhichhasspecialtrainedprofessionaltoinstallthisproductandwill notbesolddirectlytothegeneralpublicthroughretailstore. Thankyouforyourattention. Yourssincerely, Applicant: UnisonLabs Address: 1300SElCaminoReal,Suite505,SanMateo,California, UnitedStates Signature: _________________________________ NameandJob Title. :AminArbabian/CEOandCo-founder E-mail :[email protected] Tel.:1-650-627-4399

PHOTOGRAPHS OF EUT EP252312-02 Sporton International Inc. Page No. : 1 of 5 Report Template No.: SE Ver 1.0_EP Issued Date : Oct. 13, 2023 Report Version : 01 Brand Name: P L AT O Model Name: DNL1R0 PHOTOGRAPHS OF EUT EP252312-02 Sporton International Inc. Page No. : 2 of 5 Report Template No.: SE Ver 1.0_EP Issued Date : Oct. 13, 2023 Report Version : 01 PHOTOGRAPHS OF EUT EP252312-02 Sporton International Inc. Page No. : 3 of 5 Report Template No.: SE Ver 1.0_EP Issued Date : Oct. 13, 2023 Report Version : 01 PHOTOGRAPHS OF EUT EP252312-02 Sporton International Inc. Page No. : 4 of 5 Report Template No.: SE Ver 1.0_EP Issued Date : Oct. 13, 2023 Report Version : 01 PHOTOGRAPHS OF EUT EP252312-02 Sporton International Inc. Page No. : 5 of 5 Report Template No.: SE Ver 1.0_EP Issued Date : Oct. 13, 2023 Report Version : 01 Wall mount

RADIO EXPOSURE TEST REPORT Report No. : FA252312-02 TEL : 886-3-656-9065 Page Number : 2 of 12 FAX : 886-3-656-9085 Issued Date : Oct. 13, 2023 Report Template No.: CB-A1_1 Ver1.1 Report Version : 01 Table of Contents History of this test report ................................................................................................................................. 3 Summary of Test Result................................................................................................................................... 4 1 General Description ............................................................................................................................. 5 1.1 EUT General Information ....................................................................................................................... 5 1.2 Antenna Information ............................................................................................................................... 5 1.3 Table for Waveform information ............................................................................................................. 5 1.4 Accessories ............................................................................................................................................ 6 1.5 Applicable Standards ............................................................................................................................. 6 1.6 Testing Location ..................................................................................................................................... 6 2 Maximum Permissible Exposure ........................................................................................................ 7 2.1 Limit of Maximum Permissible Exposure ............................................................................................... 7 2.2 MPE Calculation Method ........................................................................................................................ 7 2.3 MPE Exemption ...................................................................................................................................... 8 2.4 Calculated Result and Limit .................................................................................................................... 9 Photographs of EUT v01 RADIO EXPOSURE TEST REPORT Report No. : FA252312-02 TEL : 886-3-656-9065 Page Number : 3 of 12 FAX : 886-3-656-9085 Issued Date : Oct. 13, 2023 Report Template No.: CB-A1_1 Ver1.1 Report Version : 01 History of this test report Report No. Version Description Issued Date FA252312-02 01 Initial issue of report Oct. 13, 2023 RADIO EXPOSURE TEST REPORT Report No. : FA252312-02 TEL : 886-3-656-9065 Page Number : 4 of 12 FAX : 886-3-656-9085 Issued Date : Oct. 13, 2023 Report Template No.: CB-A1_1 Ver1.1 Report Version : 01 Summary of Test Result Report Clause Ref Std. Clause Test Items Result (PASS/FAIL) Remark 2 - Exposure evaluation PA SS - Reference to Sporton Project No.: 252312-01 Conformity Assessment Condition: 1. The test results (PASS/FAIL) with all measurement uncertainty excluded are presented against the regulation limits or in accordance with the requirements stipulated by the applicant/manufacturer who shall bear all the risks of non-compliance that may potentially occur if measurement uncertainty is taken into account. 2. The measurement uncertainty please refer to each test result in the chapter "Measurement Uncertainty". Disclaimer: The product specifications of the EUT presented in the test report that may affect the test assessments are declared by the manufacturer who shall take full responsibility for the authenticity. Reviewed by: Sam Chen Report Producer: Viola Huang RADIO EXPOSURE TEST REPORT Report No. : FA252312-02 TEL : 886-3-656-9065 Page Number : 5 of 12 FAX : 886-3-656-9085 Issued Date : Oct. 13, 2023 Report Template No.: CB-A1_1 Ver1.1 Report Version : 01 1 General Description 1.1 EUT General Information RF General Information Evaluation Mode Frequency Range (GHz) Operating Frequency (GHz) Waveform Modulation Type 60 GHz 57-71 61.02~61.249 Hawk Frequency Modulated Continuous Wave 61.02~61.447 Owl, Parliament 1.2 Antenna Information Ant. Brand Model Name Antenna Type Connector Gain (dBi) 1 PLATO 01566000101 PCB Antenna N/A 7 2 PLATO 01566000101 PCB Antenna N/A 7 3 PLATO 01566000101 PCB Antenna N/A 7 Note: The above information was declared by manufacturer. For Hawk waveform For 3TX Ant. 1, Ant. 2 and Ant. 3 can be use as all antenna transmitting. For Owl waveform and Parliament waveform For 1TX The EUT supports the Ant. 1 and Ant. 3 with TX diversity function. At any time, there is only one antenna port can transmitting RF signal. 1.3 Table for Waveform information Waveform Frequency range Bandwidth Radio Function Hawk 61.02GHz~61.249GHz 229MHz 3 path transmit Owl 61.02GHz~61.447GHz 427.336MHz 1 path transmit Parliament 61.02 GHz~61.447 GHz 427.249 MHz 1 path transmit Note: The above information was declared by manufacturer. RADIO EXPOSURE TEST REPORT Report No. : FA252312-02 TEL : 886-3-656-9065 Page Number : 6 of 12 FAX : 886-3-656-9085 Issued Date : Oct. 13, 2023 Report Template No.: CB-A1_1 Ver1.1 Report Version : 01 1.4 Accessories Wall mount*1 1.5 Applicable Standards According to the specifications of the manufacturer, the EUT must comply with the requirements of the following standards:  47 CFR Part 2.1091  KDB 447498 D04 Interim General RF Exposure Guidance v01 The following reference test guidance is not within the scope of accreditation of TAF.  47 CFR Part 1.1307  47 CFR Part 1.1310 1.6 Testing Location Testing Location Information Test Lab.：Sporton International Inc. Hsinchu Laboratory Hsinchu ADD: No.8, Ln. 724, Bo’ai St., Zhubei City, Hsinchu County 302010, Taiwan (R.O.C.) (TAF: 3787) TEL: 886-3-656-9065 FAX: 886-3-656-9085 Test site Designation No. TW3787 with FCC. Conformity Assessment Body Identifier (CABID) TW3787 with ISED. …

Text truncated - open the document above for the full version.

RADIO TEST REPORT Report No. : FR252312-02 TEL : 886-3-656-9065 Page Number : 2 of 53 FAX : 886-3-656-9085 Issued Date : Oct. 13, 2023 Report Temp.late No.: CB-A9_1 Ver1.3 Report Version : 01 Table of Contents History of this test report ................................................................................................................................. 3 Summary of Test Result................................................................................................................................... 4 1 General Description ............................................................................................................................. 5 1.1 Information .............................................................................................................................................. 5 1.2 Applicable Standards ............................................................................................................................. 9 1.3 Testing Location ..................................................................................................................................... 9 2 Test Configuration of Equipment under Test .................................................................................. 10 2.1 Parameters of Test Software Setting ................................................................................................... 10 2.2 Conformance Tests and Related Test Frequencies............................................................................. 10 2.3 EUT Operation during Test .................................................................................................................. 11 2.4 Accessories .......................................................................................................................................... 11 2.5 Support Equipment ............................................................................................................................... 12 2.6 Far Field Boundary Calculations .......................................................................................................... 13 2.7 Test Setup Diagram ............................................................................................................................. 14 3 Transmitter Test Result ..................................................................................................................... 19 3.1 AC Power Conducted Emissions ......................................................................................................... 19 3.2 Occupied Bandwidth ............................................................................................................................ 22 3.3 EIRP Power .......................................................................................................................................... 28 3.4 Peak Conducted Power ........................................................................................................................ 33 3.5 Transmitter Spurious Emissions ........................................................................................................... 36 3.6 Frequency Stability ............................................................................................................................... 41 3.7 Operation Restriction and Group Installation ....................................................................................... 46 4 Test Equipment and Calibration Data .............................................................................................. 47 5 Measurement Uncertainty ................................................................................................................. 53 Appendix A. Test Results of AC Power-line Conducted Emissions Appendix B. Test Results of Transmitter Spurious Emissions Appendix C. Test Photos Photographs of EUT v01 RADIO TEST REPORT Report No. : FR252312-02 TEL : 886-3-656-9065 Page Number : 3 of 53 FAX : 886-3-656-9085 Issued Date : Oct. 13, 2023 Report Temp.late No.: CB-A9_1 Ver1.3 Report Version : 01 History of this test report Report No. Version Description Issued Date FR252312-02 01 Initial issue of report Oct. 13, 2023 6 2437 MHz RADIO TEST REPORT Report No. : FR252312-02 TEL : 886-3-656-9065 Page Number : 4 of 53 FAX : 886-3-656-9085 Issued Date : Oct. 13, 2023 Report Temp.late No.: CB-A9_1 Ver1.3 Report Version : 01 Summary of Test Result Report Clause Ref Std. Clause Test Items Result (PASS/FAIL) Remark 3.1 15.207 AC Power Conducted Emissions PA SS - 3.2 15.255(e) Occupied Bandwidth PA SS - 3.3 15.255(c) EIRP Power PA SS - 3.4 15.255(c) Peak Conducted Power PA SS - 3.5 15.255(d) Transmitter Spurious Emissions PA SS - 3.6 15.255(f) Frequency Stability PA SS - 3.7 15.255(a),(h) Operation Restriction and Group Installation PA SS - Reference to Sporton Project No.: 252312, 252312-01. Conformity Assessment Condition: 1. The test results (PASS/FAIL) with all measurement uncertainty excluded are presented against the regulation limits or in accordance with the requirements stipulated by the applicant/manufacturer who shall bear all the risks of non-compliance that may potentially occur if measurement uncertainty is taken into account. 2. The measurement uncertainty please refer to each test result in the chapter "Measurement Uncertainty". Disclaimer: The product specifications of the EUT presented in the test report that may affect the test assessments are declared by the manufacturer who shall take full responsibility for the authenticity. Reviewed by: Sam Chen Report Producer: Viola Huang RADIO TEST REPORT Report No. : FR252312-02 TEL : 886-3-656-9065 Page Number : 5 of 53 FAX : 886-3-656-9085 Issued Date : Oct. 13, 2023 Report Temp.late No.: CB-A9_1 Ver1.3 Report Version : 01 1 General Description 1.1 Information 1.1.1 The Channel Plan(s) For Hawk waveform RF General Information Frequency Range (GHz) Operating Frequency Range (…

Text truncated - open the document above for the full version.

UnisonLabs01566000101AntennaArray AntennaDatasheet Description: UnisonLab’s01566000101isanonboard-etchedlongrangepatchcascadeantennaarray, withthreetransmittersandfourreceivers.Thepatchcascadeisidenticalforeachtransmitand receiveantennapath,witheachantennabeingconnectedtothetransceiverusinga50Ω microstriptrace.ThearrayisintegratedintoasinglePCBcopperlayerformmWavesensor processing. Specifications:AntennaPatchMechanicalDrawing: OperationFrequency61.0-61.5GHz NumberofReceivers4 NumberofTransmitters3 TechnologyAntennaonPCB AntennaTypeCascadedPatch GainofsinglePatchAntenna7dBi GainoftransmitterPatchArray16.54dBi E-Plane[Elevation](3dB Beamwidth) <+/-40deg H-Plane[Azimuth](3dBBeamwidth)<+/-60deg PolarizationVertical UnisonLabs|1300S.ElCaminoReal,Suite505,SanMateo,CA94402 Phone:(650)627-4399|Email:[email protected]
