2A7NPMTB100AT-BOX with WCDMA, LTE and Bluetooth

Data serves you 1 MTB -100A High-protective multi-functional on-board intelligent terminal  Built-in 4G and GNSS, vehicle status real-time view  BLE 5.0 communication, to realize the mobile phone Bluetooth control car  Support a variety of wake-up ways, quick start  Built-in IMU sensor that provides driving behavior analysis  Front loading product quality, ISO / TS 16949 quality system certification product description MTB-100 series on-board terminal is a highly protective 4G on-board terminal equipment independently designed and developed by INTEST, which gathers the general function needs of vehicle remote monitoring, and provides on-board intelligent network solutions with fast and flexible installation adaptation, stable and rich functions.The product is optimized for the two-wheeler market, improve the protection level to IP 67 and provides up to 11 I / O signal control, adapted to a variety of vehicle control solutions. Product function Major function Function declaration Platform communication -Support for 2 / 3 / 4G data communication; -Support breakpoint continuous transmission. When the terminal locally caches the data when the communication condition is poor, the cached data is retransmitted after the communication is restored CAN communication -Support two high-speed CAN communication, port rate can be set, support CAN wake-up; Data collection and storage -The terminal collects and analyzes the original CAN message in real time, stores the original CAN message locally, and reports the resolved data to the TSP platform; -Local data is stored in eMMC, supports automatic cycle storage, automatically overwrites the earliest data when full, and abnormal power off local data is not lost.In case of upload failure of the network, you should read from the local data and re-upload the data not successfully uploaded before; Vehicle positioning -Support for GPS / BeiDou positioning; -Default provides speed, distance, latitude and longitude, direction, star search, GPS time, positioning scheme and other information; Timing -The terminal provides clock service, using local legal time, with the format MTB -100E 113mm*100mm*43.4mm Data serves you 2 Configuration specifications Electrical characteristics and the complete machine performance  Operating voltage range 9~16V DC  Current margin ≤300mA (12VDC)  Standby current ≤5mA  Clock error was ± 5s / 24h Enviromental parameter  Operating temperature-20°C ~ + 70°C  Storage temperature-40°C ~85°C  Relative humidity 5%~90%RH  Level of protection: IP 67 CAN communication as YYYY-MM-DD; -Support for GPS and cloud platform campus timing; Power management -The terminal supports working under 12VDC, providing normal operation, standby and two working modes.It can meet the needs of different business scenarios through the switching of different working modes. Wake up signal management -The terminal will enter the normal working mode after receiving the wake up signal. The wake up signal of this project includes CAN wake up, timing wake up, IMU wake up and Bluetooth wake up; -The terminal supports 7-way hard line wake-up signal and 3-way hard line high- level signal output, realizing vehicle control through Yingxian signal; Failure warning -The terminal supports identifying vehicle fault code and upload fault code signal, and the TSP platform identifies fault code to trigger alarm; Terminal self- inspection -Real-time self-inspection after terminal power, and reported to the cloud; -Support for sending self-test fault codes to the CAN bus Terminal Remote Settings -Support the remote terminal setting through the TSP platform, including setting the default DBC file, setting the data reporting frequency, query the terminal status, restart, etc.; BLE communication -Communicate with the mobile phone APP via BLE 5.0; -Realize the Bluetooth virtual key function, including key sharing and Bluetooth unlock, locking, car search three control functions; -The terminal supports transmitting real-time data to the owner APP through the BLE at 25Hz during the vehicle driving; Security function -Support the collision alarm function, anti-theft alarm function, identify the vehicle posture and movement through the IMU sensor, and trigger the terminal to send an alarm signal to the TSP platform; -Support independent operation with backup battery, report location data to the platform, and provide anti-theft tracking; Safe guarding -Built-in independent security chip, scalable to support PKI / CA security scheme; -Support data secure storage and data secure communication; FOTA -Terminal supports to accept the upgrade of steamed stuffed bun upgrade issued by TSP; -The terminal supports receiving other ECU upgrade packages of the vehicle and transmitting them to the corresponding ECU self-upgrade. After the upgrade success / failure, the results are reported according to the FOTA process. Data serves you 2  2 High-speed CAN communication  The CAN bus wave rate can be set and support a common wave rate like 125 / 250 / 500 / 1000kbps  Support for the CAN wake-up IMU, sensor  Triaxial accelerometer: ± 2g, ± 4g, ± 8g, ± 16g  Gyroscope: ± 250 dps, ± 500 dps, ± 1000 dps, and ± 2000 dps  Data output frequency range: 0.781Hz ~1600H z 4G Communications (North America)  Communication frequency band: LTE FDD: B 2 / B 4 / B 12 WCDMA: B 2/B 4/B5  Communication rate of 50 / 50Mbps  Built-in GNSS positioning module Vehicle positioning  Support for GPS positioning  Positioning accuracy: <10m (CEP-50)  Refresh frequency is 1Hz  Hot start, 2s.5  Cold start-up for 35s BLE communication  Bluetooth 5.0 Communications  BLE data transmission frequency of 1Mbps Back up power  Nickel metal hydride battery capacity is 600mAh  Independent working hours, 30min Data serves you 5 FCC Statements: This device complies with part 15 of the FCC rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device mus…
