2A7NX-XRCcar multimedia player

Contents Disclaimer-------------------------------------------------------------------------------------3 1.BasicOperationSetting----------------------------------------------------------4 2.Settings-------------------------------------------------------------------------------5 2.1.Network&Internet---------------------------------------------------------5 2.2.CarInfotainment-----------------------------------------------------------6 2.2.1.GeneralSettings------------------------------------------------------6 2.2.2.DisplaySetting--------------------------------------------------------8 2.2.3.VolumeOption--------------------------------------------------------8 2.2.4.SoundEffect-----------------------------------------------------------8 2.2.5.VideoOption-----------------------------------------------------------9 2.2.6.NavigationSetting--------------------------------------------------10 2.2.7.BluetoothSetting---------------------------------------------------10 2.2.8.SteeringWheelControl-------------------------------------------11 2.2.9.VersionInformation------------------------------------------------12 3.Application-------------------------------------------------------------------------12 3.1.Navigation------------------------------------------------------------------12 3.2.Radio-------------------------------------------------------------------------13 3.3.Video-------------------------------------------------------------------------14 3.4.Music------------------------------------------------------------------------15 3.5.Bluetooth-------------------------------------------------------------------16 3.6.AVINInputSupport------------------------------------------------------18 3.7.DisplayScreenInstruction--------------------------------------------19 3.8.InstallationofAntenna--------------------------------------------------20 4.TroubleshootingGuide---------------------------------------------------------21 Disclaimer Foryoursafety,itisadvisabletonotwatchvideooroperatethemachinewhenyou aredriving.Whiledriving,pleaseadjustthevolumetotheoptimumlevel.Before operatingthemachine,youareadvisabletoreadcarefullyandunderstandthe safetyinstructionsandwarningsignalsstatedinthemanual.Keepthemanualin thereachforfuturereference. 1.Firstly,pleaseensuresafetyontheroad. 2.Indifficultyoperatingthemachine,pleasestopthecarsafelybeforeyou operatethemachine. 3.Keepthemachineoutofreachfromchildrentopreventunnecessaryinjuryor damagetothemachine. 4.WhileusingtheGPSnavigation,pleaseadheretothetrafficrules. 5.Pleasedonotoperatethemachineatrestrictedareassuchaspetrolstation, winerefinery,strongelectromagneticobstructionareatopreventdanger. 6.Pleasedonotinstall,maintainorrepairthemachineonyourownwiththe poweron.Itisverydangeroustoinstallandrepairthemachinebypersonnel withoutproperprofessionalinstallationtrainingandexperienceonelectronicdevice andautomobileparts. 7.Pleasedonotinstallorstorethemachine,especiallyLEDdisplayscreen directlyunderthesunlightorhazardoussubstances.Duringinstallation,please ensurenodirectcontactwiththeair-conditioner'sventilationduct.Thiswillcause damagetothemachine,thecarorinjurytothehumanbody. 8.Pleasedonotusesharpobjecttoscratchorpressthedisplayscreen vigorouslyasthismaydamagethescreen. 9.Pleasedonotexposethemachineunderhumidweatherordirectcontactwith liquidtopreventfireorlighting. 10.Themachinecanonlysupportone12mmCDatatime.Pleasedonotinsert 8mmCDorotherobjectsintothemachine. 1.BasicOperationSetting 1.1.PowerOn/Offthemachine WhenACCisconnected,pressthepowerbuttononthefrontpaneltoswitch onthemachine. Pressthepowerbuttononthefrontpaneltoswitchonthemachine.Turnoff theengineandunplugthecarkeytoswitchoff. 1.2.VolumeAdjustment Press“”onthefrontpanel(somemodelswithvolumecontrolVOL+ /VOL-buttononthefrontpanel)toadjustthevolumeofthemachine. 1.3.MuteControl Presstheleftvolumebuttontodisplayvolumebaronthedisplayscreen. PressthemediavolumetoMUTE. 1.4.BacklightControl AdjustthebacklightatDisplaySettingunderCarSettings. 1.5.Camera Thescreenwillbeautomaticallyswitchedtorearviewsightwhenthecarisat reverseposition. 1.6.PlaybackSourceSelection Atfrontpanel,pressApplicationtoviewRadio,Music,Video,USBplay,TV (optional)orAVINmodeandoptions. Athomepage,touchAPPicontoenterapplicationinterface.Pleaseviewthe detailedoperationmanualofrespectivefunctionsatthesubsequentchapters.Slide leftorrighttoswitchbetweendifferenthomepages. 1.7.PlaybackModeandPositionMemory Whenyourebootthemachine,thesystemwillresumetotheearliermodepriorto shutdown. Forradio,itwillresumetotheradiochannelpriortoshutdown. Formusicorvideo,itwillresumeplayingthelastsongorvideopriortoshutdown. 2.Settings Touchtheicon“”onthefrontpaneltoenterSettingsinterface.Selectthe correspondingoptiontoenterthecorrespondingsettingsoption.Movetheoptions barupanddowntofindthedesiredsettings. Note: DirectionofONandOFFmodeundersettinginterface []ONmode []OFFmode 2.1.Network&Internet 2.1.1.Wi-FiConnection GotosettingsthenWi-FtoensureWi-Fiisswitchedontoconnecttothe internet. Aspertheabovepicture,searchforyourdesiredWi-Fihotspot.CompletetheWi-Fi connectionbyinsertingthepasswordandtouchConnect. Youmaychangethelanguagetype,languageinputandtypeofkeyboardinthis interface, 2.1.2.More SettingofpersonalhotspotandVPNisallowed. 2.2.CarInfotainment 2.2.1.GeneralSettings StandbyTime Thestandbytimeare0minute,0minutes,20minutes,30minutes,60minutes respectively.Standbytimecanbeadjustedinaccordancetodesire. TouchAssist Usercanchoosetoonoroffthetouchassist.Thetouchassisthas7most commonlyusedoptionsandisdisplayedontopofthescreenattheinterfacewhere itprovidestheusereasymaneuverofthemachine. ReverseVolumeControl Toadjustthevolumewhileatthereverseposition,selectReverseVolume Suppression.TherearefouroptionsavailablenamelyNone,Weak,Mediumand Strong. SelectingNonemeanstherewillnotbeanychangestothecurrentdefaulted volume. SelectingStrongmeansloweringdownthereversevolumeatmost. BootLogo Touchthebootlogo,keyinthepassword(5678)atthepopupdialogtoenterboot menu. RestoreFactorySetting Tou…

Text truncated - open the document above for the full version.

Shenzhen Xin Rui Chang Technology Co., Ltd. Agent Authorization Company: Shenzhen Xin Rui Chang Technology Co., Ltd. Address: Room 1002, Jialingyu Industry and Trade Building, Dapu North Road, Houting Community, Shajing, Baoan, Shenzhen Product Name: car multimedia player Model Number(s): XRC-7004, XRC-7007, XRC-7029, XRC-7031, XRC-7037, XRC-7042, XRC-7049, XRC-7055, XRC-7057, XRC-9004 Product Description: car multimedia player FCC ID: 2A7NX-XRC We authorize MiCOM Labs Inc., 575 Boulder Court, Pleasanton, California 94566, USA, to act on our behalf on all matters concerning the certification of above named equipment. We declare that MiCOM Labs Inc. is allowed to forward all information related to the approval and certification of equipment to the regulatory agencies as required and to discuss any issues concerning the approval application. Any and all acts carried out by MiCOM Labs on our behalf shall have the same effect as acts of our own. Signature: Date: 2022-06-28 Name: Jade Yang Title: Manager Company: Shenzhen Xin Rui Chang Technology Co., Ltd.

Shenzhen Xin Rui Chang Technology Co., Ltd. Office of Engineering Technology Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 USA Date: 2022-06-28 Subject; Request for Confidentiality FCC ID: 2A7NX-XRC To Whom It May Concern, Pursuant to the provisions of the Commission’s rules Title 47 Sections §0.457 and §0.459, we are requesting the Commission to withhold the following attachment(s) as confidential documents from public disclosure indefinitely. These documents contain detailed system and equipment descriptions and are considered as proprietary information in operation of the equipment. The public disclosure of these documents might be harmful to our company and would give competitors an unfair advantage in the market. Schematic Diagram Block Diagram Parts List Operational Description Tune-up Procedure It is our understanding that all measurement test reports, FCC ID label format and correspondence during the certification review process cannot be granted as confidential documents and this information will be available for public review once the grant of equipment authorization is issued. Sincerely, Signature: Name: Jade Yang Title: Manager

Shenzhen Xin Rui Chang Technology Co., Ltd. Model Difference Product Name: car multimedia player Model Number: XRC-7004, XRC-7007, XRC-7029, XRC-7031, XRC-7037, XRC-7042, XRC-7049, XRC-7055, XRC-7057, XRC-9004 FCC Identifier: 2A7NX-XRC All the models are the same circuit and RF module, except the model names and outlook color. Regards Sincerely Client’s signature Client’s name / title : Jade Yang / Manager Contact information / address: Room 1002, Jialingyu Industry and Trade Building, Dapu North Road, Houting Community, Shajing, Baoan, Shenzhen

BT/WIFI ANT GPS RX ANT PORT

Size:12*8mm M/N: XRC-7004 FCC ID: 2A7NX-XRC Label location

FCC ID: 2A7NX-XRC RF Exposure Evaluation Limits The criteria listed in the following table shall be used to evaluate the environment impact of human exposure to radio frequency (RF) radiation as specified in 1.1307(b) Limits for Maximum Permissible Exposure (MPE) Frequency range (MHz) Electric field strength (V/m) Magnetic field strength (A/m) Power density (mW/cm 2 ) Averaging time (minutes) (A) Limits for Occupational/Controlled Exposures 0.3–3.0 614 1.63 *(100) 6 3.0–30 1842/f 4.89/f *(900/f 2 ) 6 30–300 61.4 0.163 1.0 6 300–1500 f/300 6 1500–100,000 5 6 (B) Limits for General Population/Uncontrolled Exposure 0.3–1.34 614 1.63 *(100) 30 1.34–30 824/f 2.19/f *(180/f 2 ) 30 30–300 27.5 0.073 0.2 30 300–1500 f/1500 30 1500–100,000 1.0 30 f = frequency in MHz Friis transmission formula: Pd = (Pout*G)/(4*pi*r 2 ) Where Pd = power density in mW/cm 2 , Pout = output power to antenna in mW; G = gain of antenna in linear scale, Pi = 3.1416; R = distance between observation point and center of the radiator in cm Pd id the limit of MPE, 1 mW/cm 2 . If we know the maximum gain of the antenna and the total power input to the antenna, through the calculation, we will know the distance r where the MPE limit is reached. Test Procedure Software provided by client enabled the EUT to transmit and receive data at lowest, middle and highest channel individually. Test Result of RF Exposure Evaluation wifi mode Channel Output power to antenna (dBm) Output power to antenna (mW) Power Density at R=20cm (mW/cm 2 ) Limit (mW/cm 2 ) Result 802.11b 17.423 55.2459 0.00873 1.0 PASS 802.11g 17.756 59.6486 0.00943 1.0 PASS 802.11n HT20 19.45 88.1049 0.01392 1.0 PASS 802.11n HT40 17.456 55.6673 0.00880 1.0 PASS Remark: antenna gain=-1dBi

Shenzhen DL Testing Technology Co., Ltd. Report No.: DL-20220623025E Test Report Tel: 400-688-3552 Web:www.dl-cert.com Email: [email protected] Page 1 of 53 FCC Part 15C Test Report FCC ID: 2A7NX-XRC Applicant: Shenzhen Xin Rui Chang Technology Co., Ltd. Address: Room 1002, Jialingyu Industry and Trade Building, Dapu North Road, Houting Community, Shajing, Baoan, Shenzhen Manufacturer: Shenzhen Xin Rui Chang Technology Co., Ltd. Address: Room 1002, Jialingyu Industry and Trade Building, Dapu North Road, Houting Community, Shajing, Baoan, Shenzhen EUT: car multimedia player Trade Mark: xonrich Model Number: XRC-7004 XRC-7007, XRC-7029, XRC-7031, XRC-7037, XRC-7042, XRC-7049, XRC-7055, XRC-7057, XRC-9004 Date of Receipt: Jun. 15, 2022 Test Date: Jun. 15, 2022 – Jun. 24, 2022 Date of Report: Jun. 24, 2022 Prepared By: Shenzhen DL Testing Technology Co., Ltd. Address: 101-201, Building C, Shuanghuan, No.8, Baoqing Road, Baolong Industrial Zone, Baolong Street, Longgang District, Shenzhen, Guangdong, China Applicable Standards: FCC PART 15 C 15.247 ANSI C63.10:2013 Test Result: Pass Report Number: DL-20220623025E Prepared (Test Engineer): Pxing Huang Reviewer (Supervisor): Jack Bu Approved (Manager): Jade Yang This test report is based on a single evaluation of one sample of above mentioned products. It is not permitted to be duplicated in extracts without written approval of Shenzhen DL Testing Technology Co., Ltd. Shenzhen DL Testing Technology Co., Ltd. Report No.: DL-20220623025E Test Report Tel: 400-688-3552 Web:www.dl-cert.com Email: [email protected] Page 2 of 53 Table of Contents Page 1 . SUMMARY OF TEST RESULTS 4 1.1 MEASUREMENT UNCERTAINTY 4 2 . GENERAL INFORMATION 5 2.1 GENERAL DESCRIPTION OF EUT 5 2.2 DESCRIPTION OF TEST MODES 6 2.3 BLOCK DIGRAM SHOWING THE CONFIGURATION OF SYSTEM TESTED 7 2.4 DESCRIPTION OF SUPPORT UNITS(CONDUCTED MODE) 7 2.5 TABLE OF PARAMETERS OF TEST SOFTWARE SETTING 7 2.6 EQUIPMENTS LIST FOR ALL TEST ITEMS 8 3 . EMC EMISSION TEST 9 3.1 CONDUCTED EMISSION MEASUREMENT 9 3.1.1 POWER LINE CONDUCTED EMISSION LIMITS 9 3.1.2 TEST PROCEDURE 9 3.1.3 DEVIATION FROM TEST STANDARD 9 3.1.4 TEST SETUP 10 3.1.5 EUT OPERATING CONDITIONS 10 3.1.6 TEST RESULTS 10 3.2 RADIATED EMISSION MEASUREMENT 11 3.2.1 RADIATED EMISSION LIMITS 11 3.2.2 TEST PROCEDURE 12 3.2.3 DEVIATION FROM TEST STANDARD 12 3.2.4 TEST SETUP 12 3.2.5 EUT OPERATING CONDITIONS 13 3.2.6 TEST RESULTS (BETWEEN 9KHZ – 30 MHZ) 14 3.2.7 TEST RESULTS (BETWEEN 30MHZ – 1GHZ) 15 3.2.8 TEST RESULTS (1GHZ~25GHZ) 17 3.3 RADIATED BAND EMISSION MEASUREMENT 22 3.3.1 TEST REQUIREMENT: 22 3.3.2 TEST PROCEDURE 22 3.3.3 DEVIATION FROM TEST STANDARD 22 3.3.4 TEST SETUP 23 3.3.5 EUT OPERATING CONDITIONS 23 3.4 CONDUCTED BAND EDGE EMISSION MEASUREMENT 28 3.4.1 APPLICABLE STANDARD 28 3.4.2 TEST PROCEDURE 28 3.4.3 DEVIATION FROM STANDARD 28 3.4.4 TEST SETUP 28 3.4.5 EUT OPERATION CONDITIONS 28 3.4.6 TEST RESULTS 28 Shenzhen DL Testing Technology Co., Ltd. Report No.: DL-20220623025E Test Report Tel: 400-688-3552 Web:www.dl-cert.com Email: [email protected] Page 3 of 53 Table of Contents Page 4 . AVERAGE OUTPUT POWER 31 4.1 APPLIED PROCEDURES / LIMIT 31 4.1.1 TEST PROCEDURE 31 4.1.2 DEVIATION FROM STANDARD 31 4.1.3 TEST SETUP 31 4.1.4 EUT OPERATION CONDITIONS 31 4.1.5 TEST RESULTS 32 5 . POWER SPECTRAL DENSITY TEST 35 5.1 APPLIED PROCEDURES / LIMIT 35 5.1.1 TEST PROCEDURE 35 5.1.2 DEVIATION FROM STANDARD 35 5.1.3 TEST SETUP 35 5.1.4 EUT OPERATION CONDITIONS 35 5.1.5 TEST RESULTS 36 6 . 6DB BANDWIDTH TEST 39 6.1 APPLIED PROCEDURES / LIMIT 39 6.1.1 TEST PROCEDURE 39 6.1.2 DEVIATION FROM STANDARD 39 6.1.3 TEST SETUP 39 6.1.4 EUT OPERATION CONDITIONS 39 6.1.5 TEST RESULTS 40 7 . ANTENNA REQUIREMENT 43 7.1 STANDARD REQUIREMENT 43 7.2 EUT ANTENNA 43 8 . TEST SEUUP PHOTO 44 9 . EUT PHOTO 45 Shenzhen DL Testing Technology Co., Ltd. Report No.: DL-20220623025E Test Report Tel: 400-688-3552 Web:www.dl-cert.com Email: [email protected] Page 4 of 53 1. SUMMARY OF TEST RESULTS Test procedures according to the technical standards: FCC Part15 (15.247) , Subpart C Standard Section Test Item Judgment Remark 15.207 Conducted Emission N/A 15.247(c) Radiated Spurious Emission PASS 15.205 Band Edge Emission PASS 15.247(b)(1) Average Output Power PASS 15.247(a)(2) 6dB Bandwidth PASS 15.247(d) Power Spectral Density PASS 15.203 Antenna Requirement PASS NOTE: (1)” N/A” denotes test is not applicable in this Test Report 1.1 MEASUREMENT UNCERTAINTY The reported uncertainty of measurement y ± U, where expended uncertainty U is based on a standard uncertainty multiplied by a coverage factor of k=2，providing a level of confidence of approximately 95 %。 No. Item Uncertainty 1 Conducted Emission Test ±2.56dB 2 RF power,conducted ±0.42dB 3 Spurious emissions,conducted ±2.76dB 4 All emissions,radiated(<1G) ±3.65dB 5 All emissions,radiated(>1G) ±4.89dB 6 Temperature ±0.5°C 7 Humidity ±2% Shenzhen DL Testing Technology Co., Ltd. Report No.: DL-20220623025E Test Report Tel: 400-688-3552 Web:www.dl-cert.com Email: [email protected] Page 5 of 53 2. GENERAL INFORMATION 2.1 GENERAL DESCRIPTION OF EUT Product Name: car multimedia player Trademark xonrich Model No.: XRC-7004 XRC-7007, XRC-7029, XRC-7031, XRC-7037, XRC-7042, XRC-7049, XRC-7055, XRC-7057, XRC-9004 Model Difference All samples are the same except the mode names and outlook color, so we prepare "XRC-7004" for test only. Operation Frequency: 2412~2462 MHz for 802.11b/g/nHT20 2422~2452 MHz for 802.11nHT40 Channel numbers: 11 Channels for 802.11b/g/n(HT20) 7 channels for 802.11nHT40 Channel separation: 5MHz Modulation technology: 802.11b: DSSS (CCK, DQPSK, DBPSK) 802.11g/n(20): DSSS (CCK, DQPSK,DBPSK)+OFDM (QPSK, BPSK, 16-QAM, 64-QAM) Rate of Transmitter 802.11b: 11/5.5/2/1Mbps 802.11g: 54/48/36/24/18/12/9/6Mbps 802.11n: up to 150Mbps Antenna Type: External Antenna Antenna gain: -1dBi Power supply: DC 12V Note: 1.For a more detailed features description, please refer to the manufacturer’s specifications or …

Text truncated - open the document above for the full version.

Radiated Measurement Photos
