2A7PM-2PACKSGW4C2 Pack Compatible with Samsung Galaxy Watch Charger

Installationmethod Product name: 2 Pack Compatible with Samsung Galaxy Watch Charger Model: 2PACK-SGW4C Wireless charging standard :Qi input: DC 5V Output: DC 5V 0.5A Wireless charing Output: 2.5W Charging frequency: 108-205KHz Material: ABS&PC Product size: 1.35"diameter × 0.39"height × 39"length It is the best charging solution for Galaxy Watch currently,which comes with charging overheating protection, will never appear charging heat bright screen phenomenon,charging time is about 2 hours 30 minutes.It can also successfully complete charging in the room temperature of 35 . Compatible Watch Models: Galaxy Watch 4 40mm 44mm; Galaxy Watch 4 Classic 42mm 46mm; Galaxy Watch 3 41mm SM-R850 Galaxy Watch 3 45mm SM-R840 Galaxy Watch Active 2 40mm SM-R830 Galaxy Watch Active 2 44mm SM-R820 Galaxy Watch Active 1 SM-R500 FCCWarning ThisdevicecomplieswithPart18oftheFCCRules. RefertoFCCPart18.213(c)andKDB784748AnnerAsectionA.5: (a)Max.ElectricFieldEmissions:0.2296V/m Max.MagneticFieldEmissions:0.2344A/m (b)Themaintenanceofthesystemistheresponsibilityofthemanufacturer. (c)Topreventinterference,theproductshouldbeasfarawayfromdevicesoperatingatthesame frequencyaspossible. RFexposureconsiderations ThisequipmentcomplieswiththeFCCRFradiationexposurelimitssetforthforanuncontrolled environment.Thisequipmentshouldbeinstalledandoperatedwithaminimumdistanceof20cm betweentheradiatorandanypartofyourbody.

Reference No.: WTD22X06129770W Page 2 of 9 Waltek Testing Group (Shenzhen) Co., Ltd. Http://www.waltek.com.cn EXHIBIT 2 - EUT EXTERNAL PHOTOGRAPHS EUT View 1 EUT View 2 Reference No.: WTD22X06129770W Page 3 of 9 Waltek Testing Group (Shenzhen) Co., Ltd. Http://www.waltek.com.cn EUT View 3 EUT View 4 Reference No.: WTD22X06129770W Page 4 of 9 Waltek Testing Group (Shenzhen) Co., Ltd. Http://www.waltek.com.cn EUT View 5 EUT View 6

Reference No.: WTD22X06129770W Page 1 of 9 Waltek Testing Group (Shenzhen) Co., Ltd. Http://www.waltek.com.cn EXHIBIT 1 - PRODUCT LABELING Proposed FCC ID Label Format FCC ID: 2A7PM-2PACKSGW4C Specifications: Text is Black in color and justified. Labels are printed in indelible ink on permanent adhesive silk-screened onto the EUT or shall be affixed at a conspicuous location on the EUT. Proposed Label Location on EUT FCC ID Label Location

Reference No.: WTD22X06129770W Page 5 of 9 Waltek Testing Group (Shenzhen) Co., Ltd. Http://www.waltek.com.cn EXHIBIT 3 - EUT INTERNAL PHOTOGRAPHS EUT Housing and Board View 1 Solder Board-Component View 1 Reference No.: WTD22X06129770W Page 6 of 9 Waltek Testing Group (Shenzhen) Co., Ltd. Http://www.waltek.com.cn Solder Board-Component View 2 Solder Board-Component View 3 Reference No.: WTD22X06129770W Page 7 of 9 Waltek Testing Group (Shenzhen) Co., Ltd. Http://www.waltek.com.cn Solder Board-Component View 4 Antenna View

Waltek Testing Group (Shenzhen) Co., Ltd. Http://www.waltek.com.cn Page 1 of 12 TEST REPORT Reference No. .................... : WTD22X06129770W002 FCC ID ................................ : 2A7PM-2PACKSGW4C Applicant ........................... : BOXINTONG LTD. Address.............................. : 703Shi 1Hao BaXiang LongYuanErQu LongHuaXinQu ShenZhen GuangDong 518000, China Manufacturer ..................... : Hagibis Address.............................. : 703Shi 1Hao BaXiang LongYuanErQu LongHuaXinQu ShenZhen GuangDong 518000 Product Name ................... : 2 Pack Compatible with Samsung Galaxy Watch Charger Model No... ......................... : 2PACK-SGW4C Standards .......................... : KDB 680106 D01 V03 Date of Receipt sample .... : 2022-06-27 Date of Test........................ : 2022-06-27 to 2022-07-11 Date of Issue ..................... : 2022-07-11 Test Report Form No. ....... : WTX_KDB 680106 D01 V03W Test Result ......................... : Pass Remarks: The results shown in this test report refer only to the sample(s) tested, this test report cannot be reproduced, except in full, without prior written permission of the company. The report would be invalid without specific stamp of test institute and the signatures of approver. Prepared By: Waltek Testing Group (Shenzhen) Co., Ltd. Address: 1/F., Room 101, Building 1, Hongwei Industrial Park, Liuxian 2nd Road, Block 70 Bao'an District, Shenzhen, Guangdong, China Tel.: +86-755-33663308 Fax.: +86-755-33663309 Email: [email protected] Tested by: Approved by: Jack Huang Silin Chen Reference No.: WTD22X06129770W002 Waltek Testing Group (Shenzhen) Co., Ltd. Http://www.waltek.com.cn Page 2 of 12 TABLE OF CONTENTS 1. GENERAL INFORMATION ...................................................................................................................................4 1.1 PRODUCT DESCRIPTION FOR EQUIPMENT UNDER TEST (EUT) ...............................................................................4 1.2 AUXILIARY EQUIPMENT LIST AND DETAILS ...........................................................................................................5 1.3 TEST EQUIPMENT LIST AND DETAILS .....................................................................................................................6 2. RF EXPOSURE TEST REPORT.............................................................................................................................7 2.1 STANDARD APPLICABLE .........................................................................................................................................7 2.2 TEST CONDITIONS ..................................................................................................................................................7 2.3 TEST PROCEDURE ...................................................................................................................................................8 2.4 TEST RESULT..........................................................................................................................................................9 2.5 MEASUREMENT UNCERTAINTY ............................................................................................................................ 10 2.6 TEST PHOTOS ....................................................................................................................................................... 11 APPENDIX PHOTOGRAPHS ................................................................................................................................... 12 Reference No.: WTD22X06129770W002 Waltek Testing Group (Shenzhen) Co., Ltd. Http://www.waltek.com.cn Page 3 of 12 Report version Version No. Date of issue Description Rev.00 2022-07-11 Original / / / Reference No.: WTD22X06129770W002 Waltek Testing Group (Shenzhen) Co., Ltd. Http://www.waltek.com.cn Page 4 of 12 1. GENERAL INFORMATION 1.1 Product Description for Equipment Under Test (EUT) General Description of EUT Product Name: 2 Pack Compatible with Samsung Galaxy Watch Charger Trade Name: / Model No.: 2PACK-SGW4C Adding Model(s): / Note: The test data is gathered from a production sample, provided by the manufacturer. Technical Characteristics of EUT Frequency Range: 108-205kHz Modulation Type: ASK Antenna Type: Coil Antenna Rated Voltage: Input: 5V 0.5A Output: 2.5W Rated Current: Input : 0.5A Rated Power: Wireless Output : 2.5W Antenna Gain: 0 dBi Reference No.: WTD22X06129770W002 Waltek Testing Group (Shenzhen) Co., Ltd. Http://www.waltek.com.cn Page 5 of 12 1.2 Auxiliary Equipment List and Details Auxiliary Equipment List and Details Description Manufacturer Model Serial Number Adapter GaN2 Pro CCDAN65C2 / SNMSUNG Galaxy Watch3 / SM-R840 / Wireless Charging Load YBZ YBZ wireless charging tester / EUT Cable List and Details Cable Description Length (M) Shielded/Unshielded With Core/Without Core USB Cable 1.00 Unshielded Without Ferrite Reference No.: WTD22X06129770W002 Waltek Testing Group (Shenzhen) Co., Ltd. Http://www.waltek.com.cn Page 6 of 12 1.3 Test Equipment List and Details Description Manufacturer Model Serial No. Cal Date Due Date ELECTRIC AND MAGNETIC FIELD ANALYZER Narda EHP-200AC 180ZX10226 2021-05-20 2024-05-19 Reference No.: WTD22X06129770W002 Waltek Testing Group (Shenzhen) Co., Ltd. Http://www.waltek.com.cn Page 7 of 12 2. RF Exposure Test Report 2.1 Standard Applicable According to §1.1310 system operating under the provisions of this section shall be operating in a manner that the public is not exposed to radio frequency energy level in excess limit for maximum permissible exposure. 2.2 Test Conditions Test Mode Description Remark TM1 Wireless Charging Input : 5V 0.5A Wireless Output : 2.5W Measurement Distance: 15 cm and 20 cm Reference No.: WTD22X06129770W002 Waltek Testing Group (Shenzhen) Co., Ltd. Http://www.waltek.com.cn Page 8 of 12 2.3 Test Procedure a. The measurement probe was placed at test distance(15 cm…

Text truncated - open the document above for the full version.

Waltek Testing Group (Shenzhen) Co., Ltd. Http://www.waltek.com.cn Page 1 of 20 TEST REPORT Reference No. .................... : WTD22X06129770W001 FCC ID ................................ : 2A7PM-2PACKSGW4C Applicant ........................... : BOXINTONG LTD. Address.............................. : 703Shi 1Hao BaXiang LongYuanErQu LongHuaXinQu ShenZhen GuangDong 518000, China Manufacturer ..................... : Hagibis Address.............................. : 703Shi 1Hao BaXiang LongYuanErQu LongHuaXinQu ShenZhen GuangDong 518000 Product Name ................... : 2 Pack Compatible with Samsung Galaxy Watch Charger Model No... ......................... : 2PACK-SGW4C Standards .......................... : FCC Part 18 Date of Receipt sample .... : 2022-06-27 Date of Test........................ : 2022-06-27 to 2022-07-11 Date of Issue ..................... : 2022-07-11 Test Report Form No. ....... : WTX_Part 18W Test Result ......................... : Pass Remarks: The results shown in this test report refer only to the sample(s) tested, this test report cannot be reproduced, except in full, without prior written permission of the company. The report would be invalid without specific stamp of test institute and the signatures of approver. Prepared By: Waltek Testing Group (Shenzhen) Co., Ltd. Address: 1/F., Room 101, Building 1, Hongwei Industrial Park, Liuxian 2nd Road, Block 70 Bao'an District, Shenzhen, Guangdong, China Tel.: +86-755-33663308 Fax.: +86-755-33663309 Email: [email protected] Tested by: Approved by: Jack Huang Silin Chen Reference No.: WTD22X06129770W001 Waltek Testing Group (Shenzhen) Co., Ltd. Http://www.waltek.com.cn Page 2 of 20 TABLE OF CONTENTS 1. GENERAL INFORMATION ...................................................................................................................................4 1.1 PRODUCT DESCRIPTION FOR EQUIPMENT UNDER TEST (EUT) ...............................................................................4 1.2 TEST STANDARDS ...................................................................................................................................................5 1.3 TEST METHODOLOGY .............................................................................................................................................5 1.4 TEST FACILITY .......................................................................................................................................................5 1.5 EUT SETUP AND OPERATION MODE ......................................................................................................................6 1.6 MEASUREMENT UNCERTAINTY ..............................................................................................................................7 1.7 TEST EQUIPMENT LIST AND DETAILS .....................................................................................................................8 2. SUMMARY OF TEST RESULTS ...........................................................................................................................9 3. CONDUCTED EMISSIONS .................................................................................................................................. 10 3.1 STANDARD APPLICABLE ....................................................................................................................................... 10 3.2 TEST PROCEDURE ................................................................................................................................................. 10 3.3 BASIC TEST SETUP BLOCK DIAGRAM ................................................................................................................... 10 3.4 ENVIRONMENTAL CONDITIONS ............................................................................................................................ 10 3.5 TEST RECEIVER SETUP ......................................................................................................................................... 11 3.6 SUMMARY OF TEST RESULTS/PLOTS .................................................................................................................... 11 4. RADIATED EMISSIONS ....................................................................................................................................... 14 4.1 TEST PROCEDURE ................................................................................................................................................. 14 4.2 TEST RECEIVER SETUP ......................................................................................................................................... 16 4.3 CORRECTED AMPLITUDE & MARGIN CALCULATION ............................................................................................ 16 4.4 ENVIRONMENTAL CONDITIONS ............................................................................................................................ 16 4.5 SUMMARY OF TEST RESULTS/PLOTS .................................................................................................................... 16 APPENDIX PHOTOGRAPHS ................................................................................................................................... 20 Reference No.: WTD22X06129770W001 Waltek Testing Group (Shenzhen) Co., Ltd. Http://www.waltek.com.cn Page 3 of 20 Report version Version No. Date of issue Description Rev.00 2022-07-11 Original / / / Reference No.: WTD22X06129770W001 Waltek Testing Group (Shenzhen) Co., Ltd. Http://www.waltek.com.cn Page 4 of 20 1. GENERAL INFORMATION 1.1 Product Description for Equipment Under Test (EUT) General Description of EUT Product Name: 2 Pack Compatible with Samsung Galaxy Watch Charger Trade Name: / Model No.: 2PACK-SGW4C Adding Model(s): / Note: The test data is gathered from a production sample, provided by the manufacturer. Technical Characteristics of EUT Frequency R…

Text truncated - open the document above for the full version.

Reference No.: WTD22X06129770W Page 8 of 9 Waltek Testing Group (Shenzhen) Co., Ltd. Http://www.waltek.com.cn EXHIBIT 4 - TEST SETUP PHOTOGRAPHS Conducted Emission Test Setup Radiation Emission View (Below 30MHz) Reference No.: WTD22X06129770W Page 9 of 9 Waltek Testing Group (Shenzhen) Co., Ltd. Http://www.waltek.com.cn Radiation Emission View (30MHz to 1GHz) ***** END OF REPORT *****
