2A7QD-PJ4V00Pacojet 4 Food Processor

USER MANUAL EN 2 USER MANUAL 1 GENERAL INFORMATION/TECHNICAL SPECIFICATIONS 1.1 GENERAL INFORMATION This operating manual contains all information and instructions required for safe handling of the device. Please read through the included safety instructions carefully before using the device for the first time. Pacotizing ® The core function of the device is pacotizing®. This function processes deep-frozen foods into ultra-fine preparations without thawing. The device micro-purées and mousses in one step. Processing happens in the standard function using overpressure, resulting in volume expansion and flavor intensification. The device also offers cutting and whipping functions. See the section titled “PACOTIZING® – CUTTING – WHIPPING” for a description of each function. Aspects related to safe food handling Follow hygienic practices and comply with food safety regulations during food preparation! The food preparation to be processed may heat up during pacotizing ® ; therefore, subsequent food preparation must occur quickly to avoid spoilage and thus a health hazard. Instructions for use Before pacotizing ® , the food product must have been deep frozen for at least 24 hours in a pacotizing ® beaker at a temperature of –4°F to achieve a steady temperature of –4°F in the pacotizing ® beaker. During food preparation, the contents of the pacotizing ® beaker may not exceed the fill line. Cavities must be filled with liquid (water, broth, etc.). After filling the pacotizing ® beaker and before re-freezing food preparations remaining in the pacotizing ® beaker, the surface must be smoothed out. Pacojet Coupe Set The optional Pacojet Coupe Set is exclusively for non-frozen, boneless food preparations that can be processed repeatedly without a change in temperature caused by heat transfer. EN 3 Device descriptionThe Pacojet 4 is an innovative kitchen appliance that is suitable for commercial use. It processes deep-frozen foods into micro-purées and mousses in one step without thawing. Product image Rated power1500 W Power supplyPJ4 J220 – 240 V / 50 – 60 Hz PJ4 F220 – 240 V / 50 – 60 Hz PJ4 G220 – 240 V / 50 – 60 Hz PJ4 I220 – 240 V / 50 – 60 Hz PJ 4 S220 – 240 V / 50 – 60 Hz PJ4 B100 – 127 V / 50 – 60 Hz PJ4 P100 – 127 V / 50 – 60 Hz PJ4 N100 – 127 V / 50 – 60 Hz PJ4 L220 – 240 V / 50 – 60 Hz Network connectionWLAN802.11 b/g/n 2.4 GHz OverpressureApprox. 1 bar Power transmissionTiming belt Device controlElectronic unit, microprocessor controlled Noise emissionSound pressure level (LPA)76.4 dB (A) Dimensions (mm)497 x 204 x 365 (height x width x depth) Weight (kg)Pacojet 422.5 Spray guard0.1 Pacotizing ® blade0.06 Pacotizing ® beaker0.15 Beaker lid0.03 Protective outer beaker0.25 MaterialsHousingAluminum, coated BaseplateAluminum, coated Chassis partsSteel Beaker lidHDPE, food-safe Pacotizing® shaft with tool couplerStainless steel Spray guardTPE/HDPE, food-safe Pacojet 4 pacotizing ® bladeCast steel Pacotizing ® beakerPETG (Tritan), food-safe Protective outer beakerPolypropylene (fiberglass-reinforced) Distributor headquartersPacojet International AG CH-6300 Zug Switzerland 1.2 TECHNICAL SPECIFICATIONS EN 4 2 IMPORTANT SAFETY INSTRUCTIONS Read the safety instructions prior to using the device for the first time. 3 SCOPE OF DELIVERY 1 Device 2 Protective outer beaker* 3 Spray guard including 1 preliminary scraper 4 Pacotizing ® blade 5 Beaker lid* 6 Synthetic pacotizing ® beaker * Dishwasher safe. Also included in the scope of delivery: quick reference and safety instructions Should you discover any defects or missing components, please contact your PACOJET sales office or your official PACOJET service partner im- mediately (www.pacojet.com/service-en). Accessories and spare parts can be purchased at www.pacojet.com under the “Accessories” tab. Coupe Set (sold separately from 2023): 1 Coupe Set blade 2 Whipping disk 3 Cutter tongs EN 5 4 TOUCHSCREEN 4.1 START MENU 1 Settings 2 Favorites 3 Manual 4 Pacotizing ® 5 Cutting 6 Whipping 7 Cleaning 4.2 PACOTIZING ® /CUTTING/WHIPPING 1 Back to previous menu 2 Favorites 3 Information about pacotizing ® 4 Back to main menu 5 Selection of quantity to be pacotized ® : entire beaker, portions, or tenths of portions 6 Number of repeats 7 Normal pressure/overpressure 8 Jet ® Mode: rapid processing on/off 9 Save settings as favorite 10 Start process EN 6 5 GETTING STARTED Unpack the device.Check the contents of the package for completeness and proper condition (see section titled “SCOPE OF DELIVERY”). Place the device on a firm, flat surface at a distance of at least 10 cm to any other object. Note: Please observe the safety instructions. Plug the power cable into an outlet. Turn the device on by placing the power switch in the “I” position. The device will be in operating mode. The start menu will appear on the touchscreen. The processing modes (pacotizing ® , cutting, and whipping) and cleaning mode as well as settings, favorites, and the manual can be selected here. Note: Wi-Fi: Accept the Analytics Policy in the settings under WLAN to ensure optimal remote assistance if service is needed. Note: If the device is not used for several minutes, it switches over to standby mode. The display will turn off. A white LED will light up on the right side under the touchscreen. The device switches back to operating mode when the touchscreen is touched. The standby time can be changed in “SETTINGS.” EN 7 6 PACOTIZING ® – CUTTING – WHIPPING 6.1 BEFORE PACOTIZING® Fill the pacotizing ® beaker with the food preparation. Note: Ensure when filling the pacotizing ® beaker that a smooth surface can be created, the beaker is filled no higher than the fill line, and there are no cavities (if necessary, fill these with liquid – water, broth, etc.). Mixtures must not be frozen too hard. Note: An overfilled pacotizing ® beaker will be detected, and the volume will be reduced down to the maximum permissible. After this automated process is complete, remove the pacotized ® mass from t…

Text truncated - open the document above for the full version.

FCC ID: 2A7QD‐PJ4V00 IC: 28742‐PJ4V00 HVIN: PJ4V0 G0M‐2203‐1368 FCC ID: 2A7QD‐PJ4V00 IC: 28742‐PJ4V00 HVIN: PJ4V0 G0M‐2203‐1368 FCC ID: 2A7QD‐PJ4V00 IC: 28742‐PJ4V00 HVIN: PJ4V0 G0M‐2203‐1368

FCC ID: 2A7QD‐PJ4V00 IC: 28742‐PJ4V00 HVIN: PJ4V0 G0M‐2203‐1368 FCC ID: 2A7QD‐PJ4V00 IC: 28742‐PJ4V00 HVIN: PJ4V0 G0M‐2203‐1368 FCC ID: 2A7QD‐PJ4V00 IC: 28742‐PJ4V00 HVIN: PJ4V0 G0M‐2203‐1368

FCC ID: 2A7QD‐PJ4V00 IC: 28742‐PJ4V00 HVIN: PJ4V0 G0M‐2203‐1368 FCC ID: 2A7QD‐PJ4V00 IC: 28742‐PJ4V00 HVIN: PJ4V0 G0M‐2203‐1368 ESP32‐S2‐WROOM‐I Module w‐o shielding: FCC ID: 2A7QD‐PJ4V00 IC: 28742‐PJ4V00 HVIN: PJ4V0 G0M‐2203‐1368 FCC ID: 2A7QD‐PJ4V00 IC: 28742‐PJ4V00 HVIN: PJ4V0 G0M‐2203‐1368 FCC ID: 2A7QD‐PJ4V00 IC: 28742‐PJ4V00 HVIN: PJ4V0 G0M‐2203‐1368 FCC ID: 2A7QD‐PJ4V00 IC: 28742‐PJ4V00 HVIN: PJ4V0 G0M‐2203‐1368 FCC ID: 2A7QD‐PJ4V00 IC: 28742‐PJ4V00 HVIN: PJ4V0 G0M‐2203‐1368

Test Report No.: G0M-2203-1368-TFC091MP-V03 Eurofins Product Service GmbH Storkower Str. 38c, D-15526 Reichenwalde, Germany Page 1 of 13 RF-EXPOSURE REPORT FCC 47 CFR Part 2.1091 Maximum permissible exposure Report Reference No G0M-2203-1368-TFC091MP-V03 Testing Laboratory Eurofins Product Service GmbH Address Storkower Str. 38c 15526 Reichenwalde Germany Accreditation A2LA Accredited Testing Laboratory, Certificate No.: 1983.01 FCC Test Firm Designation Number: DE0008 Applicant Alator AG Address Bundesplatz 9 6302 Zug Switzerland Test Specification According to FCC rules Standard FCC 47 CFR 2.1091 Non-Standard Test Method None Equipment under Test (EUT): Product Description Food Processor Model(s) Pacojet 4 Additional Model(s) None Brand Name(s) Pacojet 4 Hardware Version(s) 0S Software Version(s) Module: ESP32-S2_RF_TEST_V200_40M_20200714; Main Application: 6.0 FCC-ID 2A7QD-PJ4V00 Test Result PASSED Test Report No.: G0M-2203-1368-TFC091MP-V03 Eurofins Product Service GmbH Storkower Str. 38c, D-15526 Reichenwalde, Germany Page 3 of 13 VERSION HISTORY Version History Version Issue Date Remarks Revised By 01 2022-05-02 Initial Release O. Qawasmeh 02 2023-01-24 Replaced document: G0M-2203-1368-TFC091MP-V01 Replaced by: G0M-2203-1368-TFC091MP-V02 Reasons: 1. Calculation according ISED rules removed 2. Correction of antenna gain Florian Voigt 03 2023-07-10 Replaced document: G0M-2203-1368-TFC091MP-V02 Replaced by: G0M-2203-1368-TFC091MP-V03 Reasons: 1. Using radiated/conducted fundamental power of a different test report “G0M-2203-1368-TFC247WF- V01” for calculations 2. Correction of FCC ID under “Equipment (Test Item) Under Test” information 3. Removal of ISED Limits tables 4. Evaluation of low, middle and high channel Florian Voigt Test Report No.: G0M-2203-1368-TFC091MP-V03 Eurofins Product Service GmbH Storkower Str. 38c, D-15526 Reichenwalde, Germany Page 4 of 13 ABBREVIATIONS AND ACRONYMS Acronyms Acronym Description EIRP Equivalent Isotropic Radiated Power EUT Equipment Under Test MPE Maximum Permissible Exposure Test Report No.: G0M-2203-1368-TFC091MP-V03 Eurofins Product Service GmbH Storkower Str. 38c, D-15526 Reichenwalde, Germany Page 5 of 13 REPORT INDEX 1 Equipment (Test Item) Under Test................................................................................................... 6 1.1 Reference Documents ................................................................................................................................... 7 1.2 Power density radiation sources.................................................................................................................... 8 1.3 Field strength radiation sources .................................................................................................................... 8 1.4 Concurrent Sources ...................................................................................................................................... 8 2 Result Summary ................................................................................................................................. 9 3 RF-Exposure classification ............................................................................................................ 10 4 RF-Exposure limits .......................................................................................................................... 11 5 RF-Exposure Evaluation ................................................................................................................. 12 6 Single Source Evaluation Results - FCC ...................................................................................... 13 Test Report No.: G0M-2203-1368-TFC091MP-V03 Eurofins Product Service GmbH Storkower Str. 38c, D-15526 Reichenwalde, Germany Page 6 of 13 1 Equipment (Test Item) Under Test Description Food Processor Model Pacojet 4 Additional Model(s) None Brand Name(s) Pacojet 4 Serial Number(s) 0S-02 Hardware Version(s) 0S Software Version(s) Module: ESP32-S2_RF_TEST_V200_40M_20200714; Main Application: 6.0 FCC ID 2A7QD-PJ4V00 Equipment type End Product Environment General public Test Report No.: G0M-2203-1368-TFC091MP-V03 Eurofins Product Service GmbH Storkower Str. 38c, D-15526 Reichenwalde, Germany Page 7 of 13 1.1 Reference Documents Document Type Document No. Issued by Date Radio test report FCC Part 15.247 G0M-2203-1368- TFC247WF-V01 Eurofins Product Service GmbH 2023-06-28 Test Report No.: G0M-2203-1368-TFC091MP-V03 Eurofins Product Service GmbH Storkower Str. 38c, D-15526 Reichenwalde, Germany Page 8 of 13 1.2 Power density radiation sources Mode Operating Frequency [MHz] Maximum conducted power [dBm] Maximum radiated power [dBm EIRP] Maximum duty cycle [%] Maximum antenna gain [dBi] Maximum antenna diameter [cm] IEEE 802.11 (2.4 GHz) 2412 21.4 24.4 100 3.0 N/A 2437 20.0 23.0 100 3.0 N/A 2462 18.3 21.3 100 3.0 N/A Comment: 1.3 Field strength radiation sources None 1.4 Concurrent Sources No concurrent radiation sources Test Report No.: G0M-2203-1368-TFC091MP-V03 Eurofins Product Service GmbH Storkower Str. 38c, D-15526 Reichenwalde, Germany Page 9 of 13 2 Result Summary FCC MPE Evaluation - Single radiation sources Product Standard Reference Requirement Reference Method Mode Distance [m] Verdict 47 CFR 2.1091 Maximum permissible exposure FCC KDB 447498 IEEE 802.11 (2.4 GHz) 0.20 PASS Comment: Test Report No.: G0M-2203-1368-TFC091MP-V03 Eurofins Product Service GmbH Storkower Str. 38c, D-15526 Reichenwalde, Germany Page 10 of 13 3 RF-Exposure classification RF-Exposure Categories Fixed A fixed device is defined as a device physically secured at one fixed location and cannot be easily re-located. Mobile A mobile device is defined as a transmitting device designed to be used in other than fixed locations and to generally be used in such a way that a separation distance of at least 20 centimeters is normally maintained between the transmitter's radiating structure(s) and the body of the user or …

Text truncated - open the document above for the full version.

PRODUCT SPECIFICATION REVISION: ECR/ECN INFORMATION: TITLE: WIFI 6E CABLE FLEX BALANCE ANTENNA PRODUCT SPECIFICATION SHEET No. F2 EC No: 676655 1 of 11 DATE: 2021/09/06 DOCUMENT NUMBER: CREATED / REVISED BY: CHECKED BY: APPROVED BY: PS-1461530100 Kang Cheng 2020/08/31 Cooper Zhou 2020/08/31 Stary Song 2020/08/31 TEMPLATE FILENAME: PRODUCT_SPEC[SIZE_A4](V.1).DOC TITLE WIFI 6E FLEX CABLE BALANCE ANTENNA TABLE OF CONTENTS 1. SCOPE 2. PRODUCT DESCRIPTION 3. GENERAL SPECIFICATION 4. PRODUCT STRUCTURE INFORMATION 5. APPLICABLE DOCUMENTS 6. ANTENNA SPECIFICATION 7. MECHANICAL SPECIFICATION 8. ENVIRONMENTAL SPECIFICATION 9. PACKING 10. CHANGE HISTORY PRODUCT SPECIFICATION REVISION: ECR/ECN INFORMATION: TITLE: WIFI 6E CABLE FLEX BALANCE ANTENNA PRODUCT SPECIFICATION SHEET No. F2 EC No: 676655 2 of 11 DATE: 2021/09/06 DOCUMENT NUMBER: CREATED / REVISED BY: CHECKED BY: APPROVED BY: PS-1461530100 Kang Cheng 2020/08/31 Cooper Zhou 2020/08/31 Stary Song 2020/08/31 TEMPLATE FILENAME: PRODUCT_SPEC[SIZE_A4](V.1).DOC WIFI 6E FLEX CABLE BALANCE ANTENNA 1.0 SCOPE This Product Specification covers the mechanical, electrical and environmental performances specification for WiFi 6E flex cable balance antenna. 2.0 PRODUCT DESCRIPTION 2.1 PRODUCT NAME AND SERIES NUMBER (S) Product name: WiFi 6E flex cable balance antenna Series Number: 146153 Series 2.2 DESCRIPTION Series 146153 is a balanced, dipole-type, high efficiency antenna for 2.4/5/6 GHz applications, including WiFi 6E, Bluetooth, Zigbee and others. This antenna is made from poly flexible material with small size 35*9*0.1mm and has double-sided adhesive tape for easy “peel and stick” mounting. This balanced antenna with ground plane independent design offers various cable length options for ease of integration into various devices. 2.3 FEATURES  2400~2500MHz,5150~5850MHz,5925~7125MHz, linear polarization  Ground plane independent, balanced dual band antenna  Flex size 35 x 9 x 0.1mm (not contain solder area)  IPEX MHF (U.FL compatible) connector (Such as MHF1/MHF4)  Cable OD1.13mm, 6 standard length options (50/100/150/200/250/300mm)  Cable and connector can be customized Molex 146153 SERIES 3D VIEW PRODUCT SPECIFICATION REVISION: ECR/ECN INFORMATION: TITLE: WIFI 6E CABLE FLEX BALANCE ANTENNA PRODUCT SPECIFICATION SHEET No. F2 EC No: 676655 3 of 11 DATE: 2021/09/06 DOCUMENT NUMBER: CREATED / REVISED BY: CHECKED BY: APPROVED BY: PS-1461530100 Kang Cheng 2020/08/31 Cooper Zhou 2020/08/31 Stary Song 2020/08/31 TEMPLATE FILENAME: PRODUCT_SPEC[SIZE_A4](V.1).DOC 3.0 GENERAL SPECIFICATION Product name WIFI 6E FLEX CABLE BALANCE ANTENNA Part number 146153 Frequency 2.4GHz-2.5GHz 5.15GHz- 5.85GHz 5.925GHz- 7.125GHz Polarization Linear Operating with matching -40°C to 85°C Storage with matching -40°C to 85°C RF Power 2 Watts Impedance with matching 50 Ohms Antenna type Flex Connector type 146153 0XXX 146153 1XXX Compatible MHF1 Compatible MHF4 User Implementation type Adhesive 3M9077 Cable diameter Ø1.13mm Cable length 50 mm (P/N for 1461530050/1461531050) 100 mm (P/N for 1461530100/1461531100) 150 mm (P/N for 1461530150/1461531150) 200 mm (P/N for 1461530200/1461531200) 250 mm (P/N for 1461530250/1461531250) 300 mm (P/N for 1461530300/1461531300) PRODUCT SPECIFICATION REVISION: ECR/ECN INFORMATION: TITLE: WIFI 6E CABLE FLEX BALANCE ANTENNA PRODUCT SPECIFICATION SHEET No. F2 EC No: 676655 4 of 11 DATE: 2021/09/06 DOCUMENT NUMBER: CREATED / REVISED BY: CHECKED BY: APPROVED BY: PS-1461530100 Kang Cheng 2020/08/31 Cooper Zhou 2020/08/31 Stary Song 2020/08/31 TEMPLATE FILENAME: PRODUCT_SPEC[SIZE_A4](V.1).DOC 4.0 PRODUCT STRUCTURE INFORMATION P/N 146153 0XXX Mechanical Structure Information for 1461530XXX PRODUCT SPECIFICATION REVISION: ECR/ECN INFORMATION: TITLE: WIFI 6E CABLE FLEX BALANCE ANTENNA PRODUCT SPECIFICATION SHEET No. F2 EC No: 676655 5 of 11 DATE: 2021/09/06 DOCUMENT NUMBER: CREATED / REVISED BY: CHECKED BY: APPROVED BY: PS-1461530100 Kang Cheng 2020/08/31 Cooper Zhou 2020/08/31 Stary Song 2020/08/31 TEMPLATE FILENAME: PRODUCT_SPEC[SIZE_A4](V.1).DOC P/N 146153 1XXX Mechanical Structure Information for 1461531XXX PRODUCT SPECIFICATION REVISION: ECR/ECN INFORMATION: TITLE: WIFI 6E CABLE FLEX BALANCE ANTENNA PRODUCT SPECIFICATION SHEET No. F2 EC No: 676655 6 of 11 DATE: 2021/09/06 DOCUMENT NUMBER: CREATED / REVISED BY: CHECKED BY: APPROVED BY: PS-1461530100 Kang Cheng 2020/08/31 Cooper Zhou 2020/08/31 Stary Song 2020/08/31 TEMPLATE FILENAME: PRODUCT_SPEC[SIZE_A4](V.1).DOC 5.0 APPLICABLE DOCUMENTS DOCUMENT NUMBER DESCRIPTION Sale Drawing (SD) SD-1461530050 Mechanical Dimension of the product SD-1461531050 Application Guide (AS) AS-1461530100 Antenna Application and surrounding Packing Drawing (PK) PK-1461530100 Product packaging specifications 6.0 ANTENNA SPECIFICATION All measurements are done of the antenna mounted on a PC/ABS material block of 1.5 mm thickness with VNA Agilent E5071C and Over-The-Air (OTA) chamber. All measurements in this document are done with the part no.1461530100 for different cable length. 6.1 ELECTRICAL REQUIREMENT 6.1.1 ELECTRICAL REQUIREMENTS FOR CABLE LENGHTH 50mm P/N 1461530050 Frequency Range 2.4GHz-2.5GHz 5.15GHz-5.85GHz 5.925-7.125GHz Peak Gain (Max) 3.2dBi 4.25dBi 5.8dBi Average Total efficiency >78% >79% >75% Return Loss < -10 dB < -10 dB < -10 dB 6.1.2 ELECTRICAL REQUIREMENTS FOR CABLE LENGHTH 100mm P/N 1461530100 Frequency Range 2.4GHz-2.5GHz 5.15GHz-5.85GHz 5.925-7.125GHz Peak Gain (Max) 3.0dBi 4.0dBi 5.5dBi Average Total efficiency >75% >75% >70% Return Loss < -10 dB < -10 dB < -10 dB 6.1.3 ELECTRICAL REQUIREMENTS FOR CABLE LENGHTH 150mm P/N 1461530150 Frequency Range 2.4GHz-2.5GHz 5.15GHz-5.85GHz 5.925-7.125GHz Peak Gain (Max) 2.8dBi 3.7dBi 5.2dBi Average Total efficiency >72% >70% >65% Return Loss < -10 dB < -10 dB < -10 dB PRODUCT SPECIFICATION REVISION: ECR/ECN INFORMATION: TITLE: WIFI 6E CABLE FLEX BALANCE ANTENNA PRODUCT SPECIFICATION SHEET No. F2 EC No: 676655 7 of 11 DATE: 2021/09/06 DOCUMENT NUMBER: CREATE…

Text truncated - open the document above for the full version.

Test Report No.: G0M-2203-1368-EF0115B-V01 Eurofins Product Service GmbH Storkower Str. 38c, D-15526 Reichenwalde, Germany Page 1 of 42 EMC TEST REPORT Title 47 CFR Part 15B, ISED ICES-003 Issue 7 Report Reference No G0M-2203-1368-EF0115B-V01 Testing Laboratory Eurofins Product Service GmbH Address Storkower Str. 38c 15526 Reichenwalde Germany Accreditation A2LA - Registration number: 1983.01 (ISED) ISED wireless device testing laboratory: CN 3470A DAkkS - Registration number : D-PL-12092-01-04 (FCC) FCC Filed Test Laboratory, Reg.-No.: 96970 Applicant Alator AG Address Bundesplatz 9 6302 Zug Switzerland Test Specification Standard(s) Title 47 CFR Part 15 Subpart B ISED ICES-Gen Issue 1 ; Amendment 1 (February 2021) ISED ICES-003 Issue 7 ANSI C63.4:2014+A1:2017 Non-Standard Test Method None Equipment under Test (EUT): Product Description Food Processor Model(s) Pacojet 4JAW Additional Model(s) None Brand Name(s) Pacojet 4 Hardware Version(s) 0S Software Version(s) Module: ESP32-S2_RF_TEST_V200_40M_20200714 Main Application: 6.0 FCC-ID 2A7QD-PJ4V00 IC 28742-PJ4V00 Test Result PASSED Test Report No.: G0M-2203-1368-EF0115B-V01 Eurofins Product Service GmbH Storkower Str. 38c, D-15526 Reichenwalde, Germany Page 3 of 42 ABBREVIATIONS AND ACRONYMS Acronyms Acronym Description EUT Equipment Under Test FCC Federal Communications Commission ISED Innovation, Science and Economic Development Canada T NOM Nominal operating temperature V NOM Nominal supply voltage Test Report No.: G0M-2203-1368-EF0115B-V01 Eurofins Product Service GmbH Storkower Str. 38c, D-15526 Reichenwalde, Germany Page 4 of 42 VERSION HISTORY Version History Version Issue Date Remarks Revised By 01 2022-08-29 Initial Release - Test Report No.: G0M-2203-1368-EF0115B-V01 Eurofins Product Service GmbH Storkower Str. 38c, D-15526 Reichenwalde, Germany Page 5 of 42 REPORT INDEX 1 Equipment (Test Item) Under Test................................................................................................... 6 1.1 Equipment Ports ............................................................................................................................................ 7 1.2 Equipment Photos - Internal .......................................................................................................................... 8 1.3 Equipment Photos - External ....................................................................................................................... 17 1.4 Support Equipment ...................................................................................................................................... 20 1.5 Operational Modes ...................................................................................................................................... 20 1.6 EUT Configuration ....................................................................................................................................... 20 1.7 Sample emission level calculation ............................................................................................................... 21 2 Result Summary ............................................................................................................................... 22 2.1 Test Conditions and Results - Radiated emissions acc. to ANSI C63.4 ...................................................... 23 2.2 Test Conditions and Results - Conducted emissions acc. to ANSI C63.4 ................................................... 34 3 Measurement Uncertainty .............................................................................................................. 42 Test Report No.: G0M-2203-1368-EF0115B-V01 Eurofins Product Service GmbH Storkower Str. 38c, D-15526 Reichenwalde, Germany Page 6 of 42 1 Equipment (Test Item) Under Test Description Food Processor Intended Use EUT pacotises, minces, purees or whips various masses Model Pacojet 4JAW Additional Model(s) None Brand Name(s) Pacojet 4 Hardware Version(s) 0S Software Version(s) Module: ESP32-S2_RF_TEST_V200_40M_20200714 Main Application: 6.0 Number of tested samples 1 Sample Identification EUT # Sample-ID Serial Number EUT 1 40368 220100140011 EUT Dimensions [cm] 49.7 x 20.7 x 36.5 FCC-ID 2A7QD-PJ4V00 IC 28742-PJ4V00 Class Class B Equipment type Table top Highest internal frequency [MHz] 2483 Protective Earth Yes (realized via PE) Radio Module Type IEEE 802.11 bgn radio module Model ESP32-S2-WROOM-I Manufacturer Espressif FCC-ID AC7Z-ESP32S2WROOM IC none Supply Voltage V NOM 120 V AC / 60 Hz AC/DC-Adaptor None Manufacturer Noventa AG Sonnenstrasse 1 9444 Diepoldsau Switzerland Test Report No.: G0M-2203-1368-EF0115B-V01 Eurofins Product Service GmbH Storkower Str. 38c, D-15526 Reichenwalde, Germany Page 7 of 42 1.1 Equipment Ports Name Type Attributes Comment Power AC Count: Cable length [m]: Direction: Service only: Shielded: 1 2.5 IN No No - USB IO Count: Cable length [m]: Direction: Service only: Shielded: 1 0 IO Yes Yes internally installed (not tested) Description: AC AC mains power input/output port DC DC power input/output port BAT DC power input port connected to external battery IO Input/Output port TP Telecommunication port NE Non-electrical port Test Report No.: G0M-2203-1368-EF0115B-V01 Eurofins Product Service GmbH Storkower Str. 38c, D-15526 Reichenwalde, Germany Page 8 of 42 1.2 Equipment Photos - Internal EUT WITH OPEN COVER EUT WITHOUT COVER TOP SIDE Test Report No.: G0M-2203-1368-EF0115B-V01 Eurofins Product Service GmbH Storkower Str. 38c, D-15526 Reichenwalde, Germany Page 9 of 42 EUT WITHOUT MAIN PCB TOP SIDE EUT WITHOUT COVER FRONT SIDE Test Report No.: G0M-2203-1368-EF0115B-V01 Eurofins Product Service GmbH Storkower Str. 38c, D-15526 Reichenwalde, Germany Page 10 of 42 EUT WITHOUT COVER REAR SIDE EUT MAIN PCB TOP SIDE Test Report No.: G0M-2203-1368-EF0115B-V01 Eurofins Product Service GmbH Storkower Str. 38c, D-15526 Reichenwalde, Germany Page 11 of 42 EUT MAIN PCB BOTTOM SIDE EUT CONNEC…

Text truncated - open the document above for the full version.

Test Report No.: G0M-2203-1368-TFC247WF-V01 Eurofins Product Service GmbH Storkower Str. 38c, D-15526 Reichenwalde, Germany Page 1 of 102 RADIO REPORT FCC 47 CFR Part 15C ISED Canada RSS-247 Digital transmission systems operating within the 2400.0 MHz - 2483.5 MHz band Report Reference No G0M-2203-1368-TFC247WF-V01 Testing Laboratory Eurofins Product Service GmbH Address Storkower Str. 38c 15526 Reichenwalde Germany Accreditation DAkkS - Registration number : D-PL-12092-01-04 (FCC) FCC Filed Test Laboratory, Reg.-No.: 96970 Applicant Alator AG Address Bundesplatz 9 6302 Zug Switzerland Test Specification 47 CFR Part 15C Non-Standard Test Method None Equipment under Test (EUT): Product Description Food Processor Model(s) Pacojet 4 Additional Model(s) None Brand Name(s) Pacojet 4 Hardware Version(s) 0S Software Version(s) Module: ESP32-S2_RF_TEST_V200_40M_20200714; Main Application: 6.0 FCC ID 2A7QD-PJ4V00 IC 28742-PJ4V00 Test Result PASSED Test Report No.: G0M-2203-1368-TFC247WF-V01 Eurofins Product Service GmbH Storkower Str. 38c, D-15526 Reichenwalde, Germany Page 3 of 102 VERSION HISTORY Version History Version Issue Date Remarks Revised By 01 2023-06-28 Initial Release Test Report No.: G0M-2203-1368-TFC247WF-V01 Eurofins Product Service GmbH Storkower Str. 38c, D-15526 Reichenwalde, Germany Page 4 of 102 ABBREVIATIONS AND ACRONYMS Acronyms Acronym Description BPSK Binary Phase Shift Keying DSSS Direct Sequence Spread Spectrum EUT Equipment Under Test FCC Federal Communications Commission HT High Throughput IEEE 802.11 MAC and PHY Layer for WiFi ISED Innovation, Science and Economic Development Canada OFDM Orthogonal Frequency Division Multiplexing QAM Quadrature Amplitude Modulation QPSK Quadrature Phase Shift Keying RBW Resolution bandwidth RMS Root mean square VBW Video bandwidth V NOM Nominal supply voltage Test Report No.: G0M-2203-1368-TFC247WF-V01 Eurofins Product Service GmbH Storkower Str. 38c, D-15526 Reichenwalde, Germany Page 5 of 102 REPORT INDEX 1 Equipment (Test Item) Under Test................................................................................................... 6 1.1 Photos – Equipment External ........................................................................................................................ 7 1.2 Photos – Equipment Internal ....................................................................................................................... 10 1.3 Support Equipment ...................................................................................................................................... 19 1.4 Test Modes ................................................................................................................................................. 20 1.5 Test Frequencies ......................................................................................................................................... 21 1.6 Sample emission level calculation ............................................................................................................... 22 2 Result Summary ............................................................................................................................... 23 3 Test Conditions and Results .......................................................................................................... 24 3.1 Test Conditions and Results - Occupied bandwidth .................................................................................... 24 3.2 Test Conditions and Results - 6 dB bandwidth ............................................................................................ 35 3.3 Test Conditions and Results - Maximum peak conducted output power ..................................................... 46 3.4 Test Conditions and Results - Power spectral density ................................................................................ 48 3.5 Test Conditions and Results - AC powerline conducted emissions ............................................................. 59 3.6 Test Conditions and Results - Band-edge compliance ................................................................................ 63 3.7 Test Conditions and Results - Conducted spurious emissions .................................................................... 71 3.8 Test Conditions and Results - Transmitter radiated emissions ................................................................... 82 3.9 Test Conditions and Results - Receiver radiated emissions ....................................................................... 88 ANNEX A Transmitter spurious emissions ....................................................................................................... 93 ANNEX A Receiver spurious emissions ........................................................................................................... 99 Test Report No.: G0M-2203-1368-TFC247WF-V01 Eurofins Product Service GmbH Storkower Str. 38c, D-15526 Reichenwalde, Germany Page 6 of 102 1 Equipment (Test Item) Under Test Description Food Processor Model Pacojet 4 Additional Model(s) N…

Text truncated - open the document above for the full version.
