2A7T3-C10Customized Dash Camera

High definition driving recorder Wireless WI FI versio n o f smart pho ne An instruction manual Users: Dear customer friend, thank you for purchasing the high traffic recorder product produced by our company. This product uses the mainstream of the market on the market as the main chip of the main control codec chip, the pure hardware codec 1080P vehicle record image, for you to provide the real meaning of the HD recording picture. Structure design, compact size, exquisite appearance, special car and completely hidden installation, users can install and debug themselves, and the product does not contain lithium batteries, the safety performance is excellent, please be assured of use. Illuminance CMOS WXGA HD HD photoreceptor chip has unique mounting structure design, so that it can be applied to various vehicle areas and bring convenience to you. A safe and colorful daily life. 30 frames per second (FPS) high definition HD (1920*1080) video, video file can be selective recording function; the dynamic picture continuity is very strong; there is automatic coverage function, can circulate video function, no need to worry about memory card full; support playback recording video function; card memory card the highest support 32G-TF multifunction New high-tech products. It is mainly applied to vehicle mounted video recording, which is the best helper to effectively improve traffic safety accident forensics. Before using this product, please read this user's manual in detail and keep this manual. We hope this product can meet your needs and serve you for a long time! Description of wiring Installation instructions 1. Turn off the car engine 2. The TF card is correctly inserted into the recorder card slot. [note] please use high-speed TF Card (above Class6), capacity is not less than 2MB, TF card maximum support 32GB. 3. Connect yellow power line to 12V power supply, red ACC ignition control line, black grounding, yellow joint video AV output to AVI input interface of navigation. Start the engine, check that the machine is installed correctly, the LED indicator lights up and blinks, and the machine starts to enter the video recording state. Introduction of key function Reset hole Indicator light photographing / menu Power / confirmation Micropho ne 2 key version 3 key version Open, turn off / confirm key 1. State, short press Start with a long press 3 seconds shutdown, video preview and video, in order to play the pause button. 2. Function selection is short as the confirmation key. Photographing /Menu key 1. Short press for Photographing /Menu key quick photo. . 2. After pause recording, long press the Photographing /Menu key to enter the menu mode (need to connect the CarDVD screen display) 3. Press and hold the Photographing /Menu key for 15 seconds in the recording state to restore the factory settings. 4. In the menu mode, short press the Photographing /Menu key to select the menu, long press to exit the menu mode. Upwards key 1. Short press the Upwards key to switch between the front and rear lens display modes. 2. Short press the Upwards key on the menu bar to select the upper menu option.. Reset hole Any state short press Reset hole to automatically reset and restart the system. LED scintillation indicator 1. In the WIFI state, the recording blue light flashes once in 1 second. In the WIFI state, the recording blue light is always on. The red light is on. 2. The system upgrade blue light flashes flashing for 0.3 seconds. 3. The red light is on and flashing to indicate no WiFi recording. 4. If the red light is steady, the recorder is faulty. Note: This recorder will automatically videotape in the preview and WIFI mode. 1. Download “Roadcam” (1) : iPhone Search “Roadcam” on AppStore (2) : Android Phone Search “Roadcam” on Google Play 2. Connect Mobile Phone with tachograph by WIFI: (1) :Press (2) :Choose a WIFI hotspot and press connect (3) :Then the live video screen of tachograph can be viewed. Function introduction of RoadCam 1.［recorded video］ Tachograph video list which can be viewed and download. 2.［picture］ Tachograph photo list which can be viewed and download. 3.［Record］ Press to record video 4.［take photo］ Press to Snap Product parameters Master chip: low power import processor Screen: mobile A P P intelligent connection display / car DVD navigation screen Resolution:1920*1080P Video angle: high resolution wide-angle lens Video format:H.264 compression, *MOV Video clip:1 minutes /3 minutes /5 minutes / Video mode: Circular video, automatic coverage Video resolution:HD, 1296P 30 frame /S Video signal:NTSC/PAL (default NTSC) Microphone: support (by default) Storage card:8~32G, CLASS 10 above Power supply mode: ignition with ACC Language: multilingual language (the default Chinese) Gravity sensor: three axis solid acceleration sensor (open by default) Seamless video: seamless connection of each video without missing seconds. Time imprint: time accurate overprint on video Video playback: you can directly select the required segments for playback. Temperature range: - 20 degree C~75 C Common fault treatment Warm reminder: this system supports the largest 32GMicroSD card storage. In order to ensure normal video recording, it is recommended to use genuine memory cards, such as Kingston, Samsung and so on. Since the recording system does not stop reading and writing data, it is suggested that the Class10 high-speed digit card should be used, and the SD card is not inserted when the system is open so as not to cause the damage of the storage card. 1. do not turn on after starting the car: please check whether the connection is normally electrified. 2. can not be videotaped after the opening: please check if the TF card is inserted or the TF card is formatted once; TF card is damaged or not; if there is a problem, please reinsert the card or formatted TF card once or replace the new card. 3. there is an abnormal phenomenon such as crash. Please press reset key RESET. 4. the video is blurre…

Text truncated - open the document above for the full version.

FCC ID: 2A7T3-C10 C10 External Photos of the EUT Photo 1 Photo 2 Photo 3 FCC ID: 2A7T3-C10 Photo 4 Photo 5 Photo 6 FCC ID: 2A7T3-C10 Photo 7

Label and Location Size: L: 2.0cm*W: 1.0cm Label and Location Model No.: C10 FCC ID : 2A7T3-C10

FCC ID: 2A7T3-C10 C10 Internal Photos of the EUT Photo 1 Photo 2 Photo 3 2.4GWIFI Antenna FCC ID: 2A7T3-C10 Photo 4 Photo 5 Photo 6 FCC ID: 2A7T3-C10 Photo 7 Photo 8 Photo 9 FCC ID: 2A7T3-C10 Photo 10 Photo 11 Photo 12 FCC ID: 2A7T3-C10 Photo 13 Photo 14 Photo 15 FCC ID: 2A7T3-C10 Photo 16 Photo 17 Photo 18 FCC ID: 2A7T3-C10 Photo 19

RF Exposure evaluation FCC ID: 2A7T3-C10 Exposure category: General population/uncontrolled environment EUT Type: Production Unit Device Type: Mobile Device 1. Reference According to §1.1307(b)(1), systems operating under the provisions of this section shall be operated in a manner that ensures that the public is not exposed to radio frequency energy level in excess of the Commission’s guidelines. According to §1.1310 and §2.1091 RF exposure is calculated. KDB447498 D01: Mobile and Portable Devices RF Exposure Procedures and Equipment Authorization Policies 2. Limit Limits for Maximum Permissible Exposure (MPE)/Controlled Exposure Frequency Range(MHz) Electric Field Strength(V/m) Magnetic Field Strength(A/m) Power Density (mW/cm²) Averaging Time (minute) Limits for Occupational/Controlled Exposure 0.3 – 3.0 3.0 – 30 30 – 300 300 – 1500 1500 – 100,000 614 1842/f 61.4 / / 1.63 4.89/f 0.163 / / (100) * (900/f 2 )* 1.0 f/300 5 6 6 6 6 6 Limits for Maximum Permissible Exposure (MPE)/Uncontrolled Exposure Frequency Range(MHz) Electric Field Strength(V/m) Magnetic Field Strength(A/m) Power Density (mW/cm²) Averaging Time (minute) Limits for Occupational/Controlled Exposure 0.3 – 3.0 3.0 – 30 30 – 300 300 – 1500 1500 – 100,000 614 824/f 27.5 / / 1.63 2.19/f 0.073 / / (100) * (180/f 2 )* 0.2 f/1500 1.0 30 30 30 30 30 F=frequency in MHz *=Plane-wave equivalent power density 3. MPE Calculation Method Predication of MPE limit at a given distance Equation from page 18 of OET Bulletin 65, Edition 97-01 S=PG/4πR² Where: S=power density P=power input to antenna G=power gain of the antenna in the direction of interest relative to an isotropic radiator R=distance to the center of radiation of the antenna 4. Antenna Information C10 can only use antennas certificated as follows provided by manufacturer; Antenna No. Model No. of antenna: Type of antenna: Gain of the antenna (Max.) Frequency range: 2.4GWIFI / PIFA ANT 0.00dBi for 2400-2500MHz 5. Manufacturing Tolerance WIFI(Peak) Frequency (MHz) 11b 2412 2437 2462 Target (dBm) 13.0 13.0 13.0 Tolerance ± (dB) 1.0 1.0 1.0 Frequency (MHz) 11g 2412 2437 2462 Target (dBm) 13.0 13.0 13.0 Tolerance ± (dB) 1.0 1.0 1.0 Frequency (MHz) 11n(HT20) 2412 2437 2462 Target (dBm) 12.0 12.0 12.0 Tolerance ± (dB) 1.0 1.0 1.0 6. Standalone MPE Result As declared by the Applicant, the EUT is a wireless device used in a fix application, at least 20 cm from any body part of the user or nearby persons; from the maximum EUT RF output power, the minimum separation distance, r =20cm, as well as the gain of the used antenna is 0.0dBi, the RF power density can be obtained. Modulation Type Output power Antenna Gain (dBi) Antenna Gain (linear) MPE (mW/cm 2 ) MPE Limits (mW/cm 2 ) dBm mW 2.4GWIFI 14.0 25.1189 0.0 1.000 0.0050 1.0000 Remark: 1. Output power (Peak) including turn-up tolerance; 2. MPE evaluate distance is 20cm from user manual provide by manufacturer. 7. Conclusion The measurement results comply with the FCC Limit per 47 CFR 2.1091 for the uncontrolled RF Exposure of mobile device. ----------------THE END OF REPORT---------------

Shenzhen CTA Testing Technology Co., Ltd. Room 106, Building 1, Yibaolai Industrial Park, Qiaotou Community, Fuhai Street, Bao‘an District, Shenzhen, China Shenzhen CTA Testing Technology Co., Ltd. Room 106, Building 1, Yibaolai Industrial Park, Qiaotou Community, Fuhai Street, Bao’an District, Shenzhen, China Tel:+86-755 2322 5875 E-mail:[email protected] Web:http://www.cta-test.cn FCC PART 15 SUBPART C TEST REPORT FCC PART 15.247 Report Reference No. ..................... : FCC ID............................................. : CTA22063000201 2A7T3-C10 Compiled by ( position+printed name+signature) . : File administrators Kevin Liu Supervised by ( position+printed name+signature) . : Project Engineer Kevin Liu Approved by ( position+printed name+signature) . : RF Manager Eric Wang Date of issue .................................... : Jul. 08, 2022 Testing Laboratory Name .............. : Shenzhen CTA Testing Technology Co., Ltd. Address ............................................ : Room 106, Building 1, Yibaolai Industrial Park, Qiaotou Community, Fuhai Street, Bao’an District, Shenzhen, China Applicant’s name ............................ : BISDEAL (Guangzhou) International Trading Co. LTD Address ............................................ : Room 3005, Block B, South Tower of Zhongzhou Center, Pazhou Street,Haizhu District, Guangzhou City, Guangdong Province, China Test specification ........................... : Standard ........................................... : FCC Part 15.247 Shenzhen CTA Testing Technology Co., Ltd. All rights reserved. This publication may be reproduced in whole or in part for non-commercial purposes as long as the Shenzhen CTA Testing Technology Co., Ltd. is acknowledged as copyright owner and source of the material. Shenzhen CTA Testing Technology Co., Ltd. takes no responsibility for and will not assume liability for damages resulting from the reader's interpretation of the reproduced material due to its placement and context. Test item description ..................... : Customized Dash Camera Trade Mark ....................................... : Bisdeal Manufacturer .................................... : BISDEAL (Guangzhou) International Trading Co. LTD Model/Type reference ...................... : C10 Listed Models .................................. : C Modulation Type ............................... : OQPSK (DSSS) Operation Frequency ........................ : From 2412MHz to 2462MHz Rating ............................................... : DC 12V from external circuit Result ............................................... : PASS Report No.: CTA22063000201 Page 2 of 42 Shenzhen CTA Testing Technology Co., Ltd. Room 106, Building 1, Yibaolai Industrial Park, Qiaotou Community, Fuhai Street, Bao’an District, Shenzhen, China Tel:+86-755 2322 5875 E-mail:[email protected] Web:http://www.cta-test.cn T E S T R E P O R T Equipment under Test : Customized Dash Camera Model /Type : C10 Series Model No. C Applicant : BISDEAL (Guangzhou) International Trading Co. LTD Address : Room 3005, Block B, South Tower of Zhongzhou Center, Pazhou Street,Haizhu District, Guangzhou City, Guangdong Province, China Manufacturer : BISDEAL (Guangzhou) International Trading Co. LTD Address : Room 3005, Block B, South Tower of Zhongzhou Center, Pazhou Street,Haizhu District, Guangzhou City, Guangdong Province, China Test Result: PASS The test report merely corresponds to the test sample. It is not permitted to copy extracts of these test result without the written permission of the test laboratory. Report No.: CTA22063000201 Page 3 of 42 Shenzhen CTA Testing Technology Co., Ltd. Room 106, Building 1, Yibaolai Industrial Park, Qiaotou Community, Fuhai Street, Bao’an District, Shenzhen, China Tel:+86-755 2322 5875 E-mail:[email protected] Web:http://www.cta-test.cn Contents 1 T E S T S T A N D A R D S .................................................................. 4 2 S U MM A R Y ............................................................................. 5 2.1 General Remarks 5 2.2 Product Description 5 2.3 Equipment Under Test 5 2.4 Short description of the Equipment under Test (EUT) 5 2.5 EUT operation mode 5 2.6 Block Diagram of Test Setup 6 2.7 Related Submittal(s) / Grant (s) 6 2.8 Modifications 6 3 T E S T E N V I R O N M E N T ............................................................... 7 3.1 Address of the test laboratory 7 3.2 Test Facility 7 3.3 Environmental conditions 7 3.4 Test Description 8 3.5 Statement of the measurement uncertainty 8 3.6 Equipments Used during the Test 9 4 T E S T C O N D I T I O N S A N D R E S U L T S ............................................ 10 4.1 AC Power Conducted Emission 10 4.2 Radiated Emission 11 4.3 Maximum Peak Conducted Output Power 18 4.4 Power Spectral Density 19 4.5 6dB Bandwidth 22 4.6 Out-of-band Emissions 25 4.7 Antenna Requirement 32 5 T E S T S E T U P P H O T O S O F T H E E U T .......................................... 33 6 P H O T O S O F T H E E U T ............................................................. 34 Report No.: CTA22063000201 Page 4 of 42 Shenzhen CTA Testing Technology Co., Ltd. Room 106, Building 1, Yibaolai Industrial Park, Qiaotou Community, Fuhai Street, Bao’an District, Shenzhen, China Tel:+86-755 2322 5875 E-mail:[email protected] Web:http://www.cta-test.cn 1 T E S T S T A N D A R D S The tests were performed according to following standards: FCC Rules Part 15.247: Frequency Hopping, Direct Spread Spectrum and Hybrid Systems that are in operation within the bands of 902-928 MHz, 2400-2483.5 MHz, and 5725-5850 MHz. ANSI C63.10-2013: American National Standard for Testing Unlicensed Wireless Devices KDB558074 D01 v05r02: Guidance for Compliance Measurements on Digital Transmission Systems (DTS) ,Frequency Hopping Spread Spectrum System(HFSS), and Hybrid System Devices Operating Under §15.247 of The FCC rules. Report No.: CTA22063000201 Page 5 of 42 Shenzhen CTA Testing Technology Co., Ltd. Room 106, Buil…

Text truncated - open the document above for the full version.

FCC ID: 2A7T3-C10 C10 Test Setup Photos of the EUT radiation L radiation H
