2A7VD-H717ASmart Electric Kettle Pro

User Manual Model:H717A Electric Kettle Important Safety Instructions Introduction Govee Home App Operation User Servicing Instructions Pour Over Coffee Brewing Recommended Temperatures Troubleshooting Appendix 01 03 02 05 07 07 08 09 09 11 Included in the Box Contents Important Safety Instructions 01 READ AND FOLLOW ALL INSTRUCTIONS ● Do not operate this kettle if it has been damaged. ● Do not use this kettle on slippery, uneven or unstable surfaces. ● Do not place any part of this kettle (i.e., the whole machine, power cord, plug, packaging, etc.) near high-temperature heat sources such as fireplaces, heaters, and stoves. ● To protect against fire, electric shock and injury to persons, do not immerse cord or plugs in water or other liquids. ● Close supervision is necessary when any appliance is used by or near children. ● Unplug from outlet when not in use and before cleaning. Allow the kettle to cool before putting on or taking off parts, and before cleaning the appliance. ● Do not operate any appliance with a damaged cord or plug or after the appliance malfunctions, or has been damaged in any manner. Return appliance to the nearest authorized service facility for examination, repair or adjustment. ● The use of accessory attachments not recommended by the appliance manufacturer may result in fire, electric shock or injury to persons. ● Do not let cord hang over edge of table or counter, or touch hot surfaces. ● Do not place on or near a hot gas or electric burner, or in a heated oven. ● Always attach plug to appliance first, then plug cord into the wall outlet. To disconnect, turn any control off, then remove plug from wall outlet. ● Scalding may occur if the lid is removed during the brewing cycles. ● Do not use appliance for anything other than its intended use. ● Do not use gasoline, paint thinner or other chemicals to clean the kettle. ● Do not fill the kettle above the “MAX” line. ● Do not use outdoors. Household use only. ● To disconnect, press CANCEL to turn the kettle off, then remove the plug from the wall outlet. ● SAVE THESE INSTRUCTIONS CAUTION: To avoid scalding, always handle with care when there is hot water inside the kettle. CAUTION: Do not touch hot surfaces. Use handles or knobs. When using this electrical equipment, basic safety precautions should always be followed, including the following: 02 Included in the Box Item Electric Kettle Power Base User Manual Quick Start Guide Service Card Quantity 1 1 1 1 1 Power Cord & Plug ● This kettle has a 3-prong grounding plug. Always plug into a grounded electrical outlet. Any extension cord must also be a grounding-type 3-wire cord. ● The marked electrical rating of an extension cord should be at least as high as the rating of the kettle. ● This kettle uses a short power supply cord to reduce the risk of entangling or tripping. Use extension cords with care. ● Never use the cord as a handle or otherwise yank, strain or stretch the power cord. Do not allow the cord to touch hot surfaces. ● Place the kettle near the plug, so that it can be unplugged immediately from power if an emergency occurs. ● Do not operate this kettle with a damaged cord or plug. Discard the kettle or return to an authorized service facility for examination and/or repair. ● Do not cover the cord with throw rugs, runners, or similar coverings. Do not route the cord under furniture or appliances. Arrange the cord away from high traffic areas and where it will not be tripped over. ● If the power cord or plug is damaged, please contact customer service or similar professionals for repairs to avoid danger. Risk of Electric Shock & Leakage WARNING: To reduce the risk of electric shock, do not expose the kettle to water or rain. Note: If the electrical circuit is overloaded with other appliances, your kettle may not operate properly. Operate it on a separate electrical circuit. ● Do not insert any foreign objects in the air inlet or outlet when the kettle is powered on, as this may damage the kettle itself and cause electric shock or fire. ● If any part of the kettle is damaged in operation, contact customer service or a qualified professional for repair or replacement. Do not risk repairing or replacing by yourself. 03 Introduction a. Inner Lid b. Outer Lid c. Spout d. Tea Strainer e. Screen f. Control Panel g. Tea Strainer Handle h. Handle Cover i. Handle j. Kettle Base k. Power Base l. Connector This electric kettle is specially designed to provide you with a high-quality brewing experience of special kinds of tea and coffee. Part Names Controls ON OFF ON/OFF Button Press to turn the kettle on or off. When powered back on, the kettle will restore to the mode, hold temperature, and DIY set previously. a g h i j k b c d e f i 04 Memory Function The kettle will save its previous settings when powered off. When it is powered back on, the settings will resume. Smart Function Connect this kettle to Govee Home App via Wi-Fi or Bluetooth to enjoy DIY modes such as customizing temperatures, keeping warm, setting a delayed start, or setting a countdown. Functions Boil-Dry Protection The kettle will automatically switch off its heating element when there is no water left in the kettle. Please let the kettle to cool for some time before adding water into it. ＋/— Button Increase/Decrease the Temperature: When the kettle is powered on, press the “+” or “-” Button to adjust the target temperature (Temperature Range: 104°F-212°F/4 0 °C-100°C). After flashing for 3 seconds, the number will remain solid and the kettle will begin to boil water automatically based on the target temperature if no further adjustment is made. Note: ● When the kettle is operating at any mode from M1-M4 at a specific temperature and you press the “+” or “-” Button, the indicator light of the MODE icon will go out and the new temperature will flash for 3 seconds and then remain solid. 1. When the target temperature is higher than the real temperature, the kettle will continue to boil. 2. When the ta…

Text truncated - open the document above for the full version.

Rev1/26/2023 ShenzhenQianyanTechnologyLTD FederalCommunicationsCommission AuthorizationandEvaluationDivision 7435OaklandMillsRoad Columbia,MD21046 USA Date:04-16-2024 Ref:AttestationStatementsPart2.911(d)(5)(i)Filing FCCID:2A7VD-H717A ShenzhenQianyanTechnologyLTD(“theapplicant”)certifiesthattheequipmentforwhichauthorization issoughtisnot“covered”equipmentprohibitedfromreceivinganequipmentauthorizationpursuantto section2.903oftheFCCrules. Sincerely, XiaopengPan Rev1/26/2023 ShenzhenQianyanTechnologyLTD FederalCommunicationsCommission AuthorizationandEvaluationDivision 7435OaklandMillsRoad Columbia,MD21046 USA Date:04-16-2024 Ref:AttestationStatementsPart2.911(d)(5)(ii)Filing FCCID:2A7VD-H717A ShenzhenQianyanTechnologyLTD(“theapplicant”)certifiesthat,asofthedateofthefilingofthe application,theapplicantisnotidentifiedontheCoveredList(asaspecificallynamedentityoranyofits subsidiariesoraffiliates)asanentityproducing“covered”equipment. Sincerely, XiaopengPan

ShenzhenQianyanTechnologyLTD No.3301,BlockC,Section1,ChuangzhiYunchengBuilding,LiuxianAvenue,XiliCommunity,XiliStreet, NanshanDistrict,Shenzhen,China Date:2023-12-20 FEDERALCOMMUNICATIONSCOMMISSION AUTHORIZATIONANDEVALUATIONDIVISION 7435OAKLANDMILLSROAD COLUMBIA,MD21046 USA Ref:AttestationStatementsPart2.911(d)(7)Filing GranteeCode:2A7VD ApplicantFRN:0032478174 ShenzhenQianyanTechnologyLTDcertifiesthat,asofthedateofthefilingoftheapplication,GOVEE MOMENTS(US)TRADINGLIMITEDisourdesignatedU.S.agentforserviceofprocessfortheabove referencedGranteeCode.ShenzhenQianyanTechnologyLTDacceptstomaintainanagentfornoless thanoneyearafterthegranteehasterminatedallmarketingandimportationortheconclusionofany Commission-relatedproceedinginvolvingtheequipment. GOVEEMOMENTS(US)TRADINGLIMITEDaccepts,asofthedateofthefilingoftheapplication,the obligationofthedesignatedU.S.agentforserviceofprocessfortheabovereferencedGranteeCode. DesignatedU.S.AgentInformation: Name:GOVEEMOMENTS(US)TRADINGLIMITED U.S.AgentFRN:0033426016 Address:2501ChathamRdSuiteRSpringfieldIL62704 ContactPerson:JennyYou Tel.:001(206)604-2935 Email:[email protected] Sincerely, SignedonbehalfofShenzhenQianyan TechnologyLTD SignedonbehalfofGOVEEMOMENTS(US) TRADINGLIMITED Name:XiaopengPanName:JennyYou Title:ManagerTitle:Manager Date:2023-12-20Date:2023-12-20

ShenzhenQianyanTechnologyLTD Date:April16,2024 FederalCommunicationsCommission AuthorizationandEvaluationDivision ConfidentialityRequestregardingapplicationforcertificationofFCCID:2A7VD-H717A PursuanttoSections0.457and0.459oftheCommission’sRules,weherebyrequestconfidential treatmentofinformationaccompanyingthisapplicationasoutlinedbelow: ExhibitTypeFileName Schematics BlockDiagram OperationalDescription Schematic.pdf BlockDiagram.pdf OperationalDescription.pdf Theabovematerialscontaintradesecretsandproprietaryinformationnotcustomarilyreleasedto thepublic.Thepublicdisclosureofthesematerialsmaybeharmfultotheapplicantandprovide unjustifiedbenefitstoitscompetitors. TheapplicantunderstandsthatpursuanttoSection0.457oftheRules,disclosureofthis applicationandallaccompanyingdocumentationwillnotbemadebeforethedateoftheGrant forthisapplication. Sincerely, ShenzhenQianyanTechnologyLTD Signature XiaopengPan

ShenzhenQianyanTechnologyLTD FCCID:2A7VD-H717A POWEROFATTORNEY Date:April15,2024 FederalCommunicationsCommission AuthorizationandEvaluationDivision 7435OaklandMillsRoad Columbia,MD21046 ToWhomItMayConcern: We,theundersigned,herebyauthorizeWaltekTestingGroup(Foshan)Co.,Ltd. (DaraZhou)onourbehalf,toapplytotheFederalCommunicationsCommissionon ourequipment.AnyandallactscarriedoutbyWaltekTestingGroup(Foshan)Co., Ltd.(DaraZhou)onourbehalfshallhavethesameeffectasactsofourown. ThisauthorizationexpiresonApril15,2025. ThisistoadvisethatweareinfullcompliancewiththeAnti-DrugAbuseAct. We,ShenzhenQianyanTechnologyLTDarenotsubjecttoadenialoffederal benefitspursuanttoSection5301oftheAnti-DrugActof1988,21USC853a,and nopartytotheapplicationissubjecttoadenialoffederalbenefitspursuant tothatsection. Sincerely, ShenzhenQianyanTechnologyLTD Signature XiaopengPan

Waltek Testing Group (Foshan) Co., Ltd. http://www.waltek.com.cn Reference No.:WTA24F02035498W Page 1 of 3 Picture 1 Picture 2 Waltek Testing Group (Foshan) Co., Ltd. http://www.waltek.com.cn Reference No.:WTA24F02035498W Page 2 of 3 Picture 3 Picture 4 Waltek Testing Group (Foshan) Co., Ltd. http://www.waltek.com.cn Reference No.:WTA24F02035498W Page 3 of 3 Picture 5 Picture 6

19.5mm 49.5mm Smart Electric Kettle Pro Model: H717A Power Supply: AC 120V, 60Hz Rated Power:1500W Water Tank Capacity: 1.7L / 1.8QT FCC ID: 2A7VD-H717A MADE IN CHINA This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) This device must accept any interference received, including interference that may cause undesired operation. Manufacturer Shenzhen Qianyan Technology LTD No. 3301, Block C, Section 1, Chuangzhi Yuncheng Building, Liuxian Avenue, Xili Community, Xili Street, Nanshan District, Shenzhen Household Use Only CONFORMS TO UL STD.10823077828 SN:

Waltek Testing Group (Foshan) Co., Ltd. http://www.waltek.com.cn Reference No.: WTA24F02035498W Page 1 of 6 Picture 1 Picture 2 Waltek Testing Group (Foshan) Co., Ltd. http://www.waltek.com.cn Reference No.: WTA24F02035498W Page 2 of 6 Picture 3 Picture 4 Waltek Testing Group (Foshan) Co., Ltd. http://www.waltek.com.cn Reference No.: WTA24F02035498W Page 3 of 6 Picture 5 Picture 6 Waltek Testing Group (Foshan) Co., Ltd. http://www.waltek.com.cn Reference No.: WTA24F02035498W Page 4 of 6 Picture 7 Picture 8 Waltek Testing Group (Foshan) Co., Ltd. http://www.waltek.com.cn Reference No.: WTA24F02035498W Page 5 of 6 Picture 9 Picture 10 Waltek Testing Group (Foshan) Co., Ltd. http://www.waltek.com.cn Reference No.: WTA24F02035498W Page 6 of 6 Picture 11

RF Exposure Requirements 1.1 General Information Client Information Applicant ....................................... : Shenzhen Qianyan Technology LTD Address of applicant ................... : No. 3301, Block C, Section 1, Chuangzhi Yuncheng Building, Liuxian Avenue, Xili Community, Xili Street, Nanshan District, Shenzhen Manufacturer ................................. : Zhongshan An Bo Er Electrical Appliance Co.Ltd. Address of manufacturer ............. : San Yi Wei, Tongmao, Dongsheng Town, Zhongshan, Guangdong, China General Description of E.U.T FCC ID ............................................ : 2A7VD-H717A Product Name ............................... : Electric Kettle Model No. ..................................... : H717A Model Description ........................ : --- Rated Voltage ................................ : AC 120V, 60Hz, 1500W Battery Capacity ........................... : --- Power Adapter .............................. : --- Technical Characteristics of EUT Support Standards ....................... : 802.11b, 802.11g, 802.11n Frequency Range ......................... : 2412-2462MHz for 802.11b/g/n(HT20) RF Output Power .......................... : 16.76dBm (Conducted ) Modulation .................................... : 802.11b: DSSS(DBPSK/DQPSK/CCK) 802.11g/n: OFDM (BPSK/QPSK/16QAM/64QAM) Data Rate ....................................... : 1Mbps for 802.11b; 54Mbps for 802.11g; MCS7 for 802.11n Quantity of Channels ................... 11 for 802.11b/g/n(HT20) Channel Separation ...................... 5MHz Type of Antenna ........................... FPC Antenna Antenna Gain ................................ 6.32dBi 2 Applicable Standard According to §1.1307(b)(1) and KDB 447498 D01 General RF Exposure Guidance v06, system operating under the provisions of this section shall be operating in a manner that the public is not exposed to radio frequency energy level in excess limit for maximum permissible exposure. (a) Limits for Occupational / Controlled Exposure Frequency range (MHz) Electric Field Strength (E) (V/m) Magnetic Field Strength (H) (A/m) Power Density (S) (mW/cm 2 ) Averaging Times | E | 2 , | H | 2 or S (minutes) 0.3-3.0 614 1.63 (100)* 6 3.0-30 1842/f 4.89/f (900/f)* 6 30-300 61.4 0.163 1.0 6 300-1500 / / F/300 6 1500-100000 / / 5 6 (b) Limits for General Population / Uncontrolled Exposure Frequency range (MHz) Electric Field Strength (E) (V/m) Magnetic Field Strength (H) (A/m) Power Density (S) (mW/cm 2 ) Averaging Times | E | 2 , | H | 2 or S (minutes) 0.3-1.34 614 1.63 (100)* 30 1.34-30 824/f 2.19/f (180/f)* 30 30-300 27.5 0.073 0.2 30 300-1500 / / F/1500 30 1500-100000 / / 1 30 Note: f = frequency in MHz: * = Plane-wave equivalents power density 3 Calculation Method S = (30*P*G) / (377*R 2 ) S = power density (in appropriate units, e.g., mw/cm 2 ) P = power input to the antenna (in appropriate units, e.g., mw) G = power gain of the antenna in the direction of interest relative to an isotropic radiator, the power gain factor is normally numeric gain. R = distance to the center of radiation of the antenna (in appropriate units, e.g., cm), R=20cm. 4 MPE Calculation Result Frequency (MHz) Antenna Gain (dBi) Numeric gain Conducted Power (dBm) Maximum Tune-up output power PD (mW/cm2) Limit (mW/cm2) (dBm) (mW) 2462 6.32 4.29 16.76 17.00 50.12 0.04273 1.0 Result: Pass ======End of Report======

Waltek Testing Group (Foshan) Co., Ltd. http://www.waltek.com.cn Page 1 of 51 WT-510-201-12-A TEST REPORT Reference No. .................... : WTA24F02035498W001 FCC ID ................................ : 2A7VD-H717A Applicant ............................ : Shenzhen Qianyan Technology LTD Address .............................. : No. 3301, Block C, Section 1, Chuangzhi Yuncheng Building, Liuxian Avenue, Xili Community, Xili Street, Nanshan District, Shenzhen Manufacturer .................... : Zhongshan An Bo Er Electrical Appliance Co.Ltd. Address .............................. : No.39,Rongye Street, Xiaolan Town, Zhongshan, Guangdong, China Product Name .................... : Smart Electric Kettle Pro Model No. ........................... : H717A Test specification .............. : FCC CFR47 Part 15 Subpart C (Section 15.247) Date of Receipt sample .... : 2024-03-05 Date of Test ....................... : 2024-03-05 to 2024-03-22 Date of Issue ...................... : 2024-07-10 Test Report Form No. ....... : WEW-15247A-01B Test Result ......................... Pass Remarks: The results shown in this test report refer only to the sample(s) tested, this test report cannot be reproduced, except in full, without prior written permission of the company. The report would be invalid without specific stamp of test institute and the signatures of approver. Prepared By: Waltek Testing Group (Foshan) Co., Ltd. Address: 1/F., Building 19, Sunlink Machinery City, Xingye 4 Road, Guanglong Industrial Park, Chihua Neighborhood Committee, Chencun Town, Shunde District, Foshan, Guangdong, China Tel:+86-757-23811398 Fax:+86-757-23811381 E-mail:[email protected] Tested by: Approved by: Roy Hong Danny Zhou Reference No.: WTA24F02035498W001 Page 2 of 51 Waltek Testing Group (Foshan) Co., Ltd. http://www.waltek.com.cn WT-510-201-12-A 1 Revision History Test Report No. Date of Issue Description Status WTA24F02035498W001 2024-07-10 Original Valid Reference No.: WTA24F02035498W001 Page 3 of 51 Waltek Testing Group (Foshan) Co., Ltd. http://www.waltek.com.cn WT-510-201-12-A 2 Contents Page 1 REVISION HISTORY ................................................................................................................................. 2 2 CONTENTS ............................................................................................................................................... 3 3 GENERAL INFORMATION ....................................................................................................................... 4 3.1 GENERAL DESCRIPTION OF E.U.T ................................................................................................... 4 3.2 TECHNICAL CHARACTERISTICS OF EUT ........................................................................................... 4 3.3 STANDARDS APPLICABLE FOR TESTING ............................................................................................ 4 3.4 TEST FACILITY ................................................................................................................................ 5 3.5 SUBCONTRACTED ........................................................................................................................... 5 3.6 ABNORMALITIES FROM STANDARD CONDITIONS ................................................................................ 5 4 EUT SETUP AND TEST MODE ................................................................................................................ 6 5 EQUIPMENT USED DURING TEST ......................................................................................................... 7 5.1 EQUIPMENT LIST ............................................................................................................................. 7 5.2 TEST SOFTWARE ............................................................................................................................ 8 5.3 SPECIAL ACCESSORIES AND AUXILIARY EQUIPMENT ......................................................................... 8 5.4 MEASUREMENT UNCERTAINTY ......................................................................................................... 8 6 SUMMARY OF TEST RESULT ................................................................................................................ 9 6.1 ANTENNA REQUIREMENT ............................................................................................................... 10 6.2 RADIATED SPURIOUS EMISSIONS ................................................................................................... 11 6.3 POWER SPECTRAL DENSITY .......................................................................................................... 21 6.4 DTS BANDWIDTH .......................................................................................................................... 25 6.5 RF OUTPUT POWER ...................................................................................................................... 29 6.6 OUT OF BAND EMISSIONS .............................................................................................................. 34 6.7 CONDUCTED EMISSIONS................................................................................................................ 45 7 PHOTOGRAPHS TEST SETUP ............................................................................................................. 49 7.1 PHOTOGRAPHS - RADIATED EMISSION TEST SETUP ........................................................................ 49 7.2 PHOTOGRAPHS – CONDUCTED EMISSION TEST SETUP ................................................................... 50 8 PHOTOGRAPHS – EUT CONSTRUCTIONAL DETAILS ...................................................................... 51 Reference No.: WTA24F02035498W001 Page 4 of 51 Waltek Testing Group (Foshan) Co., Ltd. http://www.waltek.com.cn WT-510-201-12-A 3 General Information 3.1 General Description of E.U.T Prod…

Text truncated - open the document above for the full version.

Antennatestreport TestLaboratoryDongguanYijiaElectronicCo.,LTD Address No.59MuyuRoad,ShatouCommunity,Chang'anTown,Dongguan City,GuangdongProvince Contact:Mr.Gan13823198410 ModelH717A ManufacturerShenzhenQianyanTechnologyLTD Address No.3301,BlockC,Section1,ChuangzhiYunchengBuilding,Liuxian Avenue,XiliCommunity,XiliStreet,NanshanDistrict,Shenzhen 1.Testprocedures NameParameterMethodStandardNo. Mobile communication antenna VSWR Genericspecificaitonforantennasusedin themobilecommunications GB/T9410-2008 AntennaGain Radiationpattern Antenna Radiationefficiency IEEEStandardTestProceduresfor Antennas ANSI/IEEEStd149 -1979 2.TestEquipment EquipmentModelNo. Serial No. ManufactureCalibration Date Next calibration Date 24probe Microwave chamber MPS2450Multi- probeOTAme asurementsystems 5*5*5 YJ-PB-F01XH-IOE2023.09.012024.09.01 NetworkAnalyzer ZVB8YJ-RD-15 ROHDE&SCH WARS 2023.08.252024.08.25 Widebandradio Communication tester CMW500YJ-RD-16 ROHDE&SCH WARS 2023.08.252024.08.25 TheuncertaintywascalculatedonthebasisoftheGUMpublishedbyISO,usingtheinclusionfactorofK=2and the95%confidenceleveltoexpresstheextendeduncertainty. Item uncertainty Antennagain ±1dB Radiationefficiency士10% 3.DUTSetupPhoto 4.2.4GAntennaPhysicalSize 5.2.4GAntennaType&Gain Type:ExternalAntenna Frequency/MHzGain/dBi 24006.32 24106.2 24206.1 24306.06 24405.96 24505.99 24605.91 24706.18 24806.31 24906.21 25006.15 6.2.4GAntennaPatternPicture 2400MHz 2450MHz 2500MHz Testerby：Wuxianming

Waltek Testing Group (Foshan) Co., Ltd. http://www.waltek.com.cn Page 1 of 38 WT-510-201-12-A TEST REPORT Reference No. .................... : WTA24F02035498W002 FCC ID ................................ : 2A7VD-H717A Applicant ............................ : Shenzhen Qianyan Technology LTD Address .............................. : No. 3301, Block C, Section 1, Chuangzhi Yuncheng Building, Liuxian Avenue, Xili Community, Xili Street, Nanshan District, Shenzhen Manufacturer .................... : Zhongshan An Bo Er Electrical Appliance Co.Ltd. Address .............................. : No.39,Rongye Street, Xiaolan Town, Zhongshan, Guangdong, China Product Name .................... : Smart Electric Kettle Pro Model No. ........................... : H717A Test specification .............. : FCC CFR47 Part 15 Subpart C (Section 15.247) Date of Receipt sample .... : 2024-03-05 Date of Test ....................... : 2024-05-21 Date of Issue ...................... : 2024-07-10 Test Report Form No. ....... : WEW-15247A-01B Test Result ......................... : Pass Remarks: The results shown in this test report refer only to the sample(s) tested, this test report cannot be reproduced, except in full, without prior written permission of the company. The report would be invalid without specific stamp of test institute and the signatures of approver. Prepared By: Waltek Testing Group (Foshan) Co., Ltd. Address: 1/F., Building 19, Sunlink Machinery City, Xingye 4 Road, Guanglong Industrial Park, Chihua Neighborhood Committee, Chencun Town, Shunde District, Foshan, Guangdong, China Tel:+86-757-23811398 Fax:+86-757-23811381 E-mail:[email protected] Tested by: Approved by: Roy Hong Danny Zhou Reference No.: WTA24F02035498W002 Page 2 of 38 Waltek Testing Group (Foshan) Co., Ltd. http://www.waltek.com.cn WT-510-201-12-A 1 Revision History Test Report No. Date of Issue Description Status WTA24F02035498W002 2024-07-10 Original Valid Reference No.: WTA24F02035498W002 Page 3 of 38 Waltek Testing Group (Foshan) Co., Ltd. http://www.waltek.com.cn WT-510-201-12-A 2 Contents Page 1 REVISION HISTORY ................................................................................................................................. 2 2 CONTENTS ............................................................................................................................................... 3 3 GENERAL INFORMATION ....................................................................................................................... 4 3.1 GENERAL DESCRIPTION OF E.U.T ................................................................................................... 4 3.2 TECHNICAL CHARACTERISTICS OF EUT ........................................................................................... 4 3.3 STANDARDS APPLICABLE FOR TESTING ............................................................................................ 4 3.4 TEST FACILITY ................................................................................................................................ 5 3.5 SUBCONTRACTED ........................................................................................................................... 5 3.6 ABNORMALITIES FROM STANDARD CONDITIONS ................................................................................ 5 3.7 DISCLAIMER .................................................................................................................................... 5 4 EUT SETUP AND TEST MODE ................................................................................................................ 6 5 EQUIPMENT USED DURING TEST ......................................................................................................... 7 5.1 EQUIPMENT LIST ............................................................................................................................. 7 5.2 TEST SOFTWARE ............................................................................................................................ 8 5.3 SPECIAL ACCESSORIES AND AUXILIARY EQUIPMENT ......................................................................... 8 5.4 MEASUREMENT UNCERTAINTY ......................................................................................................... 8 6 SUMMARY OF TEST RESULT ................................................................................................................ 9 6.1 ANTENNA REQUIREMENT ............................................................................................................... 10 6.2 RADIATED SPURIOUS EMISSIONS ................................................................................................... 11 6.3 POWER SPECTRAL DENSITY .......................................................................................................... 21 6.4 DTS BANDWIDTH .......................................................................................................................... 23 6.5 RF OUTPUT POWER ...................................................................................................................... 25 6.6 OUT OF BAND EMISSIONS .............................................................................................................. 27 6.7 CONDUCTED EMISSIONS................................................................................................................ 32 7 PHOTOGRAPHS TEST SETUP ............................................................................................................. 36 7.1 PHOTOGRAPHS - RADIATED EMISSION TEST SETUP ........................................................................ 36 7.2 PHOTOGRAPHS – CONDUCTED EMISSION TEST SETUP ................................................................... 37 8 PHOTOGRAPHS – EUT CONSTRUCTIONAL DETAILS ...................................................................... 38 Reference No.: WTA24F02035498W002 Page 4 of 38 Wa…

Text truncated - open the document above for the full version.

Waltek Testing Group (Foshan) Co., Ltd. http://www.waltek.com.cn Reference No.:WTA24F02035498W Page 1 of 2 Test Setup For Radiated Emission (30MHz to 1GHz) Test Setup For Radiated Emission (Above 1GHz) Waltek Testing Group (Foshan) Co., Ltd. http://www.waltek.com.cn Reference No.:WTA24F02035498W Page 2 of 2 Test Setup For Conducted Emission
