2A7X4-XSY088Radio

2nd Generation Solar Hand Crank Radio Flashlight Emergency Power Bank with Micro-USB FUNCTION: ●3 Bright White LED ●FM / AM / WB Radio ●Recharge cell phone in emergency. ●M ultiple ways to power the radio flashlight. ●SOS Siren Function USING THE RADIO ●Turn the VOLUME dial clockwise to turn the radio o n a nd control volume. ●Select AM, FM or WB with radio band. For better reception, extend the RADIO ANTENNA. ●Turn TUNER DIAL to select station. The green tune indicator light will come on when the station selected is fully engaged. ● Press the FLAS HLIGHT SWITCH twice in one second to activate SOS Siren Function, Press it again to turn it off. TUNE DISPLAY TUNER DIAL RADIO ON/OFF & VOLUME RADIO BAND SELECTOR RADIO ANTENNA WB 162.40 162.55 FM 8 9 9 1 7 0 4 0 2 0 6 0 8 MHz X 1 0 5 07 0 9 11 0 1 30 1 5 0 1 70 KHz TUN AM 9 8 2 1 1 USING THE FLASHLIGHT ●P ress the flashlight switch to turn it on. ●Press the flashlight switch to turn it OFF. SOLAR / HANDCRANK / USB POWER A SOLAR POWER SOLAR PANEL FLASHLIGHT ON/OFF ●Place product in average sunlight for approximately 10-12 hours, the red CHARGING INDICATOR flashe s when charging. B HAND CRANK POWER ● Lift the HAND CRANK. ●Hand crank either clockwise or counterclockwise for 3- 5 minutes to activate the internal battery for initial use, or when the unit has been idle for more than 60 days. The red CHARGING INDICATOR flashes whe n c ranking ●F or subsequent charges, turn the handle crank for 2-3 minute(crank speed>=130rmp) to produce: 10~ 15 m inutes of continuous light for three LED; 10-15 minutes of continuous radio usage (medium volume); 3- 5 minutes of talk time. C USB PORT CHARGING ●Insert one end of the CHARGING CORD into the Micro USB JACK and the other end into the computer USB port. The red CHARGING INDICATOR flashes when the li-ion battery is charging. POWER OUT USB POWER IN JACK CH ARGING YOUR CELL PHONE, PDA, MP3... ● Lift the rubber tab on the side of the unit. ●Insert one end of the CHARGING CORD into the standard USB port and the other end with the external device to be charged. Charging Protection ●Red charging indicator will turn on steadily when the unit is fully charged. Discharging Protection ●When battery is overloading or short circuit, it would sto p output automatically ●When battery voltage is lower than 2.5v, Power source will shut down automatically SPECIFICATION: ●Dimensions: 128X60X45（mm） ●Weight: approximately 270g ●Maximum power consumption: 0.5W ●Frequency range： AM 520~1710 KHz FM 87~108 MHz WB: 162.400~162.550 MHz ●W orking voltage: 2.7V~4.2V ●Power source: 2000mAh Li -ion batter y. CARE AND MAINTENANCE ： ● Wipe the outside of the unit with a soft, damp cloth. ● Clean the lens with a standard lens cleaning product. ●Do not clean unit with harsh abrasive or any solvents. ●Unit is NOT waterproof totally---only waterproof Ipx3. DO NOT submerge in water. ●When unit is idle over 60 days, Or FIRST USE. Please hand crank or sunlight recharge for 3 to 5 minutes to activate the internal battery. This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. Any Changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment. Note: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: -Reorient or relocate the receiving antenna. -Increase the separation between the equipment and receiver. -Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. -Consult the dealer or an experienced radio/TV technician for help.

1/1 US Agent for Service of Process LETTER OF ATTESTATION TO: Office of Engineering Technology Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 US Agent for Service of Process: Company Name: UGK-LVMUNITEDINC FRN: 0033476375 Contact Name: Jimmychen Address: 6547NAcademyBlvd#2266,ColoradoSprings,CO80918 Telephone No: 001-323-51 04660 Email: [email protected] Applicant: Company name: Shenzhen XinSiYuan Electronic Technology Co.,Ltd Grantee code: 2A7X4 FCC ID: 2A7X4-XSY088 FRN: 0032673303 Contact Name: Hans Yi Address: 4th Floor, Building A, No. 207, Xingye2nd Road, Fenghuang Community, FuyongTown, Baoan District, Shenzhen Telephone: 18826978584 Fax: 18826978584 E-mail: [email protected] [Shenzhen XinSiYuan Electronic Technology Co.,Ltd] certifies that, as of the date of this filing of the application with the TCB, [UGK-LVMUNITEDINC] is our designated US agent for service of process for the above referenced FCC ID. [Shenzhen XinSiYuan Electronic Technology Co.,Ltd] accepts to maintain an agent for no less than one year after the grantee has terminated all marketing and importation or the conclusion of any commission related proceeding involving equipment. [UGK-LVMUNITEDINC] accepts, as of the date of the filing of the application, the obligation of the designated US agent for service of process for the above reference FCC ID. The US Agent for Service of Process is aware of and agrees to comply with the requirements outlined in the FCC Equipment Authorization Program, Report and Order FCC 22-84, and clause § 2.911. The Applicant is aware of and agrees to comply with the requirements outlined in the FCC Equipment Authorization Program, Report and Order FCC 22-84, and clause § 2.911. Date: 2023/11/25 Applicant’s Name: Hans Yi US Agent for Service of Process’s Name: Jimmychen Title: Manager Title: Manager Signature Signature

C5266091_X24_Ed.2 1/1 “Attestation Statements” TO: Office of Engineering Technology Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 The Commission adopted rules that prohibit equipment authorization for “covered” telecommunications equipment and video surveillance equipment produced by entities identified on the Commission’s Covered List 1 , which is periodically updated. See the Covered List for more details. This Attestation Statement is to confirm that we follow the Section 2.911(d)(5)(i)-(ii) Applicant Company name: Shenzhen XinSiYuan Electronic Technology Co.,Ltd Grantee code: 2A7X4 FCC ID: 2A7X4-XSY088 FRN: 0032673303 Contact Name: Hans Yi Address: 4th Floor, Building A, No. 207, Xingye2nd Road, Fenghuang Community, FuyongTown, Baoan District, Shenzhen Telephone: 18826978584 Fax: 18826978584 E-mail: [email protected] i. [Shenzhen XinSiYuan Electronic Technology Co.,Ltd] (“the applicant”) certifies that the equipment for which authorization is sought is not “covered” equipment prohibited from receiving an equipment authorization pursuant to section 2.903 of the FCC rules. The applicant must sign this certification. ii. [Shenzhen XinSiYuan Electronic Technology Co.,Ltd] (“the applicant”) certifies that, as of the date of the filing of the application, the applicant [is not] (as a specifically named entity or any of its subsidiaries or affiliates) identified on the Covered List as an entity producing “covered” equipment. The applicant must sign this certification. [Shenzhen XinSiYuan Electronic Technology Co.,Ltd] (“the applicant”) certifies that, as of the date of the filing of the application, the applicant [ is not] identified on the Covered List as an entity producing “covered”equipment . Date: 2023/11/25 Applicant’s Name: Hans Yi Title: Manager Signature 1 The Commission’s Covered List is published by the Public Safety and Homeland Security Bureau and posted on the Commission’s website. This Covered List, which is periodically updated, identifies particular equipment, produced by particular entities, that constitutes “covered” equipment. https://www.fcc.gov/supplychain/coveredlist

Shenzhen XinSiYuan Electronic Technology Co.,Ltd 1/1 Letter of Authorization Company: Shenzhen XinSiYuan Electronic Technology Co.,Ltd Address: 4th Floor, Building A, No. 207, Xingye2nd Road, Fenghuang Community, FuyongTown, Baoan District, Shenzhen Product Name: Radio Model Number: XSY088 FCC Identifier: 2A7X4-XSY088 We authorize LGAI Technological Center S.A., Ronda de la Font del Carme, s/n, 08193 Bellaterra, Spain, to act on our behalf on all matters concerning the above named equipment. Any individual within LGAI Technological Center S.A. is authorized to act on our behalf and take action on the application. We declare that authorize LGAI Technological Center S.A., Ronda de la Font del Carme, s/n, 08193 Bellaterra, Spain, is allowed to forward all information related to the approval project to the Federal Communication Commission and to discuss any issues concerning the approval application. Any and all acts carried out by LGAI Technological Center S.A. on our behalf shall have the same effect as acts of our own. Name: Hans Yi Date: 2023-11-25 Title: Manager Signature of applicant:

Shenzhen XinSiYuan Electronic Technology Co.,Ltd 1/1 Office of Engineering Technology Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 Date: 2023-11-25 Subject: Request for Confidentiality FCC ID: 2A7X4-XSY088 To Whom It May Concern, Pursuant to the provisions of Sections 0.457 and 0.459 of Commission's rules (47CFR0.457, 0.459), we are requesting the Commission to withhold the following attachment(s) as confidential document from public disclosure. Exhibits Long-Term Confidentiality Short-Term Confidentiality NOTE 2 ID Label/Location No No Attestation Statement No No External Photos No ☐ Block Diagram ☒ ☐ Schematics ☒ ☐ Test Report No No Test Setup Photos No ☐ User’s Manual No ☐ Internal Photos No ☐ Parts List / Tune Up ☐ ☐ RF Exposure Info No No Operational Description ☒ ☐ Cover Letter(s) No No SDR Software / Security Info ☐ No NOTE 1: Long-Term Confidentiality may be permitted under special conditions (See II. LONG-TERM CONFIDENTIALITY, Section 3 of KDB 726920, use last in force) NOTE 2: Short-Term Confidentiality can be requested for a maximum of 180 days from the date of the grant. Above mentioned document contains detailed system and equipment description are considered as proprietary information in operation of the equipment. The public disclosure of above documents might be harmful to our company and would give competitor an unfair advantage in the market. It is our understanding that all measurement test reports, FCC ID label format and correspondent during certification review process cannot be granted as confidential documents and those information will be available for public review once the grant of equipment authorization is issued. Sincerely, Name: Hans Yi Date: 2023-11-25 Title: Manager Signature of applicant:

FM/AM/WB RXANT

Size:16*12mm M/N: XSY088 FCC ID: 2A7X4-XSY088 Label location

丁成 代启旺 为重要尺寸符号。 为更改尺寸符号。 材料要求： 表面处理：

Shenzhen DL Testing Technology Co., Ltd. Report No.: DL-20231117033E Test Report Tel: 400-688-3552 Web:www.dl-cert.com Email: [email protected] Page 1 of 23 FCC TEST REPORT FCC ID: 2A7X4-XSY088 Applicant: Shenzhen XinSiYuan Electronic Technology Co.,Ltd Address: 4th Floor, Building A, No. 207, Xingye2nd Road, Fenghuang Community, FuyongTown, Baoan District, Shenzhen Manufacturer: Shenzhen XinSiYuan Electronic Technology Co.,Ltd Address: 4th Floor, Building A, No. 207, Xingye2nd Road, Fenghuang Community, FuyongTown, Baoan District, Shenzhen EUT: Radio Trade Mark: N/A Model Number: XSY088 Date of Receipt: Nov. 08, 2023 Test Date: Nov. 08, 2023 - Nov. 17, 2023 Date of Report: Nov. 17, 2023 Prepared By: Shenzhen DL Testing Technology Co., Ltd. Address: 101-201, Building C, Shuanghuan, No.8, Baoqing Road, Baolong Industrial Zone, Baolong Street, Longgang District, Shenzhen, Guangdong, China Applicable Standards: FCC Part 15 Subpart B ANSI C63.4:2014 Test Result: Pass Report Number: DL-20231117033E Prepared (Test Engineer): Alisa Song Reviewer (Supervisor): Jack Bu Approved (Manager): Jade Yang This test report is based on a single evaluation of one sample of above mentioned products. It is not permitted to be duplicated in extracts without written approval of Shenzhen DL Testing Technology Co., Ltd. Shenzhen DL Testing Technology Co., Ltd. Report No.: DL-20231117033E Test Report Tel: 400-688-3552 Web:www.dl-cert.com Email: [email protected] Page 2 of 23 TABLE OF CONTENT Test Report Declaration Page 1. VERSION................................................................................................................................................................ 3 2. TEST SUMMARY .................................................................................................................................................. 3 3. GENERAL INFORMATION ................................................................................................................................. 4 4. TEST INSTRUMENT USED ................................................................................................................................ 5 5. CONDUCTED EMISSION TEST ........................................................................................................................ 6 6. RADIATION EMISSION TEST .......................................................................................................................... 10 7. SETUP PHOTOGRAPHS .................................................................................................................................. 16 8. EUT PHOTOGRAPHS ....................................................................................................................................... 18 Shenzhen DL Testing Technology Co., Ltd. Report No.: DL-20231117033E Test Report Tel: 400-688-3552 Web:www.dl-cert.com Email: [email protected] Page 3 of 23 1. VERSION Version No. Date Description 00 Nov. 17, 2023 Original 2. TEST SUMMARY EMC Emission Standard Test Item Limit Result Remark FCC PART 15 B Conducted Emission at power ports Class B PASS Radiated Emission below 1GHz Class B PASS Radiated Emission above 1GHz Class B PASS NOTE: (1)” N/A” denotes test is not applicable in this Test Report Test lab: Shenzhen DL Testing Technology Co., Ltd. Address: 101-201, Building C, Shuanghuan, No.8, Baoqing Road, Baolong Industrial Zone, Baolong Street, Longgang District, Shenzhen, Guangdong, China FCC Test Firm Registration Number: 854456 Designation Number: CN1307 IC Registered No.: 27485 CAB ID.: CN0118 Shenzhen DL Testing Technology Co., Ltd. Report No.: DL-20231117033E Test Report Tel: 400-688-3552 Web:www.dl-cert.com Email: [email protected] Page 4 of 23 3. GENERAL INFORMATION 3.1 Description of Device (EUT) EUT: Radio Trade Mark: N/A Model Number: XSY088 Test Model: XSY088 Model difference: N/A Power Supply: DC 5V from charger Battery: 3.7V Frequency range: AM: 520~1710 KHz FM: 87~108 MHz WB: 162.400~162.550 MHz Working Frequency: Above 108MHz 3.2 Tested System Details None. 3.3 Block Diagram of Test Set-up 3.4 Test Mode Description Mode1. FM+Light Mode Mode2. AM+Light Mode Mode3. WB+Light Mode Mode4. FM+USB Output Mode Mode5. AM+USB Output Mode Mode6. WB+USB Output Mode Mode7. Charging Mode 3.5 Test Auxiliary Equipment Adapter (Provide by test lab): Manufacturer: HAIWEI Model: HW-0501000E I/P: AC 100-240V 50/60Hz O/P: DC 5V 1A 3.6 Test Uncertainty Conducted Emission Uncertainty : ±2.56dB Radiated Emission Uncertainty(<1G) : ±3.65dB Radiated Emission Uncertainty (>1G) ±4.89dB EUT Adapter AC mains Shenzhen DL Testing Technology Co., Ltd. Report No.: DL-20231117033E Test Report Tel: 400-688-3552 Web:www.dl-cert.com Email: [email protected] Page 5 of 23 4. TEST INSTRUMENT USED For Conducted Emission Test (843 Shielded Room) Equipment Manufacturer Model Serial Last Cal. Next Cal. 843 Shielded Room ChengYu 843 Room 843 Sep. 20, 2022 Sep. 19, 2025 EMI Receiver R&S ESR 101421 Nov. 04, 2023 Nov. 03, 2024 LISN R&S ENV216 102417 Nov. 04, 2023 Nov. 03, 2024 Clamp COM-POWER CLA-050 431071 Nov. 04, 2023 Nov. 03, 2024 3-Loop Antenna DAZE ZN30401 13021 Nov. 04, 2023 Nov. 03, 2024 ISN T8 Schwarzbeck NTFM 8158 101135 Nov. 04, 2023 Nov. 03, 2024 ISN T5 Schwarzbeck NTFM 8158 101136 Nov. 04, 2023 Nov. 03, 2024 843 Cable 1# ChengYu CE Cable 001 Nov. 04, 2023 Nov. 03, 2024 843 Cable 1# ChengYu CE Cable 002 Nov. 04, 2023 Nov. 03, 2024 For Radiated Emission Test (966 chamber) Other Equipment Manufacturer Model Serial Last Cal. Next Cal. 966 Chamber ChengYu 966 Room 966 Sep. 20, 2022 Sep. 19, 2025 Spectrum Analyzer Agilent E4408B MY50140780 Nov. 04, 2023 Nov. 03, 2024 EMI Receiver R&S ESRP7 101393 Nov. 04, 2023 Nov. 03, 2024 Amplifier Schwarzbeck BBV9743B 00153 Nov. 04, 2023 Nov. 03, 2024 Amplifier EMEC EM01G8GA 00270 Nov. 04, 2023 Nov. 03, 2024 Broadband Trilog Antenna Schwarzbeck VULB9162 00306 Nov. 04, 2023 Nov. 03, 2024 Horn Antenna Schwarzbeck BBHA9120D 02139 Nov. 0…
