2A7ZC-FC2Handheld GNSS Data Collector

By surveyors , for surveyors GEOMATE ® FC2 Controller User Guide Revision 1.0 July 21st, 2022 GEOMATE FC2 USER GUIDE | 2022-07 2 Table of Content Table of Content.................................................................................................... 2 Preface ................................................................................................................. 3 Copyright ................................................................................................................ 3 Safety Warnings ..................................................................................................... 3 Warning and Cautions ............................................................................................ 3 Use and Care .......................................................................................................... 4 FCC Interference Statement ................................................................................... 4 CE Interference Statement ..................................................................................... 4 Technical Assistance ............................................................................................... 5 Your Comments ...................................................................................................... 5 1 Introduction ................................................................................................... 6 1.1 Battery Considerations ................................................................................... 6 2 Installation Guide ........................................................................................... 7 2.1 Exterior ........................................................................................................... 7 2.2 Micro SD, SIM card installation ...................................................................... 7 2.3 Charging ......................................................................................................... 8 2.4 Keypad and instruction .................................................................................. 8 3 Quick tour ..................................................................................................... 10 3.1 Screen on and off ......................................................................................... 10 3.2 Lock and unlock ............................................................................................ 10 3.3 Notification bar ............................................................................................ 10 3.4 Application menu ......................................................................................... 10 3.5 Backup and restore ...................................................................................... 11 3.6 Email ............................................................................................................. 11 3.7 Settings ......................................................................................................... 11 4 Basic operations ............................................................................................ 14 4.1 Language & input ......................................................................................... 14 4.2 Set Date & Time ........................................................................................... 14 4.3 Log in 4G ...................................................................................................... 16 4.4 Check the IMEI Number of the Controller ................................................... 16 4.5 Restore Factory Setting ................................................................................ 17 4.6 Upgrading the Operation System ................................................................. 18 5 Faults and solutions ....................................................................................... 20 6 Specifications ................................................................................................ 21 GEOMATE FC2 USER GUIDE | 2022-07 Pa ge | 3 Preface Copyright Copyright 2020-2022 GEOMATE POSITIONING PTE. LTD. All rights reserved. All other trademarks are the property of their respective owners. Trademarks All product and brand names mentioned in this publication are trademarks of their respective holders. Safety Warnings The Global Positioning System (GPS) is operated by the U.S. Government, which is solely responsible for the accuracy and maintenance of the GPS network. Accuracy can also be affected by poor satellite geometry and obstructions, like buildings and heavy canopy. Warning and Cautions WARNING: Charging this device below 0°c may cause unexpected damage to the battery. A Warning or Caution information is intended to minimize the risk of personal injury and/or damage to the equipment. WARNING - A Warning alerts you to a potential misused or wrong setting of the equipment. CAUTION - A Caution alerts you to a possible risk of serious injury to your person and/or damage to the equipment. GEOMATE FC2 USER GUIDE | 2022-07 Pa ge | 4 Use and Care The FC2 is a high-performance smart handheld terminal developed by GEOMATE. Therefore, the FC2 should be treated with reasonable care. FCC Interference Statement This equipment has been designed to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules in the Portable Mode. These limits are designed to provide reasonable protection against harmful interference in a residential installation. Operation is subject to the following two conditions: (1) this device may not cause harmful interference and (2) this device must accept any interference received, including interference that may cause undesired operation. An absence of specific alerts does not mean that there are no safety risks involved. CE Interference Statement Declaration of Conformity: Hereby, GEOMATE POSITIONING PTE. LTD. declare…

Text truncated - open the document above for the full version.

GEOMATE POSITIONING PTE. LTD. 2.911 (d)(5)(i) Equipment Type Attestation v1.2 Section 2.911(d)(5)(i) Certification – Equipment Type Company name: GEOMATE POSITIONING PTE. LTD. Address: 808 FRENCH ROAD #04-167 KITCHENER COMPLEX SINGAPORE (200808) Product Name: Handheld GNSS Data Collector FCC ID: 2A7ZC-FC2 Model(s): FC2 2.911(d)(5)(i) Equipment Type We, [GEOMATE POSITIONING PTE. LTD.] (“the applicant”) certify that the equipment for which authorization is sought through certification is not:  Prohibited from receiving an equipment authorization pursuant to § 2.903; of the FCC rules.  Identified as an equipment type in the “Covered List” NOTE 1 Yours sincerely, Name: Glenn Chu Date: April 28, 2024 Title and Company name: Certificate Manager GEOMATE POSITIONING PTE. LTD. NOTE 1 “Covered List”; is the List of Equipment and Services Covered By Section 2 of The Secure Networks Act, available at https://www.fcc.gov/supplychain/coveredlist References; 1) 986446 D01 Covered Equipment v01 https://apps.fcc.gov/oetcf/kdb/forms/FTSSearchResultPage.cfm?switch=P&id=325672 2) Federal Register document 2022-28263 published on 02/06/23 https://www.federalregister.gov/documents/2023/02/06/2022-28263/protecting-against-national-security-threats-to-the-com munications-supply-chain-through-the

GEOMATE POSITIONING PTE. LTD. 2.911 (d)(5)(ii) Applicant Attestation v1.3 Section 2.911(d)(5)(ii) Certification – Applicant (Covered List ) Company name: GEOMATE POSITIONING PTE. LTD. Address: 808 FRENCH ROAD #04-167 KITCHENER COMPLEX SINGAPORE (200808) Product Name: Handheld GNSS Data Collector FCC ID: 2A7ZC-FC2 Model(s): FC2 2.911(d)(5)(ii) Applicant filing We, [GEOMATE POSITIONING PTE. LTD.] (“the applicant”) certify that, as of the date of the filing of the application, the applicant is not identified NOTE 1 on the “Covered List” NOTE 2 , established pursuant to § 1.50002 of this chapter, as an entity producing covered communications equipment. Yours sincerely, Name: Glenn Chu Date: April 28, 2024 Title and Company name: Certificate Manager GEOMATE POSITIONING PTE. LTD. NOTE 1 Delete option not applicable to this application. NOTE 2 “Covered List”; is the List of Equipment and Services Covered By Section 2 of The Secure Networks Act, available at https://www.fcc.gov/supplychain/coveredlist References; 1) 986446 D01 Covered Equipment v01 https://apps.fcc.gov/oetcf/kdb/forms/FTSSearchResultPage.cfm?switch=P&id=325672 2) Federal Register document 2022-28263 published on 02/06/23 https://www.federalregister.gov/documents/2023/02/06/2022-28263/protecting-against-national-security-threats-to-the-com munications-supply-chain-through-the

GEOMATE POSITIONING PTE. LTD. * the applicant must designate a contact located in the United States for purposes of acting as the applicant’s agent for service of process, regardless of whether the applicant is a domestic or foreign entity. An applicant located in the United States may designate itself as the agent for service of process. U.S. Agent Designation for Service of Process - Certification Attestation Letter 4/28/2024 ATTN.: Reviewing Engineer FCC ID: 2A7ZC-FC2 FRN: 0032673824 Per section 2.911(d)(7) of the FCC rules, GEOMATE POSITIONING PTE. LTD. (“the applicant”) certifies that the equipment for which authorization is sought is designated to the following U.S. agent* for service of process: Company Name: iGage Mapping Corporation FRN: 0013933296 Physical U.S. Company Address: 1545 South 1100 East #1, Salt Lake City, UT 84105, United States Agent name: Mark E Silver Agent Email Address: [email protected] The above contact person accepts the obligation for service of process. The applicant accepts to maintain an agent for no less than one year after the grantee has terminated all marketing and importation or the conclusion of any Commission-related proceeding involving the equipment. Applicant Signed: Agent Signed (if different to Applicant): Signed: Printed name: Glenn Chu Title: Certification Manager Company Name: GEOMATE POSITIONING PTE. LTD. Date: 4/28/2024 Signed: Printed name: Mark E Silver Title: President Company Name: iGage Mapping Corporation Date: 4/28/2024

GEOMATE POSITIONING PTE. LTD. Date: May 30, 2024 Subject: Block declaration letter FCC ID: 2A7ZC-FC2 To Whom it may concern, The device will use software to block band 28, band38, and band40 of LTE, when it leaves the factory. The blocking function cannot be modified by the user. Yours sincerely, Signatory Name Glenn Chu Position Certificate Manager Company Name GEOMATE POSITIONING PTE. LTD. Address 808 FRENCH ROAD #04-167 KITCHENER COMPLEX SINGAPORE (200808) Tel +8675529766001 Fax / Email [email protected]

GEOMATE POSITIONING PTE. LTD. Letter of Authorization Company: GEOMATE POSITIONING PTE. LTD. Address: 808 FRENCH ROAD #04-167 KITCHENER COMPLEX SINGAPORE (200808) Product Name: Handheld GNSS Data Collector Model Number(s): FC2 We authorize MiCOM Labs Inc., 575 Boulder Court, Pleasanton, California 94566, USA, to act on our behalf on all matters concerning the certification of above named equipment. We declare that MiCOM Labs Inc. is allowed to forward all information related to the approval and certification of equipment to the regulatory agencies as required and to discuss any issues concerning the approval application. Any and all acts carried out by MiCOM Labs on our behalf shall have the same effect as acts of our own. Signature: Date: 2024-04-28 Name: Glenn Chu Title: Certificate Manager Company: GEOMATE POSITIONING PTE. LTD.

GEOMATE POSITIONING PTE. LTD. Office of Engineering Technology Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 Date: 2024-04-28 Subject; Request for Long Term Confidentiality FCC ID: 2A7ZC-FC2 To Whom It May Concern, Pursuant to the provisions of the Commission’s rules Title 47 Sections §0.457 and §0.459, we are requesting the Commission to withhold the following attachment(s) as confidential documents from public disclosure indefinitely. These documents contain detailed system and equipment descriptions and are considered as proprietary information in operation of the equipment. The public disclosure of these documents might be harmful to our company and would give competitors an unfair advantage in the market. Schematic Diagram Block Diagram Operational Description Software security requirement BOM Tune-up It is our understanding that all measurement test reports, FCC ID label format and correspondence during the certification review process cannot be granted as confidential documents and this information will be available for public review once the grant of equipment authorization is issued. Sincerely, Signature: Name: Glenn Chu Title: Certificate Manager

FCC ID: 2A7ZC-FC2 FCC ID: 2A7ZC-FC2 FCC ID: 2A7ZC-FC2 FCC ID: 2A7ZC-FC2 FCC ID: 2A7ZC-FC2

4.5cm 2.5cm Label Location FCC ID: 2A7ZC-FC2 GEOMATE POSITIONING PTE. LTD. Product name: Handheld GNSS Data Collector This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.

FCC ID: 2A7ZC-FC2 2/3/4g ANT NFC ANT 2.4G/5G WIFI BT ANT 2/3/4g ANT FCC ID: 2A7ZC-FC2 NFC ANT 2.4G/5G WIFI BT ANT FCC ID: 2A7ZC-FC2 FCC ID: 2A7ZC-FC2 FCC ID: 2A7ZC-FC2 FCC ID: 2A7ZC-FC2 FCC ID: 2A7ZC-FC2 FCC ID: 2A7ZC-FC2 FCC ID: 2A7ZC-FC2 FCC ID: 2A7ZC-FC2

Hotline: 400-6611-140 Tel: 86-755-27673339 Fax: 86-755-27673332 http://www.tct-lab.com SAR TEST REPORT FCC ID. ............................ : 2A7ZC-FC2 Test Report No. ............... : TCT240111E012 Date of issue ................... : Jun. 25, 2024 Testing laboratory .......... : SHENZHEN TONGCE TESTING LAB Testing location/ address: 2101 & 2201, Zhenchang Factory Renshan Industrial Zone, Fuhai Subdistrict, Bao'an District, Shenzhen, Guangdong, 518103, People's Republic of China Applicant's name ............ : GEOMATE POSITIONING PTE. LTD. Address ........................... : 808 FRENCH ROAD #04-167 KITCHENER COMPLEX SINGAPORE (200808) Manufacturer's name ... : GEOMATE POSITIONING PTE. LTD. Address ........................... : 808 FRENCH ROAD #04-167 KITCHENER COMPLEX SINGAPORE (200808) Test item description ..... : Handheld GNSS Data Collector Trade Mark ...................... : Model/Type reference..... : FC2 SAR Max. Values..............: 0.55 W/Kg (1g) for head; 0.79 W/Kg (1g) for Body-worn; 0.79 W/Kg (1g) for Hotspot Simultaneous Reported SAR..................................: 0.87 W/Kg (1g) for head; 1.22W/Kg (1g) for Body-worn; 1.22 W/Kg (1g) for Hotspot Date of receipt of test item ......................................... : Jan. 11, 2024 Date (s) of performance of test ................................... : Jan. 11, 2024 - Jun. 25, 2024 Tested by (+signature) ... : Karl WANG Check by (+signature) .... : Beryl Zhao Approved by (+signature): Tomsin General disclaimer: This report shall not be reproduced except in full, without the written approval of SHENZHEN TONGCE TESTING LAB. This document may be altered or revised by SHENZHEN TONGCE TESTING LAB personnel only, and shall be noted in the revision section of the document. The test results in the report only apply to the tested sample. Report No.: TCT240111E012 Page 2 of 299 Hotline: 400-6611-140 Tel: 86-755-27673339 Fax: 86-755-27673332 http://www.tct-lab.com TABLE OF CONTENTS 1.General Product Information .................................................................. 4 1.1. EUT description ..................................................................................................... 4 2.Test standard ........................................................................................... 6 3.Facilities and Accreditations .................................................................. 6 3.1. Facilities ................................................................................................................. 6 3.2. Location ................................................................................................................. 6 3.3. Environment Condition: ........................................................................................ 6 4.Test Result Summary .............................................................................. 7 5.RF Exposure Limit ................................................................................... 9 6.SAR Measurement System Configuration ........................................... 10 6.1. SAR Measurement Set-up ................................................................................... 10 6.2. E-field Probe ........................................................................................................ 11 6.3. Phantom ............................................................................................................... 11 6.4. Device Holder ....................................................................................................... 12 6.5. Data Storage and Evaluation .............................................................................. 13 6.6. Position of the wireless device in relation to the phantom.............................. 14 6.7. Tissue Dielectric Parameters.............................................................................. 17 6.8. Tissue-equivalent Liquid Properties .................................................................. 18 6.9. System Check ...................................................................................................... 19 7. Measurement Procedure ....................................................................... 20 8.Conducted Output Power ...................................................................... 23 9.Exposure Position Consideration ........................................................ 44 9.1. EUT Antenna Location ........................................................................................ 44 9.2. Test Position Consideration ............................................................................... 44 10. SAR Test Results Summary .................................................................. 45 10.1 Head 1g SAR Data ............................................................................................... 45 10.2 Body-Worn 1g SAR Data ..................................................................................... 47 10.3 Hotspot 1g SAR Data .......................................................................................... 49 10.4. Simultaneous Transmission Conclusion......................................................... 53 10.5 SAR Simultaneous Transmission Analysis ....................................................... 54 10.6.Measurement Uncertainty (450MHz-3GHz) ....................................................... 62 10.7 Test Equipment List ............................................................................................ 64 11. System Check Results .......................................................................... 65 Report No.: TCT240111E012 Page 3 of 299 Hotline: 400-6611-140 Tel: 86-755-27673339 Fax: 86-755-27673332 http://www.tct-lab.com 12.SAR Test Data ........................................................................................ 77 Appendix A: EUT Photos .......................................................................... 195 Appendix…

Text truncated - open the document above for the full version.

Report No.: TCT240111E012 Page 60 of 299 Hotline: 400-6611-140 Tel: 86-755-27673339 Fax: 86-755-27673332 http://www.tct-lab.com LTE Band 7 QPSK (20MHz) Front 1 0.32 0.18 0.29 0.61 N/A N/A 1 0.30 0.18 0.29 0.59 N/A N/A Back 1 0.51 0.34 0.46 0.97 N/A N/A 1 0.50 0.34 0.46 0.96 N/A N/A Right 1 0.01 0.01 0.03 0.04 N/A N/A 1 0.01 0.01 0.03 0.04 N/A N/A Left 1 0.01 / / 0.01 N/A N/A 1 0.01 / / 0.01 N/A N/A Bottom 1 0.02 / / 0.02 N/A N/A 1 0.02 / / 0.02 N/A N/A Top 1 / 0.01 0.02 0.02 N/A N/A 1 / 0.01 0.02 0.02 N/A N/A LTE Band 12 QPSK (10MHz) Front 1 0.18 0.18 0.29 0.47 N/A N/A 1 0.14 0.18 0.29 0.43 N/A N/A Back 1 0.33 0.34 0.46 0.79 N/A N/A 1 0.31 0.34 0.46 0.47 N/A N/A Right 1 0.01 0.01 0.03 0.03 N/A N/A 1 0.01 0.01 0.03 0.03 N/A N/A Left 1 0.01 / / 0.01 N/A N/A 1 0.01 / / 0.01 N/A N/A Bottom 1 0.01 / / 0.01 N/A N/A 1 0.01 / / 0.01 N/A N/A Top 1 / 0.01 0.02 0.02 N/A N/A 1 / 0.01 0.02 0.02 N/A N/A LTE Band 17 QPSK (10MHz) Front 1 0.17 0.18 0.29 0.46 N/A N/A 1 0.14 0.18 0.29 0.43 N/A N/A Back 1 0.36 0.34 0.46 0.82 N/A N/A 1 0.34 0.34 0.46 0.80 N/A N/A Right 1 0.01 0.01 0.03 0.04 N/A N/A 1 0.01 0.01 0.03 0.04 N/A N/A Left 1 0.01 / / 0.01 N/A N/A 1 0.01 / / 0.01 N/A N/A Bottom 1 0.01 / / 0.01 N/A N/A 1 0.01 / / 0.01 N/A N/A Top 1 / 0.01 0.02 0.02 N/A N/A 1 / 0.01 0.02 0.02 N/A N/A Report No.: TCT240111E012 Page 61 of 299 Hotline: 400-6611-140 Tel: 86-755-27673339 Fax: 86-755-27673332 http://www.tct-lab.com LTE Band 41 QPSK (20MHz) Front 1 0.31 0.18 0.29 0.60 N/A N/A 1 0.30 0.18 0.29 0.59 N/A N/A Back 1 0.51 0.34 0.46 0.97 N/A N/A 1 0.46 0.34 0.46 0.92 N/A N/A Right 1 0.02 0.01 0.03 0.05 N/A N/A 1 0.02 0.01 0.03 0.05 N/A N/A Left 1 0.01 / / 0.01 N/A N/A 1 0.01 / / 0.01 N/A N/A Bottom 1 0.04 / / 0.04 N/A N/A 1 0.03 / / 0.03 N/A N/A Top 1 / 0.01 0.02 0.02 N/A N/A 1 / 0.01 0.02 0.02 N/A N/A Simultaneous Transmission Conclusion The above numerical summed SAR results for all the case simultaneous transmission conditions were below the SAR limit. Therefore, the above analysis is sufficient to determine that simultaneous transmission cases will not exceed the SAR limit and therefore measured volumetric simultaneous SAR summation is not required per FCC KDB Publication 447498 D01v05r02. Report No.: TCT240111E012 Page 62 of 299 Hotline: 400-6611-140 Tel: 86-755-27673339 Fax: 86-755-27673332 http://www.tct-lab.com 10.6. Measurement Uncertainty (450MHz-3GHz) UNCERTAINTY EVALUATION FOR HEADSET SAR Uncertainty Component Descriptio n Uncertainty Value(%) Probably Distribution Div. (Ci) 1g (Ci) 10g Std. Unc. 1g(%) Std. Unc. 10g(%) v Measurement system Probe calibration 7.2.1 5.8 N 1 1 1 5.8 5.8 ∞ Axial isotropy 7.2.1.1 3.5 R 3 (1-C p ) 1/2 (1-C p) 1/2 1.43 1.43 ∞ Hemispherical isotropy 7.2.1.1 5.9 R 3 p C p C 2.41 2.41 ∞ Boundary Effects 7.2.1.4 1.00 R 3 1 1 0.58 0.58 ∞ Linearity 7.2.1.2 4.70 R 3 1 1 2.71 2.71 ∞ System detection limits 7.2.1.2 1 R 3 1 1 0.58 0.58 ∞ Modulation Response 7.2.1.3 3 N 1 1 1 3.00 3.00 ∞ Readout Electronics 7.2.1.5 0.5 N 1 1 1 0.50 0.50 ∞ Response Time 7.2.1.6 0 R 3 1 1 0.00 0.00 ∞ Integration Time 7.2.1.7 1.4 R 3 1 1 0.81 0.81 ∞ RF Ambient Conditions-Noise 7.2.3.7 3 R 3 1 1 1.73 1.73 ∞ RF Ambient Conditions-Reflection 7.2.3.7 3 R 3 1 1 1.73 1.73 ∞ Probe positioned mechanical Tolerance 7.2.2.1 1.4 R 3 1 1 0.81 0.81 ∞ Probe positioning with respect to phantom shell 7.2.2.3 1.4 R 3 1 1 0.81 0.81 ∞ Extrapolation interpolation and integration algorithms for Max.SAR evaluation 7.2.4 2.3 R 1 1 1 1.33 1.33 ∞ Test sample related Test sample positioning 7.2.2.4.4 2.6 N 1 1 1 2.60 2.60 ∞ Device holder uncertainty 7.2.2.4.2 7.2.2.4.3 3 N 1 1 1 3.00 3.00 ∞ output power variation-SAR drift measurement 7.2.3.6 5 R 3 1 1 2.89 2.89 ∞ SAR scaling 7.2.5 2 R 3 1 1 1.15 1.15 ∞ Phantom and tissue parameters Phantom uncertainty (shape and thickness tolerances) 7.2.2.2 4 R 3 1 1 2.31 2.31 ∞ uncertainty in SAR correction for deviation (in permittivity and conductivity) 7.2.6 2 N 1 1 0.84 2.00 1.68 ∞ Liquid conductivity (temperature uncertainty) 7.2.3.5 2.5 N 1 0.78 0.71 1.95 1.78 ∞ Liquid conductivity -measurement uncertainty 7.2.3.3 4 N 1 0.23 0.26 0.92 1.04 ∞ Liquid permittivity (temperature uncertainty) 7.2.3.5 2.5 N 1 0.78 0.71 1.95 1.78 ∞ Liquid permittivity measurement uncertainty 7.2.3.4 5 N 1 0.23 0.26 1.15 1.30 ∞ Combined standard uncertainty RSS 10.83 10.54 Expanded uncertainty (95%CONFIDENCEINTER VAL k 21.26 21.08 Report No.: TCT240111E012 Page 63 of 299 Hotline: 400-6611-140 Tel: 86-755-27673339 Fax: 86-755-27673332 http://www.tct-lab.com UNCERTAINTY FOR PERFORMANCE CHECK Uncertainty Component Description Uncertainty Value(%) Probably Distribution Div. (Ci) 1g (Ci) 10g Std. Unc. 1g(%) Std. Unc. 10g(%) v Measurement system Probe calibration 7.2.1 5.8 N 1 1 1 5.8 5.8 ∞ Axial isotropy 7.2.1.1 3.5 R 3 (1-C p ) 1/2 (1-C p) 1/2 1.43 1.43 ∞ Hemispherical isotropy 7.2.1.1 5.9 R 3 p C p C 2.41 2.41 ∞ Boundary Effects 7.2.1.4 1.00 R 3 1 1 0.58 0.58 ∞ Linearity 7.2.1.2 4.70 R 3 1 1 2.71 2.71 ∞ System detection limits 7.2.1.2 1 R 3 1 1 0.58 0.58 ∞ Modulation Response 7.2.1.3 3 N 1 1 1 0.00 0.00 ∞ Readout Electronics 7.2.1.5 0.5 N 1 1 1 0.50 0.50 ∞ Response Time 7.2.1.6 0 R 3 1 1 0.00 0.00 ∞ Integration Time 7.2.1.7 1.4 R 3 1 1 0.81 0.81 ∞ RF Ambient Conditions-Noise 7.2.3.7 3 R 3 1 1 1.73 1.73 ∞ RF Ambient Conditions-Reflection 7.2.3.7 3 R 3 1 1 1.73 1.73 ∞ Probe positioned mechanical Tolerance 7.2.2.1 1.4 R 3 1 1 0.81 0.81 ∞ Probe positioning with respect to phantom shell 7.2.2.3 1.4 R 3 1 1 0.81 0.81 ∞ Extrapolation interpolation and integration algorithms for Max.SAR evaluation 7.2.4 2.3 R 1 1 1 1.33 1.33 ∞ Dipole Deviation of experimental source from numerical source 4 N 1 1 1 4.00 4.00 ∞ Input power and SAR drift measurement 7.2.3.6 5 R 3 1 1 2.89 2.89 ∞ Dipole axis to liquid distance 2 R 3 1 1 ∞ Phantom and tissue parameters Phantom uncertainty (shape and thickness tolerances) 7.2.2.2 4 R 3 1 1 2.31 2.31 ∞ uncertainty in SAR correction for deviation (in permittivity and conductivity) 7.2.6 2 N 1 1 0.84 2.…

Text truncated - open the document above for the full version.

Report No.: TCT240111E012 Page 140 of 299 Hotline: 400-6611-140 Tel: 86-755-27673339 Fax: 86-755-27673332 http://www.tct-lab.com Z (mm) 0.00 4.00 9.00 14.00 19.00 SAR (W/Kg) 1.1304 0.8059 0.5228 0.3412 0.2264 Hot spot position Report No.: TCT240111E012 Page 141 of 299 Hotline: 400-6611-140 Tel: 86-755-27673339 Fax: 86-755-27673332 http://www.tct-lab.com MEASUREMENT 3 Middle Band SAR (Channel 21100): Date: 01/26/2024 Frequency (MHz) 2535.000000 Relative permittivity (real part) 37.432823 Relative permittivity (imaginary part) 13.671675 Conductivity (S/m) 1.925428 Variation (%) 0.420000 Crest Factor 1.0 Probe Conversion factor 4.36 E-Field Probe: SSE2 (SN 25/22 EPGO375) Area Scan dx=12mm dy=12mm, h= 5.00 mm ZoomScan 5x5x7,dx=5mm dy=5mm dz=5mm,Complete/ndx=8mm dy=8mm, h= 5.00 mm Phantom Validation plane Device Position Body back(hotspot 10mm) Band LTE band 7(1 RB#0) SURFACE SAR VOLUME SAR Maximum location: X=-10.00, Y=-56.00 SAR Peak: 0.85 W/kg SAR 10g (W/Kg) 0.376188 SAR 1g (W/Kg) 0.479512 Report No.: TCT240111E012 Page 142 of 299 Hotline: 400-6611-140 Tel: 86-755-27673339 Fax: 86-755-27673332 http://www.tct-lab.com Z (mm) 0.00 4.00 9.00 14.00 19.00 SAR (W/Kg) 0.8517 0.6173 0.4088 0.2712 0.1815 Hot spot position Report No.: TCT240111E012 Page 143 of 299 Hotline: 400-6611-140 Tel: 86-755-27673339 Fax: 86-755-27673332 http://www.tct-lab.com LTE Band 12 MEASUREMENT 1 High Band SAR (Channel 23130): Date: 01/15/2024 Frequency (MHz) 711.000000 Relative permittivity (real part) 42.126667 Relative permittivity (imaginary part) 23.264000 Conductivity (S/m) 0.914404 Variation (%) 1.520000 Crest Factor 1.0 Probe Conversion factor 1.71 E-Field Probe: SSE2 (SN 25/22 EPGO375) Area Scan dx=8mm dy=8mm, h= 5.00 mm ZoomScan 5x5x7,dx=8mm dy=8mm dz=5mm,Complete/ndx=8mm dy=8mm, h= 5.00 mm Phantom Validation plane Device Position Body front(10mm) Band LTE band 12(1 RB#0) SURFACE SAR VOLUME SAR Maximum location: X=-16.00, Y=11.00 SAR Peak: 0.15 W/kg SAR 10g (W/Kg) 0.064314 SAR 1g (W/Kg) 0.091085 Report No.: TCT240111E012 Page 144 of 299 Hotline: 400-6611-140 Tel: 86-755-27673339 Fax: 86-755-27673332 http://www.tct-lab.com Z (mm) 0.00 4.00 9.00 14.00 19.00 SAR (W/Kg) 0.1454 0.1032 0.0681 0.0473 0.0355 Hot spot position Report No.: TCT240111E012 Page 145 of 299 Hotline: 400-6611-140 Tel: 86-755-27673339 Fax: 86-755-27673332 http://www.tct-lab.com MEASUREMENT 2 High Band SAR (Channel 23130): Date: 01/15/2024 Frequency (MHz) 711.000000 Relative permittivity (real part) 42.126667 Relative permittivity (imaginary part) 23.264000 Conductivity (S/m) 0.914404 Variation (%) 2.100000 Crest Factor 1.0 Probe Conversion factor 1.71 E-Field Probe: SSE2 (SN 25/22 EPGO375) Area Scan dx=8mm dy=8mm, h= 5.00 mm ZoomScan 5x5x7,dx=8mm dy=8mm dz=5mm,Complete/ndx=8mm dy=8mm, h= 5.00 mm Phantom Validation plane Device Position Body back(10mm) Band LTE band 12(1 RB#0) SURFACE SAR VOLUME SAR Maximum location: X=6.00, Y=-31.00 SAR Peak: 0.44 W/kg SAR 10g (W/Kg) 0.172311 SAR 1g (W/Kg) 0.289128 Report No.: TCT240111E012 Page 146 of 299 Hotline: 400-6611-140 Tel: 86-755-27673339 Fax: 86-755-27673332 http://www.tct-lab.com Z (mm) 0.00 4.00 9.00 14.00 19.00 SAR (W/Kg) 0.4434 0.3478 0.2541 0.1841 0.1318 Hot spot position Report No.: TCT240111E012 Page 147 of 299 Hotline: 400-6611-140 Tel: 86-755-27673339 Fax: 86-755-27673332 http://www.tct-lab.com MEASUREMENT 3 High Band SAR (Channel 23130): Date: 01/15/2024 Frequency (MHz) 711.000000 Relative permittivity (real part) 42.126667 Relative permittivity (imaginary part) 23.264000 Conductivity (S/m) 0.914404 Variation (%) 0.410000 Crest Factor 1.0 Probe Conversion factor 1.71 E-Field Probe: SSE2 (SN 25/22 EPGO375) Area Scan dx=8mm dy=8mm, h= 5.00 mm ZoomScan 5x5x7,dx=8mm dy=8mm dz=5mm,Complete/ndx=8mm dy=8mm, h= 5.00 mm Phantom Validation plane Device Position Body back(hotspot 10mm) Band LTE band 12(1 RB#0) SURFACE SAR VOLUME SAR Maximum location: X=6.00, Y=-31.00 SAR Peak: 0.44 W/kg SAR 10g (W/Kg) 0.216037 SAR 1g (W/Kg) 0.306055 Report No.: TCT240111E012 Page 148 of 299 Hotline: 400-6611-140 Tel: 86-755-27673339 Fax: 86-755-27673332 http://www.tct-lab.com Z (mm) 0.00 4.00 9.00 14.00 19.00 SAR (W/Kg) 0.4387 0.3470 0.2557 0.1862 0.1333 Hot spot position Report No.: TCT240111E012 Page 149 of 299 Hotline: 400-6611-140 Tel: 86-755-27673339 Fax: 86-755-27673332 http://www.tct-lab.com LTE Band 17 MEASUREMENT 1 High Band SAR (Channel 23800): Date: 01/15/2024 Frequency (MHz) 711.000000 Relative permittivity (real part) 42.113335 Relative permittivity (imaginary part) 23.152000 Conductiv…
