2A82G-SMONESensor
Ningbo Siming Automotive Co.,Ltd
Click to zoom
Application Details
- Equipment Class
- DSC - Part 15 Security/Remote Control Transmitter
- Date of Grant
- Nov 22, 2022
- Application Purpose
- Original Equipment
- Date of Application
- Nov 22, 2022
- Equipment Note
- Sensor
- Frequency Range
- 315.00000000 - 315.00000000
- Country
- China
Documents & Files
Document Text
Text extracted from the exhibit documents filed with the FCC. Open a document above to read the original.
Users Manual
Installation instructions Step 1 Step 3 Step 2 4.0Nm 35 in-lbs ① Screw ② ③④ ⑤ 金属气门嘴+传感器 注意事项: 1.推荐使用思明的气门嘴搭配思明的传感器 2.为确保安全以及正确的使用，请参考说明书的步骤进行安装； Caution: 1.Please make sure to use Siming’s valves and accessories to guarantee optimal function. 2.Please follow the instruction of car manufacturer for the safety and correct operation. Sensor with clamp-in valves 1.Put down the screw nut; 2.Slide the valve stem through the valve hole of the rim. Tighten the screw-nut with 4.0 Nm with the help of the Torque tool. 3.Assemble the tire, be sure that sensor would not touched with the rim and tire. Note: Use different way to re-lean according to the different vehicle. 1.将压紧螺母旋下； 2.将气门嘴从轮毂孔穿过，并用扭矩扳 手用4.0Nm的力把压紧螺母旋紧； 3.安装轮胎，确保传感器不受轮毂与轮 胎边缘的挤压； 安装说明 www.tpms-sensor.com Europe: Siming Europe GMBH Nordring 6B , 42579 Heiligenhaus Tel: +49 160 / 75 50 544 Email: [email protected] Web: www.siming-china.com China: Ningbo Siming Automotive Co.,Ltd 360# Qiushi Road, Wangchun Industry park, Ningbo, China Tel: +86 574-87103699 E-mail: [email protected] Web: www.siming-china.com 1 Sensor 2 Valve Stem 3 Nut 4 Valve Cap 5 Installation 注意：根据不同的车型学习方式进行学习 FCC Caution: This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. Any changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment. NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception,which can be determined by turning the equipment off and on , the user is encouraged to try to correct the interference by one or more of the following measures: -- Reorient or relocate the receiving antenna. -- Increase the separation between the equipment and receiver. -- Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. -- Consult the dealer or an experienced radio/TV technician for help. To maintain compliance with FCC’s RF Exposure guidelines, This equipment should be installed and operated with minimum distance between 20cm the radiator your body: Use only the supplied antenna.
External Photos
Page 1 of 3 FCC ID: 2A82G-SMONE Shenzhen LCS Compliance Testing Laboratory Ltd. Add: 101, 201 Bldg A & 301 Bldg C, Juji Industrial Park Yabianxueziwei, Shajing Street, Baoan District, Shenzhen, 518000, China Tel: +(86) 0755-82591330 | E-mail: [email protected] | Web: www.lcs-cert.com Scan code to check authenticity External Photos of the EUT Fig. 1 Fig. 2 Page 2 of 3 FCC ID: 2A82G-SMONE Shenzhen LCS Compliance Testing Laboratory Ltd. Add: 101, 201 Bldg A & 301 Bldg C, Juji Industrial Park Yabianxueziwei, Shajing Street, Baoan District, Shenzhen, 518000, China Tel: +(86) 0755-82591330 | E-mail: [email protected] | Web: www.lcs-cert.com Scan code to check authenticity Fig. 3 Fig. 4 Page 3 of 3 FCC ID: 2A82G-SMONE Shenzhen LCS Compliance Testing Laboratory Ltd. Add: 101, 201 Bldg A & 301 Bldg C, Juji Industrial Park Yabianxueziwei, Shajing Street, Baoan District, Shenzhen, 518000, China Tel: +(86) 0755-82591330 | E-mail: [email protected] | Web: www.lcs-cert.com Scan code to check authenticity Fig. 5 Fig. 6
ID Label/Location Info
Page 1 of 1 FCC ID: 2A82G-SMONE Shenzhen LCS Compliance Testing Laboratory Ltd. Add: 101, 201 Bldg A & 301 Bldg C, Juji Industrial Park Yabianxueziwei, Shajing Street, Baoan District, Shenzhen, 518000, China Tel: +(86) 0755-82591330 | E-mail: [email protected] | Web: www.lcs-cert.com Scan code to check authenticity LABEL AND LOCATION (Size: L: 2.0cm x W: 1.5cm) Label Location Sensor Model: SMONE01 FCC ID: 2A82G-SMONE
Internal Photos
Page 1 of 4 FCC ID: 2A82G-SMONE Shenzhen LCS Compliance Testing Laboratory Ltd. Add: 101, 201 Bldg A & 301 Bldg C, Juji Industrial Park Yabianxueziwei, Shajing Street, Baoan District, Shenzhen, 518000, China Tel: +(86) 0755-82591330 | E-mail: [email protected] | Web: www.lcs-cert.com Scan code to check authenticity Internal Photos of the EUT Fig. 1 Fig. 2 Page 2 of 4 FCC ID: 2A82G-SMONE Shenzhen LCS Compliance Testing Laboratory Ltd. Add: 101, 201 Bldg A & 301 Bldg C, Juji Industrial Park Yabianxueziwei, Shajing Street, Baoan District, Shenzhen, 518000, China Tel: +(86) 0755-82591330 | E-mail: [email protected] | Web: www.lcs-cert.com Scan code to check authenticity Fig. 3 Fig. 4 Page 3 of 4 FCC ID: 2A82G-SMONE Shenzhen LCS Compliance Testing Laboratory Ltd. Add: 101, 201 Bldg A & 301 Bldg C, Juji Industrial Park Yabianxueziwei, Shajing Street, Baoan District, Shenzhen, 518000, China Tel: +(86) 0755-82591330 | E-mail: [email protected] | Web: www.lcs-cert.com Scan code to check authenticity Fig. 5 Fig. 6 Antenna Page 4 of 4 FCC ID: 2A82G-SMONE Shenzhen LCS Compliance Testing Laboratory Ltd. Add: 101, 201 Bldg A & 301 Bldg C, Juji Industrial Park Yabianxueziwei, Shajing Street, Baoan District, Shenzhen, 518000, China Tel: +(86) 0755-82591330 | E-mail: [email protected] | Web: www.lcs-cert.com Scan code to check authenticity Fig. 7
Test Report
14.4 ±1 1.5 ±0.21.5 ±0.2 9.5 ±0.5 8 ±0.5 11.31° R0.5 R0.5 R0.5 R0.5 R0.2 R1 R0.2 R0.2 R0.2 R0.2 0.3 ±0.05 5.6 ±1 1.8 ±0.15 4-C0.5 3 ±0.2 0.1 0.60 0.60 19 ±1 ID：35714 3:1 TPMS 胎压传感器 天线片 19-3-9.5-1.8 1 1 0.85 21.8.13 唐毅 QSn6.5-0.1 配用螺杆M12×1.5-56/M12.9 配用普帽M12×1.5-20/M12.9 配用螺杆M14×1.5-48/M12.9 配用连接杆1/2-13-47发黑 黑色塑料套适用于M14/直径13*12mm 产品表面本色亮光氧化 Manufacturer: Prosperous SHENZHEN PROSPEROUS TECHNOLOGY CO.，LTD. Antenna model: 35714 Antenna type:loop Antenna gain:0dBi Hpb58-3A铜 QSn6.5-0.1磷锌铜 标准：GB/T 4423-2007 注 ：棒材的纵向室温拉伸力学性能 试样尺寸：直径或对边距离5～12 热处理规范：热加工温度750～770°C；退火温度600～650°C。 1.6 序号名称规格型号材质备注ID 1 毛坯（底）6*139.76061-T6本色氧化 2 毛坯（盖）5*114.36061-T6本色氧化 3 链接螺杆1/2-13-4740Cr/35GrMo发色处理 4 螺杆孔螺杆M12*1.5*5640Cr/35GrMo镀白锌M12.9 5 螺杆孔螺帽M12*1.5*2040Cr/35GrMo普帽镀白锌 6 铁衬套1/2*13-L2840Cr/35GrMo普通电镀2163 7 螺杆防护套橡胶
Test Report
Page 1 of 33 FCC ID: 2A82G-SMONE Report No.: LCSA101922004EA Shenzhen LCS Compliance Testing Laboratory Ltd. Add: 101, 201 Bldg A & 301 Bldg C, Juji Industrial Park Yabianxueziwei, Shajing Street, Baoan District, Shenzhen, 518000, China Tel: +(86) 0755-82591330 | E-mail: [email protected] | Web: www.lcs-cert.com Scan code to check authenticity FCC TEST REPORT For Ningbo Siming Automotive Co.,Ltd Sensor Test Model: SMONE01 Additional Model No.: Please Refer to Page 6 Prepared for : Ningbo Siming Automotive Co.,Ltd Address : 360# Qiushi Road, Jishigang Town, Ningbo, China. Prepared by : Shenzhen LCS Compliance Testing Laboratory Ltd. Address : 101, 201 Bldg A & 301 Bldg C, Juji Industrial Park Yabianxueziwei, Shajing Street, Baoan District, Shenzhen, 518000, China Tel : (+86)755-82591330 Fax : (+86)755-82591332 Web : www.LCS-cert.com Mail : [email protected] Date of receipt of test sample : October 19, 2022 Number of tested samples : 2 Sample number : A101922004-1, A101922004-2 Serial number : Prototype Date of Test : October 19, 2022 ~ November11, 2022 Date of Report : November 12, 2022 Page 2 of 33 FCC ID: 2A82G-SMONE Report No.: LCSA101922004EA Shenzhen LCS Compliance Testing Laboratory Ltd. Add: 101, 201 Bldg A & 301 Bldg C, Juji Industrial Park Yabianxueziwei, Shajing Street, Baoan District, Shenzhen, 518000, China Tel: +(86) 0755-82591330 | E-mail: [email protected] | Web: www.lcs-cert.com Scan code to check authenticity FCC TEST REPORT FCC CFR 47 PART 15 C(15.231) Report Reference No. .............. : LCSA101922004EA Date of Issue ............................... : November 12, 2022 Testing Laboratory Name ......... : Shenzhen LCS Compliance Testing Laboratory Ltd. Address ...................................... : 101, 201 Bldg A & 301 Bldg C, Juji Industrial Park Yabianxueziwei, Shajing Street, Baoan District, Shenzhen, 518000, China Testing Location/ Procedure ....... : Full application of Harmonised standards ■ Partial application of Harmonised standards □ Other standard testing method □ Applicant’s Name ...................... : Ningbo Siming Automotive Co.,Ltd Address ...................................... : 360# Qiushi Road, Jishigang Town, Ningbo, China. Test Specification Standard ..................................... : FCC CFR 47 PART 15 Subpart C, ANSI C63.10-2013 Test Report Form No. ............... : LCSEMC-1.0 TRF Originator ............................ : Shenzhen LCS Compliance Testing Laboratory Ltd. Master TRF ................................. : Dated 2011-03 Shenzhen LCS Compliance Testing Laboratory Ltd. All rights reserved. This publication may be reproduced in whole or in part for non-commercial purposes as long as the Shenzhen LCS Compliance Testing Laboratory Ltd. is acknowledged as copyright owner and source of the material. Shenzhen LCS Compliance Testing Laboratory Ltd. takes no responsibility for and will not assume liability for damages resulting from the reader's interpretation of the reproduced material due to its placement and context. Test Item Description. ............... : Sensor Trade Mark ................................. : N/A Test Model .................................. : SMONE01 Ratings ....................................... : DC 3V By CR2025 lithium Battery Result ........................................ : Positive Compiled by: Supervised by: Approved by: Li Huan/ Administrator Cary Luo/ Technique principal Gavin Liang/ Manager Page 3 of 33 FCC ID: 2A82G-SMONE Report No.: LCSA101922004EA Shenzhen LCS Compliance Testing Laboratory Ltd. Add: 101, 201 Bldg A & 301 Bldg C, Juji Industrial Park Yabianxueziwei, Shajing Street, Baoan District, Shenzhen, 518000, China Tel: +(86) 0755-82591330 | E-mail: [email protected] | Web: www.lcs-cert.com Scan code to check authenticity FCC -- TEST REPORT EUT......................................... : Sensor Test Model........................... : SMONE01 Applicant............................... : Ningbo Siming Automotive Co.,Ltd Address.................................. : 360# Qiushi Road, Jishigang Town, Ningbo, China. Telephone............................... : / Fax.......................................... : / Manufacturer....................... : Ningbo Siming Automotive Co.,Ltd Address................................... : 360# Qiushi Road, Jishigang Town, Ningbo, China. Telephone............................... : / Fax.......................................... : / Factory....................... : Ningbo Siming Automotive Co.,Ltd Address................................... : 360# Qiushi Road, Jishigang Town, Ningbo, China. Telephone............................... : / Fax.......................................... : / Test Result Positive The test report merely corresponds to the test sample. It is not permitted to copy extracts of these test result without the written permission of the test laboratory. Test Report No. : LCSA101922004EA November 12, 2022 Date of issue Page 4 of 33 FCC ID: 2A82G-SMONE Report No.: LCSA101922004EA Shenzhen LCS Compliance Testing Laboratory Ltd. Add: 101, 201 Bldg A & 301 Bldg C, Juji Industrial Park Yabianxueziwei, Shajing Street, Baoan District, Shenzhen, 518000, China Tel: +(86) 0755-82591330 | E-mail: [email protected] | Web: www.lcs-cert.com Scan code to check authenticity Revision History Report Version Issue Date Revision Content Revised By 000 November 12, 2022 Initial Issue -- Page 5 of 33 FCC ID: 2A82G-SMONE Report No.: LCSA101922004EA Shenzhen LCS Compliance Testing Laboratory Ltd. Add: 101, 201 Bldg A & 301 Bldg C, Juji Industrial Park Yabianxueziwei, Shajing Street, Baoan District, Shenzhen, 518000, China Tel: +(86) 0755-82591330 | E-mail: [email protected] | Web: www.lcs-cert.com Scan code to check authenticity TABLE OF CONTENTS 1. GENERAL INFORMATION ................................................................................................................................... 6 1.1. DESCRIPTION OF DEVICE (EUT) ..........................…
Text truncated - open the document above for the full version.
Test Report
Page 1 of 34 FCC ID: 2A82G-SMONE Report No.: LCSA110922039EA Shenzhen LCS Compliance Testing Laboratory Ltd. Add: 101, 201 Bldg A & 301 Bldg C, Juji Industrial Park Yabianxueziwei, Shajing Street, Baoan District, Shenzhen, 518000, China Tel: +(86) 0755-82591330 | E-mail: [email protected] | Web: www.lcs-cert.com Scan code to check authenticity FCC TEST REPORT For Ningbo Siming Automotive Co.,Ltd Sensor Test Model: SMONE01 Additional Model No.: SMONE02, SMONE03, SMONE04, SMONE05, SMONE06， SMONE07，SMONE08 Prepared for : Ningbo Siming Automotive Co.,Ltd Address : 360# Qiushi Road, Jishigang Town, Ningbo, China. Prepared by : Shenzhen LCS Compliance Testing Laboratory Ltd. Address : 101, 201 Bldg A & 301 Bldg C, Juji Industrial Park Shajing Street, Baoan District, Shenzhen, China Tel : (+86)755-82591330 Fax : (+86)755-82591332 Web : www.LCS-cert.com Mail : [email protected] Date of receipt of test sample : November 09, 2022 Number of tested samples : 2 Sample No. : A110922039-1, A110922039-2 Serial number : Prototype Date of Test : November 09, 2022 ~ November 14, 2022 Date of Report : November 14, 2022 Page 2 of 34 FCC ID: 2A82G-SMONE Report No.: LCSA110922039EA Shenzhen LCS Compliance Testing Laboratory Ltd. Add: 101, 201 Bldg A & 301 Bldg C, Juji Industrial Park Yabianxueziwei, Shajing Street, Baoan District, Shenzhen, 518000, China Tel: +(86) 0755-82591330 | E-mail: [email protected] | Web: www.lcs-cert.com Scan code to check authenticity FCC TEST REPORT FCC CFR 47 PART 15C(15.231) Report Reference No. ................. : LCSA110922039EA Date of Issue ................................... : November 14, 2022 Testing Laboratory Name ............ : Shenzhen LCS Compliance Testing Laboratory Ltd. Address ........................................... : 101, 201 Bldg A & 301 Bldg C, Juji Industrial Park Shajing Street, Baoan District, Shenzhen, China Testing Location/ Procedure ........... : Full application of Harmonised standards ■ Partial application of Harmonised standards □ Other standard testing method □ Applicant’s Name .......................... : Ningbo Siming Automotive Co.,Ltd Address ........................................... : 360# Qiushi Road, Jishigang Town, Ningbo, China. Test Specification Standard ......................................... : FCC CFR 47 PART 15 C(15.231) Test Report Form No. ..................... : LCSEMC-1.0 TRF Originator ................................ : Shenzhen LCS Compliance Testing Laboratory Ltd. Master TRF ..................................... : Dated 2011-03 Shenzhen LCS Compliance Testing Laboratory Ltd. All rights reserved. This publication may be reproduced in whole or in part for non-commercial purposes as long as the Shenzhen LCS Compliance Testing Laboratory Ltd. is acknowledged as copyright owner and source of the material. Shenzhen LCS Compliance Testing Laboratory Ltd. takes no responsibility for and will not assume liability for damages resulting from the reader's interpretation of the reproduced material due to its placement and context. Test Item Description. .................. : Sensor Trade Mark ...................................... : N/A Test Model ...................................... : SMONE01 Ratings ............................................ : DC 3.0V By CR2050HR Battery Result ........................................... : Positive Compiled by: Supervised by: Approved by: Li Huan/Administrator Cary Luo/ Technique principal Gavin Liang/ Manager Page 3 of 34 FCC ID: 2A82G-SMONE Report No.: LCSA110922039EA Shenzhen LCS Compliance Testing Laboratory Ltd. Add: 101, 201 Bldg A & 301 Bldg C, Juji Industrial Park Yabianxueziwei, Shajing Street, Baoan District, Shenzhen, 518000, China Tel: +(86) 0755-82591330 | E-mail: [email protected] | Web: www.lcs-cert.com Scan code to check authenticity FCC -- TEST REPORT Test Result Positive The test report merely corresponds to the test sample. It is not permitted to copy extracts of these test result without the written permission of the test laboratory. Test Report No. : LCSA110922039EA November 14, 2022 Date of issue Test Mode............................... : SMONE01 EUT......................................... : Sensor Applicant............................... : Ningbo Siming Automotive Co.,Ltd Address.................................. : 360# Qiushi Road, Jishigang Town, Ningbo, China. Telephone............................... : / Fax.......................................... : / Manufacturer........................ : Ningbo Siming Automotive Co.,Ltd Address................................... : 360# Qiushi Road, Jishigang Town, Ningbo, China. Telephone............................... : / Fax.......................................... : / Factory................................... : Ningbo Siming Automotive Co.,Ltd Address................................... : 360# Qiushi Road, Jishigang Town, Ningbo, China. Telephone............................... : / Fax.......................................... : / Page 4 of 34 FCC ID: 2A82G-SMONE Report No.: LCSA110922039EA Shenzhen LCS Compliance Testing Laboratory Ltd. Add: 101, 201 Bldg A & 301 Bldg C, Juji Industrial Park Yabianxueziwei, Shajing Street, Baoan District, Shenzhen, 518000, China Tel: +(86) 0755-82591330 | E-mail: [email protected] | Web: www.lcs-cert.com Scan code to check authenticity Revision History Report Version Issue Date Revision Content Revised By 000 November 14, 2022 Initial Issue --- Page 5 of 34 FCC ID: 2A82G-SMONE Report No.: LCSA110922039EA Shenzhen LCS Compliance Testing Laboratory Ltd. Add: 101, 201 Bldg A & 301 Bldg C, Juji Industrial Park Yabianxueziwei, Shajing Street, Baoan District, Shenzhen, 518000, China Tel: +(86) 0755-82591330 | E-mail: [email protected] | Web: www.lcs-cert.com Scan code to check authenticity TABLE OF CONTENTS 1. GENERAL INFORMATION ...................................................................................................................................... 6 1.1. DE…
Text truncated - open the document above for the full version.
Test Setup Photos
Page 1 of 1 FCC ID: 2A82G-SMONE Shenzhen LCS Compliance Testing Laboratory Ltd. Add: 101, 201 Bldg A & 301 Bldg C, Juji Industrial Park Yabianxueziwei, Shajing Street, Baoan District, Shenzhen, 518000, China Tel: +(86) 0755-82591330 | E-mail: [email protected] | Web: www.lcs-cert.com Scan code to check authenticity Test Setup Photos of the EUT Test Setup Photo(s) of Radiated Emissions Measurement Fig. 1 Fig. 2
Contact Information
Applicant
Jerry Yang
Test Firm
Shenzhen LCS Compliance Testing Laboratory Ltd.Gavin Liang
Technical Specifications
| # | Rule Parts | Frequency Range | Power Output |
|---|---|---|---|
| 2 | 15.231 | 315 MHz - 315 MHz | - |
