2A82K-WBMC22G1WHarry Potter interactive wand

WBHE HARRY POTTER INTERACTIVE WAND CAD# G15092B3 6/2022 80# Gloss Text DIMENSIONS: 7.5" W x 3.688" H FOLDED DIMENSIONS: 7.5" W x 1.25" H CLIENT: WARNER MEDIA PROJECT: WIZARDING WORLD HARRY POTTER MAGIC CASTER ULTIMATE WAND EXPERIENCE PART #: TEMPLATE: G15092B3 DATE: 08.25.22 MECHANICAL NAME: J11982_D1_r2_V3_CC21.indd OPERATOR: JM/RT COMPONENT: 2-SIDED INSERT ROUND 2 BURBANK JOB # J11982 BLACK DIELINE WANDS_WW_INSERT AQ quick start guide Scan the QR code with your phone’s camera to install the free Harry Potter: Magic Caster Wand™ app. For more information, including warranty information, visit HarryPotterMagicCasterWand.com For the ultimate wand experience, download the app.* Wand and box arrive precharged. To store and charge wand, place on the built-in USB port inside the box indentation. Then, connect USB charging cable (supplied in the box) to the port on the side of the wand box. Connect the charging cable to power source. WARNING: To reduce the risk of injury, wand should be charged by the box. The box should only be charged via a compliant USB-C cable and USB 5V/1A-2A charger. Do not try to remove or replace the batteries. A USB charger is not included. Charging Wand and Box CLIENT: WARNER MEDIA PROJECT: WIZARDING WORLD HARRY POTTER MAGIC CASTER ULTIMATE WAND EXPERIENCE PART #: TEMPLATE: G15092B3 DATE: 11.18.22 MECHANICAL NAME: J11982_D1_r5_V3_CC21.indd OPERATOR: RT/MC COMPONENT: 2-SIDED INSERT ROUND 5 BURBANK JOB # J11982 BLACK DIELINE WANDS_WW_INSERT_REV AQ WBHE HARRY POTTER INTERACTIVE WAND CAD# G15092B3 6/2022 80# Gloss Text DIMENSIONS: 7.5" W x 3.688" H FOLDED DIMENSIONS: 7.5" W x 1.25" H FCC/IC STATEMENT This device complies with part 15 of the FCC Rules and Industry Canada license-exempt RSSs. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: - Reorient or relocate the receiving antenna. - Increase the separation between the equipment and receiver. - Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. - Consult the dealer or an experienced radio/TV technician for help. Caution: Changes or modifications to this unit not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment. L’émetteur/récepteur exempt de licence contenu dans le présent appareil est conforme aux CNR d’Innovation, Sciences et Développement économique Canada applicables aux appareils radio exempts de licence. L’exploitation est autorisée aux deux conditions suivantes: (1) l’appareil ne doit pas produire de brouillage, et (2) l’appareil doit accepter tout brouillage radioélectrique subi, même si le brouillage est susceptible d’en compromettre le fonctionnement. This Class B digital apparatus complies with Canadian ICES-003. Cet appareil numérique de classe B est conforme à la norme canadienne NMB-003. CAN ICES-3 (B) / NMB-3 (B) Hereby, Warner Bros. declares that the radio equipment type Wand, Box (associated with Family No: WBMC22G1) is in compliance with Directive 2014/53/EU. The full text of the EU declaration of conformity is available at the following internet address: HarryPotterMagicCasterWand.com/ComplianceInformation This radio equipment operates with the following frequency bands and maximum radio-frequency power: FCC ID: 2A82K-WBMC22G1W FCC ID: 2A82K-WBMC22G1B IC: 12514A-WBMC22G1W IC: 12514A-WBMC22G1B *A compatible smartphone or tablet and the companion app are required. Companion app requires registration for a free account; consent of a parent or legal guardian may be required to register for the app in certain territories. Some experiences may require future downloads. Additional data rates may apply when downloading the application. To find all compatible devices, go to HarryPotterMagicCasterWand.com/CompatibleDevices © Warner Bros. Entertainment Inc. HARRY POTTER: MAGIC CASTER WAND, WIZARDING WORLD and all related trademarks, characters, names, and related indicia are © & ™ Warner Bros. Entertainment Inc. WB SHIELD: © & ™ WBEI. Publishing Rights © JKR. (s22) Patent Pending Family No (device)Frequency BandsMaximum Conducted Power (dBm) WBMC22G1 (Wand) WBMC22G1 (Box) Bluetooth LE 2.4GHz Bluetooth LE 2.4GHz 4dBm 4dBm

WARNER BROS. HOME ENTERTAINMENT INC. 4000 Warner Blvd. Burbank, CA 91522 Letter of Authorization and Anti- Drug Statement Applicant Name: Warner Bros. Home Entertainment Inc. Address: 4000 Warner Blvd., Burbank, CA 91522 USA Product Name: Harry Potter Magic Caster Wand Model Number: WBMC22G1SAVW, WBMC22G1SHRW, WBMC22G1SHNW, WBMC22G1SWSW, WBMC22G1SLYW, WBMC22G1SDFW FCC ID: 2A82K-WBMC22G1W We authorize: CETECOM Inc., to act on our behalf on all matters concerning the above named equipment. We declare that CETECOM Inc. is allowed to forward all information related to the approval project to the Federal Communications Commission and discuss any issues concerning the approval application. The applicant must certify that neither the applicant nor any party to the application is subject to a denial of Federal benefits, that include FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C. § 862 because of a conviction for possession or distribution of a controlled substance. See 47 CFR 1.2002(b) for the definition of a "party" for these purposes. Does the applicant or authorized agent so certify? Q Yes I certify that I am authorized to sign this application. All of the statements herein and the exhibits attached hereto, are true and correct to the best of my knowledge and belief. In accepting a Grant of Equipment Authorization as a result of the representations made in this application, the applicant is responsible for (1) labeling the equipment with the exact FCC ID specified in this application, (2) compliance statement labeling pursuant to the applicable rules, and (3) compliance of the equipment with the applicable technical rules. If the applicant is not the actual manufacturer of the equipment, appropriate arrangements have been made with the manufacturer to ensure that production units of this equipment will continue to comply with the FCC's technical requirements. Authorizing an agent to sign this application, is done solely at the applicant's discretion; however, the applicant remains responsible for all statements in this application. If an agent has signed this application on behalf of the applicant, a written letter of authorization which includes information to enable the agent to respond to the above section 5301 (Anti-Drug Abuse) Certification statement has been provided by the applicant. It is understood that the letter of authorization must be submitted to the FCC upon request, and that the FCC reserves the right to contact the applicant directly at any time. Signature of Authorized Person Filing: Title: Director of Finance Date: 11/1/2022

WARNER ROS Federal Communications Commission Equipment Authorization Division 7435 Oakland Mills Road Columbia, MD 21048 Date: 11/1/2022 Subject:Request for Permanent Confidentiality FCC ID: 2A82K-WBMC22G1W To Whom It May Concern: In accordance with §0.457(d) and §0.459 of CFR 47, and KDB 726920, Warner Bros. Home Entertainment Inc. hereby requests permanent confidentiality for documents filed under the following exhibit types: l. Block Diagram 2. Schematic Diagram 3. Part List 4. Operational Description These items contain detailed system and equipment description and related information about the product which Warner Bros. Home Entertainment Inc. considers to be proprietary, confidential and a custom design which otherwise would not be released to the general public. Since this design is a basis from which future technological products will evolve, Warner Bros. Home Entertainment Inc. also feels that this information would be of benefit to its competitors, and that the disclosure of the information in these exhibits would give our competitors an unfair advantage in the market. We are aware that exhibit types cover letters, attestations, label document, test reports, RF exposure information {SAR and MPE reports), cannot be requested to be classified confidential and are thus subject to publication, as will be documents of all other exhibits types for which we have not requested a confidentiality classification. Best~ sire Name: Anselm Gunsch Title: Director of Finance Company Name: Warner Bros. Home Entertainment Inc. Address: 4000 Warner Blvd., Burbank, CA 91522 USA

Company LOGO Federal Communications Commission Equipment Authorization Division 7435 0akland Mills Road Columbia, MD 21048 Date: u/0 /2o Subject:Request for Short Term Confidentiality FCC-ID: 2A82K-WBMC22G1W To Whom It May Concern: In accordance with §0.457(d) and $0.459 of CFR 47, Warner Bros. Home Entertainment Inc. hereby requests short term confidentiality for documents filed under the following exhibit types: 1. Internal Photographs 2. User/ Instruction Manual 3. Test Set-up Photographs until the product will be publicly announced. Short term confidentiality release date/ period: 180 days from grant issue date These items contain detailed system and equipment description and related information about the product which Warner Bros. Home Entertainment Inc. considers to be proprietary, confidential and a custom design which otherwise would not be released to the general public. Since this design is a basis from which future technological products will evolve, Warner Bros. Home Entertainment Inc. also feels that this information would be of benefit to its competitors, and that the disclosure of the information in these exhibits would give our competitors an unfair advantage in the market. We are informed and aware of our obligation that we have to inform the involved TCB in written and in due time if we intend to market the product prior to the above specified confidentiality release date so that the short term confidentiality classification can be reset prior to product launch. We are aware that exhibit types cover letters, attestations, label document, test reports, RF exposure information (SAR and MPE reports], cannot be requested to be classified confidential and are thus subject to publication, as will be documents of all other exhibits types for which we have not requested a confiyity classification. Best Si Name: Anselm unsch Title: Director of Finance Company Name: Warner Bros. Home Entertainment Inc. Address: 4000 Warner Blvd., Burbank, CA 91522 USA

1 st click2 nd click3 rd click Wand 2 Wand No: WBMC22G1SAVW FCC ID: 2A82K-WBMC22G1W IC: 12514A-WBMC22G1W Wand 3 Wand No: WBMC22G1SHRW FCC ID: 2A82K-WBMC22G1W IC: 12514A-WBMC22G1W Wand 4 Wand No: WBMC22G1SHNW FCC ID: 2A82K-WBMC22G1W IC: 12514A-WBMC22G1W Wand 5 Wand No: WBMC22G1SWSW FCC ID: 2A82K-WBMC22G1W IC: 12514A-WBMC22G1W Wand 6 Wand No: WBMC22G1SLYW FCC ID: 2A82K-WBMC22G1W IC: 12514A-WBMC22G1W Wand 7 (shown here) Wand No: WBMC22G1SDFW FCC ID: 2A82K-WBMC22G1W IC: 12514A-WBMC22G1W *Note 1: The above marking examples are laser etched into the eachwand. The Wand’s FCC & IC IDs are not on the physical device due to the space limitation and legibility instead will be e-labeled in the Companion App shown below Wand -Product Labeling/Markings *Note 1: The above e-labeling is displayed here by using the BLE connection to wand and reading the Dev No to properly map the associated FCC & IC IDs. The same is done for box e-Labeling Outer Sleeve Wand -Package Labeling/Markings Wand 2 Wand No: WBMC22G1SAVW Box No: WBMC22G1SAVB Wand 3 Wand No: WBMC22G1SHRW Box No: WBMC22G1SHRB Wand 4 Wand No: WBMC22G1SHNW Box No: WBMC22G1SHNB Wand 5 Wand No: WBMC22G1SWSW Box No: WBMC22G1SWSB Wand 6 Wand No: WBMC22G1SLYW Box No: WBMC22G1SLYB Wand 7 (shown above) Wand No: WBMC22G1SDFW Box No: WBMC22G1SDFB Product Name * Note: currently as of Nov 2022, the above are permanent stick-on thermally printed labels. In the future, the FCC and IC IDs may be printed directly on the sleeve same as the Product Name and Wand/Box Numbers.

Internal Wand W2 Model: WBMC22G1SAVW WBMC22G1SAVB WBMC22G1SAVW Internal Assembly BLE IC (Nrf52832 EW Main v1.4 PCBA (180 0 ) Chip Antenna EW Main v1.4 PCBA (0 0 ) EW Main v1.4 PCBA (180 0 ) Product Packaging FCC / IC IDs Device No. (HVIN) Internal Wand W3 Model: WBMC22G1SHRW WBMC22G1SHRB WBMC22G1SHRW Internal Assembly BLE IC (Nrf52832 EW Main v1.4 PCBA (180 0 ) Chip Antenna EW Main v1.4 PCBA (0 0 ) EW Main v1.4 PCBA (180 0 ) Product Packaging FCC / IC IDs Device No. (HVIN) Internal Wand W4 Model: WBMC22G1SHNW WBMC22G1SHNB WBMC22G1SHNW Internal Assembly BLE IC (Nrf52832 EW Main v1.4 PCBA (180 0 ) Chip Antenna EW Main v1.4 PCBA (0 0 ) EW Main v1.4 PCBA (180 0 ) Product Packaging FCC / IC IDs Device No. (HVIN) Internal Wand W5 Model: WBMC22G1SWSW WBMC22G1SWSB WBMC22G1SWSW Internal Assembly BLE IC (Nrf52832 EW Main v1.4 PCBA (180 0 ) Chip Antenna EW Main v1.4 PCBA (0 0 ) EW Main v1.4 PCBA (180 0 ) Product Packaging FCC / IC IDs Device No. (HVIN) Internal Wand W6 Model: WBMC22G1SLYW WBMC22G1SLYB WBMC22G1SLYW Internal Assembly BLE IC (Nrf52832 EW Main v1.4 PCBA (180 0 ) Chip Antenna EW Main v1.4 PCBA (0 0 ) EW Main v1.4 PCBA (180 0 ) Product Packaging FCC / IC IDs Device No. (HVIN) Internal Wand W7 Model: WBMC22G1SDFW WBMC22G1SDFB WBMC22G1SDFW Internal Assembly BLE IC (Nrf52832 EW Main v1.4 PCBA (180 0 ) Chip Antenna EW Main v1.4 PCBA (0 0 ) EW Main v1.4 PCBA (180 0 ) Product Packaging FCC / IC IDs Device No. (HVIN)

A2LA Accredited IC recognized # 3462B-1 CETECOM Inc. 411 Dixon Landing Road  Milpitas, CA 95035  U.S.A. Phone: + 1 (408) 586 6200  Fax: + 1 (408) 586 6299  E-mail: [email protected]  http://www.cetecom.com CETECOM Inc. is a Delaware Corporation with Corporation number: 2905571 © Copyright by CETECOM Radio Frequency Exposure Evaluation Report FOR: Warner Bros. Home Entertainment Inc. Models: WBMC22G1SAVW WBMC22G1SHRW WBMC22G1SHNW WBMC22G1SWSW WBMC22G1SLYW WBMC22G1SDFW Product Description: Harry Potter interactive wand FCC ID: 2A82K-WBMC22G1W IC: 12514A- WBMC22G1W Applied Rules and Standards: CFR 47 Part 2 (2.1093), FCC KDB 447498 D01 General RF Exposure Guidance v06 ISED RSS-102 Issue 5 REPORT #: EMC_FOXBC-001-22001_FCC_SAREX_Rev1 DATE: 11-16-2022 Test Report #: EMC_FOXBC-001-22001_FCC_SAREX_Rev1 FCC ID: 2A82K-WBMC22G1W Date of Report: 11-16-2022 Page 2 of 7 IC: 12514A- WBMC22G1W Contents 1. Assessment ................................................................................................................................................ 3 2. Administrative Data .................................................................................................................................... 4 2.1. Identification of the Testing Laboratory Issuing the Test Report ......................................................... 4 2.2. Identification of the Client / Manufacturer ............................................................................................ 4 3. Equipment under Assessment .................................................................................................................... 5 4. FCC and ISEDC Exemption Limits for Routine Evaluation .......................................................................... 6 4.1. FCC SAR test exclusions per KDB 447498 4.3.1. Standalone SAR test exclusion considerations ..... 6 4.2. ISED SAR test exclusions per IC RSS-102 Issue 5 ............................................................................. 6 5. Stand-alone Transmission SAR Exclusion Evaluation................................................................................ 6 5.1. Justification for using the 5 mm Distance ............................................................................................ 6 5.2. SAR Exclusion Calculation .................................................................................................................. 6 6. Revision History ......................................................................................................................................... 7 Test Report #: EMC_FOXBC-001-22001_FCC_SAREX_Rev1 FCC ID: 2A82K-WBMC22G1W Date of Report: 11-16-2022 Page 3 of 7 IC: 12514A- WBMC22G1W 1. Assessment The following device was evaluated against the limits for general population uncontrolled exposure specified in CFR 47 Part 2.1093 according to SAR evaluation exclusion requirements specified in FCC regulation as listed in KDB 447498, and ISEDC RSS-102 Issue 5. The device meets the requirements for SAR exclusion as stipulated by the above given FCC/ISED rules. Company Description Models Warner Bros. Home Entertainment Inc. Harry Potter interactive wand WBMC22G1SAVW; WBMC22G1SHRW WBMC22G1SHNW; WBMC22G1SWSW WBMC22G1SLYW; WBMC22G1SDFW Note: The device models in the above table have identical internal electronic assemblies and use the same PCBAs and FPCAs across all wand styles. The wand's Radio Code and Radio Settings identical and unchanging across all the wand styles. Only one representative sample was tested. Responsible for Testing Laboratory: 11-16-2022 Compliance Arndt Stoecker (Director of Regulatory Services) Date Section Name Signature Responsible for the Report: 11-16-2022 Compliance Kris Lazarov (EMC Engineer) Date Section Name Signature The test results of this test report relate exclusively to the test item specified in Section3. CETECOM Inc. USA does not assume responsibility for any conclusions and generalizations drawn from the test results with regard to other specimens or samples of the type of the equipment represented by the test item. The test report may only be reproduced or published in full. Reproduction or publication of extracts from the report requires the prior written approval of CETECOM Inc. USA. Test Report #: EMC_FOXBC-001-22001_FCC_SAREX_Rev1 FCC ID: 2A82K-WBMC22G1W Date of Report: 11-16-2022 Page 4 of 7 IC: 12514A- WBMC22G1W 2. Administrative Data 2.1. Identification of the Testing Laboratory Issuing the Test Report Company Name: CETECOM Inc. Department: Compliance Street Address: 411 Dixon Landing Road City/Zip Code Milpitas, CA 95035 Country USA Telephone: +1 (408) 586 6200 Fax: +1 (408) 586 6299 Director of Regulatory Services: Arndt Stoecker Responsible Project Leader: Sangeetha Sivaraman 2.2. Identification of the Client / Manufacturer Client’s Name: Warner Bros. Home Entertainment Inc. Street Address: 4000 Warner Blvd City/Zip Code Burbank, CA 91522 Country USA Manufacturer’s Name: Same as Client Manufacturers Address: City/Zip Code Country Test Report #: EMC_FOXBC-001-22001_FCC_SAREX_Rev1 FCC ID: 2A82K-WBMC22G1W Date of Report: 11-16-2022 Page 5 of 7 IC: 12514A- WBMC22G1W 3. Equipment under Assessment Model No WBMC22G1SAVW; WBMC22G1SHRW; WBMC22G1SHNW; WBMC22G1SWSW; WBMC22G1SLYW; WBMC22G1SDFW HW Version EW Main v1.4 SW Version s132_nrf52_7.2.0 FCC-ID 2A82K-WBMC22G1W IC: 12514A- WBMC22G1W FVIN: s132_nrf52_7.2.0 HMN N/A PMN Harry Potter Magic Caster Wand Product Description Harry Potter interactive wand Device Category Fixed Installation Mobile Portable  Mixed Mobile and Portable Frequency Range / number of channels BLE: 2402 MHz (ch 0) – 2480 MHz (ch 39), 40 channels Modes of Operation / Declared Output power Bluetooth 5.1 Low Energy (limited to 1Mbps Max) / 4 dBm Max. declared antenna gain 2 dBi Minimum distance of antenna or radiating parts to user 5mm Power Supply/ Rated Operating Voltage Range 5VDC / 1A Operating Temperature Range 0°C to + 45°C C…

Text truncated - open the document above for the full version.

A2LA Accredited IC recognized # 3462B-1 CETECOM Inc. 411 Dixon Landing Road  Milpitas, CA 95035  U.S.A. Phone: + 1 (408) 586 6200  Fax: + 1 (408) 586 6299  E-mail: [email protected]  http://www.cetecom.com CETECOM Inc. is a Delaware Corporation with Corporation number: 2905571 © Copyright by CETECOM FCC / ISED Test Report FOR: Warner Bros. Home Entertainment Inc. Models: WBMC22G1SAVW WBMC22G1SHRW WBMC22G1SHNW WBMC22G1SWSW WBMC22G1SLYW WBMC22G1SDFW Product Description: Harry Potter interactive wand FCC ID: 2A82K-WBMC22G1W IC: 12514A- WBMC22G1W Applied Rules and Standards: 47 CFR Part 15.247 (DTS) RSS-247 Issue 2 (DTSs) & RSS-Gen Issue 5 REPORT #: EMC_FOXBC-001-22001_15.247_BLE_DTS_Rev2 DATE: 11-16-2022 Test Report #: EMC_FOXBC-001-22001_15.247_BLE_DTS_Rev2 FCC ID: 2A82K-WBMC22G1W Date of Report 11-16-2022 Page 2 of 48 IC: 12514A- WBMC22G1W TABLE OF CONTENTS 1 ASSESSMENT .............................................................................................................................................................. 3 2 ADMINISTRATIVE DATA ............................................................................................................................................... 4 2.1 IDENTIFICATION OF THE TESTING LABORATORY ISSUING THE EMC TEST REPORT ........................................................................... 4 2.2 IDENTIFICATION OF THE CLIENT ............................................................................................................................................. 4 2.3 IDENTIFICATION OF THE MANUFACTURER ................................................................................................................................. 4 3 EQUIPMENT UNDER TEST (EUT) ................................................................................................................................... 5 3.1 EUT SPECIFICATIONS ......................................................................................................................................................... 5 3.2 EUT SAMPLE DETAILS ......................................................................................................................................................... 5 3.3 SUPPORT EQUIPMENT (SE) DETAILS ...................................................................................................................................... 6 3.4 TEST SAMPLE CONFIGURATION ............................................................................................................................................. 6 3.5 SOFTWARE USED TO CONFIGURE THE SAMPLES ....................................................................................................................... 6 3.6 JUSTIFICATION FOR WORST CASE MODE OF OPERATION ............................................................................................................ 6 4 SUBJECT OF INVESTIGATION ...................................................................................................................................... 7 5 MEASUREMENT RESULTS SUMMARY .......................................................................................................................... 7 6 MEASUREMENT UNCERTAINTY.................................................................................................................................... 8 6.1 ENVIRONMENTAL CONDITIONS DURING TESTING: ...................................................................................................................... 8 6.2 DATES OF TESTING: ............................................................................................................................................................ 8 7 MEASUREMENT PROCEDURES .................................................................................................................................... 9 7.1 RADIATED MEASUREMENT .................................................................................................................................................... 9 7.2 POWER LINE CONDUCTED MEASUREMENT PROCEDURE .......................................................................................................... 11 7.3 RF CONDUCTED MEASUREMENT PROCEDURE ....................................................................................................................... 11 8 TEST RESULT DATA .................................................................................................................................................. 12 8.1 MAXIMUM PEAK CONDUCTED OUTPUT POWER ....................................................................................................................... 12 8.2 POWER SPECTRAL DENSITY ............................................................................................................................................... 16 8.3 BAND EDGE COMPLIANCE .................................................................................................................................................. 20 8.4 EMISSION BANDWIDTH 6DB AND 99% OCCUPIED BANDWIDTH ................................................................................................... 25 8.5 RADIATED TRANSMITTER SPURIOUS EMISSIONS AND RESTRICTED BANDS ................................................................................... 32 8.6 AC POWER LINE CONDUCTED EMISSIONS ............................................................................................................................. 45 9 TEST SETUP PHOTOS ................................................................................................................................................ 47 10 TEST EQUIPMENT AND ANCILLARIES USED FOR TESTING ......................................................................................... 47 11 HISTORY ...................................................................................................................................…

Text truncated - open the document above for the full version.

Approval sheet Page 1 of 12 ASC_RFECA3216060A1T_V09 Aug. 2018 RFECA Series – RoHS Compliance CERAMIC ANTENNA Halogens Free Product 2.4 GHz ISM Band RF Application P/N: RFECA3216060A1T *Contents in this sheet are subject to change without prior notice. Approval sheet Page 2 of 12 ASC_RFECA3216060A1T_V09 Aug. 2018 FEATURES 1. Surface Mounted Devices with a small dimension of 3.2 X 1.6 X 0.6 mm 3 meet future miniaturization trend. 2. LTCC process. 3. High stability in Temperature / Humidity Change. 4. Superb performance to place on the middle of PCB edge and excellent peak/ average gain observed by field test application. APPLICATIONS 1. ISM Band 2.4GHz applications. 2. Bluetooth.. CONSTRUCTION DIMENSIONS Figure Symbol Dimension (mm) L 3.10 ± 0.20 W 1.60 ± 0.20 T 0.60 ± 0.10 A 0.25 ± 0.20 PINConnection 1 Feeding 2 Soldering terminal Approval sheet Page 3 of 12 ASC_RFECA3216060A1T_V09 Aug. 2018 SOLDER LAND PATTERN DESIGN Type-1: Empty Space 8.0mm x 3.0 mm Figure (Empty Space 8.0 mm x 3.0 mm) The limited size for ECA3216 is L>30mm and D>6mm Land Pattern TYPE-1 TEST BOARD ELECTRONIC CHARACTERISTICS *Note 1. Central Frequency should be defined after customers’ application approval. Item Specification Working Frequency Range 2.4GHz~2.4835GHz (Note-1) Gain 2 dBi (Typical) VSWR 2.0 max. Polarization Linear Azimuth Beamwidth Omni-directional Impedance 50 Power Capacity 3 W max. Maximum Input Power 5 Watts for 5 minutes Approval sheet Page 4 of 12 ASC_RFECA3216060A1T_V09 Aug. 2018 Type-2: Empty Space 6.3mm x 4.0 mm Figure (Empty Space 6.3 mm x 4.0 mm) The limited size for ECA3216 is L>30mm and D>6mm Land Pattern TYPE-2 TEST BOARD ELECTRONIC CHARACTERISTICS *Note 1. Central Frequency should be defined after customers’ application approval. Item Specification Working Frequency Range 2.4GHz~2.4835GHz (Note-1) Gain 2 dBi (Typical) VSWR 2.0 max. Polarization Linear Azimuth Beamwidth Omni-directional Impedance 50 Power Capacity 3 W max. Maximum Input Power 5 Watts for 5 minutes Approval sheet Page 5 of 12 ASC_RFECA3216060A1T_V09 Aug. 2018 Antenna on Type-1 Test Board ( Empty Space 8x3 mm &Thick ness 0.8mm) Antenna S11 on Type-1 Test Board Antenna VSWR on Type-1 Test Board 1.782 @ 2.40 GHz 1.328 @ 2.45 GHz 1.816 @ 2.50 GHz -11.0208 dB @ 2.40 GHz -17.0222 dB @ 2.45 GHz -10.7612 dB @ 2.50 GHz Approval sheet Page 6 of 12 ASC_RFECA3216060A1T_V09 Aug. 2018 Antenna on Type-2 Test Board ( Empty Space 6.3x4 mm &Thick ness 0.8mm) Antenna S11 on Type-2 Test Board Antenna VSWR on Type-2 Test Board 1.453 @ 2.40 GHz 1.216 @ 2.45 GHz 1.732 @ 2.50 GHz -14.6741 dB @ 2.40 GHz -20.2120 dB @ 2.45 GHz -11.4374 dB @ 2.50 GHz Approval sheet Page 7 of 12 ASC_RFECA3216060A1T_V09 Aug. 2018 RADIATION PATTERN Radiation Pattern and Gain were dependent on measurement board design. The specification of RFECA3216060A1T antenna was measured based on the PCB size and installation position as shown in the below figure Test Board. Antenna on Type-1 Test Board ZX plane ZY plane XY plane Frequency [MHz] Max Value [dB] Average [dB] Max Value [dB] Average [dB] Max Value [dB] Average [dB] 2400 0.29 -3.32 1.82 -0.51 1.49 -2.87 2450 0.55 -2.88 2.09 -0.21 1.95 -2.48 2500 -0.15 -3.44 1.82 -0.62 1.82 -2.73 Approval sheet Page 8 of 12 ASC_RFECA3216060A1T_V09 Aug. 2018 Antenna on Type-2 Test Board ZX plane ZY plane XY plane Frequency [MHz] Max Value [dB] Average [dB] Max Value [dB] Average [dB] Max Value [dB] Average [dB] 2400 1.57 -2.83 1.95 -0.76 1.10 -2.93 2450 1.70 -2.62 2.02 -0.62 1.57 -2.61 2500 1.46 -2.82 1.90 -0.71 1.75 -2.68 Approval sheet Page 9 of 12 ASC_RFECA3216060A1T_V09 Aug. 2018 RELIABILITY TEST Test item Test condition / Test method Specification Solderab…

Text truncated - open the document above for the full version.
