2A82N-DEGRIITHMDegrii Smart Thermostat

AuthoritytoActasAgent Date:2022-11 - 14 TUVRheinlandGroup 762ParkAvenue Youngsville,NC27596 ToWhomItMayConcern: IappointTUVRheinland(Shenzhen)Co.,Ltd.toactasouragentinthepreparationapplicationfor equipmentcertification.Icertifythatsubmitteddocumentsproperlydescribethedeviceorsystemforwhich equipmentcertificationissought.Ialsocertifythateachunitmanufactured,importedormarketed,asdefinedinthe FCCorIndustryCanada’sregulationswillhaveaffixedtoitalabelidenticaltothatsubmittedforapprovalwith thisapplication. Forinstanceswhereourauthorizedagentsignstheapplicationforcertificationonourbehalf,I acknowledgethatallresponsibilityforcomplyingwiththetermsandconditionsforCertification,as specifiedbyTUVRheinlandGroup,stillresideswithDegrii,Inc./8TheGreen,SteA,Dover,DE 19901 ForTCBapplications,Wecertifythatwearenotsubjecttodenialoffederalbenefits,thatincludes FCCbenefits,pursuanttoSection5301oftheAnti-DrugAbuseActof1988,21U.S.C.862.Further, noparty,asdefinedin47CFR1.2002(b),totheapplicationissubjecttodenialoffederalbenefits, thatincludesFCCbenefits. Thankyou, AgencyAgreementExpirationDate:12months By: MrJasonSun (PrintName) Title: Directorof Quality Telephone: +8613925229746 Onbehalfof: Degrii,Inc. (CompanyName) QF094234Page1of1Revision0

北京众清科技有限公司 AntennaTestReport Contents: 1.AntennaProfile 2.AntennaPerformanceTest 3.AntennaPassiveTest --------------------------------------------------------------------------------------------------------------------------------- Tester:FengBoyuan Approval:LiHongyu Date:2022/10/25 2.AntennaPerformanceTest S Parameter Test Phi=0 Theta=90 3Dmodel PassiveTestForBLEAntenna(2.4G) Frequency(MHZ)Efficiency(%)Efficiency(db)PeakGain(dbi) 240053%-2.753.09 241054%-2.673.16 242056%-2.503.33 243061%-2.183.60 244061%-2.163.60 245057%-2.413.30 246057%-2.453.24 247060%-2.193.78 248063%-2.043.97 249060%-2.213.80 250056%-2.543.33

ConfidentialInformation www.speed-hz.com SPEEDhaspossessionofproprietaryinformationprovidedinthispresentationandthisproprietary informationshallbekeptinstrictconfidenceandnotdisclosedtoanypersonorfirmwithouttheprior writtenconsentofSPEEDCommunicationTechnology. Pa ge 1 SPEEDTECHNOLOGY SPEEDCommunicationTechnologyLimited Approvalsheetof ZHONGQING Antenna Customer/Project MARS FrequencyBandWIFI SCTP/NVersionT16 Date2022-10-9 MaterialCodeF-0G-C6-0002-000-00 SPEED Checkedby RFERICGUO Designby RF 刘健烨 MEERICGUOME 邓润溪 QCTAOZHUTAORemark Customer Date Confirmedby RF ME Remark ConfidentialInformation www.speed-hz.com SPEEDhaspossessionofproprietaryinformationprovidedinthispresentationandthisproprietary informationshallbekeptinstrictconfidenceandnotdisclosedtoanypersonorfirmwithouttheprior writtenconsentofSPEEDCommunicationTechnology. Page2 Index 1.Indication.....................................................................3 2.MeasurementData.........................................................4 2.1WIFIAntenna............................................................4 2.2Gain..........................................................................7 3.Appearancedrawing.......................................................9 4.SuggestionsandConclusion..............................................10 ConfidentialInformation www.speed-hz.com SPEEDhaspossessionofproprietaryinformationprovidedinthispresentationandthisproprietary informationshallbekeptinstrictconfidenceandnotdisclosedtoanypersonorfirmwithouttheprior writtenconsentofSPEEDCommunicationTechnology. Page4 DescriptionoftheMARSantennainformation 1AntennashapeFPC+WIRE+IPAX1 2AntennatypeWIFI 3MaterialMARS(NBA3001) 4FrequencyHZ:WiFi2.4G2400M-2500M 5PeakGainDBI≥4 6Efficiency%≥35 7ImpedanceΩ:50Ω 8WirelengthMM47 9ColorBlack 10EditionT16 11OtherattributesNO 12ManufacturerSPEED 13Manufacturermodel ConfidentialInformation www.speed-hz.com SPEEDhaspossessionofproprietaryinformationprovidedinthispresentationandthisproprietary informationshallbekeptinstrictconfidenceandnotdisclosedtoanypersonorfirmwithouttheprior writtenconsentofSPEEDCommunicationTechnology. Page 5 2.MeasurementData 2.1WIFIAntenna VSWRmeasurements(S 11 )wereperformedusingAgilent5071CNetworkAnalyzer.Thetestingwas performedinfreespace.Thissectionsummarizestheelectricalperformancestructuredrawings confirmedbythecustomers,2400MHZ~2500MHZWIFIantenna. Figure3:WIFIRETURNLOSS ConfidentialInformation www.speed-hz.com SPEEDhaspossessionofproprietaryinformationprovidedinthispresentationandthisproprietary informationshallbekeptinstrictconfidenceandnotdisclosedtoanypersonorfirmwithouttheprior writtenconsentofSPEEDCommunicationTechnology. Page6 Figure4:WIFISWR ConfidentialInformation www.speed-hz.com SPEEDhaspossessionofproprietaryinformationprovidedinthispresentationandthisproprietary informationshallbekeptinstrictconfidenceandnotdisclosedtoanypersonorfirmwithouttheprior writtenconsentofSPEEDCommunicationTechnology. Page 7 2.2Gain Frequency(MHZ)Efficiency(db)Efficiency(%)PeakGain（dbi） 2400-3.4844.94.88 2410-3.6842.84.68 2420-3.9340.44.43 2430-3.9440.34.42 2440-3.742.74.66 2450-3.6343.44.73 2460-3.841.74.56 2470-3.8241.54.54 2480-3.9440.44.42 2490-439.84.36 2500-4.1438.54.22 2.3DirectionalDiagram Figure5:Theta=90 ° ConfidentialInformation www.speed-hz.com SPEEDhaspossessionofproprietaryinformationprovidedinthispresentationandthisproprietary informationshallbekeptinstrictconfidenceandnotdisclosedtoanypersonorfirmwithouttheprior writtenconsentofSPEEDCommunicationTechnology. Page8 Figure6:Phi=90 ° Figure7:Phi=0° Figure7:3dmodel ConfidentialInformation www.speed-hz.com SPEEDhaspossessionofproprietaryinformationprovidedinthispresentationandthisproprietary informationshallbekeptinstrictconfidenceandnotdisclosedtoanypersonorfirmwithouttheprior writtenconsentofSPEEDCommunicationTechnology. Pa ge 10 4.SuggestionsandConclusion Thisreportsummarizestheelectricalperformancestructuredrawingsconfirmedbythecustomersof MARSproject.Speedislookingforwardtogettingyourapproval.Thanksforyourcooperation.

MS-0044715Page1of1Revision1 Date:2022-11-14____ FederalCommunicationsCommission EquipmentAuthorizationBranch 7435OaklandMillsRoad,Columbia,MD21046,USA Subject:ConfidentialityRequestforFCCID:2A82N-DEGRIITHM PursuanttoFCC47CRF0.457(d),theapplicantrequeststhatapartofthesubjectFCC/ICapplicationbeheldconfidential. TypeofConfidentialityRequestedExhibit ShortTermPermanentBlockDiagrams ShortTermn/aExternalPhoto ShortTermPermanentInternalPhotos*** ShortTermPermanentOperationDescription/TheoryofOperation ShortTermPermanentSchematics ShortTermPermanentTestSetup*** ShortTermPermanentTune-UpProcedure ShortTermPermanentUser’sManual*** ShortTermPermanentPartList/AntennaConstruction Degrii,Inc.hasspentsubstantialeffortindevelopingthisproductanditisoneofthefirstofitskindinindustry.Having thesubjectinformationeasilyavailableto"competition"wouldnegatetheadvantagetheyhaveachievedbydeveloping thisproduct.Notprotectingthedetailsofthedesignwillresultinfinancialhardship. PermanentConfidentiality: Theapplicantrequeststheexhibitslistedaboveaspermanentlyconfidentialbepermanentlywithheldfrompublicreview duetomaterialsthatcontaintradesecretsandproprietaryinformationnotcustomarilyreleasedtothepublic. (***ExceptionalcaseforPermanentConfidentialityfortheseExhibitsbyPAGonly) Short-TermConfidentiality: Theapplicantrequeststheexhibitsselectedaboveasshorttermconfidentialbewithheldfrompublicviewforaperiodof specifynumberofdaysnottoexceed180daysfromthedateoftheGrantofEquipmentAuthorizationandpriorto marketing.Thisistoavoidprematurereleaseofsensitiveinformationpriortomarketingorreleaseoftheproducttothe public.ApplicantisalsoawarethattheyareresponsibletonotifyTUVRheinlandintheeventinformationregardingthe productortheproductismadeavailabletothepublic.TUVRheinlandwillthenreleasethedocumentslistedabovefor publicdisclosurepursuanttoFCCPublicNoticeDA04-1705. Sincerely, By:__________________________________Mr.JasonSun_/DirectorofQuality (Signature/Title)(Printname) Email:[email protected]

WIFI+BLE antenna BLE antenna

The EUT is Smart Thermostat which supported IEEE 802.11 b/g/n 2.4GHz Wi-Fi and Bluetooth Low Energy. The Mars Intelligent Thermostat is an intelligent HVAC device controller Device, local interaction contains three capacitive touch keys And LED dot matrix screen, remote interaction through mobile APP real now. The Mars smart thermostat is based on user-set information and data Ground sensor data, combined with local and cloud control algorithms, Intelligent adjustment of home decoration HVAC system working mode, in order to real Now the temperature, humidity, air circulation in the living environment Intelligent adjustment to achieve a balance between comfort and energy saving. SPECIFICATION: Input: 24V~ 60Hz 0.1A max Dimensions: 145mm x 83mm x 22mm Operating Temperature: 32°F~130°F Operating Humidity: 5%~95%RH (non-condensing) Storage Temperature: -22~140°F Storage Humidity: 5%~95%RH (non-condensing) Technical Specification of Wi-Fi 802.11 b/g/n (WBR1) Operating Frequency 2412 - 2462 MHz for 802.11b/g/n(HT20) Type of Modulation DSSS(DBPSK/DQPSK/CCK) OFDM(BPSK/QPSK/16QAM/64QAM) Data Rate 1/2/5.5/11 Mbps for 802.11b 6/9/12/18/24/36/48/54 Mbps for 802.11g MCS0 ~ MCS7 for 802.11n Channel Number 11 channels for 802.11b/g/n(HT20) Channel Separation5 MHz Number of Antenna:1 Antenna typeFPC antenna Antenna Gain:4.88dBi Technical Specification of Bluetooth Low Energy (WBR1) Operating Frequency2402 – 2480 MHz Data rate1Mbps Channel Number40 channels Channel separation2MHz Modulation GFSK Number of Antenna1 Antenna TypeFPC antenna Antenna Gain4.88dBi Technical Specification of Bluetooth Low Energy (ESP32) Operating Frequency2402 – 2480 MHz Data rate1Mbps Channel Number40 channels Channel separation2MHz Modulation GFSK Number of Antenna1 Antenna TypePCB Layout antenna Antenna Gain3.97dBi

1.AntennaProfile Device BLE Antenna 3.AntennaPassiveTest

ConfidentialInformation www.speed-hz.com SPEEDhaspossessionofproprietaryinformationprovidedinthispresentationandthisproprietary informationshallbekeptinstrictconfidenceandnotdisclosedtoanypersonorfirmwithouttheprior writtenconsentofSPEEDCommunicationTechnology. Page3 1.Indication Thisreportsummarizestheelectricalperformancestructuredrawingsconfirmedbythecustomersof MARSproject.TheantennaisanassemblyInsidetheTemperatureandhumiditymachine(seeFigure1). ThegainandefficiencyoftheantennawasmeasuredintheBluetestchamber.Thechamberprovides lessthan–40dBreflectivityfrom600MHzthrough6GHz. Figure1:ProposedAntenna Figure2:WIFI

Prüfbericht - Produkte Test Report - Products Prüfbericht - Nr.: Test Report No.: CN22PK9E 001 Seite 21 von 23 Page 21 of 23 6 Safety Human Exposure 6.1 Radio Frequency Exposure Compliance 6.1.1 Electromagnetic Fields RESULT:Pass Test Specification Test standard: FCC KDB Publication 447498 v06 CFR47 FCC Part 2: Section 2.1091 CFR47 FCC Part 1: Section 1.1310 RSS-102 Issue 5 February 2021 FCC requirements FCC requirement: Systems operating under the provisions of this section shall be operated in a manner that ensures that the public is not exposed to radio frequency energy level in excess limit for maximum permissible exposure. In accordance with 47 CFR FCC Part 2 Subpart J, section 2.1091 this device has been defined as a mobile device whereby a distance of 20cm normally can be maintained between the user and the device. MPE Calculation Method according to KDB 447498 v06 Power Density: S (mW/cm 2 ) = PG/4πR 2 or EIRP/4πR 2 Where: S = power density (mW/cm 2 ) P = power input to the antenna (mW) G = power gain of the antenna in the direction of interest relative to an isotropic radiator R = distance to the center of radiation of the antenna (cm) From the peak RF output power, the minimum mobile separation distance, d=20 cm, as well as the antenna gain, the RF power density can be calculated as below: S (mW/cm 2 ) = PG/4πR 2 a)EUT RF Exposure Evaluation standalone operations Maximum conducted Power Measured e.i.r.p Test Mode (dBm)(mW) Antenna Gain (dBi) (dBm)(mW) S (mW/cm 2 ) = PG/4πR 2 Limit (mW/cm 2 ) BLE (ESP)18.774.1313.9722.67184.9270.0371.0 BLE (WBR1)5.43.4674.8810.2810.6660.0021.0 2.4GHz Wi-Fi24.5281.8384.8829.38866.9620.171.0 b)EUT RF Exposure Evaluation simultaneous transmission operations Simultaneous transmission mode The sum of the ratiosResult BLE(ESP32) + BLE (WBR1) + 2.4GHz Wi-Fi 0.037/1 + 0.17/1< 1Pass Prüfbericht - Produkte Test Report - Products Prüfbericht - Nr.: Test Report No.: CN22PK9E 001 Seite 22 von 23 Page 22 of 23 IC requirements: The EUT shall comply with the requirement of RSS-102 section 2.5.2. Exemption from Routine Evaluation Limits – RF Exposure Evaluation RF exposure evaluation is required if the separation distance between the user and/or bystander and the device’s radiating element is greater than 20 cm, except when the device operates as follows: at or above 300 MHz and below 6 GHz and the source-based, time-averaged maximum e.i.r.p. of the device is equal to or less than 1.31 x 10 -2 ƒ 0.6834 W (adjusted for tune-up tolerance), where ƒ is in MHz; RF exposure evaluation exempted power: 2.670 W a)EUT RF Exposure Evaluation standalone operations: Measured Peak Power Measured e.i.r.p (mW) Test Mode (dBm)(mW) Antenna Gain (dBi) (dBm)(mW) BLE (ESP)18.774.1313.9722.67184.927 BLE (WBR1)5.43.4674.8810.2810.666 2.4GHz Wi-Fi24.5281.8384.8829.38866.962 b)EUT RF Exposure Evaluation simultaneous transmission operations Simultaneous transmission mode The sum of the ratiosResult BLE(ESP32) + BLE (WBR1) + 2.4GHz Wi-Fi 0.18/2.67 + 0.867/2.67< 1Pass The e.i.r.p. for BLE and DTSs are less than the RF exposure evaluation exempted power. So RF exposure evaluation is not required. “RF Radiation Exposure Statement Caution: This Transmitter must be installed to provide a separation distance of at least 20 cm from all persons.”

Prüfbericht - Produkte Test Report - Products Prüfbericht-Nr.: Test report no.: CN22PK9E 002 Auftrags-Nr.: Order no.: 168392703 Seite 1 von 21 Page 1 of 21 Kunden-Referenz-Nr.: Client reference no.: N/A Auftragsdatum: Order date: 2022-09-28 Auftraggeber: Client: Degrii, Inc. 8 The Green, Ste A, Dover, DE 19901, United States Prüfgegenstand: Test item: Degrii Smart Thermostat Bezeichnung / Typ-Nr.: Identification / Type no.: THM (Trademark: Degrii) Auftrags-Inhalt: Order content: FCC and IC approval Prüfgrundlage: Test specification: CFR47 FCC Part 15: Subpart C Section 15.247 CFR47 FCC Part 15: Subpart C Section 15.207 CFR47 FCC Part 15: Subpart C Section 15.209 RSS-247 Issue 2 February 2017 RSS-Gen Issue 5 February 2021 Wareneingangsdatum: Date of sample receipt: 2022-10-10 Please refer to photo documents Prüfmuster-Nr.: Test sample no.: A003345059-001 to 003 Prüfzeitraum: Testing period: 2022-10-11 – 2022-10-31 Ort der Prüfung: Place of testing: TÜV Rheinland (Shenzhen) Co., Ltd. Prüflaboratorium: Testing laboratory: TÜV Rheinland (Shenzhen) Co., Ltd. Prüfergebnis*: Test result*: Pass geprüft von: tested by: X Signed by: Alex Lan genehmigt von: authorized by: X Signed by: Lin Lin Datum: Date: 2022-12-01 Ausstellungsdatum: Issue date: 2022-12-02 Stellung / Position Assistant Project Manager Stellung / Position Reviewer Sonstiges / Other: FCC ID: 2A82N-DEGRIITHM IC: 29487-DEGRIITHM HVIN: THM Zustand des Prüfgegenstandes bei Anlieferung: Condition of the test item at delivery: Prüfmuster vollständig und unbeschädigt Test item complete and undamaged: * Legende: 1 = sehr gut 2 = gut 3 = befriedigend 4 = ausreichend 5 = mangelhalt P(ass) = entspricht o.g. Prüfgrundlage(n) F(ail) = entspricht nicht o.g. Prüfgrundlage(n) N/A = nicht anwendbar N/T = nicht getestet Legend: 1 = very good 2 = good 3 = satisfactory 4 = sufficient 5 = poor P(ass) = passed a.m. test specifications(s) F(ail) = failed a.m. test specifications(s) N/A = not applicable N/T = not tested Dieser Prüfbericht bezieht sich nur auf das o.g. Prüfmuster und darf ohne Genehmigung der Prüfstelle nicht auszugsweise vervielfältigt werden. Dieser Bericht berechtigt nicht zur Verwendung eines Prüfzeichens. This test report only relates to the a. m. test sample. Without permission of the test center this test report is not permitted to be V05 duplicated in extracts. This test report does not entitle to carry any test mark. TÜV Rheinland (Shenzhen) Co., Ltd. 1601 R&D Room, 1602-1604, 17-18F, Building 7 Site C, Vanke Cloud City Phase I, Xingke First Street, Xili Street, Xili Community, Nanshan District, Shenzhen 518052, P.R. China Mail: [email protected] · Web: www.tuv.com Prüfbericht - Produkte Test Report - Products Prüfbericht - Nr.: Test Report No.: CN22PK9E 002 Seite 2 von 21 Page 2 of 21 Test Summary 5.1.1 ANTENNA REQUIREMENT RESULT: Pass 5.1.2 MAXIMUM CONDUCTED OUTPUT POWER RESULT: Pass 5.1.3 CONDUCTED POWER SPECTRAL DENSITY RESULT: Pass 5.1.4 99%DB BANDWIDTH RESULT: Pass 5.1.5 6DB BANDWIDTH RESULT: Pass 5.1.6 CONDUCTED SPURIOUS EMISSIONS MEASURED IN 100 KHZ BANDWIDTH RESULT: Pass 5.1.7 RADIATED SPURIOUS EMISSION RESULT: Pass 5.1.8 CONDUCTED EMISSION ON AC MAINS RESULT: Pass Prüfbericht - Produkte Test Report - Products Prüfbericht - Nr.: Test Report No.: CN22PK9E 002 Seite 3 von 21 Page 3 of 21 Contents 1 GENERAL REMARKS ......................................................................................................................4 1.1 COMPLEMENTARY MATERIALS ........................................................................................................4 2 TEST SITES ...................................................................................................................................5 2.1 TEST FACILITIES ............................................................................................................................5 2.2 LIST OF TEST AND MEASUREMENT INSTRUMENTS .............................................................................5 2.3 TRACEABILITY ...............................................................................................................................6 2.4 CALIBRATION ................................................................................................................................6 2.5 MEASUREMENT UNCERTAINTY ........................................................................................................6 2.6 LOCATION OF ORIGINAL DATA ........................................................................................................6 2.7 STATUS OF FACILITY USED FOR TESTING .........................................................................................6 3 GENERAL PRODUCT INFORMATION ..................................................................................................7 3.1 PRODUCT FUNCTION AND INTENDED USE .........................................................................................7 3.2 RATINGS AND SYSTEM DETAILS ......................................................................................................7 3.3 INDEPENDENT OPERATION MODES ..................................................................................................9 3.4 NOISE GENERATING AND NOISE SUPPRESSING PARTS ......................................................................9 3.5 SUBMITTED DOCUMENTS ................................................................................................................9 4 TEST SET-UP AND OPERATION MODES .......................................................................................... 10 4.1 PRINCIPLE OF CONFIGURATION SELECTION .................................................................................... 10 4.2 TEST OPERATION AND TEST SOFTWARE ........................................................................................ 10 4.3 SPECIAL ACCESSORIES AND AUXILIARY EQUIPMENT ....................................................................... 10 4.4 …

Text truncated - open the document above for the full version.

Prüfbericht - Produkte Test Report - Products Prüfbericht-Nr.: Test report no.: CN22PK9E 001 Auftrags-Nr.: Order no.: 168392703 Seite 1 von 23 Page 1 of 23 Kunden-Referenz-Nr.: Client reference no.: N/A Auftragsdatum: Order date: 2022-09-28 Auftraggeber: Client: Degrii, Inc. 8 The Green, Ste A, Dover, DE 19901, United States Prüfgegenstand: Test item: Degrii Smart Thermostat Bezeichnung / Typ-Nr.: Identification / Type no.: THM (Trademark: Degrii) Auftrags-Inhalt: Order content: FCC and IC approval Prüfgrundlage: Test specification: CFR47 FCC Part 15: Subpart C Section 15.247 CFR47 FCC Part 15: Subpart C Section 15.207 CFR47 FCC Part 15: Subpart C Section 15.209 CFR47 FCC Part 2: Section 2.1091 RSS-247 Issue 2 February 2017 RSS-Gen Issue 5 February 2021 RSS-102 Issue 5 February 2021 Wareneingangsdatum: Date of sample receipt: 2022-10-10 Please refer to photo documents Prüfmuster-Nr.: Test sample no.: A003345059-001 to 003 Prüfzeitraum: Testing period: 2022-10-11 – 2022-10-31 Ort der Prüfung: Place of testing: TÜV Rheinland (Shenzhen) Co., Ltd. Prüflaboratorium: Testing laboratory: TÜV Rheinland (Shenzhen) Co., Ltd. Prüfergebnis*: Test result*: Pass geprüft von: tested by: X Signed by: Alex Lan genehmigt von: authorized by: X Signed by: Lin Lin Datum: Date: 2022-12-01 Ausstellungsdatum: Issue date: 2022-12-02 Stellung / Position Assistant Project Manager Stellung / Position Reviewerr Sonstiges / Other: FCC ID: 2A82N-DEGRIITHM IC: 29487-DEGRIITHM HVIN: THM Zustand des Prüfgegenstandes bei Anlieferung: Condition of the test item at delivery: Prüfmuster vollständig und unbeschädigt Test item complete and undamaged: * Legende: 1 = sehr gut 2 = gut 3 = befriedigend 4 = ausreichend 5 = mangelhalt P(ass) = entspricht o.g. Prüfgrundlage(n) F(ail) = entspricht nicht o.g. Prüfgrundlage(n) N/A = nicht anwendbar N/T = nicht getestet Legend: 1 = very good 2 = good 3 = satisfactory 4 = sufficient 5 = poor P(ass) = passed a.m. test specifications(s) F(ail) = failed a.m. test specifications(s) N/A = not applicable N/T = not tested Dieser Prüfbericht bezieht sich nur auf das o.g. Prüfmuster und darf ohne Genehmigung der Prüfstelle nicht auszugsweise vervielfältigt werden. Dieser Bericht berechtigt nicht zur Verwendung eines Prüfzeichens. This test report only relates to the a. m. test sample. Without permission of the test center this test report is not permitted to be V05 duplicated in extracts. This test report does not entitle to carry any test mark. TUV Rheinland (Shenzhen) Co., Ltd. 1601 R&D Room, 1602-1604, 17-18F, Building 7 Site C, Vanke Cloud City Phase I, Xingke First Street, Xili Street, Xili Community, Nanshan District, Shenzhen 518052, P.R. China Mail: [email protected] Web: www.tuv.com Prüfbericht - Produkte Test Report - Products Prüfbericht - Nr.: Test Report No.: CN22PK9E 001 Seite 2 von 23 Page 2 of 23 Test Summary 5.1.1 ANTENNA REQUIREMENT RESULT: Pass 5.1.2 MAXIMUM CONDUCTED PEAK OUTPUT POWER RESULT: Pass 5.1.3 CONDUCTED POWER SPECTRAL DENSITY RESULT: Pass 5.1.4 99%DB BANDWIDTH RESULT: Pass 5.1.5 6DB BANDWIDTH RESULT: Pass 5.1.6 CONDUCTED SPURIOUS EMISSIONS MEASURED IN 100 KHZ BANDWIDTH RESULT: Pass 5.1.7 RADIATED SPURIOUS EMISSION RESULT: Pass 5.1.8 CONDUCTED EMISSION ON AC MAINS RESULT: Pass 6.1.1 ELECTROMAGNETIC FIELDS RESULT: Pass Prüfbericht - Produkte Test Report - Products Prüfbericht - Nr.: Test Report No.: CN22PK9E 001 Seite 3 von 23 Page 3 of 23 Contents 1 GENERAL REMARKS ......................................................................................................................4 1.1 COMPLEMENTARY MATERIALS ........................................................................................................4 2 TEST SITES ...................................................................................................................................5 2.1 TEST FACILITIES ............................................................................................................................5 2.2 LIST OF TEST AND MEASUREMENT INSTRUMENTS .............................................................................5 2.3 TRACEABILITY ...............................................................................................................................6 2.4 CALIBRATION ................................................................................................................................6 2.5 MEASUREMENT UNCERTAINTY ........................................................................................................6 2.6 LOCATION OF ORIGINAL DATA ........................................................................................................6 2.7 STATUS OF FACILITY USED FOR TESTING .........................................................................................6 3 GENERAL PRODUCT INFORMATION ..................................................................................................7 3.1 PRODUCT FUNCTION AND INTENDED USE .........................................................................................7 3.2 RATINGS AND SYSTEM DETAILS ......................................................................................................7 3.3 INDEPENDENT OPERATION MODES ..................................................................................................9 3.4 NOISE GENERATING AND NOISE SUPPRESSING PARTS ......................................................................9 3.5 SUBMITTED DOCUMENTS ................................................................................................................9 4 TEST SET-UP AND OPERATION MODES .......................................................................................... 10 4.1 PRINCIPLE OF CONFIGURATION SELECTION .................................................................................... 10 4.2 TEST OPERATION AND TEST SOFTWARE ........................................................................................ 10 4.3 SPECIAL ACCESS…

Text truncated - open the document above for the full version.

Prüfbericht - Produkte Test Report - Products Appendix A CN22PK9E 001 Page 1 of 3 Appendix A: Photographs of the Test Set-Up APPENDIX A: PHOTOGRAPHS OF THE TEST SET-UP.......................................................................................................1 PHOTOGRAPH 1: SET-UP FOR RADIATED SPURIOUS EMISSION, BELOW 1GHZ....................................................................................2 PHOTOGRAPH 2: SET-UP FOR RADIATED SPURIOUS EMISSION, ABOVE 1GHZ....................................................................................2 PHOTOGRAPH 3: SET-UP FOR CONDUCTED EMISSION ON AC MAINS...............................................................................................3 Prüfbericht - Produkte Test Report - Products Appendix A CN22PK9E 001 Page 2 of 3 Photograph 1: Set-up for Radiated Spurious Emission, Below 1GHz Photograph 2: Set-up for Radiated Spurious Emission, Above 1GHz Prüfbericht - Produkte Test Report - Products Appendix A CN22PK9E 001 Page 3 of 3 Photograph 3: Set-up for Conducted Emission on AC Mains
