2A86Y-TG-182Portable Wireless Speaker,Bluetooth Speaker

Shenzhenchengtaielectronicandtechnologyco.,LTD 2.911(d)(5)(i)EquipmentTypeAttestationv1.2 Section2.911(d)(5)(i)Certification–EquipmentType Companyname:Shenzhenchengtaielectronicandtechnologyco.,LTD Address:6thFloor,BuildingC,QinyuIndustrialZone,SanweiSanweiCommunity,HangchengStreet, BaoanDistrictShenzhenChina ProductName:PortableWirelessSpeaker,BluetoothSpeaker FCCID:2A86Y-TG-182 Model(s):TG-182,TG-116,TG-126,TG-143,TG-149,TG-157,TG-165C,TG-165,TG-183,TG-191, TG-227 2.911(d)(5)(i)EquipmentType We,[Shenzhenchengtaielectronicandtechnologyco.,LTD](“theapplicant”)certifythatthe equipmentforwhichauthorizationissoughtthroughcertificationisnot:  Prohibitedfromreceivinganequipmentauthorizationpursuantto§2.903;oftheFCCrules.  Identifiedasanequipmenttypeinthe“CoveredList” NOTE1 Yourssincerely, Name:FangRuanDate:2024.3.27 TitleandCompanyname:Manager/Shenzhenchengtaielectronicandtechnologyco.,LTD NOTE1 “CoveredList”;istheListofEquipmentandServicesCoveredBySection2ofTheSecureNetworksAct,availableat https://www.fcc.gov/supplychain/coveredlist References; 1)986446D01CoveredEquipmentv01 https://apps.fcc.gov/oetcf/kdb/forms/FTSSearchResultPage.cfm?switch=P&id=325672 2)FederalRegisterdocument2022-28263publishedon02/06/23 https://www.federalregister.gov/documents/2023/02/06/2022-28263/protecting-against-national-security-threats-to-the-com munications-supply-chain-through-the

Shenzhenchengtaielectronicandtechnologyco.,LTD 2.911(d)(5)(ii)ApplicantAttestationv1.3 Section2.911(d)(5)(ii)Certification–Applicant(CoveredList) Companyname:Shenzhenchengtaielectronicandtechnologyco.,LTD Address:6thFloor,BuildingC,QinyuIndustrialZone,SanweiSanweiCommunity,HangchengStreet, BaoanDistrictShenzhenChina ProductName:PortableWirelessSpeaker,BluetoothSpeaker FCCID:2A86Y-TG-182 Model(s):TG-182,TG-116,TG-126,TG-143,TG-149,TG-157,TG-165C,TG-165,TG-183,TG-191, TG-227 2.911(d)(5)(ii)Applicantfiling We,[Shenzhenchengtaielectronicandtechnologyco.,LTD](“theapplicant”)certifythat,asofthe dateofthefilingoftheapplication,theapplicantisnotidentified NOTE1 onthe“CoveredList” NOTE2 , establishedpursuantto§1.50002ofthischapter,asanentityproducingcoveredcommunications equipment. Yourssincerely, Name:FangRuanDate:2024.3.27 TitleandCompanyname:Manager/Shenzhenchengtaielectronicandtechnologyco.,LTD NOTE1 Deleteoptionnotapplicabletothisapplication. NOTE2 “CoveredList”;istheListofEquipmentandServicesCoveredBySection2ofTheSecureNetworksAct,availableat https://www.fcc.gov/supplychain/coveredlist References; 1)986446D01CoveredEquipmentv01 https://apps.fcc.gov/oetcf/kdb/forms/FTSSearchResultPage.cfm?switch=P&id=325672 2)FederalRegisterdocument2022-28263publishedon02/06/23 https://www.federalregister.gov/documents/2023/02/06/2022-28263/protecting-against-national-security-threats-to-the-com munications-supply-chain-through-the

Shenzhenchengtaielectronicandtechnologyco.,LTD 2.911(d)(7)USAAgentv1.5 Section2.911(d)(7)USAAgentforServiceofProcess Companyname:Shenzhenchengtaielectronicandtechnologyco.,LTD Address:6thFloor,BuildingC,QinyuIndustrialZone,SanweiSanwei Community,HangchengStreet,BaoanDistrictShenzhenChina ProductName:PortableWirelessSpeaker,BluetoothSpeaker FCCID:2A86Y-TG-182 Model(s):TG-182,TG-116,TG-126,TG-143,TG-149,TG-157,TG-165C,TG-165,TG-183, TG-191,TG-227 2.911(d)(7)USADesignatedAgentforServiceofProcess We,[Shenzhenchengtaielectronicandtechnologyco.,LTD](“theapplicant”) designate[StoneTradingLimited] NOTE1 forthepurposeofacceptingserviceofprocess onbehalfoftheapplicant. Applicantconsent:Weacknowledgeourconsenttoacceptserviceofprocessinthe UnitedStatesformattersrelatedtotheapplicableequipment,andatthephysicalU.S. addressandemailaddressofthedesignatedagentandacknowledgeour acceptanceofourobligationtomaintainanagentforserviceofprocessintheUnited Statesfornolessthanoneyearaftereitherwethegranteehavepermanently terminatedallmarketingandimportationoftheapplicableequipmentwithintheU.S., orattheconclusionofanyCommission-relatedadministrativeorjudicialproceeding involvingtheequipment,whicheverislater. Agentobligation:Weacknowledgeourobligationtoacceptserviceofprocessinthe UnitedStatesformattersrelatedtotheapplicableequipmentatourphysicalU.S. addressandemailaddressfornolessthanoneyearaftereitherthegranteehas permanentlyterminatedallmarketingandimportationoftheapplicableequipment withintheU.S.,orattheconclusionofanyCommission-relatedadministrativeor judicialproceedinginvolvingtheequipment,whicheverislater. USAAgent Companyname:StoneTradingLimited USAAddress:6547NAcademyBlvd #2266,ColoradoSprings,CO80918,United States FRNNumber ： 0033401936 ContactName:DongmeiFang TelephoneNo:+12134573118 Email:[email protected] Applicant Companyname:Shenzhenchengtai electronicandtechnologyco.,LTD Address:6thFloor,BuildingC,Qinyu IndustrialZone,SanweiSanwei Community,HangchengStreet,Baoan DistrictShenzhenChina GranteeFRNNumber ： 0033044058 FCCGranteeCode:2A86Y ContactName:FangRuan TelephoneNo:+8617093468875 Email:[email protected] Shenzhenchengtaielectronicandtechnologyco.,LTD 2.911(d)(7)USAAgentv1.5 Signature: Title:manager Signature: Title:Manager Date:2024.3.27Date:2024.3.27 NOTE1:AnapplicantlocatedintheUnitedStatesmaydesignateitselfastheagentforservice ofprocess. Reference;FederalRegisterdocument2022-28263publishedon02/06/23 https://www.federalregister.gov/documents/2023/02/06/2022-28263/protecting-against-nation al-security-threats-to-the-communications-supply-chain-through-the

Shenzhenchengtaielectronicandtechnologyco.,LTD AgentAuthorization Company:Shenzhenchengtaielectronicandtechnologyco.,LTD Address:6thFloor,BuildingC,QinyuIndustrialZone,SanweiSanwei Community,HangchengStreet,BaoanDistrictShenzhenChina ProductName:PortableWirelessSpeaker,BluetoothSpeaker ModelNumber(s):TG-182,TG-116,TG-126,TG-143,TG-149,TG-157,TG-165C, TG-165,TG-183,TG-191,TG-227 ProductDescription:PortableWirelessSpeaker,BluetoothSpeaker WeauthorizeMiCOMLabsInc.,575BoulderCourt,Pleasanton,California94566,USA, toactonourbehalfonallmattersconcerningthecertificationofabovenamed equipment. WedeclarethatMiCOMLabsInc.isallowedtoforwardallinformationrelatedtothe approvalandcertificationofequipmenttotheregulatoryagenciesasrequiredandto discussanyissuesconcerningtheapprovalapplication.Anyandallactscarriedoutby MiCOMLabsonourbehalfshallhavethesameeffectasactsofourown. Signature:Date:2024.3.27 Name:FangRuan Title:Manager Company:Shenzhenchengtaielectronicandtechnologyco.,LTD

Shenzhen chengtai electronic and technology co.,LTD Model Difference Product description: Portable Wireless Speaker,Bluetooth Speaker Model name: TG-182,TG-116,TG-126,TG-143,TG-149,TG-157,TG-165C,TG-165,TG- 183,TG-191,TG-227 Trade Name: N/A FCC ID: 2A86Y-TG-182 All the model are the same circuit and RF module, except for model No. and appearance (for color, silk-screen only). Regards Sincerely Client’s signature: Client’s name / title : Fang Ruan/ Manager Contact information / address: 6th Floor, Building C, Qinyu Industrial Zone, Sanwei, Sanwei Community, Hangcheng Street, Baoan District, Shenzhen

Shenzhenchengtaielectronicandtechnologyco.,LTD OfficeofEngineeringTechnology FederalCommunicationsCommission 7435OaklandMillsRoad Columbia,MD21046 USA Date:2024.3.27 Subject;RequestforConfidentiality FCCID:2A86Y-TG-182 ToWhomItMayConcern, PursuanttotheprovisionsoftheCommission’srulesTitle47Sections§0.457and§0.459,we arerequestingtheCommissiontowithholdthefollowingattachment(s)asconfidential documentsfrompublicdisclosureindefinitely. Thesedocumentscontaindetailedsystemandequipmentdescriptionsandareconsideredas proprietaryinformationinoperationoftheequipment.Thepublicdisclosureofthesedocuments mightbeharmfultoourcompanyandwouldgivecompetitorsanunfairadvantageinthemarket. SchematicDiagram BlockDiagram PartsList OperationalDescription Tune-upProcedure Inadditionaltoabovementioneddocuments,inordertocomplywiththemarketingregulations inTitle47CFR§2.803andtheimportationrulesinTitle47CFR§2.1204,whileensuringthat businesssensitiveinformationremainsconfidentialuntiltheactualmarketingofnewly authorizeddevices,werequestShortTermConfidentialityofthefollowingattachment(s); ExternalPhotos TestSetupPhotos InternalPhotos UserManual For45days,pursuanttoPublicNoticeDA04-1705. OR For180dayspursuanttoKDB726920D01. Itisourunderstandingthatallmeasurementtestreports,FCCIDlabelformatand correspondenceduringthecertificationreviewprocesscannotbegrantedasconfidential documentsandthisinformationwillbeavailableforpublicreviewoncethegrantofequipment authorizationisissued. Sincerely, Signature: Name:FangRuan Title:Manager

Model Name: TG-182,TG-116,TG-126,TG-143,TG-149,TG-157,TG-165C,TG-165,TG-183,TG-191,TG-227

2cm Model: TG-182 FCC ID: 2A86Y-TG-182 This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2)this device must accept any interference received, including interference that may causeundesired operation. Label Location 1cm

Model Name: TG-182,TG-116,TG-126,TG-143,TG-149,TG-157,TG-165C,TG-165,TG-183,TG-191,TG-227 TX ANT

FCC ID:2A86Y-TG-182 RF EXPOSURE EVALUATION METHOD SAR Test Exclusion Thresholds for 100 MHz – 6 GHz and ≤ 50 mm Approximate SAR Test Exclusion Power Thresholds at Selected Frequencies and Test Separation Distances are illustrated in the following Table. The 1-g and 10-g SAR test exclusion thresholds for 100 MHz to 6 GHz at test separation distances ≤ 50 mm are determined by: [(max. power of channel, including tune-up tolerance, mW)/(min. test separation distance, mm)] · [√f(GHz)] ≤ 3.0 for 1-g SAR and ≤ 7.5 for 10-g extremity SAR,where f(GHz) is the RF channel transmit frequency in GHz Power and distance are rounded to the nearest mW and mm before calculation The result is rounded to one decimal place for comparison The test exclusions are applicable only when the minimum test separation distance is ≤ 50 mm and for transmission frequencies between 100 MHz and 6 GHz. When the minimum test separation distance is < 5 mm, a distance of 5 mm is applied to determine SAR test exclusion. FCC ID:2A86Y-TG-182 For BT mode -- The max. field strength of fundamental frequency is 93.81 dBuv/m. EIRP[dBm] = E[dBμV/m] - 95.2 = 93.81 - 95.2 = -1.39dBm, conducted power = EIRP - ANT gain = -1.39 - (1.2) = -2.59 dBm. The max. tune-up level is -1.59dBm(0.693mw), MPE=0.693 mw / 5mm * √(2.402GHz) = 0.214 < 7.5 (extremity sar), sar exempt. Conclusion: No SAR is required.

Project No.:ZKT-240318L2622E Page 1 of 41 FCC TEST REPORT FCC ID:2A86Y-TG-182 Report Number. ................................ : ZKT-240318L2622E Date of Test ................................................. : Mar.12 to Mar. 25, 2024 Date of issue .................................... : Mar. 25, 2024 Total number of pages ...................... 41 Test Result ..................................... : PASS Testing Laboratory. ........................... : Shenzhen ZKT Technology Co., Ltd. Address .......................................... : 1/F, No. 101, Building B, No. 6, Tangwei Community Industrial Avenue, Fuhai Street, Bao'an District, Shenzhen, China Applicant's name ............................ : Shenzhen chengtai electronic and technology co.,LTD Address .......................................... : 6thFloor,BuildingC,QinyuIndustrialZone,Sanwei,Sanwei Community,Hangcheng Street,Baoan District,Shenzhen Manufacturer's name ..................... : Shenzhen chengtai electronic and technology co.,LTD Address .......................................... : 6thFloor,BuildingC,QinyuIndustrialZone,Sanwei,Sanwei Community,Hangcheng Street,Baoan District,Shenzhen Test specification: Standard ........................................... : FCC CFR Title 47 Part 15 Subpart C Section 15.249 ANSI C63.10:2013 Test procedure ................................. : / Non-standard test method ............. : N/A Test Report Form No. .................... : TRF-EL-111_V0 Test Report Form(s) Originator .... : ZKT Testing Master TRF .................................... : Dated: 2023-01-05 This device described above has been tested by ZKT, and the test results show that the equipment under test (EUT) is in compliance with the FCC requirements. And it is applicable only to the tested sample identified in the report. This report shall not be reproduced except in full, without the written approval of ZKT, this document may be altered or revised by ZKT, personal only, and shall be noted in the revision of the document. Product name ................................... : Portable Wireless Speaker,Bluetooth Speaker Trademark ...................................... : N/A Model/Type reference ...................... : TG-182,TG-116,TG-126,TG-143,TG-149,TG-157,TG-165C,TG-165, TG-183,TG-191,TG-227 Battery ............................................... DC 3.7V 1200mAh Ratings ............................................. : DC 5V from adapter, AC120V/60Hz for adapter or DC 3.7V from battery Project No.:ZKT-240318L2622E Page 2 of 41 Testing procedure and testing location: Testing Laboratory ..................................... : Shenzhen ZKT Technology Co., Ltd. Address ...................................................... : 1/F, No. 101, Building B, No. 6, Tangwei Community Industrial Avenue, Fuhai Street, Bao'an District, Shenzhen, China Alen He Tested by (name + signature) .................... : Joe Liu Reviewer (name + signature) ..................... : Lake Xie Approved (name + signature) .................... : Project No.:ZKT-240318L2622E Page 3 of 41 Table of Contents Page 1.VERSION 5 2 SUMMARY OF TEST RESULTS 6 2.1 TEST FACILITY 7 2.2 MEASUREMENT UNCERTAINTY 7 3. GENERAL INFORMATION 8 3.1 GENERAL DESCRIPTION OF EUT 8 3.2 DESCRIPTION OF TEST MODES 9 3.3 BLOCK DIGRAM SHOWING THE CONFIGURATION OF SYSTEM TESTED 10 3.4 DESCRIPTION OF SUPPORT UNITS(CONDUCTED MODE) 11 3.5 EQUIPMENTS LIST FOR ALL TEST ITEMS 12 4. EMC EMISSION TEST 13 4.1 CONDUCTED EMISSION MEASUREMENT 13 4.1.1 POWER LINE CONDUCTED EMISSION LIMITS 13 4.1.2 TEST PROCEDURE 13 4.1.3 DEVIATION FROM TEST STANDARD 13 4.1.4 TEST SETUP 14 4.1.5 EUT OPERATING CONDITIONS 14 4.1.6 TEST RESULTS 15 4.2 RADIATED EMISSION MEASUREMENT 17 4.2.1 RADIATED EMISSION LIMITS 17 4.2.2 TEST PROCEDURE 18 4.2.3 DEVIATION FROM TEST STANDARD 18 4.2.4 TEST SETUP 18 4.2.5 EUT OPERATING CONDITIONS 19 5. BANDWIDTH OF FREQUENCY BAND EDGE 30 5.1 TEST REQUIREMENT: 30 5.2 TEST PROCEDURE 30 5.3 DEVIATION FROM TEST STANDARD 30 5.4 TEST SETUP 30 5.5 EUT OPERATING CONDITIONS 31 5.6 TEST RESULT 32 6. CHANNEL BANDWIDTH 36 6.1 APPLIED PROCEDURES / LIMIT 36 6.2 TEST PROCEDURE 36 6.3 DEVIATION FROM STANDARD 36 6.4 TEST SETUP 36 Project No.:ZKT-240318L2622E Page 4 of 41 Table of Contents Page 6.5 EUT OPERATION CONDITIONS 36 6.6 TSET RESULTS 37 7.ANTENNA REQUIREMENT 40 8. TEST SETUP PHOTO 41 9. EUT CONSTRUCTIONAL DETAILS 41 Project No.:ZKT-240318L2622E Page 5 of 41 1.VERSION Report No. Version Description Approved ZKT-240318L2622E Rev.01 Initial issue of report Mar. 25, 2024 Project No.:ZKT-240318L2622E Page 6 of 41 2 SUMMARY OF TEST RESULTS Test procedures according to the technical standards: FCC Part15 (15.249) , Subpart C Standard Section Test Item Judgment Remark FCC part 15.203 Antenna requirement PASS FCC part 15.207 AC Power Line Conducted Emission PASS FCC part 15.249 Fundamental & Radiated Spurious Emission Measurement PASS FCC part 15.215 (c) 20dB Channel Bandwidth PASS FCC part 15.205 Band Edge PASS NOTE: (1)” N/A” denotes test is not applicable in this Test Report Project No.:ZKT-240318L2622E Page 7 of 41 2.1 TEST FACILITY Shenzhen ZKT Technology Co., Ltd. Add. : 1/F, No. 101, Building B, No. 6, Tangwei Community Industrial Avenue, Fuhai Street, Bao'an District, Shenzhe , China FCC Test Firm Registration Number: 692225 Designation Number: CN1299 IC Registered No.: 27033 2.2 MEASUREMENT UNCERTAINTY The reported uncertainty of measurement y ± U，where expended uncertainty U is based on a standard uncertainty multiplied by a coverage factor of k=2，providing a level of confidence of approximately 95 %。 No. Item Uncertainty 1 Conducted Emission Test ±1.38dB 2 RF power conducted ±0.16dB 3 Spurious emissions conducted ±0.21dB 4 All emissions radiated(<1G) ±4.68dB 5 All emissions radiated(>1G) ±4.89dB 6 Temperature ±0.5°C 7 Humidity ±2% Project No.:ZKT-240318L2622E Page 8 of 41 3. GENERAL INFORMATION 3.1 GENERAL DESCRIPTION OF EUT Product Name: Portable Wireless Speaker,Bluetooth Speaker Model No.: TG-182,T…

Text truncated - open the document above for the full version.

Product specification Quick Reference Date Antenna module on the system board Frequenc Range 2400 ~ 2500MHz Ant. Port Input Pwr. (dBm) 0 (Typ. BT class 2 output power) Tot. Rad. Pwr. (dBm) -1.2 (Input pwr – loss pwr) Peak EIRP(dBm) 1.2 Directivity (dBi) 1 (all direction antenna) Efficiency (dB) 6 0.2 % Gain (dBi) 1.2 (Avg Gain XY-plane) Maximum Power (dBm) 1.7 (XY-plane) Minimum Power (dBm) -4(XY-plane) Avg. Power (dBm) -0.5(XY-plane) Input Impendence(ohm) 50 Polarization Type V ertical & Horizontal V . S .W . R < 1.4 All the technical data and information contained herein are subject to change without prior notice Antenna Layout & module on the system board Antenna Gain Gain Table Unit in dBi @2.44GHz XY-plane XZ-plane YZ-plane Efficiency Peak Avg. Peak Avg. Peak Avg. Module Board 1.2 -0.5 1.9 -3.6 1.1 -3.0 6 0.2 % Retum Loss The Environment of Antenna Radiation Pattem 3D radiation pattern diagram XY-plane XZ-plane YZ-plane

Test Setup Photograph Radiated Emissions Test Setup Below 1G Above 1G Conduction Emissions Test Setup
