User Manual for HiBreak E-Ink Smartphone 1.Product Specifications Product Model Display Screen Display Size Host Dimensions Resolution DPI Display Front light Microphone Speaker Network Mobile Communication Bluetooth Connectivity Storage Capacity Camera GPS Location Gyroscope Operating System Charging Port Battery Capacity Product Weight Bigme HiBreak Color E-ink Display 5.84 inches 720 x 1440pX BW: 276, Color: 92 DPI 36-level Adjustable Front Light Dual Microphone Array Supported Bluetooth 5.0 Android 11 Open System 6GB RAM + 128GB ROM (Expandable up to 1TB) Dual Cameras (Front & Rear) Type-C 3300mAh ≈170g Supported Supported Supported 2.4G/5G WIFI + 4G Full Netcom 76.8 x 154 x 8.6mm 2.Physical Buttons Customizable Function key Power key Volume / Page-Turn key In the "Custom key" section of the "Settings ", you can customize the functions of key: 1.Single Tap: None, Return to Home, Back, Screenshot, Multi-task Switching, Clear Cache, Full refresh, E Ink Center, Previous Page, Next Page; 2.Long Press: None, Return to Home, Back, Screenshot, Multi-task Switching, Clear Cache, Full refresh, E Ink Center, Previous Page, Next Page. 3.Main Interface Operation 1.Slide inward from the edges of the screen to return to the previous page. 2.Slide upwards from the middle of the bottom edge of the screen to return to the Apps center . Gesture Control 3.Slide upwards from the left side of the bottom edge of the screen to view the apps running in the background. 4.Slide upwards from the right side of the bottom edge of the screen to perform a full-screen refresh. In the "Gesture Settings" section of the " Settings", you can customize gesture functions: 1.Slide upwards from the bottom to the left: None, Back Home Screen, Back, Screenshot, Multitasking Switcher, Clear Cache, Full Refresh, E Ink Center, Previous Page, Next Page. 2.Slide upwards from the bottom to the center: None, Back Home Screen, Back, Screenshot, Multitasking Switcher, Clear Cache, Full Refresh, E Ink Center, Previous Page, Next Page. 3.Slide upwards from the bottom to the right: None, Back Home Screen, Back, Screenshot, Multitasking Switcher, Clear Cache, Full Refresh, E Ink Center, Previous Page, Next Page. 1.By long-pressing an app icon on the desktop, you can drag and adjust the position of the app, edit the home screen, and manage app settings and uninstall apps. 2.After long-pressing an app icon on the desktop, select "Edit Screen" from the menu to enter the home screen editing page. Then tap the corner marker "-" in the upper left corner of the app to uninstall each app individually. Desktop App Management 4.Control Center Pulling down from the top-right corner of the screen can expand the Control Center for quick access to shortcuts such as turning on/off WiFi, mobile data, Bluetooth, and more. 5.E Ink Center Through the dropdown menu in the top-right corner of the screen, select "Eink Center". Here, we have preset various modes for you to choose from, including "Default", "Magazine", " Comic", and "Video". If you wish to personalize the settings according to your usage habits, you can also select the "Custom" mode. Through the drop-down menu in the upper right corner of the screen, select "Eink Center" - "App optimization". You can freely adjust the font size, turn on or off the text enhancement function, and adjust the icon color and background color. 6.Split Screen Application Select"Split Screen"through the drop-down menu in the upper right corner of the screen. You can adjust the different split-screen ratios, such as 1:1, 2:1, or 1:2, by sliding the dividing line in the middle of the screen. Split Screen 1 (1:1)Split Screen 2 (2:1) 7.Floating Ball Through the Floating Ball app on the home screen, you can customize settings, including turning the Floating Ball on or off, adjusting its size, and customizing button functions. 8.Bigme GPT 1.Intelligent chat function: You can ask it questions covering various aspects such as encyclopedia knowledge, professional field information, and current events news. 2.AI Creation: Simply input a creative theme, and it can automatically generate a creative outline and main text for you. 3.AI Painting: You only need to provide multiple specific key prompts and phrases to describe the image, and it can automatically generate the corresponding picture for you. 1.New: Click the "+" button at the bottom of the home page, and you can create text notes and voice notes. You can also import MP3 audio files with a size not exceeding 1GB and a duration not exceeding 5 hours for transcription 9.Bigme V2T(Voice to Text) . 2.Real-time voice-to-text transcription: This function supports the recognition of multiple domestic languages such as Mandarin, Tianjin dialect, Hebei dialect, Northeast dialect, Gansu dialect, Shandong dialect, Taiyuan dialect, etc., as well as multiple international languages such as English, Spanish, French, Japanese, Korean, Russian, etc. During real-time transcription, simply click the " Language" button in the upper right corner to easily switch languages. 10.Gallery 1.You can select one or multiple images to export as a PDF document and save it in the path of [Internal Storage/Documents/]. 2.When opening a single image for browsing, you can use the [OCR] function at the bottom to extract text from the image, and you can copy or export the text as a TXT document, which will be saved in the path of [Internal Storage/Pictures/OCR/]. 3.You can select an image as a screensaver. 11.Bookshelf 1.It supports multiple mainstream book formats, including PDF, TXT, EPUB, EPUB3, HTML, HTM, AZW, AZW3, FB2, DOC, DOCX, RTF, MOBI, OEB, and ZIP, among others. 2.By copying books to the Books directory, the local bookshelf will automatically scan and display your books. 3.Click "Import" - "Local Import" in the upper right corner of the bookshelf management page to manually import books from the Books or Download directories. 4.Click "Import" - "WiFi Import" in the upper right corner of the booksh…
