Portable Power Station PS151032 User Manual Disclaimer Before using this product, please read the user manual of this product carefully to ensure correct use after full understanding. Please keep this manual properly after reading it. Incorrect handling of this product may cause serious injury to you or others, or damage to the product and damage to property. Once you use this product, you are deemed to have understood and accepted all the terms and contents of this user manual. Users promise to be responsible for their actions and all the consequences arising therefrom. Our company will not bear all losses caused by users' failure to use products according to the User Manual. According to laws and regulations, the Company has the right of final interpretation of this user manual and all materials related to this product. Please visit the official DEENO website for the latest product information if the material is updated, the version is changed or the service is terminated without prior notice. Directory Safety guidelines 01 Parameter specification 02 Getting Started 03 1. Product details 2. Display icon descriptions 3. Product instructions 4. Product charging instructions 5. Buzzer sound canceled/restored 03 04 05 07 09 Fault display and treatment 10 Frequently Asked Questions 11 Product maintenance and maintenance 12 Product warranty card 12 1 Please follow the following instructions to ensure safe use: 1. Do not put your finger into the bottom of the handle when the handle is pulled up to avoid injury. 2. It is strictly forbidden to keep this product close to heat source, such as fire source or heating furnace. 3. It is strictly forbidden to let this product contact with any liquid. Do not immerse this product in water or wet it. Never use this product in rain or humid environment. 4. It is forbidden to use this product in strong static electricity or strong magnetic field environment. 5. It is forbidden to disassemble or puncture this product with sharp objects in any way. 6. It is forbidden to use wires or other metal objects to cause short circuit of this product. 7. Do not use unofficially provided chargers or accessories. If you need to replace it, please inquire about the relevant purchase information through DEENO's official sales channel. 8. When using this product, please strictly follow the use environment temperature in this user manual. 9. Do not move this product during charging or use, which may lead to poor contact of input/output interface. 10. It is forbidden to pile other heavy objects on this product. 11. It is forbidden to block the fan forcibly during use, block the inlet and outlet of the fan, or leave the product in an unventilated or dusty space. 12. Please avoid impact, fall and violent vibration. In case of severe external force impact, please turn off the power supply immediately and stop using it. Please fix it properly during transportation to avoid vibration and impact. 13. In case of fire, dry powder and carbon dioxide fire extinguisher should be used for this product, and water should not be used to extinguish the fire. 14. If there is dirt on the interface of this product, please wipe it clean with a dry cloth. 15. Please place this product carefully to prevent damage caused by dumping. If the product is dumped and seriously damaged, please shut down immediately, place the battery in an open area, away from combustibles and people, and scrap it according to local laws and regulations. 16. Keep this product out of reach of children and pets. 17. This product contains batteries, which are dangerous chemicals. It is strictly forbidden to dispose of them in ordinary garbage bins. For details, please follow the local laws and regulations on battery recycling and disposal. Safety fingerCite 2 Parameter specification Battery specification Capacity 1036Wh (28.8 V 36Ah) Battery type LiFePO4 (lithium iron phosphate) Cycle life The remaining capacity after 3500 times is ≥ 80% Enter specifications Adapter input 24V 200W Max Car charge input 12V 8A/24V 8A 196W Max Solar energy input 12-32V 8A 200W Max Adapter charging time 5-6 hours (0-100%) Vehicle charging time 12V 10-12 hrs/24V 5-6 hrs (0-100%) Solar charging time 6-10 hours (0-100%) * The above data are from DEENO Laboratory and are for reference only. Please note that the charging time will vary due to factors such as use environment and test method. Output specification AC output x 3 120V ~ 50Hz/60Hz continuous 1500W (peak 3000W) pure sine wave USB-A Fast Charge x 3 Outputs 5V 3A, 9V 2A, 12V 1.5 A 18W Max each USB-C Output x 2 Outputs 5V/9V/12V/15V 3A, 20V 5A 100W Max each Car Charge Output x 1 12V 10A 120W Max DC5.5*2. 5 Output x 1 24V 5A 120W Max DC5.5*2. 1 Output x 1 12V 5A 120W Max LED Illumination 12W (Low-Medium-High-SOS) Operating temperature Optimum operating/storage ambient temperature 20 °C ~ 30 °C (68 °C ~ 86 °C) Discharge ambient temperature -20 °C ~ 45 °C (-4 °C ~ 113 °C) Charging ambient temperature 0 °C ~ 45 °C (32 °C ~ 113 °C) Storage ambient temperature -20 °C ~ 45 °C (-4 °C ~ 113 °C) * Whether this product can be charged or discharged depends on the actual temperature of the battery pack rather than the ambient temperature. Other specifications Net weight 14.8 KG (32.6 lbs) Dimensions L393*W227*H239mm Certification standard UN 38.3, PSE, CE, ROHS, REACH, FCC Packaging content Product body, adapter, MC4-DC7.9*0. 9 charging line, car charging head-DC7.9*0. 9 charging line, instruction manual (including warranty card), accessory bag 4 1. Battery charge indication: When charging, the icon rotates clockwise. 2. Charging status indication: When charging status, the icon is always on. 3. Percentage of battery power: Percentage of current remaining power. 4. Low temperature alarm: When the battery temperature is lower than 0 °C (32 °C) when charging or lower than-20 °C (-4 °C) when discharging, the product is prohibited from charging/discharging, and this icon is always on. Please put the product i…

Text truncated - open the document above for the full version.

ShenZhenShiDiNengKeJiYouXianGongSi 1/1 Letter of Authorization Company: ShenZhenShiDiNengKeJiYouXianGongSi Address: ShenZhenShiNanShanQuXiLiJieDaoYangGuangSheQuSongBaiLu1008HaoGangHongJi GaoXinZhiNengChanYeYuanADong202 Product Name: Power Station Model Number: PS151032 FCC Identifier: 2A8F6-PS151032 We authorize LGAI Technological Center S.A., Ronda de la Font del Carme, s/n, 08193 Bellaterra, Spain, to act on our behalf on all matters concerning the above named equipment. Any individual within LGAI Technological Center S.A. is authorized to act on our behalf and take action on the application. We declare that authorize LGAI Technological Center S.A., Ronda de la Font del Carme, s/n, 08193 Bellaterra, Spain, is allowed to forward all information related to the approval project to the Federal Communication Commission and to discuss any issues concerning the approval application. Any and all acts carried out by LGAI Technological Center S.A. on our behalf shall have the same effect as acts of our own. Name: jadeyang Date: 2022-08-23 Title: Manager Signature of applicant:

ShenZhenShiDiNengKeJiYouXianGongSi 1/1 Office of Engineering Technology Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 Date: 2022-08-23 Subject: Request for Confidentiality FCC ID: 2A8F6-PS151032 To Whom It May Concern, Pursuant to the provisions of Sections 0.457 and 0.459 of Commission's rules (47CFR0.457, 0.459), we are requesting the Commission to withhold the following attachment(s) as confidential document from public disclosure. Exhibits Long-Term Confidentiality Short-Term Confidentiality NOTE 2 ID Label/Location No No Attestation Statement No No External Photos No ☐ Block Diagram ☒ ☐ Schematics ☒ ☐ Test Report No No Test Setup Photos No ☐ User’s Manual No ☐ Internal Photos No ☐ Parts List / Tune Up ☐ ☐ RF Exposure Info No No Operational Description ☒ ☐ Cover Letter(s) No No SDR Software / Security Info ☐ No NOTE 1: Long-Term Confidentiality may be permitted under special conditions (See II. LONG-TERM CONFIDENTIALITY, Section 3 of KDB 726920, use last in force) NOTE 2: Short-Term Confidentiality can be requested for a maximum of 180 days from the date of the grant. Above mentioned document contains detailed system and equipment description are considered as proprietary information in operation of the equipment. The public disclosure of above documents might be harmful to our company and would give competitor an unfair advantage in the market. It is our understanding that all measurement test reports, FCC ID label format and correspondent during certification review process cannot be granted as confidential documents and those information will be available for public review once the grant of equipment authorization is issued. Sincerely, Signature: Name: jadeyang Title: Manager

Size:24*20mm M/N: PS151032 FCC ID: 2A8F6-PS151032 Label location

ANT

FCC ID: 2A8F6-PS151032 Product Name: Power Station Product Model No.: PS151032 Transmitting mode Keep the EUT in continuously wireless charging mode Power supply: Input: DC 28.8V from battery Wireless Output: 15W(MAX) Date of Receipt: Jul. 29, 2022 Test Date: Jul. 29, 2022 – Aug. 17, 2022 Date of Report: Aug. 17, 2022 Test Modes: Mode 1 Phone Charge Mode Note: We have evaluated 1%, 50% and 99% battery charging mode, and the worst mode (99%) is showed in this report. RF Exposure Evaluation 1 Measuring Standard KDB 680106 RF Exposure Wireless Charging Apps v03r01 2 Requirements According to the item 5 of KDB 680106 v03r01: Inductive wireless power transfer applications that meet all of the following requirements are excluded from submitting an RF exposure evaluation. (1) Power transfer frequency is less than 1MHz. Yes; the device operate in the frequency range from 115 KHz to 205 KHz (2) Output power from each primary coil is less than or equal to 15 watts. Yes; the maximum output power of the primary coil is 15W. (3) The system may consist of more than one source primary coils, charging one or more clients. If more than one primary coil is present, the coil pairs may be powered on at the same time. Yes; the transfer system includes only single primary coils. (4) Client device is placed directly in contact with the transmitter. Yes; Client device is placed directly in contact with the transmitter. (5) Mobile exposure conditions only (portable exposure conditions are not covered by this exclusion). Yes, mobile exposure conditions only. (6) The aggregate H-field strengths anywhere at or beyond 15 cm surrounding the device, and 20 cm away Yes, see test result in item 6. from the surface from all coils that by design can simultaneously transmit, and while those coils are simultaneously energized, are demonstrated to be less than 50% of the applicable MPE limit. Remark: Meet all the above requirements. Limits The criteria listed in the following table shall be used to evaluate the environment impact of human exposure to radio frequency (RF) radiation as specified in 1.1307(b) Limits for Maximum Permissible Exposure (MPE) 3 Test Setup 4 Test Procedure 1) The RF exposure test was performed in anechoic chamber. 2) The measurement probe was placed at test distance (15 cm from all sides and 20 cm from the top) which is between the edge of the charger and the geometric center of probe. 3) The highest emission level was recorded and compared with limit as soon as measurement of each points (A, B, C, D, E) were completed. 4) The EUT was measured according to the dictates of KDB 680106 v03r01. Remark：The EUT’s test position A, B, C, D and E is valid for the E and H field measurements. 5 Description of Support Units Mobile phone (Provide by test lab): Manufacturer: SAMSUNG Model: Galaxy S21 5G 6 Test Instruments list Test Equipment Manufacturer Model No. SN. Cal.Date (mm-dd-yy) Cal.Due date (mm-dd-yy) Exposure Level Tester Narda ELT-400 N-0231 June. 25 2022 June. 26 2023 Magnetic field probe 100cm 2 Narda ELT probe 100cm 2 M0675 June. 25 2022 June. 26 2023 Field Probe ETS HI-6105 / June. 25 2022 June. 26 2023 Laser Data Interface ETS HI-6113 / June. 25 2022 June. 26 2023 7 Test Result DC 28.8V E-Filed Strength at 15 cm from the edges surrounding the EUT (V/m) Frequency Range (MHz) Test Position A Test Position B Test Position C Test Position D Limits (V/m) 0.115-0.205 0.14 0.16 0.13 0.11 614 E-Filed Strength at 20 cm from the top of the EUT (V/m) Frequency Range (MHz) Test Position E Limits (V/m) 0.115-0.205 0.13 614 H-Filed Strength at 15 cm from the edges surrounding the EUT (A/m) Frequency Range (MHz) Test Position A Test Position B Test Position C Test Position D Limits (A/m) 0.115-0.205 0.05 0.13 0.02 0.14 1.63 H-Filed Strength at 20 cm from the top of the EUT (A/m) Frequency Range (MHz) Test Position E Limits (A/m) 0.115-0.205 0.13 1.63 AC 120V/60Hz E-Filed Strength at 15 cm from the edges surrounding the EUT (V/m) Frequency Range (MHz) Test Position A Test Position B Test Position C Test Position D Limits (V/m) 0.115-0.205 0.16 0.14 0.15 0.12 614 E-Filed Strength at 20 cm from the top of the EUT (V/m) Frequency Range (MHz) Test Position E Limits (V/m) 0.115-0.205 0.16 614 H-Filed Strength at 15 cm from the edges surrounding the EUT (A/m) Frequency Range (MHz) Test Position A Test Position B Test Position C Test Position D Limits (A/m) 0.115-0.205 0.03 0.14 0.05 0.16 1.63 H-Filed Strength at 20 cm from the top of the EUT (A/m) Frequency Range (MHz) Test Position E Limits (A/m) 0.115-0.205 0.15 1.63 8 Test Set-up Photo Please see annex test setup photos.

Shenzhen DL Testing Technology Co., Ltd. Report No.: DL-20220817031E Test ReportTel: 400-688-3552Web:www.dl-cert.comEmail: [email protected] Page 1 of 19 TEST REPORT FCC ID: 2A8F6-PS151032 Applicant: ShenZhenShiDiNengKeJiYouXianGongSi Address: ShenZhenShiNanShanQuXiLiJieDaoYangGuangSheQuSongBaiLu1008HaoGangHongJi GaoXinZhiNengChanYeYuanADong202 Manufacturer: ShenZhenShiDiNengKeJiYouXianGongSi Address: ShenZhenShiNanShanQuXiLiJieDaoYangGuangSheQuSongBaiLu1008HaoGangHongJi GaoXinZhiNengChanYeYuanADong202 EUT: power station Trade Mark: CHASING Model Number: PS151032 Date of Receipt: Jul. 29, 2022 Test Date: Jul. 29, 2022 – Aug. 17, 2022 Date of Report: Aug. 17, 2022 Prepared By: Shenzhen DL Testing Technology Co., Ltd. Address: 101-201, Building C, Shuanghuan, No.8, Baoqing Road, Baolong Industrial Zone, Baolong Street, Longgang District, Shenzhen, Guangdong, China Applicable Standards: FCC PART 15 Subpart C ANSI C63.10:2013 Test Result: Pass Report Number: DL-20220817031E Prepared (Engineer): Lily Fu Reviewer (Supervisor): Jack Bu Approved (Manager): Jade Yang This test report is based on a single evaluation of one sample of above mentioned products. It is not permitted to be duplicated in extracts without written approval of Shenzhen DL Testing Technology Co., Ltd. Shenzhen DL Testing Technology Co., Ltd. Report No.: DL-20220817031E Test Report Tel: 400-688-3552 Web:www.dl-cert.com Email: [email protected] Page 2 of 19 TABLE OF CONTENT Test Report Declaration Page 1. VERSION ................................................................................................................................................. 3 2. TEST SUMMARY ..................................................................................................................................... 3 3. GENERAL INFORMATION ..................................................................................................................... 4 4. TEST INSTRUMENT USED ..................................................................................................................... 5 5. CONDUCTED EMISSION TEST .............................................................................................................. 6 6. RADIATION EMISSION TEST ............................................................................................................... 10 7. BANDWIDTH TEST ............................................................................................................................... 18 8. SETUP PHOTOGRAPHS ...................................................................................................................... 19 9. EUT PHOTOGRAPHS ........................................................................................................................... 19 Shenzhen DL Testing Technology Co., Ltd. Report No.: DL-20220817031E Test Report Tel: 400-688-3552 Web:www.dl-cert.com Email: [email protected] Page 3 of 19 1. VERSION Version No. Date Description 00 Aug. 17, 2022 Original 2. TEST SUMMARY EMC Emission Test Item Section in CFR 47 Result Remark AC Power Line Conducted Emission 15.207 PASS Spurious Emission 15.209(a)(f) PASS 20dB Bandwidth 15.215 PASS Antenna requirement 15.203 PASS NOTE: (1)” N/A” denotes test is not applicable in this Test Report (2) Test Facility: Shenzhen DL Testing Technology Co., Ltd. Address: 101-201, Building C, Shuanghuan, No.8, Baoqing Road, Baolong Industrial Zone, Baolong Street, Longgang District, Shenzhen, Guangdong, China Shenzhen DL Testing Technology Co., Ltd. Report No.: DL-20220817031E Test Report Tel: 400-688-3552 Web:www.dl-cert.com Email: [email protected] Page 4 of 19 3. GENERAL INFORMATION 3.1 Description of Device (EUT) Product Name: power station Trade Mark: CHASING Model No.: PS151032 Model Difference: N/A Serial No.: N/A Hardware version: H1.0 Software version: S1.0 Operation Frequency: 115kHz ~ 205KHz Modulation type: MSK Antenna Type: Inductive loop coil Antenna Antenna gain: 0dBi Power supply: Input: DC 28.8V from battery Wireless Output: 15W(MAX) Adapter1: Model No.: PSY2528000 Input: 100-240V~ 50/60Hz 3.0A Output: DC 25.2V/8.0A 201.6W Adapter2: Model No.: YHY-24010000 Input: 100-240V~ 50/60Hz 4.0A Output: DC 24V/10A 3.2 Tested System Details None. 3.3 Block Diagram of Test Set-up 3.4 Test Mode Description Mode1. Wireless Charge Mode Note: We have evaluated 1%, 50% and 99% battery charging mode, and the worst mode (99%) is showed in this report. 3.5 Test Auxiliary Equipment Mobile phone (Provide by test lab): Manufacturer: SAMSUNG Model: Galaxy S21 5G 3.6 Test Uncertainty Conducted Emission Uncertainty(150KHz-30MHz) : ±2.56dB Radiated Emission Uncertainty(9KHz-1GHz) : ±3.24dB AC Mains EUT Adapter Shenzhen DL Testing Technology Co., Ltd. Report No.: DL-20220817031E Test Report Tel: 400-688-3552 Web:www.dl-cert.com Email: [email protected] Page 5 of 19 4. TEST INSTRUMENT USED For Conducted Emission Test (843 Shielded Room) Equipment Manufacturer Model Serial Last Cal. Next Cal. 843 Shielded Room ChengYu 843 Room 843 Nov. 25, 2019 Nov. 24, 2022 EMI Receiver R&S ESR 101421 Dec. 07, 2021 Dec. 06, 2022 LISN R&S ENV216 102417 Dec. 07, 2021 Dec. 06, 2022 Clamp COM-POWER CLA-050 431071 Dec. 05, 2021 Dec. 04, 2022 3-Loop Antenna DAZE ZN30401 13021 Dec. 07, 2021 Dec. 06, 2022 ISN T8 Schwarzbeck NTFM 8158 101135 Dec. 07, 2021 Dec. 06, 2022 ISN T5 Schwarzbeck NTFM 8158 101136 Dec. 07, 2021 Dec. 06, 2022 843 Cable 1# ChengYu CE Cable 001 Dec. 07, 2021 Dec. 06, 2022 843 Cable 1# ChengYu CE Cable 002 Dec. 07, 2021 Dec. 06, 2022 For Radiated Emission Test (966 chamber) Equipment Manufacturer Model Serial Last Cal. Next Cal. 966 Chamber ChengYu 966 Room 966 Nov. 25, 2019 Nov. 24, 2022 Spectrum Analyzer Agilent E4408B MY50140780 Dec. 07, 2021 Dec. 06, 2022 EMI Receiver R&S ESRP7 101393 Dec. 07, 2021 Dec. 06, 2022 Amplifier Schwarzbeck BBV9743B 00153 Dec. 07, 2021 Dec. 06, 2022 Amplifier EMEC EM01G8GA 00270 Dec. 07, 2021 Dec. 06, 2022 Broadband Trilog…

Text truncated - open the document above for the full version.

Fine Page 1 of 3 承 認 書 SPECIFICATION FOR APPROVAL 客 戶： CUSTOMER: 深圳潜行创新科技有限公司 Shenzhen Sneak Innovation Technology Co., Ltd. 客 戶 料 號： CUST P/N: A28三线圈 松 岛 料 號： FINE P/N: A28三线圈 産 品 型 號： DESC: F19.5x27-9Ts-3coil-0.08x105-20mm 日 期： DATE: 2022/8/26 版 本： Version: A.0 擬制 PREPARED BY 審核 CHECKED BY 批准 APPROVED BY 客戶承認 CUSTOMER APPROVE 黄燕铭 宁元安 黄锦华 Fine Page 2 of 3 版本變更履歷 Version Change History 版本 Rev. 變 更 前 Before Change 變 更 後 After Change 更 改 日 期 Change Date 批 准 Approved By A.0 新发行 ---- 2018/03/16 黄锦华 Fine Page 3 of 3 SPECIFICATION 産 品 型 號： DESC F19.5x27-9Ts-10coil-0.08x105-20mm 版本 Rev：A.0 客戶CUST: 松岛料号 Fine P/N： DD4752 客户料号CUST P/N: triple coil 一、尺寸DIMENSION:(mm) 二、原理图SCHEMATIC DIAGRAM: A 93.0±1.5 B 52.0±0.5 C 20±2 D 42.5±0.5 E 17.5±1 F 26.5±0.5 G 20±2.0 K 3±2.0 Note: 1. The size of a single magnetic sheet is F46.5*52.0mm and the thickness is 0.8mm. It is bonded with double-sided tape and has a hand tearing position; 2. Wrap 8mm wide high temperature adhesive tape for 1-2Ts at the outlet position of the upper coil; 三、绕线参数Winding Specification: 序号 NO. 端子 TERMINAL 线径 WIRE 圈数 Turns 绕线方向 Winding Direction 1 S F 丝包线0.08*105P 9Ts CCW 2 S F 丝包线0.08*105P 9Ts CCW 四、电气特性ELECTRICAL CHARACTERISTICS: 温度TEMPERATURE:25±10°C, 湿度RELATIVE HUMIDITY:65±20% 序号 NO. 项目 ITEM 端子 TERMINAL 标准 SPECIFICATION 测试条件 TEST FREQUENCY 测试仪器 TEST EQUIPMENTS 1 IND. S-F 6.8uH±10% 上线圈 100KHz/1.0V LCZ METER 1062B 2 IND. S-F 6.8uH±10% 下线圈 100KHz/1.0V LCZ METER 1062B 3 DCR S-F ≤45mΩ 100KHz/1.0V LCZ METER 1062B 4 Q S-F ≥60 100KHz/1.0V LCZ METER 1062B 擬制/日期PREPARED BY/DATE 審核/日期CHECKED BY/DATE 黄燕铭2022/8/26 黄锦华2022/8/26
