2A8HX-BLE520-ABLE Module

2019 BLE520-A User Manual BLUETOOTH LOW ENERGY MODULE BASED ON NRF52832 Wuxi Ghostyu Electronics Co,.Ltd Description BLE520-A is a low-power, high-performance BLE module based on nRF52832. It supports Bluetooth 5.4 and is specially designed for IoT applications. It has a small size and excellent RF performance. It is very suitable for consumer smart items, IoT devices, embedded integrated Bluetooth function, using intelligent mobile terminal to realize data transmission and control. •Support Bluetooth low energy 5.4 protocol stack •2Mbps Bluetooth connection speed •512KB Flash + 256KB RAM for most applications •Up to 1.05dBm transmit power •Comes with 128-bit AES hardware encryption This document can help users quickly understand the interface definition, electrical performance, and structural dimensions of the BLE520-A module. Combined with this document and other application documents of the BLE520-A module, users can smoothly embed the module into various terminal designs. Product Appearance Basic parameters Type Content Working frequency 2402-2480MHz transmit power 1dBm Receive sensitivity Receive sensitivity up to -96dBm transmit current Instantaneous 5mA@0dBm receive current Instantaneous 5mA Antenna type On board PCB Antenna Operating Voltage 1.7V~3.6V Lowest power consumption 0.3uA (chip sleep) chip memory NRF52832-QFAA Flash：512Kb RAM：64Kb Operating temperature -40°C~+85°C Module size 18mm*26mm *2mm Dimensions and Footprint The appearance size of BLE520-A is 18mm*26mm*2mm (error ±0.2mm). The recommended package is shown in the figure below (top view, the chip is on the front side). The pin signal description is as follows: Module Signal Description No pin name direction Function Description 1 GND - Power ground 2 NC Not Connect 3 NC Not Connect 4 P0.25 two-way General IO 5 P0.26 two-way General IO 6 P0.27 two-way General IO 7 P0.28/A4 two-way General IO; Analog Input 4 8 P0.29/A5 two-way General IO; Analog Input 5 9 P0.30/A6 two-way General IO; Analog Input 6 10 P0.31/A7 two-way General IO; Analog Input 7 11 P0.00/NC Not Connect 12 P0.01/NC Not Connect 13 P0.02/A0 two-way General IO; Analog Input 0 14 P0.03/A1 two-way General IO; Analog Input 1 15 P0.04/A2 two-way General IO; Analog Input 2 16 P0.05/A3 two-way General IO; Analog Input 3 17 P0.06 two-way General IO 18 P0.07 two-way General IO 19 P0.08 two-way General IO 20 P0.09 two-way General IO; NFC antenna pin NFC1 21 P0.10 two-way General IO; NFC antenna pin NFC1 22 P0.11 two-way General IO 23 P0.12 two-way General IO BLE520-A (nRF52832) 24 P0.13 two-way General IO 25 P0.14 two-way General IO 26 P0.21/RESET two-way General IO; Reset pin 27 GND - Power ground 28 VCC - Power input, voltage range: 1.7V~3.6V 29 P0.15 two-way General IO 30 P0.16 two-way General IO 31 P0.17 two-way General IO 32 P0.18 two-way General IO 33 P0.19 two-way General IO 34 P0.20 two-way General IO 35 SWCLK input SWD programming interface, SWCLK signal 36 SWDIO two-way SWD programming interface, SWDIO signal 37 P0.22 two-way General IO 38 P0.23 two-way General IO 39 P0.24 two-way General IO 40 GND - Power ground Hardware Reference Designs Power Interface Power input range: 1.7V~3.6V, the typical voltage is 3.3V, the power supply capacity is required to be at least 50mA, and the power supply ripple is required to be low, the VCC pin is reserved for filter capacitors, 1uF+100nF+100pF is recommended, if the application The environment is relatively harsh, often subject to ESD interference or high EMC requirements. It is recommended to connect magnetic beads in series and TVS tubes in parallel to increase the module's stability. Reset function Reset is a hardware reset pin, used for module reset, active low, pull low for at least 200ms, and then pull high or suspend to reset. The reset circuit has been set inside the module, because no external reset is required, the internal reset circuit is shown in the following figure: UART serial port The level of the serial port changes with the change of the input voltage of the module. The recommended VCC voltage is 3.3V. If the module is powered by 3.3V, the serial port TXD and RXD can be directly connected to the 3.3V MCU serial port (the module TXD is connected to the MCU RX, the module RXD connected to the TX of the MCU). When the module level does not match the MCU level, such as the Arduino serial port 5V, adding a level conversion circuit between the module serial port and the Arduino serial port is recommended. There are two ways: Using level conversion chip Use an MOS tube circuit. The recommended circuit of the level conversion chip is as follows. The chip model used is TI's TXS0102DCUR, two-way communication (without direction control), only need to pay attention that VCCA is smaller than VCCB. The MOS tube level conversion circuit uses the N-MOS model 2N7002, which supports two- way communication and is extremely low cost. (Yes, you read that right; the circuits of TXD and RXD are precisely the same, so there is no need to switch directions). Restore factory parameters Reload is the pin for restoring the factory settings. Low level is active. Pulling Reload low for at least 5 seconds will restore the module to the factory state. Indicator light interface The LED pin is active low and can be connected to a light-emitting diode to indicate the current working status of the module. The recommended circuit is shown in the figure below (if VCC is lower than 3V, it is recommended to add a triode driver, but the pull-down of the LED pin is prohibited). Connect an indicator light in series between the LED pin of the module and the power supply VCC. The status of the indicators is as follows: state light status When the module is powered on On for 1 second and then off When the broadcast is off extinguished When the broadcast is on Alternate flashing, cycle 1s, on for 200ms; When there is no data connected Heartbeat flashing, cycle 2s, bright 20ms; When there is data connected High-frequency flicker, cycle 200s, b…

Text truncated - open the document above for the full version.

CFR 47 §2.911(d)(7) U.S Agent U.S. AGENT LETTER OF ATTESTATION Date: 2023-08-29 FEDERAL COMMUNICATIONS COMMISSION Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046 Ref: Attestation Statements CFR 47 §2.911(d)(7) Filing FCC ID: 2A8HX-BLE520-A Wuxi Ghostyu Electronics Co,.Ltd (“the Applicant”) certifies that, as of the date of the filing of the application, Iconsigh Inc. (U.S. agent). is our designated U.S. agent for service of process for the above referenced FCC ID. Wuxi Ghostyu Electronics Co,.Ltd (“the Applicant”)accepts to maintain an agent for no less than one year after the grantee has terminated all marketing and importation or the conclusion of any Commission-related proceeding involving the equipment. Iconsigh Inc. accepts, as of the date of the filing of the application, the obligation of the designated U.S. agent for service of process for the above referenced FCC ID. Designated U.S. Agent Information: Company Name: Iconsigh Inc. Address: 2310 Homestead Road, Suite C1, Los Altos, CA, 94024, USA FRN: 0033398652 Tel.: +1 (408) 320-9867 Email: [email protected] Signed by (printed name): Benjamin Kaur Signature: Applicant: Wuxi Ghostyu Electronics Co,.Ltd Add: 205 Laboratory Building, No.258 Zhongnan Road, Liangxi District,Wuxi city,Jiangsu Province,China FRN: 0032800930 Tel: (0510) 83486610 Email: [email protected] Signed by (printed name): Yu Liu Signature:

Company Name: Wuxi Ghostyu Electronics Co,.Ltd Add: 205 Laboratory Building, No.258 Zhongnan Road, Liangxi District,Wuxi city,Jiangsu Province,China Tel: (0510) 83486610 Fax: N/A E- mail: [email protected] Attestation Letter Date: 2023-08-29 FEDERAL COMMUNICATIONS COMMISSIONS Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046 We , Wuxi Ghostyu Electronics Co,.Ltd, hereby authorize CHINA CERTIFICATION ICT CO., LTD (DONGGUAN) to act as a laboratory for testing and test report generation for the following project(s): (P roduct name: BLE Module, Model number: BLE520-A, FCC ID: 2A8HX-BLE520-A) The chip nRF52832 support the 2.4 GHz/BLE/NFC/ANT function, but for this device, Only BLE is used, other function is shielded by software. They cannot be used by any end user. Please contact me if there is need for any additional clarification or information. Sincerely, Signature Contact Person: Yu Liu Title: CEO CFR 47 §2.911(d)(5)(i)(ii) Attestation Letter

THIS MUST BE SIGNED BY THE APPLICANT/AGENT AND SHOULD BE PLACED ON APPROPRIATE LETTERHEAD Request for Modular/Limited Modular Approval Date: October 13, 2023 Subject: Manufacturer’s Declaration for ☒ - Modular Approval ☐ - Split Modular Approval ☐ - Limited Modular Approval ☐ - Limited Split Modular Approval Confidentiality Request for: ______( FCC ID:2A8HX-BLE520-A)______ 8 Basic Requirements – FCC Part 15.212(a)(1) For Items Marked “NO(*)”, the Limited Module Description Must be Filled Out on the Following Pages Modular Approval Requirement Requirement Met 1. The modular transmitter must have its own RF shielding. This is intended to ensure that the module does not have to rely upon the shielding provided by the device into which it is installed in order for all modular transmitter emissions to comply with FCC limits. It is also intended to prevent coupling between the RF circuitry of the module and any wires or circuits in the device into which the module is installed. Such coupling may result in non-compliant operation. The physical crystal and tuning capacitors may be located external to the shielded radio elements. 15.212(a)(1)(i) ☒ - YES ☐ - NO(*) Details: <example – The module contains a metal shield which covers all RF components and circuitry. The shield is located on the top of the board next to antenna connector> 2. The modular transmitter must have buffered modulation/data inputs (if such inputs are provided) to ensure that the module will comply with FCC requirements under conditions of excessive data rates or over-modulation. 15.212(a)(1)(ii) ☒ - YES ☐ - NO(*) Details: <example – Data to the modulation circuit is buffered as described in the operational description provided with the application> 3. The modular transmitter must have its own power supply regulation on the module. This is intended to ensure that the module will comply with FCC requirements regardless of the design of the power supplying circuitry in the device into which the module is installed. 15.212(a)(1)(iii) ☒ - YES ☐ - NO(*) Details: <example – The module contains its own power supply regulation. Please refer to schematic filed with this application> 4. The modular transmitter must comply with the antenna and transmission system requirements of §§ 15.203, 15.204(b), 15.204(c), 15.212(a), and 2.929(b). The antenna must either be permanently attached or employ a ‘‘unique’’ antenna coupler (at all connections between the module and the antenna, including the cable). The ‘‘professional installation’’ provision of § 15.203 is not applicable to modules but can apply to limited modular approvals under paragraph 15.212(b). 15.212(a)(1)(iv) ☒ - YES ☐ - NO(*) Details: <example – The module connects to its antenna using an UFL connector which is considered a non-standard connector. A list of antennas tested and approved with this device may be found in users manual provided with the application> 5. The modular transmitter must be tested in a stand-alone configuration, i.e., the module must not be inside another device during testing. This is intended to demonstrate that the module is capable of complying with Part 15 emission limits regardless of the device into which it is eventually installed. Unless the transmitter module will be battery powered, it must comply with the AC line conducted requirements found in Section 15.207. AC or DC power lines and data input/output lines connected to the module must not contain ferrites, unless they will be marketed with the module (see Section 15.27(a)). The length of these lines shall be length typical of actual use or, if that length is unknown, at least 10 centimeters to insure that there is no coupling between the case of the module and supporting equipment. Any accessories, peripherals, or support equipment connected to the module during testing shall be unmodified or commercially available (see Section 15.31(i)). 15.212(a)(1)(v) ☒ - YES ☐ - NO(*) Details: <example – The module was tested stand-alone as shown in test setup photographs filed with this application> THIS MUST BE SIGNED BY THE APPLICANT/AGENT AND SHOULD BE PLACED ON APPROPRIATE LETTERHEAD Modular Approval Requirement Requirement Met 6. The modular transmitter must be labeled with its own FCC ID number, or use an electron display (see KDB Publication 784748). If using a permanently affixed label with its own FCC ID number, if the FCC ID is not visible when the module is installed inside another device, then the outside of the device into which the module is installed must also display a label referring to the enclosed module. This exterior label can use wording such as the following: “Contains Transmitter Module FCC ID: XYZMODEL1” or “Contains FCC ID: XYZMODEL1.” Any similar wording that expresses the same meaning may be used. The Grantee may either provide such a label, an example of which must be included in the application for equipment authorization, or, must provide adequate instructions along with the module which explain this requirement. In the latter case, a copy of these instructions must be included in the application for equipment authorization. If the modular transmitter uses an electronic display of the FCC identification number, the information must be readily accessible and visible on the modular transmitter or on the device in which it is installed. If the module is installed inside another device, then the outside of the device into which the module is installed must display a label referring to the enclosed module. This exterior label can use wording such as the following: “Contains FCC certified transmitter module(s).” Any similar wording that expresses the same meaning may be used. The user manual must include instructions on how to access the electronic display. A copy of these instructions must be included in the application for equipment authorization. 15.212(a)(1)(vi) ☒ - YES ☐ - NO(*) Details: <example – There is a label on the module as shown in the labeling exhibit filed with this…

Text truncated - open the document above for the full version.

China Certification ICT Co., Ltd (Dongguan) Report No.: CR22080009-EXP EUT EXTERNAL PHOTOGRAPHS China Certification ICT Co., Ltd (Dongguan) Report No.: CR22080009-EXP Antenna

China Certification ICT Co., Ltd (Dongguan) Report No.: CR22080009-INP EUT INTERNAL PHOTOGRAPHS RF chip

1 1 2 2 3 3 4 4 DD CC BB AA Title NumberRevisionSize A4 Date:2022/7/12 BLE520-A 0.8pF C105 50R Trace DC Block V1.0 nRESET GNDGND GND GND 32MHz 1 3 X1 20pF C34 20pF C35 32.768KHz 12 X2 20pF C2 20pF C3 XL2 XL1 XC1 XC2 VDD P0.07 P0.08 P0.10/NFC2 P0 .11 P0.12P0.13P0.14P0.17P0.18P0.19P0.20P0.21 P0.22 P0.23 P0.24 P0 .25 DEC1 P0 .28 P0.29 SWCLK SWDIO P0.06 RF P0 .27 P0.26 VDD VDD DEC3P0.02 P0.03 P0.04 P0.05 P0 .15 P0.16 P0.09/NFC1 DEC4P0 .30 P0.31 DEC2 100nF C1 4.7uF C48 100nF C36 100nF C33 100nF C13 0.8pF C30 1.2pF C301 3.9nH L30 1uF C46 10uH L47 15nH L471 DEC1 1 P0.10 12 VDD 13 VSS 31 ANT 30 DEC2 32 DEC3 33 XC1 34 XC2 35 VDD 36 P0 .25 37 P0.26 38 P0.00/XL1 2 P0.01/XL2 3 P0.02/AIN0 4 P0.03/AIN1 5 P0.04/AIN2 6 P0.05/AIN3 7 P0.06 8 P0.07 9 P0.08 10 P0.09 11 P0 .11 14 P0.12 15 P0.13 16 P0.14 17 P0.27 39 P0.28 /AIN4 40 P0 .29 /AIN5 41 P0 .30 /AIN6 42 P0 .31 /AIN7 43 N.C. 44 DEC4 46 VSS 45 VDD 48 DCC 47 SWDCLK 25 SWDIO 26 P0.22 27 P0.23 28 P0.24 29 P0 .15 18 P0.16 19 P0.17 20 P0.18 21 P0.20 23 P0.21 /RESET 24 P0 .19 22 nRF52832 U1 ANT NO TE:12.5pF12.5*2-5=20pF 32K9pGND12pF 2450AT45A100 A1 nRESET VDD 1 2 3 4 5 6 7 8 P1 1 2 3 4 5 6 7 8 P2 GND GND SWCLK SWDIO P0.06 P0.08 P0.28 P0.29 P0.27 P0 .10 /NFC2 P0 .09 /NFC1 P0.18 P0.16 P0.17 12 P3 P0.19 P0.20 nRF_RX nRF_TX PIA101 PIA102 COA1 PIC101 PIC102 COC1 PIC201 PIC202 COC2 PIC301 PIC302 COC3 PIC1301 PIC1302 COC13 PIC3001 PIC3002 COC30 PIC3301 PIC3302 COC33 PIC3401 PIC3402 COC34 PIC3501 PIC3502 COC35 PIC3601 PIC3602 COC36 PIC4601 PIC4602 COC46 PIC4801 PIC4802 COC48 PIC10501PIC10502 COC105 PIC30101 PIC30102 COC301 PIL3001PIL3002 COL30 PIL4701 PIL4702 COL47 PIL47101PIL47102 COL471 PIP101 PIP102 PIP103 PIP104 PIP105 PIP106 PIP107 PIP108 COP1 PIP201 PIP202 PIP203 PIP204 PIP205 PIP206 PIP207 PIP208 COP2 PIP301 PIP302 COP3 PIU101 PIU102 PIU103 PIU104 PIU105 PIU106 PIU107 PIU108 PIU109 PIU1010 PIU1011 PIU1012 PIU1013 PIU1014 PIU1015 PIU1016 PIU1017 PIU1018 PIU1019PIU1020 PIU1021 PIU1022 PIU1023 PIU1024 PIU1025 PIU1026 PIU1027 PIU1028 PIU1029 PIU1030 PIU1031 PIU1032 PIU1033 PIU1034 PIU1035 PIU1036 PIU1037PIU1038PIU1039PIU1040PIU1041PIU1042PIU1043PIU1044PIU1045PIU1046PIU1047PIU1048 COU1 PIX101 PIX103 COX1 PIX201 PIX202 COX2
