IMW4100 QUICK START GUIDE HydraActive Wireless Speaker with Armband 正面背面 FCC Statement FCC Statement This device complies with the part 15 of the FCC rules. Opera�on is subject to the following two condi�ons: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired opera�on. Cau�on: Changes or modifica�ons not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment. Note: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protec�on against harmful interference in a residen�al installa�on. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instruc�ons, may cause harmful interference to radio communica�ons. However, there is no guarantee that interference will not occur in a par�cular installa�on. If this equipment does cause harmful interference to radio or television recep�on, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: - Reorient or relocate the receiving antenna. - Increase the separa�on between the equipment and receiver. - Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. - Consult the dealer or an experienced radio/TV technician for help. Altec Lansing Edison, NJ 08817 CALL:1-855-292-4087 ALTECLANSING.COM FCC ID:2A8JA-IMW4100 Thank you for purchasing an Altec Lansing product. Download our App to unlock all the features our products have to oer! A Closer Look Volume Down Volume Up Armband Status Indicator Light USB-C PortAUX Port Power/Play/Pause In the Box USB-C Charge Cable IMW4100 HydraActive Wireless Speaker with Armband Bluetooth® Pairing 1-2 SEC AL HydraActive Paired (White Always On) PRESS & HOLD TO POWER ON TO POWER ON Pairing Mode White & OrangeFlashing LED Controlling Music For additional user materials and warranty information, please visit alteclansing.com PRESS: - PRESS & HOLD (2 sec): You can also use a 3.5mm Auxillary Cable (not included) to connect audio devices. PRESS: + PRESS & HOLD (2 sec): PRESS: AUX Port Charging About 2 Hours Full Charge LED Indicator Light Charging = LED Flash Charging Complete = LED Always On PRESS & HOLD Turn on the first speaker and connect it to a Bluetooth compatible device. Then turn on the second speaker. True Wireless Pairing PRESS Briefly press and at the same time on either speaker, the speakers will pair together as a stereo pair. and Briefly press and at the same time on either speaker to stop TWS mode. pairing mode for a dierent device. The speaker will automatically shut down if not operated for half an hour. Triple clickto disconnect current device and re-enter PKGY7001XXX A0首次发行20231130 快速指南(多合一) 李鹏飞 2023/11/30 BK305 (IMW4100) Y7001XXX / / BK305 IMW4100_En;快速指南;展开尺寸:700*100mm, 成型尺寸:圆型直径100mm;108g铜版纸风琴折,4C双面 印刷,需折叠

Rev1/26/2023 DolphinElectronics(DongGuan)Co.,Ltd FederalCommunicationsCommission AuthorizationandEvaluationDivision 7435OaklandMillsRoad Columbia,MD21046 USA Date:2023.10.18 Ref:AttestationStatementsPart2.911(d)(5)(i)Filing FCCID:2A8JA-IMW4100 DolphinElectronics(DongGuan)Co.,Ltd(“theapplicant”)certifiesthattheequipmentforwhich authorizationissoughtisnot“covered”equipmentprohibitedfromreceivinganequipment authorizationpursuanttosection2.903oftheFCCrules. Sincerely, AllisonLi Rev1/26/2023 DolphinElectronics(DongGuan)Co.,Ltd FederalCommunicationsCommission AuthorizationandEvaluationDivision 7435OaklandMillsRoad Columbia,MD21046 USA Date:2023.10.18 Ref:AttestationStatementsPart2.911(d)(5)(ii)Filing FCCID:2A8JA-IMW4100 DolphinElectronics(DongGuan)Co.,Ltd(“theapplicant”)certifiesthat,asofthedateofthefilingofthe application,theapplicantisnotidentifiedontheCoveredList(asaspecificallynamedentityoranyofits subsidiariesoraffiliates)asanentityproducing“covered”equipment. Sincerely, AllisonLi

Dolphinelectronics(DongGuan)Co.,Ltd AvoveSouthIndustrialPark,No.2,BaolongRoad, DongguanCity,GuangdongProvince, China Date:September26,2023 FederalCommunicationsCommission AuthorizationandEvaluationDivision 7435OaklandMillsRoad Columbia,MD21046 FCCID:2A8JA-IMW4100 FRN：0032826778 USAgent–AttestationStatement/Part2.911(d)(7) Dolphinelectronics(DongGuan)Co.,Ltdcertifies,thatasofSeptember26,2023wehave designatedSakarInternational,InctoacceptserviceofprocessonourbehalfforFCCID: 2A8JA-IMW4100 Dolphinelectronics(DongGuan)Co.,Ltd,acceptstomaintainanagentofserviceofprocessin theUnitedStatesfornolessthanoneyearaftereitherthegranteehaspermanentlyterminatedall marketingandimportationoftheapplicableequipmentwithintheU.S.,ortheconclusionofany Commission-relatedadministrativeorjudicialproceedinginvolvingtheequipment,whicheveris later. SakarInternational,Inc,acceptsasofthedateofthefilingofthisapplication,theobligationof beingthedesignatedagentforthepurposeofacceptingserviceofprocessonbehalfofDolphin electronics(DongGuan)Co.,LtdforFCCID:2A8JA-IMW4100 DesignatedAgentInformation: CompanyName:SakarInternational,Inc FRN:0018921932 Address:195CarterDrive,Edison,NJ08817,USA ContactPerson:DAWNLEITAO Tel:732.248.1306 Email:[email protected] Sincerely, Company:Dolphinelectronics(DongGuan) Co.,Ltd DesignatedAgent:SakarInternational,Inc CompanyRepresentative: AllisonLi DesignatedAgentRepresentative: DAWNLEITAO Signature:Signature:

Rev11/20/07 DolphinElectronics(DongGuan)Co.,Ltd. FederalCommunicationsCommission AuthorizationandEvaluationDivision ConfidentialityRequestregardingapplicationforcertificationofFCCID:2A8JA-IMW4100 PursuanttoSections0.457and0.459oftheCommission’sRules,weherebyrequestconfidential treatmentofinformationaccompanyingthisapplicationasoutlinedbelow: ExhibitTypeFileName BlockDiagram Schematics OperationalDescription BlockDiagram Schematics OperationalDescription Theabovematerialscontaintradesecretsandproprietaryinformationnotcustomarilyreleasedto thepublic.Thepublicdisclosureofthesematerialsmaybeharmfultotheapplicantandprovide unjustifiedbenefitstoitscompetitors. TheapplicantunderstandsthatpursuanttoSection0.457oftheRules,disclosureofthis applicationandallaccompanyingdocumentationwillnotbemadebeforethedateoftheGrant forthisapplication. PursuanttoDA04-1705June15,2004oftheCommission’spublicnotice,Wealsorequestingthe commissiontograntshort-termconfidentialityrequestonthefollowingattachmentsuntil180 daysaftertheGrantDateofEquipmentAuthorizations. ExhibitTypeFileName UsermanualUsermanual InternalphotosInternalphotos Date:2023.10.18 Sincerely, AllisonLi

Report No. EDG2309190204E005Page 1 of 4Ver.1.0 FCC ID: 2A8JA-IMW4100 Report No. EDG2309190204E005Page 2 of 4Ver.1.0 Report No. EDG2309190204E005Page 3 of 4Ver.1.0 Report No. EDG2309190204E005Page 4 of 4Ver.1.0

PKGY7000XXX A0首次发行李鹏飞20230918 铭牌档案—镭雕 李鹏飞 2023/9/18 BK305 (IMW4100) Y7000XXX / / ITEM#: IMW4100-BLK Wireless Speaker DC Input: 5V 1A FCC ID: 2A8JA-IMW4100 MID#6121023 Made in China ITEM#: IMW4100-BLK Wireless Speaker DC Input: 5V 1A FCC ID: 2A8JA-IMW4100 MID#6121023 Made in China 4mm 档案位置示意图,档案上下居中 Size: 30*16mm 工艺: Laser 1:1

Report No. EDG2309190204E005Page 1 of 2Ver.1.0 FCC ID: 2A8JA-IMW4100 ANT Report No. EDG2309190204E005Page 2 of 2Ver.1.0

Report No. EDG2309190204E00502RPage 1 of 7Ver.1.0 TEST REPORT Product Name：Bluetooth Wireless Speaker Model Number： IMW4100, IMW4100-BLK, IMW4100-MINT, IMW4100-CB, IMW4100-CM, IMW4100-DR, IMW4100-TL, IMW4100-TRD, IMW4100-RYB, IMW4100-AB, IMW4100-ORG FCC ID：2A8JA-IMW4100 Prepared for:Dolphin Electronics (DongGuan) Co.,Ltd Address:Room 301,Building 3,No.2 Baolong Road, Houjie Town, Dongguan City, Guangdong Province,China Prepared by:EMTEK (DONGGUAN) CO., LTD. Address:-1&2/F.,Building 2, Zone A, Zhongda Marine Biotechnology Research and Development Base, No.9, Xincheng Avenue, Songshanhu High-technology Industrial Development Zone, Dongguan, Guangdong, China TEL: +86-0769-22807078 FAX: +86-0769-22807079 Report Number:EDG2309190204E00502R Date(s) of Tests:September 19, 2023 to October 17, 2023 Date of issue:October 17, 2023 $二维码$ Report No. EDG2309190204E00502RPage 2 of 7Ver.1.0 Table of Contents 1. TEST RESULT CERTIFICATION................................................................................................................................3 2. EUT SPECIFICATION.................................................................................................................................................5 3. TEST REQUIREMENT............................................................................................................................................... 6 4. MEASUREMENT RESULT.........................................................................................................................................7 Report No. EDG2309190204E00502RPage 3 of 7Ver.1.0 1.TEST RESULT CERTIFICATION Applicant:Dolphin Electronics (DongGuan) Co.,Ltd Address: Room 301,Building 3,No.2 Baolong Road, Houjie Town, Dongguan City, Guangdong Province,China Manufacturer:Dolphin Electronics (DongGuan) Co.,Ltd Address: Room 301,Building 3,No.2 Baolong Road, Houjie Town, Dongguan City, Guangdong Province,China EUT:Bluetooth Wireless Speaker Model Name: IMW4100, IMW4100-BLK, IMW4100-MINT, IMW4100-CB, IMW4100-CM, IMW4100-DR, IMW4100-TL, IMW4100-TRD, IMW4100-RYB, IMW4100-AB, IMW4100-ORG Trademark:Altec Lansing Measurement Procedure Used: APPLICABLE STANDARDS STANDARDTEST RESULT § 15.247(i), § 2.1093PASS The above equipment was tested by EMTEK(DONGGUAN) CO., LTD. The test data, data evaluation, test procedures, and equipment configurations shown in this report were made in accordance with the procedures given in ANSI C63.10 (2013) and the energy emitted by the sample EUT tested as described in this report is in compliance with the requirements of FCC Rules FCC § 15.247(i), § 2.1093 . The test results of this report relate only to the tested sample identified in this report Date of Test :September 19, 2023 to October 17, 2023 Prepared by : Xia Yang /Editor Reviewer : Tim Dong/ Supervisor Approve & Authorized Signer : Sam Lv / Manager Report No. EDG2309190204E00502RPage 4 of 7Ver.1.0 Modified History VersionReport No.Revision DateSummary EDG2309190204E00502RSeptember 28, 2023Original Report Report No. EDG2309190204E00502RPage 5 of 7Ver.1.0 2. EUT Specification CharacteristicsDescription Product:Bluetooth Wireless Speaker Model Number: IMW4100, IMW4100-BLK, IMW4100-MINT, IMW4100-CB, IMW4100-CM, IMW4100-DR, IMW4100-TL, IMW4100-TRD, IMW4100-RYB, IMW4100-AB, IMW4100-ORG All products are the same, only the model number and color of appearance are different Here we selected IMW4100 for all the test Sample:1# Data Rate: 1Mbps for GFSK modulation 2Mbps for π/4-DQPSK modulation 3Mbps for 8DPSK modulation Modulation: GFSK, π/4-DQPSK, 8DPSK Operating Frequency Range(s) : 2402-2480MHz Number of Channels: 79 channels Transmit Power Max: 4.80 dBm(0.003020 W) Antenna Gain:2.499 dBi Power supply: DC 5V from USB, DC 3.7V from battery Evaluation applied:MPE Evaluation SAR Evaluation Report No. EDG2309190204E00502RPage 6 of 7Ver.1.0 3. Test Requirement SAR Evaluation According to 447498 D01 V06, systems operating under the provisions of this section shall be operated in a manner that ensures that the public is not exposed to radio frequency energy level in excess of the Commission’s guidelines. Routine SAR evaluation refers to that specifically required by§2.1093, using measurements or computer simulation. When routine SAR evaluation is not required, portable transmitters with output power greater than the applicable low threshold require SAR evaluation to quality for TCB approval. One antenna is available for the EUT. The minimum separation distance is 5mm. Report No. EDG2309190204E00502RPage 7 of 7Ver.1.0 4. Measurement Result Antenna gain:2.499 dBi Transmit Frequency (MHz) Mode Measured Power (dBm) E.I.R.P (dBm) Tune up Power (dBm) Max tune up power(dBm) Calculation Result 1-g SAR 2402GFSK4.066.566±171.55351873 2441GFSK4.346.846±171.56607983 2480GFSK4.807.307±181.98726523 2402Π/4-DQPSK2.925.425±161.23400383 2441Π/4-DQPSK3.405.905±161.24398143 2480Π/4-DQPSK2.735.235±161.25387963 24028DPSK2.925.425±161.23400383 24418DPSK3.255.755±161.24398143 24808DPSK3.465.965±161.25387963 According to KDB 447498, no stand-alone required for BT antenna, and no simultaneous SAR measurement is required. *** End of Report ***

2.4G-2.48FrequencybandonboardPIFAantennatestreport    SPECIFICATIONS Frequency（MHz）2400-2480 PeakGain（dBi）2.499 AverageGain（dBi）＞-4 VSWR＜3.2 Impedance（Ω）50Ω AntennaTypePlannarInvertedFAntennaonboard PolarizationLinear Manufacture DolphinElectronics(DongGuan)Co.,Ltd. adress Room301,Building3,No.2BaolongRoad,HoujieTown,DongguanCity,Guangdong Province,China  Testenvironment:ChinaScienceandtechnologydarkroomtestsystem  Z X Y  Antennaphysicalandphysicaldimensions   AntennapassiveS-parameter： VSWR、ReturnLossandsmithchart Antennaefficiencyandgain  Frequency（MHz）Gain（dBi）Effciency（%）AverageGain（dBi）Efficiency（dB） 24001.43359.329%-2.717-2.267 24100.92751.861%-3.416-2.852 24200.82952.112%-3.166-2.831 24300.88149.299%-3.258-3.072 24401.19250.672%-3.144-2.952 24501.68853.067%-2.735-2.752 24602.19459.423%-2.276-2.260 24702.11856.680%-2.438-2.466 24802.49961.727%-2.112-2.095 Average1.52954.908%-2.806-2.616 Peak2.49961.727%-2.112-2.095 2440MHz2D-ThetaPattern 2440MHz2D-PhiPattern 2440MHz3D-HorizontalPattern 2440MHz3D-VerticalPattern 2440MHz3D-TotalPattern
