2A8M8-TOP10210.1-inch central control screen

1 PADdisplayinstructions Geardisplayandhighandlowspeed display 1.WhengearDhasnosignal,itsdisplayis thesameasthatofothergears; 2.WhenthegearDsignalisvalid,itwillbe highlightedandamplified;WhenNgearand Rgeararevalid,theeffectshallrefertoD gear; 3.Whenthehigh-speedswitchisturnedon, "L"lightislit; 4.Whenthehigh-speedswitchisturnedon, "H"lightislit. Maininterface(homepage) 1.FrontstripLEDlamp TurnonthefrontstripLEDlighttolightup theicon; 2.FrontandtopstripLEDlights 3.WhenthefrontandtopstripLEDlights areturnedonatthesametime,theicon islit; 4.READYlight Whenthevehicleisinadrivablestate,the READYlightislit. Leftinstrumentpaneldisplay 1.2WD/4WDdisplay Whenthe4WDswitdsisturnedon,the iconwillbelit.Whenthe2WDswitchis turnedon,theiconwillbelit. 2.Parkingbreakdisplay WhentheParkingbreakispulledup,the iconisdisplayed; 3.Vehiclespeeddisplay Accordingtothecollecteddata,thevehicle speed(value)isdisplayedinrealtime,and thepointerindicatesinrealtime.The maximumrangeoftheinstrumentis 80mph. 3 1 2 12 43 1 2 3 2 Rightinstrumentpaneldisplay 1.Displaywhenthemotorisoverheated; 2.Displayincaseofsystemfault; 3.DisplaywhenEPShasfault; 4.Displaywhenthepowerbatteryis undervoltage; 5.Accordingtothecollecteddata,theSOC (value)isdisplayedinrealtime,andthe pointerindicatesinrealtime； 6.Batteryindicator Whenthebatteryindicatorisdisplayedin red,thebatterycapacityislessthan20%; Whenthebatteryindicatorisdisplayedin yellow,thebatterycapacityislessthan40%; Whenthebatteryindicatorisshowningreen, itindicatesthatthebatterycapacityisnot lessthan40%,andwhenthered,yellowand greensymbolcyclechanges,itmeansthe vehicleisinthechargingstate. 5 6 Middlepositiondisplay 12hoursystemdisplay,real-timedisplayof thecurrenttime. Bottompositiondisplay 1.Rangemilesdisplay Displaytheremainingmileageofthevehicle inrealtime. 2.Displayofsubtotalmileage Realtimedisplayofsubtotalmileage. 3.Totalmileagedisplay Realtimedisplayoftotalmileage. 13 2 123456 3 Realtimedisplayoftotalbatteryvoltage; Realtimedisplayoftotalbatterycurrent; Realtimedisplayofthemaximumcellvoltage; Realtimedisplayoftheminimumcellvoltage; Realtimedisplayofthemaximumcell temperature; Realtimedisplayoftheminimumcell temperature; Realtimedisplayoffaultcode ； 3.Faultcode 1 3 2 Informationinterface 1.Batterystatus Realtimedisplayofmotorbusvoltage; Realtimedisplayofmotorbuscurrent; Realtimedisplayofmotortemperature; Realtimedisplayofcontrollertemperature; ； 2.Motorstatus 4 5 FCCWarning: AnyChangesormodificationsnotexpresslyapprovedbythepartyresponsible forcompliancecouldvoidtheuser'sauthoritytooperatetheequipment. Thisdevicecomplieswithpart15oftheFCCRules.Operationissubjecttothe followingtwoconditions: (1)Thisdevicemaynotcauseharmfulinterference,and (2)thisdevicemustacceptanyinterferencereceived,includinginterference thatmaycauseundesiredoperation. Note:Thisequipmenthasbeentestedandfoundtocomplywiththelimitsfora ClassBdigitaldevice,pursuanttopart15oftheFCCRules.Theselimitsare designedtoprovidereasonableprotectionagainstharmfulinterferenceina residentialinstallation.Thisequipmentgeneratesusesandcanradiateradio frequencyenergyand,ifnotinstalledandusedinaccordancewiththe instructions,maycauseharmfulinterferencetoradiocommunications. However,thereisnoguaranteethatinterferencewillnotoccurinaparticular installation.Ifthisequipmentdoescauseharmfulinterferencetoradioor televisionreception,whichcanbedeterminedbyturningtheequipmentoff andon,theuserisencouragedtotrytocorrecttheinterferencebyoneor moreofthefollowingmeasures: -Reorientorrelocatethereceivingantenna. -Increasetheseparationbetweentheequipmentandreceiver. -Connecttheequipmentintoanoutletonacircuitdifferentfromthattowhich thereceiverisconnected. -Consultthedealeroranexperiencedradio/TVtechnicianforhelp. Thistransmittermustnotbeco-locatedoroperatinginconjunctionwithany otherantennaortransmitter. ThisequipmentcomplieswithFCCradiationexposurelimitssetforthforan uncontrolledenvironment.Thisequipmentshouldbeinstalledandoperated withminimumdistance20cmbetweentheradiator&yourbody.

SC Autosports,LLC Federal Communica/ons Commission Authoriza/on and Evalua/on Division 7435 Oakland Mills Road Columbia, MD 21046 USA Date: May 10, 2023 Ref: AKesta /on Statements Part 2.911(d)(5)(i) Filing FCC ID: 2A8M8-TOP102 SC Autosports,LLC (“the applicant”) cer/fies that the equipment for which authoriza/on is sought is not “covered” equipment prohibited from receiving an equipment authoriza/on pursuant to sec/on 2.903 of the FCC rules. Sincerely, Signature: Printed name: Johnny Tai Rev 2/17/2023

SC Autosports,LLC Federal Communica/ons Commission Authoriza/on and Evalua/on Division 7435 Oakland Mills Road Columbia, MD 21046 USA Date: May 10, 2023 Ref: AKesta /on Statements Part 2.911(d)(5)(ii) Filing FCC ID: 2A8M8-TOP102 SC Autosports,LLC (“the applicant”) cer/fies that, as of the date of the filing of the applica/on, the applicant is not iden/fied on the Covered List as an en/ty producing “covered” equipment. Sincerely, Signature: Printed name: Johnny Tai Rev 2/17/2023

SC Autosports,LLC Federal Communica/ons Commission Authoriza/on and Evalua/on Division 7435 Oakland Mills Road Columbia, MD 21046 USA Date: May 10, 2023 Ref: AKesta /on Statements Part 2.911(d)(7) Filing FCC ID: 2A8M8-TOP102 SC Autosports,LLC (“the applicant”) cer/fies that, as of the date of the filing of the applica/on, we designate ourselves as the U.S. agent for service of process. Designated U.S. Agent Informa/on: FRN: 0032860181 Name: SC Autosports,LLC Address: 8050 Forest Lane Dallas,TX 75243, United States Contact Person: Johnny Tai Tel.: 972-271-0877 Extension: 109 Email: [email protected] Sincerely, SC Autosports,LLC Signature: printed name: Johnny Tai Rev 1/26/2023

SC Autosports,LLC Federal Communications Commission Authorization and Evaluation Division Confidentiality Request regarding application for certification of FCC ID: 2A8M8-TOP102 Pursuant to Sections 0.457 and 0.459 of the Commission’s Rules, we hereby request confidential treatment of information accompanying this application as outlined below: The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these materials may be harmful to the applicant and provide unjustified benefits to its competitors. The applicant understands that pursuant to Section 0.457 of the Rules, disclosure of this application and all accompanying documentation will not be made before the date of the Grant for this application. Pursuant to DA04-1705 June 15, 2004 of the Commission’s public notice, we also request that the information attached to this application be temporarily confidential for 180 days as outlined below: Sincerely, Signature: printed name: Johnny Tai Exhibit TypeFile Name (Block Diagram, Schematics, Operational Description) (Block Diagram.pdf, Schematics.pdf, Operational Description.pdf) Exhibit TypeFile Name User Manual External Photos Internal Photos Test Setup Photos User Manual.pdf External Photos.pdf Internal Photos.pdf Test Setup Photos.pdf Rev 11/20/07 Date: May 10, 2023 Rev 11/20/07

SC Autosports,LLC Federal Communications Commission Authorization and Evaluation Division 1435 Oakland Mills Road Columbia, MD 21046 Date: May 10, 2023 SUBJECT: FCC Application for (FCC ID: 2A8M8-TOP102) To Whom It May Concern: We, the undersigned, hereby authorize Mina Xu at Centre Testing International Group Co., Ltd / Building C, Hongwei Industrial Park Block 70, Bao'an District, Shenzhen, China on our behalf, to apply to the Federal Communications Commission on our equipment. Any and all acts carried out by Mina Xu at Centre Testing International Group Co., Ltd / Building C, Hongwei Industrial Park Block 70, Bao'an District, Shenzhen, China on our behalf shall have the same effect as acts of our own. This is to advise that we are in full compliance with the Anti- Drug Abuse Act. We, the applicant, are not subject to a denial of federal benefits pursuant to Section 5301 of the Anti-Drug Act of 1988, 21 USC853a, and no party to the application is subject to a denial of federal benefits pursuant to that section. Regards, Signature: printed name: Johnny Tai M:\Master Documents\TEMPLATES\POA_Letter.doc

SC Autosports,LLC Federal Communications Commission Date: 2023-05-10 Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046 SUBJECT: FCC SDoC declaration for FCC ID: 2A8M8-TOP102 To Whom it may concern, We, as the grantee of this project, would like to declare that this device has been tested according to the FCC requirement and found compliant with the following standards: FCC Part 15 Subpart B. Sincerely, Signature: ________________________________ Product Name:10.1-inch central control screen Brand Name:KANDI Model Name:TOP102 Testing Lab:Centre Testing International Group Co., Ltd Company Name:SC Autosports,LLC Name :Johnny Tai E-mail:[email protected] Te l .:972-271-0877 Extension: 109

ReportNo.:EED32P80617301Page 48 of 64 8 PHOTOGRAPHSOFEUTConstructionalDetails ViewofProduct-1 ViewofProduct-2 ReportNo.:EED32P80617301Page 49 of 64 ViewofProduct-3 ViewofProduct-4 ReportNo.:EED32P80617301Page 50 of 64 ViewofProduct-5 ViewofProduct-6

64.7x30mm R1 10.1-inch central control screen Model:TOP102 FCC ID: 2A8M8-TOP102 Bluetooth R

ReportNo.:EED32P80617301Page 51 of 64 ViewofProduct-7 ViewofProduct-8 ReportNo.:EED32P80617301Page 52 of 64 ViewofProduct-9 ViewofProduct-10 ReportNo.:EED32P80617301Page 53 of 64 ViewofProduct-11 ViewofProduct-12 ReportNo.:EED32P80617301Page 54 of 64 ViewofProduct-13 ViewofProduct-14 ReportNo.:EED32P80617301Page 55 of 64 ViewofProduct-15 ViewofProduct-16 ReportNo.:EED32P80617301Page 56 of 64 ViewofProduct-17 ViewofProduct-18 ReportNo.:EED32P80617301Page 57 of 64 ViewofProduct-19 ViewofProduct-20 ReportNo.:EED32P80617301Page 58 of 64 ViewofProduct-21 ViewofProduct-22 ReportNo.:EED32P80617301Page 59 of 64 ViewofProduct-23 ViewofProduct-24 ReportNo.:EED32P80617301Page 60 of 64 ViewofProduct-25 ViewofProduct-26 ReportNo.:EED32P80617301Page 61 of 64 ViewofProduct-27 ViewofProduct-28 ReportNo.:EED32P80617301Page 62 of 64 ViewofProduct-29 ViewofProduct-30 ReportNo.:EED32P80617301Page 63 of 64 ViewofProduct-31 ViewofProduct-32 ReportNo.:EED32P80617301Page 64 of 64 ViewofProduct-33 Thetestreportiseffectiveonlywithbothsignatureandspecializedstamp,Theresult(s)showninthis reportreferonlytothesample(s)tested.WithoutwrittenapprovalofCTI,thisreportcan’tbereproduced exceptinfull. ***EndofReport***

ReportNo.:EED32P80617303Page1of7 1COVERPAGE RFExposureEvaluationReport Product:10.1-inchcentralcontrolscreen Trademark:KANDI Model/Typereference:TOP102 SerialNumber:N/A ReportNumber:EED32P80617303 FCCID:2A8M8-TOP102 DateofIssue:Jul.11,2023 TestStandards: 47CFRPart1.1307 47CFRPart1.1310 447498D04InterimGeneralRF ExposureGuidancev01 Testresult:PASS Preparedfor: SCAutosports,LLC 8050ForestLaneDallas,TX75243 Preparedby: CentreTestingInternationalGroupCo.,Ltd. HongweiIndustrialZone,Bao’an70District, Shenzhen,Guangdong,China TEL:+86-755-33683668 FAX:+86-755-33683385 Compiledby:Reviewedby: FrazerLi TomChen Approvedby:Date:Jul.11,2023 AaronMa CheckNo.:8857270423 ReportNo.:EED32P80617303Page2of7 2Version VersionNo.DateDescription 00Jul.11,2023Original ReportNo.:EED32P80617303Page3of7 3Contents Page 1COVERPAGE....................................................................................................................................................................1 2VERSION............................................................................................................................................................................2 3CONTENTS........................................................................................................................................................................3 4GENERALINFORMATION..............................................................................................................................................4 4.1CLIENTINFORMATION...................................................................................................................................................4 4.2GENERALDESCRIPTIONOFEUT...................................................................................................................................4 4.3PRODUCTSPECIFICATIONSUBJECTIVETOTHISSTANDARD...........................................................................................4 4.4TESTLOCATION.............................................................................................................................................................5 4.5DEVIATIONFROMSTANDARDS......................................................................................................................................5 4.6ABNORMALITIESFROMSTANDARDCONDITIONS..........................................................................................................5 4.7OTHERINFORMATIONREQUESTEDBYTHECUSTOMER................................................................................................5 5SAREVALUATION...........................................................................................................................................................6 5.1RFEXPOSURECOMPLIANCEREQUIREMENT.................................................................................................................6 5.1.1Limits....................................................................................................................................................................6 5.1.2TestProcedure....................................................................................................................................................6 5.1.3EUTRFExposureEvaluation..........................................................................................................................7 ReportNo.:EED32P80617303Page4of7 4GeneralInformation 4.1ClientInformation Applicant: SCAutosports,LLC AddressofApplicant: 8050ForestLaneDallas,TX75243 Manufacturer: SCAutosports,LLC AddressofManufacturer: 8050ForestLaneDallas,TX75243 Factory: SCAutosports,LLC AddressofFactory: 8050ForestLaneDallas,TX75243 4.2GeneralDescriptionofEUT ProductName:10.1-inchcentralcontrolscreen ModelNo.(EUT): TOP102 TradeMark: KANDI 4.3 ProductSpecificationsubjectivetothisstandard FrequencyRange:BT:2402MHz~2480MHz 2.4GWIFI:IEEE802.11b/g/n(HT20):2412MHzto2462MHz IEEE802.11n(HT40):2422MHzto2452MHz ModulationType:BT:GFSK,π/4DQPSK,8DPSK 2.4GWIFI:IEEEfor802.11b:DSSS(CCK,DQPSK,DBPSK) IEEEfor802.11g:OFDM(64QAM,16QAM,QPSK,BPSK) IEEEfor802.11n(HT20andHT40):OFDM(64QAM,16QAM,QPSK,BPSK) TestPowerGrade:Default TestSoftwareofEUT:RFtest AntennaType: Internalantenna AntennaGain: AntennaScheme1:2.20dBi AntennaScheme2:2.17dBi Note:Thetwoschemesareofthesameantennatype.Thetestwascarriedout usingantennascheme1,andrecordedinthereport. PowerSupply:DC12.0V SampleReceivedDate: Apr.27,2023 SampletestedDate: Apr.27,2023toMay12,2023 Remark： CompanyNameandAddressshownonReport,thesample(s)andsampleInformationwas/wereprovided bytheapplicantwhoshouldberesponsiblefortheauthenticitywhichCTIhasn’tverified. ReportNo.:EED32P80617303Page5of7 4.4TestLocation Alltestswereperformedat: CentreTestingInternationalGroupCo.,Ltd BuildingC,HongweiIndustrialParkBlock70,Bao'anDistrict,Shenzhen,China Telephone:+86(0)75533683668Fax:+86(0)75533683385 Notestsweresub-contracted. FCCDesignationNo.:CN1164 4.5DeviationfromStandards None. 4.6AbnormalitiesfromStandardConditions None. 4.7OtherInformationRequestedbytheCustomer None. ReportNo.:EED32P80617303Page6of7 5SAREvaluation 5.1RFExposureComplianceRequirement 5.1.1Limits TheSAR-basedexemptionformulaof§1.1307(b)(3)(i)(B),repeatedhereasFormula(B.2),appliesfor singlefixed,mobile,andportableRFsourceswithavailablemaximumtime-averagedpoweroreffective radiatedpower(ERP),whicheverisgreater,oflessthanorequaltothethresholdPth(mW). Thismethodshallonlybeusedatseparationdistancesfrom0.5cmto40cmandatfrequenciesfrom 0.3GHzto6GHz(inclusive).PthisgivenbyFormula andfisinGHz,distheseparationdistance(cm),andERP20cmisperFormula(B.1). The1mWBlanketExemptionof§1.1307(b)(3)(i)(A)appliesforsinglefixed,mobile,andportableRF sourceswithavailablemaximumtime-averagedpowerofnomorethan1mW,regardlessofseparation distance. 5.1.2TestProcedure SoftwareprovidedbyclientenabledtheEUTtotransmitandreceivedataatlowest,middleandhighest channelindividually. ReportNo.:EED32P80617303Page7of7 5.1.3EUTRFExposureEvaluation …
