2A8O6-EWIL1Electric Wind Instrument

OPERATION INSTRUCTIONS Note: All accessories of this instrument except the mouthpiece cannot be disassembled. All consequences caused by self-disassembly or modification shall be borne by the customer himself. Product Diagram Detailed functions Instrument charging Battery/charge Correct playing posture Connect the signal output mode Playing and skills Introduction of fingering Semitone playing way Common malfunction and the solutions Product maintenance and precautions Tone list Voulme knob Blow Vibrato Glide Pitch bend Fingering Tone Transpose ON/OFF Glide Plate Octave Rollers Hook clasp Pitch bend controller Earphone Speaker Battery cover Mouthpieces There is a vibrato sensor inside the mouthpiece, when you gently biting the mouthpiece , there will be a uniform vibrato effect. Do not bite it too hard. LCD screen This screen will show the contents of various parameters such as tone, tonality, power, blowing sensitivity, volume adjustment, MIDI channel, vibrate , fingering adjustment etc. You can easily use this EWI through the screen. 1. Volume button Volume range from 1 to 16, the higher the number, the louder the sound. 2. Blow The blowing strength range is 1-32, the larger the number, the smaller the air consumption, and it will automatically make a sound if the number over 28. 3. Vibrate adjustment The range is 0-127, the larger the number, the more obvious the vibrato effect. 4. Glide Plate The range is 0-127, the larger the number, the more obvious the glide adjustment. 5. Pitch bend adjustment The range is 0-127, the larger the number, the more obvious the pitch bend effect. 6. Fingering type adjustment You can choose flute or saxophone fingering type according to your needs. 7. Tone adjustment There are 88 kinds of tones you can choose 8. Pitch knob Built-in 12 pitches 9. ON/OFF Press and hold for 3s to turn on and off. 10. Glide bar It will automatically make glide when you press this glide bar. When using the articulation technique, the glide is automatically interrupted (The glide refers to the smooth transition between two different pitches). 11-15. Octave Adjust the high, middle, bass by moving your thumb up and down. A-C quickly change the tone or mode control area: A-C 3 commonly used tones have been set before leaving the factory, and you can quickly change them with one click. If you want to change to other tones, you can also store them in the keys. The specific operation is as follows: If you want to use the violin tone, you can use the tone knob to call out the violin tone. Press and hold any button from 1 to 3 for 3 seconds, the screen will show Saved, at this time you can let go, the current tone and the mode used have been saved to the corresponding button. When you short press again, it will directly call up the saved tone. D-F 3 function button D is for MIDI set up, E is vibrato switch, and F is Bluetooth switch. 16. Neck Strap clip Fix the neck strap into the buckle, adjust the length of the neck strap, move the weight of the EWI on the neck as much as possible, and relax your hands as much as possible, so as to better play and protect the instrument. 17. Pitch bend controller Pressing down the sensor, it will produce lower bend effect, and it will return to the normal pitch when letting go. 18. 3.5 Headphone output jack You can put your headphone into this jack, which can avoid bothering your family even though you practice it in the mid-night. This jack also can connect to the speakers or turning equipment. The speaker will automatically close when this jack be used. 19. Speaker The speaker will make the sound to play without using external speakers and headphone. 20. Battery cover Opening this cover you can find built-in battery. The charging jack is at the bottom of the tail and has a rechargeable battery. Putting the charging wire into the jack, there will be a red light when charging, and it will turn to green when fully charged. When charging, there is a power display in the upper right corner of the screen. Please charge it ASAP when the battery shows the last bar. Do not use it during charging. It will automatically shut down when the power is too low. Better to use the neck strap for beginners and put the weight on the neck strap. With your hands relaxed, place the EWI directly in front of you(like the same way you hold a saxophone or clarinet), 0 with your left hand above and your right below. Play at a 45 angle to your body. Left-handed players can choose to customize special instruments. The right hand is on the top and the left hand is on the bottom. 1. 6.5 Audio output jack Sound can be connected to the speakers or the turning equipment when the audio wire put into this jack. 2. 3.5 Headphone output jack This jack can put into the headphone, which can avoid bothering your family even though you practice it at the 1. Note Induction Keys The note keys are divided into three parts, 6 sensor keys, 6 long bar sensor keys, and 6 octave keys on the back. 2. Pitch bend playing skills Pitch bending controller: Slide the finger down and slowly return to the original position, and the lower bend effect can appear, and the lower bend tone of two semitone ranges can be played. 3. Glide playing skills The EWI's glide plate let you use a glide effect to move between notes for greater expressiveness in your performance. Press and hold the metal bar on the right side of octave key with your thumb, and there will be a glide effect between the notes played. 4. Bite vibrato playing skills Vibrato can be produced by gently biting the mouthpiece while blowing. The vibrato fluctuation and vibrato speed can be controlled by the multi-function knob, to know more details please see the functions page. mid-night. This jack also can connect to the speakers or turning equipment. When 6.5 jack or 3.5 jack is plugged into an audio plug or a headphone, the built-in speakers will be automatically turned off without sound. When unplugged, the built-in speakers of this instrument …

Text truncated - open the document above for the full version.

Jiangxi Baorui Electronic Technology Co., Ltd. The northwest corner of the intersection of Guangzhou Road and Chuangxin Avenue, High-tech Industrial Park, Xinfeng County Ganzhou China Federal Communications Commission Authorization and Evaluation Division Equipment Authorization Branch 7435 Oakland Mills Road Columbia, MD 21046 2024-4-11 To whom it may concern: We, Jiangxi Baorui Electronic Technology Co., Ltd., hereby certify that the equipment for which authorization is sought (FCC ID: 2A8O6-EWIL1) is not “covered” equipment prohibited from receiving an equipment authorization pursuant to § 2.903 of the FCC rules. We also certify that, as of the date of the filing of the application, we are not identified on the Covered List (https://www.fcc.gov/supplychain/coveredlist) as an entity producing “covered” equipment. By signing this form, we confirm the above and that we are aware of the application requirements listed under § 2.911(b) and (d)(5) and (6). The information provided in this letter is based on the referenced rule parts of Title 47 of the CFR as well as KDB 986446 D01. Sincerely, Signature Zhen Zhang Business Manager Jiangxi Baorui Electronic Technology Co., Ltd. 62_[model] CoveredEqu_2.911(d)(5)(i) and (ii) - U, V03

Jiangxi Baorui Electronic Technology Co., Ltd. Add: The northwest corner of the intersection of Guangzhou Road and Chuangxin Avenue, High-tech Industrial Park, Xinfeng County Ganzhou China Date: 2024-4-11 FCC ID: 2A8O6-EWIL1 Dear Sir/Madam, We, Jiangxi Baorui Electronic Technology Co., Ltd. Hereby declares the following statement for Federal Communications Commission, PCB board, circuit, structure and internal of these model(s) are the same, Only model number is different for these model: Product name: Electric Wind Instrument Model no.: EWI L1, L1,L2,L3,L5,L6,S06L S3000,S6000,S9000, S05, S06, S07.S08.S09.S10.S55 S56.S57.S58.S59.S60.S66.S68, C06, C07, C08, C09, C8600, C8800, C8900 ,C8100, C8200 Sincerely, Name/Title： Zhen Zhang/Business Manager Company: Jiangxi Baorui Electronic Technology Co., Ltd. Address: The northwest corner of the intersection of Guangzhou Road and Chuangxin Avenue, High-tech Industrial Park, Xinfeng County Ganzhou China Phone: 18665151289 Fax: 18665151289 E-Mail: [email protected]

CONFIDENTIALITY REQUEST for Certification Service in USA Federal Communication Commission Equipment Authorization Division, Application Processing Branch 7435 Oakland Mills Road Columbia, MD 21046 Date:<2024-4-11> Pursuant to Paragraphs §0.457 and 0.459 of the Commission’s Rules (47 C.F.R.) and Section §552(b)(4) of the Freedom of Information Act, we requests confidentiality for the following products: FCC ID Model name 2A8O6-EWIL1 EWI L1 For the product stated above, we request that the following information be held confidential; Exhibits Long-Term Confidentiality Short-Term Confidentiality Short-Term Confidentiality Days External Photos Internal Photos Block Diagram Schematics Test Setup Photos User’s Manual Parts List Tune Up Operational Descriptions The long-term confidentiality exhibits contain our trade secrets and proprietary information that could be of benefit to our competitors. The short-term confidentiality on the basis of ensuring that business sensitive information remains confidential until the actual marketing of our new device. If you have any questions, please feel free to contact me at the address shown below. Sincerely, Name/Title： Zhen Zhang/Business Manager Company: Jiangxi Baorui Electronic Technology Co., Ltd. Address: The northwest corner of the intersection of Guangzhou Road and Chuangxin Avenue, High-tech Industrial Park, Xinfeng County Ganzhou China Phone: 18665151289 Fax: 18665151289 E-Mail: [email protected]

Jiangxi Baorui Electronic Technology Co., Ltd. The northwest corner of the intersection of Guangzhou Road and Chuangxin Avenue, High-tech Industrial Park, Xinfeng County Ganzhou China Federal Communications Commission Authorization and Evaluation Division Equipment Authorization Branch 7435 Oakland Mills Road Columbia, MD 21046 2024-4-11 To whom it may concern: We, the undersigned, hereby authorize Eurofins Product Service GmbH to act on our behalf in all matters relating to applications for equipment authorization FCC ID: 2A8O6-EWIL1 including the signing of all documents related to these matters. Any and all acts carried out by Eurofins Product Service GmbH on our behalf shall have the same effect as acts of our own. By signing this application form, we agree to Eurofins’ current valid General Terms and Conditions (AGB),Testing and Certification Regulations (PZO) which can be viewed on following website www.eurofins.de/ee or retrieved on request. We also hereby certify that no party to this application is subject to a denial of benefits, including FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C. 862. Sincerely, Name/Title： Zhen Zhang/Business Manager Company: Jiangxi Baorui Electronic Technology Co., Ltd. Address: The northwest corner of the intersection of Guangzhou Road and Chuangxin Avenue, High-tech Industrial Park, Xinfeng County Ganzhou China Phone: 18665151289 Fax: 18665151289 E-Mail: [email protected]

Page 1 of 5 FCC ID: 2A8O6-EWIL1 Shenzhen LCS Compliance Testing Laboratory Ltd. Add: 101, 201 Bldg A & 301 Bldg C, Juji Industrial Park Yabianxueziwei, Shajing Street, Baoan District, Shenzhen, 518000, China Tel: +(86) 0755-82591330 | E-mail: [email protected] | Web: www.lcs-cert.com Scan code to check authenticity External Photos of the EUT Fig. 1 Fig. 2 Page 2 of 5 FCC ID: 2A8O6-EWIL1 Shenzhen LCS Compliance Testing Laboratory Ltd. Add: 101, 201 Bldg A & 301 Bldg C, Juji Industrial Park Yabianxueziwei, Shajing Street, Baoan District, Shenzhen, 518000, China Tel: +(86) 0755-82591330 | E-mail: [email protected] | Web: www.lcs-cert.com Scan code to check authenticity Fig. 3 Fig. 4 Page 3 of 5 FCC ID: 2A8O6-EWIL1 Shenzhen LCS Compliance Testing Laboratory Ltd. Add: 101, 201 Bldg A & 301 Bldg C, Juji Industrial Park Yabianxueziwei, Shajing Street, Baoan District, Shenzhen, 518000, China Tel: +(86) 0755-82591330 | E-mail: [email protected] | Web: www.lcs-cert.com Scan code to check authenticity Fig. 5 Fig. 6 Page 4 of 5 FCC ID: 2A8O6-EWIL1 Shenzhen LCS Compliance Testing Laboratory Ltd. Add: 101, 201 Bldg A & 301 Bldg C, Juji Industrial Park Yabianxueziwei, Shajing Street, Baoan District, Shenzhen, 518000, China Tel: +(86) 0755-82591330 | E-mail: [email protected] | Web: www.lcs-cert.com Scan code to check authenticity Fig. 7 Fig. 8 Page 5 of 5 FCC ID: 2A8O6-EWIL1 Shenzhen LCS Compliance Testing Laboratory Ltd. Add: 101, 201 Bldg A & 301 Bldg C, Juji Industrial Park Yabianxueziwei, Shajing Street, Baoan District, Shenzhen, 518000, China Tel: +(86) 0755-82591330 | E-mail: [email protected] | Web: www.lcs-cert.com Scan code to check authenticity Fig. 9

Page 1 of 1 FCC ID: 2A8O6-EWIL1 Shenzhen LCS Compliance Testing Laboratory Ltd. Add: 101, 201 Bldg A & 301 Bldg C, Juji Industrial Park Yabianxueziwei, Shajing Street, Baoan District, Shenzhen, 518000, China Tel: +(86) 0755-82591330 | E-mail: [email protected] | Web: www.lcs-cert.com Scan code to check authenticity LABEL AND LOCATION (Size: L 4.0cm x W 2.0cm) Label Location Electric Wind Instrument Model: EWI L1 FCC ID: 2A8O6-EWIL1

Page 1 of 4 FCC ID: 2A8O6-EWIL1 Shenzhen LCS Compliance Testing Laboratory Ltd. Add: 101, 201 Bldg A & 301 Bldg C, Juji Industrial Park Yabianxueziwei, Shajing Street, Baoan District, Shenzhen, 518000, China Tel: +(86) 0755-82591330 | E-mail: [email protected] | Web: www.lcs-cert.com Scan code to check authenticity Internal Photos of the EUT Fig. 1 Fig. 2 Page 2 of 4 FCC ID: 2A8O6-EWIL1 Shenzhen LCS Compliance Testing Laboratory Ltd. Add: 101, 201 Bldg A & 301 Bldg C, Juji Industrial Park Yabianxueziwei, Shajing Street, Baoan District, Shenzhen, 518000, China Tel: +(86) 0755-82591330 | E-mail: [email protected] | Web: www.lcs-cert.com Scan code to check authenticity Fig. 3 Fig. 4 Page 3 of 4 FCC ID: 2A8O6-EWIL1 Shenzhen LCS Compliance Testing Laboratory Ltd. Add: 101, 201 Bldg A & 301 Bldg C, Juji Industrial Park Yabianxueziwei, Shajing Street, Baoan District, Shenzhen, 518000, China Tel: +(86) 0755-82591330 | E-mail: [email protected] | Web: www.lcs-cert.com Scan code to check authenticity Fig. 5 Fig. 6 Page 4 of 4 FCC ID: 2A8O6-EWIL1 Shenzhen LCS Compliance Testing Laboratory Ltd. Add: 101, 201 Bldg A & 301 Bldg C, Juji Industrial Park Yabianxueziwei, Shajing Street, Baoan District, Shenzhen, 518000, China Tel: +(86) 0755-82591330 | E-mail: [email protected] | Web: www.lcs-cert.com Scan code to check authenticity Fig. 7 Fig. 8 Bluetooth Antenna

Page 1 of 4 FCC ID: 2A8O6-EWIL1 Shenzhen LCS Compliance Testing Laboratory Ltd. Add: 101, 201 Bldg A & 301 Bldg C, Juji Industrial Park Yabianxueziwei, Shajing Street, Baoan District, Shenzhen, 518000, China Tel: +(86) 0755-82591330 | E-mail: [email protected] | Web: www.lcs-cert.com Scan code to check authenticity FCC RF Exposure Evaluation 1. Product Information FCC ID : 2A8O6-EWIL1 Product name : Electric Wind Instrument Test Model : EWI L1 Additional Model No. : L1,L2,L3,L5,L6,S06L S3000,S6000,S9000, S05, S06, S07.S08.S09.S10.S55 S56.S57.S58.S59.S60.S66.S68, C06, C07, C08, C09, C8600, C8800, C8900 ,C8100, C8200 Model Declaration : PCB board, structure and internal of these model(s) are the same, So no additional models were tested Power Supply : Input: DC 5V, 2000mA DC 3.7V by Rechargeable Li-ion Battery, 1700mAh For Adapter Input: 100-240V~, 50/60Hz, 0.3A Adapter Output: 5V2000mA Hardware Version : V1.7 Software Version 20231121-01-G01 Bluetooth : Frequency Range : 2402MHz~2480MHz Channel Number : 79 channels for Bluetooth V5.0 (DSS) 40 channels for Bluetooth V5.0 (DTS) Channel Spacing : 1MHz for Bluetooth V5.0 (DSS) 2MHz for Bluetooth V5.0 (DTS) Modulation Type : GFSK, π/4-DQPSK, 8-DPSK for Bluetooth V5.0 (DSS) GFSK for Bluetooth V5.0 (DTS) Bluetooth Version : V5.0 Antenna Type : Internal Antenna Antenna Gain : 0dBi Exposure category : General population/uncontrolled environment EUT Type : Production Unit Device Type : Portable Device 2. Evaluation method and Limit According to KDB447498 D01 General RF Exposure Guidance v06 Section 4.3.1 Standalone SAR test exclusion considerations: “Unless specifically required by the published RF exposure KDB procedures, standalone 1-g head or body and 10-g extremity SAR evaluation for general population exposure conditions, by measurement or numerical simulation, is not required when the corresponding SAR Test Exclusion Threshold condition, listed below, is satisfied. These test exclusion conditions are based on source-based time-averaged maximum conducted output power of the RF channel requiring evaluation, adjusted for tune-up tolerance, and the minimum test separation distance required for the exposure conditions.22 The minimum test separation distance is determined by the smallest distance from the antenna and radiating structures or outer surface of Page 2 of 4 FCC ID: 2A8O6-EWIL1 Shenzhen LCS Compliance Testing Laboratory Ltd. Add: 101, 201 Bldg A & 301 Bldg C, Juji Industrial Park Yabianxueziwei, Shajing Street, Baoan District, Shenzhen, 518000, China Tel: +(86) 0755-82591330 | E-mail: [email protected] | Web: www.lcs-cert.com Scan code to check authenticity the device, according to the host form factor, exposure conditions and platform requirements, to any part of the body or extremity of a user or bystander (see 5) of section 4.1). To qualify for SAR test exclusion, the test separation distances applied must be fully explained and justified by the operating configurations and exposure conditions of the transmitter and applicable host platform requirements, typically in the SAR measurement or SAR analysis report, according to the required published RF exposure KDB procedures. When no other RF exposure testing or reporting is required, a statement of justification and compliance must be included in the equipment approval, in lieu of the SAR report, to qualify for the SAR test exclusion. When required, the device specific conditions described in the other published RF exposure KDB procedures must be satisfied before applying these SAR test exclusion provisions; for example, handheld PTT two-way radios, handsets, laptops & tablets etc.“ [(max. power of channel, including tune-up tolerance, mW)/ (min. test separation distance, mm)] · [√f (GHz)] ≤ 3.0 for 1-g SAR and ≤ 7.5 for 10-g extremity SAR, where: • f (GHz) is the RF channel transmit frequency in GHz • Power and distance are rounded to the nearest mW and mm before calculation • The result is rounded to one decimal place for comparison • 3.0 and 7.5 are referred to as the numeric thresholds in the step 2 below The test exclusions are applicable only when the minimum test separation distance is ≤ 50 mm and for transmission frequencies between 100 MHz and 6 GHz. When the minimum test separation distance is < 5 mm, a distance of 5 mm according to f) in section 4.1 is applied to determine SAR test exclusion. When one of the following test exclusion conditions is satisfied for all combinations of simultaneous transmission configurations, further equipment approval is not required to incorporate transmitter modules in host devices that operate in the mixed mobile and portable host platform exposure conditions. The grantee is responsible for documenting this according to Class I permissive change requirements. Antennas that qualify for standalone SAR test exclusion must apply the estimated standalone SAR to determine simultaneous transmission test exclusion. a) The [∑ of (the highest measured or estimated SAR for each standalone antenna configuration, adjusted for maximum tune-up tolerance) / 1.6 W/kg] + [∑ of MPE ratios] is ≤ 1.0. b)The SAR to peak location separation ratios of all simultaneously transmitting antenna pairs operating in portable device exposure conditions are all ≤ 0.04, and the [∑ of MPE ratios] is ≤ 1.0. 3. Refer Evaluation Method ANSI C95.1–1999: IEEE Standard for Safety Levels with Respect to Human Exposure to Radio Frequency Electromagnetic Fields, 3 kHz to 300 GHz. FCC KDB publication 447498 D01 General RF Exposure Guidance v06: Mobile and Portable Devices RF Exposure Procedures and Equipment Authorization Policies. FCC CFR 47 part1 1.1310: Radiofrequency radiation exposure limits. FCC CFR 47 part2 2.1093: Radiofrequency radiation exposure evaluation: portable devices Page 3 of 4 FCC ID: 2A8O6-EWIL1 Shenzhen LCS Compliance Testing Laboratory Ltd. Add: 101, 201 Bldg A & 301 Bldg C, Juji Industrial Park Yabianxueziwei, Shajing Street, Baoan District, Shenzhen, 518…

Text truncated - open the document above for the full version.

Inverted F Antenna Specification Summary ITEM ANT SPEC Model Name Bluetooth ANT Center Frequency Horizontal Vertical 2400MHz 2400MHz 2500MHz 2400MHz 2400MHz 2500MHz -1.26 -0.76 0.0 -5.25 -2.46 -1.86 MAX. Gain 0.0 dBi Polarization Horizontal and Vertical Azimuth Beam Pattern Omni-directional Impedance 50 Ohm Antenna Length 38.20mm Manufacture ZHUHAI JIELI TECHNOLOGY CO.,LTD Antenna Photo & Length (mm) Bluetooth Antenna Horizontal: 2400 MHz 2450 MHz 2500 MHz Power (dBm) Max: 0 Min: -40 Scale: 5/div Frequency (MHz) Gain(dBi) Max Min Avg 2400 -1.26174 -30.0801 -7.18716 2450 -0.765802 -36.5604 -7.48023 2500 0.0 -22.0315 -6.59127 Vertical: 2400 MHz 2450 MHz 2500 MHz Power (dBm) Max: 0 Min: -30 Scale: 5/div Frequency (MHz) Gain(dBi) Max Min Avg 2400 -5.2537 -22.1424 -12.4294 2450 -2.4652 -24.5837 -10.4702 2500 0.0 -29.5214 -9.20432 ANT Test Labs：Attestation of Global Compliance Co., Ltd.

Page 1 of 61 FCC ID: 2A8O6-EWIL1 Report No.: LCSA01244108EA Shenzhen LCS Compliance Testing Laboratory Ltd. Add: 101, 201 Bldg A & 301 Bldg C, Juji Industrial Park Yabianxueziwei, Shajing Street, Baoan District, Shenzhen, 518000, China Tel: +(86) 0755-82591330 | E-mail: [email protected] | Web: www.lcs-cert.com Scan code to check authenticity Appendix A RF Test Data for BT (Conducted Measurement) Product Name: Electric Wind Instrument Test Model: EWI L1 Environmental Conditions Temperature: 23.8° C Relative Humidity: 52.1% ATM Pressure: 100.0 kPa Test Engineer: Jay Luo Supervised by: Nick Peng Page 2 of 61 FCC ID: 2A8O6-EWIL1 Report No.: LCSA01244108EA Shenzhen LCS Compliance Testing Laboratory Ltd. Add: 101, 201 Bldg A & 301 Bldg C, Juji Industrial Park Yabianxueziwei, Shajing Street, Baoan District, Shenzhen, 518000, China Tel: +(86) 0755-82591330 | E-mail: [email protected] | Web: www.lcs-cert.com Scan code to check authenticity A.1 20dB Emission Bandwidth Test Result TestMode Antenna Frequency[MHz] 20db EBW[MHz] FL[MHz] FH[MHz] Limit[MHz] Verdict DH5 Ant1 2402 0.951 2401.538 2402.489 --- --- 2441 0.945 2440.541 2441.486 --- --- 2480 1.029 2479.478 2480.507 --- --- 2DH5 Ant1 2402 1.311 2401.346 2402.657 --- --- 2441 1.290 2440.364 2441.654 --- --- 2480 1.338 2479.331 2480.669 --- --- 3DH5 Ant1 2402 1.296 2401.343 2402.639 --- --- 2441 1.305 2440.349 2441.654 --- --- 2480 1.305 2479.349 2480.654 --- --- Page 3 of 61 FCC ID: 2A8O6-EWIL1 Report No.: LCSA01244108EA Shenzhen LCS Compliance Testing Laboratory Ltd. Add: 101, 201 Bldg A & 301 Bldg C, Juji Industrial Park Yabianxueziwei, Shajing Street, Baoan District, Shenzhen, 518000, China Tel: +(86) 0755-82591330 | E-mail: [email protected] | Web: www.lcs-cert.com Scan code to check authenticity Test Graphs DH5_Ant1_2402 DH5_Ant1_2441 DH5_Ant1_2480 Page 4 of 61 FCC ID: 2A8O6-EWIL1 Report No.: LCSA01244108EA Shenzhen LCS Compliance Testing Laboratory Ltd. Add: 101, 201 Bldg A & 301 Bldg C, Juji Industrial Park Yabianxueziwei, Shajing Street, Baoan District, Shenzhen, 518000, China Tel: +(86) 0755-82591330 | E-mail: [email protected] | Web: www.lcs-cert.com Scan code to check authenticity 2DH5_Ant1_2402 2DH5_Ant1_2441 Page 5 of 61 FCC ID: 2A8O6-EWIL1 Report No.: LCSA01244108EA Shenzhen LCS Compliance Testing Laboratory Ltd. Add: 101, 201 Bldg A & 301 Bldg C, Juji Industrial Park Yabianxueziwei, Shajing Street, Baoan District, Shenzhen, 518000, China Tel: +(86) 0755-82591330 | E-mail: [email protected] | Web: www.lcs-cert.com Scan code to check authenticity 2DH5_Ant1_2480 3DH5_Ant1_2402 Page 6 of 61 FCC ID: 2A8O6-EWIL1 Report No.: LCSA01244108EA Shenzhen LCS Compliance Testing Laboratory Ltd. Add: 101, 201 Bldg A & 301 Bldg C, Juji Industrial Park Yabianxueziwei, Shajing Street, Baoan District, Shenzhen, 518000, China Tel: +(86) 0755-82591330 | E-mail: [email protected] | Web: www.lcs-cert.com Scan code to check authenticity 3DH5_Ant1_2441 3DH5_Ant1_2480 Page 7 of 61 FCC ID: 2A8O6-EWIL1 Report No.: LCSA01244108EA Shenzhen LCS Compliance Testing Laboratory Ltd. Add: 101, 201 Bldg A & 301 Bldg C, Juji Industrial Park Yabianxueziwei, Shajing Street, Baoan District, Shenzhen, 518000, China Tel: +(86) 0755-82591330 | E-mail: [email protected] | Web: www.lcs-cert.com Scan code to check authenticity Page 8 of 61 FCC ID: 2A8O6-EWIL1 Report No.: LCSA01244108EA Shenzhen LCS Compliance Testing Laboratory Ltd. Add: 101, 201 Bldg A & 301 Bldg C, Juji Industrial Park Yabianxueziwei, Shajing Street, Baoan District, Shenzhen, 518000, China Tel: +(86) 0755-82591330 | E-mail: [email protected] | Web: www.lcs-cert.com Scan code to check authenticity A.2 Maximum conducted output power Test Result Peak Te s t Mode Antenna Frequency[MHz] Conducted Peak Powert[dBm] Conducted Limit[dBm] Verdict DH5 Ant1 2402 -1.79 ≤20.97 PASS 2441 0.71 ≤20.97 PASS 2480 0.08 ≤20.97 PASS 2DH5 Ant1 2402 0.17 ≤20.97 PASS 2441 2.63 ≤20.97 PASS 2480 1.48 ≤20.97 PASS 3DH5 Ant1 2402 0.56 ≤20.97 PASS 2441 2.88 ≤20.97 PASS 2480 1.74 ≤20.97 PASS Page 9 of 61 FCC ID: 2A8O6-EWIL1 Report No.: LCSA01244108EA Shenzhen LCS Compliance Testing Laboratory Ltd. Add: 101, 201 Bldg A & 301 Bldg C, Juji Industrial Park Yabianxueziwei, Shajing Street, Baoan District, Shenzhen, 518000, China Tel: +(86) 0755-82591330 | E-mail: [email protected] | Web: www.lcs-cert.com Scan code to check authenticity Test Graphs DH5_Ant1_2402 DH5_Ant1_2441 DH5_Ant1_2480 Page 10 of 61 FCC ID: 2A8O6-EWIL1 Report No.: LCSA01244108EA Shenzhen LCS Compliance Testing Laboratory Ltd. Add: 101, 201 Bldg A & 301 Bldg C, Juji Industrial Park Yabianxueziwei, Shajing Street, Baoan District, Shenzhen, 518000, China Tel: +(86) 0755-82591330 | E-mail: [email protected] | Web: www.lcs-cert.com Scan code to check authenticity 2DH5_Ant1_2402 2DH5_Ant1_2441 Page 11 of 61 FCC ID: 2A8O6-EWIL1 Report No.: LCSA01244108EA Shenzhen LCS Compliance Testing Laboratory Ltd. Add: 101, 201 Bldg A & 301 Bldg C, Juji Industrial Park Yabianxueziwei, Shajing Street, Baoan District, Shenzhen, 518000, China Tel: +(86) 0755-82591330 | E-mail: [email protected] | Web: www.lcs-cert.com Scan code to check authenticity 2DH5_Ant1_2480 3DH5_Ant1_2402 Page 12 of 61 FCC ID: 2A8O6-EWIL1 Report No.: LCSA01244108EA Shenzhen LCS Compliance Testing Laboratory Ltd. Add: 101, 201 Bldg A & 301 Bldg C, Juji Industrial Park Yabianxueziwei, Shajing Street, Baoan District, Shenzhen, 518000, China Tel: +(86) 0755-82591330 | E-mail: [email protected] | Web: www.lcs-cert.com Scan code to check authenticity 3DH5_Ant1_2441 3DH5_Ant1_2480 Page 13 of 61 FCC ID: 2A8O6-EWIL1 Report No.: LCSA01244108EA Shenzhen LCS Compliance Testing Laboratory Ltd. Add: 101, 201 Bldg A & 301 Bldg C, Juji Industrial Park Yabianxueziwei, Shajing Street, Baoan District, Shenzhen, 518000, China Tel: +(86) 0755-82591330 | E-mail: [email protected] | Web: www.lcs-cert.com Scan code to check authenticity Page 14 of 61 FCC ID: 2A8O6-EWIL1 Report No.: LC…

Text truncated - open the document above for the full version.

Page 41 of 61 FCC ID: 2A8O6-EWIL1 Report No.: LCSA01244108EA Shenzhen LCS Compliance Testing Laboratory Ltd. Add: 101, 201 Bldg A & 301 Bldg C, Juji Industrial Park Yabianxueziwei, Shajing Street, Baoan District, Shenzhen, 518000, China Tel: +(86) 0755-82591330 | E-mail: [email protected] | Web: www.lcs-cert.com Scan code to check authenticity 2DH5_Ant1_2402 2DH5_Ant1_2441 Page 42 of 61 FCC ID: 2A8O6-EWIL1 Report No.: LCSA01244108EA Shenzhen LCS Compliance Testing Laboratory Ltd. Add: 101, 201 Bldg A & 301 Bldg C, Juji Industrial Park Yabianxueziwei, Shajing Street, Baoan District, Shenzhen, 518000, China Tel: +(86) 0755-82591330 | E-mail: [email protected] | Web: www.lcs-cert.com Scan code to check authenticity 2DH5_Ant1_2480 3DH5_Ant1_2402 Page 43 of 61 FCC ID: 2A8O6-EWIL1 Report No.: LCSA01244108EA Shenzhen LCS Compliance Testing Laboratory Ltd. Add: 101, 201 Bldg A & 301 Bldg C, Juji Industrial Park Yabianxueziwei, Shajing Street, Baoan District, Shenzhen, 518000, China Tel: +(86) 0755-82591330 | E-mail: [email protected] | Web: www.lcs-cert.com Scan code to check authenticity 3DH5_Ant1_2441 3DH5_Ant1_2480 Page 44 of 61 FCC ID: 2A8O6-EWIL1 Report No.: LCSA01244108EA Shenzhen LCS Compliance Testing Laboratory Ltd. Add: 101, 201 Bldg A & 301 Bldg C, Juji Industrial Park Yabianxueziwei, Shajing Street, Baoan District, Shenzhen, 518000, China Tel: +(86) 0755-82591330 | E-mail: [email protected] | Web: www.lcs-cert.com Scan code to check authenticity Page 45 of 61 FCC ID: 2A8O6-EWIL1 Report No.: LCSA01244108EA Shenzhen LCS Compliance Testing Laboratory Ltd. Add: 101, 201 Bldg A & 301 Bldg C, Juji Industrial Park Yabianxueziwei, Shajing Street, Baoan District, Shenzhen, 518000, China Tel: +(86) 0755-82591330 | E-mail: [email protected] | Web: www.lcs-cert.com Scan code to check authenticity A.8 Duty Cycle Test Result TestMode Antenna Frequency[MH z] ON Time [ms] Period [ms] Duty Cycle [%] Duty Cycle Factor[dB] 1/T Factor[kHz] DH5 Ant1 2402 2.91 3.75 77.60 1.10 0.34 2441 2.91 3.75 77.60 1.10 0.34 2480 2.91 3.75 77.60 1.10 0.34 2DH5 Ant1 2402 2.90 3.75 77.33 1.12 0.34 2441 2.90 3.75 77.33 1.12 0.34 2480 2.89 3.75 77.07 1.13 0.35 3DH5 Ant1 2402 2.90 3.75 77.33 1.12 0.34 2441 2.90 3.75 77.33 1.12 0.34 2480 2.90 3.75 77.33 1.12 0.34 Page 46 of 61 FCC ID: 2A8O6-EWIL1 Report No.: LCSA01244108EA Shenzhen LCS Compliance Testin…
