2A8OG-VM-M300SMagnito Mouse

Please be advised that change s o r modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment

Ventron 59, Wonpogongwon 1-ro, Danwon-gu, Ansan-si, Gyeonggi-do, Republic of Korea Timco Engineering, Inc. 849 N.W. State Road 45 P.O. Box 370 Newberry, Florida 32669 USA Date: 05/12/2022 RE: Request of Confidentiality for FCC ID: 2A8OG-VM-M300S Pursuant to Sections 0.457 and 0.459 of the Commission’s Rules(CFR 47), and Section 552 (b) (4) of the Freedom of Information materials Act, we, Ventaron, hereby requests confidentiality and treatment of certain information accompanying this application. The materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these matters might be harmful to the applicant and provide unjustified benefits to its competitors. We are also hereby Short-Term Confidentiality for 180days after the grant as outlined in Public Notice DA 04-1705 2004 of the Commission’s public notice. This provision will give Ventaron temporary confidentiality of commercially sensitive information prior to product release. The requested permanent and Short-Term confidential exhibits are listed as follows: Permanent & Short-Term Confidential List Permanent Block Diagram Schematics Parts List Operational Description Short-Term (180days after the grant) User’s Manual Internal Photos The applicant understands that pursuant to Section 0.457 of the Rules, disclosure of this application and all accompanying documentations, where applicable, will not be public before the date of the Grant for this application. Sincerely, SangMin Shin CEO of Ventaron

Ventron 59, Wonpogongwon 1-ro, Danwon-gu, Ansan-si, Gyeonggi-do, Republic of Korea Date: 30/11/2022 Timco Engineering, Inc. 849 N.W. State Road 45 P.O. Box 370 Newberry, Florida 32669 USA Letter of Authorization We, the undersigned, hereby authorize Erin Kim from JNM Korea Co., Ltd to act on our behalf in all manners relating to application for equipment authorization for FCC ID: 2A8OG-VM-M300S including signing of all documents relating to these matters. Any and all acts carried out by Erin Kim from JNM Korea Co., Ltd on our behalf shall have the same affect as acts of our own. This authorization is valid until further written notice from Ventaron. “I, the undersigned, hereby certify that we are not subject to a denial of federal benefits, that includes FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C. 853(a).” Sincerely, SangMin Shin CEO of Ventaron

Top View Bottom View Front View Rear View Right Side View Left Side View

VM-M300S VM-M300S VM-M300S Pattern Antenna

시 점 확 인 필 정 부 시 점 확 인 센 터 진본 2022-11-15 09:11:03 KST 페이지(page) : ( 2 )/( 총(Total) 6 ) ICRT-QPA-17-03 Rev.2 Report No. ICRT-TR-E222692-0A Contents 1. Applicant & Manufacturer & Test Laboratory Information .................................................................................. 4 1.1 Applicant information ........................................................................................................................................ 4 1.2 Manufacturer Information ................................................................................................................................. 4 1.3 Test Laboratory Information ............................................................................................................................ 4 2. Equipment under Test(EUT) Information ................................................................................................................. 5 2.1 General Information ........................................................................................................................................... 5 2.2 Additional Information ...................................................................................................................................... 5 2.3 Mode of operation during the test .................................................................................................................. 5 2.4 Modifications of EUT ......................................................................................................................................... 5 3. Maximum Permissible Exposure ............................................................................................................................... 6 3.1 RF Exposure calculation .................................................................................................................................. 6 3.2 Result ..................................................................................................................................................................... 7 페이지(page) : ( 3 )/( 총(Total) 6 ) ICRT-QPA-17-03 Rev.2 Report No. ICRT-TR-E222692-0A Revision History Issued Report No. Issued Date Revisions Effect Section ICRT-TR-E222692-0A 2022-11-02 Initial Issue All 페이지(page) : ( 4 )/( 총(Total) 6 ) ICRT-QPA-17-03 Rev.2 Report No. ICRT-TR-E222692-0A 1. Applicant & Manufacturer & Test Laboratory Information 1.1 Applicant information Applicant ventaron Address 59, Wonpogongwon 1-ro, Danwon-gu, Ansan-si, Gyeonggi-do, Republic of Korea Contact Person SANGMIN SHIN Telephone No. 82-10-9830-7786 Fax No. - E-mail [email protected] 1.2 Manufacturer Information Manufacturer Dongguan Lingjie Electronics & Technology Co., Ltd Address No.23, ZhenXing North Road, TeiYuan Community, XieGang Town, DongGuan City GuangDong province, China 1.3 Test Laboratory Information Conducted tests were performed at Laboratory ICR Co., Ltd. Address 112, Hwanggeum 3-ro 7beon-gil, Hagun-ri, Yangchon-eup, Gimpo-si, Gyeonggi- do, Korea Telephone No. +82-2-6351-9002 Fax No. +82-2-6351-9007 RRA No. KR0165 KOLAS No. KT652 페이지(page) : ( 5 )/( 총(Total) 6 ) ICRT-QPA-17-03 Rev.2 Report No. ICRT-TR-E222692-0A 2. Equipment under Test(EUT) Information 2.1 General Information Product Name Magnito Mouse Brand Name - Model Name VM-M300S Additional Model Name VM-M300W, VM-M300G, VM-M300P, VM-300B FCC ID 2A8OG-VM-M300S Power Supply DC 3.0 V 2.2 Additional Information Equipment Class DSS - Frequency Hopping Spread Spectrum system DTS - Digital Transmission System Device Type Stand-alone Operating Frequency 2 402 ㎒ ~ 2 480 ㎒ RF Output Power DSS : Bluetooth BDR -7.04 ㏈m DTS : Bluetooth LE -6.96 ㏈m Number of Channel DSS : Bluetooth BDR 79 DTS : Bluetooth LE 40 Modulation Type GFSK Antenna Type PCB Antenna Antenna Gain 2.34 ㏈i Antenna Operating Mode Single Antenna Equipment with only one antenna 2.3 Mode of operation during the test - The EUT is continuous transmission mode during the test with set at Low Channel, Middle Channel, and High Channel. To get a maximum radiated emission levels from the EUT, the EUT was moved throughout the XY, YZ, XZ planes. 2.4 Modifications of EUT - None 페이지(page) : ( 6 )/( 총(Total) 6 ) ICRT-QPA-17-03 Rev.2 Report No. ICRT-TR-E222692-0A 3. Maximum Permissible Exposure 3.1 RF Exposure calculation According to the FCC rule §1.1310 the limit for General Population/Uncontrolled exposure is 1 ㎽/㎠ for the device operating 1 500 ㎒ ~ 100 000 ㎒. Kind of EUT WIRELESS MOUSE Operating Frequency Band □ WLAN(802.11b/g/n(HT20)): 2 412 ㎒ ~ 2 462 ㎒ □ WLAN(802.11n(HT40)): 2 422 ㎒ ~ 2 452 ㎒ □ WLAN: 5 180 ㎒ ~ 5 320 ㎒ / 5 500 ㎒ ~ 5 700 ㎒ □ WLAN: 5 745 ㎒ ~ 5 825 ㎒ ■ Bluetooth: 2 402 ㎒ ~ 2 480 ㎒ Max. Output Power DSS : Bluetooth BDR -7.04 ㏈m DTS : Bluetooth LE -6.96 ㏈m Exposure Evaluation Applied □ MPE □ SAR ■ N/A 페이지(page) : ( 7 )/( 총(Total) 6 ) ICRT-QPA-17-03 Rev.2 Report No. ICRT-TR-E222692-0A 3.2 Result According to above equation, the following result was obtained. Operating Mode Target Power W / tolerance Max tune up power Antenna Gain Safe Distance (㎝) Power Density (㎽/㎝²) @ 20 ㎝ Separation Limit (㎽/㎝²) (㏈m) (㎽) Log Linear Bluetooth BDR -7.04 ± 1.0 -6.04 0.249 2.34 1.71 0.185 0.000 08 1.00 Bluetooth LE -6.96 ± 1.0 -5.96 0.254 0.187 0.000 09 According to above table, for Bluetooth BDR safe distance, D = 0.282 * √ (0.249 * 1.71)/1.00 = 0.185 ㎝. For getting power density at 20 ㎝ separation in above table, following formula was used. S = P * G / (4π * R²) = 0.249 * 1.71 / (4 * π * 20^2) = 0.000 08 Where: S = Power Density, P = Power input to the external antenna (Output power from the EUT antenna port (㏈m) – cable loss (㏈)), G = Gain of Transmit Antenna (linear gain), R = Distance from Transmitting Antenna - END -

시 점 확 인 필 정 부 시 점 확 인 센 터 진본 2022-11-15 09:09:52 KST 페이지(page) : ( 2 )/( 총(Total) 34 ) ICRT-QPA-17-03 Rev.2 Report No. ICRT-TR-E222690-0A Contents 1. Applicant & Manufacturer & Test Laboratory Information .................................................................................. 4 1.1 Applicant information ........................................................................................................................................ 4 1.2 Manufacturer Information ................................................................................................................................. 4 1.3 Test Laboratory Information ............................................................................................................................ 4 2. Equipment under Test(EUT) Information ................................................................................................................. 5 2.1 General Information ........................................................................................................................................... 5 2.2 Additional Information ...................................................................................................................................... 5 2.3 Mode of operation during the test .................................................................................................................. 5 2.4 Modifications of EUT ......................................................................................................................................... 5 3. Test Summary ................................................................................................................................................................. 6 3.1 Test standards and results .............................................................................................................................. 6 3.2 Purpose of the test ............................................................................................................................................. 6 3.3 Test Methodology ............................................................................................................................................... 6 3.4 Configuration of Test System ......................................................................................................................... 6 3.5 Antenna requirement ......................................................................................................................................... 7 4. Used equipment on test ............................................................................................................................................... 8 5. 6 ㏈ Bandwidth .............................................................................................................................................................. 9 5.1 Operating environment ..................................................................................................................................... 9 5.2 Measurement method ........................................................................................................................................ 9 5.3 Limit ....................................................................................................................................................................... 9 5.4 Test data ............................................................................................................................................................... 9 6. Maximum Conducted Output Power ....................................................................................................................... 12 6.1 Operating environment ................................................................................................................................... 12 6.2 Measurement method ...................................................................................................................................... 12 6.3 Limit ..................................................................................................................................................................... 12 6.4 Test data ............................................................................................................................................................. 12 7. Power Spectral Density .............................................................................................................................................. 15 7.1 Operating environment ................................................................................................................................... 15 7.2 Measurement method ...................................................................................................................................... 15 7.3 Limit ..................................................................................................................................................................... 15 7.4 Test data ............................................................................................................................................................. 15 8. Conducted Spurious Emission ................................................................................................................................ 18 8.1 Operating environment ................................................................................................................................... 18 8.2 Measurement method ...................................................................................................................................... 18 8.3 Limit ..................................................................................................................................................................... 18 8.4 Test data .................................…

Text truncated - open the document above for the full version.

Antenna Specification Specifications Summary ITEMSPEC. $QWHQQD7\SH3&%$QWHQQD Center Frequency 2402 MHz 2441 MHz 2480 MHz 2.34 dBi 2.07dBi 1.45 dBi MAX. GAIN2.34 dBi PolarizationHorizontal Azimuth Beam Pattern Omni-directional Impedance50Ÿ Antenna Length3.1cm Antenna Photo & Length (mm) Test Address 16 Tzu Chiang Road, Hsinchu Industrial District Hsinchu Hsien 303, Taiwan Test Date2009-04-14 Test Instrument vector network analyzer - R&S ZVB20 1. Main antenna : 2402 MHz 1.1 Horizontal Frequency(MHZ):2402Antenna Polarity:Horizontal Maximum Value(dBi):2. 34 Average Gain(dBi) :-2.48 Minimum Gain(dBi):-55.18 1.2 Vertical Frequency(MHZ):2402Antenna Polarity:Vertical Maximum Value(dBi):-4.51 Average Gain(dBi) :-8.98 Minimum Gain(dBi):-62.3 2. Main antenna : 2441 MHz 2.1 Horizontal Frequency(MHZ):2441Antenna Polarity:Horizontal Maximum Value(dBi): 2.07 Average Gain(dBi) :-2.54 Minimum Gain(dBi):-66.98 2.2 Vertical Frequency(MHZ):2441Antenna Polarity:Vertical Maximum Value(dBi):-4.29 Average Gain(dBi) :-8.81 Minimum Gain(dBi):-51.4 2. Main antenna : 2480 MHz 2.1 Horizontal Frequency(MHZ):2480Antenna Polarity:Horizontal Maximum Value(dBi):1.45 Average Gain(dBi) :-3.34 Minimum Gain(dBi):-53.4 2.2 Vertical Frequency(MHZ):2480Antenna Polarity:Vertical Maximum Value(dBi):-4.95 Average Gain(dBi) :-9.06 Minimum Gain(dBi):-60.00
