2A8P6-FKS934MOVT FKS934
Festina Lotus SA
Click to zoom
Application Details
- Equipment Class
- DTS - Digital Transmission System
- Date of Grant
- Aug 01, 2023
- Application Purpose
- Original Equipment
- Date of Application
- Aug 01, 2023
- Equipment Note
- MOVT FKS934
- Frequency Range
- 2402.00000000 - 2480.00000000
- Company
- Festina Lotus SA
- Country
- Spain
Documents & Files
Document Text
Text extracted from the exhibit documents filed with the FCC. Open a document above to read the original.
Users Manual
MOVT FKS934 FKS934 QUICK GUIDE Welcome to the Festina Connected family. We are delighted to introduce you to a new era of watchmaking. Please allow us to share some important information with you. ESP Le damos la bienvenida a la familia Festina Connected. Estamos encantados de introducirle en una nueva era en la fabricación de relojes. Permítanos compartir con usted información importante. FRA Bienvenue dans la famille Festina Connected. Nous sommes heureux de vous faire entrer dans la nouvelle ère de l'horlogerie. Nous allons vous donner quelques informations importantes. GER Willkommen in der Welt von Festina Connected. Wir freuen uns, Ihnen eine neue Generation von Uhren vorstellen zu dürfen. Hier sind einige wichtige Informationen für Sie. ITA Benvenuti nella famiglia Festina Connected. Siamo lieti di presentarvi una nuova era dell'orologeria e di condividere con voi alcune importanti informazioni. ENGLISH To get started with your watch you need to pair it with your phone. 1. Download the app from Google Play or App store. Scan the code with your phone 2. Open the app. Press and hold the crown on the watch to start pairing process. Do not try to connect your watch via Bluetooth in the phone settings. ENGLISH Manual More information about the product is available in the Festina Connected app and on the product webpage. Charging To charge the watch, place the watch in the charging dock as shown in the illustration. You will receive a notification in your watch when it’s time to charge the watch. The watch has a battery life of up to 10 days. Important information Do not disassemble the watch, there are no serviceable parts inside the watch. Do not allow small children to play with the device as small parts may come loose and pose a choking haz- ard. Do not use this transmitting device near sensitive medical equipment without requesting permission. If you have electronic medical implants, do not use this device without consulting medical expertise first. This product is not a medical device and should not be used to diagnose or treat medical conditions. All content provided herein is for information purposes only and is not intended to be a substitute for professional medical advice. Always seek the advice of your physician or other qualified health care provider before starting a new exercise program or diet and never disregard professional medical advice or delay in seeking it because of something you have read on any of our apps or material. This product is licensed under patents owned by CSEM Switzerland. Batteries, WARNING This watch uses a lithium-ion rechargeable battery. Do not remove or replace the battery. Risk of fire and burns. Do not disassemble, heat above 55°C or incinerate. Keep battery out of reach of children. Never put batteries in mouth. Swallowing may lead to serious injury or death. If ingested, immediately seek medical attention. Radio frequency exposure Your Festina Connected device is equipped with a radio transmitter and receiver of Bluetooth™ Low Energy type, operating in the frequency range 2400 to 2500 MHz. Its radiated output power is far below exposure limits set by national authorities such as the FCC, IC, European Council and international health agencies. Waste Electrical and Electronic Equipment, WEEE Directive 2012/19/EU This product must not be disposed of with household waste but through an authorised WEEE collection point. The symbol on the product or its packaging indicates that this product must not be disposed of with your other household waste. Instead, it is your responsibility to dispose of your waste equipment by handing it over to a designated collection point for the recycling of waste electrical and electronic equipment. The separate collection and recycling of your waste equipment at the time of disposal will help conserve natural resources and ensure that it is recycled in a manner that protects human health and the environment. For more information about where you can drop off your waste for recycling, please contact your local authority, or where you purchased your product. Disposal of Batteries and Accumulators Directive 2066/66/EC When batteries are changed, they must be removed and taken to an approved collection facility. Separable batteries must be removed prior to the disposal of the product and disposed of separately EC Declaration of Conformity We, FESTINA LOTUS SA, of C/Velázquez nº 150, 3º 1ª 28002 Madrid (Spain) declare under our sole responsibility that our product Festina Connected watch of model MOVT FKS934 is in conformity to the essential requirements and other relevant requirements of the RE Directive 2014/53/EU: EN 62479:2010, EN 50663:2017, EN 62368-1:2014+A11:2017, EN 55032:2015+A1:2020, EN IEC 61000-3-2:2019+A1:2021, EN 61000-3-3:2013+A1:2019, EN 55035:2017+A11:2020, ETSI EN 301 489-1 V2.2.3:2019, ETSI EN 301 489-17 V3.2.4:2020, ETSI EN 300 328 V2.2.2:2019. RoHS Directive 2011/65/EU Annex II and its amendment (EU) 2015/863. REACH Regulation (EC) No.1907/2006. Barcelona, August 2023 Carlos Casas, Legal For full declaration of conformity, please go to https://festinagroup.com/certification/ FCC Declaration of Conformity FCC ID: 2A8P6-FKS934 This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. Any Changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment. Note: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates uses and can radiate radio frequency energy and, if not installed and used in a…
Text truncated - open the document above for the full version.
Attestation Statements
Rev1/26/2023 FestinaLotusSA FederalCommunicationsCommission AuthorizationandEvaluationDivision 7435OaklandMillsRoad Columbia,MD21046 USA Date:7-13-2023 Ref:AttestationStatementsPart2.911(d)(5)(i)Filing FCCID:2A8P6-FKS934 FestinaLotusSA("theapplicant")certifiesthattheequipmentforwhichauthorizationissoughtis not“covered”equipmentprohibitedfromreceivinganequipmentauthorizationpursuanttosection 2.903oftheFCCrules. Sincerely, (Applicantsignature) (Applicantprintedname)CarlosCasasDiaz/Legal Rev1/26/2023 FestinaLotusSA FederalCommunicationsCommission AuthorizationandEvaluationDivision 7435OaklandMillsRoad Columbia,MD21046 USA Date:7-13-2023 Ref:AttestationStatementsPart2.911(d)(5)(ii)Filing FCCID:2A8P6-FKS934 FestinaLotusSA(“theapplicant”)certifiesthat,asofthedateofthefilingoftheapplication,the applicantisnotidentifiedontheCoveredList(asaspecificallynamedentityoranyofitssubsidiariesor affiliates)asanentityproducing“covered”equipment. Sincerely, (Applicantsignature) (Applicantprintedname)CarlosCasasDiaz/Legal
Attestation Statements
Festina Lo Via Layeta China Date: 7‐ 1 Federal C Authoriza 7435 Oa Columbi a FCC ID: US Festina Lo service o Festina Lo less than importatio related ad FCC US the desi g for FCC I Designat Company FRN: 003 Address: Contact P Phone: 7 Email: Su Sincerely Company Company Diaz/Lega Signature otus SA ana, 20, 4 Bar 13‐2023 Communicat ation and Ev kland Mills R a, MD 21046 2A8P6-F S Agen otus SA certif of process on otus SA , acc n one year af on of the app dministrative Agent, LLC, gnated agent ID: 2A8P6-F ted Agent In y Name: FCC 33402884 3722 Illinoi s Person: Tim 708-571-3148 upport@FCC y, y: Festina Lot y Represent al e: [Signature rcelona, 0800 tions Comm valuation Div Road 6 KS934 t – Atte fies, that as o n our behalf f cepts to main fter either the plicable equi e or judicial p accepts as t for the purp FKS934. nformation: C US Agent, s Avenue, Sa Payne 8 CUSAgent.co tus SA ative: Car e] 03 Spain mission vision station of 6‐12‐2023 for FCC ID: 2 ntain an agen e grantee ha ipment within proceeding in of the date o pose of acce : , LLC aint Charles, om los Casas Statem , we have de 2A8P6-FKS9 nt of service as permanen n the U.S., o nvolving the of the filing o pting service , IL, 60174, U Designat Designat Signature ment / Pa esignated FC 934. of process i ntly terminate or the conclu equipment, of this applica e of process USA ted Agent: F ted Agent Re e: art 2.91 CC US Agen n the United ed all market sion of any C whichever is ation, the ob on behalf o f CC US Agen epresentativ 1(d)(7) nt, LLC to ac d States for n ting and Commission s later. ligation of b e f Festina Lotu nt, LLC e: Tim Payn cept no - eing us SA e
Cover Letter(s)
FestinaLotusSA Date:2023-7-13 To:FederalCommunicationsCommission 7435OaklandMillsRoad Columbia,MD FCCID:2A8P6-FKS934 ToWhomItMayConcern: ThisletteristoascertainthatFestinaLotusSA/ViaLayetana,20,4Barcelona,08003 Spain EUT：MOVTFKS934 MODELNo.:FKS934 HasbeentheunitsusedforconductingFCCcompliancetesting,theSDoCpartHavebe testedbyEMTEK(SHENZHEN)CO.,LTD. Ifyouhaveanyquestionorconcerns,pls.contactus. Sincerely, Client’ssignature ： Client’sname/title ： CarlosCasasDiaz/Legal Contactinformation/address:FestinaLotusSA/ViaLayetana,20,4Barcelona,08003Spain
Cover Letter(s)
Rev11/20/07 FestinaLotusSA FederalCommunicationsCommission AuthorizationandEvaluationDivision ConfidentialityRequestregardingapplicationforcertificationof FCCID: 2A8P6-FKS934 PursuanttoSections0.457and0.459oftheCommission’sRules,weherebyrequestconfidential treatmentofinformationaccompanyingthisapplicationasoutlinedbelow: ExhibitTypeFileName BlockDiagram, Schematics, OperationalDescription, BlockDiagram, Schematics, OperationalDescription, Theabovematerialscontaintradesecretsandproprietaryinformationnotcustomarilyreleasedto thepublic.Thepublicdisclosureofthesematerialsmaybeharmfultotheapplicantandprovide unjustifiedbenefitstoitscompetitors. Client’sname/title：CarlosCasasDiaz/Legal Contactinformation/address:FestinaLotusSA/ViaLayetana,20,4Barcelona,08003Spain
Cover Letter(s)
FestinaLotusSA FederalCommunicationsCommission AuthorizationandEvaluationDivision 1435OaklandMillsRoad Columbia,MD21046 Date:2023-7-13 SUBJECT:FCCApplicationforFCCID:2A8P6-FKS934 ToWhomItMayConcern: We,theundersigned,herebyauthorizeLisaWangatEMTEK(SHENZHEN)CO.,LTD.on ourbehalf,toapplytotheFederalCommunicationsCommissiononourequipment.Any andallactscarriedoutbyEMTEK(SHENZHEN)CO.,LTD.onourbehalfshallhavethe sameeffectasactsofourown. ThisistoadvisethatweareinfullcompliancewiththeAnti-DrugAbuseAct.We,the applicant,arenotsubjecttoadenialoffederalbenefitspursuanttoSection5301ofthe Anti-DrugActof1988,21USC853a,andnopartytotheapplicationissubjecttoadenial offederalbenefitspursuanttothatsection. Regards, Client’sname/title：CarlosCasasDiaz/Legal Contactinformation/address:FestinaLotusSA/ViaLayetana,20,4Barcelona,08003Spain
Cover Letter(s)
FestinaLotusSA FederalCommunicationsCommission AuthorizationandEvaluationDivision 1435OaklandMillsRoad Columbia,MD21046 Date:2023-7-13 SUBJECT:FCCApplicationforFCCID:2A8P6-FKS934 ProductName:MOVTFKS934 ModelNumber:FKS934 ToWhomItMayConcern: Becausethesizeofourproductisverysmall,itisimpracticaltolabelthesurfaceofthe product,andelectroniclabelcannotbeused.accordingtoFCCKDB784748D01 section3,wewillputtheproductlabelintheusermanualprovidedwiththeproductand ontheouterpackingbox. Regards, Client’sname/title：CarlosCasasDiaz/Legal Contactinformation/address:FestinaLotusSA/ViaLayetana,20,4Barcelona,08003Spain
Cover Letter(s)
FestinaLotusSA Date:2023-7-13 To:FederalCommunicationsCommission 7435OaklandMillsRoad Columbia,MD RE:ShortTermConfidentialityRequestFor FCCID:2A8P6-FKS934 ToWhomItMayConcern: Inaccordancewithsections0.457and0.459ofCFR47,FestinaLotusSA.requests short-termConfidentialityoffollowingsectionsofthisapplicationforaperiodof180 daysaftergrantisissued. Testsetupphotos Externalphotos Internalphotos User’smanual Thesedocumentscontaindetailedsystemandequipmentdescriptionsandrelated informationabouttheproduct,whichFestinaLotusSAconsiderstobeproprietary, confidential,andacustomdesignandotherwise,wouldnotreleasetothegeneralpublic. Sincethisdesignisabasisfromwhichfuturetechnologicalproductswillevolve,Festina LotusSAfeelsthatthisinformationwouldbeofbenefittoitscompetitors,andthatthe disclosureoftheinformationinthesedocumentswouldgiveourcompetitorsanunfair advantageinthemarket. Pleasecontactmeifthereisanyinformationyoumayneed. Sincerely, Client’sname/title：CarlosCasasDiaz/Legal Contactinformation/address:FestinaLotusSA/ViaLayetana,20,4Barcelona,08003 Spain
External Photos
EUTEXTERNALPHOTOGRAPHS ----------------Theend----------------
Internal Photos
EUT INTERNAL PHOTOGRAPHS Antenna
RF Exposure Info
FCCID:2A8P6-FKS934 Accordingto§15.247(i)and§1.1307(b)(1),systemsoperatingundertheprovisionsofthissection shallbeoperatedinamannerthatensuresthatthepublicisnotexposedtoradiofrequencyenergy levelinexcessoftheCommission’sguidelines. AccordingtoKDB447498D01GeneralRFExposureGuidanceV06 The1-gand10-gSARtestexclusionthresholdsfor100MHzto6GHzattestseparationdistances ≤50mmaredeterminedby: [(max.powerofchannel,includingtune-uptolerance,mW)/(min.testseparationdistance,mm)]* [ √ f(GHz)] ≤ 3.0for1-gSARand ≤ 7.5for10-gextremitySAR,where f(GHz)istheRFchanneltransmitfrequencyinGHz； PoweranddistanceareroundedtothenearestmWandmmbeforecalculation； Theresultisroundedtoonedecimalplaceforcomparison ； Thetestexclusionsareapplicableonlywhentheminimumtestseparationdistanceis≤50mm andfortransmissionfrequenciesbetween100MHzand6GHz.Whentheminimumtest separationdistanceis<5mm,adistanceof5mmisappliedtodetermineSARtestexclusion. Weuse5mmasseparationdistancetocalculate. Maximummeasuredtransmitterpower: BLE: TransmitFrequency (GHz) ModeMaxConducted Power(dBm) tuneupmaximum power(dBm) Result calculation 1-gSAR 2.402(1M)GFSK4.2950.9803 2.440(1M)GFSK4.4450.9883 2.480(1M)GFSK4.8250.9963 2.402(2M)GFSK4.4150.9803 2.440(2M)GFSK4.550.9883 2.480(2M)GFSK4.8650.9963 Conclusion: Forthemaxresult:0.988≤3.0for1-gSARextremitySAR,NoSARisrequired. Signature:Date:2023.7.26 NAMEANDTITLE(Pleaseprintortype):LisaWang/Manager COMPANY(Pleaseprintortype):ShenzhenEMTEKCo.,Ltd./Building69,MajialongIndustry Zone,NanshanDistrict,Shenzhen,Guangdong,China
Test Report
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`GHFCGSNHCBHS!HaNHCTCMbSAHN!R MGHKNHC M JHC \H CNGSH K cMV HG! C NM d CHSHIMABCDBC 01ef3=<84>g584h8g73 ! "#$%&'(&)*+,-&.( /0123456789:5;<9=>5?2@;<9=8@61A@B71?5? C@;2D?@7296 :@75 <5E7 B@;2D?@7296 :@75 FGGH IJHK JLM N OGIN PQ M RJS TNUV WTXI OYGNN "#Z%&'(&.[+\].-&.( ^5435?@71?5 N_ `142:27a Nbc Y d?5ee1?5 Q "#fg(h(&-&.( ijGkHHlRHmMk MRJ Rmn oRkHpH KRH MpkHpH KRH PQlMpkMqmMKMpHn mopmMk ijFMRJIkMSkM VKK lMmn mMGnkMR JVr pk qkm kKpm!Jk r MpkKpm!mn mM mM!K mMHk RRo MM pmMkqmHmM!K ijMJosnmMkmHHk RRo mHpPmkmMp JH !!K RnM!mK m M!k ijGkmHmHmMq Rmpm!kmH MJqmpMnk kH KRmM!K mMqmppmH! RHm!mp iNjGk mHmMq RmpPmklkHm M l!k lpm Mp q !" #$%&'()*+,-./'&01., 23456789:79;<=>?:7<9 @&'* AB CDEFGDHIDHJKL HA MLMN OPP/*QQ RM A H SS CTH SUG MH V.,0&W0Q X M EBMNDML Y*) Z[\[U][ ^_'&1) CM"MC MHE`"EMH CL a&,b-&W0b/*/ EMH cEG 232d8ef=7g:7<9<;hijklm n/.PbW0@&'* XoRp qG] %&'()*a.P*) qG] O,0*,,&%1r* s %*/1&)@.$ s O,0*,,&Yt(* uvH THHH Y*Q0+0*' RGB wHHH MHwu""MCMHCAw NM MH H x/*yb*,Wtz&,{* !X|I z*W*1}*P~&0* ! Y*Q0~&0* !] z*'&/ pDTH D"D C TME!LL !" #$%&'()**+),)-.+ #$/&'(0+12**3414455,++0*).+6(71+018-9 : ;"< ;=>? !" #$%&'()&'*+(' ,-./01212345365 789&:8;89&(&;<&(=>?@(8A?8;?A>$ BCDE FGGHIDF DI III III DI JIDFKFD"DF DI " III KHKLDIM GCDEFGGHIDF DIK JNO P Q LD DI I RST III LD DI""DFDIFU VVVS IL LOK FLHK"III K S N VVVSL P P!P J DI ILLDFDWDU ,-X/012Y4Z0623[42\ OMHIF DIU] KF EFHE LIMC KDK"MJ^BHCEDKMLCU S_`HKDI M DIFEHKDI" F"ab ILMPcdFI"DLIFEWEe KKMeILL HIF DIU f(&9gAh&;(8iA(j RST k III DIkL LD DI""DFDIFU k d !" #$#%&'()*(* +,+,-./012343567648 +,+,9./01:373 +,+,+;<2=>3?@466823>66@@=>=6A><3A:B3=A C46DE6A><FGHI JJ ./01 !KL!!KMMKKLL C46DE6A><FGHI JKM!LJ N63OP3=AF:Q= MJ L M K JM JK KL LM J JK R@@=>=6A><FS …
Text truncated - open the document above for the full version.
Test Report
ReportNo.ENS2302240168W00801RPage1of58Ver.1.0 TESTREPORT ProductName:MOVTFKS934 ModelNumber:FKS934 FCCID:2A8P6-FKS934 Preparedfor:FestinaLotusSA Address:ViaLayetana,20,4Barcelona,08003Spain Preparedby:EMTEK(SHENZHEN)CO.,LTD. Address:Building69,MajialongIndustryZone,NanshanDistrict, Shenzhen,Guangdong,China Tel:(0755)26954280 Fax:(0755)26954282 ReportNumber:ENS2302240168W00801R Date(s)ofTests:July1,2023toJuly8,2023 Dateofissue:July11,2023 $二维码$ ReportNo.ENS2302240168W00801RPage2of58Ver.1.0 TableofContents 1TESTRESULTCERTIFICATION.......................................................................................................3 2EUTTECHNICALDESCRIPTION.....................................................................................................5 3SUMMARYOFTESTRESULT..........................................................................................................6 4TESTMETHODOLOGY.....................................................................................................................7 4.1GENERALDESCRIPTIONOFAPPLIEDSTANDARDS............................................................7 4.2MEASUREMENTEQUIPMENTUSED.......................................................................................7 4.3DESCRIPTIONOFTESTMODES.............................................................................................9 5FACILITIESANDACCREDITATIONS.............................................................................................10 5.1FACILITIES................................................................................................................................10 5.2EQUIPMENT.............................................................................................................................10 5.3LABORATORYACCREDITATIONSANDLISTINGS................................................................10 6TESTSYSTEMUNCERTAINTY.......................................................................................................11 7SETUPOFEQUIPMENTUNDERTEST.........................................................................................12 7.1RADIOFREQUENCYTESTSETUP1.....................................................................................12 7.2RADIOFREQUENCYTESTSETUP2.....................................................................................12 7.3CONDUCTEDEMISSIONTESTSETUP.................................................................................15 7.4BLOCKDIAGRAMCONFIGURATIONOFTESTSYSTEM.....................................................16 7.5SUPPORTEQUIPMENT...........................................................................................................16 8TESTREQUIREMENTS...................................................................................................................17 8.1DTS6DBBANDWIDTH............................................................................................................17 8.2DTS99%BANDWIDTH............................................................................................................20 8.3MAXIMUMPEAKCONDUCTEDOUTPUTPOWER................................................................23 8.4MAXIMUMPOWERSPECTRALDENSITY..............................................................................27 8.5UNWANTEDEMISSIONSINNON-RESTRICTEDFREQUENCYBANDS.............................30 8.6RADIATEDSPURIOUSEMISSION..........................................................................................43 8.7CONDUCTEDEMISSIONSTEST............................................................................................55 8.8ANTENNAAPPLICATION.........................................................................................................58 ReportNo.ENS2302240168W00801RPage3of58Ver.1.0 1TESTRESULTCERTIFICATION Applicant: FestinaLotusSA Address: ViaLayetana,20,4Barcelona,08003Spain Manufacturer: FestinaLotusSA Address: ViaLayetana,20,4Barcelona,08003Spain EUT:MOVTFKS934 ModelName:FKS934 Trademark:Kronaby,Jaguar,Lotus,Festina MeasurementProcedureUsed: APPLICABLESTANDARDS STANDARDTESTRESULT FCC47CFRPart2,SubpartJ FCC47CFRPart15,SubpartC PASS ICRSS-GEN,Issue5(04-2018)+A1(03-2019)+A2(02-2021) ICRSS-247Issue2(02-2017) PASS TheaboveequipmentwastestedbyEMTEK(SHENZHEN)CO.,LTD.Thetestdata,dataevaluation,test procedures,andequipmentconfigurationsshowninthisreportweremadeinaccordancewiththe proceduresgiveninANSIC63.10(2013)andtheenergyemittedbythesampleEUTtestedasdescribed inthisreportisincompliancewiththerequirementsofFCCRulesPart2,Part15.247,ICRSS-247Issue 2andICRSS-GEN,Issue5. Thetestresultsofthisreportrelateonlytothetestedsampleidentifiedinthisreport. DateofTest:July1,2023toJuly8,2023 Preparedby: UnaYu/Editor Reviewer: JoeXia/ Supervisor Approve&AuthorizedSigner:LisaWang/Manager ReportNo.ENS2302240168W00801RPage4of58Ver.1.0 ModifiedHistory VersionReportNo.RevisionDateSummary Ver.1.0ENS2302240168W00801R/OriginalReport ReportNo.ENS2302240168W00801RPage5of58Ver.1.0 2EUTTECHNICALDESCRIPTION Characteristics Description Product: MOVTFKS934 ModelNumber: FKS934 Samplenumber:2# DeviceType： BluetoothV5.3 DataRate:1Mbps,2Mbps Modulation:GFSK OperatingFrequencyRange:2402-2480MHz NumberofChannels:40Channels TransmitPowerMax:4.86dBm AntennaType:InternalAntenna AntennaGain:-13.75dBi PowerSupply: Working:DC3.7VfromInternalbattery Charging:DC5Vfromadapter TestVoltage:DC5Vfromadapter,DC3.7V DateofReceived: July1,2023 TemperatureRange:5°C~+45°C Note:formoredetails,pleaserefertotheUser’smanualoftheEUT. ReportNo.ENS2302240168W00801RPage6of58Ver.1.0 3SUMMARYOFTESTRESULT FCC PartClause ICPart Clause TestParameterVerdictRemark 15.247(a)(2) RSS-247,5.2(a) RSS-Gen6.7 EmissionBandwidthPASS 15.247(b)(3) RSS-247,5.4(d) RSS-Gen6.12 MaximumPeakConductedOutput Power PASS 15.247(e) RSS-247,5.2(b) RSS-Gen6.12 MaximumPowerSpectralDensity Level PASS 15.247(d)RSS-247,5.5 UnwantedEmissionInto Non-RestrictedFrequencyBands PASS 15.247(d)RSS-247,5.5 UnwantedEmissionIntoRestricted FrequencyBands(c…
Text truncated - open the document above for the full version.
Test Report
ReportNo.ENS2302240168W00801RPage41of58Ver.1.0 BLE_2M_Ant1_2402_30~1000 BLE_2M_Ant1_2402_1000~26500 BLE_2M_Ant1_2440_30~1000 ReportNo.ENS2302240168W00801RPage42of58Ver.1.0 BLE_2M_Ant1_2440_1000~26500 BLE_2M_Ant1_2480_30~1000 BLE_2M_Ant1_2480_1000~26500 ReportNo.ENS2302240168W00801RPage43of58Ver.1.0 8.6RADIATEDSPURIOUSEMISSION 8.6.1ApplicableStandard AccordingtoFCCPart15.247(d),15.205,15.209andKDB558074D0115.247MeasGuidancev05r02 AccordingtoICRSS-GenandRSS-247 8.6.2ConformanceLimit AccordingtoFCCPart15.247(d):radiatedemissionswhichfallintherestrictedbands,asdefinedin §15.205(a),mustalsocomplywiththeradiatedemissionlimitsspecifiedin§15.209(a)(see§15.205(c)). AccordingtoFCCPart15.205,Restrictedbands MHzMHzMHzGHz 0.090-0.11016.42-16.423399.9-4104.5-5.15 10.495-0.50516.69475-16.69525608-6145.35-5.46 2.1735-2.190516.80425-16.80475960-12407.25-7.75 4.125-4.12825.5-25.671300-14278.025-8.5 4.17725-4.1777537.5-38.251435-1626.59.0-9.2 4.20725-4.2077573-74.61645.5-1646.59.3-9.5 6.215-6.21874.8-75.21660-171010.6-12.7 6.26775-6.26825123-1382200-230014.47-14.5 8.291-8.294149.9-150.052310-239015.35-16.2 8.362-8.366156.52475-156.525252483.5-250017.7-21.4 8.37625-8.38675156.7-156.92690-290022.01-23.12 8.41425-8.41475162.0125-167.173260-326723.6-24.0 12.29-12.293167.72-173.23332-333931.2-31.8 12.51975-12.52025240-2853345.8-335836.43-36.5 12.57675-12.57725322-335.43600-4400(2) 13.36-13.41 AccordingtoFCCPart15.205,thelevelofanytransmitterspuriousemissioninRestrictedbandsshallnot exceedtheleveloftheemissionspecifiedinthefollowingtable Restricted Frequency(MHz) FieldStrength(μV/m)FieldStrength (dBμV/m) Measurement Distance 0.009-0.4902400/F(KHz)20log(uV/m)300 0.490-1.70524000/F(KHz)20log(uV/m)30 1.705-303029.530 30-88100403 88-21615043.53 216-960200463 Above960500543 8.6.3TestConfiguration Testaccordingtoclause7.2radiofrequencytestsetup2 8.6.4TestProcedure ThistestisrequiredforanyspuriousemissionthatfallsinaRestrictedBand,asdefinedinSection 15.205.Itmustbeperformedwiththehighestgainofeachtypeofantennaproposedforusewiththe EUT.Usethefollowingspectrumanalyzersettings: TheEUTwasplacedonaturntablewhichis0.8mabovegroundplane. MaximumprocedurewasperformedonthehighestemissionstoensureEUTcompliance. Span=wideenoughtofullycapturetheemissionbeingmeasured RBW=1MHzforf 1GHz(1GHzto25GHz),100kHzforf<1GHz(30MHzto1GHz) ReportNo.ENS2302240168W00801RPage44of58Ver.1.0 VBW RBW Sweep=auto Detectorfunction=peak Trace=maxhold FollowtheguidelinesinANSIC63.10-2013withrespecttomaximizingtheemissionbyrotatingtheEUT, measuringtheemissionwhiletheEUTissituatedinthreeorthogonalplanes(ifappropriate),adjusting themeasurementantennaheightandpolarization,etc.Apre-ampandahighpassfilterarerequired forthistest,inordertoprovidethemeasuringsystemwithsufficientsensitivity.Allowthetraceto stabilize.Thepeakreadingoftheemission,afterbeingcorrectedbytheantennafactor,cableloss, pre-ampgain,etc.,isthepeakfieldstrength,whichmustcomplywiththelimitspecifiedinSection 15.35(b).Submitthisdata. NowsettheVBWto10Hz,whilemaintainingalloftheotherinstrumentsettings.Thispeaklevel,once corrected,mustcomplywiththelimitspecifiedinSection15.209.Ifthedwelltimeperchannelofthe hoppingsignalislessthan100ms,thenthereadingobtainedwiththe10HzVBWmaybefurther adjustedbya“dutycyclecorrectionfactor”,derivedfrom20log(dwelltime/100ms),inaneffortto demonstratecompliancewiththe15.209limit.Submitthisdata. Repeataboveproceduresuntilallfrequencymeasuredwascomplete. 8.6.5TestResults Temperature: 22 ̊C RelativeHumidity: 43 ATMPressure:1011mbar SpuriousEmissionbelow30MHz(9KHzto30MHz) Freq. (MHz) Ant.Pol. Emission Level(dBuV/m) Limit3m(dBuV/m)Over(dB) H/VPKAVPKAVPKAV ---------------- Note:theamplitudeofspuriousemissionthatisattenuatedbymorethan20dBbelowthepermissible limithasnoneedtobereported. Distanceextrapolationfactor=40log(Specificdistance/testdistance)(dB); Limitline=Specificlimits(dBuV)+distanceextrapolationfactor ReportNo.ENS2302240168W00801RPage45o…
Text truncated - open the document above for the full version.
Contact Information
Applicant
Carlos Casas Diaz(Legal)
Test Firm
EMTEK (Shenzhen) Co., Ltd.Lisa Wang
[email protected]8675526954280
Technical Specifications
| # | Rule Parts | Frequency Range | Power Output |
|---|---|---|---|
| 1 | 15C | 2.40 GHz - 2.48 GHz | 3.06 mW |
