2A8QW-LKA15Portable Speakers

WWW.LOVEKARAOKEUSA.COM ©Love Karaoke USA Model: LKA15 PRO OWNER’S MANUAL 2 IMPORTANT SAFETY INSTRUCTIONS For all products: 1. Read these instructions. 2. Keep these instructions. 3. Heed all warnings. 4. Follow all instructions. 5. Do not use this apparatus near water. 6. Do not block any ventilation openings. Install this apparatus in accordance with the manufacturer’s instructions. 7. Do not install this apparatus near any heat sources such as radiators, heat registers, stoves, or other apparatus (including amplifiers) that produce heat. 8. Do not defeat the safety purpose of the polarized or grounding- type plug. A polarized plug has two blades with one wider than the other. A grounding-type plug has two blades and a third grounding prong. The wide blade or the third prong is provided for your safety. If the provided plug does not fit into your outlet, consult an electrician for the replacement of the obsolete outlet. 9. Protect the power cord from being walked on or pinched, particularly at plugs, convenience receptacles, and the point where they exit from the apparatus. 10. Use only attachments/accessories specified by the manufacturer. 11. Unplug this apparatus during lightning storms or when unused for long periods of time. 12. To disconnect this apparatus from the AC mains completely, disconnect the power-supply cord plug from the AC receptacle. 13. Use only with the cart, stand, tripod, bracket, or table specified by the manufacturer or sold with the apparatus. When a cart is used, use caution when moving the cart/apparatus combination to avoid injury from tip-over. 14. The mains plug of the power supply cord shall remain readily operable. 15. Do not expose batteries to excessive heat such as sunshine, Fire or the like. 16. This apparatus is intended to be used only with the power supply and/or charging cable provided by the manufacturer. 17. Refer all servicing to qualified service personnel. Servicing is required when the apparatus has been damaged in any way, such as power- supply cord or plug is damaged, liquid has been spilled or objects have fallen into the apparatus, the apparatus has been exposed to rain or moisture, does not operate normally, has been dropped, or is missing battery doors. 18. CAUTION: Permanent hearing loss may occur if earphones or headphones are used at high volume for prolonged periods of time. Note:To prevent possible hearing damage, do not listen to high volume levels for long periods. (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: • Reorient or relocate the receiving antenna. • Increase the separation between the equipment and receiver. • Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. • Consult the dealer or an experienced radio/TV technician for help. Caution: Changes or modifications not expressly approved by LK Love Karaoke could void the user’s authority to operate the equipment. For Products That Transmit RF Energy Operation is subject to the following two conditions: (1) This device may not cause harmful interference; and (2) this device must accept any interference received, including interference that may cause undesired operation. The Lightning flash with arrowhead symbol, with an equilateral triangle is intended to alert the user of the presence of uninsulated dangerous voltage within the product's enclosure that may be of sufficient magnitude to constitute a risk of electric shock to persons. CAUTION: TO REDUCE TH E RISK OF ELECTRIC SHOCK,DO NOT REMOVE COVER (OR BACK). NO USER SERVICEABLE PART S INSIDE. REFER SERVICING TO QUALIFIED SERVICE PERSONNEL The exclamation point within an equilateral triangle is intended to alert the user of the presence of important operating and maintenance (servicing) instructions in the literature accompanying the appliance. 3 This product must not be disposed of or dumped with your other household waste. You are liable to dispose of all your electronic or electrical waste equipment by relocating over to the specified collection point for the recycling of such hazardous waste. Isolated collection and proper recovery of your electronic and electrical waste equipment at the time of disposal will allow us to help conserve natural resources. Moreover, proper recycling, and collection points, please contact your local city center, household waste disposal service, shop from where you purchased the equipment or manufacturer of the equipment. Instructions for Users on Removal, Recycling, and Disposal of Batteries The remove the batteries from your equipment or remote control, reverse the procedure described in the owner’s manual for inserting batteries. For products with a built-in battery that lasts for the lifetime of the product, removal may not be possible for the user. In this case, recycling or recovery, it becomes necessary to replace such a battery; this procedure must be performed by authorized services centers. In the European Union and other locations, it is illegal to dispose of any battery with household trash. All batteries must be disposed of in an environmentally sound manner. Contact your local waste-management officials for information regarding the environmentally sound collec…

Text truncated - open the document above for the full version.

LOVE KARAOKE USA LLC 2.911 (d)(5)(i) Equipment Type Attestation v1.2 Section 2.911(d)(5)(i) Certification – Equipment Type Company name: LOVE KARAOKE USA LLC Address: 523 Sullivan Way, Mountain House, CA 95391, USA Product Name: Portable Speakers FCC ID: 2A8QW-LKA15 Model(s): LKA15 PRO,LKA15,LKR06,LKR08,LKR10,LKR12,LKR15,LKR17, LKR700,LKR800,LKR1000,LKR1500,LKBEST,LKLEGEND,LKSING, LKMASTER,LK2032, LKAUS,KARAOKE 2.911(d)(5)(i) Equipment Type We, [LOVE KARAOKE USA LLC] certify that the equipment for which authorization is sought through certification is not:  Prohibited from receiving an equipment authorization pursuant to § 2.903; of the FCC rules.  Identified as an equipment type in the “Covered List” NOTE 1 Yours sincerely, Name: Hoang Huynh Date: May.17,2023 Title and Company name: Managing Director / LOVE KARAOKE USA LLC NOTE 1 “Covered List”; is the List of Equipment and Services Covered By Section 2 of The Secure Networks Act, available at https://www.fcc.gov/supplychain/coveredlist References; 1) 986446 D01 Covered Equipment v01 https://apps.fcc.gov/oetcf/kdb/forms/FTSSearchResultPage.cfm?switch=P&id=325672 2) Federal Register document 2022-28263 published on 02/06/23 https://www.federalregister.gov/documents/2023/02/06/2022-28263/protecting-against-national-security-threats-to-the-com munications-supply-chain-through-the

LOVE KARAOKE USA LLC 2.911 (d)(5)(ii) Applicant Attestation v1.2 Section 2.911(d)(5)(ii) Certification – Applicant (Covered List ) Company name: LOVE KARAOKE USA LLC Address: 523 Sullivan Way, Mountain House, CA 95391, USA Product Name: Portable Speakers FCC ID: 2A8QW-LKA15 Model(s): LKA15 PRO,LKA15,LKR06,LKR08,LKR10,LKR12,LKR15,LKR17, LKR700,LKR800,LKR1000,LKR1500,LKBEST,LKLEGEND,LKSING, LKMASTER,LK2032, LKAUS,KARAOKE 2.911(d)(5)(ii) Applicant filing We, [LOVE KARAOKE USA LLC] certify that, as of the date of the filing of the application, the applicant is not identified NOTE 1 on the “Covered List” NOTE 2 , established pursuant to § 1.50002 of this chapter, as an entity producing covered communications equipment. Yours sincerely, Name: Hoang Huynh Date: May.17,2023 Title and Company name: Managing Director / Shenzhen Jackson Technology Co., Ltd. NOTE 1 Delete option not applicable to this application. NOTE 2 “Covered List”; is the List of Equipment and Services Covered By Section 2 of The Secure Networks Act, available at https://www.fcc.gov/supplychain/coveredlist References; 1) 986446 D01 Covered Equipment v01 https://apps.fcc.gov/oetcf/kdb/forms/FTSSearchResultPage.cfm?switch=P&id=325672 2) Federal Register document 2022-28263 published on 02/06/23 https://www.federalregister.gov/documents/2023/02/06/2022-28263/protecting-against-national-security-threats-to-the-com munications-supply-chain-through-the

LOVE KARAOKE USA LLC Agent Authorization Company: LOVE KARAOKE USA LLC Address: 523 Sullivan Way, Mountain House, CA 95391, USA Product Name: Portable Speakers Model Number(s): LKA15,LKR06,LKR08,LKR10,LKR12,LKR15,LKR17,LKR700,LKR800,LKR1000,LKR150 0,LKBEST,LKLEGEND,LKSING, LKMASTER,LK2032, LKAUS,KARAOKE,LKA15 PRO Product Description: Portable Speakers We authorize MiCOM Labs Inc., 575 Boulder Court, Pleasanton, California 94566, USA, to act on our behalf on all matters concerning the certification of above named equipment. We declare that MiCOM Labs Inc. is allowed to forward all information related to the approval and certification of equipment to the regulatory agencies as required and to discuss any issues concerning the approval application. Any and all acts carried out by MiCOM Labs on our behalf shall have the same effect as acts of our own. Signature: Date: May.17,2023 Name: Hoang Huynh Title: Managing Director Company: LOVE KARAOKE USA LLC

- Page 1 of 4 - ET-23040369 Product Name: Portable Speakers Model No.: LKA15 PRO Ext Photos - Page 2 of 4 - ET-23040369 - Page 3 of 4 - ET-23040369 - Page 4 of 4 - ET-23040369 -----END-----

Label size： 5mm *35mm FCC ID: 2A8QW-LKA15

- Page 1 of 8 - ET-23040369 Product Name: Portable Speakers Model No.: LKA15 PRO Internal photos - Page 2 of 8 - ET-23040369 - Page 3 of 8 - ET-23040369 - Page 4 of 8 - ET-23040369 - Page 5 of 8 - ET-23040369 BT ANT - Page 6 of 8 - ET-23040369 - Page 7 of 8 - ET-23040369 - Page 8 of 8 - ET-23040369 ------END-----

FCC ID: 2A8QW-LKA15 RF Exposure Evaluation Limits The criteria listed in the following table shall be used to evaluate the environment impact of human exposure to radio frequency (RF) radiation as specified in 1.1307(b) Limits for Maximum Permissible Exposure (MPE) Frequency range (MHz) Electric field strength (V/m) Magnetic field strength (A/m) Power density (mW/cm 2 ) Averaging time (minutes) (A) Limits for Occupational/Controlled Exposures 0.3–3.0 614 1.63 *(100) 6 3.0–30 1842/f 4.89/f *(900/f 2 ) 6 30–300 61.4 0.163 1.0 6 300–1500 f/300 6 1500–100,000 5 6 (B) Limits for General Population/Uncontrolled Exposure 0.3–1.34 614 1.63 *(100) 30 1.34–30 824/f 2.19/f *(180/f 2 ) 30 30–300 27.5 0.073 0.2 30 300–1500 f/1500 30 1500–100,000 1.0 30 f = frequency in MHz Friis transmission formula: Pd = (Pout*G)/(4*pi*r 2 ) Where Pd = power density in mW/cm 2 , Pout = output power to antenna in mW; G = gain of antenna in linear scale, Pi = 3.1416; R = distance between observation point and center of the radiator in cm Pd id the limit of MPE, 1 mW/cm 2 . If we know the maximum gain of the antenna and the total power input to the antenna, through the calculation, we will know the distance r where the MPE limit is reached. Test Procedure Software provided by client enabled the EUT to transmit and receive data at lowest, middle and highest channel individually. FCC ID: 2A8QW-LKA15 Test Result of RF Exposure Evaluation The source of the evaluation data results is based on the test report ET-23040369E01/02 BT Antenna gain=-0.58dBi FOR BLE Mode Output power (dBm) Output power (mW) Numeric antenna gain Power Density at R=20cm (mW/cm 2 ) Limit (mW/cm 2 ) Result GFSK 1.30 1.35 0.87 0.0002 1.0 PASS FOR BT Mode Output power (dBm) Output power (mW) Numeric antenna gain Power Density at R=20cm (mW/cm 2 ) Limit (mW/cm 2 ) Result GFSK 1.41 1.38 0.87 0.0002 1.0 PASS π/4-DQPSK 1.35 1.36 0.87 0.0002 1.0 PASS 8-DPSK 1.44 1.39 0.87 0.0002 1.0 PASS Then SAR evaluation is not require .

Report No.: ET-23040369E02 This test report is valid for the tested samples only. It cannot be reproduced except in full without prior written consent of Shenzhen ETR Standard Technology Co., Ltd. TEST REPORT Applicant: LOVE KARAOKE USA LLC Address of Applicant: 523 Sullivan Way, Mountain House, CA 95391, USA Manufacturer/Factory: LOVE KARAOKE USA LLC Address of Manufacturer/Factory: 523 Sullivan Way, Mountain House, CA 95391, USA Product Name: Portable Speakers Model No.: LKA15 PRO,LKA15,LKR06,LKR08,LKR10,LKR12,LKR15,LKR17, LKR700,LKR800,LKR1000,LKR1500,LKBEST,LKLEGEND,LKSING, LKMASTER,LK2032, LKAUS,KARAOKE Trade Mark: LK LOVE KARAOKE FCC ID: 2A8QW-LKA15 Applicable standards: FCC CFR Title 47 Part 15 Subpart C Section 15.247 Date of Test: Apr.23, 2023-Apr.27, 2023 Date of report issued: May 22, 2023 Test Result : PASS * * In the configuration tested, the EUT complied with the standards specified above. Remark: The results shown in this test report refer only to the sample(s) tested , this test report cannot be reproduced, except in full without prior written permission of the company. The report would be invalid without specific stamp of test institute and the signatures of compiler and approver Prepared By Shenzhen ETR Standard Technology Co., Ltd. Address: No.103, No.10, Phase I, Zone 3, Xinxing Industrial Park, Xinhe, Fuhai Street, Bao'an District, Shenzhen, Guangdong, China Compiled by: Reviewed by: Approved by: Project Engineer Project Manager Authorized Signature - Page 2 of 50 - Report No.: ET-23040369E02 Report Revision History Report No. Description Issue Date ET-23040369E02 Original May 22, 2023 - Page 3 of 50 - Report No.: ET-23040369E02 Tel:(86-755) 85259392 Email:[email protected] Web: www.etrlab.cn No.103, No.10, Phase I, Zone 3, Xinxing Industrial Park, Xinhe, Fuhai Street, Bao'an District, Shenzhen, Guangdong, China Contents Page 1 TEST SUMMARY ......................................................................................................................................4 2 GENERAL INFORMATION .......................................................................................................................5 2.1 GENERAL DESCRIPTION OF EUT ..........................................................................................................5 2.2 TEST MODE .........................................................................................................................................7 2.3 DESCRIPTION OF SUPPORT UNITS ........................................................................................................7 2.4 DEVIATION FROM STANDARDS ..............................................................................................................7 2.5 ABNORMALITIES FROM STANDARD CONDITIONS ....................................................................................7 2.6 TEST FACILITY.....................................................................................................................................7 2.7 TEST LOCATION...................................................................................................................................7 2.8 ADDITIONAL INSTRUCTIONS ..................................................................................................................7 3 TEST INSTRUMENTS LIST ......................................................................................................................8 4 TEST RESULTS AND MEASUREMENT DATA .......................................................................................9 4.1 ANTENNA REQUIREMENT ......................................................................................................................9 4.2 CONDUCTED EMISSIONS ....................................................................................................................10 4.3 CONDUCTED PEAK OUTPUT POWER ...................................................................................................13 4.4 20DB EMISSION BANDWIDTH ..............................................................................................................14 4.5 CARRIER FREQUENCIES SEPARATION .................................................................................................21 4.6 HOPPING CHANNEL NUMBER .............................................................................................................25 4.7 DWELL TIME ......................................................................................................................................27 4.8 BAND EDGE.......................................................................................................................................32 4.8.1 Conducted Emission Method ......................................................................................................32 4.8.2 Radiated Emission Method .........................................................................................................36 4.9 SPURIOUS EMISSION .........................................................................................................................38 4.9.1 Conducted Emission Method ......................................................................................................38 4.9.2 Radiated Emission Method .........................................................................................................42 5 TEST SETUP PHOTO .............................................................................................................................50 6 EUT CONSTRUCTIONAL DETAILS .......................................................................................................50 - Page 4 of 50 - Report No.: ET-23040369E02 Tel:(86-755) 85259392 Email:[email protected] Web: www.etrlab.cn No.103, No.10, Phase I, Zone 3, Xinxing Industrial Park, Xinhe, Fuhai Street, Bao'an District, Shenzhen, Guangdong, China 1 Test Summary Test Item Section in CFR 47 Result Test by A…

Text truncated - open the document above for the full version.

Inverted F Antenna Specification Summary ITEM ANT SPEC Model Name 2.4G ANT Horizontal Vertical 2400MHz 2400MHz2500MHz2400MHz2400MHz 2500MHz Center Frequency -1.26 -0.76 -0.58 -5.25 -2.46 -1.86 MAX. Gain -0.58dB Polarization Horizontal and Vertical Azimuth Beam Pattern Omni-directional Impedance 50 Ohm Antenna Length 38.20mm Manufacture ZHUHAI JIELI TECHNOLOGY CO.,LTD Antenna Photo & Length (mm) Horizontal: 2400 MHz 2450 MHz 2500 MHz Power (dBm) Max: 0 Min: -40 Scale: 5/div Gain(dB) Frequency (MHz) Max Min Avg 2400 -1.26174 -30.0801 -7.18716 2450 -0.765802 -36.5604 -7.48023 2500 -0.585582 -22.0315 -6.59127 Vertical: 2400 MHz 2450 MHz 2500 MHz Power (dBm) Max: 0 Min: -30 Scale: 5/div Gain(dB) Frequency (MHz) Max Min Avg 2400 -5.2537 -22.1424 -12.4294 2450 -2.4652 -24.5837 -10.4702 2500 -1.86120 -29.5214 -9.20432 ANT Test Labs：Attestation of Global Compliance Co., Ltd.

ET-23040369 Page 1 of 2 Product Name: Portable Speakers Model No.: LKA15 PRO Test Setup Photo Radiated emissions 30MHz to1GHz Above 1GHz ET-23040369 Page 2 of 2 Conducted Emission ------End------
