OperationManual Brand:Z-AiHour ProductName：SmartSensorLightsensor Model：ZAH-SENSOR-02N Powerswitch BatteryindicatorSoilsensingprobe Signalindicator Ambienttemperature&humiditysensor TechnicalParameters:  Temperaturemeasurementrange:-40~125°C;Accuracy:±0.3°C. Humiditymeasurementrange:0~100%RH;Accuracy:±3%RH. Illuminationmeasurementrange:0~60000Lux;Accuracy:lessthan1Lux. Carbondioxideconcentrationmeasurementrange:400~60000ppm;Accuracy:1ppm.  Soiltemperaturemeasurementrange:0~80°C;Accuracy:±0.5°C  Soilmoisturemeasurementrange:0~100%RH;Accuracy:±3%RH  SoilpHvaluemeasurementrange:3~10;Accuracy:±0.5 SoilEcvaluemeasurementrange:0~10000us/cm;Accuracy:±5%  Theremotelycontrolledoutputterminalcanconnecttoamaximumof750WACor150WDC  Supportconnectionswithdifferenttypesofsensorsandcommunicationmodules;Interfaceexpansion:UART,SPI,I 2 C,RS485  Protectiongrade:IP65;Waterproofplasticshell;Size:133mm×69mm×50mm  Operatingtemperature:-10~60°C  Transmissionpower:23dBm;Antennainterface:50ohm/SMA-K Transmitfrequencyband ： 433MHz/800MHz/900MHz  Inputchargingvoltage:DC12V;Powerinterface:DC005;Operatingcurrent:30mA Announcements Donotbendorbreaktheantenna,orplacethedeviceinanironcontainer.Keepthedeviceinanopenenvironment;otherwise,thedevice mayfailtoconnecttotheserver. Putthedeviceinadryenvironmenttopreventwatervaporfromaffectingthecircuitboardsinsidethedevice. Instructions 1.Powerswitchisonthesideofthedevice.Pressitoncetoturnonthepower.Iftheredindicatorlightsup,indicatingthatthepoweris connected.Pressitagaintoturnoffthepower. 2.Afterthepoweristurnedon,thedevicewillbeconnectedautomaticallytotheserver,andthenetworkindicatorwillflashbluelight.Itwill stopaftertheindicatorcontinuestoflashfor4-5seconds,indicatingthatnetworkissuccessfullyconnected.Iftheindicatorcontinuesto flashformorethan5seconds,thatmeansthenetworkconnectionfails.Considerplacingthedeviceinanopenplaceandthenrestartingthe devicetotrytoaccessthenetwork. 3.Whenpowersupplyisconnected,thebatteryindicatorisred.Ifthedeviceisfullycharged,thebatteryindicatorwillturntogreen. 4.Insertthesoilsensingprobeintothesoil. 5.Searchthesubscriptionof"Z-AiHour"onWeChat,andselectthecorrespondingprogramfromthesubscriptiontochecktheinformation data. FCC Requirement changesormodificationsnotexpresslyapprovedbythepartyresponsiblefor compliancecouldvoidtheuser’s authoritytooperatetheequipment. ThisdevicecomplieswithPart15oftheFCCRules.Operationissubjecttothe followingtwoconditions: (1)thisdevicemaynotcauseharmfulinterference,and (2)thisdevicemustacceptanyinterferencereceived,includinginterferencethat maycauseundesiredoperation. Note:Thisequipmenthasbeentestedandfoundtocomplywiththelimitsfora ClassBdigitaldevice,pursuanttoPart15oftheFCCRules.Theselimitsare designedtoprovidereasonableprotectionagainstharmfulinterferenceina residentialinstallation.Thisequipmentgenerates,uses,andcanradiateradio frequencyenergy,andif notinstalledandusedinaccordancewiththeinstructions, maycauseharmfulinterferencetoradiocommunications.However,thereisno guaranteethatinterferencewillnotoccurinaparticularinstallation.Ifthis equipmentdoescauseharmfulinterferencetoradioortelevisionreception,which canbedeterminedbyturningtheequipmentoffandon,theuserisencouragedto trytocorrecttheinterferencebyoneormoreofthefollowingmeasures: –Reorientorrelocatethereceivingantenna. –Increasetheseparationbetweentheequipmentandreceiver. –Connecttheequipmentintoanoutletona circuitdifferentfromthattowhichthe receiverisconnected. –Consultthedealeroranexperiencedradio/TVtechnicianforhelp.
