2A8U7-VLTR01Voltron20x BLE Device

Xcite ™ Z350, Xcite ™ Z380 ENOperator's manual2-35 ES-MXManual de usuario36-73 FR-CAManuel d’utilisation74-112 Contents Conformity certificates.............................................. 2 Introduction............................................................... 2 Safety........................................................................8 Operation................................................................ 14 Maintenance........................................................... 18 Troubleshooting...................................................... 26 Transportation, storage and disposal......................29 Technical data.........................................................31 Service....................................................................33 Registered trademarks............................................35 Conformity certificates USA requirements Labels are placed on the engine and/or in the engine compartment stating that the machine will fulfill the requirements. This is also applicable to special requirements for any of the states, (California emission rules etc.). Do not remove these labels. Certificates can also be supplied with the machine at delivery or written in the Engine manual. Take care of them as they are valuable documents. WARNING: Failure to follow cautious operating practices can result in dangerous injury to the operator or other persons. The owner must understand these instructions, and must let only approved persons who understand these instructions to operate the mower. Each person operating the mower must be of sound mind and body and must not be under the influence of mind altering substances. WARNING: Engine exhaust, some of its constituents, and certain vehicle components contain or emit chemicals known to the State of California to cause cancer and birth defects or other reproductive harm. WARNING: Battery posts, terminals and related accessories contain lead and lead compounds, chemicals known to the State of California to cause cancer and birth defects or other reproductive harm. Clean your hands after handling. WARNING: Engine exhaust and certain vehicle components contain or emit chemicals considered to cause cancer, birth defects, or other reproductive system damage. The engine exhaust contains carbon monoxide, which is an odorless, colorless, poisonous gas. Do not use the machine in enclosed spaces. When this product is worn out and no longer used, return it to the reseller or other party for recycling. To implement improvements, specifications and designs can be altered without prior notification. Use only original parts for repairs. The use of other parts voids the warranty. Do not modify or install non-standard equipment to the unit without consent from the manufacturer. Modifications to the unit may cause unsafe operations or damage the unit. Introduction Pre-delivery inspection and product numbers A pre-delivery inspection has been done of this product. Make sure that you receive a signed copy of the pre-delivery inspection document from your dealer. Service agent contact information: This operator’s manual is for product with product number / serial number: / Engine: Transmission: 21922 - 005 - 12.12.2022 The product numbers are found on the type plate. Refer to Product overview on page 3 for the location of the type plate. Product description This product is a ride-on lawn mower. The control levers let the operator steer the product and adjust the speed of the product. An hour meter shows how many hours the product has been used. Intended use The product is made to cut grass on open and level ground only. Do not use the product for other tasks. Product overview 5 6 6 11 2 3 1 17 4 789 10 16 3 13 14 12 15 1. Accessory rack 2. Fuel tank 3. Seat suspension adjustment 4. Cutting height adjustment 5. Left control lever with start/stop button 6. Tracking control 7. Parking brake pedal 8. Battery compartment cover 9. Seat adjustment lever 10. Deck lifting pedal 11. Right control lever with PTO button 12. Fuses 13. Control panel 14. Key switch with key 1922 - 005 - 12.12.20223 15. Type plate 16. Throttle control 17. Oil drain plug Control panel overview 6 123 5 4 8 9 7 1. Display 2. Key switch unlocked position 3. Key switch locked position 4. Key switch 5. Engine START/STOP button 6. ON/OFF button for the headlights 7. Down button 8. OK button 9. Up button To do selections on the display You can select between engine speed, session time, battery status and ambient temperature to show on the display during operation. Refer to Symbols on the control panel and display on page 7 for descriptions of the symbols. 1. Push the OK button on the control panel to open the menu structure. 2. Push the up and down buttons on the control panel until the correct symbol is selected. 3. Push the OK button and wait 5 seconds. The selected symbol shows on the display together with the current value. Message types There are 4 types of messages that can show on the display. A message is shown as a symbol or a combination of symbols. Message type Description Information message In the lower right corner of the dis- play. Shows an engaged function or that servicing is necessary. Caution message In the center of the display. Shows a condition that is not correct. Refer to Caution messages on the display on page 28. Warning message In the center of the display. A warn- ing triangle shows together with an additional symbol if there is a safety warning or the product is defective. Refer to Warning messages on the display on page 29 . Error mes- sage In the center of the display. A warn- ing triangle shows together with a number. The product cannot be operated until servicing is done. Speak to your Husqvarna servicing dealer. Steering controls The direction of the product is controlled by the 2 control levers. Refer to Product overview on page 3. The right control lever has a PTO (Power Take-Off) 41922 - 005 - 12.12.2022 button. The left control l…

Text truncated - open the document above for the full version.

Address Contact Registered office VAT no Husqvarna Consumer Outdoor Prod. N.A. Inc. Telephone: Charlotte, NC 0 8825 Statesville Rd Fax: Organization no Charlotte, NC 28269 20-3600732 United States www.husqvarna.com Authority to Act as Agent Date: October 24, 2022 American Certification Body, Inc. 313 Park Avenue Suite 300 Falls Church, VA 22046 To Whom It May Concern: Ryan Urness and Amanda Hauck of Laird Connectivity, LLC are authorized to act on our behalf, until otherwise notified, for applications to American Certification Body, Inc. (ACB). We certify that we are not subject to denial of federal benefits, that includes FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C. 862. Further, no party, as defined in 47 CFR 1.2002 (b), to the application is subject to denial of federal benefits, that includes FCC benefits. We also declare that the information provided to the FCC is true and correct to the best of our knowledge (47 CFR 2.911(d)) and we have been informed of the grantee responsibilities (47 CFR 2.909) with regard to certified equipment. Thank you, Agency Agreement Expiration Date: (12 months) By: __________________________ Brandon McCollum (Signature) (Print name) Title: Certification Engineer On behalf of: Husqvarna Consumer Outdoor Prod. N.A. Inc. (Company Name) Telephone: +1 (980) 345-1448

Address Contact Registered office VAT no Husqvarna Consumer Outdoor Prod. N.A. Inc. Telephone: Charlotte, NC 0 8825 Statesville Rd Fax: Organization no Charlotte, NC 28269 20-3600732 United States www.husqvarna.com 1 (1) Request for Confidentiality Date: October 27, 2022 Subject: Confidentiality Request for: FCC ID: 2A8U7-VLTR01 and IC ID: 23218-VLTR01 Pursuant to FCC 47 CFR 0.457(d) and 0.459 and/or IC RSP-100, Section 12.4, the applicant requests that a part of the subject application(s) be held confidential. Type of Confidentiality Requested Exhibit ☐ Short Term ☒ Permanent Block Diagrams ☒ Short Term ----------------------- External Photos ☒ Short Term ☐ Permanent * 1 Internal Photos ☐ Short Term ☒ Permanent Operation Description/Theory of Operation ☐ Short Term ☒ Permanent Schematics ☐ Short Term ----------------------- Test Setup Photos ☒ Short Term ☐ Permanent * 1 User’s Manual Husqvarna Consumer Outdoor Products N.A., Inc has spent substantial effort in developing this product and it is one of the first of its kind in industry. Having the subject information easily available to "competition" would negate the advantage they have achieved by developing this product. Not protecting the details of the design will result in financial hardship. Permanent Confidentiality: The applicant requests the exhibits listed above as permanently confidential be permanently withheld from public review due to materials that contain trade secrets and proprietary information not customarily released to the public. Short-Term Confidentiality for FCC Applications: The applicant requests the exhibits selected above as short term confidential be withheld from public view for a period of 180 2 days from the date of the Grant of Equipment Authorization and prior to marketing. This is to avoid premature release of sensitive information prior to marketing or release of the product to the public. Applicant is also aware that they are responsible to notify ACB in the event information regarding the product or the product is made available to the public before the requested period has expired. ACB will then release the documents listed above for public disclosure pursuant to FCC Public Notice DA 04-1705. Short Term Confidentiality for Industry Canada Applications: Starting May 2022, ISED will recognize short term confidentiality on certain exhibits until the intended date of marketing. The applicant requests the exhibits selected above as short term confidential be withheld from public view until: 27 April, 2023. Sincerely, By: __________________________ Brandon McCollum (Signature/Title) (Print name) 1 - The asterisked items (*) require further information to be provided to ACB before permanent confidentiality will be extended to these exhibits. Please refer to FCC KDB 726920 and the specific Document link for D01 found at: https://apps.fcc.gov/oetcf/kdb/forms/FTSSearchResultPage.cfm?switch=P&id=41731 and review section II, 3) regarding specific information that must accompany these requests. 2 - Please refer to https://acbcert.com/documents/misc-docs/Memo-Short-Term-Vs-Standard-Confidentiality.pdf for complete details.

EXTERNAL PHOTOS Company Name Husqvarna Consumer Outdoor Products N.A., Inc Model # 599426001 FCC ID # 2A8U7-VLTR01 IC # 23218-VLTR01 Page 1 of 4 EXTERNAL PHOTOS Company Name Husqvarna Consumer Outdoor Products N.A., Inc Model # 599426001 FCC ID # 2A8U7-VLTR01 IC # 23218-VLTR01 Page 2 of 4 EXTERNAL PHOTOS Company Name Husqvarna Consumer Outdoor Products N.A., Inc Model # 599426001 FCC ID # 2A8U7-VLTR01 IC # 23218-VLTR01 Page 3 of 4 EXTERNAL PHOTOS Company Name Husqvarna Consumer Outdoor Products N.A., Inc Model # 599426001 FCC ID # 2A8U7-VLTR01 IC # 23218-VLTR01 Page 4 of 4

598468601 Art No Compare 5984686 N/Acm 3 Volume MikeWate Designer Checked by 5984686 LABEL Name Drawn byApproved by Original scale Size Sheet Descriptive Name 1:1 MattAlbi 2022-03-24 VOLTRON Date (YYYY-MM-DD)View pos. Treatment Material WHITE VINYL, PLASTIC ADHESIVE CLEAR LAMINATE N/A g 1/1 Analytic weight Units Drawing STD mm Document ID CLT_D1 000 681 906 Local ID This drawing is our exclusive property and is to be returned on request. It must not in any form be used to the prejudice of our interests. © Revision Drawing No ANSI 3 B Tolerances unless otherwise specified acc: 1 PLCS ±.1 2 PLCS ±.06 3 PLCS ±.020 MUST CONFORM TO ASME Y14.5M-1994 "Items shown on this drawing must comply with Husqvarna Group Policy for substances classified as "banned" or "restricted" according to the Husqvarna Group Restricted Materials List. (See www.purchase.husqvarna.com)" Certification Demand 70405 70590 70590 MattAlbi B MattAlbi RvNoZoneDescription of revisionRev byDateECR/ECO A1RELEASE TO PRODUCTIONMattAlbi20220324 B1REMOVED VARIANT 02 (WILL ADD AS REQUIRED)MattAlbi20221111 B2FCC ID AND IC CODES CORRECTEDMattAlbi20221111 598468601 (NOT TO SCALE) 7 9 8 2.46" (62.5mm) 0.59" 2X (15mm) 4X R 0.035" (0.90mm) 6 0.69" (17.4mm) NOTES: 1. REFERENCE HUSQVARNA DRAWING NUMBER 5887025 REV F OR HIGHER FOR LABEL MATERIAL/TREATMENT 2. MUST COMPLY WITH ALL HUSQVARNA GROUP POLICIES ACCORDING TO THE GROUP'S RESTRICTED MATERIALS LIST 3. ADOBE AI FILE LOCATED IN SMARTEAM ATTACHED TO THE ARTICLE NUMBER 4. EXAMPLE QR CODE CONTENT: "https://www.hqr.codes/?HID=910450713ORA2018020012357&IPR=123E4567-e89b-a456-426655440000" - URL WITH PARAMETER SEPARTED BY "?" i.e. URL?HID&IPR, SHOULD BE USED - URL: https://www.hqr.codes (21 CHARACTERS) - IPRID: 123e4567-e89b-12d3-a456-426655440000 (36 CHARACTERS) - HID: 910450713ORA2018020012357 (25 CHARACTERS) - "/?", "HID=", AND "&IPR" AS PARAMETERS (11 CHARACTERS) - TOTAL CHARACTER COUNT = 93 5. MINIMUM QR CODE SIZE TO BE 13mm = (100/10)*33/25 FOR VERSION 4 & 15mm = (100/10)*37/25 FOR VERSION 5 - VERSION 5 WITH LEVEL M CORRECTION (122 CHARCATERS), VERSION 4 WITH LEVEL L CORRECTION (114 CHARACTERS) - EACH OF THE DATA DOTS SHOULD BE AT LEAST 0.4mm ACROSS 6. USE FONT ARIAL, NARROW BOLD (5.55 pt) 7. USE FONT ARIAL, NARROW (5.55 pt) 8. USE FONT ARIAL, NARROW (4.85 pt) 9. USE FONT ARIAL, NARROW BOLD (5.25 pt) LABEL INSTALLED VIEW (FOR ORIENTATION PURPOSES ONLY)

INTERNAL PHOTOS Company Name Husqvarna Consumer Outdoor Products N.A., Inc Model # 599426001 FCC ID # 2A8U7-VLTR01 IC # 23218-VLTR01 Page 1 of 2 INTERNAL PHOTOS Company Name Husqvarna Consumer Outdoor Products N.A., Inc Model # 599426001 FCC ID # 2A8U7-VLTR01 IC # 23218-VLTR01 Page 2 of 2

A Company: Husqvarna Page 1 of 13 Name: Voltron20x Report: TR3614D Model: 599426001 Quote: 319494 Serial: Engineering Sample Test Report C-3614D Equipment Under Test: Voltron20x Requirement(s): FCC 1.1310 ISED RSS-102 Test Date(s): 8/30/2022 Prepared for: Husqvarna Attn: Matt Albinger 9335 Harris Corners Parkway Suite Charlotte, NC 28269 Report Issued by: Anthony Smith, EMC Engineering Specialist Signature: Date: 11/16/2022 Report Reviewed by: Adam Alger, Laboratory Manager Signature: Date: 11/16/2022 Report Constructed by: Anthony Smith, EMC Engineering Specialist Signature: Date: 11/16/2022 This test report may not be reproduced, except in full, without approval of Laird Connectivity LLC Company: Husqvarna Page 2 of 13 Name: Voltron20x Report: TR3614D Model: 599426001 Quote: 319494 Serial: Engineering Sample CONTENTS Contents ........................................................................................................................................................ 2 Laird Connectivity Test Services in Review ............................................................................................... 3 1 Test Report Summary ........................................................................................................................... 4 2 Client Information ................................................................................................................................. 5 2.1 Equipment Under Test (EUT) Information .................................................................................... 5 2.2 Product Description ...................................................................................................................... 5 2.3 Modifications Incorporated for Compliance ................................................................................. 5 2.4 Deviations and Exclusions from Test Specifications ..................................................................... 5 2.5 Additional Information .................................................................................................................. 5 3 References ............................................................................................................................................ 6 4 Uncertainty Summary ........................................................................................................................... 7 5 Test Data ............................................................................................................................................... 8 5.1 Antenna Port Conducted Emissions .............................................................................................. 8 6 FCC 1-G SAR Test Exclusion Calculations ............................................................................................ 11 6.1 Power Calculations ...................................................................................................................... 11 6.2 Distance ....................................................................................................................................... 11 6.3 SAR Test Exclusion Calculation .................................................................................................... 11 6.4 Result .......................................................................................................................................... 11 7 IC Exemption Calculation for Routine SAR Evaluation ........................................................................ 12 7.1 Power Calculations ...................................................................................................................... 12 7.2 Distance ....................................................................................................................................... 12 7.3 Exemption Limits ......................................................................................................................... 12 7.4 SAR Test Exclusion Calculation .................................................................................................... 12 7.5 Result .......................................................................................................................................... 12 8 Revision History .................................................................................................................................. 13 Company: Husqvarna Page 3 of 13 Name: Voltron20x Report: TR3614D Model: 599426001 Quote: 319494 Serial: Engineering Sample Laird Connectivity Test Services in Review The Laird Connectivity LLC laboratory located at W66 N220 Commerce Court Cedarburg, Wisconsin, 53012 USA is recognized through the following organizations: A2LA – American Association for Laboratory Accreditation Accreditation based on ISO/IEC 17025:2017 with Electrical (EMC) Scope A2LA Certificate Number: 1255.01 Scope of accreditation includes all test methods listed herein unless otherwise noted Federal Communications Commission (FCC) – USA Accredited Test Firm Registration Number: 953492 Recognition of two 3 meter Semi-Anechoic Chambers Innovation, Science and Economic Development Canada Accredited U.S. Identification Number: US0218 Recognition of two 3 meter Semi-Anechoic Chambers Company: Husqvarna Page 4 of 13 Name: Voltron20x Report: TR3614D Model: 599426001 Quote: 319494 Serial: Engineering Sample 1 TEST REPORT SUMMARY During 8/30/2022 the Equipment Under Test (EUT), Voltron, as provided by Husqvarna was tested to the following requirements: Requirements Description Method Result FCC: 1.1310 IC: RSS-102 Radiofrequency Radiation Exposure Limits Distance ≤ 5mm 1g-SAR Reported Notice: The results relate only to the item tested as configured and described in this report. Any additional configurations, modes of operation, or modifications made to the equipment under test after the specified test date(s) are at the decision of the client and may not apply…

Text truncated - open the document above for the full version.

A Company: Husqvarna Page 1 of 33 Name: Voltron20x Report: TR3614A Model: 599426001 Quote: 319494 Serial: Engineering Sample Test Report C-3614A Equipment Under Test: Voltron20x Requirement(s): FCC 15.247, RSS-247 Test Date(s): 8/29/2022-8/31/2022 Prepared for: Husqvarna Attn: Matt Albinger 9335 Harris Corners Parkway Suite Charlotte, NC 28269 Report Issued by: Anthony Smith, EMC Engineering Specialist Signature: Date: 11/16/2022 Report Reviewed by: Adam Alger, Laboratory Manager Signature: Date: 11/16/2022 Report Constructed by: Anthony Smith, EMC Engineering Specialist Signature: Date: 11/16/2022 This test report may not be reproduced, except in full, without approval of Laird Connectivity LLC Company: Husqvarna Page 2 of 33 Name: Voltron20x Report: TR3614A Model: 599426001 Quote: 319494 Serial: Engineering Sample CONTENTS Contents ........................................................................................................................................................ 2 Laird Connectivity Test Services in Review ............................................................................................... 3 1 Test Report Summary ........................................................................................................................... 4 2 Client Information ................................................................................................................................. 5 2.1 Equipment Under Test (EUT) Information .................................................................................... 5 2.2 Product Description ...................................................................................................................... 5 2.3 Modifications Incorporated for Compliance ................................................................................. 5 2.4 Deviations and Exclusions from Test Specifications ..................................................................... 5 2.5 Additional Information .................................................................................................................. 5 3 References ............................................................................................................................................ 6 4 Uncertainty Summary ........................................................................................................................... 7 5 Test Data ............................................................................................................................................... 8 5.1 Antenna Port Conducted Emissions .............................................................................................. 8 5.2 Radiated Emissions ..................................................................................................................... 25 6 Revision History .................................................................................................................................. 33 Company: Husqvarna Page 3 of 33 Name: Voltron20x Report: TR3614A Model: 599426001 Quote: 319494 Serial: Engineering Sample Laird Connectivity Test Services in Review The Laird Connectivity LLC laboratory located at W66 N220 Commerce Court Cedarburg, Wisconsin, 53012 USA is recognized through the following organizations: A2LA – American Association for Laboratory Accreditation Accreditation based on ISO/IEC 17025:2017 with Electrical (EMC) Scope A2LA Certificate Number: 1255.01 Scope of accreditation includes all test methods listed herein unless otherwise noted Federal Communications Commission (FCC) – USA Accredited Test Firm Registration Number: 953492 Recognition of two 3 meter Semi-Anechoic Chambers Innovation, Science and Economic Development Canada Accredited U.S. Identification Number: US0218 Recognition of two 3 meter Semi-Anechoic Chambers Company: Husqvarna Page 4 of 33 Name: Voltron20x Report: TR3614A Model: 599426001 Quote: 319494 Serial: Engineering Sample 1 TEST REPORT SUMMARY During 8/29/2022-8/31/2022 the Equipment Under Test (EUT), Voltron, as provided by Husqvarna was tested to the following requirements: FCC 15.247 / RSS-247, DTS Requirements Description Specification Method Compliant FCC: 15.247 (a)(2) IC: RSS-247 5.2 (a) Digital Modulation System 6 dB bandwidth 500 kHz ANSI C63.10 Yes FCC: 2.1049 IC: RSS-GEN 6.7 Occupied Bandwidth Reported ANSI C63.10 Yes FCC: 15.247 (b)(3) IC: RSS-247 5.4 (d) Maximum Conducted Output Power 30 dBm ANSI C63.10 Yes FCC: 15.247 (e) IC: RSS-247 5.2 (b) Digital Modulation System Power Spectral Density 8 dBm / 3 kHz ANSI C63.10 Yes FCC: 15.247 (d) IC: RSS-247 5.5 RF Spurious Emissions at the Transmitter Antenna Terminal 20 dBc ANSI C63.10 Yes FCC: 15.247 (d) IC: RSS-GEN 8.10 Spurious Radiated Emissions in Restricted Bands FCC 15.209 RSS-GEN 8.9 ANSI C63.10 Yes FCC: 2.1055 (d) IC: RSS-GEN 6.11 Frequency Stability Reported ANSI C63.10 Yes Notice: The results relate only to the item tested as configured and described in this report. Any additional configurations, modes of operation, or modifications made to the equipment under test after the specified test date(s) are at the decision of the client and may not apply to the data seen in this test report. The decision rule for Pass / Fail assessment to the specification or standard listed in this test report has been agreed upon by the client and laboratory to be as follows: Measurement Type Rule Emissions – Amplitude 1 dB below specified limit Emissions – Frequency 1% less than the specification Immunity Tested at specified level Company: Husqvarna Page 5 of 33 Name: Voltron20x Report: TR3614A Model: 599426001 Quote: 319494 Serial: Engineering Sample 2 CLIENT INFORMATION Company Name Husqvarna Contact Person Matt Albinger Address 9335 Harris Corners Parkway Suite 500 Charlotte, NC 28269 2.1 Equipment Under Test (EUT) Information The following information has been supplied by the client Product Name Voltron20x Model Number 599426001 Serial Nu…

Text truncated - open the document above for the full version.

APPLICATION SPECIFICATION REVISION: ECR/ECN INFORMATION: TITLE: 2.4/5GHz Ceramic Antenna Application Specification SHEET No. B EC No: 731890 1 of 25 DATE: 2022/12/13 DOCUMENT NUMBER: CREATED / REVISED BY: CHECKED BY: APPROVED BY: AS-2065140001 Liu Hai Cheng Kang Benson Hung TEMPLATE FILENAME: APPLICATION_SPEC[SIZE_A](V.1).DOC TITLE 2.4/5GHZ CERAMIC ANTENNA TABLE OF CONTENTS 1.0 SCOPE 2.0 PRODUCT DESCRIPTION 3.0 APPLICABLE DOCUMENTS 4.0 ANTENNA PERFORMANCE 5.0 MATCHING NETWORK DESRICPTION 6.0 RECOMMENDED REFLOW CONDITION 7.0 RF PERFORMANCE AS A FUNCTION OF IMPLEMENTATION 8.0 OTHER MOLEX ANTENNA PRODUCTS 9.0 CHANGE HISTORY APPLICATION SPECIFICATION REVISION: ECR/ECN INFORMATION: TITLE: 2.4/5GHz Ceramic Antenna Application Specification SHEET No. B EC No: 731890 2 of 25 DATE: 2022/12/13 DOCUMENT NUMBER: CREATED / REVISED BY: CHECKED BY: APPROVED BY: AS-2065140001 Liu Hai Cheng Kang Benson Hung TEMPLATE FILENAME: APPLICATION_SPEC[SIZE_A](V.1).DOC 2.4/5GHZ CERAMIC ANTENNA 1.0 SCOPE This specification describes the antenna application and surrounding. The information in this document is for reference and benchmark purposes only. Antenna illustrations in this document are generic representations. They are not intended to be an image of any antenna listed in the scope. 2.0 PRODUCT DESCRIPTION 2.1 PRODUCT NAME AND SERIES NUMBER (S) Product name: 2.4/5GHz Ceramic Antenna Series Number: 2065140001 2.2 DESCRIPTION 206514 is a SMT high performance antenna implemented using ceramic with recommendation to meet the customer needs. It is designed to cover the frequency bands from 2.4-2.5GHz and 5.15-5.85GHz. 2.3 PRODUCT STRUCTURE INFORMATION Please refer to PS-2065140001 for full information. ANTENNA 3D VIEW APPLICATION SPECIFICATION REVISION: ECR/ECN INFORMATION: TITLE: 2.4/5GHz Ceramic Antenna Application Specification SHEET No. B EC No: 731890 3 of 25 DATE: 2022/12/13 DOCUMENT NUMBER: CREATED / REVISED BY: CHECKED BY: APPROVED BY: AS-2065140001 Liu Hai Cheng Kang Benson Hung TEMPLATE FILENAME: APPLICATION_SPEC[SIZE_A](V.1).DOC 3.0 APPLICABLE DOCUMENTS DOCUMENT NUMBER DESCRIPTION Sale Drawing (SD) SD-2065140001 Mechanical Dimension of the product Product Specification (PS) PS-2065140001 Product Specification Packing Drawing (PK) PK-2065140001 Product packaging specifications 4.0 ANTENNA PERFORMANCE 4.1 RF TEST CONDITIONS All measurements are done of the antenna mounted on a reference PCB (100*40*0.8mm) with VNA Agilent E5071C and Over-The-Air (OTA) chamber. FIGURE4.1.1 ANTENNA LOADED WITH REFERENCE PCB TESTED WITH VNA E5071C DUT APPLICATION SPECIFICATION REVISION: ECR/ECN INFORMATION: TITLE: 2.4/5GHz Ceramic Antenna Application Specification SHEET No. B EC No: 731890 4 of 25 DATE: 2022/12/13 DOCUMENT NUMBER: CREATED / REVISED BY: CHECKED BY: APPROVED BY: AS-2065140001 Liu Hai Cheng Kang Benson Hung TEMPLATE FILENAME: APPLICATION_SPEC[SIZE_A](V.1).DOC FIGURE4.1.2 ANTENNA LOADED WITH REFERENCE PCB TESTED IN OTA CHAMBER 4.2 ANTENNA PERFORMANCE DESCRIPTION EQUIPMENT REQUIREMENT Frequency Range VNA E5071C 2.4-2.5GHz 5.15-5.85GHz Return Loss VNA E5071C < -8 dB < -5 dB Peak Gain (Max) OTA Chamber 3.5dBi 6.2dBi Average Total Efficiency OTA Chamber >75% >75% Polarization OTA Chamber Linear Input Impedance VNA E5071C 50 ohms Note that the above antenna performance is measured with just the antenna mounted on a reference PCB to similar a free-space condition. When implement into the system, the frequency resonant might be off-tune due to the loading of surrounding components especially metal plane. This off-tune can be compensated through matching. Although module manufacturers specify a peak gain limit, it is based on free-space conditions. The peak gain will be degraded by 1 to 2dBi in the actual implementation as the radiation pattern will change due to the surround components. As such, during selection of antenna, you can select one with high peak gain to compensate for the loss. Molex can offer assistant to choose the best location and best tuning in-order to meet this peak gain requirement. DUT APPLICATION SPECIFICATION REVISION: ECR/ECN INFORMATION: TITLE: 2.4/5GHz Ceramic Antenna Application Specification SHEET No. B EC No: 731890 5 of 25 DATE: 2022/12/13 DOCUMENT NUMBER…
