NIGHT OWL Quick Setup Guide What's in the box CameraBaseCable QSGInstallation Hardware Know your camera LED Motion Sensor Mic Lens infrared lamp Silicone Reset TF Card tray Micro USB Step 1 Download the Night Owl Protect app. Note: You need register a Night Owl account before you can log in. Ensure that your cell phone is on the Wi-Fi network. Step 2 Short press the power button to turn on the camera. And the camera give a voice prompt “Device is ready for use”. Step 3 Camera continues to a voice prompt “Camera is in pairing mode”. And add a camera according to the app’s prompt in Night Owl app. Step 4 During the network connection, the camera will give a voice prompt “Please be patient as camera connects to WIFI”. Step 5 When camera is successfully connected, the camera will give a voice prompt “Woohoo, setup is now complete”. Step 6 Please name your Night Owl camera and now you can into live view. Pairing camera Mounting camera Step 1 Use the provided anchors and screws to mount the wall mount base. If the wall is wooden, you can screw the mount directly. Step 2 Attach your camera to the camera base and secure it by rotating clockwise. Step 3 Adjust the camera's view angle to your preferred position. Note: 1. Avoid installing the camera with the camera lens facing direct sunlight. 2. Mind any plants or objects that may obstruct the view. 3. We suggest you mount the camera within a 30 feet range of your Wi-Fi router. Keep the camera close to the router and camera will have better performance. Notice 1. Please make sure to fully charge the included battery before use the camera. 2. Extreme weather conditions will aect battery eciency. We suggest only operating the camera between -4° to 140° Degrees Fahrenheit. Specification Operating Temperature: -10°C~50°C / 14°F~122°F Resolution: 2560×1440 Lens: 105°Wide Angle Audio: Built-in Mic/Speaker, two-way full duplex Video Compression: H.265 AI: Human Detection and vehicle detection Night Vision: Color mode and Black&White mode Support Platform: Android / iOS Wi-Fi: 802.11 b/g/n/ax – 2.4GHz, 5.8GHz Battery Capacity: 18650 5200mAh 3.7V Weather Resistant: IP65 NEED HELP? For system manuals, troubleshooting guides, FAQs, video tutorials and more: 1.Please visit Support.NightOwlSP.com 2.Enter FBWNIP4U into the Search bar. For more Support Videos, go to www.youtube.com/nightowlsp Why call? Our Support Site Has it All! FCC RADIATION NORM FCC This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. FCC Compliance Statement These limits are designed to provide reasonable protection against frequency interference in residential installation. This equipment generates, uses, and can radiate radio frequency energy, and if not installed or used in accordance with the instructions, may cause harmful interference to radio communication. However, there is no guarantee that interference will not occur in television reception, which can be determined by turning the equipment o and on. Theuser is encouraged to try and correct the interference by one or more of the following measures: Reorient or relocate the receiving antenna. Increase the separation between the equipment and the receiver. Connect the equipment into an outlet on a circuit dierent from that to which the receiver is connected. Consult the dealer or an experienced radio/TV technician for help. CAUTION! The Federal Communications Commission warns the user that changes or modifications to the unit not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment. This equipment should be installed and operated with a minimum distance of 8 inches between the radiator and your body.

Agent Authorization Company:SHARETRONIC DATA TECHNOLOGY (HONG KONG) LIMITED. Address: Room 1904 19/F Tung Wai Commercial Building 109-111 Gloucester Rd Wan Chai HK Product Name: Wire Free Camera with Battery Model Number(s): FBWNIP-4L-BS-U-301 Product Description:Frequency in 2402-2480MHz, BT mode operation In 2412MHz~2462MHz, 2.4G WIFI, In 5180MHz~5240MHz, 5745-5825MHz, WIFI 5G We authorize MiCOM Labs Inc., 575 Boulder Court, Pleasanton, California 94566, USA, to act on our behalf on all matters concerning the certification of above named equipment. We declare that MiCOM Labs Inc. is allowed to forward all information related to the approval and certification of equipment to the regulatory agencies as required and to discuss any issues concerning the approval application. Any and all acts carried out by MiCOM Labs on our behalf shall have the same effect as acts of our own. Signature: Date: 2022-10-13 Name: Awen Feng Title: N/A Company: SHARETRONIC DATA TECHNOLOGY (HONG KONG) LIMITED.

SHARETRONIC DATA TECHNOLOGY (HONG KONG) LIMITED Add: Room 1904 19/F Tung Wai Commercial Building 109-111 Gloucester Rd Wan Chai HK Date: 2022.10.13 FCC ID: 2A8WL-BWNIP-4L-BS Dear Sir/Madam, We, SHARETRONIC DATA TECHNOLOGY (HONG KONG) LIMITED Hereby declares the following statement for Federal Communications Commission, Except the model number is different, everything else is the same.: Product name: Wire Free Camera with Battery Model no.: FBWNIP-4L-BS-U-301, BTWN81-4-3BL-B, CAM-2PK-B4LWNPU-FP-B, CAM-B4LWNPU-FP-B, BWNIP-4L-BS-U-301 Sincerely, Name/Title： Awen Feng Company: SHARETRONIC DATA TECHNOLOGY (HONG KONG) LIMITED Address: Room 1904 19/F Tung Wai Commercial Building 109-111 Gloucester Rd Wan Chai HK Phone: +86 769 86819888 Fax: +86 769 86815888 E-Mail: [email protected]

SHARETRONIC DATA TECHNOLOGY (HONG KONG) LIMITED Office of Engineering Technology Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 USA Date: 2022-10-13 Subject; Request for Confidentiality FCC ID: 2A8WL-BWNIP-4L-BS To Whom It May Concern, Pursuant to the provisions of the Commission’s rules Title 47 Sections §0.457 and §0.459, we are requesting the Commission to withhold the following attachment(s) as confidential documents from public disclosure indefinitely. These documents contain detailed system and equipment descriptions and are considered as proprietary information in operation of the equipment. The public disclosure of these documents might be harmful to our company and would give competitors an unfair advantage in the market. Schematic Diagram Block Diagram Parts List Operational Description Tune-up Procedure In additional to above mentioned documents, in order to comply with the marketing regulations in Title 47 CFR §2.803 and the importation rules in Title 47 CFR §2.1204, while ensuring that business sensitive information remains confidential until the actual marketing of newly authorized devices, we request Short Term Confidentiality of the following attachment(s); External Photos Test Setup Photos Internal Photos User Manual For 45 days, pursuant to Public Notice DA 04-1705. OR For 180 days pursuant to KDB 726920 D01. It is our understanding that all measurement test reports, FCC ID label format and correspondence during the certification review process cannot be granted as confidential documents and this information will be available for public review once the grant of equipment authorization is issued. Sincerely Signature: Name: Awen Feng Title:N/A

FCC ID:2A8WL-BWNIP-4L-BS FCC ID:2A8WL-BWNIP-4L-BS FCC ID:2A8WL-BWNIP-4L-BS FCC ID:2A8WL-BWNIP-4L-BS

FCC ID:2A8WL-BWNIP-4L-BS FCC ID:2A8WL-BWNIP-4L-BS FCC ID:2A8WL-BWNIP-4L-BS FCC ID:2A8WL-BWNIP-4L-BS ANT FCC ID:2A8WL-BWNIP-4L-BS FCC ID:2A8WL-BWNIP-4L-BS

RF Exposureevaluation Exposure category: General population/uncontrolledenvironmentEUT Type: ProductionUnit Device Type: MobileDevice Refer Standard: KDB 447498 D01 General RF Exposure Guidancev06FCC Part 2§2.1091 FCC ID:2A8WL-BWNIP-4L-BS 1. Reference According to §1.1307(b)(1), systems operating under the provisions of this section shallbeoperated in a manner that ensures that the public is not exposed to radio frequencyenergylevel in excess of the Commission’sguidelines. According to §1.1310 and §2.1091 RF exposure iscalculated. KDB447498 D01: Mobile and Portable Devices RF Exposure Procedures andEquipmentAuthorizationPolicies 2. Limit Limits for Maximum Permissible Exposure (MPE)/ControlledExposure Frequency Range(MHz) ElectricField Strength(V/m) MagneticField Strength(A/m) PowerDensity (mW/cm²) AveragingTime (minute) Limits for Occupational/ControlledExposure 0.3 –3.0 614 1.63 (100)* 6 3.0 –30 1842/f 4.89/f (900/f 2 )* 6 30 –300 61.4 0.163 1.0 6 300 –1500 / / f/300 6 1500 –100,000 / / 5 6 Limits for Maximum Permissible Exposure (MPE)/UncontrolledExposure Frequency Range(MHz) ElectricField Strength(V/m) MagneticField Strength(A/m) PowerDensity (mW/cm²) AveragingTime (minute) Limits for Occupational/ControlledExposure 0.3 –3.0 614 1.63 (100)* 30 3.0 –30 824/f 2.19/f (180/f 2 )* 30 30 –300 27.5 0.073 0.2 30 300 –1500 / / f/1500 30 1500 –100,000 / / 1.0 30 F=frequency inMHz *=Plane-wave equivalent powerdensity 3. MPE Calculation Method Predication of MPE limit at a givendistance Equation from page 18 of OET Bulletin 65, Edition97-01 S=PG/4πR² Where: S=powerdensity P=power input toantenna G=power gain of the antenna in the direction of interest relative to an isotropicradiator R=distance to the center of radiation of theantenna 4. Result As declared by the Applicant, the EUT is a wireless device used in a fix application, atleast20 cm from any body part of the user or nearby persons; from the maximum EUT RFoutputpower, the minimum separation distance, r =20cm, as well as the gain of the used BT antenna is 2.04 dBi, the RF power density can beobtained. BLE Freq.(MHz) Output Power (dBm) Targetpo werW/tol erance (dBm) Max tuneuppowe rtolerance (dBm) Outputp ower toantenn a AntGai n(dBi) PowerDensit y atR=20cm (mW/cm2) Limit(mW/ cm2) Result GFSK 2402 3.112 3±1.0 4 2.512 2.04 0.00080 1 Pass 2440 3.253 3±1.0 4 2.512 2.04 0.00080 1 Pass 2480 2.125 2±1.0 3 1.995 2.04 0.00063 1 Pass WIFI 2.4G Modulatio n Type Target power W/ tolerance (dBm) Max tune up power tolerance(dB m) Max Output power to antenna (mW) Antenna Gain Antenna Gain (linear) Power Density at R=20cm (mW/cm2) Limit (mW/cm2) Result 802.11b 18±1.0 19 79.433 2.04 1.60 0.02528 1.0 Pass 802.11g 15±1.0 16 39.811 2.04 1.60 0.01267 1.0 Pass 802.11n (HT20) 15±1.0 16 39.811 2.04 1.60 0.01267 1.0 Pass 802.11n (HT40) 14±1.0 15 31.623 2.04 1.60 0.01006 1.0 Pass 802.11ax (HT20) 14±1.0 15 31.623 2.04 1.60 0.01006 1.0 Pass 802.11ax (HT40) 9±1.0 10 10.000 2.04 1.60 0.00318 1.0 Pass Power Density at R=20cm (mW/cm2) BLE Power Density at R=20cm (mW/cm2) 2.4G WIFI Power Density at R=20cm (mW/cm2) 5.18GHz – 5.24 GHz WIFI ∑MPE ratios Limit (mW/cm2) Result 0.00080 0.02528 0.00974 0.03582 1.0 Pass Power Density at R=20cm (mW/cm2) BLE Power Density at R=20cm (mW/cm2) 2.4G WIFI Power Density at R=20cm (mW/cm2) 5.745 GHz -5.825 GHz WIFI ∑MPE ratios Limit (mW/cm2) Result 0.00080 0.02528 0.00974 0.03582 1.0 Pass Note: The estimation distance is20cm 5. Conclusion The measurement results comply with the FCC Limit per 47 CFR 2.1091 for theuncontrolled RF Exposure of mobiledevice.

Shenzhen DL Testing Technology Co., Ltd. Report No.: DL-20220915012E-1 Test Report Tel: 400-688-3552 Web:www.dl-cert.com Email: [email protected] Page 1 of 51 FCC Test Report FCC ID : 2A8WL-BWNIP-4L-BS Applicant: SHARETRONIC DATA TECHNOLOGY (HONG KONG) LIMITED Address: Room 1904 19/F Tung Wai Commercial Building 109-111 Gloucester Rd Wan Chai HK Manufacturer: EWIC PHILIPPINES INC. Address: BLDG NOS 7&8 L2 B4 EZP Warehouse Laguna Technopark Annex,Barangay BO Binan,Binan,Philippines,4024 EUT: Wire Free Camera with Battery Trade Mark: N/A Model Number: FBWNIP-4L-BS-U-301, BTWN81-4-3BL-B, CAM-2PK-B4LWNPU-FP-B, CAM-B4LWNPU-FP-B, BWNIP-4L-BS-U-301 Date of Receipt: Aug. 29, 2022 Test Date: Aug. 30, 2022 - Oct. 08, 2022 Date of Report: Oct. 09, 2022 Prepared By: Shenzhen DL Testing Technology Co., Ltd. Address: 101-201, Building C, Shuanghuan, No.8, Baoqing Road, Baolong Industrial Zone, Baolong Street, Longgang District, Shenzhen, Guangdong, China Applicable Standards: FCC PART 15 C 15.247 ANSI C63.10:2013 Test Result: Pass Report Number: DL-20220915012E-1 Prepared (Test Engineer): Pxing Huang Reviewer (Supervisor): Jack Bu Approved (Manager): Jade Yang This test report is based on a single evaluation of one sample of above mentioned products. It is not permitted to be duplicated in extracts without written approval of Shenzhen DL Testing Technology Co., Ltd. Shenzhen DL Testing Technology Co., Ltd. Report No.: DL-20220915012E-1 Test Report Tel: 400-688-3552 Web:www.dl-cert.com Email: [email protected] Page 2 of 51 Table of Contents Page 1 . SUMMARY OF TEST RESULTS 4 1.1 TEST FACILITY 5 1.2 MEASUREMENT UNCERTAINTY 5 2 . GENERAL INFORMATION 6 2.1 GENERAL DESCRIPTION OF EUT 6 2.2 DESCRIPTION OF TEST MODES 7 2.3 BLOCK DIGRAM SHOWING THE CONFIGURATION OF SYSTEM TESTED 8 2.4 DESCRIPTION OF SUPPORT UNITS(CONDUCTED MODE) 8 2.5 TABLE OF PARAMETERS OF TEST SOFTWARE SETTING 8 2.6 EQUIPMENTS LIST FOR ALL TEST ITEMS 9 3 . EMC EMISSION TEST 10 3.1 CONDUCTED EMISSION MEASUREMENT 10 3.1.1 POWER LINE CONDUCTED EMISSION LIMITS 10 3.1.2 TEST PROCEDURE 10 3.1.3 DEVIATION FROM TEST STANDARD 10 3.1.4 TEST SETUP 11 3.1.5 EUT OPERATING CONDITIONS 11 3.1.6 TEST RESULTS 11 3.2 RADIATED EMISSION MEASUREMENT 14 3.2.1 RADIATED EMISSION LIMITS 14 3.2.2 TEST PROCEDURE 15 3.2.3 DEVIATION FROM TEST STANDARD 15 3.2.4 TEST SETUP 15 3.2.5 EUT OPERATING CONDITIONS 16 3.2.6 TEST RESULTS (BETWEEN 9KHZ – 30 MHZ) 17 3.2.7 TEST RESULTS (BETWEEN 30MHZ – 1GHZ) 18 3.2.8 TEST RESULTS (1GHZ~25GHZ) 20 3.3 RADIATED BAND EMISSION MEASUREMENT 21 3.3.1 TEST REQUIREMENT: 21 3.3.2 TEST PROCEDURE 21 3.3.3 DEVIATION FROM TEST STANDARD 21 3.3.4 TEST SETUP 22 3.3.5 EUT OPERATING CONDITIONS 22 4.POWER SPECTRAL DENSITY TEST 24 4.1.1 APPLIED PROCEDURES / LIMIT 24 4.1.2 TEST PROCEDURE 24 4.1.3DEVIATION FROM STANDARD 24 4.1.4TEST SETUP 24 Shenzhen DL Testing Technology Co., Ltd. Report No.: DL-20220915012E-1 Test Report Tel: 400-688-3552 Web:www.dl-cert.com Email: [email protected] Page 3 of 51 Table of Contents Page 4.1.5 EUT OPERATION CONDITIONS 24 4.1.6 TEST RESULTS 25 5. CHANNEL BANDWIDTH 27 5.1.1 APPLIED PROCEDURES / LIMIT 27 5.1.2 TEST PROCEDURE 27 5.1.3 DEVIATION FROM STANDARD 27 5.1.4 TEST SETUP 27 5.1.5 EUT OPERATION CONDITIONS 27 5.1.6 TEST RESULTS 28 6.PEAK OUTPUT POWER TEST 30 6.1.1 APPLIED PROCEDURES / LIMIT 30 6.1.2 TEST PROCEDURE 30 6.1.3 DEVIATION FROM STANDARD 30 6.1.4 TEST SETUP 30 6.1.5 EUT OPERATION CONDITIONS 30 6.1.6 TEST RESULTS 31 7. CONDUCTED BAND EDGE AND SPURIOUS EMISSION 33 7.1.1 APPLICABLE STANDARD 33 7.1.2 TEST PROCEDURE 33 7.1.3 DEVIATION FROM STANDARD 33 7.1.4 TEST SETUP 33 7.1.5 EUT OPERATION CONDITIONS 33 7.1.6 TEST RESULTS 33 8. ANTENNA REQUIREMENT 40 8.1 STANDARD REQUIREMENT 40 8.2 EUT ANTENNA 40 9. TEST SEUUP PHOTO 41 10. EUT PHOTO 41 Shenzhen DL Testing Technology Co., Ltd. Report No.: DL-20220915012E-1 Test Report Tel: 400-688-3552 Web:www.dl-cert.com Email: [email protected] Page 4 of 51 1. SUMMARY OF TEST RESULTS Test procedures according to the technical standards: FCC Part15 (15.247) , Subpart C Standard Section Test Item Judgment Remark 15.207, Conducted Emission PASS 15.205/15.209, Radiated Emission and Restricted Bands PASS 15.247(b)(3), Conducted Peak Output Power PASS 15.247 (d), Conducted Unwanted Emission and Bandedge PASS 15.247(a)(2), 6dB Bandwidth& 99% OCB PASS 15.247 (e), Power Spectral Density PASS 15.203/15.247 (c), Antenna Requirement PASS NOTE: (1)” N/A” denotes test is not applicable in this Test Report Shenzhen DL Testing Technology Co., Ltd. Report No.: DL-20220915012E-1 Test Report Tel: 400-688-3552 Web:www.dl-cert.com Email: [email protected] Page 5 of 51 1.1 TEST FACILITY Shenzhen DL Testing Technology Co., Ltd. Add. : 101-201, Building C, Shuanghuan, No.8, Baoqing Road, Baolong Industrial Zone, Baolong Street, Longgang District, Shenzhen, Guangdong, China FCC Test Firm Registration Number: 854456 Designation Number: CN1307 ISED Registration number: 27485 IC Registered No.:CN0118 1.2 MEASUREMENT UNCERTAINTY The reported uncertainty of measurement y ± U, where expended uncertainty U is based on a standard uncertainty multiplied by a coverage factor of k=2,providing a level of confidence of approximately 95 %. No. Item Uncertainty 1 Conducted Emission Test ±2.56dB 2 RF power,conducted ±0.42dB 3 Spurious emissions,conducted ±2.76dB 4 All emissions,radiated(<1G) ±3.65dB 5 All emissions,radiated(>1G) ±4.89dB 6 Temperature ±0.5°C 7 Humidity ±2% Shenzhen DL Testing Technology Co., Ltd. Report No.: DL-20220915012E-1 Test Report Tel: 400-688-3552 Web:www.dl-cert.com Email: [email protected] Page 6 of 51 2. GENERAL INFORMATION 2.1 GENERAL DESCRIPTION OF EUT Product Name: Wire Free Camera with Battery Test Model No.: FBWNIP-4L-BS-U-301 Sample ID: DL-20220915012E-1# Serial No.: BTWN81-4-3BL-B, CAM-2PK-B4LWNPU-FP-B, CAM-B4LWNPU-FP-B, BWNIP-4L-BS-U-301 Model Difference PCB board, circuit, structure and internal of these model(s) are the same, Only model name is different for these model. Operat…
