1 14.12.2022 rev1 FX True Ballistic Chronograph Quick Start To use the chronograph, follow these steps: • Remove the chronograph from the table stand and connect it to a tripod or the table stand. • Place the chronograph next to the gun and aim it at the target you plan to shoot. • Press the power button to turn on the chronograph. • Once the chronograph has started up, press the power button again to activate it. • Shoot. 2 Manual 1. SETUP During transport, the chronograph can be placed inside the table stand. To set up the chronograph, first push it out of the table stand from the tabs located on the sides of the unit. Then, connect the chronograph to the stand, or alternatively, use a tripod. The power button for the chronograph is located below the display of the device. Next to the power button, you will find a USB-C charging port and charging LEDs. To turn on the chronograph, press the power button. To turn it off, press and hold the power button. The chronograph will automatically shut down after a period of inactivity to save power. To To activate the chronograph, press the power button after the initial boot sequence. 3 2. CHARGING The chronograph has a lithium ion battery that should be charged before using it for the first time. Use the supplied USB-A to USB-C cable to charge the battery. While the battery is charging, the LED lights on the side of the USB port will show the charging progress. A solid red light (only) means that the battery is almost empty, while a solid green light indicates that charging is complete. A flashing green light means that the battery level is more than 75% 3. POSITIONING THE CHRONOGRAPH The best placement for the chronograph is behind the muzzle and close to the barrel on either side of the gun. The barrel of the gun should be positioned vertically between the top and bottom of the device, with the middle being the optimal placement. The performance of the chronograph improves when it is positioned close to the barrel because this reduces the cosine error, which can affect the accuracy of the readings. Cosine error is a type of error that can arise when measuring the velocity of projectiles with radar technology, and it is caused by the angle at which the radar beam hits the projectile. By positioning the chronograph close to the barrel, you can reduce the cosine error and improve the accuracy of the readings. If the chronograph needs to be positioned away from the barrel, make sure to set the correct Barrel Offset in the configuration menu. The default setting for Barrel Offset is 0”-8”. This ensures that the chronograph accurately measures the bullet's velocity. It is important not to place other devices, such as other velocity chronographs, in front of the radar when using the chronograph. This can interfere with the accuracy of the readings. 4 ALTERNATIVE POSITIONS FOR THE CHRONOGRAPH Positioning the chronograph next to the muzzle, or in front of it, is only possible when the gun has a very light muzzle blast. The intense pressure and heat generated by the gun when it is fired can damage the chronograph if it is positioned too close to the muzzle. Therefore, it is important to position the chronograph carefully to avoid damage and ensure accurate measurements. If the gun has a strong muzzle blast, it is necessary to position the chronograph further away from the muzzle. While it is possible to position the chronograph behind the shooter, keep in mind that the shooter may block the field of view to the muzzle. If this occurs, the chronograph will not trigger at the muzzle and the recorded velocity will be in front of the muzzle. To avoid this issue, position the chronograph so that it has a clear view of the muzzle. This will ensure that the chronograph triggers at the correct time and provides an accurate measurement of the bullet's velocity. Positioning the chronograph away from the barrel is not recommended because it increases the angle between the radar beam and the bullet trajectory. This can cause the chronograph to provide inaccurate measurements of the bullet's velocity. If it is necessary to use this position, make sure to set the correct Barrel Offset in the device's configuration menu. This will help to counteract the effects of cosine error, which can cause the chronograph to provide inaccurate measurements when the angle between the radar beam and bullet trajectory is large. Barrel Offset (max 20”) 5 4. ALIGNING AND TRIGGERING To use the chronograph, first aim the sight on top of it at the target. The triangle shape on the top view of the chronograph represents the radar cone, with the middle part indicating the strongest signal and the side parts indicating weaker signals. A radar cone is a term used to describe the shape and direction of a radar beam. When a radar signal is transmitted, it spreads out in a cone shape, with the narrowest part of the cone at the point where the signal is emitted. As the signal travels farther from the source, the cone widens. The radar cone is important because it determines the area that the radar can detect and the direction in which it can detect objects. Because the strong signal emitted by the chronograph is very narrow, it is important to aim the device carefully for accurate results. The weak signal is also important, as it is used for triggering the chronograph. When the bullet enters the radar cone (indicated by the weak signal), the chronograph is triggered. If the chronograph is not positioned with a clear line of sight to the muzzle, it will trigger slightly after the bullet exited the muzzle and will not be able to accurately measure the velocity at the muzzle. For accurate results, the chronograph should have a clear line of sight to the target, which should be at least 25 yards away. The absolute minimum distance is 15 yards. Any obstacles in the line of sight may affect the accuracy of the readings or cause the chronograph to fail to trigger correctly. Metal or concrete surfaces i…
